Panasonic KX-TCD420 User Manual

C

2

1

3

4

5

6

7

8

0

R

IN

T

9

Digital Cordless Answering System

Operating Instructions

Preparation Cordless Telephone Useful InformationAnswering System

Contents

Preparation

Before Initial Use.........................2

Important Information .................. 3

Setting up .................................... 4

Cordless Telephone

Using the Telephone ................... 9

Making Calls.............................. 10

Caller ID .................................... 11

Answering Calls......................... 13

Phonebook ................................14

Handset Settings ....................... 18

Base Unit Settings..................... 24

Initial Settings ............................26

Multi-unit User Operation........... 28

Intercom .................................... 32

Answering System

Answering System..................... 33

Remote Operation ..................... 40

Useful Information

Before Requesting Help ............ 41

Technical Information................ 44

Index..........................................45

Guarantee ................................. 46

Model No.

KX-TCD420E

A

L

L

ON

OFF

Caller ID Compatible

PLEASE READ BEFORE USE AND SAVE.

Charge the battery for about 7 hours before initial use.

Before Initial Use

Thank you for purchasing your new Panasonic digital cordless telephone.

Order accessory items for all Communications Products with ease and confidence

•

either by telephoning our Customer Care Centre on:

08700 100 076 Monday - Friday 9:00am - 5:30pm

Or go on line through our Internet Accessory ordering application at

•

shop@Panasonic http://www.panasonic.co.uk

•

Most major credit and debit cards accepted.
All enquires transactions and distribution facilities are provided directly by Panasonic

•

UK Ltd.
It couldn’t be simpler!

•

Dear purchaser,
You have acquired a KX-TCD420E, which is a product made in regard with
the European Standards for Cordless Telephones (DECT). DECT technology is
characterized by high-security protection against interceptions as well as high-quality
digital transmission. This telephone was designed for a wide range of applications. For
example, this telephone can be used within a network of base units and handsets,
constituting a telephone system which:

operates up to 6 handsets at one base unit.

•

allows an intercom between 2 handsets.

•

allows the operation of a handset at up to 4 base units, expanding the communication

•

radio area.

Caller ID Service, where available, is a telephone company service. After subscribing
to Caller ID, this phone will display the caller’s phone number.

Accessories (included)

AC Adaptor

PQLV19E

Telephone Line

Cord
PQJA87S

(for UK)

Rechargeable
Batteries
(AAA size)

HHR-4EPT/BA2

Battery Cover

PQKK10134Z4

(P03P)

Additional accessories are available for purchase. Contact your Panasonic Customer
Care Helpline for further details. U.K. 08700 100 076 R.O.I. 01289 8333

2

Important Information

Only use the power supply included with
the product.
Do not connect the AC Adaptor to any AC
outlet other than the standard AC220­240V.
The apparatus is approved for use with
PQLV19E power supply.
This apparatus is unable to make
emergency telephone calls under the
following conditions:

The portable handset batteries need

•

recharging, or have failed.
During a mains power failure.

•

When the Key Lock is set to ON.

•

When the unit is in Direct Call mode.

•

Do not open the base unit or handset
(other than to change the batteries).
This apparatus should not be used near
emergency/intensive care medical
equipment and should not be used by
people with pacemakers.
Care should be taken that objects do not
fall onto, and liquids are not spilled into
the unit. Do not subject this unit to
excessive smoke, dust, mechanical
vibration or shock.

Environment

Do not use this unit near water.
This unit should be kept away from heat
sources such as radiators, cookers, etc. It
should also not be placed in rooms where
the temperature is less than 5°C or
greater than 40°C.
The AC Adaptor is used as the main
disconnect device, ensure that the AC
outlet is located/installed near the unit and
is accessible.

Battery Caution

Use only specified batteries.

Only use rechargeable batteries.

Do not mix old and new batteries.

Do not dispose of batteries in a fire, they

may explode.

Check local waste management codes for

special disposal instructions.

Do not open or mutilate the batteries.

Released electrolyte is corrosive and may

cause burns or injury to the eyes or skin.

The electrolyte may be toxic if swallowed.

Exercise care in handling the batteries in

order not to short the batteries with

conductive materials such as rings,

bracelets and keys.

The batteries and/or conductor may

overheat and cause burns.

Charge the batteries provided in

accordance with the information given in

this operating guide.

Location

For maximum distance noise-free

•

operation, place your base unit:

- Away from electrical appliances such
as TV, radio, personal computer or
another phone.

- In a convenient high and central
location.

Safety Caution

The ringer tone is reproduced through the
earpiece. To avoid damage to hearing,
first answer the call, then hold the phone
to the ear.

Preparation

WARNING:

TO PREVENT THE RISK OF
ELECTRICAL SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN
OR ANY OTHER TYPE OF
MOISTURE.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

3

Setting up

Connection

Do not connect the telephone line cord to the phone socket 4 until the handset is fully
charged.

Plug in the AC adaptor and the telephone line cord in order 1, 2, 3.
(Switch on AC mains outlet.)

LINE

1

Hook

Fasten the AC adaptor
cord to prevent it from
being disconnected.

The AC adaptor must remain connected at all times (It is normal for the adaptor to feel
warm during use).

2

4

3

Never install telephone wiring during a lightning storm.

•

Battery Installation

Please ensure the batteries are inserted as shown. part should be inserted first.
Close the cover as indicated by the arrow.

• When you replace the batteries, part should be removed first.

To replace the battery:

Press the notch on the cover firmly
and slide it as indicated by the arrow.
Replace 2 batteries and close the
cover then charge the handset for
about 7 hours.

4

Setting up

Battery Charge

At the time of shipment, the batteries are
not charged. To charge, place the
handset on the base unit. Please charge

the batteries for about 7 hours before
initial use. During charging, the battery

icon is as shown below.

Fully charged During charging

(Flashing)

Display icon Battery strength

Battery Life

Battery life is dependent on use and
conditions but in general when using fully
charged Ni-MH batteries (700 mAh):
Talk time: 10hrs approx.
Standby time: 120hrs approx.
When using Ni-Cd batteries (250 mAh):
Talk time: 4hrs approx.
Standby time: 40hrs approx.
(Times indicated are for peak
performance)
The batteries reach peak performance
after several full charge/discharge cycles.
The batteries cannot be overcharged
unless they are repeatedly removed and
replaced.
If battery life is shortened then please
check that battery and charge terminals
are clean.
For maximum battery life, it is
recommended that the handset is not
recharged until battery icon flashes .

Preparation

High

Medium

Low

Needs to be

charged

The handset which power is off will be
turned on automatically when it is placed
on the base unit.
In normal use, the handset and the base
unit should be powered on at all times.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

5

Setting up

Symbols Used in This Operating Instructions

Symbol Meaning

To search the desired item, press UP or DOWN.

To select the desired item, press RIGHT.

To search and then to select the desired item, press UP or DOWN then
RIGHT.

To move the cursor to the right or to the left, press RIGHT or LEFT.

