Page 1

Digital Cordless Phone

Model No. KX-TCD700NL

Operating Instructions

Charge the batteries for approx. 10 hours before initial use.

Caller ID Compatible

PLEASE READ BEFORE USE AND SAVE

30401 English KX-TCD700NL 25/4/01 2:31 pm Page 1

Page 2

Thank you for purchasing your new Panasonic digital cordless telephone.

For your future reference

Serial No. Date of purchase (found on the bottom of the unit)

Name and address of dealer

Accessories included

AC Adaptor

one

Telephone Line Cord

one

Batteries

Panasonic AA(R6)P-6P

two (AA size)

Battery Cover

one

Belt Clip

one

Dear purchaser,

You have acquired a KX-TCD700NL, which is a product made in regard with the European Standards for Cordless Telephones (DECT). DECT technology is characterized by high-security protection against interceptions as well as high-quality digital transmission. This telephone was designed for a wide range of applications. For example, this telephone can be used within a network of base units and handsets, constituting a telephone system which:

• operates up to 6 handsets at one base unit

• allows an intercom between handsets

• allows the operation of a handset at up to 4 base units, expanding the communication radio area.

This telephone may be used for:

• operating several handsets

• operating at several base units

• connecting the base unit to a PBX.

30401 English KX-TCD700NL 25/4/01 2:31 pm Page 2

Page 3

Safety Instructions

Take special care to follow the safety suggestions listed below.

Environment

1) Do not use this unit near water—for example, near a bathtub, washbowl, sink, etc. Damp basements should also be avoided.

2) The unit should be kept away from heat sources such as radiators, cookers, etc. It also should not be placed in rooms where the temperature is less than 5°C or greater than 40°C.

3) The AC adaptor is used as the main disconnect device, ensure that the AC outlet is located/installed near the unit and is easily accessible.

Placement

1) Do not place heavy objects on top of this unit.

2) Care should be taken so that objects do not fall onto, and liquids are not spilled into, the unit. Do not subject this unit to excessive smoke, dust, mechanical vibration or shock.

3) Place the unit on a flat surface.

Lightning Surge

This unit has already been equipped with a built-in lightning protection circuit. However, we recommend that you install the following options, if your area has frequent lightning strikes.

1) Lightning protection on the telephone line.

2) Lightning protection on the power source.

To install the above options, please contact your local sales shop.

• Lightning damage is not covered in the warranty even if lightning protection is installed.

WARNING:

TO PREVENT THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR ANY TYPE OF MOISTURE.

If there is any trouble, disconnect the unit from the telephone line and connect a known working phone. If the known working phone operates properly, do not reconnect the unit to the telephone line until the problem has been repaired. If the known working phone does not operate properly, consult your telephone company.

30401 English KX-TCD700NL 25/4/01 2:31 pm Page 3

Page 4

Contents

Chapter 1

Preparation

Chapter 3

Programmable Functions (On the Handset)

Chapter 2

(Basic Operations)

Getting Started ................................6

Connections....................................6

Installing the Batteries in the

Handset..........................................7

Battery Charge ...............................7

Battery Information.........................7

Battery Replacement......................8

Base Unit Location.........................8

Wall Mounting.................................9

Location of Controls......................10

Displays..........................................11

Basic Start-up Operations ............12

Summary of Programmable

Functions........................................27

Setting Time Alarm Function........28

Set Time of Alarm.........................28

Set Alarm ON/OFF .......................28

Setting Ringer Options .................29

Select Handset Ringer Volume....29

Select Ringer Pattern for

External Incoming Calls................29

Select Ringer Pattern for Internal

Call ...............................................29

Select Ringer Pattern for Paging

Tone..............................................29

Select Ringer Pattern for Alarm

Tone..............................................29

Setting T one Options.....................30

Set Key Confirmation Tone

ON/OFF........................................30

Set Call Waiting Tone ON/OFF ....30

Set Range Warning Alarm

ON/OFF........................................30

Set Battery Low Tone ON/OFF ....30

Setting Display Options................31

Select the Standby Mode Display31

Select the Talk Mode Display.......31

Setting Call Options ......................32

Set Direct Call Number ................32

Set Direct Call ON/OFF................33

Set Call Prohibition .......................33

Setting Other Options ...................34

Set Auto T alk ON/OFF..................34

Select Battery Type......................34

Change Handset PIN ...................35

Registration....................................36

Registering a Handset to a

Base Unit......................................36

Cancelling a Base Unit.................37

Select Base Unit ............................38

Reset Handset ................................39

Making Calls ...................................13

To Select the Receiver Volume.....14

Answering Calls .............................15

Speed Dialling ...............................16

Caller ID Service ............................19

Using the Caller List ......................21

For Optional Multi-Unit Users.......22

Paging/Intercom.............................23

Special Features............................25

How to Use the Pause Feature (For Analog PBX Line/Long Distance Service Users)

..............25

Using the Recall Feature..............25

Setting the Key Lock ON/OFF......26

30401 English KX-TCD700NL 25/4/01 2:31 pm Page 4

Page 5

Chapter 4

Programmable Functions (On the Base Unit)

Programmable Functions (On

the Base Unit) ................................40

Bell Selection................................40

Select Base Unit Ringer Volume ..41

Setting the Clock..........................41

Select Earth/Flash Mode..............42

Select Pause Timing.....................42

Set Base Unit PIN ........................43

Cancelling a Handset...................43

Call Restriction .............................44

Set Auto Route Selection..............45

Storing the Carrier Code ..............45

Storing the Area Code(s)..............46

Using International Carrier

Services........................................47

Reset Base Unit .............................48

Option Covers................................49

Using the Belt Clip.........................50

Before Requesting Help................51

Chapter 5

Useful Information

30401 English KX-TCD700NL 25/4/01 2:31 pm Page 5

Page 6

Connections

Plug in the AC Adaptor and the telephone line cord to the rear of the unit. Then connect the cord as shown.

Getting Started

USE ONLY WITH Panasonic AC ADAPTOR PQLV1CE.

• Be careful not to confuse the telephone line jack with the AC adaptor jack on the base unit. If connected improperly, the base unit will not work and damage may occur.

• The AC Adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.)

• If your unit is connected to a telephone line or PBX which does not support Caller ID services, you cannot access those services.

• The unit will not work during a power failure. We recommend you connect a standard telephone on the same line for power protection.

To Power Outlet (AC 230V, 50Hz)

AC Adaptor

Telephone Line Cord

To Single-Line Telephone Jack

Fasten the AC adaptor cord to prevent it from being disconnected

30401 English KX-TCD700NL 25/4/01 2:31 pm Page 6

LINE

Hook

Fasten the AC adaptor cord to prevent it from being disconnected

Page 7

➡

Installing the Batteries in the Handset

Battery Strength

You can check the present battery strength on the display.

Battery strength Fully charged Medium Low No power

Battery icon ÒÚ ÛÛ

(Flashing)

Recharge

When “Û” flashes or the unit beeps every 15 seconds, recharge the batteries.

• If the

rechargeable batteries are not inserted correctly, the handset will not work.

Chapter 1

Battery Information

After your batteries are fully charged:

• Battery life may vary depending on usage conditions, such as: – when viewing the Caller ID Caller List, and – ambient temperature.

• Clean the handset charge contacts with a soft, dry cloth once a month.

Clean more often if the unit is subject to grease, dust or high humidity.

Otherwise the batteries may not charge properly.

• If the batteries are fully charged, you do not have to place the handset on the base unit until “Û” flashes. This will maximise the battery life.

• The batteries cannot be overcharged.

Operation Ni-MH battery life (Included) Ni-Cd battery life (optional)

While in use (Talk) Up to about 20 hours Up to about 12 hours (based on 800m/A per hour)

While not in use (Standby) Up to about 160 hours Up to about 100 hours

Battery Charge

At the time of shipment, the batteries are not charged. To charge, place the handset on the base unit. Please charge the batteries for approximately 10 hours before initial use. During charging, the battery icon is as shown above.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 7

Page 8

Battery Caution:

To reduce the risk of fire or injury to persons, read and follow these instructions.

1. Use only the batteries specified.

2. Do not use non-rechargeable batteries.

3. Do not mix old and new batteries.

4. Do not dispose of the batteries in a fire, they may explode. Check with local

waste management codes for special disposal instructions.

5. Do not open or mutilate the batteries. Released electrolyte is corrosive and

may cause burns or injury to the eyes or skin. The electrolyte may be toxic if swallowed.

6. Exercise care in handling the batteries in order not to short the batteries with

conductive materials such as rings, bracelets, and keys. The batteries and/or conductor may overheat and cause burns.

7. Charge the batteries provided with or identified for use with this product only

in accordance with the instructions and limitations specified in this manual.

• Bij dit produkt zijn batterijen geleverd. Wanneer deze leeg zijn, moet u ze niet weggooien maar inleveren als KCA.

➡ Getting Started

Battery Replacement

If “Û” flashes after a few telephone calls even when the handset batteries have been fully charged, it is time to replace the batteries with new ones.

Remember to charge the new batteries after replacement (see page 7).

• Discard defective batteries as soon as possible. Defective batteries may leak into the unit.

For maximum distance and noise-free operation, the recommended base unit location is:

• Away from electrical appliances such as TV, radio, personal computer or another telephone.

• In a convenient high and central location.

