EB
Web Site: http://www.panasonic-europe.com
Basic Operating Instructions
Digital Camera/
Lens Kit/Body
Model No. DMC-GX1X/DMC-GX1K
DMC-GX1
Before use, please read these instructions completely.
More detailed instructions
on the operation of this
camera are contained in
“Operating Instructions for advanced
features (PDF format)” in the supplied
CD-ROM. Install it on your PC to read it.
Model number suffix “EB” denotes UK model.
VQT3U05
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic Digital
Camera. Please read these Operating Instructions carefully and keep them handy for
future reference. Please note that the actual controls and components, menu items, etc. of
your Digital Camera may look somewhat different from those shown in the illustrations in
these Operating Instructions.
Carefully observe copyright laws.
•
Recording of pre-recorded tapes or discs or other published or broadcast material for purposes
other than your own private use may infringe copyright laws. Even for the purpose of private
use, recording of certain material may be restricted.
Information for Your Safety
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE,
DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR
•
SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
• USE ONLY THE RECOMMENDED ACCESSORIES.
• DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AND SHALL
BE EASILY ACCESSIBLE.
∫ Product identification marking
Product Location
Digital Camera Bottom
Battery charger Bottom
∫ About the battery pack
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Do not heat or expose to flame.
•
• Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long period of
time with doors and windows closed.
Warn ing
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC or incinerate.
VQT3U05 (ENG)
2
Caution for AC mains lead
For your safety, please read the following
text carefully.
This appliance is supplied with a moulded
three pin mains plug for your safety and
convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced
please ensure that the replacement fuse
has a rating of 5-ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark Ï or the BSI
mark Ì on the body of the fuse.
If the plug contains a removable fuse
cover you must ensure that it is refitted
when the fuse is replaced.
If you lose the fuse cover the plug must
not be used until a replacement cover is
obtained.
A replacement fuse cover can be
purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET
OUTLET IN YOUR HOME THEN THE
FUSE SHOULD BE REMOVED AND
THE PLUG CUT OFF AND DISPOSED
OF SAFELY.
THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF
PLUG IS INSERTED INTO ANY 13AMPERE SOCKET.
If a new plug is to be fitted please
observe the wiring code as stated below.
If in any doubt please consult a qualified
electrician.
∫ IMPORTANT
The wires in this mains lead are coloured
in accordance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with
the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured Blue must be
connected to the terminal which is marked
with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be
connected to the terminal which is marked
with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER
WIRE TO THE EARTH TERMINAL
WHICH IS MARKED WITH THE LETTER
E, BY THE EARTH SYMBOL Ó OR
COLOURED GREEN OR
GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF
-
KEEP DRY.
∫ Before use
Remove the connector cover.
∫ How to replace the fuse
The location of the fuse differ according to
the type of AC mains plug (figures A and
B). Confirm the AC mains plug fitted and
follow the instructions below.
Illustrations may differ from actual AC
mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach
the fuse cover.
Fuse cover
Figure A Figure B
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
(ENG) VQT3U05
3
∫ About the battery charger
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN CABINET OR IN
•
ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO
PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE
VENTILATION VENTS.
• DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH NEWSPAPERS,
TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
• DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED CANDLES, ON
THE UNIT.
• DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY MANNER.
The battery charger is in the standby condition when the AC power supply cord is connected.
•
The primary circuit is always “live” as long as the power cord is connected to an electrical
outlet.
∫ Cautions for Use
•
Do not use any other USB connection cables except the supplied one.
• Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30; optional).
Part numbers: RP-CDHM15 (1.5 m) (5 feet), RP-CDHM30 (3.0 m) (10 feet)
• Always use a genuine Panasonic AV cable (DMW-AVC1; optional).
• Always use a genuine Panasonic remote shutter (DMW-RSL1; optional).
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise adversely affecting
the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields
created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,
disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops functioning properly,
turn this unit off and remove the battery or disconnect AC adaptor (DMW-AC8E; optional).
Then reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound
•
may be adversely affected.
VQT3U05 (ENG)
4
Information for Users on Collection and Disposal of Old Equipment and used
Cd
Batteries
These symbols on the products, packaging, and/or accompanying
documents mean that used electrical and electronic products and
batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used
batteries, please take them to applicable collection points, in accordance
with your national legislation and the Directives 2002/96/EC and 2006/
66/EC.
By disposing of these products and batteries correctly, you will help to
save valuable resources and prevent any potential negative effects on
human health and the environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling of old products and
batteries, please contact your local municipality, your waste disposal
service or the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact
your dealer or supplier for further information.
[Information on Disposal in other Countries outside the European
Union]
These symbols are only valid in the European Union. If you wish to
discard these items, please contact your local authorities or dealer and
ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this
case it complies with the requirement set by the Directive for the
chemical involved.
(ENG) VQT3U05
5
Contents
Information for Your Safety...............................................................................................2
Care of the camera ...........................................................................................................7
Accessories ......................................................................................................................8
Names and Functions of Main Parts...............................................................................12
Changing the Lens..........................................................................................................15
Attaching the Shoulder Strap ..........................................................................................16
Charging the Battery.......................................................................................................17
• Charging...................................................................................................................17
Inserting and Removing the Card (optional)/the Battery.................................................18
About the Card................................................................................................................19
• About cards that can be used with this unit ..............................................................19
Setting Date/Time (Clock Set) ........................................................................................20
Selecting the Recording Mode........................................................................................21
Taking a Still picture .......................................................................................................23
• Taking pictures using the Touch Shutter function ....................................................23
Taking Pictures using the Automatic Function (Intelligent Auto Mode) ..........................24
• Recording using Intelligent Auto Plus Mode.............................................................25
Taking Pictures with Defocus Control Function..............................................................26
Recording Motion Pictures..............................................................................................27
• Recording still pictures while recording motion pictures...........................................27
Compensating the Exposure ..........................................................................................28
Easily set a suitable exposure (one push AE) ................................................................29
Using the function button................................................................................................30
Playing Back Pictures/Motion Pictures ...........................................................................31
• Playing Back Pictures...............................................................................................31
• Playing Back Motion Pictures...................................................................................32
Deleting Pictures.............................................................................................................33
Switching the display of the LCD Monitor .......................................................................34
Setting the Menu.............................................................................................................35
Setting the Quick Menu ..................................................................................................36
Types of menus ..............................................................................................................37
About the supplied software ...........................................................................................43
• Installing supplied software ......................................................................................44
Reading the Operating Instructions (PDF format) ..........................................................45
Specifications..................................................................................................................46
VQT3U05 (ENG)
6
Care of the camera
Do not subject to strong vibration, shock, or pressure.
The lens, LCD monitor, or external case may be damaged if used in
•
below conditions. It may also malfunction or image may not be
recorded.
– If you drop or hit the camera.
– If you press hard on the lens or the LCD monitor.
This camera is not dust/splash/water proof.
Avoid using the camera in a location with a lot of dust,
water, sand, etc.
•
Liquid, sand and other foreign material may get into the space
around the lens, buttons, etc. Be particularly careful since it may
not just cause malfunctions, but it may become unrepairable.
– Do not use in places with a lot of sand or dust.
– Do not use in places where water can come into contact with this
unit such as when using it on a rainy day or on the beach.
Do not place your hands inside the mount of the digital
camera body. Since the sensor unit is a precision
apparatus, it may cause a malfunction or damage.
∫ About Condensation (When the lens or the LCD monitor
is fogged up)
•
Condensation occurs when the ambient temperature or humidity
changes. Be careful of condensation since it causes lens and LCD
monitor stains, fungus and camera malfunction.
• If condensation occurs, turn the camera off and leave it for about
2 hours. The fog will disappear naturally when the temperature of
the camera becomes close to the ambient temperature.
(ENG) VQT3U05
7
Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of October 2011. These may be subject to change.
1 Digital Camera Body
(This is referred to as camera body in these operating instructions.)