To go to the next step.

" " The words in " " indicate the words in display.

Replacing the Batteries

If the icon flashes after a few telephone calls even when the handset batteries have
been fully charged, 2 batteries must be replaced.

Charge new batteries for approximately 7 hours before initial use.
(The telephone line cord must not be connected to the telephone socket at this
time.)

When replacing the batteries, ensure that the correct battery type is selected.

Selecting the Battery Type

1

Press
MENU.

23

Search/Select
"SETTING HS".

Search/Select
"OTHER OPT".

4

Search/Select
"BATTERY TYPE".

5

Search/Select
"NI-CD" or "NI-MH".

o exit the operation, press any time.

T

•

• Do not use non-rechargeable batteries. If non-rechargeable batteries are fitted and

start charging, it may cause the leakage of the battery electrolyte.

Please use only Panasonic P03P(Ni-MH) or P03H(Ni-Cd) batteries.

6

Setting up

Location of Controls

Handset

Receiver

Display

1

2

3
4

21

4

5

Charge
Contact

Microphone

Base unit

5

7

8

0

R

L

IN

E

Preparation

1 - : PHONEBOOK Button

2 - TALK Button

3 - Navigator Key

6
7

C

3

6

A

L

L

9

O

N

O

F

F

IN

T

8

9

Charge
Contact

4 - REDIAL/PAUSE Button

R

5 - RECALL Button

6 - : MENU/OK Button

7 - OFF/POWER Button

C

8 - CLEAR Button

INT

9 - INTERCOM Button

PAGE Button
and Indicator

Handset Display

Within range of a base unit

Out of range/No registration/
No power on base unit

Paging

Making or answering calls

Phonebook Mode

In Setting Mode

Battery strength is low.

Battery strength is high.

Answering System ON

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

Call BAR ON (p.21)

Direct Call ON (p.22)

Key Lock ON (p.23)

Ringer Volume OFF (p.19)

7

Setting up

Wall Mounting

This unit can be mounted on a wall.

- Insert screws into the wall. The centre of the screw hole should be 8 cm horizontally
apart.

- Connect the AC adaptor and the telephone line cord.

- Arrange the wires as shown, then mount the unit.

8 cm

Screws

Wall Template

8 cm

8

Using the Telephone

Power On/Off

Power on Power off

Press for more than
1 second. *1

*1 When button is released, the display changes to the standby mode.
*2 The display goes blank.

Press for more than
2 seconds. *2

Making a Call

Pre-dialling Post-dialling

Phone Number

1122

*1 If you need correction, press CLEAR. Digit is cleared to the left, then enter numbers.

Answering a Call

Press TALK. *1

• Each ringer will start ringing with lower volume then gradually increase the volume
when receiving a call.

*1 You can also answer a call by pressing any dialling button, INTERCOM,

*1

Press TALK.

Press TALK.

Terminating a Call

(During a call)

Phone Number

Press OFF.

t

or x.

Setting the Clock/Date

After a mains power failure the clock needs to be reset. Ensure that icon is not
flashing.

Cordless Telephone

1

Press MENU.

4

Press OK.

To exit the operation, press any time.

•

*1 For example, to set 7:15, enter 0715.
*2 For example, to set the 16th of February, 2003, enter 160203.

2

Search/Select
"SETTING BS".

5

Press
RIGHT.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

"INPUT CODE"

"INPUT CODE"

3

twice

Enter day,
month then
year. *2

Time

Enter time.
4-digit
(24 hour clock) *1

Date

76

Press OK.

9

Making Calls

Redialling

The last 10 numbers dialled are stored in the redial list automatically.

Dialling with the Redial List Dialling the Last Number Dialled

11223

Press
REDIAL.*1

Search the desired
dialled item.

Press
TALK.

Press TALK.

Editing the Dialled Number in the Redial List

Press REDIAL.

1

Press REDIAL.*1

45 6

Move
cursor.

23

C

Press
CLEAR.*2

Search/Select the
desired dialled item.

AND/

OR

Number

Edit the phone
number.*3

Search/Select
"EDIT CALL NO".

Press TALK.

Press OK 3 times
to store the number.

OR

The 1st digit of
the desired dialled
number blinks.

If you need to
store a name,
go to Name
on page 14 or
press OK.

Clearing One/All Dialled Item(s) in the Redial List

12 34

Press REDIAL.*1

To exit the operation, press any time.

•

*1 If there is no item stored in the redial list, the display shows "NO ITEM".
*2 Digits are cleared to the left of the flashing digit.
*3 Digits are added to the left of the flashing digit. If you need to clear and/or add more

than one number, repeat the steps from 4.

Search/Select the
desired dialled item.

Search/Select

"CLEAR" or
"ALL CLEAR".

Search/Select
"YES".

10

Caller ID

Caller ID Service

Caller ID is a service of your Network provider and will only operate if you have
subscribed to this feature.
After subscribing to Caller ID, this phone will display the caller information.
If your unit is connected to a PBX or a telephone line that does not support this service,
you will not be able to use it.
Caller ID does not display caller information while using the handset for an intercom call.
However, the caller information will be stored to the Caller ID List.
Call Waiting: Call Waiting is a service of your Network provider and will only operate if
you have subscribed to this service.
After subscription, your handset displays a second caller’s phone number while talking
and a Call Waiting tone is heard.
You can answer the second call, keeping the first call on hold.
Please consult your Network provider for details of this service.

Caller ID Display

When receiving a call, the display shows its phone
number.
For example, a caller whose phone number is
01234567890 has been received.

If you store a phone number with a name in the
phonebook, the display shows caller’s name when
receiving a call.

Cordless Telephone

If the caller has requested not to display his/her
information, the display shows "PRIVATE".

If the caller dialled from an area which does not provide
Caller ID service, the display shows "OUT OF AREA".

When new calls have been received, the display
shows the number of calls.
For example, 4 new calls have been received.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

11

Caller ID

Caller ID List

Information up to 50 different callers is stored from the most recent call to the oldest call
in the caller list. When the 51st call is received, the oldest caller information is cleared.
If you receive a call from the same phone number you stored with a name in the
phonebook, the display will show the caller’s name.

Calling Back

12

Search the desired
received item.*1

Editing the Received Number in the Caller List

Press TALK.

1

Search/Select the
desired received
item.*1

C

45

Press
CLEAR.*2

23

Search/Select
"EDIT CALL NO".

Press TALK.

AND/

OR

Number

Edit the
number.*3

Press OK 3 times
to store the number.

The 1st digit of the
desired received
number blinks.

OR

Move
cursor.

If you need to store
a name, go to
Name on page 14
or press OK.

Clearing One/All Received Item(s) in the Caller List

123

Search/Select the
desired received item.*1

To exit the operation, press any time.

•

*1 If there is no item stored in the caller list, the display shows "NO ITEM". on the

right edge of the display when searching the item in the caller list indicates that the
item has been already shown previously.