Base Unit Location

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 8

Niet

weggooien,

maar inleveren

als KCA.

Page 9

Wall Mounting

This unit can be mounted on a wall.

• Install screws using the wall template below.

• Connect the line cord, and AC Adaptor.

• Arrange the wires as shown, then mount the unit.

6cm

WALL TEMPLATE

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 9

Page 10

Location of Controls

Base Unit

Handset

Page Button

Charge Contacts

Display

Receiver

(Function/OK) Button

P (Talk Off/Power) Button

N (Intercom) Button

Charge Contact

Microphone

M (Recall) Button

(Speed Dial) Button

O (Talk) Button

Navigator Key ( , , , )

Charge Contact

W (Cancel) Button

X (Redial/

Pause) Button

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 10

Page 11

Displays

Handset Display

Icons

(The display shows all possible configurations)

Î The in-range icon indicates that

the handset is in range of the base unit. It flashes when the handset is out of range.

Ï The page/intercom icon is

displayed when paging or using the intercom. It flashes when another unit pages the handset.

 The talk icon is displayed when

making or answering calls. It flashes when an outside call is being received.

Ë The direct call icon is displayed

when this mode is turned on.

Ô The call prohibition icon is displayed

when this mode is turned on.

Â The program icon indicates that the

unit is in the programming mode.

È The ringer off icon indicates that

ringer tone is temporarily turned OFF.

Ò The battery icon indicates the

battery strength.

Ó The Key Lock icon is displayed

when key lock is set on the handset. In this mode, keypad is disabled.

Á The speed dial icon is displayed

when this mode is turned on.

LCD

Note: The LCD on your handset is a 7 segment display and each character will be displayed as shown in the table above. Some displayed characters differ e.g. character M is displayed as m. This is not a fault of the display and is normal display condition.

Symbols Used

Z shows that you should press the following key(s).

888888888888

ВКБЛИН ОПФУТ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 11

Page 12

Making a Call

(For further information on making calls, see pages 13-14.)

1. ZO

2. Dial a phone number

The dialled number is displayed. (If a number is entered incorrectly, ZP).

After a few seconds, the display will start showing the length of the call.

Terminating a Call

1. To hang up, ZP.

• The handset will return to the standby mode.

• The dialled number is stored in the redial memory.

Turning the Power On

1. Z and hold P

• After all characters briefly appear, a confirmation tone sounds. The display will change to the standby mode when the button is released.

• The current connected base unit number is displayed (–1–)

• The number of New Caller ID calls received are displayed (eg. 02)

• You can choose whether to display the base unit number, handset number,

clock or no display in the standby mode (see page 31).

Basic Start-up Operations

-1-œœœœœœœ02

Î Ò

Answering a Call

(For further information on answering calls, see page 15.)

1. ZO

• You can also answer a call by pressing any dialling button

K to I, J or L (-Any Key Answer).

After a few seconds, the display will start showing the length of the call.

Turning the Power Off

Make sure that the unit is in the standby mode.

1. Z and hold P until a long beep sounds.

• The display will go blank. (On location of the handset in the base unit, the battery icon will display even after power off).

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 12

Page 13

Making Calls ➡

Note: for basic making calls operation, see page 12.

To Dial after Confirming the Entered Number

With this feature you are able to confirm the entered number before you start dialling.

1. Dial a Phone Number

If number is not entered correctly: To clear one digit, ZWbriefly. To clear all digits, Z and hold W.

2. Phone number confirmed, ZO

(After a few seconds, the length of call is displayed).

3. To end call, ZP.

(After a few seconds, the display returns to the standby

mode).

• Note: If Î flashes and an alarm tone sounds after pressing O, move closer to the base unit. Then try again.

To Redial the Last Number Dialled

1. ZO

2. ZX

(The last number dialled is displayed and automatically redialled).

• After a few seconds, the length of call is displayed.

To Redial after Confirming the Numbers in Redial Memory

The unit automatically stores the last 10 numbers dialled into redial memory.

(The last number dialled is displayed).

2. ZSor U to select required number

(To exit the list, ZW).

3. ZO

(After a few seconds the length of call is displayed).

0123456789

ВКБЛИН

Î ÏÔÓÒ

0123456789

ВКБЛИН

Î Ï  ÔÓÒ

00-00-31

ВКБЛИН

Î Ï  ÔÓÒ

-1-œœœœœœœ02

ВКБЛИН

Î ÏÔÓÒ

0123456789

ВКБЛИН

Î Ï  ÔÓÒ

00-00-00

ВКБЛИН

Î Ï  ÔÓÒ

0123456789

ВКБЛИН

Î ÏÔÓÒ

00-00-00

ВКБЛИН

Î Ï  ÔÓÒ

Chapter 2

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 13

Page 14

➡ Making Calls

To Edit/Clear Numbers in the Redial List

To edit and clear numbers in the redial memory, press X, select number and then follow from step 2 (page 20).

Direct Call

You can store one number into memory and then call this number by pressing O. Incoming calls are accepted. To use this feature, store the direct call number and turn on the mode by programming (see page 32). The factory pre-set is OFF.

Dialling the Stored Number

Make sure that “Ë” is displayed (see page 32), then ZO.

• The number stored in the direct call memory is dialled automatically.

• When the handset is in “direct call”mode, it is not possible to make any

calls until direct call is cancelled.This also includes emergency calls.

To Select the Receiver Volume

3 levels (HIGH, MEDIUM, LOW) are available. The factory pre-set is MEDIUM.

1. During conversation, ZSor U to select level

S = receiver volume up U = for receiver volume down

⁄⁄⁄

= HIGH, ⁄⁄= MEDIUM, ⁄= LOW

2. After volume selection, ZW

(The display returns to length of call, etc).

Dialling a Stored Hot Key Number

(To register a number as Hot Key, see page 17). You can assign up to 9 phone numbers in the speed dial list as hot key dials. The

dialling buttons (A to I) function as memory stations.

1. Z and hold a memory station number (A to I).

• The stored number is displayed.

• To search for a number, ZUor S until the desired number is displayed.

2. ZO

• The number is dialled automatically.

3. To hang up, ZP.

S U

00-00-31

ВКБЛИН

Î Ï  ÔÓÒ

vol

⁄⁄⁄

ВКБЛИН

Î Ï  ÔÓÒ

vol⁄œœ

ВКБЛИН

Î Ï  ÔÓÒ

00-00-36

ВКБЛИН

Î Ï  ÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 14

Page 15

Answering Calls

For basic answering call operation, see page 12.

• The handset and base unit will not ring if both ringer volumes are set to OFF (p. 29, 41).

Auto T alk

If you set the Auto Talk Feature to ON (p. 34), you can answer a call by lifting the handset off the base unit without pressing O.

To Turn the Handset Ringer Off Temporarily

When an external call is incoming, user can turn off ringer temporarily.

1. During incoming call, Z and hold U.

(Bell off symbol is displayed and the handset stops ringing).

2. Answer call by pressing O, K-I, J or L (-Any

Key Answer).

• The ringer will turn back on for the next call.

• This function will not work when the handset is on the base

unit or if an internal call is incoming.

Lighted Handset Keypad

The handset dialling buttons will light when you press a button, lift the handset off the base unit or receive a call. The lights will go out about 10 seconds after pressing a button, lifting the handset or answering a call.

888888888888

ÂÊÁËÈ Í

Î Ï  ÔÓÒ

00-00-00

ВКБЛИН

Î Ï  ÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 15

Page 16

Speed Dialling

Storing Phone Numbers in Memory

You can store up to 20 telephone numbers in the handset.

Storing new numbers

1. ZYor V

2. ZYor V

(Speed dial is selected, speed dial icon is displayed Á).

3. Enter phone number (Up to 24 digits)

(Phone numbers are displayed from the left edge of the LCD).

• If a pause is required for dialling, ZXwhile entering number. Pressing X counts as one digit.

4. ZY

(Speed dial is saved (saved) - a confirmation tone sounds) (After 2 seconds, next index list No. is displayed. If user wants to continue, start again from step 3).

• If speed dial memory is full, ‘memory full’ is displayed.

5. ZWor T (twice) or P (once).

The display returns to the standby mode.

Dialling a Stored Number

There are 3 ways to display the speed dial list, (scrolling, jumping and hot key).

To register a speed dial to hot key, see page 17.

Displaying the list by Scrolling/Jumping.

1. ZÁ

2. (Scrolling) ZSor U to select phone number.

(Jumping) Z 00 to 19 to select Index No.

3. ZO

To exit speed dial memory, ZW.

• If no digits are input over 1 minute, speed dial is cancelled and display returns to standby mode.

new speed

ВКБЛИН

Î ÏÔÓÒ

00-É00000000

Â Ê Á ËÈÍ Î ÏÔÓÒ

-1-1 01

ВКБЛИН

Î ÏÔÓÒ

00-1234567É0

Â Ê Á ËÈÍ Î ÏÔÓÒ

saved

Â Ê Á ËÈÍ Î ÏÔÓÒ

-1-1 01

ВКБЛИН

Î ÏÔÓÒ

memory full

Â Ê Á ËÈÍ Î ÏÔÓÒ

01-É

Â Ê Á ËÈÍ Î ÏÔÓÒ

(Standby Mode)

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 16

Page 17

➡

Speed Dial Menu

In the speed dial menu, it is possible to carry out the following operations:

• Edit a speed dial number (edit).

