Panasonic DBS Section 400 Programming Guide

Download
Digital Business System
Section 400
Programming
USA
(Applies to CPC-AII/B Version 9.2
and CPC-EX Version 2.3)
Doc. Part No. 7L0182AZDJ
Issued August 1,1995
Revised April 2000
The contents of this document are subject to change without notice and do not constitute a commitment on the part of Panasonic Telecommunication Systems Company (PTSC). Every effort has been made to ensure the accuracy of this document. However, due to ongoing product improvements and revisions, PTSC cannot guarantee the accuracy of printed material after the date of publication, nor can it accept responsibility for errors or omissions. PTSC will update and revise this document as needed.
The software and hardware described in this document may be used or copied only in accordance with the terms of the license pertaining to said software or hardware.
© 1995 by Panasonic Telecommunication Systems Company (PTSC)
Revised April 2000
All rights reserved.

Section 400-Programming Table of Contents

Section 400-Table of Contents
About This Section
Structure........................................................................................................................... xvii
FF Key Programming ...................................................................................................... xvii
Program Sequence .......................................................................................................... xviii
Introduction to DBS Programming
Before You Begin................................................................................................ Intro-3
Preparations for Programming.................................................................................... Intro-3
Initializing DBS Systems (RAMCLR)....................................................................... Intro-4
Upgrading CPC-B Software (New Function Reset)................................................... Intro-5
Understanding FF Key Programming.............................................................. Intro-6
Program Structure....................................................................................................... Intro-6
How to Enter the Programming Mode........................................................................ Intro-7
Example Programming Entry ..................................................................................... Intro-9
Default Program Settings................................................................................... Intro-9
Chapter 1. System Programming (FF1)
Date and Time Settings ............................................................................................. 1-3
Day/Date Setting............................................................................................................. 1-3
Time Setting.................................................................................................................... 1-5
General System Settings............................................................................................ 1-6
Call Duration Display..................................................................................................... 1-6
SMDR Display Start Timer for CO Calls....................................................................... 1-7
Least Cost Routing (LCR) Access.................................................................................. 1-8
Override Toll Restriction With SSD Numbers............................................................... 1-9
SSD Display Restriction............................................................................................... 1-10
Auto Flash Redial ......................................................................................................... 1-11
One Touch Dial............................................................................................................. 1-12
Onhook Transfer........................................................................................................... 1-13
Key Bank Hold ............................................................................................................. 1-14
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - iii -
Table of Contents Section 400-Programming
Non-Appearing Trunk Hold.......................................................................................... 1-15
SLT Flash Control ........................................................................................................ 1-16
Extension Number Digits.............................................................................................. 1-18
Alternate Attendant....................................................................................................... 1-19
Attendant Intercom Calling .......................................................................................... 1-20
Extension Intercom Calling .......................................................................................... 1-21
Alert Tone for Voice Calls............................................................................................ 1-22
Alert Tone for Busy Override & OHVA ...................................................................... 1-23
System Installation Area Code ..................................................................................... 1-24
SSD Name Display....................................................................................................... 1-25
API/AEC Slot Assignment ........................................................................................... 1-26
Voice Mail Busy Tone.................................................................................................. 1-27
Analog Transfer Ring Pattern....................................................................................... 1-28
Attendant Overflow for Primary Attendant.................................................................. 1-29
Delayed Ring ................................................................................................................ 1-30
AEC Disconnect Signal Duration................................................................................. 1-31
Second Attendant Position............................................................................................ 1-32
Third Attendant Position............................................................................................... 1-33
Fourth Attendant Position............................................................................................. 1-34
Attendant Transfer Extension....................................................................................... 1-35
Attendant Override ....................................................................................................... 1-36
Attendant LED Alarm Indication ................................................................................. 1-37
Extension (BLF) Delayed Ring .................................................................................... 1-38
Analog Transfer Ring Pattern....................................................................................... 1-39
Multiple DID/DNIS...................................................................................................... 1-40
Page Duration ............................................................................................................... 1-42
SLT DISA Ring Pattern................................................................................................ 1-43
AEC Disconnect Signal Duration................................................................................. 1-44
DID/DNIS to a Voice Mailbox..................................................................................... 1-46
DID/DNIS Answer Code.............................................................................................. 1-48
LCD Timer for Caller ID.............................................................................................. 1-50
Internal Hold Tone........................................................................................................ 1-51
Door Opener Access Code Required............................................................................ 1-52
API Port Type............................................................................................................... 1-53
API Baud Rate .............................................................................................................. 1-54
Serial Port Parameters (TTY Settings).................................................................. 1-55
Parity Check.................................................................................................................. 1-55
Odd/Even Parity............................................................................................................ 1-56
Baud Rate...................................................................................................................... 1-57
Stop Bit Length............................................................................................................. 1-58
Data Length................................................................................................................... 1-59
SMDR Printing Mode 1: Outbound and Inbound......................................................... 1-60
SMDR Printing Mode 2: Long-Distance and Local Calls............................................ 1-61
SMDR Printing Mode 3: Header Title.......................................................................... 1-62
- iv - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
Serial Port Flow Control (XON / XOFF) .................................................................... 1-63
RAI Baud Rate.............................................................................................................. 1-64
PBX Settings............................................................................................................. 1-65
PBX Access Code(s)................................................................................................... 1-65
Automatic Pause Position For PBX Access Codes ...................................................... 1-66
External (UNA) Relay Control............................................................................... 1-68
Ring Patterns For UNA Terminals (M, C and B)........................................................ 1-68
External Page Interface Control For Paging Groups .................................................... 1-69
Class of Service ........................................................................................................ 1-70
Extension Class Of Service........................................................................................... 1-70
Account Codes...................... ................... ................... .................. ................... ......... 1-72
Verified Forced Account Codes ................................................................................... 1-72
Toll Restriction For Verified Forced Account Codes................................................... 1-74
Flexible Function Screens ....................................................................................... 1-75
Flexible Function Screen Soft-Key Assignment .......................................................... 1-75
Flexible Function Screen Text...................................................................................... 1-80
Flexible Function Screen Default ................................................................................. 1-81
Flexible Function Screens Default (All)....................................................................... 1-82
Caller ID Automatic DISA...................................................................................... 1-83
Automatic DISA Callers............................................................................................... 1-83
Door Phones ............................................................................................................. 1-84
Door Phone Extensions................................................................................................. 1-84
Door Phone Ring Assignments..................................................................................... 1-86
Door Opener Access Code............................................................................................ 1-88
Door Phone Tone Type................................................................................................. 1-89
Door Phone Ring Timeout Timer................................................................................. 1-90
Door Phone Ring Pattern.............................................................................................. 1-91
Door Opener Relay Timer ............................................................................................ 1-92
System Timers.......................................................................................................... 1-93
Automatic Night Mode Start Time............................................................................... 1-93
Attendant Hold Recall Timer for CO Calls .................................................................. 1-95
Extension Hold Recall Timer for CO Calls.................................................................. 1-96
Attendant Transfer Recall Timer for CO Calls............................................................. 1-97
Extension Transfer Recall Timer for CO Calls ............................................................ 1-98
Attendant Hunt Group Recall Timer ............................................................................ 1-99
Extension Hunt Group Recall Timer .......................................................................... 1-100
Attendant Park Hold Recall Timer ............................................................................. 1-101
Extension Park Hold Recall Timer............................................................................. 1-102
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - v -
Table of Contents Section 400-Programming
Attendant Call Reversion Timer for CO Calls............................................................ 1-103
Unsupervised Conference Timer ................................................................................ 1-104
Automatic Pause Timer .............................................................................................. 1-105
CO Flash Timer .......................................................................................................... 1-106
SLT Onhook Flash Timer........................................................................................... 1-108
CO Ring Cycle Detection Timer ................................................................................ 1-109
Inbound Ring Cycle Expansion Timer ....................................................................... 1-110
Dial Pause Timer ........................................................................................................ 1-111
PBX Flash Timer ........................................................................................................ 1-112
Call Forward-No Answer Timer................................................................................. 1-113
Outbound Ground Start Detection Timer ................................................................... 1-114
Inbound Ground Start Detection Timer...................................................................... 1-115
Attendant Hold Recall Timer for Intercom Calls ....................................................... 1-116
Extension Hold Recall Timer for Intercom Calls....................................................... 1-117
Attendant Transfer Recall Timer for Intercom Calls.................................................. 1-118
Extension Transfer Recall Timer for Intercom Calls.................................................. 1-119
CO Delayed Ring Timer............................................................................................. 1-120
Extension (DSS/BLF) Delayed Ring Timer............................................................... 1-122
Hunt Group No Answer Timer................................................................................... 1-124
Automatic Day Mode Start Time................................................................................ 1-125
Automatic Night 2 Mode Start Time.......................................................................... 1-127
Programming and DISA Codes............................................................................ 1-129
Remote Programming ID Code .................................................................................. 1-129
DISA Inbound Call ID Code ...................................................................................... 1-130
DISA Outbound Call ID Code 1................................................................................. 1-131
DISA Outbound Call ID Code 2................................................................................. 1-132
ID Code For System Programming ............................................................................ 1-133
New Function Reset............................................................................................... 1-134