*2 Digits are cleared to the left of the flashing digit.
*3 Digits are added to the left of the flashing digit. If you need to clear and/or add more

than one number, repeat the steps from 3.

Search/Select

"CLEAR" or
"ALL CLEAR".

Search/Select
"YES".

12

Answering Calls

Auto Talk

If you set Auto Talk to on, you can answer the phone by lifting the handset off the base
unit.

12 3 4 5

Press
MENU.

To exit the operation, press any time.

•

Search/Select
"SETTING HS".

Search/Select
"OTHER OPT".

Search/Select
"AUTO TALK".

Temporary Bell Off

When an external call is incoming, you can temporarily turn off the handset ringer.
This function will not work when the handset is on the base unit or if an internal call is
incoming.

Press and hold
DOWN for
over 1 second.

Search/Select
"ON" or "OFF".

Cordless Telephone

Receiver Volume

During a call, press UP or DOWN to change the volume setting to LOW (0), MEDIUM
(00), HIGH (000).

(During a call)

Press UP or
DOWN.

Handset Locator/Paging

Using this feature, you can locate a misplaced handset by paging.

Press on the base unit.

1

<To stop paging>

Press on the base unit OR on one of the handsets.

3

*1 You can also stop paging by pressing any dialling buttons, INTERCOM,

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

All registered handsets ring for 1 minute.

2

*1

t

or x.

13

Phonebook

You can store up to 20 caller information in the phonebook. If you received a call from
the same phone number you stored with a name in the phonebook, the display will show
the caller’s name.

Storing a Caller Information

1

Press MENU.

Name

56

Enter name.
(max. 9 characters)*1

To exit the operation, press any time.

•

*1 If you need correction, press RIGHT or LEFT to move cursor then clear character by

pressing CLEAR, and/or enter characters. Characters are cleared or added to the left
of the flashing character. To enter characters, see Character Selection below.

*2 To continue storing another caller information, repeat the steps from 3.

Character Selection

Keys

Character Table

Number of times key is pressed

1

1

#

2

A

3

D

4

G

5

J

23 4

Select
"NEW PHONE".

Press OK.*2

4*5,6-7

3

2

]

[

2

C

B

3

F

E

I

H

K

4

5

L

/

Phone Number

Enter phone number.
(max. 24 digits) *1

Keys

8

1

Number of times key is pressed

1

6

8

0

M

7

P

T

9

W

Blank

2

N

Q

U

X

0

Press OK.

3

4

O

6

R

S

V

8

Y

Z

5

7

9

B

ACDEFGHIJKLMNOPQRSTU

Z123456789*0 -

14

#

[]

/

,

VW XY

Editing a Caller Information

Phonebook

1

Press

PHONEBOOK.*1

<Phone Number>

4

Move cursor.

<Name>

78 9

Move cursor.

Clearing a Caller Information

23

Search/Select
desired item.

5

C

Press CLEAR.*2 Press OK.

C

Press CLEAR.*2

Select "EDIT".

AND/

OR

AND/

OR

Number

Edit the phone
number.*3

Edit the name.*4

Name

The 1st digit of the
desired phone
number blinks.

6

Press OK.

1234

Press
PHONEBOOK.*1

Dialling with the Phonebook

Search/Select
desired item.

Search/Select
"CLEAR".

Search/Select
"YES".*5

123

Press
PHONEBOOK.*1

Search
desired item.

Press TALK.

Cordless Telephone

To exit the operation, press any time.

•

*1 If there is no item stored in the phonebook, the display shows "NO ITEM".
*2 Digits are cleared to the left of the flashing digit.
*3 Digits are added to the left of the flashing digit. If you need to clear or add more than

one digit, repeat the steps from 4.

*4 Characters are added to the left of the flashing character. If you need to clear or add

more than one character, repeat the steps from 7.

*5 To continue clearing another caller information, repeat the steps from 2.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

15

Phonebook

Storing the Phone Number into the Phonebook
When Pre-dialling

Phone Number

1

*1

234

Press OK twice.Press OK to

store the number.

Name

Enter name.*2

5

Press OK.

To exit the operation, press any time.

•

*1 If you need correction, press CLEAR. Digit is cleared to the left, then enter numbers.
*2 To enter characters, see Character Selection on page 14.

Storing the Number from the Redial/Caller List into
the Phonebook

Press REDIAL.*1

12

OR

Search/Select
the desired received
number.*1

Search/Select
the desired dialled
number.

Search/Select
"SAVE TEL NO".*2

3

Press OK.

If you need to store a name, go to Name on page 14.

OR

4

Press OK.

To exit the operation, press any time.

•

*1 If there is no item stored in the redial/caller list, the display shows "NO ITEM".
*2 If you need correction, press RIGHT or LEFT to move cursor then clear a digit by

pressing CLEAR, and/or enter digits. Digits are cleared or added to the left of the
flashing digit.

16

Phonebook

Hot Key

You can assign the dialling buttons 1 through 9 as hot keys. You can choose 9 phone
numbers from the phonebook.

Registering a Phone Number as a Hot Key

1

Press
PHONEBOOK.*1

5

Search/Select
"YES".

Dialling with Hot Key

Press and hold the dialling button registered as a hot key.

12

Clearing the Hot Key Registration

Press and hold the dialling

1234

button registered as
a hot key.

To exit the operation, press any time.

•

*1 If there is no item stored in the phonebook, the display shows "NO ITEM".
*2 The number is flashing if the dialling button is already assigned as a hot key.
*3 Phonebook registration will be remained even hot key registration is cleared.

23 4

Search/Select
desired item.

Press RIGHT. Select "CLEAR". Search/Select

Search/Select
"HOT KEY REG".

Search/Select
desired dialling
button number.*2

Press TALK.

"YES".*3

Cordless Telephone

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

17

Handset Settings

: Time Alarm

Before programming, please follow steps 1 to 3.

You must set the clock before setting the time alarm.

12 3

Press MENU. Search/Select

Setting Alarm Time

Search/Select

"SETTING HS".

"TIME ALARM".

4567

Search/Select
"SET TIME".

Setting Time Alarm On/Off

Time

Enter time.
4-digit
(24 hour clock).

Press OK.

Search/Select

"OFF",
"ONCE" or
"REPEAT DAILY".

45

Search/Select
"SET ALARM".

• To exit the operation, press any time.

To stop time alarm: Time alarm will sound for 3 minutes. When the alarm sounds, press
any dialling buttons or key. Alarm stops and display returns to the standby mode.
If "ONCE" is selected, the setting is turned off. When in talk or intercom mode, the alarm
will not sound until the call is ended.

Search/Select

"OFF",
"ONCE" or
"REPEAT DAILY".

18

Handset Settings

: Ringer Option

Before programming, please follow steps 1 to 3.

12 3

Press MENU. Search/Select

Setting the Ringer Volume

The choices are 6 levels and off.

Search/Select

"SETTING HS".

"RINGER OPT".

45

Search/Select
"RINGER VOL".