• Clear a speed dial number (clear).

• Register a speed dial number to Hot Key (hot key reg).

(Standby Mode)

01-111222333

ÂÊÁ ËÈÍ

Î ÏÔÓÒ

• If key is already related to speed dial no., the key no. flashes.

• Select key (eg.2)

ZYor V

• A confirmation tone sounds.

• Display returns to standby mode.

or V

• Select key (1-9)

3. ZYor V

or V

• The number to edit flashes.

• To clear

ZW.

• New digits are added to the left of the flashing digit.

• To move cursor

Z T V.

• When No. is confirmed.

• Speed dial is saved.

• A confirmation tone

sounds.

ZYor V

edit

Â Ê Á ËÈÍ Î ÏÔÓÒ

clear

Â Ê Á ËÈÍ Î ÏÔÓÒ

hot key reg

Â Ê Á ËÈÍ Î ÏÔÓÒ

01-Ü11222333

Â Ê Á ËÈÍ Î ÏÔÓÒ

ZYor V

yes

Â Ê Á ËÈÍ Î ÏÔÓÒ

• A confirmation tone sounds.

• Next speed dial no. is displayed.

cleared

Â Ê Á ËÈÍ Î ÏÔÓÒ

• If last speed dial no. is deleted, ‘no item’ is displayed.

02-333444555

Â Ê Á ËÈÍ Î ÏÔÓÒ

no item

ÂÊÁ ËÈÍ

Î ÏÔÓÒ

saved

Â Ê Á ËÈÍ Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

key 1

Â Ê Á ËÈÍ Î ÏÔÓÒ

key z

Â Ê Á ËÈÍ Î ÏÔÓÒ

key 3

Â Ê Á ËÈÍ Î ÏÔÓÒ

yes

Â Ê Á ËÈÍ Î ÏÔÓÒ

ZYor V

01-111222333

ÂÊÁ ËÈÍ

Î ÏÔÓÒ

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

1. ZÁ 2. ZSUto select no.

Note:

• To exit the programming mode at anytime, Z P.

• To exit the speed dial

list, ZP.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 17

Page 18

Saving Numbers in Speed Dial List (save speed)

Telephone numbers can be saved into the speed dial list from other lists eg. Caller ID list, re-dial list, etc.

To save a number from other lists;

1. Display number to be saved

2. ZYor V

3. ZYor V

“save speed” is selected. Speed dial icon is displayed.

• Edit number if required.

4. ZYto save number.

• Aconfirmation tone sounds.

• The display returns to the standby mode.

➡ Speed Dialling

0123456789

ВКБЛИН

Î ÏÔÓÒ

save speed

Â КБЛИН Î ÏÔÓÒ

07-Ö12345678

Â Ê Á ËÈÍ Î ÏÔÓÒ

–1–000000001

ВКБЛИН

Î ÏÔÓÒ

saved

Â Ê Á ËÈÍ Î ÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 18

Page 19

This unit is compatible with a Caller ID service offered by your telephone company. If you should subscribe to a Caller ID service, the calling party’s information will be shown on the handset display after the first ring.

You cannot access the Caller ID service while using the handset and base unit for an internal call.

How Caller Information is Displayed when a Call is Received

• Incoming Call

• Caller’s phone number is displayed after first ring.

1.ZO(Length of call is displayed).

• Caller’s phone number cannot be displayed in the following cases: – If the caller dialled from an area which does not provide a

Caller ID service, the display will show

• – If the caller has requested not to display his/her phone

number, the display will show

• If your unit is connected to a telephone line or a PBX which does not support Caller ID service, you cannot access those services.

Checking the Number of New Calls

In the standby mode, when new calls have been received, the display shows the number of new calls.

• For example if you have received 10 new calls the display will show the following.

out of area

ВКБЛИН

Î Ï  ÔÓÒ

Caller ID Service ➡

888888888888

ВКБЛИН

Î Ï  ÔÓÒ

0123456789

ВКБЛИН

Î Ï  ÔÓÒ

00-00-00

ВКБЛИН

Î Ï  ÔÓÒ

private

ВКБЛИН

Î Ï  ÔÓÒ

-1-888888810

ВКБЛИН

Î ÏÔÓÒ

Caller ID, where available, is a telephone company service. After subscribing to Caller ID, this phone will display the caller’s phone number.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 19

Page 20

➡ Caller ID Service

Caller ID Sub-Menu

In the Caller ID sub-menu, it is possible to carry out the following operations:

• Save a Caller ID Number to speed dial list (save speed).

• Edit a Caller ID Number (edit call no).

• Delete a Caller ID Number (clear).

• Delete all Caller ID Numbers (all clear).

1. ZSor U to select number

2. ZYor V

0123456789

ВКБЛИН

ÎÏÔÓÒ

save speed

Â КБЛИН ÎÏÔÓÒ

3. S U

edit call no

Â КБЛИН ÎÏÔÓÒ

4. S U

clear

Â КБЛИН ÎÏÔÓÒ

5. S U

all clear

Â КБЛИН ÎÏÔÓÒ

001122334455

ВКБЛИН

ÎÏÔÓÒ

cleared

Â КБЛИН

ÎÏÔÓÒ

yes

Â КБЛИН

ÎÏÔÓÒ

Â КБЛИН

ÎÏÔÓÒ

07-Ö12345678

Â Ê Á ËÈÍ

Î ÏÔÓÒ

Ö123456789

ВКБЛИН

Î ÏÔÓÒ

S U

Â КБЛИН

ÎÏÔÓÒ

cleared

Â КБЛИН

ÎÏÔÓÒ

S U

yes

Â КБЛИН

ÎÏÔÓÒ

no item

ВКБЛИН

ÎÏÔÓÒ

(Speed dial icon is turned on) ZYto save number.

(Edit no. as required). (Move cursor using V or T to select digit, W = cancel, new digits are input to left of flashing digit). Then ZYto save number.

A confirmation tone sounds.

Next Caller’s No. is displayed.

A confirmation tone sounds.

V or Y

Note: The intercom icon will not be displayed when editing/clearing numbers in

the Redial List.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 20

Page 21

Using the Caller List ➡

Viewing the Caller List

Telephone numbers of up to 50 different callers are stored from the most recent to the oldest call in the Caller List. When the 51st call is received, the oldest call is deleted. To check the caller ’s phone number, follow the steps below.

1. Ensure display is in standby mode

eg. (Clock is displayed – 3 new calls).

2. ZSor U (newest number is displayed).

• To search from the most recent to the oldest call, ZU repeatedly.

• To search from the oldest to the most recent call ZS repeatedly.

• To scroll between callers, ZSor U.

• If no number is displayed in step 2, the Caller List is empty.

• If more than one call is received from the same caller only

the most recent call will be recorded.

3. To exit the list, ZWor P.

• Display returns to standby mode.

• New call counter is cleared.

What ‘⁄’ means

When you have checked new calls, answered the call or called back the caller, ‘⁄’ will be added to the caller’s number.

When the same caller calls again, the call entry with ‘

⁄’ will be

deleted and replaced with the new call entry.

When viewing long telephone numbers

If the caller’s number is greater than 12 digits the whole telephone number will not be shown. ZCto see the remaining numbers.

16-00 03

ВКБЛИН

Î ÏÔÓÒ

0123456789

ВКБЛИН

ÎÏÔÓÒ

16-02 00

ВКБЛИН

Î ÏÔÓÒ

no item

ВКБЛИН

ÎÏÔÓÒ

01234567890

⁄

ВКБЛИН

ÎÏÔÓÒ

012345678901

ВКБЛИН

ÎÏÔÓÒ

ВКБЛИН

ÎÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 21

Page 22

Calling Back from the Caller List

Using the list you can automatically call back a caller.

1. Select Caller ID number by pressing S or U.

2. ZO.

• After a few seconds the length of call is displayed.

3. To hang up ZP.

(The handset will return to the standby mode).

➡ Using the Caller List

Radio Range

Operating More than One Handset

You can register and operate up to 6 handsets at the base unit. Operating more than one handset allows you to have an internal call while simultaneously conducting an external phone call using another handset.

• The optional handset/charger model number is KX-A114EX. The functions of the optional handset are the same as those of KX-TCD700NL handset.

• To register a handset to a base unit, see page 36.

Operating More than One Base Unit

You can register and operate your handset at up to 4 base units. Since each base unit forms a radio cell, you can extend the range or area in

which you can make/answer calls with the same handset by placing the base units in suitable locations. For example you can use a handset in different radio areas, such as at home or the office. However, calls in progress are cancelled when the unit moves to another radio area.

Ex. optional KX-A114EX handsets are added to 2 base units.

0123456789

ВКБЛИН

ÎÏÔÓÒ

-1-0-00-0001

ВКБЛИН

Î ÏÔÓÒ

00-00-00

ВКБЛИН

Î Ï  ÔÓÒ

For Optional Multi-Unit Users

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 22

Page 23

Paging/Intercom ➡

Paging All Handsets from the Base Unit

1. ZÏ(On the Base Unit).

• All handsets will ring for one minute.

2. To stop paging, ZÏagain or ZOon one of the handsets.

Intercom between Handsets

A 2-way intercom is available between handsets. Eg. Handset 1 is paging Handset 2

1. (Handset 1) ZN

(Int icon blinks until connection is established).