2 Interchangeable Lens
“LUMIX G X VARIO PZ 14–42 mm/F3.5–5.6 ASPH./POWER O.I.S.”
(This is referred to as lens in these operating instructions. This is attached to the
camera body at the time of purchase.)
3 Lens Cap
(This is attached to the interchangeable lens at the time of purchase.)
4 Lens Rear Cap
5 Body Cap
6 Interchangeable Lens
“LUMIX G VARIO 14–42 mm/F3.5–5.6 ASPH./MEGA O.I.S.”
(This is referred to as lens in these operating instructions.)
7 Lens Hood
8 Lens Cap
(This is attached to the interchangeable lens at the time of purchase.)
9 Lens Rear Cap
(This is attached to the interchangeable lens at the time of purchase.)
10 Body Cap
(This is attached to the camera body at the time of purchase.)
11 Body Cap
(This is attached to the camera body at the time of purchase.)
12 Battery Pack
(Indicated as battery pack or battery in the text)
Charge the battery before use.
13 Battery Charger
(Indicated as battery charger or charger in the text)
14 AC Mains Lead
15 USB Connection Cable
16 CD-ROM
•
Software: Use it to install the software to your PC.
17 CD-ROM
Operating Instructions
•
18 Hot shoe cover
(This is attached to the camera body at the time of purchase.)
19 Shoulder Strap
¢1 At purchase, these parts are supplied fitted together.
•
SD Memory Card, SDHC Memory Card and SDXC Memory Card are indicated as
• The card is optional.
• Description in these operating instructions is based on the interchangeable lens (H-PS14042).
• Consult the dealer or your nearest Service Centre if you lose the supplied accessories. (You
can purchase the accessories separately.)
¢1
¢1
card
in the text.
VQT3U05 (ENG)
8
1
12 13
K2CT39A00002
14
K1HY08YY0017
15
16
VFF0867 VKF4970 VFC4765
17 18 19
DMC-GX1X
2
23
VYF3443
H-PS14042
4
VFC4605
5
VKF4385
678 9
VYC1009 VYF3201 VFC4315H-FS014042
DMC-GX1K
3
10
VKF4385
11
VKF4385
DE-A94ADMW-BLD10E
DMC-GX1
4
¢2 Supplied in DMC-GX1X only
¢3 Supplied in
¢4 Supplied in
DMC-GX1K only
DMC-GX1 only
(ENG) VQT3U05
9
Sales and Support Information
Customer Communications Centre
• For customers within the UK: 0844 844 3899
• For customers within Ireland: 01 289 8333
• For further support on your product, please visit our website:
www.panasonic.co.uk
Direct Sales at Panasonic UK
• Order accessory and consumable items for your product with ease and confidence by phoning
our Customer Communications Centre Monday–Thursday 9:00 a.m.–5:30 p.m.,
Friday 9:30 a.m.–5:30 p.m. (Excluding public holidays)
• Or go on line through our Internet Accessory ordering application at www.pas-europe.com.
• Most major credit and debit cards accepted.
• All enquiries transactions and distribution facilities are provided directly by Panasonic UK.
• It couldn’t be simpler!
• Also available through our Internet is direct shopping for a wide range of finished products.
Take a browse on our website for further details.
VQT3U05 (ENG)
10
∫ Optional Accessories
Lithum Ion Battery DMW-BLD10
AC Adaptor
DC Coupler
¢1
¢1
DMW-AC8
DMW-DCC9
Live Viewfinder DMW-LVF2
Flash DMW-FL220, DMW-FL360, DMW-FL500
Remote Shutter DMW-RSL1
Zoom Lever DMW-ZL1
MC Protector DMW-LMCH37¢3, DMW-LMC52
ND Filter DMW-LND37¢3, DMW-LND52
PL Filter (Circular Type) DMW-LPL37¢3, DMW-LPL52
Lens Cap DMW-LFC37¢3, DMW-LFC52
¢2
¢4
¢4
¢4
¢4
Lens Rear Cap DMW-LRC1
Body Cap DMW-BDC1
Tripod Adaptor
¢5
DMW-TA1
AV Cable DMW-AVC1
HDMI mini Cable RP-CDHM15, RP-CDHM30
H-PS45175, H-PS14042, H-VS014140, H-FS100300,
Interchangeable Lens
H-FS045200, H-FS014042, H-FS014045, H-F007014,
H-F008, H-ES045, H-X025, H-H020, H-H014
The 3D Interchangeable Lens H-FT012
Mount Adaptor DMW-MA1, DMW-MA2M, DMW-MA3R
Class 10 64 GB SDXC Memory Card
Class 10 32 GB SDHC Memory Card
Class 10 16 GB SDHC Memory Card
Class 10 8 GB SDHC Memory Card
Class 10 4 GB SDHC Memory Card
Class 6 32 GB SDHC Memory Card
Class 6 16 GB SDHC Memory Card
Class 6 8 GB SDHC Memory Card
Class 6 4 GB SDHC Memory Card
Class 4 16 GB SDHC Memory Card
Class 4 8 GB SDHC Memory Card
Class 4 4 GB SDHC Memory Card
Class 4 2 GB SD Memory Card
•
This unit is compatible with UHS-I
RP-SDU64GE1K
RP-SDA32GE1K/RP-SDU32GE1K
RP-SDA16GE1K/RP-SDU16GE1K
RP-SDA08GE1K/RP-SDU08GE1K
RP-SDU04GE1K
RP-SDQ32GE1K
RP-SDQ16GE1K
RP-SDQ08GE1K
RP-SDQ04GE1K
RP-SDN16GE1A
RP-SDN08GE1A
RP-SDN04GE1A
RP-SDN02GE1A
standard SDHC/SDXC memory cards.
Some optional accessories may not be available in some countries.
¢1 The AC Adaptor (optional) can only be used with the designated Panasonic DC Coupler
(optional). The AC adaptor (optional) cannot be used by itself.
Do not attempt to use AC adaptor in other devices.
¢2 The interchangeble lens (H-PS14042) is not used.
¢3 When the interchangeble lens (H-PS14042) is used
¢4 When the interchangeble lens (H-FS014042) is used
5 Use if the attached lens is in contact with the tripod pedestal.
¢
(ENG) VQT3U05
11
Names and Functions of Main Parts
89
12 13 14 18
11
15 1716
10
∫ Camera body
1 Sensor
2 Self-timer indicator/
AF Assist Lamp
3Flash
4 Lens fitting mark
5 Mount
6 Lens lock pin
7 Lens release button
8 Flash open button
9 Playback button
10 [AF/AE LOCK] button/
[Fn2] button
11 Rear dial
12 Touch screen/LCD monitor
13 [Fn1] button
14 [Q.MENU] button/
Delete/Return button
15 [MENU/SET] button
16 [AF/MF] button
17 Cursor buttons
3/ISO
1/WB (White Balance)
2/AF Mode button
4/[DRIVE MODE] button
This button in picture record mode will allow the user to select between the following
options.
Single/Burst/Auto bracket/Self-timer
18 [DISP.] button
1
23
4567
12
VQT3U05 (ENG)
19 Stereo microphone
23 24 25 26 27
19 21 22
20
34 35 3633
20 Mode dial
21 Shutter button
22 Motion picture button
23 Focus distance reference mark
24 Hot shoe cover
•
Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
25 Camera ON/OFF switch
26 Status indicator
27 Intelligent Auto button
28 Speaker
•
Do not cover the speaker with your fingers,
etc.
29 Shoulder strap eyelet
Be sure to attach the shoulder strap when
•
using the camera to ensure that you will not
drop it.
30 [REMOTE] socket
31 [HDMI] socket
32 [AV OUT/DIGITAL] socket
33 Tripod receptacle
34 Card/Battery door
35 DC coupler cover
•
When using an AC adaptor, ensure that the
Panasonic DC coupler (DMW-DCC9;
optional) and AC adaptor (DMW-AC8E;
optional) are used.