Search/Select
desired ringer volume.

Cordless Telephone

If

•

"RINGER OFF"

Setting the Ringer Pattern for External Call/Internal Call/Paging/Alarm

There are 20 patterns available on each ringer.

is selected, is displayed.

45

Search/Select

"EXT RINGER",
"INT RINGER",
"PAGING" or
"ALARM".

• To exit the operation, press any time.

• Each ringer will start ringing with lower volume then gradually increase the volume

when receiving a call.

*1 If you select one of the melody ringer patterns, it keeps ringing for 10 seconds even

if a caller hangs up a call. Therefore, you may hear dial tone or no one there after you
answer a call.

Search/Select
desired ringer pattern.*1

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

19

Handset Settings

: Tone Option

You can set the following sounds on or off.
Key Tone: Key tone will sound when you press any key, and a confirmation tone and

an error tone will be heard during operation.

Call Waiting Tone: Call waiting tone will sound when an incoming external call is

received during an intercom call.

Range Warning Alarm: Alarm will sound when you move out of range of a base unit.
Battery Low Alarm: Alarm will sound when the batteries need to be charged.

1

Press MENU.

234

Search/Select
"SETTING HS".

Search/Select
"TONE OPT".

5

Search/Select
"ON" or "OFF".

To exit the operation, press any time.

•

: Display Option

Selecting the Standby Mode Display

12 3

Press MENU. Search/Select

Search/Select

"SETTING HS".

"DISPLAY OPT".

45

Search/Select
"STANDBY MODE".

Search/Select

"CLOCK",*1
"OFF",
"BS NO"(Base unit number) or
"HS NO"(Handset number).

Search/Select

"KEY TONE",
"CALL WAITING",
"RANGE ALARM" or
"BATTERY LOW".

To exit the operation, press any time.

•

*1 Time will only be displayed if the clock has been set. When new calls have been

received, the display shows the number of new call.

20

Handset Settings

Before programming, please follow steps 1 to 3.

12 3

Press MENU. Search/Select

Selecting the Talk Mode Display

Even if you select "PHONE NO", the other party’s phone number will not appear on your
display when you receive calls without subscribing to a Caller ID service.

Search/Select

"SETTING HS".

"DISPLAY OPT".

45

Selecting the Display Language

45

To exit the operation, press any time.

•

*1 You can select one of 10 languages.

If you set a language you cannot read, reset the handset to its initial settings.
Press MENU DOWN RIGHT UP RIGHT 4-digit Handset PIN UP OK
All handset setting will be reset to their initial settings (p.26), however, the Phonebook
data will be saved.

Search/Select
"TALK MODE".

Search/Select
"LANGUAGE".

Search/Select

"TALK TIME"(Length of the call) or
"PHONE NO"(Phone number).

Search/Select
desired language.*1

: Call Option

Call BAR On/Off

This allows you to make emergency and internal call.

12 3

Press MENU. Search/Select

4-digit

56

Handset PIN

Factory preset 0000

Search/Select
"SETTING HS".

Search/Select

"ON" or "OFF".*1

"CALL OPT".

4

Search/Select
"CALL BAR".

Cordless Telephone

To exit the operation, press any time.

•

*1 If "ON" is selected, is displayed.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

21

Handset Settings

Before programming, please follow steps 1 to 3.

12 3

Press MENU. Search/Select

Setting the Direct Call Number

After a direct call number has been set and on, you can dial the direct call number only
by pressing TALK. Incoming calls are accepted.

Search/Select

"SETTING HS".

"CALL OPT".

45 6

Search/Select
"DIRECT NO".

Setting the Direct Call On/Off

Phone Number

Enter the direct
call number. (max. 24 digits)

Press OK 3 times.

45

Search/Select
"SET DIRECT".

To exit the operation, press any time.

•

*1 If "ON" is selected, is displayed.

Changing Handset PIN

The factory preset is 0000. Once you have programmed the handset PIN, you
cannot confirm it. We recommend you write down the handset PIN. If you forget
it, please consult our Panasonic Customer Care Helpline. U.K. 08700 100 076
R.O.I. 01289 8333

12 3

Press MENU. Search/Select

Search/Select
"ON" or "OFF".*1

: Other Options

Search/Select

"SETTING HS".

"OTHER OPT".

4

Search/Select
"HSPIN CHANGE".

Current 4-digit

5

Handset PIN

To exit the operation, press any time.

•

22

New 4-digit

67

Handset PIN

New 4-digit Handset
PIN again to verify

Handset Settings

Key Lock

You can lock the handset dialling buttons. Only incoming calls are accepted while the
key lock is on. The key lock is cancelled if the handset is turned off.

When the key lock is on, emergency calls cannot be made until key lock is
cancelled.

Key Lock On Key Lock Off

Press OK for more
than 2 seconds.

is displayed and all dialling buttons are locked.

•

Press OK for more
than 2 seconds.

Recall Feature

RECALL is used to access special telephone services. Contact your Network provider

for details. If your unit is connected to a PBX, pressing RECALL allows you to access
some features of your host PBX such as transferring an extension call.

Dialling Pause (for PBX line/long distance service
users)

A dialling pause is used when a pause in the dialling of the phone number is necessary
using a PBX or accessing a long distance service.
For example, when 9 (line access number) is dialled followed by a pause to access an
outside line through a PBX:

9

12 3 4

Press PAUSE.*1

Entering a pause prevents misdialling when you redial or dial a stored number.

•

Pressing

•

press

PAUSE

PAUSE

once creates one pause. To extend the pause requirement time,

accordingly.

Phone Number

Press TALK.

Cordless Telephone

*1 is displayed on the LCD.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

23

Base Unit Setings

Before programming, please follow steps 1 to 2.

12

Press MENU. Search/Select

"SETTING BS".

Changing Base Unit PIN

The factory preset is 0000. Once you have programmed the base unit PIN, you
cannot confirm it. We recommend you write down the base unit PIN. If you forget
it, please consult our Panasonic Customer Care Helpline. U.K. 08700 100 076
R.O.I. 01289 8333

Current 4-digit Base Unit PIN

5

3
6

Call Restriction

You can restrict selected handset(s) from dialling selected phone numbers. You can
assign up to 10 call restriction numbers (up to 8 digits). If you dial a restricted number,
the call does not connect and restricted number flashes.

3

789

45

New 4-digit Base Unit PIN again to verify

6

Phone Number

Enter phone
number to be
restricted.
(up to 8 digits)

4-digit Base

45 6

Unit PIN

Factory preset 0000

Press RIGHT.

"INPUT CODE"

New 4-digit Base Unit PIN

Handset Number

Select desired handset.*1

Press OFF.

OR

To continue entering call
restriction numbers, repeat
the steps 7 to 8.
(up to 10 numbers)

Press RIGHT.

Cancelling Call Restricted Handset(s)

34 5 6 7

To exit the operation, press any time.

•

*1 The selected handset number flashes.
*2 The selected handset(s) will stop flashing.