DID/DNIS and T1 Settings.................................................................................... 1-135
Inbound DID Dial Numbers ....................................................................................... 1-135
System Configuration ................................................................................................. 1-137
Sync Source 1 ............................................................................................................. 1-143
Sync Source 2 ............................................................................................................. 1-145
Sync Source 3 ............................................................................................................. 1-146
Network Re-Sync Timer............................................................................................. 1-147
Disconnect Timer........................................................................................................ 1-148
Guard Timer................................................................................................................ 1-149
Release Acknowledge Timer...................................................................................... 1-150
Outpulse Delay Timer................................................................................................. 1-151
Wink Timeout Timer .................................................................................................. 1-152
Incoming Detection Timer.......................................................................................... 1-153
Answer Supervision Timer......................................................................................... 1-154
- vi - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
Immediate Glare Timer............................................................................................... 1-155
Wink Glare Timer....................................................................................................... 1-156
Digital Pad Settings .................................................................................................... 1-157
Trunk Configuration ................................................................................................... 1-160
Number of T1 Channels.............................................................................................. 1-161
Frame Format.............................................................................................................. 1-163
Line Coding ................................................................................................................ 1-164
Failure Mode............................................................................................................... 1-165
Remote Loopback....................................................................................................... 1-166
Yellow Alarm Send .................................................................................................... 1-167
Flash Key Operation................................................................................................... 1-168
Red Alarm Detection .................................................................................................. 1-169
Yellow Alarm Detection............................................................................................. 1-170
Yellow Alarm Recovery............................................................................................. 1-172
Other Alarms Detection.............................................................................................. 1-174
Other Alarms Recovery .............................................................................................. 1-176
Frame Loss Counter.................................................................................................... 1-177
Slip Counter................................................................................................................ 1-178
Red Alarm Counter..................................................................................................... 1-179
Loss of Signal Counter ............................................................................................... 1-180
Sync Loss Counter...................................................................................................... 1-181
Yellow Alarm Counter................................................................................................ 1-182
Yellow Alarm Relay................................................................................................... 1-183
Red Alarm Relay ........................................................................................................ 1-184
Sync Loss Relay.......................................................................................................... 1-185
Frame Loss Relay ....................................................................................................... 1-186
AIS Relay.................................................................................................................... 1-187
Relay Reset ................................................................................................................. 1-188
T1 Trunk Type Emulation .......................................................................................... 1-189
DID/DNIS................................................................................................................... 1-190
Outgoing Signaling Type............................................................................................ 1-191
Incoming Signaling Type............................................................................................ 1-192
Trunk Mode ................................................................................................................ 1-193
Robbed Bit Setting...................................................................................................... 1-194
Incoming Dialing Method........................................................................................... 1-195
Dial Tone Transmission.............................................................................................. 1-196
Busy Tone Transmission ............................................................................................ 1-197
Dial Tone Receive ...................................................................................................... 1-198
Ringback Tone Transmission ..................................................................................... 1-199
DNIS Number Setting................................................................................................. 1-200
DID/DNIS Flexible Ringing Assignments ................................................................. 1-201
T1 Trunk Closure........................................................................................................ 1-203
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - vii -
Table of Contents Section 400-Programming
Chapter 2. Trunk Programming (FF2)
Trunk Port Operation...................................................................................................... 2-3
DTMF/Pulse Dialing for Trunks..................................................................................... 2-4
Pooled Trunk Access for Group “9”............................................................................... 2-5
Pooled Trunk Access for Groups “81-86”...................................................................... 2-6
Trunk Port Type.............................................................................................................. 2-7
DISA Auto Answer......................................................................................................... 2-8
Private Trunk Line.......................................................................................................... 2-9
Automatic Pause for PBX Line .................................................................................... 2-10
Dial Tone Detection...................................................................................................... 2-11
Outbound DTMF Signal Duration for Auto-Dialed Digits .......................................... 2-12
Unsupervised Trunk Conference .................................................................................. 2-13
Inbound Ring Pattern.................................................................................................... 2-14
Trunk Disconnect Detection Timer .............................................................................. 2-15
DISA Start Time........................................................................................................... 2-16
DISA End Time ............................................................................................................ 2-17
Trunk Circuit Type ....................................................................................................... 2-18
DID Immediate or Wink Start ...................................................................................... 2-21
Wink Start Timer .......................................................................................................... 2-22
Time Out for Dialed DID Digits................................................................................... 2-23
DID Interdigit Timeout................................................................................................. 2-24
Trunk Port Class ........................................................................................................... 2-25
Chapter 3. Extension Programming (FF3)
Extension Numbers......................................................................................................... 3-3
Terminal Type................................................................................................................. 3-5
EM/24 Port Assignment.................................................................................................. 3-7
Forced Least Cost Routing ............................................................................................. 3-8
Forced Account Codes.................................................................................................... 3-9
Extension Lockout Code............................................................................................... 3-10
Offhook Signal (CO) .................................................................................................... 3-11
Call Waiting/OHVA..................................................................................................... 3-12
Busy Override Send...................................................................................................... 3-13
Busy Override Receive................................................................................................. 3-14
Prime Line Pickup ........................................................................................................ 3-15
Auto Pickup (Ringing Line) ......................................................................................... 3-16
Unsupervised Conference............................................................................................. 3-17
Station Message Detail Recorder (SMDR) Report....................................................... 3-18
Offhook Signal Volume................................................................................................ 3-19
Offhook Signal Pattern ................................................................................................. 3-20
PSD Name Display on Large-Sized LCD Phones........................................................ 3-21
- viii - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
Page Group Extensions................................................................................................. 3-22
Display When Idle ........................................................................................................ 3-23
Display During Intercom Dial Tone............................................................................. 3-25
Display When Calling an Extension............................................................................. 3-27
Display When Accessing CO Dial Tone ...................................................................... 3-29
Display When Conversing on a CO Trunk................................................................... 3-31
Display When Receiving a Page................................................................................... 3-33
Display After Receiving a Call Waiting Tone.............................................................. 3-35
Display When Dialing a Busy Extension ..................................................................... 3-37
Extension Directory Display......................................................................................... 3-39
Extension Class of Service Assignment ....................................................................... 3-40
Inbound DID Dial Numbers ......................................................................................... 3-41
AEC Disconnect ........................................................................................................... 3-41
Ringback Tone From ML Keys.................................................................................... 3-42
Station Port Class.......................................................................................................... 3-43
SLT Hookflash.............................................................................................................. 3-45
Extension Ring Pattern ................................................................................................. 3-46
Digital SLT Receiving Volume.................................................................................... 3-48
Auto Set Relocation Code............................................................................................. 3-49
Permanent Call Forward Type...................................................................................... 3-51
Permanent Call Forward Extension.............................................................................. 3-52
ML/MCO Separation.................................................................................................... 3-53
VAU Hunting Priority .................................................................................................. 3-54
AEC Disconnect ........................................................................................................... 3-55
VAU Port Assignment.................................................................................................. 3-56
Hot Dial Pad.................................................................................................................. 3-57
Auto-Redial on Extensions........................................................................................... 3-58
Chapter 4. Ringing and Hunt Groups (FF4)
CO Day Ring Assignments............................................................................................. 4-3
CO Day Ring Assignments for Hunt Groups ................................................................. 4-4
CO Night Ring Assignments .......................................................................................... 4-5
CO Night Ring Assignments for Hunt Groups............................................................... 4-6
Hunt Group Pilot Numbers............................................................................................. 4-7
Terminal/Circular Hunt Groups...................................................................................... 4-9
Hunt Group Type.......................................................................................................... 4-11
Call Next Hunt Group................................................................................................... 4-13
Hunt Group Members................................................................................................... 4-14
Transfer Extension........................................................................................................ 4-15
Hunt Group Transfer Timer.......................................................................................... 4-16
Hunt Group Members................................................................................................... 4-17
Call Coverage Group Members.................................................................................... 4-18
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - ix -
Table of Contents Section 400-Programming
CO Delayed Day Ring Assignments ............................................................................ 4-20
CO Delayed Day Ring Assignments for Hunt Groups................................................. 4-21
CO Delayed Night Ring Assignments.......................................................................... 4-22
CO Delayed Night Ring Assignments for Hunt Groups............................................... 4-23
Extension Ring Table.................................................................................................... 4-25
Extension Delayed Ring Table ..................................................................................... 4-26