Do not attempt to use AC adaptor in other
devices.
• Always use a genuine Panasonic AC adaptor (DMW-AC8E; optional).
• When using an AC adaptor, use the AC Mains Lead supplied with the AC adaptor.
• It is recommended to use a fully charged battery or AC adaptor when recording motion
pictures.
• If while recording motion pictures using the AC adaptor and the power supply is cut off
due to a power outage or if the AC adaptor is disconnected etc., the motion picture being
recorded will not be recorded.
36 Release lever
28
29
30
31
32
(ENG) VQT3U05
13
∫ Lens
40 41393837
42 37 43 44 45 40 41
H-PS14042
(LUMIX G X VARIO PZ 14–42 mm/
F3.5–5.6 ASPH./POWER O.I.S.)
37 Lens surface
38 Zoom lever
39 Focus lever
40 Contact point
41 Lens fitting mark
42 Tele
43 Focus ring
44 Wide
45 Zoom ring
H-FS014042
(LUMIX G VARIO 14 – 42 mm/F3.5 – 5.6
ASPH./MEGA O.I.S.)
VQT3U05 (ENG)
14
Changing the Lens
By changing the lens, you will increase your picture taking-options and further your
enjoyment of the camera. Change the lens using the following procedure.
•
Check that the camera is turned off.
Detaching the lens
Preparations: Attach the lens cap.
While pressing on the lens release button B, rotate
the lens toward the arrow until it stops and then
remove.
Attaching the lens
Preparations: Remove the lens rear cap from the lens.
•
If the body cap is fitted to the camera, remove it.
Align the lens fitting marks A (red marks) and then rotate the lens in the
direction of the arrow until it clicks.
• Do not press the lens release button B when you attach a lens.
(ENG) VQT3U05
15
Attaching the Shoulder Strap
• We recommend attaching the shoulder strap when using the camera to prevent it from
dropping.
Pass the shoulder strap through the
shoulder strap eyelet on the camera body.
A: Shoulder strap eyelet
Pass the end of the shoulder strap through
the ring in the direction of the arrow and
then pass it through the stopper.
Pass the end of the shoulder strap through
the hole on the other side of the stopper.
Pull the other side of the
shoulder strap and then check
that it will not come out.
• Perform steps 1 to 4 and then attach
the other side of the shoulder strap.
VQT3U05 (ENG)
16
Charging the Battery
∫ About batteries that you can use with this unit
The battery that can be used with this unit is DMW-BLD10E.
Charging
The battery is not charged when the camera is shipped. Charge the battery before use.
•
• Charge the battery with the charger indoors.
Attach the battery paying
attention to the direction of
the battery.
Connect the AC mains lead.
• The [CHARGE] indicator A lights
up and charging begins.
∫ About the [CHARGE] indicator
The [CHARGE] indicator turns on:
The [CHARGE] indicator is turned on during charging.
The [CHARGE] indicator turns off:
The [CHARGE] indicator will turn off once the charging has completed without any
problem. (Disconnect the charger from the electrical socket and detach the battery after
charging is completed.)
∫ Charging time
Charging time Approx. 120 min
•
The indicated charging time is for when the battery has been discharged completely.
The charging time may vary depending on how the battery has been used. The charging
time for the battery in hot/cold environments or a battery that has not been used for a
long time may be longer than normal.
(ENG) VQT3U05
17
Inserting and Removing the Card (optional)/
the Battery
• Check that this unit is turned off.
• We recommend using a Panasonic card.
Slide the release lever in the direction
of the arrow and open the card/
battery door.
• Always use genuine Panasonic batteries
(DMW-BLD10E).
• If you use other batteries, we cannot
guarantee the quality of this product.
Battery: Being careful about the
battery orientation, insert all the way
until you hear a locking sound and
then check that it is locked by lever
A.
Pull the lever A in the direction of the
arrow to remove the battery.
Card: Push it securely all the way
until you hear a “click” while being
careful about the direction in which
you insert it.
To remove the card, push the card
until it clicks, then pull the card out upright.
B: Do not touch the connection terminals of the card.
1:Close the card/battery door.
2:Slide the release lever in the
direction of the arrow.
VQT3U05 (ENG)
18
About the Card
About cards that can be used with this unit
The following cards which conform to the SD video standard can be used with this unit.
(These cards are indicated as card in the text.)
Remarks
SD Memory Card
(8 MB to 2 GB)
SDHC Memory Card
(4 GB to 32 GB)
SDXC Memory Card
(48 GB, 64 GB)
¢ SD Speed Class is the speed standard regarding continuous writing. Check via the label on
the card, etc.
• Use a card with SD Speed Class
higher when recording motion pictures.
• SDHC Memory Card can be used with SDHC Memory Card
or SDXC Memory Card compatible equipment.
• SDXC Memory Card can only be used with SDXC Memory
Card compatible equipment.
• Check that the PC and other equipment are compatible when
using the SDXC Memory Cards.
http://panasonic.net/avc/sdcard/information/SDXC.html
• This unit is compatible with UHS-I standard SDHC/SDXC
memory cards.
• Only the cards with capacity listed left can be used.
e.g.:
Note
Keep the Memory Card out of reach of children to prevent swallowing.
•
¢
with “Class 4” or
(ENG) VQT3U05
19
Setting Date/Time (Clock Set)
ON
OFF
The clock can be setup with the following procedure at the time of purchase. Change the
clock setting in [CLOCK SET] of the [SETUP] menu.
For details, read the PDF.
• The clock is not set when the camera is shipped.
Turn the camera on.
• The status indicator 1 lights when you turn this unit on.
Touch [CLOCK SET].
Touch the items you wish to set (Year/Month/
Day/Hours/Minutes), and set using [3]/[4].
• You can continue to switch the settings by continuously
touching [3]/[4].
• Touch [RETURN] to cancel the date and time settings
without setting a date and time.
To set the display order and the time display format.
•
Touch [STYLE] to display the settings screen for setting
display order/time display format.
Touch [SET] to set.
Touch [SET] in the confirmation screen.
VQT3U05 (ENG)
20
Selecting the Recording Mode
∫ To select a Recording Mode with the mode dial
Select the mode by rotating the mode dial.
• Rotate the mode dial slowly to select the desired mode A.
∫ To select Intelligent Auto Mode
Press [¦].
• [¦] button will light up when it is switched to Intelligent Auto Mode.
• The Recording Mode selected by the mode dial is disabled while the
[
¦] button is lit.
Intelligent Auto Mode
The subjects are recorded using settings automatically selected by the camera.
Programme AE Mode
The subjects are recorded using your own settings.
Aperture-Priority AE Mode
The shutter speed is automatically determined by the aperture value you set.
Shutter-Priority AE Mode
The aperture value is automatically determined by the shutter speed you set.
Manual Exposure Mode
The exposure is adjusted by the aperture value and the shutter speed which are
manually adjusted.
Custom Mode
Use this mode to take pictures with previously registered settings.
Scene Mode
This allows you to take pictures that match the scene being recorded.
Creative Control Mode
Record while checking the image effect.
(ENG) VQT3U05
21
∫ Scene Mode
[PORTRAIT]
This mode allows you to improve the appearance of the
persons concerned and make their skin tones look healthier.
This mode enables the texture of their skin to appear even
[SOFT SKIN]
softer than with [PORTRAIT]. (It is effective when taking
pictures of people from the chest up.)
[SCENERY]
[ARCHITECTURE]
[SPORTS]
[PERIPHERAL
DEFOCUS]
[FLOWER]
[FOOD]
[OBJECTS]
[NIGHT PORTRAIT]
[NIGHT SCENERY]
[ILLUMINATIONS]
[BABY1]
[BABY2]
[PET]
[PARTY] For recording with more natural colours when recording inside.
[SUNSET]
For recording broad vistas.
For recording buildings in sharp focus.
For recording scenes including quickly moving objects with
suitable settings.
For recording with the subject emphasised against a defocused
background.