24

Unit PIN

Factory preset 0000

4-digit Base

6

Handset
Number

Select desired
handset.*2

Press RIGHT.

Press OFF.

Base Unit Settings

Before programming, please follow steps 1 to 2.

12

Press MENU. Search/Select

"SETTING BS".

Cancelling Call Restricted Number

4-digit Base Unit PIN

6

3

Time Break/Earth Recall

An earth relay can be installed as an option depending on your PBX requirements.
Please consult our Panasonic Customer Care Helpline for installation. On installation,
you can then select the time break recall or earth mode to suit your PBX or Network
provider.

34 56 7

456

Factory preset 0000

<to continue>

87

Press RIGHT.

4-digit Base Unit

3

PIN

Factory preset 0000

Repeat the
steps 5 to 7.

"INPUT CODE"

Press RIGHT
repeatedly until
desired call restriction
number is displayed.

<to finish>

OR

Press OFF.

1

Time Break Recall *1

2

OR

Earth Recall

2

C

Press CLEAR.

Press OK.

Cordless Telephone

Pause Timing

You can set the pause timing to 3 or 5 seconds, depending on your PBX requirements.

3 Seconds

34 56

To exit the operation, press any time.

•

The factory preset is in shade.

•

*1 "1-2" stands for 80 msec.

PIN

Factory preset 0000

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

4-digit Base Unit

3

3

1

OR

5 Seconds

2

7

Press OK.

25

Initial Settings

: Reset Handset

You can reset all of the handset settings to their initial settings.

1

Press MENU.

234

Search/Select
"SETTING HS".

Search/Select
"RESET HS".

4-digit Handset PIN

Factory preset 0000

5

Search/Select
"YES" or "NO".

• To exit the operation, press any time.

Handset Initial Settings

Function Initial Setting

Time Alarm Mode OFF
Alarm Time Clear
Handset Ringer Volume 6
Handset External Ringer Pattern 1
Handset Internal Ringer Pattern 1
Handset Paging Tone Pattern 1
Handset Alarm Tone Pattern 1
Key Tone ON
Call Waiting Tone ON
Range Warning Alarm OFF
Battery Low Alarm ON
Standby Mode Display Clock
Talk Mode Display Length of the Call
Display Language English
Call BAR OFF
Direct Call Mode OFF
Direct Call Number Clear
4-Digit Handset PIN 0000
Auto Talk OFF
Base Unit Access Automatic Base Unit Access
Redial Memory All Clear
Handset Receiver Volume Medium

26

Reset Base Unit Settings

If the base unit is reset, the Caller ID list will clear.

Initial Settings

1

Press MENU. Press 0.

4-digit Base Unit PIN

45

Factory preset 0000

• To exit the operation, press any time.

Base Unit Initial Settings

Ringer Mode All Handsets
Number of Rings 3
Time Break/Earth Recall Time Break Recall
Pause Timing 3 seconds
Call Restricted Handsets All Clear
Call Restriction Numbers All Clear
4-Digit Base Unit PIN 0000

23

Search/Select
"SETTING BS".

Press OK.

Function Initial Setting

"INPUT CODE"

0

Cordless Telephone

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

27

Multi-unit User Operation

: Handset Registration to a Base Unit

Handset Registration

The handset supplied with the base unit is already registered. If an optional handset is
purchased, it must be registered. Additional KX-A142E handsets are available to
purchase separately. Up to 6 handsets can be registered to a single base unit. Using
additional handsets allows you to have an intercom call while simultaneously conducting
a call to an outside line.
Handset must be registered within 1 minute after pressing PAGE button. If over 1
minute, press then start over again.

Charge the optional handset batteries for 7 hours before initial use.

12 3

Press MENU.

4

Press
RIGHT.*1

5

6

Search/Select desired
base unit number
available to register
the handset.

To exit the operation, press any time.

•

*1 If a handset has been already registered to 4 base units, "MEMORY FULL" is

displayed.

Search/Select
"SETTING HS".

Press and hold on the Base Unit
(for about 10 seconds) until the green indicator flashes.

If all registered handsets start ringing (Paging),
press to stop paging then start over again.

4-digit Base

78

Unit PIN after

"BS PIN"

displayed.

Factory preset 0000

Search/Select
"REGISTRATION".

Press OK.

is

"REGISTER HS"

When a handset is
registered successfully,
a confirmation tone
sounds and " "
icon lights.

28

Multi-unit User Operation

Cancelling a Base Unit

You can cancel any base unit that your handset is registered to.

12 3

Press MENU.

Search/Select
"SETTING HS".

Search/Select
"REGISTRATION".

4

Search/Select
"CANCEL BS".

4-digit Handset PIN

56

Factory preset 0000

Search/Select
desired base unit
number to cancel.*1

78

Press RIGHT.

Cancelling a Handset

Each handset can cancel itself or another handset.

1

Press MENU.

4-digit Base

45 6

Unit PIN

Factory preset 0000

To exit the operation, press any time.

•

*1 The selected base unit number flashes.
*2 The selected handset number flashes.

Search/Select
"YES" or "NO".

2

Search/Select
"SETTING BS".

Handset Number

Select desired handset.*2

"INPUT CODE"

3

Press OK.

7

Please wait until

"SETTING BS"

is displayed.

Cordless Telephone

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

29

Multi-unit User Operation

Before programming, please follow steps 1 to 4.

12 34

Press
MENU.

Ringer Mode Selection;
Setting the All Handsets Mode

56

"All handsets" mode.

Setting the Selected Handsets Mode

56 7

"Selected handsets"
mode.

Setting the Selected then All Handsets Mode

The specific handset(s) will ring for a selected number of rings.
If not answered, all handsets will ring.

5

"Selected then all
handsets" mode.

Number of Rings

89

Select how many times
it rings. (up to 6 rings)

Search/Select
"SETTING BS".

1

2

3

67

*2

"INPUT CODE"

Press OK.

Handset Numbers*1

Press desired
handset numbers.

Handset Numbers

Press desired
handset numbers.

Press OK.

*1

1

Press OK.

Press RIGHT.

4-digit Base Unit
PIN

Factory preset 0000

To exit the operation, press any time.

•

The factory preset is in shade.

•

*1 The selected handset number flashes.
*2 Press dialling button through to enter the number of rings.

30

1

6

Multi-unit User Operation

: Base Unit Selection

When Automatic Base Unit Access is selected, if you move outside of the radio range of
the current base unit, the handset automatically searches for other registered bases.
When a specified base unit is selected, the handset will access that base unit only. Calls
(both incoming and outgoing) can be conducted only via the selected base unit, even if
the radio cells overlap with neighbouring base units.

12 3 4

Press MENU.

• To exit the operation, press any time.

Operating Additional Base Units: You can register and operate your handset with up
to 4 base units. Each base unit forms 1 radio cell. If the individual bases are linked to the
same telephone line then you can extend the operating range of the system by
positioning the bases so that the two radio cells overlap. If the handset is set to AUTO
base selection, then in standby mode the handset will automatically swap to the second
base if the range on the first base is exceeded. It is not possible to transfer calls between
bases (only between handsets linked to the same base unit).