CO Night 2 Ring Assignments ..................................................................................... 4-27
CO Night 2 Ring Assignments for Hunt Groups.......................................................... 4-28
CO Delayed Night 2 Ring Assignments....................................................................... 4-29
CO Delayed Night 2 Ring Assignments for Hunt Groups............................................ 4-30
Chapter 5. FF Key Programming (FF5)
FF Key Assignments for Extensions .............................................................................. 5-3
FF Key Assignments for DSS Consoles......................................................................... 5-8
Attendant Feature Package Key Assignments.............................................................. 5-10
Chapter 6. Name and Message Assignments (FF6)
General Notes..... .................. ................... ................... .................. ................... ........... 6-2
Extension Name.............................................................................................................. 6-3
System Speed Dial Names.............................................................................................. 6-4
Personal Speed Dial Names............................................................................................ 6-5
Absence Messages.......................................................................................................... 6-6
Trunk Name Assignment................................................................................................ 6-8
Hunt Group Name Assignment....................................................................................... 6-9
Call Waiting/OHVA Text Reply .................................................................................. 6-10
DID/DNIS Text Name Assignment.............................................................................. 6-11
Chapter 7. Toll Restrictions (FF7)
An Overview of Toll Restrictions............................................................................. 7-2
International Calling For TRS Types 3-6 ....................................................................... 7-5
DTMF Signaling During Incoming Calls For TRS Types 0-6....................................... 7-6
Maximum Dialed Digits For TRS Types 3-6 ................................................................. 7-7
3-Digit Toll Restriction For TRS Types 2-6................................................................... 7-8
7-Digit Toll Restriction For TRS Types 2-6................................................................... 7-9
Dialing Plan Switch ...................................................................................................... 7-10
Operator Access............................................................................................................ 7-11
- x - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
International Calling on Extensions.............................................................................. 7-12
Country Code Table...................................................................................................... 7-13
Equal Access Code Format........................................................................................... 7-14
Office Code Restriction Table For TRS Types 2-6...................................................... 7-15
Area Code Table For TRS Types 3-6........................................................................... 7-16
Office Code Table For TRS Types 3-6......................................................................... 7-17
Special Area Code Table For TRS Types 3-6 .............................................................. 7-18
Special Office Code Table For TRS Types 3-6............................................................ 7-19
Special 7-Digit Table For TRS Types 2-6.................................................................... 7-20
Day TRS Types 0-7 for Trunks .................................................................................... 7-21
Night TRS Types 0-7 for Trunks.................................................................................. 7-22
Area Code Table For TRS Types 3-6 (Global Copy)................................................... 7-23
Office Code Table For TRS Types 3-6 (Global Copy) ................................................ 7-24
Area & Office Code Table for TRS Types 3-6 (Global Copy)..................................... 7-25
Special Office Code Table For TRS Types 3-6 (Global Copy).................................... 7-26
Chapter 8. Least Cost Routing (FF8)
An Overview of Least Cost Routing......................................................................... 8-2
LCR Area Codes............................................................................................................. 8-6
LCR Office Codes .......................................................................................................... 8-7
Special LCR Area Codes................................................................................................ 8-8
Special LCR Office Code Tables.................................................................................... 8-9
Time Priority Route Tables........................................................................................... 8-10
LCR Trunk Groups....................................................................................................... 8-12
LCR Delete Tables........................................................................................................ 8-13
LCR Add Tables........................................................................................................... 8-14
Chapter 9. Copy Program Settings (FF9)
Trunk Copy..................................................................................................................... 9-3
Extension Copy............................................................................................................... 9-4
FF Key Copy................................................................................................................... 9-5
Chapter 10. Speed Dial Programming (FF10)
System Speed Dial Numbers ........................................................................................ 10-3
Personal Speed Dial Numbers ...................................................................................... 10-5
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - xi -
Table of Contents Section 400-Programming
Appendix A. Large-Scr een Displays
Appendix B. Termi nal Programming
Appendix C. CPC-EX 1.0 Updates
Compatibility............................................................................................................. C-1
44-Series Phone Support.......................................................................................... C-1
Directory Mode................................................................................................................. C-2
Variable Mode .................................................................................................................. C-2
Handset Mute.................................................................................................................... C-2
Off-Hook Monitoring ....................................................................................................... C-2
Analog Adapter................................................................................................................. C-2
MSG (Message) Key ........................................................................................................ C-2
DSS/72 and EM/24 - Key Arrangement........................................................................... C-2
FF-Key Programming .............................................................................................. C-3
Speed Dial Enhancements........................................................................................ C-3
Additional Serial Port............................................................................................... C-3
T1 Networking Capability ....................................................................................... C-3
Modification to Toll Restriction Service................................................................. C-3
Maximum Time Priority Route Tables................................................................... C-3
SMDR Modifications................................................................................................ C-4
ISDN Support............................................................................................................ C-4
Modification to T1 Signaling Types........................................................................ C-4
Installation Notes ...................................................................................................... C-4
CPC-EX Installation ......................................................................................................... C-4
44-Series Enhanced Phone Features....................................................................... C-7
Directory Mode............................................................................................................... C-12
Variable Mode ................................................................................................................ C-13
Handset Mute.................................................................................................................. C-15
- xii - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
Off-Hook Monitoring ..................................................................................................... C-16
Analog Adapter............................................................................................................... C-16
MSG (Message) Key ...................................................................................................... C-19
DSS/72 Console - Key Arrangement.............................................................................. C-20
EM/24 - Key Arrangement ............................................................................................. C-23
Speed-Dial Enhancements...................................................................................... C-25
Additional Serial Port on CPC Card .................................................................... C-28
T1 Networking ........................................................................................................ C-31
Hardware Requirements ................................................................................................. C-31
Network Extension to Extension Calling........................................................................ C-32
Call Forwarding to Network Extensions ........................................................................ C-33
Paging Across Network Nodes....................................................................................... C-33
Network Route Selection................................................................................................ C-33
Remote CO Access......................................................................................................... C-33
SMDR Network Support ................................................................................................ C-34
Independent Node Attendant Assignment...................................................................... C-34
Settings Modified for Networking......................................................................... C-34
Extension Number Digits................................................................................................ C-34
SMDR Printing Mode 1: Outbound and Inbound........................................................... C-35
T1 Trunk Type................................................................................................................ C-35
Extension Numbers......................................................................................................... C-36
Forced LCR/NRS............................................................................................................ C-36
Other Changes to Programming Addresses......................................................... C-37
Enhanced Programming Addresses ................................................................................ C-37
Modification to Toll Restriction Service............................................................... C-37
Maximum Time Priority Route Tables................................................................. C-40
ISDN Support.......................................................................................................... C-41
Hardware Requirements ................................................................................................. C-41
Setting Modified for ISDN ............................................................................................. C-41
Modifications to SMDR.......................................................................................... C-42
Setting Modified for SMDR ........................................................................................... C-43
Modification to T1 Signaling Types...................................................................... C-44
Outgoing Signaling Type................................................................................................ C-44
Incoming Signaling Type................................................................................................ C-45
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - xiii -
Table of Contents Section 400-Programming
Appendix D. CPC-AII/B 8.0 Updates
Contents..................................................................................................................... D-2
44-Series Phone Support.......................................................................................... D-3
Enhanced Phone Features........................................................................................ D-4
Directory Mode................................................................................................................ D-8
Variable Mode ................................................................................................................. D-9
Handset Mute................................................................................................................. D-11
Off-Hook Monitoring .................................................................................................... D-12
Separate Speaker Volumes for Internal vs. CO calls..................................................... D-12
Analog Adapter.............................................................................................................. D-13
MSG (Message) Key ..................................................................................................... D-15
DSS/72 Console - Key Arrangement............................................................................. D-17
EM/24 - Key Arrangement ............................................................................................ D-21
Modification to Toll Restriction Service............................................................... D-23
TAPI Support.......................................................................................................... D-26
Key Telephone Installation Notes.......................................................................... D-27
Desi Strip Cover............................................................................................................. D-27
Key Telephone Wall Mounting Instructions ................................................................. D-27
Appendix E. CPC-AII/B 9.0 Updates
Appendix F. CPC-AII/B 9.1 Updates
Call Record............................................................................................................... F-1
Appendix G. CPC-EX 2.0 Updates
Appendix H. CPC-EX 2.1 Updates
Call Record ...................................................................................................................... H-1
- xiv - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
Appendix I. CPC-M 3.2 Updates
Enhanced Features............................................................................................................. I-1
Software Corrections ......................................................................................................... I-1
Off-Hook Voice Announce (OHVA) via API .................................................................. I-1
Small LCD Soft Key Support via API............................................................................... I-2
Call Record (OHVA) via API............................................................................................ I-2
Appendix J. CPC-AII/B 9.2 Updates
New Features ..................................................................................................................... J-1
Software Corrections ......................................................................................................... J-1
16-Port Voice Mail Support via API ................................................................................. J-1