Flowers outdoors are recorded with natural colours in macro settings.
For recording food in natural colours.
For recording jewellery and other small objects with clarity and
brightness, and crisp colours.
For clearly recording both a human subject and a night view in
the background.
This allows you to take vivid pictures of the nightscape.
Illuminations are photographed beautifully.
For recording with settings optimised for the recording of
babies and pets. In addition, for setting birthdays and names
and having these appear when you play back the recording.
This allows you to take vivid pictures of the red colour of the sun.
∫ Creative Control Mode
[EXPRESSIVE]
[RETRO]
[HIGH KEY]
[LOW KEY]
[SEPIA]
[HIGH DYNAMIC]
[TOY EFFECT]
[MINIATURE EFFECT]
This is a pop art style image effect that emphasises the colour.
This is a soft image effect that gives the appearance of a
tarnished photograph.
This effect brightens the image as a whole and creates a soft
and light ambience.
This effect creates a dark and peaceful atmosphere in the
image as a whole, making bright areas stand out.
A sepia colour image effect.
From dark areas to light areas, this effect creates a
well-balanced light across the entire image.
This effect produces vignetting, making it look like the image
was taken with a toy camera.
This is an imaging effect which defocuses the surroundings to
make it look like a diorama.
VQT3U05 (ENG)
22
Applicable modes:
AB
×
Taking a Still picture
Selecting the Recording Mode.
Press the shutter button halfway to focus.
A Aperture value
B Shutter speed
• Aperture value and shutter speed are displayed. (It
will flash in red if the correct exposure is not achieved,
except when set to flash.)
• When the image is correctly focused, the picture
will be taken, since the [FOCUS PRIORITY] is set
initially to [ON].
Press the shutter button fully (push it in
further), and take the picture.
Taking pictures using the Touch Shutter function
Just by touching the subject to focus, it will focus on the subject and take the picture
automatically.
1 Touch [ ].
2 Touch [ ].
Icon will change to [ ], and taking a picture with the
•
Touch Shutter function becomes possible.
3 Touch the subject you wish to focus on, and then
take a picture.
AF area with same function as [Ø] in AF mode is
•
displayed at the position you touch, and picture is taken
when it is focused when the AF mode is set to [š], [ ], [ ], or [Ø].
4 Touch [ ] to cancel the Touch Shutter function.
(ENG) VQT3U05
23
Taking Pictures using the Automatic Function
×
(Intelligent Auto Mode)
In this mode, the camera makes the optimal settings for the subject and scene, so we
recommend it when you wish to leave the settings to the camera and record without
thinking about them.
Press [¦].
• [¦] button will light up when it is switched to Intelligent Auto Mode.
¦] button is turned off during recording to prevent the light reflecting
[
on glass or similar, but this is not a malfunction.
• [¦] button is turned off when it is pressed again, and it will be set to
the [REC] Modes selected by the mode dial.
• Defocus control can be set by touching [ ] on the recording screen
and then touching [ ].
• When the subject is touched, AF Tracking function works.
∫ Scene Detection
When the camera identifies the optimum scene, the icon of the scene
concerned is displayed in blue for 2 seconds, after which its colour
changes to the usual red.
×
VQT3U05 (ENG)
24
Recording using Intelligent Auto Plus Mode
The brightness and colour optimally set by the camera can be easily matched to your
preferences.
This mode is useful for those who would like the settings made by the camera to match
their preferences but do not like dealing with detailed settings.
Press [MENU/SET] when in Intelligent
Auto Mode.
Press 3/4/2/1 to select the Intelligent Auto Mode Menu [¦] and
then press 1.
Press 1 to select [ ] and then press
[MENU/SET].
Setting brightness
Press the rear dial to display the setting screen.
1
•
Each press of the rear dial switches among brightness
setting, Defocus Control and end operation.
2 Touch the slide bar to set.
•
Setting can also be performed by rotating the rear dial.
Setting colour
1 Press 1 ( ) to display the setting screen.
2 Touch the slide bar to set.
•
This will adjust the colour of the image from a reddish
colour to a bluish colour.
• Setting can also be performed by rotating the rear dial.
• Pressing the 1 cursor button again returns to the
recording screen.
(ENG) VQT3U05
25
Applicable modes:
××
Taking Pictures with Defocus Control Function
You can easily set the blurriness of the background while checking the screen.
Touch [ ].
Touch [ ] to display the setting screen.
Touch the slide bar to set.
• Setting can also be performed by rotating the rear dial.
Recording of pictures or motion pictures.
• It is also possible to record a picture by touching [ ].
• Defocus Control operation can be ended by touching [ ].
VQT3U05 (ENG)
26
Applicable modes:
A
B
C
A
Recording Motion Pictures
•
Screen here is an example of when the Recording Mode is set to
[ ] (Programme AE Mode).
Start recording by pressing the motion picture
button.
A Elapsed recording time
B Available recording time
• Recording of motion picture appropriate for each mode is
possible.
• The recording state indicator (red) C will flash while recording
motion pictures.
Stop the recording by pressing the motion picture button again.
Recording still pictures while recording motion pictures
Still pictures can be recorded even while recording a motion picture. (simultaneous
recording)
During motion picture recording, press the
shutter button fully to record a still picture.
• Simultaneous recording indicator A is displayed while
recording still pictures.
• You can also take pictures using the Touch Shutter function.
(ENG) VQT3U05
27
Applicable modes:
A B
Compensating the Exposure
Use this function when you cannot achieve appropriate exposure due to the difference in
brightness between the subject and the background. Look at the following examples.
Underexposed
Properly
exposed
Overexposed
Compensate the exposure
towards positive.
Compensate the exposure
towards negative.
Press the rear dial to switch to Exposure Compensation operation.
Rotate the rear dial to compensate the exposure.
A Exposure Compensation value
B [EXPO.METER]
• Select [0] to return to the original exposure.
• Rotate the rear dial to display the [EXPO.METER].
VQT3U05 (ENG)
28
Easily set a suitable exposure (one push AE)
A
ョㄏヒ
With one push AE, you can easily achieve a suitable exposure setting when the exposure
setting is too bright or too dark. ( , , modes only)
At purchase, one push AE is assigned to the [Fn1] button.
How to tell if the exposure is not adequate
If the aperture values and shutter speed blink red A when the
•
shutter button is pressed halfway.
• If the Manual Exposure Assistance is anything other than
when in mode.
1 Set the [Fn BUTTON SET] of the [CUSTOM] menu to [ONE PUSH AE].
•
The initial setting for [Fn1] is [ONE PUSH AE].
2 (When exposure is not adequate) Press [Fn1].
•
The exposure meter is displayed, and the aperture and shutter speed are changed to give
a suitable exposure. Which items of the settings change will depend on the Recording
Mode.
(ENG) VQT3U05
29
Using the function button
The recording functions etc. registered in the [Fn BUTTON
SET] of the [CUSTOM] menu can be assigned to the [Fn1],
[Fn2] (function) buttons, [Fn3] and [Fn4] icon.
You can use the assigned functions by pressing the buttons for
[Fn1] and [Fn2] and by touching the icons for [Fn3] and [Fn4].
•
To use [Fn2], set the [AF/AE LOCK /Fn2] of the [CUSTOM] menu
to [Fn2].
Select [Fn1], [Fn2], [Fn3] or [Fn4] from the [Fn BUTTON SET] in the
[CUSTOM] menu and press [MENU/SET].
Select the function you want to assign and press [MENU/SET].
• Assign your favourite function to [Fn1], [Fn2], [Fn3] and [Fn4].
• Exit the menu after it is set.
モョバモユチロヰヤレ
ョㄏビ
ョㄏヒ
VQT3U05 (ENG)
30
Playing Back Pictures/Motion Pictures
A
Playing Back Pictures
Press [(].
Forward or rewind the image by dragging the
screen horizontally.
Forward: drag from right to left
Rewind: drag from left to right
Using the Playback Zoom
Touch the part to enlarge firmly.