2. (Handset 1) ZB

3. (Handset 2)

When the unit rings, ZOto answer.

• The intercom duration is displayed.

4. (Handsets 1 and 2)

To end the intercom, ZP.

• Intercom calls can be conducted within the radio area of the current base unit, but not with units in neighbouring radio areas.

Intercom cannot be accepted in the following areas:

– when the other party is in intercom mode. – when the other party is on hold during external call. – while the other party is in conference call.

Transferring a Call from One Handset to Another

The intercom can be used during a call, enabling you to transfer a call between handsets registered to the same base unit.

Transferring a Call using the Intercom

Eg. Handset 1 is transferring an external call to Handset 2.

1. (Handset 1)

During a call, ZN(Intercom icon turns on).

• The call is put on hold.

2. (Handset 1) Z desired handset no. eg. B

• You will hear an internal ring back tone until the other handset is answered.

-1-œœœœœœœ02

ВКБЛИН

Î ÏÔÓÒ

(1)

ВКБЛИН

ÎÏÔÓÒ

(1)-(2)

ВКБЛИН

ÎÏÔÓÒ

00-00-00

ВКБЛИН

ÎÏÔÓÒ

(1)

ВКБЛИН

ÎÏÔÓÒ

(1)-(2)

ВКБЛИН

ÎÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 23

Page 24

➡ Paging/Intercom

Transferring a Call using the Intercom (continued)

3. (Handset 2) When the unit rings,ZOor N to answer.

4. (Handset 1) Transferring a call ZP

• The transfer is completed or to return to the External Call ZN.

Transferring a Call without the Intercom

This feature enables you to transfer the call to another handset without waiting for the paged handset to answer.

Eg. Handset 1 is transferring a call to Handset 2.

1. (Handset 1)

During a call, ZN(Intercom icon turns on).

• The call is put on hold.

2. (Handset 1) Z desired handset no. eg. B

• You will hear an internal ring back tone until the other handset is answered.

3. (Handset 1) ZP.

4. (Handset 2) When the unit rings, ZOto answer.

• The transfer is completed.

• If the paged handset is not answered within 30 seconds, a ring tone

sounds at the paging handset. The paging handset can return to the call by pressing O.

Conference

During a call using the handset, you can make an intercom call to another handset and then combine the calls together to establish a conference call between handsets registered to the same base unit.

1. (Handset 1) During a call, ZNthen enter the desired handset number eg. B.

• The call is put on hold.

• If there is no answer, ZNto return to the call.

2. (Handset 2) When the unit rings,ZOor N to answer.

3. (Handset 1) ZCto establish a conference call.

4. (Handset 1 or 2) ZPto hang up on conference call.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 24

Page 25

Special Features ➡

How to Use the Pause Feature

(For Analog PBX Line/Long Distance Service Users) We recommend you insert “X” if a pause is required for dialling with a PBX or to

access a long distance service (When X is pressed, ‘p’ is displayed on LCD). Eg. Line access number I (PBX).

1. ZI, X and then phone number.

2. ZO

(After a few seconds, display will start showing the length of the call).

• Pressing X once creates a pause.

This prevents misdialling when you redial or dial a stored number.

• Pressing X more than once increases the length of the pause between

numbers.

Using the Recall Feature

M is used to access special telephone services (optional) such as call waiting. Contact your telephone company business office for details.

If your unit is connected to a PBX, pressing M allows you to access some features of your host PBX such as transferring an extension call. (When M is pressed, ‘f’ is displayed on LCD).

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 25

Page 26

➡ Special Features

Setting the Key Lock (ON)

You can lock the handset dialling buttons. Only incoming calls are accepted until the key lock is cancelled. You can answer a call by pressing any dialling button K to I, J or L (-Any Key Answer).

Make sure that the unit is in the standby mode.

1. ZYfor more than 2 seconds.

• Confirmation tone sounds and all dialling buttons are locked.

• Key lock icon ‘Ó’ is displayed.

To Cancel the Key Lock

Make sure that the unit is in the standby mode.

1. ZYfor more than 2 seconds

• Key lock icon ‘Ó’ disappears and key lock is cancelled.

Note:

• The key lock will also be cancelled when the power is turned

OFF.

• When the handset is in ‘Key Lock’ mode , emergency calls

cannot be made until the key lock is cancelled.

-1-œœœœœœœ02

ВКБЛИН

Î ÏÔÓÒ

-1-œœœœœœœ02

ВКБЛИН

Î ÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 26

Page 27

Summary of Programmable Functions

Chapter 3

On the Handset

You can program the following function items using the handset near the base unit. See the corresponding pages for function details.

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or V

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

• time alarm

• ringer opt

• tone opt

• display opt

• call opt

• other opt

• registration

• select bs

• set time Set Time of Alarm (p.28)

• set alarm Set Alarm ON/OFF (p.28)

• ringer vol Select the Handset Ringer Volume (p.29)

• eht ringer Set Ringer Pattern for Ext. Incoming Call (p.29)

•int ringer Set Ringer Pattern for Internal Call (p.29)

• paging Set Ringer Pattern for Paging Tone (p.29)

• alarm Set Ringer Pattern for Alarm Tone (p.29)

• key tone Set Key Confirmation Tone ON/OFF (p.30)

• call waiting Set Call Waiting Tone ON/OFF (p.30)

• range alarm Set Range Warning Alarm ON/OFF (p.30)

• battery low Set Battery Low Tone ON/OFF (p.30)

• standby mode Select the Standby Mode Display (p.31)

(Base Unit Number, Handset Number, Clock or Off)

• talk mode Select the Talk Mode Display (p.31) (Talk Time, or Phone No.)

• callbar Set Call Prohibition (p.33)

• direct no Set Direct Call Number (p.32)

• set direct Set Direct Call ON/OFF (p.33)

• hspin change Change Handset PIN (p.35)

• auto talk Set Auto Talk ON/OFF (p.34)

• battery type Select Battery Type (p.34)

• register hs Registering a Handset to a Base Unit (p.36)

• cancel base Cancelling a Base Unit (p.37)

Select Base Unit (p.38)

Reset Handset (p.39)

• reset hs

Refer to relevant page as indicated.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 27

Page 28

Setting Time Alarm Function

Within the Time Alarm menu, it is possible to program the following:

• Set Time of Alarm (set time).

• Set Alarm ON/OFF (set alarm). (In this mode, it is possible to set the alarm

to once (once), repeat daily (repeat daily) or off (off)).

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

set time

Â КБЛИН Î ÏÔÓÒ

Éœ–œœ00000

Â КБЛИН Î ÏÔÓÒ

á1–590000000

Â КБЛИН Î ÏÔÓÒ

19–5É0000000

Â КБЛИН Î ÏÔÓÒ

• If time has previously been entered, time is displayed.

• Enter new time.

• A confirmation tone

sounds.

• Display returns to function menu.

• Make selection.

• If time is currently

displayed, new time will be entered over existing digit.

• To cancel one digit, ZWbriefly.

• To cancel all digits Z and hold W.

• The flashing icon indicates the digit to be edited.

set alarm

Â КБЛИН Î ÏÔÓÒ

once88888888

Â КБЛИН Î ÏÔÓÒ

S U

repeat daily

Â КБЛИН Î ÏÔÓÒ

S U

off88888888

Â КБЛИН Î ÏÔÓÒ

Z Y or V

S U

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

To Stop the Alarm

When the alarm sounds, press any dialling button K to I, J, L or O to end alarm tone.

• The alarm time turns off and the display returns to the standby mode. If ‘Once’ is selected, the setting is automatically turned off.

• If the unit is in talk or intercom mode during the alarm time, the alarm will not sound. After finishing, the alarm will start ringing.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 28

Page 29

Setting Ringer Options

Within the Ringer Option menu, it is possible to program the following:

• Select the Handset Ringer Volume ( ringer vol) (6 levels available plus OFF (ringer off)).

• Select the Ringer Pattern for External Incoming Call (ext ringer).

• Select the Ringer Pattern for Internal Call (int ringer).

• Select the Ringer Pattern for Paging Tone (paging).

• Select the Ringer Pattern for Alarm Tone (alarm).

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

or V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

ringer opt

Â КБЛИН Î ÏÔÓÒ

• Select Ringer Volume.

• Z Y or V

• A confirmation tone

sounds.

ringer vol

Â КБЛИН Î ÏÔÓÒ

ext ringer

Â КБЛИН Î ÏÔÓÒ

S U

int ringer

Â КБЛИН Î ÏÔÓÒ

S U

paging

Â КБЛИН Î ÏÔÓÒ

vol⁄œœœœœ

Â КБЛИН Î ÏÔÓÒ

S U

vol

⁄⁄⁄

œœœ

Â КБЛИН Î ÏÔÓÒ

vol

⁄⁄⁄⁄⁄⁄

Â КБЛИН Î ÏÔÓÒ

ringer off

Â КБЛИН Î ÏÔÓÒ

S U

alarm

Â КБЛИН Î ÏÔÓÒ

ringer vol

Â КБЛИН Î ÏÔÓÒ

S U

• Volume is sounded during scrolling.

• Current setting is displayed.

• Select Ringer.

•

Z Y or V

• A confirmation tone sounds.

• Display returns to function menu.

ringer 1

Â КБЛИН Î ÏÔÓÒ

S U

ringer 20

Â КБЛИН Î ÏÔÓÒ

• Ringer is sounded during scrolling.