Search/Select
"SETTING HS".

Search/Select
"SELECT BS".

Search/Select
"AUTO" or specific
base unit number.

Cordless Telephone

1

Radio Cell

Eg.
Additional
handsets
(KX-A142E)
registered with
2 base units.

Note: Calls are disconnected when the handset moves from one radio cell to

another.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

2

4

3

5

31

Intercom

Intercom between Handsets

You can use your handsets as a 2-way intercom.
For example, when Handset 1 calls Handset 2. To hang up, press .

<Handset 1>

12

Press INTERCOM.

INT

( on the display)

2

Press desired
Handset Number.

<Handset 2>

• Intercom calls can be conducted within the radio cell of the current base unit, but not
with units in neighbouring radio areas.

Transferring a Call to Another Handset/Conference Call

Intercom can be used during a call to transfer an external call between handsets that are
registered to the same base unit. For example, when handset 1 transfers a call to
Handset 2. To hang up, press .

<Handset 1>

(During a call)

*1 You can also press any dialling button, INTERCOM,

*2 If you press after pressing desired handset number, a call can be transferred to

another handset without speaking to another handset.

If the transferred call is not answered within 30 seconds, Handset 1 will ring again.
*3 When Handset 2 answers a call transferred, press to complete a call transfer or

press dialling button to establish the conference call.

12

Press INTERCOM.

INT

3

( on the display)

<Handset 2>

3

Press TALK.*1

2

Press desired
Handset Number.*2

3

or x.

t

3

4

Press TALK.*1

*3

32

Answering System

Summary of Answering System

Before programming, please follow steps 1 to 2.

12

Press

Press

Press

Press

Press

Press

Press

Press

Press

INT

Press INTERCOM.

1

2

4

5

ALL

6

4

7

6

7

8

ON

9

To repeat an/a incoming/memo message during playback. (p. 35)

To skip an/a incoming/memo message during playback. (p. 35)

To playback new incoming/memo message(s). (p. 35)

To playback all incoming/memo message(s). (p. 35)

To playback a greeting message. (p. 34)

To record a memo message. (p. 35)

To record a greeting message. (p. 34)

To set the answering system ON. (p. 36)

To stop the answering system operation. (p.35)

Answering System

Press

Press

Press

Press

*1 These function are available only during incoming/memo message playback.
*2 This function is available only during your own greeting message playback.

0

OFF

4

5

6

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

To set the answering system OFF. (p.36)

To erase one incoming/memo message.*1 (p.35)

To erase all incoming/memo message(s). (p36)

ALL

To erase the recorded greeting message.*2 (p.34)

33

Answering System

Greeting Messages

You can choose to use one of two pre-recorded greeting messages, or you can record
your own greeting message.
All messages (greeting, incoming & memo) are stored indefinitely on a “Flash memory”
IC chip - even if a power failure occurs.

Pre-Recorded Greeting Messages

You can choose to play either:

- A pre-recorded message which allows you to select a caller’s recording time of “1
minute” or “Unlimited” (up to 20 minutes).

When the recording time is set to “1 minute” or “unlimited”.

- “Hello, we are not available now. Please leave your name, message and phone
number after the beep. We will return your call.”

OR

- A “greeting only”. If you select “greeting only” (p.36) and set the answering system
ON, the unit will answer a call with a greeting message, then hang up. It will not

record any incoming messages.

When the recording time is set to “greeting only”.

- “Hello, no one is available to take your call. Please call back later.”

To Playback Pre-Recorded/Your Own Greeting Message

Press

INT

123

Recording Your Own Greeting Message

The total recording time is approximately 20 minutes. The greeting recording time is
limited to 2 minutes and 30 seconds.
We recommend you record a brief greeting message in order to leave more time for
recording new incoming/memo messages.

123

Press
INTERCOM.

*1 The display starts to show the length of the recording time.
*2 The greeting message you selected is played.

Clearing a Greeting Message

1245

34

INT

INT

INTERCOM.

7

Press

INTERCOM.

6

45

6

3

The greeting message is played.

6

Talk clearly
to the
microphone.*1

6

6

*2

9

Answering System

Incoming/Memo Messages

Incoming messages and memo messages are stored in chronological order. New
messages cannot be recorded when “Memory full” is heard. We recommend you erase
unnecessary messages after each playback to leave more time for recording new
message(s).
If new message(s) is/are recorded, icon on the handset display will flash. When the
memory is full, it will flash faster.
If you set the clock and current date then set the answering system ON, a synthesized
voice announces the day and time incoming/memo message was recorded after
playback.

Recording a Memo Message

INT

12

Press

INTERCOM.

7

345 6

4

Talk clearly
to the
microphone.*1

9

Playback New/All Incoming/Memo Message(s)

INT

12

Press

INTERCOM.

1

2

9

Repeat*2

Skip*3

Stop

Clear one

4

message.*4

Playback new

4

message(s).

OR

34

Playback all

5

ALL

messages.

*1 The display starts to show the length of the recording time.
*2 If you press within 5 seconds from the start of playback, the previous message will be

played. If you press after 5 seconds from the start of playback, the current message
will be played.

*3 The next message will be played if recorded.

*4 If you erase a message when there is more than one message in memory, the next

message will begin playback.

(During
playback
a message)

Answering System

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

35

Answering System

Clearing All Incoming/Memo Messages

INT

12

Press
INTERCOM.

Selecting the Caller’s Recording Time

You can select “1 minute”, “unlimited” or “greeting only” for the caller’s recording time.

12

Press
MENU.

345

The factory preset is in shade.

•

*1 "" is displayed.

Search/Select
"SETTING BS".

3

34

"INPUT CODE"

1

1 minute

2

Unlimited

3

Greeting only*1

5

ALL

6

Press OK.

Recording Your Telephone Conversation

When you record your 2-way telephone conversation, you should inform the other party
that the conversation is being recorded. During recording, a beep will sound
approximately every 15 seconds.

(During
conversation)

12 43

Press
MENU.

"RECORDING"

is displayed.

Press OK.

Press #
to end
recording.

Answering System On/Off

When you set the answering system ON, a caller can leave her/his messages.

8

On

123

Press INTERCOM.

36

INT

ON

Off

0

OFF

is displayed.

Answering System

Before programming, please follow steps 1 to 2.

12

Press MENU. Search/Select

"SETTING BS".

Recording Quality

It is possible to select either high quality or normal quality recording of incoming
messages. Available recording time will vary as follows:

Quality Recording Time
Normal :Approx. 20 minutes
High :Approx. 10 minutes

1

3456

• The factory preset is off.

Selecting the Number of Rings

You can select the number of times the unit rings before the answering system answers
a call, from 2 to 7 or Auto (for Toll Saver*).