1k>2k>4k>8k>16k
A The zoom position indication
• You can also enlarge/reduce the picture by rotating the rear
dial.
• The more a picture is enlarged, the more its quality
deteriorates.
• You can move the enlarged part by dragging the image.
• Picture will return to the original size (1k) by touching [ ].
• When you touch [ ] , the magnification becomes lower.
(ENG) VQT3U05
31
Playing Back Motion Pictures
BA
The motion picture file formats that can be played back on this unit are AVCHD recorded
on a Panasonic Digital Camera (LUMIX) (excluding AVCHD Progressive), MP4, and
QuickTime Motion JPEG.
Press [(].
Select a picture with a Motion Picture icon ([ ])
and then touch [ ] to play back.
A Motion picture icon
B The motion picture recording time
• After playback starts, the elapsed playback time is displayed on
the screen.
For example, 8 minutes and 30 seconds is displayed as
[8m30s].
∫ Operations performed during Motion Picture Playback
Play/Pause Stop
Fast rewind Fast forward
Frame-by-frame rewind
(while pausing)
Reduce volume level Increase volume level
Frame-by-frame forward
(while pausing)
VQT3U05 (ENG)
32
Deleting Pictures
Once deleted, pictures cannot be recovered.
To delete a single picture
Select the picture to be deleted, and then touch
[].
Touch [DELETE SINGLE].
• Confirmation screen is displayed.
Picture is deleted by selecting [YES].
To delete multiple pictures (up to 100¢) or all the pictures
¢ Burst group will be treated as a single picture. (All the pictures in the selected burst group will
be deleted.)
Touch [ ].
Touch [DELETE MULTI] or [DELETE ALL].
• [DELETE ALL] > Confirmation screen is displayed.
Picture is deleted by selecting [YES].
• It is possible to delete all pictures except the ones set as favourite when
[ALL DELETE EXCEPTÜ] is selected with the [DELETE ALL] set.
(When [DELETE MULTI] is selected) Touch the
picture to be deleted.
(repeat this step)
• [‚] appears on the selected pictures. Touching again cancels
the setting.
(When [DELETE MULTI] is selected) Touch [OK].
• Confirmation screen is displayed.
Picture is deleted by selecting [YES].
(ENG) VQT3U05
33
Switching the display of the LCD Monitor
DISP.
AFS
0
AFS
0
WB
ISO
STD.
60
F3.5
0
AWB
1/98
16016
0
Press [DISP.] to change.
(In Recording Mode)
•
Screen will switch as follows:
(Example of LCD monitor display)
L
AFS
AFS
0
989898
A With information
B Without information
C With information (tilt sensor display)
D Without information (tilt sensor display)
(In Playback Mode)
Screen will switch as follows:
•
(Example of LCD monitor display)
L
1/98
1/98
AWB
AWB
0
16
0
60F3.5
F3.5
60
60
F3.5
0
WB
AWB
ISO
160
AFS
P
10:00 1.DEC.2011
s
100-0001
RGB
STD.
STD.
AFS
AFS
1/98
L
0
F3.5
0
100-0001
989898
60
ISO
160
A With information
B Detailed information display
C Histogram display
D Without information
VQT3U05 (ENG)
34
Setting the Menu
or
or
or
A
Press [MENU/SET].
Select the menu item by pressing 3/4 or
by rotating the rear dial.
• Select the item at the very bottom, and press 4 or
rotate the rear dial right to move to the next screen.
Press [MENU/SET] or the rear dial.
• Depending on the menu item, its setting may not appear or it may be displayed in a
different way.
Select the settings by pressing 3/4 or by
rotating the rear dial.
• The figure on the right is an example of setting
[I.DYNAMIC] from [OFF] to [HIGH].
Press [MENU/SET] or the rear dial to set.
∫ Close the menu
Press [ ] several times or press the shutter button halfway.
∫ Switching to other menus
e.g.: Switching to the [SETUP] menu from [REC] Mode menu
1 Press 2.
A Menu toggle icon
2 Press 4 or rotate the rear dial to select the
[SETUP] menu icon [ ].
3 Press 1 or the rear dial.
•
Select a menu item next and set it.
(ENG) VQT3U05
35
Setting the Quick Menu
ヲハヮユワヶ
A
B
By using the Quick Menu, some of the menu settings can be easily found.
Press [Q.MENU] to display the Quick Menu.
Touch the menu item.
• Menu item can be switched by touching [ ]/[ ].
Select and touch the setting.
Touch [EXIT] to exit menu once the setting is
completed.
∫ Change the Quick Menu to your preferred item
1 Touch [ ].
2 Select the menu in the top row and drag it to the
bottom row.
A Items that can be setup as Quick Menus.
B Items that can be displayed in the Quick Menu
screen.
• If there is no empty space in the bottom row, drag it into
the menu item to be replaced.
New item can be set replacing the old item.
• When the item is dragged from the bottom row to the
top row, the setting will be cancelled and that space will
become empty.
3 Touch [EXIT].
•
It will return to screen of above step 1. Touch [EXIT] to switch to the recording screen.
VQT3U05 (ENG)
36
Types of menus
∫ [REC] Mode Menu
This menu lets you set the aspect ratio, number of pixels and other aspects of the pictures
you are recording.
[PHOTO STYLE], [METERING MODE], [I.RESOLUTION], [I.DYNAMIC] and [DIGITAL ZOOM]
•
are common to both the [REC] Mode menu and [MOTION PICTURE] Mode menu. Changing
these settings in one of these menus is reflected in other menu.
[PHOTO STYLE]
[ASPECT RATIO]
[PICTURE SIZE] Set the number of pixels.
[QUALITY]
[FACE RECOG.]
[QUICK AF]
[METERING MODE]
[FLASH]
[RED-EYE REMOVAL]
[FLASH SYNCHRO]
[FLASH ADJUST.]
[I.RESOLUTION]
[I.DYNAMIC] (Intelligent
dynamic range control)
[ISO LIMIT SET]
[ISO INCREMENTS]
[LONG SHTR NR]
[SHADING COMP.]
You can select effects to match the type of image you wish to
record. You can adjust the colour and image quality of the
effects.
Sets the aspect ratio of the image.
Set the compression rate at which the pictures are to be stored.
Sets the focus and exposure automatically prioritising
registered faces.
Speeds up the focusing that takes place when you press the
shutter button.
Sets the light metering method for measuring brightness.
Sets the manner in which the flash works.
Automatically detects red-eye caused by the flash and corrects
the image data accordingly.
Sets the flash synchronisation method.
Adjusts the amount of light released by the flash.
Records pictures with more defined outlines and sense of
clarity.
Automatically corrects contrast and exposure.
When the ISO sensitivity is set to [AUTO] or [ ], an optimal
ISO sensitivity is set with the selected value as an upper limit.
The ISO sensitivity settings values changes in steps of 1/3 EV
or 1 EV.
You can eliminate the generated noise by recording with a
slower shutter speed.
If the screen periphery darkens as a result of lens
characteristics, the brightness in this region will be corrected.
(ENG) VQT3U05
37
[EX. TELE CONV.]
[DIGITAL ZOOM]
[BURST RATE]
[AUTO BRACKET]
[SELF-TIMER] Sets the time until recording for self-timer recording.
[COLOR SPACE]
[STABILIZER]
When the number of pixels is set to anything other than [L], the
Tele effect is increased without degradation in image quality.
Increases the Tele effect. The higher the level of magnification,
the greater the degradation in image quality.
Sets the burst speed for burst recording.
Sets single/burst recording, correction width and recording
sequence for Auto Bracket recording.
Set this when you want to correct the colour reproduction of the
recorded pictures on a PC, printer etc.
When camera shake is sensed during recording, the camera
corrects it automatically.
∫ [MOTION PICTURE] Mode Menu
This menu lets you set the [REC MODE], [REC QUALITY], and other aspects for motion
picture recording.
