Panasonic DMC-FZ300 Basic Manual

Basic Owner’s Manual

Digital Camera

Model No. DMC-FZ300

Please read these instructions carefully before using this product, and save this manual
for future use.

More detailed instructions on the operation of this camera are
contained in “Owner’s Manual for advanced features (PDF format)” in
the supplied disc.

Register online at http://shop.panasonic.com/support (U.S. customers only)

If you have any questions, visit:
USA : http://shop.panasonic.com/support
Canada : www.panasonic.ca/english/support

PP

SQT0946

M0715KZ0

Dear Customer,

Date of Purchase Dealer Phone No.

Dealer Purchased From Model No.

Dealer Address Serial No.

Thank you for choosing Panasonic!

You have purchased one of the most sophisticated and reliable products on the market
today. Used properly, we’re sure it will bring you and your family years of enjoyment.
Please take time to fill in the information below. The serial number is on the tag located
on the underside of your camera. Be sure to retain this manual as your convenient
camera information source.

Please note that the actual controls and components, menu items, etc. of your Digital
Camera may look somewhat different from those shown in the illustrations in this Owner’s
Manual.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast material for
purposes other than your own private use may infringe copyright laws. Even for the
purpose of private use, recording of certain material may be restricted.

For the U.S.A. and Canada only

A lithium ion battery that is recyclable powers the product you have
purchased. Please call 1-800-8-BATTERY for information on how to
recycle this battery.

Information for Your Safety

WARNING:

To reduce the risk of fire, electric shock or product damage,

• Do not expose this unit to rain, moisture, dripping or splashing.

• Use only the recommended accessories.

• Do not remove covers.

• Do not repair this unit by yourself. Refer servicing to qualified service

personnel.

The socket outlet shall be installed near the equipment and shall be easily accessible.

SQT0946 (ENG)

2

■

Product identification marking

Product Location

Digital camera Bottom
Battery charger Bottom

THE FOLLOWING APPLIES ONLY IN THE U.S.A.

Certification and Compliance

See Camera for the certification and compliance mark specific to that device.

1 Select [Wi-Fi] in the [Setup] menu
2 Select [Wi-Fi Setup] in the [Wi-Fi]
3 Press

Contains FCC ID : VPYLBXN604

This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.

This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65.
This equipment has very low levels of RF energy that are deemed to comply without
testing of specific absorption ratio (SAR).

to select [Approved Regulations], and press [MENU/SET]

SQT0946 (ENG)

3

THE FOLLOWING APPLIES ONLY IN THE U.S.A.

FCC Note:

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, follow the attached installation

Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.

Declaration of Conformity
Trade Name: Panasonic
Model No.: DMC-FZ300

Responsible Party: Panasonic Corporation of North America

Support Contact: http://www.panasonic.com/contactinfo

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

instructions and use only shielded interface cables with ferrite core when
connecting to computer or peripheral devices.

Two Riverfront Plaza, Newark, NJ 07102-5490

DMC-FZ300

SQT0946 (ENG)

4

THE FOLLOWING APPLIES ONLY IN CANADA.

Certification and Compliance

See Camera for the certification and compliance mark specific to that device.

1 Select [Wi-Fi] in the [Setup] menu
2 Select [Wi-Fi Setup] in the [Wi-Fi]
3 Press

CAN ICES-3(B)/NMB-3(B)

Contains IC : 772C-LBXN604

This device complies with RSS-210 of the IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired operation of the device.

This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment has very low levels of RF energy that are deemed to comply without testing
of specific absorption ratio (SAR).

to select [Approved Regulations], and press [MENU/SET]

SQT0946 (ENG)

5

■

About the battery pack

CAUTION

Battery pack (Lithium ion battery pack)

• Use the specified unit to recharge the battery pack.

• Do not use the battery pack with equipment other than the specified unit.

• Do not get dirt, sand, liquids, or other foreign matter on the terminals.

• Do not touch the plug terminals (+ and −) with metal objects.

• Do not disassemble, remodel, heat or throw into fire.

If any electrolyte should come into contact with your hands or clothes, wash it off
thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse
eyes thoroughly with water, and then consult a doctor.

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only with the type

recommended by the manufacturer.

• When disposing of the batteries, please contact your local authorities or dealer and

ask for the correct method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time
with doors and windows closed.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C (140 °F) or
incinerate.

■

About the battery charger

CAUTION!
To reduce the risk of fire, electric shock or product damage,

• Do not install or place this unit in a bookcase, built-in cabinet or in another

confined space. Ensure this unit is well ventilated.

Battery charger

This battery charger operates on AC between 110V and 240V.
But

• In the U.S.A. and Canada, the battery charger must be connected to a 120V AC
power supply only.

• When connecting to an AC supply outside of the U.S.A. or Canada, use a plug
adaptor to suit the AC outlet configuration.

SQT0946 (ENG)

6

■

Cautions for Use

• Do not use any other USB connection cables except the supplied one or a genuine
Panasonic USB connection cable (DMW-USBC1: optional).

• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

• Use a “High Speed HDMI micro cable” with the HDMI logo. Cables that do not comply
with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D-Type A plug, up to 2 m (6.6 feet) long)

• Always use a genuine Panasonic shutter remote control (DMW-RSL1: optional).

Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise adversely
affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong magnetic
fields created by speakers or large motors.

• Electromagnetic wave radiation may adversely affect this unit, disturbing the pictures
and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops functioning
properly, turn this unit off and remove the battery or disconnect AC adaptor (DMW­AC10PP: optional). Then reinsert the battery or reconnect AC adaptor and turn this unit
on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures and/or
sound may be adversely affected.

SQT0946 (ENG)

7

Contents

■