* Toll Saver (When set to “Auto”)
When you call the unit from a touch tone telephone:
If the unit answers on the 2nd ring, there is at least one new message.
If the unit answers on the 5th ring, there are no new messages.
Hang up when you hear the 3rd ring. This will save you the toll charge for the call.

8

OR

2

"INPUT CODE"

ON (High)

OFF (Normal)

Press OK.

Answering System

AUTO

0

OFF

OR

35

• The factory preset is in shade.

2

4

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

2

·

The unit will answer

·

·

after the selected number of rings.

7

6

Press OK.

37

Answering System

Before programming, please follow steps 1 to 2.

12

Press MENU. Search/Select

"SETTING BS".

Monitor Function On/Off

When your greeting message is being played to the caller and the caller’s message is
being recorded, you can listen to it through the handset.

1

345

• The factory preset is in shade.

Setting the Remote Code

The 3-digit remote code prevents unauthorised use of your unit for listening recorded
incoming/memo messages

345

4

1

OR

2

.

Enter a 3-digit remote code
number to set on.

OR

"INPUT CODE"

Off

On

Off

6

Press OK.

6

Press OK.

38

Answering System

Remote Operation from a Touch Tone Phone

You can operate the answering system from any touch tone phone.

Firstly you must store your remote code using the handset near the base unit.

The 3-digit remote code prevents unauthorised use of your answering system for listening to
recorded messages.

Turning ON the Answering System Remotely

1. Call your unit from a touch tone phone and wait for 20 rings.

2. Enter the remote code within 10 seconds of hearing the long beep.

3. The unit answers and the greeting message is played.

4. Enter the remote code to access the voice menu.

5. A synthesized voice menu will guide you on how to operate the answering system.

6. Follow the menu or enter the direct remote commands.

7. To end the remote operation, hang up.

• If your remote code is not stored, you cannot turn on the answering system remotely.

Direct Remote Commands

After entering the remote code, you can choose to operate your answering system using
direct commands as below, in place of listening to the voice menu. Hang up to end the
remote operation at any time.

1

2

4

5

6

7

Record

Repeat message
(during playback)*1

Skip message
(during playback)

New message playback

All message playback

ALL

Greeting message
playback

Greeting message
recording

9

0

OFF

4

5

6

Stop operating

Answering system off

Erasing specific
message
(during playback)

Erasing all messages

ALL

Erasing greeting
messages
(during playback)

Disconnect

*1 If you press within 5 seconds from the start of playback, the previous message will be

played. If you press after 5 seconds from the start of playback, the current message
will be played.

Answering System

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

39

Remote Operation

Voice Menu

The words in “ ” mean a voice guidance.

Press .

Press .

Press .

Press .

2

2

2

2

Press .

“Press 1 to playback
all messages.
Press 2 for other functions.”

“Press 1 to playback
new messages.
Press 2 for other functions.”

“Press 1 to record your
messages.
Press 2 for other functions.”

"Press 1 to erase all messages.
Press 2 for other functions.”

1

“All message playback.”

At the end of the last message,
“End of final message” and the
remaining recording time are
announced.

“New message playback.”

“Please leave your
message.”

Talk after you hear
this message.

“No messages.”

Hang up

Press .

2

“Press 1 to record
your greeting.
Press 2 for other functions.”

“Record greeting after
the beep.”

Talk after a long beep.

• After playback, the voice menu will start again from the beginning.

• If you hear “Memory full” after playback, erase some or all of the messages.

40

9

Before Requesting Help

If you experience any problems with the normal use of your apparatus, you should
unplug it from the telephone outlet and connect a known working telephone in its place.
If the known working telephone still has problems, then please contact the customer
service department of your Network provider.
If it operates correctly, then the problem is likely to be a fault in your apparatus.
In this case, contact your supplier for advice. Your Network provider may charge you if
they attend a service call that is not due to apparatus supplied by them.

Turn the power OFF then ON (Handset) / Disconnect then connect the AC adaptor
(Base unit).

Problem Possible cause Solution

NO LCD display in handset.•Handset not turned on.

Handset will not turn on.

Batteries charge icon not
counting up.

icon flashes.

Handset busy tone heard
when is pressed.

No dial tone.

Cannot dial out.

Batteries not inserted.

•

Batteries not charged.

•

Dirty charge contact.

•

Base not powered up.

•

Handset not registered to

•

base.
Handset out of range of

•

base.
No power into base unit.

•

Handset out of range of

•

base.
Another handset in use.

•

Telephone line not

•

connected.

Call BAR set.

•

Particular dialled number is

•

restricted.
Key lock mode ON.

•

Turn on power (p.9).

•

Insert the 2 rechargeable

•

batteries supplied (p.4).
Place handset in base and

•

connect AC adaptor to base
and AC outlet (full charge
period 7 hrs).

Clean charge / battery

•

contact and retry charge.
Connect AC adaptor to

•

base unit and AC outlet.

Register handset to base.

•

Move handset closer to

•

base.
Connect AC adaptor to

•

base unit and AC outlet.

Move handset closer to

•

base.
Wait for the other user to

•

complete call.

Insert telephone cord to

•

network.
Turn power OFF then ON.

•

Turn feature off.

•

Remove number from call

•

restricted list.
Turn key lock OFF.

•

Useful Information

Handset will not ring.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

Ringer switched off.

•

Set ringer to one of 6

•

volume levels.
(see "Handset Settings".)

41

Before Requesting Help

Problem Possible cause Solution

Last number redial does not
work.

No Caller ID number
displayed.

icon flashes.

is disappeared.

Cannot register handset to
base.

Number exceeded 24 digits.•Redial manually.

•

Service not supplied.

•

Caller has withheld info.

•

Battery low.

•

Wrong battery type

•

selected.

Max. number of bases

•

already registered to
handset.
Max. number of handsets

•

already registered to base
unit.
Wrong PIN number entered

•

(Default 0000).

Electrical noise in local

•

area.

Caller ID service must be

•

arranged with Network
provider.

Recharge batteries.

•

Set the correct battery type.

•

Delete unused base

•

registrations from handset.

Delete unused handset

•

registrations from base.

If PIN number is lost,

•

contact the Panasonic
Customer Care Helpline.
Move base/handset away

•

from sources of electrical
noise (e.g TV, radio).

42

Answering System

Problem Possible cause Solution

Before Requesting Help

The answering system is on,
but incoming messages are
not recorded.

You cannot operate the
answering system from a
touch tone phone.

You cannot operate the
answering system with the
handset.

While recording a greeting
message, the unit starts to ring
and stops recording.

During playback, the unit
starts to ring and stops
playback.

The recording time is set to

•

“greeting only”.

Memory is full.

•

Incorrect remote code

•

entered.
Tone are too short to

•

activate the unit.
The answering system is

•

off.

Someone is operating the

•

answering system
You are too far from the

•

base unit.
The unit is recording a

•

message.

A call is being received.

•

A call is being received.

•

Select “1 minute” or

•

“unlimited (see “Answering
System”).
Erase some or all of the

•

messages.