• [PHOTO STYLE], [METERING MODE], [I.RESOLUTION], [I.DYNAMIC] and [DIGITAL ZOOM]
are common to both the [REC] Mode menu and [MOTION PICTURE] Mode menu. Changing
these settings in one of these menus is reflected in other menu.
– For details, refer to the explanation for the corresponding setting in [REC] Mode menu.
[REC MODE] Sets the file format for the motion pictures you record.
[REC QUALITY]
[PICTURE MODE]
[CONTINUOUS AF]
[EX. TELE CONV.]
[WIND CUT]
[MIC LEVEL DISP.] Set whether or not the mic levels are displayed on the screen.
[MIC LEVEL ADJ.]
[FLICKER RED.]
This sets up the picture quality of motion pictures.
Sets the recording method for still pictures during motion
picture recording.
Continues to focus on the subject for which focus has been
achieved.
If the [REC QUALITY] is set to other than [FSH] and [FHD], the
Tele effect is increased.
This prevents the recording of wind-noise automatically.
Adjust the sound input level to 4 different levels.
The shutter speed can be fixed to reduce the flicker or striping
in the motion picture.
VQT3U05 (ENG)
38
∫ [CUSTOM] Menu
Operation of the unit, such as displaying of the screen and button operations, can be set
up according to your preferences. Also, it is possible to register the modified settings.
[CUST. SET MEM.]
[AF/AE LOCK /Fn2]
[Fn BUTTON SET]
[HISTOGRAM]
[GUIDE LINE]
[HIGHLIGHT]
[EXPO.METER] Set whether or not to display the exposure meter.
[AF/AE LOCK]
[AF/AE LOCK HOLD]
[DIRECT FOCUS AREA]
[FOCUS PRIORITY]
[SHUTTER AF]
[PINPOINT AF TIME]
Registers the current camera settings as custom set.
Assigns AF/AE lock or Fn2 (function button) to the [AF/AE
LOCK]/[Fn2] button.
You can assign various recording and other functions to the
function button.
This allows you to set either to display or not display the
histogram.
This will set the pattern of guide lines displayed when taking a
picture.
When the Auto Review function is activated or when playing
back, white saturated areas appear blinking in black and white.
Sets the fixed content for focusing and exposure when the AF/
AE lock is on.
This will set the operation of [AF/AE LOCK] button when taking
a picture with fixed focus or exposure.
Moves the AF area or MF assist using the cursor button when
recording.
It will set so no picture can be taken when it is out of focus.
Set whether or not the focus is adjusted automatically when the
shutter button is pressed halfway.
Sets the time for which the screen is enlarged when the shutter
button is pressed halfway with Auto Focus Mode set to [ ].
AF assist lamp will illuminate the subject when the shutter
[AF ASSIST LAMP]
button is pressed half-way making it easier for the camera to
focus when recording in low light conditions.
[AF+MF]
[MF ASSIST] When you set the focus manually, the display is enlarged.
[MF GUIDE]
You can set the focus manually after the automatic focus has
finished.
When you set the focus manually, an MF guide that allows you
to check the direction to achieve focus is displayed.
(ENG) VQT3U05
39
[POWER ZOOM LENS]
interchangeable lens that is compatible with power zoom
(electrically operated zoom).
Sets the screen display and lens operations when using an
[LVF DISP.STYLE]
[LCD DISP.STYLE]
[¦ BUTTON SWITCH]
[ BUTTON] Enables/disables the motion picture button.
[ REC AREA]
[REMAINING DISP.]
[PLAY ON LCD]
[TOUCH SETTINGS]
[TOUCH SCROLL]
[DIAL GUIDE] Set whether or not to display the dial operation guide.
[MENU RESUME]
[PIXEL REFRESH]
[SENSOR CLEANING]
[SHOOT W/O LENS]
This will set the display style of the Optional Live Viewfinder.
This will set the display style of the LCD monitor.
It is possible to set how the [¦] button to toggle to Intelligent
Auto Mode will operate.
This changes the angle of view during motion picture recording
and still picture recording.
This will switch display between the number of recordable
pictures and available recording time.
When you switch from Recording Mode to Playback Mode, the
LCD monitor switches on.
Enables/disables the Touch operation.
This allows you to set the speed of continuously forwarding or
rewinding pictures using touch operation.
The last operated menu position is saved even if the camera is
turned off.
It will perform optimisation of imaging device and image
processing.
Dust reduction to blow off the debris and dust that have affixed
to the front of the imaging device is performed.
When no lens is attached to the camera, the shutter is set to cut
out.
VQT3U05 (ENG)
40
∫ Setup Menu
This menu lets you perform the clock settings, select the operating beep tone settings and
set other settings which make it easier for you to operate the camera.
[CLOCK SET]
[WORLD TIME]
[TRAVEL DATE]
[BEEP]
[VOLUME]
[LCD DISPLAY]/
[VIEWFINDER]
[LCD MODE]
[ECONOMY]
[AUTO REVIEW]
[USB MODE]
[VIDEO OUT]
[TV ASPECT]
[HDMI MODE]
[VIERA Link]
[3D PLAYBACK]
[MENU GUIDE]
[LANGUAGE]
[VERSION DISP.]
[NO.RESET] Returns the image file number to 0001.
[RESET]
[FORMAT]
Setting Date/Time.
Sets the times for the region where you live and your holiday
destination.
Departure date and return date of the travel as well as the
name of the travel destination can be set.
Set the volume for electronic noises and the electronic shutter
noise.
Adjust the volume of the speaker to any of 7 levels.
Brightness, colour, or red or blue tint of the LCD monitor/
Optional Live Viewfinder is adjusted.
The brightness of the LCD monitor can be adjusted depending
on how bright it is around the camera.
Suppresses the unit power consumption to prevent the battery
being run down.
Set the length of time that the picture is displayed after taking
the still picture.
Sets the communication method when connecting using the
USB connection cable (supplied).
Set to match the colour television system in each country.
Set to match the type of TV.
Sets the HDMI output image format when playing back via an
HDMI mini cable (optional).
Equipment that supports the VIERA Link will connect
automatically.
Setup the output method for 3D pictures.
Set the screen that is displayed when the mode dial is set to
/.
Set the language displayed on the screen.
This enables the firmware versions of the camera and lens to
be checked.
The [REC] or [SETUP]/[CUSTOM] menu settings are reset to
the initial settings.
The card is formatted.
(ENG) VQT3U05
41
∫ [PLAYBACK] Mode Menu
This menu lets you set the Protection, Cropping or Print Settings, etc. of recorded pictures.
[2D/3D SETTINGS]
[SLIDE SHOW]
[PLAYBACK MODE]
[TITLE EDIT] Input texts (comments) on the recorded pictures.
[TEXT STAMP]
[VIDEO DIVIDE]
[RESIZE] Reduces the image size (number of pixels).
[CROPPING]
[ASPECT CONV.]
[ROTATE] Rotate pictures manually in 90o steps.
[ROTATE DISP.]
[FAVORITE]
[PRINT SET] Sets the images for printing and the number of prints.
[PROTECT]
[FACE REC EDIT]
Switches the playback method for 3D images.
Selects the type etc. of the images and plays back in order.
Selects the type etc. of the images and plays back only
particular images.
Stamps the recorded pictures with recording date and time,
names, travel destination, travel date etc.
Splits the recorded motion picture in two.
Crops the recorded image.
Changes the aspect ratio of images recorded with an aspect
ratio of [16:9] for printing.
This mode allows you to automatically display pictures
vertically if they were recorded holding the camera vertically.
Marks can be added to images, and images can be set as
favourites.
Protects images to prevent deletion by mistake.
Removes or changes information relating to personal identity.
VQT3U05 (ENG)
42
About the supplied software
The supplied CD-ROM includes the following software.
Install the software on to your computer before use.