• Current setting is

displayed.

S U

Note:

• If Ringer Off is saved È icon is displayed.

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

}

(20 patterns available).

S U

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 29

Page 30

Setting T one Options

Within the Tone Option menu, it is possible to program the following:

• Set Key Confirmation Tone ON/OFF (key tone) (on/off).

You can choose whether or not the handset keys will sound tones (eg. key tone, confirmation tone, error tone).

• Set Call Waiting Tone ON/OFF (call waiting) (on/off).

If an incoming call has been received during an intercom between handsets, a call waiting tone sounds.

• Set Range Warning Alarm ON/OFF (range alarm) (on/off).

You can choose whether or not the handset will sound a range warning alarm.

• Set Battery Low Tone ON/OFF (battery low) (on/off).

You can choose whether or not the handset will sound a battery low tone.

or V

• Current setting is displayed.

• Select ON/OFF.

Z Y or V

• Display returns to function menu.

Â КБЛИН Î ÏÔÓÒ

S U

off

Â КБЛИН Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

tone opt

Â КБЛИН Î ÏÔÓÒ

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

S U

key tone

Â КБЛИН

Î ÏÔÓÒ

call waiting

Â КБЛИН

Î ÏÔÓÒ

battery low

Â КБЛИН

Î ÏÔÓÒ

S U

range alarm

Â КБЛИН

Î ÏÔÓÒ

S U

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 30

Page 31

Setting Display Options

Within the Display Option menu, it is possible to program the following:

• Select the Standby Mode Display (standby mode).

In the standby mode, it is possible to set the display to show; Base Number (bs no), Handset Number (hs no), Clock (clock) and OFF ( off).

• Select the Talk Mode Display (talk mode).

In the talk mode, it is possible to set the display to show Talk Time (talk time) or Phone Number (phone no).

bs no

Â КБЛИН Î ÏÔÓÒ

S U

hs no

Â КБЛИН Î ÏÔÓÒ

S U

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

or V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

display opt

Â КБЛИН Î ÏÔÓÒ

standby mode

Â КБЛИН Î ÏÔÓÒ

Y or V

talk mode

Â КБЛИН Î ÏÔÓÒ

• ZPor (W 3 times).

-1- 01

ВКБЛИН

Î ÏÔÓÒ

• Select Setting.

• Z Y or V

clock

Â КБЛИН Î ÏÔÓÒ

S U

off

Â КБЛИН Î ÏÔÓÒ

standby mode

Â КБЛИН

Î ÏÔÓÒ

S U

• ZPor (W 3 times).

-1- 01

ВКБЛИН

Î ÏÔÓÒ

• Select Setting.

• Z Y or V

talk mode

Â КБЛИН

Î ÏÔÓÒ

talk time

Â КБЛИН Î ÏÔÓÒ

S U

phone no

Â КБЛИН Î ÏÔÓÒ

Note:

• In the Standby Mode, (standby mode) your handset is pre-set to display ‘Base Number’ (bs no).

• In Talk Mode your handset is pre-set to display ‘Talk Time’ (talk time).

• To return to a previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 31

Page 32

Setting Call Option

Within the Call Option menu, it is possible to program the following:

• Set Call Prohibition (call bar) see page 33.

• Set Direct Call Number (direct no). You can store a number in the direct call

memory. This feature allows you to make a call easily by pressing O. Incoming calls are accepted.

• Set Direct Call ON/OFF (set direct) (on/off) see page 33.

save

Â КБЛИН

Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

ZYor V

call opt

Â КБЛИН Î ÏÔÓÒ

ZSor U

call bar

Â КБЛИН Î ÏÔÓÒ

direct no

Â КБЛИН Î ÏÔÓÒ

Â КБЛИН

Î ÏÔÓÒ

ZYor V

• Z Y or V

• A confirmation tone

sounds.

• Select ON/OFF.

eg. (Select OFF).

eg. (Select ON).

• Direct Call No. Input mode.

• If direct call no. is already registered, it is displayed. If not enter new number.

direct no

Â КБЛИН Î ÏÔÓÒ

• ZPor (

W 3 times).

(eg. Direct Call “ON”).

off

Â КБЛИН Î ÏÔÓÒ

direct no

Â ÊÁË ÈÍ Î ÏÔÓÒ

-1- 01

ÂÊÁË ÈÍ

Î ÏÔÓÒ

Ö123456789

Â КБЛИН

Î ÏÔÓÒ

0123456789É

Â КБЛИН

Î ÏÔÓÒ

Note:

• To return to the previous step during programming, ZT(except while editing number).

• To exit the programming mode at any time, ZP.

S U

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 32

Page 33

• Set Call Prohibition (this prohibits anyone from making a call with your handset except for emergency calls. Incoming calls are accepted (call bar)).

• Set Direct Call ON/OFF (set direct) (on/off).

hs pin

Â ÈÍ Î ÏÔÓÒ

off

Â КБЛИН Î ÏÔÓÒ

S U

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

or V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

call opt

Â КБЛИН Î ÏÔÓÒ

call bar

Â КБЛИН Î ÏÔÓÒ

S U

See ‘Set Direct

Call Number’

(p.32)

direct mo

Â КБЛИН Î ÏÔÓÒ

Y or V

set direct

Â КБЛИН Î ÏÔÓÒ

• I

f ON is selected ‘Direct Call’ icon is displayed.

•

ZPor

(W 3 times).

•

Z Y or V

• A confirmation tone sounds.

• If ON is selected ‘Ô’ Icon is

displayed.

•

ZPor

(W 3 times).

-1- 01

ÂÊÁË ÈÍ

Î ÏÔÓÒ

• Select ON/OFF.

• Z Y or V

(Display if OFF is selected).

Â КБЛИН Î ÏÔÓÒ

call bar

Â КБЛИН Î ÏÔ Ó Ò

set direct

Â КБЛИН

Î ÏÔÓÒ

S U

Â КБЛИН Î ÏÔÓÒ

-1- 02

КБЛИН

Î ÏÔ Ó Ò

off

Â КБЛИН Î ÏÔÓÒ

set direct

Â ÊÁË ÈÍ Î ÏÔÓÒ

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

• Enter PIN (4 digits)

----

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 33

Page 34

Setting Other Options

Within the Other Option menu, you can program the following:

• Change Handset PIN (hspin change). The factory pre-set is 0000.

• Set Auto Talk ON/OFF (auto talk).

The Auto Talk feature allows you to answer a call by lifting the handset off the base unit without pressing O. If you want to use this feature, turn the feature ON. The factory pre-set is OFF. In order to view caller’s phone number before answering a call, leave the Auto Talk feature OFF.

• Select Battery Type (battery type).

Two Nickel Metal Hydride (Ni-MH) rechargeable batteries are included with this unit. Ensure that the battery selection is set to Ni-MH, or the battery strength will not be displayed correctly.

Â КБЛИН

Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

other opt

Â КБЛИН Î ÏÔÓÒ

hspin change

Â КБЛИН

Î ÏÔÓÒ

Z Y or V

(

W 3 times).

Z Y or V

See Change handset PIN(p.35).

battery type

Â КБЛИН Î ÏÔÓÒ

ZPor

(

W 3 times).

auto talk

Â КБЛИН

Î ÏÔÓÒ

ni-nh

Â КБЛИН Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

-1- 01

ВКБИН

Î ÏÔÓÒ

ni-cd

Â КБЛИН Î ÏÔÓÒ

S U

auto talk

Â КБЛИН

Î ÏÔÓÒ

S U

battery type

Â КБЛИН

Î ÏÔÓÒ

off

Â КБЛИН Î ÏÔÓÒ

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

Y or V

or V

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 34

Page 35

• Change Handset PIN (hspin change)

• You can program a 4 digit password for the handset. The factory pre-set is

0000. Changing the password may prevent the unauthorised use of your unit by another person.

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

Y or V

time alarm

Â КБЛИН Î ÏÔÓÒ

ZYor V

other opt

Â КБЛИН Î ÏÔÓÒ

hspin change

Â КБЛИН Î ÏÔÓÒ

old pin8œœœœ

Â КБЛИН Î ÏÔÓÒ

new pin8œœœœ

Â КБЛИН Î ÏÔÓÒ

verify88œœœœ

Â КБЛИН Î ÏÔÓÒ

• Re-enter new PIN (verify).

hspin change

Â КБЛИН

Î ÏÔÓÒ

• Enter current PIN (old pin). If PIN is incorrect, error tone sounds.

• Enter new PIN (4 digits).

Note: The PIN is not displayed

É is deleted

as a number is entered.

• If PIN is incorrect, error tone sounds. (Display returns to new pin). If PIN is correct, confirmation tone sounds.

• ZPor (W 3 times)

to return to standby mode.

NOTE: Once you have programmed the password, you cannot confirm it. We recommend you write down the password. If you forget it, please consult your nearest Panasonic Service Centre.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 35

Page 36

Registration

• Registering a Handset to a Base Unit (register hs)

The handset supplied with the base unit is already registered. If an optional handset/base unit is purchased, the following procedure needs to be carried out before initial use.

Z and Hold Ï on base unit for 10 secs. A confirmation tone sounds.

-1-888888800

ВКБЛИН

Q ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

registration

Â КБЛИН Î ÏÔÓÒ

Y or V

base 2

Â КБЛИН Î ÏÔÓÒ

S U

base 4

Â КБЛИН Î ÏÔÓÒ

• Select base unit.