Off-Hook Voice Announce (OHVA) via API ................................................................... J-2
Small LCD Softkey Support via API................................................................................. J-3
Call Record (OHVA) via API............................................................................................ J-3
Appendix K. CPC-EX 2.3 Updates
New Features ................................................................................................................... K-1
Software Corrections ....................................................................................................... K-2
16-Port Voice Mail Support via API ............................................................................... K-3
Off-Hook Voice Announce (OHVA) via API ................................................................. K-4
Small LCD Soft Key Support via API............................................................................. K-4
Call Record (OHVA) via API.......................................................................................... K-5
Special Features.............................................................................................. .......... K-6
*UNA Transfer ................................................................................................................ K-6
*UNA Call Reversion...................................................................................................... K-7
*Forwarding to UNA for CO Held Call .......................................................................... K-8
*All Ring Group ............................................................................................................ K-10
*Private Password.......................................................................................................... K-11
*Additional RAI Access Method................................................................................... K-14
ISDN Programming Flexibility ..................................................................................... K-16
CPC-EX Version 2.3.2............................................................................................ K-24
Affected Items................................................................................................................ K-24
Feature Changes............................................................................................................. K-24
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - xv -
Table of Contents Section 400-Programming
List of Figures
Figure 1. CPC memory clear switch ................................................................................ Intro-4
Figure 2. Phone keys used in programming mode ........................................................... Intro-7
Figure 1-1. Soft key numbering on large-display phones .................................................... 1-75
Figure 1-2. Example of a CO Ring Cycle and its Detection Timer ................................... 1-109
Figure 1-3. Trunk Closure Example in a DBS 96 (32-trunk system) ................................. 1-203
Figure 5-1. FF key layout on a 34-button phone ...................................................................5-4
Figure 5-2. FF key layout on an EM/24 unit ......................................................................... 5-4
Figure 5-3. FF key layout on a DSS/72 console .................................................................... 5-9
Figure 6-1. Key layout of a DSS/72 console for text name assignment ................................. 6-2
Figure C-1. CPC-EX ..............................................................................................................C-5
Figure C-2. Desk Stand Removal. ..........................................................................................C-6
Figure C-3. Inserting the wall mount bracket (rotated desk stand) .......................................C-6
Figure C-4. Handset guide insertion for wall mounting, key telephone ................................C-7
Figure C-5. 44-Series Small-Display Phone ..........................................................................C-8
Figure C-6. 44-Series Large-Display Phone .......................................................................C-10
Figure C-7. DSS/72 Console (VB-44320) key layout ..........................................................C-21
Figure C-8. DSS/72 #1 Default Extension Numbers ............................................................C-22
Figure C-9. EM/24 Unit (VB-44310) keys ...........................................................................C-24
Figure C-10. CPC-EX Serial Port 2 ....................................................................................C-29
Figure C-11. T1 Network Extension Numbering ................................................................C-32
Figure C-12. T1 Network Call Priority Routing ..................................................................C-33
Figure C-13. SMDR Format for CPC-EX ...........................................................................C-42
Figure D-1. 44-Series Small-Display Phone ........................................................................ D-4
Figure D-2. 44-Series Large-Display Phone ........................................................................ D-6
Figure D-3. DSS/72 Console (VB-44320) key layout ......................................................... D-18
Figure D-4. DSS/72 #1 Default Extension Numbers .......................................................... D-19
Figure D-5. EM/24 Unit (VB-44310) keys .......................................................................... D-21
Figure D-6. Desk Stand Removal. ...................................................................................... D-27
Figure D-7. Inserting the wall mount bracket (rotated desk stand) ................................... D-28
Figure D-8. Handset guide insertion for wall mounting, key telephone ............................. D-28
- xvi - DBS Manu al - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
List Of Tables
Table 1. DBS program structure...................................................................................... Intro-6
Table 2. Default settings ................................................................................................... Intro-9
Table 1-1. Date/Day of Week Programming Instructions ..................................................... 1-3
Table 1-2. SLT Hookflash Control Settings .......................................................................... 1-16
Table 1-3. Analog Transfer Ring Patterns (vary depending on analog connection)............ 1-39
Table 1-4. AEC Disconnect Signal Duration values ............................................................ 1-44
Table 1-5. RAI Modem Card Compatibility ......................................................................... 1-64
Table 1-6. Class of Service features ..................................................................................... 1-70
Table 1-7. Feature codes for Flexible Function Screen soft keys ........................................ 1-76
Table 1-8. Door phone ring timer values .............................................................................1-90
Table 1-9. Attendant Hold Recall Timer values for CO calls .............................................. 1-95
Table 1-10. Extension Hold Recall Timer values for CO calls ............................................ 1-96
Table 1-11. Attendant Transfer Recall Timer values for CO calls ....................................... 1-97
Table 1-12. Extension Transfer Recall Timer values for CO calls ....................................... 1-98
Table 1-13. Attendant Hunt Group Recall Timer values for CO calls ................................. 1-99
Table 1-14. Extension Hunt Group Recall Timer values for CO calls ............................... 1-100
Table 1-15. Attendant Park Hold Recall Timer values ...................................................... 1-101
Table 1-16. Extension Park Hold Recall Timer values ...................................................... 1-102
Table 1-17. Attendant Call Reversion Timer values .......................................................... 1-103
Table 1-18. Unsupervised Conference Timer values ..........................................................1-104
Table 1-19. Automatic Pause Timer values ........................................................................ 1-105
Table 1-20. CO Flash Timer values ................................................................................... 1-106
Table 1-21. SLT Onhook Flash Timer values ..................................................................... 1-108
Table 1-22. Inbound Ring Cycle Expansion Timer values ..................................................1-110
Table 1-23. Dial Pause Timer values ..................................................................................1-111
Table 1-24. PBX Flash Timer values ..................................................................................1-112
Table 1-25. Ring control for Call Forward-No Answer Timer ...........................................1-113
Table 1-26. Call Forward-No Answer Timer values ...........................................................1-113
Table 1-27. Outbound Ground Start Detection Timer values .............................................1-114
Table 1-28. Inbound Ground Start Detection Timer values ................................................1-115
Table 1-29. Attendant Hold Recall Timer values for intercom calls ...................................1-116
Table 1-30. Extension Hold Recall Timer values for intercom calls ...................................1-117
Table 1-31. Attendant Transfer Recall Timer values for intercom calls .............................1-118
Table 1-32. Extension Transfer Recall Timer values for intercom calls .............................1-119
Table 1-33. CO Delayed Ring Timer values ..................................................................... 1-120
Table 1-34. Extension Delayed Ring Timer values ............................................................ 1-122
Table 1-35. Hunt Group No Answer Timer values .............................................................1-124
Table 1-36. System Configuration for T1 installation ........................................................ 1-137
Table 1-37. Minimum T1 programming (default settings appear in bold) ...................... 1-138
Table 1-38. T1 Disconnect Timer values ............................................................................ 1-148
Table 1-39. T1 Guard Timer values ................................................................................... 1-149
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - xvii -
Table of Contents Section 400-Programming
Table 1-40. Release Acknowledge Timer values ................................................................ 1-150
Table 1-41. Outpulse Delay Timer values .......................................................................... 1-151
Table 1-42. Wink Timeout Timer values .............................................................................1-152
Table 1-43. Incoming Detection Timer values ................................................................... 1-153
Table 1-44. Answer Supervision Timer values ................................................................... 1-154
Table 1-45. Immediate Glare Timer values ........................................................................ 1-155
Table 1-46. Wink Glare Timer values ................................................................................. 1-156
Table 1-47. Digital Pad Settings - circuit types ................................................................. 1-157
Table 1-48. Digital Pad Settings - pad numbers and related dB levels ............................. 1-158
Table 1-49. Digital Pad Settings - default values .............................................................. 1-158
Table 1-50. Yellow Alarm Detection timer values ..............................................................1-170
Table 1-51. Yellow Alarm Recovery timer values .............................................................. 1-172
Table 1-52. Other Alarms Detection timer values ............................................................. 1-174
Table 1-53. Other Alarms Recovery timer values .............................................................. 1-176
Table 1-54. DID/DNIS Flexible Ring settings in different CPC-B versions ...................... 1-201
Table 2-1. Ring Patterns for inbound trunk calls .................................................................2-14
Table 2-2. Trunk Disconnect Detection Timer values .......................................................... 2-15
Table 2-3. Wink Start Timer settings .................................................................................... 2-22
Table 2-4. DID Dialed Digit Timer values ........................................................................... 2-23
Table 2-5. DID Interdigit Timer values ................................................................................ 2-24
Table 2-6. Trunk Port Class - circuit types ..........................................................................2-25
Table 3-1. Terminal Types...................................................................................................... 3-5
Table 3-2. Soft key menus during idle mode ........................................................................ 3-23
Table 3-3. Soft key menus during intercom dial tone ........................................................... 3-25
Table 3-4. Soft key menus when calling an extension .......................................................... 3-27
Table 3-5. Soft key menus when accessing CO dial tone ..................................................... 3-29
Table 3-6. Soft key menus during a trunk call ......................................................................3-31
Table 3-7. Soft key menus when receiving a page ................................................................3-33
Table 3-8. Soft key menus after receiving a call waiting tone ............................................. 3-35
Table 3-9. Soft key menus when dialing a busy extension ................................................... 3-37
Table 3-10. Station Port Class - circuit types ...................................................................... 3-43
Table 3-11. Extension ring patterns ..................................................................................... 3-46
Table 5-1. Feature codes for FF key assignment................................................................... 5-5
Table 6-1. Preset Absence Messages 0-4 ............................................................................... 6-6
Table 6-2. Default call waiting/OHVA text reply messages ................................................. 6-10
Table 7-1. Toll restriction types .............................................................................................. 7-2
Table 7-2. NANP changes ...................................................................................................... 7-3
Table 7-3. Maximum number of dialed digits for TRS types 3-6 ........................................... 7-7
Table 7-4. Differences between old and new dialing plans ................................................. 7-10
- xviii - DBS Manual - revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Table of Contents
Table 8-1. Time Priority Route Table format ......................................................................... 8-3
Table 8-2. Time Priority Route Table format........................................................................ 8-10
Table 10-1. DSS key functions in System Speed Dial programming .................................... 10-4
Table 10-2. DSS key functions in Personal Speed Dial programming ................................ 10-6
Table B-1. Terminal programming commands .......................................................................B-2
Table B-2. Codes for switching SMDR/Bus Monitor modes ..................................................B-3
Table C-1. 44-Series Phones .................................................................................................C-1
Table C-2. Small-Display Phone Features .............................................................................C-8
Table C-3. Large-Display Phone Features ..........................................................................C-10
Table C-4. TRS Operator Access settings ............................................................................C-38
Table D-1. 44-Series Phones ................................................................................................ D-3
Table D-2. Key to 44-Series Small-Display Phone ............................................................... D-5
Table D-3. Key to 44-Series Large-Display Phone ............................................................... D-6
Table D-4. TRS Operator Access settings ........................................................................... D-23
Table K-1. UNA Call Revision Timer Values .........................................................................K-7
DBS-2.3/9.2-400 DBS Manual - revised April 2000 - xix -
Table of Contents Section 400-Programming
(This page left blank intentionally)
- xx - DBS Manual - revised April 2000 DBS-2.3/9.2-400