• PHOTOfunSTUDIO 7.0 HD Edition (Windows XP/Vista/7)
This software allows you to acquire pictures to the PC, and also categorise these acquired
pictures by their recording date or the model name of the camera used. You can resize pictures
and add effects to the pictures. Various printing functions, such as layout printing, and writing
function to CD-R
add the date of recording to pictures with this software.
Also, [AVCHD] motion pictures can be loaded and written to DVD.
¢ This can be used only if the [Recording] tab is displayed on the [Properties] of the CD/DVD
drive on the PC.
• QuickTime (Windows XP/Vista/7)
This software is required for creating panorama pictures and for replay in “PHOTOfunSTUDIO
7.0 HD Edition”.
You can also play back motion pictures (.MP4/.MOV extension) recorded on a digital camera.
This is included as standard in Mac OSs.
• SILKYPIX Developer Studio (Windows XP/Vista/7, Mac OS X v10.4/v10.5/v10.6/v10.7)
This is software to edit RAW format images.
Using RAW files recorded on this camera allows images to be edited with a higher quality.
Edited images can be saved in a format (JPEG, TIFF, etc.) that can be displayed on a personal
computer.
For details on how to use the SILKYPIX Developer Studio, refer to the “Help” or the
Ichikawa Soft Laboratory’s support website:
http://www.isl.co.jp/SILKYPIX/english/p/support/
• LoiLoScope 30 day full trial version (Windows XP/Vista/7)
LoiLoScope is a video editing software where that draws out the full power of your PC. Creating
videos is as easy as organizing cards on top of a desk. Use your music, picture and video files
to create videos to share with your friends and family by burning it to a DVD, uploading it to
websites, or simply share your videos with your friends via e-mail.
– This will only install a shortcut to the trial version download site.
For more information on how to use LoiLoScope, read the LoiLoScope manual
available for download at the link below.
Manual URL: http://loilo.tv/product/20
¢
are supported too. If you forgot to set the date on the digital camera, you can
(ENG) VQT3U05
43
Installing supplied software
• Before inserting the CD-ROM, close all running applications.
Check the environment of your PC.
• Operating environment of “PHOTOfunSTUDIO 7.0 HD Edition”
– OS:
Windows
Windows Vista
Windows
– CPU:
Pentium
Pentium
Pentium
– Display:
1024k768 pixels or more (1920k1080 pixels or more recommended)
– RAM:
512 MB or more (Windows
1 GB or more (Windows
2 GB or more (Windows
– Free hard disk space:
450 MB or more for installing software
• Refer to the operating instructions of “PHOTOfunSTUDIO 7.0 HD Edition” (PDF) for
further operating environment.
R
XP (32bit) SP2/SP3,
R
(32bit) or SP1/SP2,
R
7 (32bit/64bit) or SP1
R
III 500 MHz or higher (WindowsR XP),
R
III 800 MHz or higher (Windows VistaR),
R
III 1 GHz or higher (WindowsR 7)
R
XP/Windows VistaR),
R
7 32bit),
R
7 64bit)
• For details on SILKYPIX Developer Studio 3.1 SE, please read the support site given on
P43.
Insert the CD-ROM with the supplied software.
• When you insert the supplied CD-ROM, the install menu will start.
Click on the [Recommended Installation].
• Proceed with installation according to messages appearing on the screen.
Note
The software compatible with your PC will be installed.
•
• “PHOTOfunSTUDIO 7.0 HD Edition” is not compatible with Mac.
• On the Mac, SILKYPIX can be installed manually.
1 Insert the CD-ROM with the supplied software.
2 Double-click on the automatically displayed folder.
3 Double-click the icon in the application folder.
VQT3U05 (ENG)
44
Reading the Operating Instructions (PDF format)
More detailed instructions on the operation of this camera are contained in
“Operating Instructions for advanced features (PDF format)” in the supplied
CD-ROM. Install it on your PC to read it.
∫ For Windows
Turn the PC on and insert the CD-ROM containing the Operating
Instructions (supplied).
Select the desired language and then click
[Operating Instructions] to install.
Double click the “Operating Instructions”
shortcut icon on the desktop.
∫ When the Operating Instructions (PDF format) will
not open
You will need Adobe Acrobat Reader 5.0 or later or Adobe
Reader 7.0 or later to browse or print the Operating
Instructions (PDF format).
Insert the CD-ROM containing the Operating Instructions (supplied), click A and then
follow the messages on the screen to install.
(Compatible OS: Windows XP SP3/Windows Vista SP2/Windows 7)
•
You can download and install a version of Adobe Reader that you can use with your OS from
the following Web Site.
http://get.adobe.com/reader/otherversions
∫ To uninstall the Operating Instructions (PDF format)
Delete the PDF file from the “Program Files\Panasonic\Lumix\” folder.
∫ For Mac
Turn the PC on and insert the CD-ROM containing the Operating
Instructions (supplied).
Open the “Manual” folder in the CD-ROM and then copy the PDF file
with the desired language inside the folder.
Double click the PDF file to open it.
(ENG) VQT3U05
45
Specifications
Digital Camera Body (DMC-GX1):
Information for your safety
Power Source: DC 8.4 V
Power Consumption: 2.6 W (When recording with LCD Monitor)
[When the Interchangeable lens (H-PS14042) is used]
2.7 W (When recording with LCD Monitor)
[When the Interchangeable lens (H-FS014042) is used]
1.6 W (When playing back with LCD Monitor)
[When the Interchangeable lens (H-PS14042) is used]
1.7 W (When playing back with LCD Monitor)
[When the Interchangeable lens (H-FS014042) is used]
Camera effective pixels
Image sensor 4/3q Live MOS sensor, total pixel number 16,680,000 pixels,
Digital Zoom Max. 4k
Extra Tele Conversion
(Except for the
maximum picture size
for each aspect ratio)
Focus Auto Focus/Manual Focus,
Shutter system Focal-plane shutter
Burst recording
Burst speed 20 pictures/second (Super high speed),
Number of
recordable pictures
16,000,000 pixels
Primary colour filter
ON/OFF simple enlargement (compatible with lenses from
other manufacturers)
Face Detection/AF Tracking/23-area-focusing/
1-area-focusing/Pinpoint (Touch focus area selection
possible)
4.2 pictures/second (High speed),
3 pictures/second (Middle speed),
2 pictures/second (Low speed)
9 pictures (when there are RAW files)
Depends on the capacity of the card
(when there are no RAW files)
VQT3U05 (ENG)
46
ISO sensitivity
(Standard Output
AUTO/ /160/200/400/800/1600/3200/6400/12800
(1/3 EV step change possible)
Sensitivity)
Minimum Illumination Approx. 9 lx (when i-Low light is used, the shutter speed is
1/25th of a second)
[When the Interchangeable lens (H-PS14042) is used]
Approx. 9 lx (when i-Low light is used, the shutter speed is
1/25th of a second)
[When the Interchangeable lens (H-FS014042) is used]
Shutter speed B (Bulb) (Max. approx. 120 seconds),
60 seconds to 1/4000th
of a second
Taking still pictures during motion picture recording
Motion picture priorities: 1/25th of a second to 1/16000th of a
second
Still picture priorities: B (Bulb) (Max. approx. 120 seconds),
60 seconds to 1/4000th of a second
Metering range EV 0 to EV 18
White Balance Auto White Balance/Daylight/Cloudy/Shade/Incandescent
lights/Flash/White set1/White set2/White Balance K set
Exposure (AE) Programme AE (P)/Aperture-priority AE (A)/Shutter-priority
AE (S)/Manual exposure (M)/AUTO
Exposure Compensation (1/3 EV Step, j5EV to i5EV)
Metering Mode Multiple/Centre weighted/Spot
LCD monitor 3.0q TFT LCD (3:2)
(Approx. 460,000 dots) (field of view ratio about 100%)
Touch screen
Flash Built-in pop up flash
GN 7.6 equivalent (ISO160·m)
Flash range:
Approx. 40 cm (1.32 feet) to 6.8 m (22.4 feet)
[When the Interchangeable lens (H-PS14042) is mounted,
WIDE, [ISO AUTO] is set]
Flash range:
Approx. 1.0 m (3.29 feet) to 6.8 m (22.4 feet)
[When the Interchangeable lens (H-FS014042) is mounted,
WIDE, [ISO AUTO] is set]
AUTO, AUTO/Red-Eye Reduction, Forced ON, Forced ON/
Red-Eye Reduction, Slow Sync., Slow Sync./Red-Eye
Reduction, Forced OFF
(ENG) VQT3U05
47
Flash synchronization
Equal to or smaller than 1/160th of a second
speed
Microphone Stereo
Speaker Monaural
Recording media SD Memory Card/SDHC Memory Card/SDXC Memory Card
Picture size
Still picture When the aspect ratio setting is [X]
4592k3448 pixels, 3232k2424 pixels, 2272k1704 pixels
When the aspect ratio setting is [Y]
4576k3056 pixels, 3232k2160 pixels, 2272k1520 pixels
When the aspect ratio setting is [W]
4576k2576 pixels, 3232k1824 pixels, 1920k1080 pixels
When the aspect ratio setting is [ ]
3424k3424 pixels, 2416k2416 pixels, 1712k1712 pixels
Recording quality
Motion pictures [AVCHD]
When set to [FSH]: 1920k1080 pixels (50i
Approx. 17 Mbps)/
When set to [SH]: 1280k720 pixels (50p
¢
recording/
¢
recording/
Approx. 17 Mbps)
(
¢Sensor output is 25 frames/sec.)