ZYor V

• (“Hyphen” is moving during searching). Connection OK.

• Enter PIN (4 digits).

• Base is found

• On completion of

registration, a confirmation tone sounds

• If registration is not successful within 5 minutes, an error tone sounds and display returns to original standby mode.

ZYor V

(Searching Base).

bs9pin É

Â КБЛИН Î ÏÔÓÒ

88-888888888

Â КБЛИН Q ÏÔÓÒ

-2-888888801

ВКБЛИН

Î ÏÔÓÒ

Â КБЛИН Î ÏÔÓÒ

S U

cancel base

Â КБЛИН Î ÏÔÓÒ

NOTES:

• Charge the optional handset batteries for about 10 hours before initial use.

• Register the handset within 1 minute. If not registered within 1 minute, ZP on the handset to cancel the programming mode. Then re-start registration.

• Calls (both incoming and outgoing) can be conducted only via the displayed base unit (even if the radio areas overlap with neighbouring base units).

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

See Page 37

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 36

Page 37

• Cancelling a Base Unit (cancel base)

If another handset is out of range and/or its power is OFF when ‘Cancelling a Handset’, the previous base unit number will still remain in the cancelled handset. Therefore, you need to cancel the base unit registered in the cancelled handset.

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

ZYor V

ZV or Y

time alarm

Â КБЛИН Î ÏÔÓÒ

registration

Â КБЛИН Î ÏÔÓÒ

Â КБЛИН

Î ÏÔÓÒ

S U

cancel base

Â КБЛИН

Î ÏÔÓÒ

hs9pin99œœœœ

Â КБЛИН Î ÏÔÓÒ

• Enter PIN (4 digits) (hs pin).

• If entered PIN is correct, registered base number is displayed.

base 1

Â КБЛИН Î ÏÔÓÒ

base 1

Â КБЛИН Î ÏÔÓÒ

• ZSor U

o select base

unit(s) to cancel.

ZYor V

“Base1” flashes.

ZYor V

• Display returns to function menu.

Â КБЛИН Î ÏÔÓÒ

S U

yes

Â КБЛИН Î ÏÔÓÒ

cleared

Â КБЛИН Î ÏÔÓÒ

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

See Page 36

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 37

Page 38

Select Base Unit (select bs)

• Automatic Base Unit Access (auto)

The handset automatically selects a registered base unit.

• When the handset moves to another base unit radio area, it loses contact with the previous base unit and automatically accesses the new base unit.

• If the handset is in the overlap area between several base unit radio areas, the handset will access the nearest base unit.

Specified Base Unit Access eg. (base1)

You can only select one registered base unit (1 to 4) you want to operate (select bs).

• You can choose the base unit/telephone line where you can make/receive calls.

The factory pre-set is ‘Automatic Base Unit Access’. To select the desired base unit, program as follows:

base 1

Â КБЛИН

Î ÏÔÓÒ

-1- 01

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

or V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

ZYor V

or U

time alarm

Â КБЛИН Î ÏÔÓÒ

eg. H/set is registered to Base 1 and 2.

ZYor V

• Search for base unit.

base 2

Â КБЛИН

Î ÏÔÓÒ

ni-cd

ВКБЛИН

Q ÏÔÓÒ

auto

Â КБЛИН Î ÏÔÓÒ

-2-888888801

ВКБЛИН

Î ÏÔÓÒ

S U

select bs

Â КБЛИН

Î ÏÔÓÒ

auto

Â КБЛИН Î ÏÔÓÒ

S U

eg. Base 2 is selected.

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

• A confirmation

tone sounds.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 38

Page 39

Reset Handset (reset hs)

This function enables the handset to clear the following settings at one time. They will return to their initial settings.

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

(Standby Mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting hs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or U

or V

time alarm

Â КБЛИН Î ÏÔÓÒ

reset hs

Â КБЛИН Î ÏÔÓÒ

• If PIN is correct “no” is displayed.

• A confirmation tone

sounds.

• Enter PIN (4 digits).

hs9pin00œœœœ

Â КБЛИН Î ÏÔÓÒ

S U

yes

Â КБЛИН Î ÏÔÓÒ

cleared

Â КБЛИН Î ÏÔÓÒ

• Select ‘yes’.

Note:

• To return to the previous step during programming, ZT.

• To exit the programming mode at any time, ZP.

Function Initial Setting

Time Alarm Mode OFF Alarm Time Clear Handset Ringer Volume 3 Handset External

Ringer Pattern

Handset Internal Ringer Pattern

Handset Paging Tone Pattern

Handset Alarm Tone Pattern

Key Tones ON Call Waiting Tone ON Range Warning Alarm OFF Battery Low Alarm ON Standby Mode Display Base Unit Number Talk Mode Display Length of the Call Call Prohibition OFF Direct Call Mode OFF Direct Call Number Clear Handset Password 0000 Auto Talk OFF Base Unit Access Automatic Base

Unit Access

Handset Receiver Volume

Redial Memory All Clear

• Display returns to

standby mode.

ZPor (W twice).

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

• Display returns to function menu.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 39

Page 40

Programmable Functions (On the Base Unit)

Bell Selection

There are three choices for Bell Selection when a call is being received

• all handsets ring. “All handsets”

• the selected handset(s) ring(s). “Selected handset(s)”

• the selected handset rings first. Then if it does not answer, all other handsets

will ring, “Selected then all handsets”.

The factory pre-set is “All handsets”. To change the bell selection, program as follows:

(Standby Mode)

1. Select “all handsets” to ring.

• Enter PIN (4 digits).

or V

or U

or V

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

input code

Â КБЛИН ÎÏÔÓÒ

• A confirmation tone sounds.

• Display returns to function menu.

• “All Handset” ringing mode.

ZYor V

2. Select “selected

handset(s)” to ring.

• Enter PIN (4 digits).

-F

to select

handset(s).

ZYor V

182-Ü23456

Â КБЛИН ÎÏÔÓÒ

3. Select “selected then all handsets” to ring.

• Enter PIN (4 digits).

183-Ü23456

Â КБЛИН ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

• The current selected

handset flashes.

-F

to select handset(s).

ZYor V

183-Ü234ä6

Â КБЛИН ÎÏÔÓÒ

183-Ü234ä6-3

Â КБЛИН ÎÏÔÓÒ

• The current number of

rings is displayed.

ZA-F

to select no. of rings.

• A confirmation tone

sounds.

• Display returns to

function menu.

ZYor V

183-Ü234ä6-5

Â КБЛИН ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

• A confirmation tone sounds.

• Display returns to function menu.

• The current selected handset flashes.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 40

Page 41

To Select the Base Unit Ringer Volume

4 levels are available. The factory pre-set is MEDIUM. When set to OFF, the base unit will not ring.

Setting the Clock

To set clock, please program as below. The clock can be displayed as an option in standby mode (see page 31). After a power failure the clock will need re-setting. Clock may take up to one minute to appear on the handset display.

(Standby Mode)

or V

or U

Y or V

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

input code

Â КБЛИН

ÎÏÔÓÒ

• Setting the Clock.

• If the clock has been set previously, time will be displayed.

Enter new time (4-digits) eg. ZA

ZB, C, D

(24 hour clock)

• A confirmation tone sounds.

• Display returns to function menu.

Ø œœ–œœ

Â КБЛИН

ÎÏÔÓÒ

Ø1–œœ30000

Â КБЛИН

ÎÏÔÓÒ

Ø12-34000001

Â КБЛИН

ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

➡

Current setting is displayed

ZK- C to select

volume 0 = Ringer OFF

1 = Low Volume 2 = Medium Volume 3 = High Volume (Ringer sounds on selection)

ZYor V

• Select Ringer Volume

221

Â КБЛИН ÎÏÔÓÒ

2222

Â КБЛИН ÎÏÔÓÒ

• Aconfirmation tone sounds.

• Display returns to function

menu.

setting bs

ВКБЛИН

Î ÏÔÓÒ

Chapter 4

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 41

Page 42

• 3 seconds is selected.

ZAor B to

select Pause time. eg.

1 = 3 seconds 2 = 5 seconds.

• Select Pause Timing.

• Enter PIN (4 digits)

• Select Flash Timing.

• Enter PIN (4 digits)

Select Earth/Flash Mode

The earth relay can be installed as an option depending on your PBX requirements. Please consult your nearest Panasonic Service Centre for installation. Then you can select the flash or earth mode. The factory pre-set is Flash.

Select Pause Timing

You can set the pause timing to 3 or 5 seconds, depending on your PBX requirements. The factory pre-set is 3 seconds.

(Standby Mode)

• Select Earth.

• Enter PIN (4 digits)

or V

or U

or V

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

input code

Â КБЛИН ÎÏÔÓÒ

3221

Â КБЛИН ÎÏÔÓÒ

• Current setting is displayed. 1 = Flash 2 = Earth

• Earth is selected. Current setting is displayed.

ZAto select Flash.

(If Flash is already selected

ZY).

eg. Flash 1 is selected.

ZYor V

• A confirmation tone sounds.

• Display returns to function menu.

eg. Earth is selected.

ZYor V

3222

Â КБЛИН

ÎÏÔÓÒ

33-123456

Â КБЛИН ÎÏÔÓÒ

3222

Â КБЛИН ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

• A confirmation tone sounds.