About This Section

This
Section 400
FF keys on a DBS key phone. (Other programming methods, as well as overall software feature
updates, are described in Appendix B through K of this section.)
is intended for use as a technical reference manual for DBS programming via the

Structure

Section 400
Chapter 1 covers FF1 programs; Chapter 2 covers FF2 programs; and so on. The FF keys categorize the programs by subject -- each FF key represents a group of related programs as follows:
Chapter 1 FF1 -- System Chapter 2 FF2 -- Trunks Chapter 3 FF3 -- Extensions Chapter 4 FF4 -- Ring Assignments & Hunt/Call Coverage Groups Chapter 5 FF5 -- FF Key Features Chapter 6 FF6 -- Displayed Names & Messages Chapter 7 FF7 -- Toll Restriction Chapter 8 FF8 -- Least Cost Routing Chapter 9 FF9 -- Program Copy Chapter 10 FF10 -- Speed Dial Numbers
is structured according to FF key numbering. For example,

FF Key Programming

FF key programming is accomplished by entering programming mode, then punching in each program’s address (press the FF key, then enter a string of numbers that are separated by the pound # key). The phone’s LCD display will show prompts while you are punching in the string, to guide you through the programming. Within each address string (usually at the end of it), you have a choice of numbers to press in order to set the program; the number you press determines the program setting.
Once you’ve entered programming mode and punched in an FF key address, you do not have to keep pressing the FF key to go to the next [sequential] address -- the DBS will automatically display the next prompt after you set the first one (or press # to accept the dis played setting). To jump to an a ddress in another FF key, simply press that FF key while still in programming mode.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 - xxv -
About This Section Section 400-Programming

Program Sequence

Although FF key programming separates DBS programs into groups, it is important to note that the numerical sequence of the FF keys and the addresses within them, does not necessarily represent a logical progression for programming a particular feature or application. For example, some DID settings are in FF1 (System), while others are in FF2 (Trunks), FF3 (Extensions) and FF6 (Names and Messages).
In
Section 400,
the feature or application it affects (if any). Also, the forms in the DBS Manual provide a more concise view of programming DBS features.
each program explanation includes related information about
Section 450
of
- xxvi - DBS Manual - Revised April 2000 DBS-2.3/9.2-400

Introduction to DBS Programming

This introduction provides an overview of DBS programming from a phone. For descriptions of other DBS programming methods, see Appendix B of this manual.
The following table summarizes the topics contained in this introduction.
Topic Page
Before You Begin Intro-3
Preparations for Programming Intro-3 Initializing DBS Systems (RAMCLR) Intro-4 Upgrading CPC-B Software (New Function Reset) Intro-5
Understanding FF Key Programming Intro-6
Program Structure Intro-6 How to Enter the Programming Mode Intro-7 Example Programming Entry Intro-9
Default Program Settings Intro-9
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-1
Intro-2 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming

Before You Begin

This section describes preparations that should be completed
If you are familiar with FF key programming for DBS
programming
systems, you may begin programming as soon as these preparations have been made.
If you are new to DBS programming, be sure to read
Key Programming”
.

Preparations for Programming

Prior to programming the DBS system, make sure you have completed the following steps:
1. Confirm that the DBS features meet customer requirements. See
700-Feature Operation
2. Confirm that you have the DBS hardware required for the end user. See
Section 300-Installation
3. Use
Forms and Tables (Section 450)
Use the following guidelines when completing
• Be sure to record
“Understanding FF
on page Intro-5 before you begin.
for DBS feature descriptions.
for details.
to record the customer’s site data.
Forms and Tables:
program entries.
all
before you start
Section
• Leave the default values for equipment that is not connected.
• Pay careful attention to program items that require a power-down to take effect. Be sure to complete the necessary programming in these areas before you make the system operational.
4. To program a new DBS system, you must first initialize the software to default values (see performing an upgrade and the system is using a CPC-B card, you must first perform the New Function Reset procedure (see
Software”
Once these steps are completed, use the site data in program the system.
on page Intro-5).
“Initializing DBS Systems”
, next page). If you are
“Upgrading CPC-B
Forms and Tables
to
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-3
Introduction to DBS Programming Section 400-Programming

Initializing DBS Systems (RAMCLR)

After installing a new DBS system, or when upgrading to a higher-level
version, you must initialize the CPC (Central Processing Card) before
programming the system.
IMPORTANT:
This procedure
be performed before you program
must
the DBS system. Failure to initialize the CPC before programming may cause operational problems.
The procedure described below re-initializes the entire DBS memory, and resets all programs to their default values. This means that all programs used, as well as features set on individual extensions, must be reprogrammed. If you have PCAS, you can download existing settings (thru CPC Version 4.0) and upload them to the new version. The new features introduced in CPC Versions 5.0 thru 6.1x, as well as the Permanent Call Forwarding feature, must be manually reprogrammed.
1. Power-off the DBS (set power switch to OFF).
2. Slide the CPC’s SW1 switch to “RAMCLR”.
3. Power-on the DBS. Wait until the bottom status LED on the CPC card stops flashing (this takes less than a minute).
4. Slide SW1 back to “RAMHOLD”.
5. From any display phone, verify the software version by pressing
ON/OFF CONF 7777
Figure 1. CPC memory clear switch
TRK1 TRK2 TRK3 EC1 EC2 EC3 EC4 EC5 EC6 EC7 EC8 EC/TRK SCC CPC AUX1 AUX2
STATUS LED
SW 1
RAM H OLD
RAM C LR
Intro-4 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming

Upgrading CPC-B Software (New Function Reset)

Perform the following procedure when upgrading CPC-B software to a new version.
Exception:
initialized instead; see page.
If upgrading to Version 7.0, the system must be
“Initializing DBS Systems (RAMCLR)”
, previous
IMPORTANT:
Perform New Function Reset if upgrading to a new whole number release (not necessary for a “point” release; e.g., from 9.0 to 9.2).
New Function Reset clears unused registers and adds new programs, but retains all current DBS settings. If you are upgrading from a CPC-B version prior to 3.1, New Function Reset will also clear any existing DID numbers that are extension-based.
1. Power-off the DBS. Remove the CPC-B card.
2. Replace the existing EPROMs 1-4 with new EPROMs.
3. Re-install the CPC-B card, then power the system back on.
4. If upgrading to a new release, perform New Function Reset as shown
below:
FF1 8# 1# (0 or 1)#
0=Do not perform New Function Reset.
1=Perform New Function Reset.
NOTE: If you enter “1” (to reset), the following displays:
CONFIRM
0:NO 1:YES
This is to confirm that you want to reset the data before the DBS actually performs the reset. Press one of the following:
0=Do not complete the reset.
1=Complete the reset.
5. Power OFF the system, wait at least 3 seconds, then power it back ON.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-5
Introduction to DBS Programming Section 400-Programming

Understanding FF Key Programming

Program Structure

Program entries for the DBS are organized into 10 primary groups, which are listed in Table 1 below. Each group has its own Flexible Function (FF) key on the phone. These keys can be identified by the LED on the left side of the key. On key telephones, the FF keys are numbered left-to-right, starting on the bottom row.
After you enter the programming mode (see
Programming Mode”
programming the entries (“addresses”) of the group. The phone’s LCD display will prompt you through the addresses.
Table 1. DBS program structure
FF Key Programming Group
FF1 System settings FF2 CO Trunk settings FF3 Extension settings FF4 Ring Assignments and Hunt Groups FF5 FF Key Assignments FF6 Names and Messages on LCD Display FF7 Toll Restrictions (TRS) FF8 Least Cost Routing (LCR) FF9 Copy Program Settings
FF10 Speed-Dialing (system and personal)
“How to Enter the
, next page), press the desired FF key to start
In the programming mode, some of the phone keys can be used to store your settings and move forward or backward through the program addresses. Figure 2 (next page) identifies these keys and what they do in programming mode.
Intro-6 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Figure 2. Phone keys used in programming mode
CONF:
to default setting.
:
Stores your entry and
*
moves backward (decrements program address number).
Resets entry
VOL ^:
programming level.
FLASH:
backward (decrements port number in the same address; or decrements program address number).
HOLD:
forward (increments port number in the same address; or increments program address number).
:
#
moves forward (increments program address number).
Moves backward to the previous
Stores your entry and moves
Stores your entry and moves
Stores your entry and

How to Enter the Programming Mode

From the Attendant port...
Programming can be performed from an Attendant display phone. The phone connected to extension port 1, assigned extension number 100 is automatically the Primary Attendant phone. By default, extension port 2 (extension number 101) is the Second Attendant phone (although this extension assignment can be reprogrammed). Up to two other phones can also be programmed as Third and Fourth Attendant phones. Programming is also possible from other extensions (see
“From a Non-Attendant Port”
page). To enter the programming mode from any Attendant phone, press:
ON/OFF PROG ## [desired FF key]
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-7
, next
Introduction to DBS Programming Section 400-Programming
Notes:
• Name settings can only be programmed from the Attendant phone or a DSS console connected to it.
• When you enter the programming mode on the Attendant phone -- and the DBS is set for only one Attendant -- the system will automatically change to the “Night” mode. After you exit the programming mode (by pressing ON/OFF), the system will return to the appropriate mode according to the system clock and the mode’s start time.
From a non-Attendant port ...
When programming from a display phone other than an Attendant, press:
ON/OFF #98 [NNNN] PROG ## [desired FF key]
(where “[NNNN]” is the programming authorization code -- “9999” by default)
Notes:
• In CPC-A versions prior to 3.3, if a non-Attendant phone is used for programming, you must enter the programming authorization code twice -­once to begin programming, and once to exit programming. Otherwise, other non-Attendant extensions cannot enter the programming mode.
• Beginning with CPC-A Version 3.3, and CPC-B versions, a non-Attendant phone only has to enter the authorization code once, to begin programming. As soon as programming is complete, any other non­Attendant phone can enter the programming mode.
From the Test Terminal port ...
You can also program from a phone connected to the test terminal (CN3) of the main DBS cabinet:
1. Slide the SW1 switch on the cabinet to “Test” mode. This will provide a direct connection to ports 7 and 8 (if the DBS is already in service, make sure beforehand that placing ports 7 and 8 out of service is acceptable).
2. Press: (where “[NNNN]” is the programming authorization code -- “9999” by default)
ON/OFF #98 [NNNN] PROG ### [desired FF key]
When you are finished programming, be sure to return SW1 to the “ST” position.
Intro-8 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming

Example Programming Entry

To set the DBS time and date from an Attendant phone, press:
ON/OFF PROG ##
(
“Program Mode”
is displayed on line 1,
“MAIN MODE”
FF1
(
“System Program”
is displayed on line 1,
“SELECT SUB MODE”
1#
(
“SELECT TIME MODE”
is displayed on line 1;
“1:DATE 2:TIME”
1#
(
“DATE SET MODE”
is displayed on line 1;
“MONTH/DAY/YEAR”
MMDDYY
(Enter new date in
MMDDYY
format)
# ON/OFF
(to store the program change and exit programming mode; the new date should now be displayed on all LCD phones)
on line 2)
on line 2)
on line 2)
on line 2)

Default Program Settings

The following table shows the default settings for all DBS program addresses. Some of these addresses contain number ranges which are shown in parentheses. These are the acceptable ranges for trunk numbers, extension ports, etc. in a DBS 96 + DBS 96 configuration with a CPC-B card. For the acceptable ranges in other configurations, see
Table 2. Default settings
Program Address Topic Default Page
FF1: System Settings
FF1 1#: Date and Time Settings 1-3
FF1 1# 1# (MMDDYY)# Day/Date Setting Sun JAN 1 1-3 FF1 1# 2# (HHMM)# Time Setting 12:00 1-4
FF1 2# 1#: General System Settings 1-5
FF1 2# 1# 1# (0 or 1)# Call Duration Display 1 (Displayed) 1-5 FF1 2# 1# 2# (0-2)# SMDR Display Start Timer for CO Calls 0 (Begins after
FF1 2# 1# 3# (0 or 1)# Least Cost Routing (LCR) Access 0 (Pooled trunk) 1-7 FF1 2# 1# 4# (SSD)# Override Toll Restriction With SSD Numbers No TRS Override 1-8
Section 300-Installation.
1-1
1-6
5 sec)
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-9
Introduction to DBS Programming Section 400-Programming
Program Address Topic Default Page
FF1 2# 1# 5# (0 or 1)# SSD Display Restriction 0 (Display DBS-
dialed digits)
FF1 2# 1# 6# (0 or 1)# Auto Flash Redial 1 (REDIAL
sends flash) FF1 2# 1# 7# (0 or 1)# One Touch Dial 1 (Enabled) 1-11 FF1 2# 1# 8# (0 or 1)# Onhook Transfer 1 (Enabled) 1-12 FF1 2# 1# 9# (0 or 1)# Key Bank Hold 0 (Disabled) 1-13 FF1 2# 1# 10# (0 or 1)# Non-Appearing Trunk Hold 1 (System hold) 1-14 FF1 2# 1# 11# (0 or 1)# SLT Flash Control 1 (Retrieves held
call) FF1 2# 1# 12# (0 or 1)## Extension Number Digits 1 (3 digits) 1-17 FF1 2# 1# 13# (0 or 1)# Alternate Attendant
(CPC-A/B prior to 2.0)
1 (Enabled) 1-18 FF1 2# 1# 14# (0 or 1)# Attendant Intercom Calling 1 (Voice) 1-19 FF1 2# 1# 15# (0 or 1)# Extension Intercom Calling 1 (Voice) 1-20 FF1 2# 1# 16# (0 or 1)# Alert Tone for Voice Calls 1 (Enabled) 1-21 FF1 2# 1# 17# (0 or 1)# Alert Tone for Busy Override & OHVA 0 (Disabled) 1-22 FF1 2# 1# 18# (0 or 1)# System Installation Area Code 1 (1+Area) 1-23 FF1 2# 1# 19# (0 or 1)# SSD Name Display 0 (5 names) 1-24 FF1 2# 1# 20# (2-9 or 2-18)# API/AEC Slot Assignment No assignment 1-25 FF1 2# 1# 21# (0 or 1)# Voice Mail Busy Tone 0 (Silence) 1-26 FF1 2# 1# 22# (0-6)# Analog Transfer Ring Pattern
(CPC-A 3.21 or higher)
FF1 2# 1# 22# (1-15)# Attendant Overflow for Primary Attendant
(CPC-B 1.0 only)
FF1 2# 1# 23# (0 or 1)# Delayed Ring
(CPC-AII/B)
FF1 2# 1# 23# (0-15)# AEC Disconnect Signal Duration
(CPC-A 3.3 or higher)
0 (.4 sec on/
3.6 sec off)
8 (maximum 8
stacked calls)
0 (Disabled) 1-29
0 (No signal) 1-30
FF1 2# 1# 24# (11-69 or 101-699)# Second Attendant Position Ext. 11 or 101 1-31 FF1 2# 1# 25# (11-69 or 101-699)# Third Attendant Position None 1-32 FF1 2# 1# 26# (11-69 or 101-699)# Fourth Attendant Position None 1-33 FF1 2# 1# 27# (11-69 or 101-699)# Attendant Transfer Extension None 1-34 FF1 2# 1# 28# (0 or 1)# Attendant Override 1 (Enabled) 1-35 FF1 2# 1# 29# (0 or 1)# Attendant LED Alarm Indication
(CPC-B 2.09 thru 4.0 with AFP)
1 (can assign
alarm) FF1 2# 1# 30# (0 or 1)# Extension (BLF) Delayed Ring 0 (Disabled) 1-37 FF1 2# 1# 31# (0-6)# Analog Transfer Ring Pattern
(CPC-AII/B)
0 (.5 sec on/
3.5 sec off)
FF1 2# 1# 32# (0 or 1)# Multiple DID/DNIS
(CPC-B 4.0 or higher)
0 (Disabled) 1-39 FF1 2# 1# 33# (0 or 1)# Page Duration 0 (Unlimited) 1-41 FF1 2# 1# 34# (0 or 1)# SLT DISA Ring Pattern 0 (1 sec on/
3 sec off) FF1 2# 1# 35# (0-15)# AEC Disconnect Signal Duration
(CPC-AII/B 5.0 or higher)
0 (No signal sent) 1-43
1-9
1-10
1-15
1-27
1-28
1-36
1-38
1-42
Intro-10 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Program Address Topic Default Page
FF1 2# 1# 36# (0-2)# DID/DNIS to a Voice Mailbox
(CPC-B 6.0 or higher)
FF1 2# 1# 37# (6 char.)# DID/DNIS Answer Code
(CPC-B 6.0 or higher)
FF1 2# 1# 38# (0-2)# LCD Timer for Caller ID
higher)
FF1 2# 1# 39# (0 or 1)# Internal Hold Tone
(CPC-AII/B 6.1 or
(CPC-AII/B 7.0 or higher)
FF1 2# 1# 40# (0 or 1)# Door Opener Access Code Required
(CPC-AII/B 7.0 or higher)
FF1 2# 1# (41 or 42)# 1# (0 or 1)# API Port Type FF1 2# 1# (41 or 42)# 2# (0 or 1)# API Baud Rate
(CPC-AII/B 7.0 or higher)
(CPC-AII/B 7.0 or higher)
0 (No DID/DNIS
1-44 digits trans­ mitted)
None 1-46
0 (5 sec) 1-48
0 (Disabled) 1-49 0 (Not required) 1-50
0 (Standard API) 1-51 0 (9600 bps) 1-52
Program Address Topic Default Page
FF1 2# 2#: Serial Port Parameters (TTY Settings) 1-53
FF1 2# 2# 1# (0 or 1)# Parity Check 1 (On) 1-53 FF1 2# 2# 2# (0 or 1)# Odd/Even Parity 1 (Even) 1-54 FF1 2# 2# 3# (1-4)# Baud Rate 4 (9600 bps) 1-55 FF1 2# 2# 4# (1-3)# Stop Bit Length 1 (1 bit) 1-56 FF1 2# 2# 5# (3 or 4)# Data Length 4 (8 bits) 1-57 FF1 2# 2# 6# (0 or 1)# SMDR Printing Mode 1: Outbound and
Inbound
FF1 2# 2# 7# (0 or 1)# SMDR Printing Mode 2: Long-Distance and
Local Calls
FF1 2# 2# 8# (0 or 1)# SMDR Printing Mode 3: Header Title 0 (No header
FF1 2# 2# 9# (0 or 1)# Serial Port Flow Control (XON / XOFF) 1 (No DBS flow
FF1 2# 2# 10# (0 or 1)# RAI Baud Rate 0 (300 bps) 1-62
1 (Outbound and Inbound)
1 (Long-distance and local)
titles)
control)
1-58
1-59
1-60
1-61
FF1 2# 3#: PBX Settings 1-63
FF1 2# 3# (1-8)# (0-999 or 0*-99*)#
FF1 2# 3# (9-18)# (1-3)# Automatic Pause Position for PBX Access
PBX Access Code(s) None 1-63
None 1-64
Codes
FF1 2# 4#: External (UNA) Relay Control 1-66
FF1 2# 4# 1# (0 or 1)# Ring Patterns for UNA Terminals (M, C and B)0 (1 sec on/
3 sec off)