[MP4]
When set to [FHD]: 1920k1080 pixels (25 frames/sec.,
Approx. 20 Mbps)/
When set to [HD]: 1280k720 pixels (25 frames/sec.,
Approx. 10 Mbps)/
When set to [VGA]: 640k480 pixels (25 frames/sec.,
Approx. 4 Mbps)
Quality RAW/RAWiFine/RAWiStandard/Fine/Standard/MPOiFine/
MPOiStandard
Recording file format
Still Picture RAW/JPEG (based on “Design rule for Camera File system”,
based on “Exif 2.3” standard, DPOF corresponding)/MPO
Motion pictures AVCHD/MP4
Audio compression AVCHD Dolby Digital (2 ch)
MP4 AAC (2 ch)
VQT3U05 (ENG)
48
Interface
Digital “USB 2.0” (High Speed)
¢ Data from the PC can not be written to the camera using the
USB connection cable.
Analogue video/
audio
NTSC/PAL Composite (Switched by menu)
Audio line output (monaural)
Terminal
[REMOTE] φ 2.5 mm jack
[AV OUT/DIGITAL] Dedicated jack (8 pin)
[HDMI] MiniHDMI TypeC
Dimensions Approx. 116.3 mm (W)k67.8 mm (H)k39.4 mm (D)
[4.58q (W)k2.67q(H)k1.55q (D)]
(excluding the projecting parts)
Mass Approx. 318 g/0.70 lb
[with the card and battery]
Approx. 272 g/0.60 lb (camera body)
Approx. 413 g
/0.91 lb
[with the Interchangeable lens (H-PS14042), card and battery]
Approx. 483 g/1.06 lb
[with the Interchangeable lens (H-FS014042), card and battery]
Operating temperature 0 oC to 40 oC (32 oF to 104 oF)
Operating humidity 10%RH to 80%RH
Battery Charger (Panasonic DE-A94A):
Information for your safety
Input: AC 110 V to 240 V, 50/60 Hz, 0.2 A
Output: DC 8.4 V, 0.65 A
Battery Pack (lithium-ion) (Panasonic DMW-BLD10E):
Information for your safety
Voltage/capacity: 7.2 V/1010 mAh
(ENG) VQT3U05
49
Interchangeable Lens (H-PS14042)
“LUMIX G X VARIO PZ 14–42 mm/F3.5–5.6 ASPH./POWER O.I.S.”
Focal length f=14 mm to 42 mm
(35 mm film camera equivalent: 28 mm to 84 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Aperture range F3.5 (Wide) to F5.6 (Tele)
Minimum aperture
F22
value
Lens construction 9 elements in 8 groups (4 aspherical lenses, 2 ED Lens)
Nano surface coating Ye s
In focus distance 0.2 m (0.66 feet) (Wide to focal length 20 mm) to ¶ (from the
focus distance reference line),
0.3 m (0.99 feet) (focal length 21 mm to Tele) to ¶ (from the
focus distance reference line)
Maximum image
0.17k (35 mm film camera equivalent: 0.34k)
magnification
Optical Image
Available
Stabiliser
[O.I.S.] switch None
(Setting of the [STABILIZER] is done in [REC] menu.)
Mount “Micro Four Thirds Mount”
Angle of view 75x (Wide) to 29x (Tele)
Filter diameter 37 mm (1.46 inch)
Max. diameter Approx. 61 mm (2.40 inch)
Overall length Approx. 26.8 mm (1.06 inch) (from the tip of the lens to the
base side of the lens mount when the lens barrel is recessed)
Mass Approx. 95 g
/0.21 lb
VQT3U05 (ENG)
50
Interchangeable Lens (H-FS014042)
“LUMIX G VARIO 14– 42 mm/F3.5 – 5.6 ASPH./MEGA O.I.S.”
Focal length f=14 mm to 42 mm
(35 mm film camera equivalent: 28 mm to 84 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Aperture range F3.5 (Wide) to F5.6 (Tele)
Minimum aperture value
F22
Lens construction 12 elements in 9 groups (1 aspherical lens)
In focus distance 0.3 m (0.99 feet) to ¶ (from the focus distance reference line)
Maximum image
0.16k (35 mm film camera equivalent: 0.32k)
magnification
Optical Image
Available
Stabiliser
[O.I.S.] switch None (Setting of the [STABILIZER] is done in [REC] menu.)
Mount “Micro Four Thirds Mount”
Angle of view 75x (Wide) to 29x (Tele)
Filter diameter 52 mm (2.05 inch)
Max. diameter Approx. 60.6 mm (2.39 inch)
Overall length Approx. 63.6 mm (2.50 inch)
(from the tip of the lens to the base side of the lens mount)
Mass Approx. 165 g/
0.36 lb
(ENG) VQT3U05
51
• G MICRO SYSTEM is a lens exchange type digital camera
EU
VQT3U05
F1111 KD0
Pursuant to at the directive 2004/108/EC, article 9(2)
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Panasonic Corporation
Web Site: http://panasonic.net
Panasonic Corporation 2011
system of LUMIX based on a Micro Four Thirds System
standard.
• Micro Four Thirds™ and Micro Four Thirds Logo marks are
trademarks or registered trademarks of Olympus Imaging
Corporation, in Japan, the United States, the European
Union and other countries.
• Four Thirds™ and Four Thirds Logo marks are trademarks
or registered trademarks of Olympus Imaging Corporation,
in Japan, the United States, the European Union and other
countries.
• SDXC Logo is a trademark of SD-3C, LLC.
• “AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
• Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
• HDMI, the HDMI Logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
• HDAVI Control™ is a trademark of Panasonic Corporation.
• QuickTime and the QuickTime logo are trademarks or
registered trademarks of Apple Inc., used under license
therefrom.
• Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the United
States and/or other countries.
• Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
• Windows and Windows Vista are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Other names of systems and products mentioned in these instructions are usually the
registered trademarks or trademarks of the manufacturers who developed the system or
product concerned.
This product is licensed under the AVC patent portfolio license for the personal and
non-commercial use of a consumer to (i) encode video in compliance with the AVC Standard
(“AVC Video”) and/or (ii) decode AVC Video that was encoded by a consumer engaged in a
personal and non-commercial activity and/or was obtained from a video provider licensed to
provide AVC Video. No license is granted or shall be implied for any other use. Additional
information may be obtained from MPEG LA, LLC. See http://www.mpegla.com
.
Loading...