• Display returns to function menu.

setting bs

ВКБЛИН

Î ÏÔÓÒ

3221-2

Â КБЛИН ÎÏÔÓÒ

• Current setting is displayed. 1=Flash 1 (700m sec) 2=Flash 2 (110m sec)

ZA- B to select

Flash time.

3221-1

Â КБЛИН ÎÏÔÓÒ

ZYor V

• A confirmation tone sounds.

• Display returns to function menu.

setting bs

ВКБЛИН

Î ÏÔÓÒ

➡ Programmable Functions (On the Base Unit)

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 42

Page 43

➡

Set Base Unit PIN

You can program a 4 digit password for the base unit. The factory pre-set is

0000. Changing the password may prevent the unauthorised use of your unit by another person.

Cancelling a Handset

Each handset can cancel itself or another handset.

(Standby Mode)

• Set Base Unit PIN.

• Enter NEW PIN (4 digits) twice.

• Enter PIN (4-digits).

• If 2nd entry of NEW PIN

is incorrect, error tone sounds.

• If 2nd input is correct, a confirmation tone sounds and display returns to function menu.

or V

or U

or V

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

input code

Â КБЛИН

ÎÏÔÓÒ

5 œœœœ œœœœ

Â КБЛИН ÎÏÔÓÒ

5 œœœœ œœœœ

Â КБЛИН ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

• To Cancel a Handset.

• Enter PIN (4-digits).

• All registered

handset numbers are displayed.

ZA-F to

select the handset to cancel.

• A confirmation tone sounds.

• Display returns to function menu.

eg. Handset

F is

selected to cancel.

ZYor V

7 123456

Â КБЛИН

ÎÏÔÓÒ

7 12345ã

Â КБЛИН

ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

NOTE: Once you have programmed the password, you cannot confirm it. We recommend you write down the password. If you forget it, please consult your nearest Panasonic Service Centre.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 43

Page 44

➡ Programmable Functions (On the Base Unit)

Call Restriction

You can restrict desired handset(s) from dialling selected phone numbers. Phone numbers beginning with the restricted digits cannot be dialled out. For example, if “00” is assigned as the call restriction number, international calls cannot be made. For selected handset(s) you can assign up to 6 call restriction numbers (up to 8 digits). Set the call restricted handset(s) and the restriction number(s) by programming. The factory pre-set is OFF.

(Standby Mode)

• To Set Call Restriction.

1. ZF

2. Enter PIN (4 digits).

• All registered handset numbers are displayed.

3. ZAto F to select

handset to restrict.

• The selected handset(s) number(s) flashes.

4. ZY

Enter a call restriction number up to 8 digits.

• If you misdial, ZW

• A confirmation

tone sounds.

• Display returns to function menu.

To Cancel the Call Restricted Handset(s)

Follow steps 1 to 2, then enter the handset number(s) you want to cancel. When finished, ZY,then ZP to return to the standby mode.

When you dial a restricted number,the call is

disconnected and the dialled number flashes. Eg. The restricted number is “00”.

To Cancel the Call Restricted Number(s)

Follow steps 1 to 3, then select the call restriction number you want to cancel by pressing Y. Then Z

W. When finished, Z Y,then ZP to return to

the standby mode.

eg. input 012.

6. ZY

• Aconfirmation tone sounds.

• To continue entering a

number, enter the next number, then ZY.

or V

or U

or V

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

input code

Â КБЛИН ÎÏÔÓÒ

60123456

Â КБЛИН ÎÏÔÓÒ

60Ü234ä6

Â КБЛИН ÎÏÔÓÒ

601-012

Â КБЛИН ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

ÖÖ-888888801

ВКБЛИН

Î Ï  ÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 44

Page 45

➡

Automatic Route Selection

Automatic Route Selection (ARS) is a feature which selects the least expensive carrier service when making long distance calls.

1. After subscribing to a 2nd carrier service, store the 2nd carrier code.

2. Then store the area codes (up to 25 codes) – 2nd carrier service charge rates are higher than the first carrier service.

3. When one of the area codes are dialled, the 2nd carrier code will be used. If you do not store any area codes, all phone numbers will be dialled with the 2nd carrier code.

Example: Second carrier code: 1603 (The second service is cheaper).

Area code: 0113 Dialled number: 0113-055789 → Sent number: 0113-055789. Dialled number: 0114-055789 → Sent number: 1603-0114-055789.

• When dialling the area code, do not leave a long pause between numbers. If

there are pauses, a busy tone will be heard and you will not be able to finish dialling the number. Please contact your telephone company regarding the carrier telephone charges.

Storing the Carrier Code

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

(Standby mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZY or V

setting bs

ВКБЛИН

Î ÏÔÓÒ

ZS or U

or V

input code

Â КБЛИН ÎÏÔÓÒ

• The current setting is displayed. 0 = ARS OFF 1 = ARS ON.

ZAto select ON.

• Enter carrier code (max 7 digits).

• ZYor V

• Aconfirmation tone sounds and

code is stored.

• Enter PIN (4 digits).

9 œœœœ000000

Â КБЛИН

ÎÏÔÓÒ

91œ0œ0000000

Â КБЛИН

ÎÏÔÓÒ

91œ1–0000000

Â КБЛИН

ÎÏÔÓÒ

91œ1–1603

Â КБЛИН

ÎÏÔÓÒ

91œ1–0000000

Â КБЛИН ÎÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 45

Page 46

➡ Programmable Functions (On the Base Unit)

Automatic Route Selection

continued

• Storing the Area Code.

• Enter PIN (4 digits).

• Enter area code.

• ZY or V

• 1st Area code is stored to memory

2nd Area code is displayed.

• Enter area code.

• Aconfirmation tone sounds

and setting is stored.

• 3rd Area code is displayed. Enter Area Code if required (25 codes can be entered).

• ZY or V

9 œœœœ œœœ

Â КБЛИН ÎÏÔÓÒ

92801–045

Â КБЛИН ÎÏÔÓÒ

92803–

Â КБЛИН ÎÏÔÓÒ

94809–192

Â КБЛИН ÎÏÔÓÒ

92802–0996

Â КБЛИН ÎÏÔÓÒ

• ZB

92801—

Â КБЛИН ÎÏÔÓÒ

• ZY or V

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

(Standby mode)

new speed

ВКБЛИН

Î ÏÔÓÒ

ZY or V

setting bs

ВКБЛИН

Î ÏÔÓÒ

ZS or U

or V

input code

Â КБЛИН ÎÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 46

Page 47

➡

Using International Carrier services

Automatic Route Selection (ARS) is also used for international calls. After subscribing to a second international carrier service, store the second

international carrier code (see page 45). Store “00 (international code)” and those country codes (up to 25 codes) instead of area codes (see page 44).

Example: Second international carrier code: 1605

Country code: 0033 (The first carrier service is cheaper.) Dialled number: 0033-55789 → Sent number: 0033-55789 Dialled number: 0044-55789 → Sent number: 1605-0044-55789

• If you stored a phone number with “00” in the speed dialling memory and use a second carrier service which does require “00”, turn the “00” delete mode ON.

To turn the international code “00” delete mode ON/OFF

Some international carrier services do not require “00” before the country code. In this case, turn the delete mode ON by programming. “00” will automatically be deleted when dialling. The factory pre-set is OFF.

Example: Second international carrier code: 1888 (This service does

not require “00”.) Delete mode: ON Dialled number: 0044-55789 → Sent number: 1888-4455789

(Standby mode)

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting bs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or V

input code

Â КБЛИН ÎÏÔÓÒ

• Enter PIN (4 digits).

• The current setting

is displayed 0 = OFF 1 = ON

9œœœœ0000000

Â КБЛИН

ÎÏÔÓÒ

930œœ0000000

Â КБЛИН ÎÏÔÓÒ

931œœ0000000

Â КБЛИН ÎÏÔÓÒ

9œœœœ0000000

Â КБЛИН ÎÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 47

Page 48

➡ Programmable Functions (On the Base Unit)

Reset Base Unit

This function enables the base unit to clear the following settings at one time. They will return to their initial settings. The following are factory default settings of the Base Unit.

Function Initial Setting

Bell Selection All Handsets Earth/Flash Flash Flash Timing 110 m seconds Pause Timing 3 seconds ARS Setting OFF Carrier Code All Clear Area Code All Clear 00 Delete mode OFF Call Restricted Handset(s) All Clear Call Restriction number(s) All Clear Base Unit PIN 0000 Base Unit Ringer Volume Medium Clock No setting

-1-888888801

ВКБЛИН

Î ÏÔÓÒ

new speed

ВКБЛИН

Î ÏÔÓÒ

ZYor V

setting bs

ВКБЛИН

Î ÏÔÓÒ

ZSor U

or V

input code

Â КБЛИН ÎÏÔÓÒ

•ZY

or V

• Enter PIN (4 digits).

• A confirmation tone

sounds.

• Display returns to function menu.

0 œœœœ000000

Â КБЛИН ÎÏÔÓÒ

œœœœœœœœœœœœ

Â КБЛИН ÎÏÔÓÒ

setting bs

ВКБЛИН

Î ÏÔÓÒ

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 48

Page 49

Option Covers ➡

You can change the look of your phone’s handset with option covers.

