CS-KE36NKU
- 26 -
INDOOR UNIT
33
40
22
20
36
16
25
18
39
38
37
17
19
19
8
7
6
4
1
35
2
3
47
5
9
10
26
42
34
21
12
15
11
13
14
58
41
59
52
54
46
49
50
23
45
55
25
48
44
56
24
53
18
28
43
31
30
57
29
27
32
51
Page 2
ATTENTION!
- 27 -
To ensure correct parts supply,please let us know the following,
Part No. when you make service parts order:
1.Part No. 2.Description 3.Q'ty 4.Volts-Hz-Ph 5.Product Mode No.
CS-KE36NKU
INDOOR UNIT
KeyNo.
1 CV6233135366 Evaporator Ass'y 1 8520412028100
2 CV6233135359 Mounting Plate 1 8522238529601
3 CV6233135342 Mounting Plate Ass'y 1 8520221720200
4 CV6233135335 Mounting, Tube 1 8522236232411
5 CV6231485876 Mounting Thermostat 1 8522530322401
* 6 CV6233135328 Cross-Flow Fan Ass'y 1 8520250930600
* 7 CV6231718318 Bearing Housing Ass'y 1 8520251013200
8 CV6233135311 Cover Rubber 1 8522251421911
9 CV6233190587 Grille Ass'y 1 8520150194200
10 CV6233135434 Grille 1 8522150155711
11 CV6233166674 Ornamental Plate 1 8522151642312
12 CV6233190570 Air Filter Ass'y 2 8520230739401
13 CV6233135403 Mounting Filter 2 8522230639211
14 CV6233190563 Indicator Plate 1 8522130825306
15 CV6233135380 Cover 2 8522251534911
16 CV6233135373 Frame Ass'y 1 8520220150300
17 CV6233135526 Guide Air Defl 1 8522236020211
18 CV6233135519 Mounting Blade 3 8522247821611
19 CV6233135502 Blade 3 8522151937511
20 CV6233135496 Mounting 1 8522151479011
21 CV6233135489 Mounting 1 8522151479111
22 CV6233135472 Wire SWP-A 2 8522131543401
23 CV6233135465 Flap 1 8522152332311
24 CV6233135458 Flap 1 8522152332411
25 CV6231299640 Mounting 4 8522151444001
26 CV6231918879 Mounting 2 8522151452002
27 CV6233135588 Gear Ass'y 1 8520223116700
28 CV6233135571 Mounting 1 8522151478411
29 CV6233135564 Cover 1 8522251534711
30 CV6233135557 Gear 1 8522133118901
31 CV6233135540 Gear 2 8522133119001
* 32 CV6233135533 Step Motor 24BYJ48-1256 1 1FA4M3A008200
33 CV6231718363 Cap, Drain Pan 1 8522234812401
34 CV6233135656 Drain Hose Ass'y 1 8520130329900
35 CV6233135649 Mounting Plate, Fan Motor 1 8522235435711
36 CV6233135632 Mounting Plate, Fan Motor 1 8522235435811
37 CV6233135625 Mounting, Tube 1 8522236232511
38 CV6233135618 Mounting, Tube 1 8522236232611
39 CV6233135601 Mounting 1 8522151478911
* 40 CV6233166698 Fan Motor SIC-41CVJ-D847-1 1 1FA4M5B010300
NOTE: Metal and plastic parts will be supplied basically
Part No. Description Model Number Q'ty Reference No.
with necessary heat insulation pads or packing.
Each key number with an asterisk (*) means the
recommended service parts.
Page 3
ATTENTION!
- 28 -
To ensure correct parts supply,please let us know the following,
Part No. when you make service parts order:
1.Part No. 2.Description 3.Q'ty 4.Volts-Hz-Ph 5.Product Mode No.
CS-KE36NKU
INDOOR UNIT
KeyNo.
41 CV6233135731 Terminal Cover Ass'y 1 8520530908600
42 CV6233135724 Rear Panel 1 8522223024501
* 43 CV6233190617 Circuit Board Ass'y CB-CS-KE36NKU 1 8FA0518190500
* 44 CV6233135700 Indicator Lamp Ass'y IND-KHS3682 1 8FA0516108800
* 45 CV6233190594 Thermistor KTEC-35-135-1 1 1FA4V2E054900
46 CV6233135687 Terminal Base 1 8FA0526600400
* 47 CV6233135670 Thermistor PT2M-51H-S6-1 1 1FA4V2E048100
48 CV6233135663 Elec.Component Box 1 8522530775611
49 CV6233135809 Mounting Plate 1 8522238529701
50 CV6280622277 Csa Washer C2801P-O 1 8522238910100
51 CV6233135793 Cover,Elec.Component Box 1 8522531552211
52 CV6233135786 Cover,Elec.Component Box 1 8522531552311
53 CV6233135779 Cover Plate 1 8522530944201
54 CV6233135762 Cover Plate 1 8522530944301
55 CV6233135755 Angle Terminal 1 8522530637001
* 56 CV6233187136 Remote Control Switch PRCS-8HVPULS4U 1 8FA0005458100
57 CV6233003573 Holder 1 8512537707701
58 CV6231856935 Cover 1 8522251530001
59 CV6231857192 Mounting Thermostat 1 8522530331001
NOTE: Metal and plastic parts will be supplied basically
Part No. Description Model Number Q'ty Reference No.
CV6233187112 Operation Manual 1 8526418122100
with necessary heat insulation pads or packing.
Each key number with an asterisk (*) means the
recommended service parts.