FF1 2# 4# (2-9)# (0 or 1)# External Page Interface Control for Paging
Groups
0 (Internal paging only)
1-66
1-67
FF1 2# 5#: Class of Service 1-68
FF1 2# 5# (1-8)# (1-21)# (0 or 1)# Extension Class of Service 0 (All features
disabled)
1-68
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-11
Introduction to DBS Programming Section 400-Programming
Program Address Topic Default Page
FF1 2# 6#: Account Codes 1-70
FF1 2# 6# (1-100)# 1# (0001-9999)# Verified Forced Account Codes None set 1-70 FF1 2# 6# (1-100)# 2# (0-7)# Toll Restriction for Verified Forced Account
Codes
0 (TRS type 0 -­ intercom calls only)
1-72
FF1 2# 7#: Flexible Function Screens
FF1 2# 7# 1# (25-39)# (1-10)# (Code)#
FF1 2# 7# 2# (25-39)# (1-10)# (Text)#
FF1 2# 7# 3# (25-39)# (0 or 1)# Flexible Function Screen Default 0 (Do not default) 1-79 FF1 2# 7# 4# (0 or 1)# Flexible Function Screens Default (All) 0 (Do not default) 1-80
Flexible Function Screen Soft -Key As signmen t None 1-73
Flexible Function Screen Text None 1-78
FF1 2# 8#: Caller ID Automatic DISA
FF1 2# 8# (1-10)# (PhoneNo.)# Automatic DISA Callers None 1-81
FF1 2# 9#: Door Phones
FF1 2# 9# (1-4)# 1# (3-144)# Door Phone Extensions No assignment 1-82 FF1 2# 9# (1-4)# 2# (1-144)#
(0 or 1)# FF1 2# 9# (1-4)# 3# (0000-9999)# Door Opener Access Code 9999 1-86 FF1 2# 9# (1-4)# 4# (0 or 1)# Door Phone Tone Type 0 (Slow chime) 1-87 FF1 2# 9# (1-4)# 5# (0-15)# Door Phone Ring Timeout Timer 3 (20 sec) 1-88 FF1 2# 9# (1-4)# 6# (0-5)# Door Phone Ring Pattern 1 (4 sec between
FF1 2# 9# (1-4)# 7# (0-5)# Door Opener Relay Timer 1 (Open for 4 sec) 1-90
(CPC-AII/B 7.0 or higher)
Door Phone Ring Assignments 0 (Do not ring) 1-84
(CPC-AII/B 6.0 or higher)
(CPC-AII/B 6.1 or higher)
1-73
1-81
1-82
1-89 rings)
Program Address Topic Default Page
FF1 3#: System Timers 1-91
FF1 3# 1# (0000-2359)# Automatic Night Mode Start Time Not set 1-91 FF1 3# 2# (0-12)# Attendant Hold Recall Timer for CO Calls 1 (20 sec) 1-93 FF1 3# 3# (0-12)# Extension Hold Recall Timer for CO Calls 7 (140 sec) 1-94 FF1 3# 4# (0-12)# Attendant Transfer Recall Timer for CO Calls 1 (20 sec) 1-95 FF1 3# 5# (0-12)# Extension Transfer Recall Timer for CO Calls 7 (140 sec) 1-96 FF1 3# 6# (0-12)# Attendant Hunt Group Recall Timer 1 (20 sec) 1-97 FF1 3# 7# (0-12)# Extension Hunt Group Recall Timer 7 (140 sec) 1-98 FF1 3# 8# (0-12)# Attendant Park Hold Recall Timer 1 (20 sec) 1-99 FF1 3# 9# (0-12)# Extension Park Hold Recall Timer 7 (140 sec) 1-100 FF1 3# 10# (0-12)# Attendant Call Reversion Timer for CO Calls 9 (180 sec) 1-101 FF1 3# 11# (0-15)# Unsupervi sed Conference Timer 2 (10 min) 1-102 FF1 3# 12# (0-15)# Automatic Pause Timer 7 (3.5 sec) 1-103 FF1 3# 13# (0-15)# CO Flash Timer 9 (1 sec) 1-104
Intro-12 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Program Address Topic Default Page
FF1 3# 14# (0-6)# SLT Onhook Flash Timer 4 (200 - 1500 ms) 1-106 FF1 3# 15# (0-3)# CO Ring Cycle Detection Timer 1 (6 sec) 1-107 FF1 3# 16# (0-15)# Inbound Ring Cycle Expansion Timer 7 (350 ms) 1-108 FF1 3# 17# (0-15)# Dial Pause Timer 1 (1.5 sec) 1-109 FF1 3# 18# (0-10)# PBX Flash Timer 7 (.8 sec) 1-110 FF1 3# 19# (0-15)# Call Forward-No Answer Timer 2 (After 12 sec) 1-111 FF1 3# 20# (1-8)# Outbound Ground Start Detection Timer
(CPC-B only)
FF1 3# 21# (1-8)# Inbound Ground Start Detection Timer
(CPC-B only)
FF1 3# 22# (0-12)# Attendant Hold Recall Timer for Intercom
Calls
FF1 3# 23# (0-12)# Extension Hold Recall Timer for Intercom
Calls
FF1 3# 24# (0-12)# Attendant Transfer Recall Timer for Intercom
Calls
FF1 3# 25# (0-12)# Extension Transfer Recall Timer for Intercom
Calls FF1 3# 26# (0-15)# CO Delayed Ring Timer 2 (After 12 sec) 1-118 FF1 3# 27# (0-15)# Extension (DSS/BLF) Delayed Ring Timer 2 (After 12 sec) 1-120 FF1 3# 28# (0-15)# Hunt Group No Answer Timer 2 (After 12 sec) 1-122 FF1 3# 29# (HHMM)# Automatic Day Mode Start Time Not set 1-123 FF1 3# 30# (HHMM)# Automatic Night 2 Mode Start Time Not set 1-125
4 (4 sec) 1-112
4 (4 sec) 1-113
1 (20 sec) 1-114
7 (140 sec) 1-115
1 (20 sec) 1-116
7 (140 sec) 1-117
FF1 4# thru 7#: Programming and DISA Codes 1-127
FF1 4# (0000-9999)# Remote Programming ID Code 9999 1-127 FF1 5# (0000-9999)# DISA Inbound Call ID Code Not set 1-128 FF1 6# 1# (0000-9999)# DISA Outbound Call ID Code 1 1111 1-129 FF1 6# 2# (0000-9999)# DISA Outbound Call ID Code 2 9999 1-130 FF1 7# (0000-9999)# ID Code for System Programming 9999 1-131
Program Address Topic Default Page
FF1 8# 1# and 2#: New Function Reset
FF1 8# 1# (0 or 1)# New Function Reset 0 (Do not reset) 1-132 FF1 8# 2# (0 or 1)# Confirm New Function Reset 0 (Do not com-
FF1 8# 3# thru 7#: DID/DNIS and T1 Settings
FF1 8# 3# (0000-9999)# (10-69 or 100-699)#
FF1 8# 4# 1# 1# (0-8)# System Configuration 0 (DBS 40) 1-135 FF1 8# 4# 1# 2# (1-3)# Sync Source 1 3 (Free run) 1-141 FF1 8# 4# 1# 3# (0-3)# Sync Source 2 0 (None) 1-143
Inbound DID Dial Numbers Not set 1-133
(CPC-B only, 4.0 or higher)
(CPC-B only, 4.0 or higher)
1-132
1-132
plete reset)
1-133
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-13
Introduction to DBS Programming Section 400-Programming
Program Address Topic Default Page
FF1 8# 4# 1# 4# (0-3)# Sync Source 3 0 (None) 1-144 FF1 8# 4# 2# 1# (0-25)# Network Re-Sync Timer 25 (No retries) 1-145 FF1 8# 4# 2# 2# (0-12)# Disconnect Timer 1 (200 ms) 1-146 FF1 8# 4# 2# 3# (0-15)# Guard Timer 6 (1200 ms) 1-147 FF1 8# 4# 2# 4# (0-15)# Release Acknowledge Timer 9 (240 sec) 1-148 FF1 8# 4# 2# 5# (0-8)# Outpulse Delay Timer 2 (500 ms) 1-149 FF1 8# 4# 2# 6# (0-15)# Wink Timeout Timer 15 (5500 ms) 1-150 FF1 8# 4# 2# 7# (0-15)# Incoming Detection Timer 7 (90 ms) 1-151 FF1 8# 4# 2# 8# (0-8)# Answer Supervision Timer 3 (600 ms) 1-152 FF1 8# 4# 2# 9# (0-15)# Immediate Glare Timer 3 (60 ms) 1-153 FF1 8# 4# 2# 10# (0-15)# Wink Glare Timer 3 (60 ms) 1-154 FF1 8# 4# 3# (1-12)# (0-30)# D igital Pad Settings 16 (-2 dB) 1-155 FF1 8# 4# (4/5)# 1# 1# (0 or 1)# Trunk Configuration FF1 8# 4# (4/5)# 1# 2# (0-24)# Number of T1 Channels 0 (None) 1-159 FF1 8# 4# (4/5)# 1# 3# (0 or 1)# Frame Format 0 (Superframe) 1-160 FF1 8# 4# (4/5)# 1# 4# (0 or 1)# Line Coding 0 (AMI) 1-161 FF1 8# 4# (4/5)# 1# 5# (0 or 1)# Failure Mode 0 (T1 continues