1. Remove the battery cover by sliding while pressing the arrow. Remove the batteries.

2. The option cover is locked with the right and left tabs. Unlock one of the tabs by pressing horizontally ➀ and vertically ➁, and partially pull down the option cover ➂, ➃ as shown.

3. Unlock the other tab by pressing horizontally ➀ and vertically ➁, and partially pull down the option cover ➂ in the same way. Remove the cover from the handset completely.

TabTab

Chapter 5

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 49

Tab Tab

Page 50

4. Place the new option cover fitting the tabs on the cover into their slots on the handset.

5. Snap the option cover shut on the lower ➀, middle ➁ and upper ➂ parts of the handset.

6. Connect the batteries and close the battery cover.

➡ Option Covers

Using the Belt Clip

You can hang the handset on your belt or pocket using the belt clip.

To remove the belt clip

Tabs

Slot

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 50

Page 51

Before Requesting Help ➡

Problem Remedy

The unit does not work. • Turn the power ON (p.12).

• Check the settings.

• Charge the batteries fully (p.7).

• Clean the charge contacts and charge again (p.7).

• Unplug the AC adaptor and turn the power OFF to

reset. Plug in the AC adaptor and turn the power ON. Then try again.

• The handset has been cancelled or has not been registered. Register the handset (p.36).

• Re-install the handset batteries and try again.

“Î” flashes and an alarm tone • You are too far from the base unit. Move closer and

sounds when you

. • try again.

• Plug in the AC adaptor.

A busy tone sounds when you • Another handset is in use.

You cannot dial. • The unit is in call prohibition mode. Cancel the mode

(p.33).

• The dialled number is restricted. Cancel the number (p.44).

• Key lock mode is set. Cancel the mode (p.26).

“Î” flashes during a conversation • The handset is out of range. Move closer to the

and the call is disconnected. • base unit and make the call again.

• Plug in the AC adaptor.

Static, sound cuts in/out, fades. • Locate the handset and base unit away from other Interference from other electrical • electrical appliances. units. • Move closer to the base unit.

The handset does not ring. • Turn the power ON (p.12).

• The ringer is set to OFF. Select the desired volume level (p.29).

The base unit does not ring. • The ringer is set to OFF. Set to HIGH, MEDIUM or

LOW (p.41).

You cannot program function items • Programming is not possible while the unit is in the such as the handset ringer volume. • talk or intercom mode.

• Do not pause for over 60 seconds while programming.

You cannot store a phone number • You cannot store a phone number while the unit is in memory. • in the talk or intercom mode.

• Do not pause for over 60 seconds while storing.

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 51

Page 52

➡ Before Requesting Help

Problem Remedy

While programming or searching, • To answer the call, lift the handset or

. the unit starts to ring and stops • Start again from the beginning after hanging up. the program/search.

The unit does not display the • Other telephone equipment may be interfering with caller’s phone numbers. • your phone. Disconnect them and try again.

• Other electrical appliances connected to the same outlet may be interfering with the Caller ID information. Telephone line noise may be affecting the Caller ID information.

does not function. • The handset is too far from the base unit.

• The handset is engaged in an outside call.

You cannot redial. • If the last number dialled was more than 24 digits

long, the number will not be redialled correctly.

The paged handset does not • The handset is not in the same radio area. answer. • The handset is engaged in an outside call.

• The handset has been cancelled or has not been registered. Register the handset in the base unit (p.36).

While using the intercom, two tones • Acall is being received. To answer,

then

sound. •

The unit misdials when connected • Check the pause function (p.25). to a PBX.

You cannot register the handset • The base unit has registered a maximum of 6 in the base unit. • handsets or the handset has registered a maximum

of 4 base units.

• Awrong base unit password was entered. Enter the correct password.

• There is interference from other electrical units, locate the handset and base unit away from them.

• You must finish registration within 1 minute after the ringer tone sounds, or programming will be cancelled (p.36).

The battery strength is not • Check that the battery type selection is correct displayed correctly. • (p.34).

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 52

Page 53

Problem Remedy

“Û” flashes or the unit bleeps • Charge the batteries fully (p.7). every 15 seconds.

You charged the batteries fully, • Install new batteries (p.7). but “Û” flashes. • Clean the charge contacts and charge again (p.7).

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 53

Page 54

GARANTIE

Onze produkten zijn van zeer hoge kwaliteit en met ulterste zorg geproduceerd. Mocht er desondanks aanspraak op garantie worden germaakt, dan zijn de volgende bepalingen van toepassing. Bij reparatie ten gevolge van materiaal- en/of constructiefouten binnen 12 maanden, vanaf de datum van aankoop, wordt het apparaat gratis hersteld.

AFWIJKENDE BEPALINGEN

1a. Voor V.P.S. projectlebulzen, (thermische) printerkoppen, fotokopleerapparatuur en elektronische whiteboards

geldt een garantiepweriode van 6 maanden op materiaal en arbeldsloon.

2a. Voor magnetronbuizen geldt een garantieperiode van 2 jaar op het materiaal en van 12 maanden op het

arbeidsloon.

2b. Voor 1/2” C.C.D. chip in zwart/wilt videocamera’s geldt een garantieperiode van 5 jaar op het materiaal en van 12

maanden op het arbeidsloon.

3. Voor mobiele service aan video-projectie systemen, professionele magnetronovens, elektronische whiteboards en fotokopleerapparatuur worden vanaf 3 maanden na aankoopdatum van het apparaat voorrijkosten berekend.

4. Voor reparatie aan (auto)mobiele telefoonapparatuur, telefooncentratles, professionele magnetronovens, fotokopleerapparatuur. elektronische whiteboards, facsimile-apparatuur en laserbeamprinters dient u altijd eerst uw dealer te raadplegen.

5. Het reinigen van koppen valt nlet onder garantie. raadpleeg altijd eerst de gebrulksaanwijzing en/of uw dealer.

6. De volgende onderdelen vallen bulten garantie: snoeren, fluorescentlebuizen, elementen, naalden, stofkappen, glasplaten, keramiekplaten, letterwielschijven en antennes.

7. De volgende verbruiksmaterialen vallen buiten garantie: batterijen, accu’s of andere voedingsbronnen met een beperkte levensduur, CD’s, tapes, cassettes of andere gelulds- en/of informatiedragers, luchtfilters, inklinten en verbrulksmaterialen voor fotokopieer-apparatuur, laser-beamprinters en facsimile-apparatuur (drum, developer, toner etc.) en (thermisch) papier.

8. Voor MII-videokoppen geldt een garantieperiode van 3 maanden of (indien aerder) 500 uur.

9. Voor bronlamp van de LCD videoprojectoren geldt een garantieperiode van 30 dagen.

10. De software updates van de professionele non-lineaire videomontage systemen en telecommunicatie-apparatuur vallen bulten deze garantiebepalingen.

Voor reparatle client de apparatuur franco verzonden te worden aan:

PANASONIC-CENTRE NEDERLAND (Servicom b.v.), Zonweg 60, 2516 BM DEN HAAG, tel. 070-3314314. DE GARANTIE VERVALT INDIEN:

a. Geen geldige en.volledig ingevuld (op de dag van verkoop) garantlebewijs en gedateerde fakuur zijn bijgesloten. b. Enig gegeven op bijgevoegd garantiebewijs is gewijigd. c. Het type-,serienummer en/of andere identificatie-gegevens van het apparaat zijn verwijderd, baschadigd of gewijzigd. d. Het aparaat niet volgens bijbehorende gebruiksaanwijzing werd aangesloten, geïnstalleerd, perlodiek

onderhouden, gebruikt of indien het defect een gevolg is van slijtage of verwaalozing.

e. De schade of het defect het gevolg is van reparaties en/of wijzigingen in het apparaat welke zijn ultgevoerd door een niet door ons hiertoe gernachtigde instantie of dealer. f. Het defect is ontstaan tijdens transport. g. Projectie- en beeldbulzen zijn ingebrand. h. Het defect is ontstaan orndat er geen originete accessoires en/of ondeugdellijke verbrulksmaterialen zijn

toegepast.

i. Het defect is ontstaan door lekkende of verkeerde geplaatste batterijen, accu’s of andere voedingsbronnen met

een beperkte levensduur of verbrulksmaterialen.

j. Het defect is veroorzaakt door vuur, bliksern, aardbeving, overstrorningen of elke andere natuurramp of ongeval.

Datum

aankoop

Type No.

Serie No.

Dealerstempel

GARANTIEBEWIJS

Zorgvuldig door koper te bewaren tezamen met gedateerde koopbon

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 54

Page 55

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 55

Page 56

0436

Manufacturers Declaration:

Kyushu Matsushita Electric (U.K.) Limited hereby declare that this product is in conformity with the essential requirements and other relevant provisions of the R&TTE Directive, 1999/5/EC.

A copy of the manufacturers declaration of conformity to the essential requirements of the R&TTE Directive is available at the following web address: http://doc.panasonic-tc.de

Sales department: HAAGTECHNO BV POSTBUS 236 5201 AE DEN BOSCH

Tel: 073-6402575 Fax: 073-6415200

Kyushu Matsushita Electric (U.K.) Ltd.

Pencarn Way, Duffryn, Newport, South Wales, NP10 8YE, United Kingdom

Printed in Thailand PQQX12931ZA NUO201LL0

1999/5/EC

30401 English KX-TCD700NL 25/4/01 2:32 pm Page 56