Enter the correct remote

•

code.
Press each button firmly.

•

Turn on the answering

•

system.

Retry when other user has

•

finished operation.
Move closer to the base

•

unit.
To answer the call, press

•

TALK.

To answer the call, press

•

TALK. The recording stops
halfway. Start from the
beginneing after hanging
up.

To answer the call, press

•

TALK.

Helpline Tel.No. :U.K. 08700 100 076 R.O.I. 01289 8333

Useful Information

43

Technical Information

Specifications

Standard: DECT=(Digital Enhanced Cordless

Number of channels: 120 Duplex Channels
Frequency range: 1.88 GHz to 1.9 GHz
Duplex procedure: TDMA (Time Division Multiple Access)
Channel spacing: 1728 kHz
Bit rate: 1152 kbit/s
Modulation: GFSK
RF Transmission Power: approx. 250 mW
Voice coding: ADPCM 32 kbit/s
Power source: AC Adaptor 220 - 240 V, 50 Hz
Power consumption, base unit: 5 VA
Operating conditions: 5 - 40 °C, 20 - 80 % relative air humidity (dry)
Dimensions, Base Unit: About (58 mm x 128 mm x 105 mm) x 170 g
Dimensions, Handset: About (143 mm x 48 mm x 32 mm) x 120 g

Specifications are subject to change.

•

The illustrations used in this manual may differ slightly from the original device.

•

Connections: The telephone will not work during a power failure. We therefore
recommend you use a standard telephone and T Adaptor to connect this Digital
Cordless Phone to the line. Your Panasonic Sales Shop can offer you more information
about connection possibilities.

elecommunications)

T
GAP=(Generic Access Profile)

44

Index

AC Adaptor .......................................... 2, 4

Accessories.............................................. 2

Answering Calls ..................................... 13

Answering System

Answering System On/Off................. 36

Greeting Messages........................... 34

Incoming/Memo Messages............... 35

Recording Your Telephone Conversa-

tion .................................................... 36

Auto Talk................................................ 13

Base Unit

Initial Settings.................................... 27

PIN .................................................... 24

Reset................................................. 27

Selection ........................................... 31

Battery

Caution................................................ 3

Charge ................................................ 5

Installation........................................... 4

Life ...................................................... 5

Battery Low Alarm.................................. 20

Call Restriction

Cancelling Call Restricted

Handset(s) ........................................ 24

Cancelling Call Restricted Number... 25

Call Waiting............................................ 11

Caller ID List

Calling Back...................................... 12

Clearing............................................. 12

Editing ............................................... 12

Storing............................................... 16

Calls

Answering ........................................... 9

Making .......................................... 9, 10

Redialling .......................................... 10

Terminating ......................................... 9

Cancelling a Base Unit........................... 29

Cancelling a Handset............................. 29

Clock/Date................................................ 9

Conference Call ..................................... 32

Handset

Display................................................ 7

Initial Settings ................................... 26

Locator.............................................. 13

Paging............................................... 13

PIN.................................................... 22

Registration....................................... 28

Reset ................................................ 26

Ringer ............................................... 19

Intercom................................................. 32

Key

Lock .................................................. 23

Tone.................................................. 20

Making Calls

Redialling.......................................... 10

with the Phonebook .......................... 15

Phonebook

Hot Key............................................. 17

Storing .............................................. 14

Power On/Off ........................................... 9

Range Warning Alarm ........................... 20

Recall..................................................... 23

Receiver Volume ................................... 13

Remote Code......................................... 38

Ringer Pattern........................................ 19

Ringer Volume ....................................... 19

Setting up................................................. 4

Specifications......................................... 44

Time Alarm ............................................ 18

Time Break/Earth Recall........................ 25

Tone Option ........................................... 20

Voice Menu............................................ 40

Wall Mounting.......................................... 8

Useful Information

Dialling Pause ........................................ 23

Direct Call Number................................. 22

Display

Standby Mode................................... 20

Talk Mode ......................................... 21

Guarantee .............................................. 46

45

Guarantee

CONDITIONS OF GUARANTEE

This guarantee is in addition to and does not in any way affect any statutory or other rights of
consumer purchasers. If within the applicable guarantee period, the appliance proves to be
defective by reason of faulty design, workmanship or materials, we undertake subject to the
following conditions to have the defective appliance (or any part or parts there of) repaired or
replaced free of charge.

1. The appliance shall have been purchased and used solely within either the UK or ROI and

in accordance with standard operating instructions and the technical and/or Safety
Standards required in the UK.

2. The appliance should be returned together with this guarantee and proof of date of

purchase promptly on being found defective at the purchaser's risk and expense to the
authorised dealer from whom the appliance was purchased or to the nearest authorised
dealer. All enquires must be through such dealers.

3. This guarantee shall not apply to damage caused through fire, accident, lightning, misuse,

wear and tear, neglect, incorrect adjustment or repair, to damage caused through
installation, adaption, modification or use in an improper manner or inconsistent with the
technical and/or safety standards required in the country where this appliance is used, or
to damage occurred during transit to or from the purchaser.

4. If at any time during the guarantee period any part or parts of the appliance are replaced

with a part or parts not supplied or approved by us or of an objective quality safe and
suitable for the appliance, or the appliance has been dismantled or repaired by any person
not authorised by us, we shall have the right to terminate this guarantee in whole or in part
immediately without further notice.

5. The purchaser's sole and exclusive remedy under this guarantee against us is for the

repair or replacement of the appliance or any defective part or parts and no other remedy,
including, but not limited to, incidental or consequential damage or loss of whatsoever
nature shall be available to the purchaser.

6. This guarantee shall not apply to batteries and any other items of limited natural life.

7. Our decision on all matters relating to complaints shall be final. Any appliance or defective

part which has been replaced shall become our property.

8. The guarantee period applicable to this product shall be 12 months.

Please keep these Operating Instructions with your receipt.

Panasonic Business Systems U.K.

Receipt No. Date of Purchase

Model No. KX-TCD420E Serial No.

46

Hereby, Panasonic Communications Co., Ltd., declares that this Dect Cordless Telephone is
in compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC.

A copy of the manufacturer's declaration of conformity to the essential requirements of the
R&TTE Directive is available at the following
web address: http://doc.panasonic-tc.de

For your future reference

Serial No. Date of purchase

(found on the bottom of the unit)

Name and address of dealer

Attach or keep original receipt to assist with any repair under warranty.

Customer Care Helpline Tel. No.: U.K. 08700 100 076

R.O.I. 01289 8333

0436

1999/5/EC

This equipment is designed for use on the United Kingdom only.
In the event of problem, you should contact your equipment supplier in the first
instance.

Technical specifications are subject to change.

Sales Department:
Panasonic Business Systems U.K.

Panasonic House, Willoughby Road, Bracknell, Berkshire, RG12 8FP

Panasonic Communications Co., Ltd.

1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan

PQQX13446ZA

D0203NR0