FF1 8# 4# (4/5)# 1# 6# (0 or 1)# Remote Loopback Reserved for
FF1 8# 4# (4/5)# 1# 7# (0 or 1)# Yellow Alarm Send 1 (Yes) 1-164 FF1 8# 4# (4/5)# 1# 8# (0 or 1)# Flash Key Operation 0 (Release and
FF1 8# 4# (4/5)# 2# 1# (0-5)# Red Alarm Detection 2 (8) 1-166 FF1 8# 4# (4/5)# 2# 2# (0-15)# Yellow Alarm Detection 1 (50 ms) 1-167 FF1 8# 4# (4/5)# 2# 3# (0-15)# Yellow Alarm Recovery 1 (10 ms) 1-169 FF1 8# 4# (4/5)# 2# 4# (0-15)# Other Alarms Detection 1 (250 ms) 1-171 FF1 8# 4# (4/5)# 2# 5# (0-15)# Other Alarms Recovery 1 (250 ms) 1-173 FF1 8# 4# (4/5)# 3# 1# (0-9000)# Frame Loss Counter 9000 1-174 FF1 8# 4# (4/5)# 3# 2# (0-9000)# Slip Counter 9000 1-175 FF1 8# 4# (4/5)# 3# 3# (0-9000)# Red Alarm Counter 9000 1-176 FF1 8# 4# (4/5)# 3# 4# (0-9000)# Loss of Signal Counter 9000 1-177 FF1 8# 4# (4/5)# 3# 5# (0-9000)# Sync Loss Counter 9000 1-178 FF1 8# 4# (4/5)# 3# 6# (0-9000)# Yellow Alarm Counter 9000 1-179 FF1 8# 4# (4/5)# 4# 1# (0 or 1)# Yellow Alarm Relay 0 (Off) 1-180 FF1 8# 4# (4/5)# 4# 2# (0 or 1)# Red Alarm Relay 0 (Off) 1-181 FF1 8# 4# (4/5)# 4# 3# (0 or 1)# Sync Loss Relay 0 (Off) 1-182 FF1 8# 4# (4/5)# 4# 4# (0 or 1)# Frame Loss Relay 0 (Off) 1-183 FF1 8# 4# (4/5)# 4# 5# (0 or 1)# AIS Relay 0 (Off) 1-184 FF1 8# 4# (4/5)# 4# 6# (0 or 1)# Relay Reset 0 (Automatically
(CPC-B 4.0 to 6.02)
0 (Analog) 1-158
1-162 to operate after error detected)
1-163 future use
1-165 reseize)
1-185 cleared)
Intro-14 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Program Address Topic Default Page
FF1 8# 4# 6# (1-64)# 1# (0-3)# T1 Trunk Type Emulation 3 (E&M) 1-186 FF1 8# 4# 6# (1-64)# 2# (0-2)# DID/DNIS 0 (Neither) 1-187 FF1 8# 4# 6# (1-64)# 3# (0-2)# Outgoing Signaling Type 0 (Immediate
start)
FF1 8# 4# 6# (1-64)# 4# (0 or 1)# Incoming Signaling Type 0 (Immediate
start/ringdown)
FF1 8# 4# 6# (1-64)# 5# (0 or 1)# Trunk Mode 0 (Incoming and
outgoing)
FF1 8# 4# 6# (1-64)# 6# (0 or 1)# Robbed Bit Setting 1 (On) 1-191 FF1 8# 4# 6# (1-64)# 7# (0 or 1)# Incoming Dialing Method 1 (DTMF) 1-192 FF1 8# 4# 6# (1-64)# 8# (0 or 1)# Dial Tone Transmission Reserved for
future use
FF1 8# 4# 6# (1-64)# 9# (0 or 1)# Busy Tone Transmission Reserved for
future use
FF1 8# 4# 6# (1-64)# 10# (0 or 1)# Dial Tone Receive 0 (Off) 1-195 FF1 8# 4# 6# (1-64)# 11# (0 or 1)# Ringback Tone Transmission 0 (Off) 1-196 FF1 8# 4# 7# (0000-9999 )# (1 0-6 9 or
100-699)# FF1 8# 5# (0000-9999)# (10-69 or
100-699)# (0000[00]-1111[11])#
FF1 8# 6# (0000-9999)# (10-69 or 100-699)# (0000[00]-1111[11])#
FF1 8# 7# (1/2)# (1-4)# (1-8)# (0 or 1)# T1 Trunk Closure 0 (Open) 1-200
DNIS Number Setting No assignment 1-197
DID Flexible Ringing Assignments 1100 or 111000
(Ringing enabled; Delayed ringing disabled)
DNIS Flexible Ringing Assignments 1100 or 111000
(Ringing enabled; Delayed ringing disabled)
1-188
1-189
1-190
1-193
1-194
1-198
1-198
Program Address Topic Default Page
FF2: Trunk Settings
FF2 (1-64)# 1# (0 or 1)# Trunk Port Operation 0 (In service) 2-3 FF2 (1-64)# 2# (0 or 1)# DTMF/Pulse Dialing for Trunks 0 (DTMF) 2-4 FF2 (1-64)# 3# (0 or 1)# Pooled Trunk Access for Group “9” 1 (Trunk is
included)
FF2 (1-64)# (4-9)# (0 or 1)# Pooled Trunk Access for Groups “81-86” 0 (Trunk is not
included)
FF2 (1-64)# 10# (1 or 2)# Trunk Port Type 1 (CO trunk) 2-7 FF2 (1-64)# 11# (0 or 1)# DISA Auto Answer 0 (DISA tone not
provided)
FF2 (1-64)# 12# (1-144)# Private Trunk Line Not set 2-9 FF2 (1-64)# 13# (0 or 1)# Automatic Pause for PBX Line 1 (Disabled) 2-10
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-15
2-1
2-5
2-6
2-8
Introduction to DBS Programming Section 400-Programming
Program Address Topic Default Page
FF2 (1-64)# 14# (0 or 1)# Dial Tone Detection 0 (Digits out-
pulsed after Dial Pause Timer)
FF2 (1-64)# 15# (1-3)# Outbound DTMF Signal Duration for Auto-
Dialed Digits
FF2 (1-64)# 16# (0 or 1)# Unsupervised Trunk Conference 0 (Disabled on
FF2 (1-64)# 17# (0-9)# Inbound Ring Pattern 0 (Determined by
FF2 (1-64)# 18# (0-15)# Trunk Disconnect Detection Timer 7 (over 350 ms) 2-15 FF2 (1-64)# 19# (HHMM)# DISA Start Time Not set 2-16 FF2 (1-64)# 20# (HHMM)# DISA End Time Not set 2-17 FF2 (1-64)# 21# (0-4)# Trunk Circuit Type 0 (Loop start) 2-18 FF2 (1-64)# 22# (0 or 1)# DID Immediate or Wink Start 0 (Wink start) 2-21 FF2 (1-64)# 23# (0-15)# Wink Start Timer 3 (200 ms) 2-22 FF2 (1-64)# 24# (0-15)# Time Out for Dialed DID Digits 4 (18 sec) 2-23 FF2 (1-64)# 25# (0-15)# DID Interdigit Timeout 5 (80 ms) 2-24 FF2 (1-64)# 26# (4-8)# Trunk Port Class Automatically set 2-25
1 (75 ms on/ 50 ms off)
trunk)
CO)
2-11
2-12
2-13
2-14
Program Address Topic Default Page
FF3: Extension Settings
FF3 (1-144)# 1# (10-69 or 100-699)# Extension Numbers 10/100 (Port 1)
11/101 (Port 2) ... etc.
FF3 (1-144)# 2# (1-48)# Terminal Type 4 (34-button key
phone)
FF3 (1-144)# 3# (1-144)# EM/24 Port Assignment No assignment 3-7 FF3 (1-144)# 4# (0 or 1)# Forced Least Cost Routing 0 (Disabled) 3-8 FF3 (1-144)# 5# (0-2)# Forced Account Codes 0 (Voluntary) 3-9 FF3 (1-144)# 6# (0000-9999)# Extension Lockout Code Not set 3-10 FF3 (1-144)# 7# (0 or 1)# Offhook Signal (CO) 0 (Disabled)
1 (Enabled for Primary Atten­ dant only)
FF3 (1-144)# 8# (0 or 1)# C all Waiting/OHVA 1 (Enabled) 3-12 FF3 (1-144)# 9# (0 or 1)# B usy Override Send 0 (Disabled) 3-13 FF3 (1-144)# 10# (0 or 1)# Busy Override Receive 1 (Enabled) 3-14 FF3 (1-144)# 11# (0 or 1)# Prime Line Pickup 0 (Disabled) 3-15 FF3 (1-144)# 12# (0 or 1)# Auto Pickup (Ringing Line) 1 (Enabled) 3-16 FF3 (1-144)# 13# (0 or 1)# Unsupervised Conference 0 (Disabled) 3-17
3-1
3-3
3-5
3-11
Intro-16 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Program Address Topic Default Page
FF3 (1-144)# 14# (0 or 1)# Station Message Detail Recorder (SMDR)
Report
FF3 (1-144)# 15# (0-4)# Offhook Signal Volume 2 (Mid-level) 3-19 FF3 (1-144)# 16# (0 or 1)# Offhook Signal Pattern 0 (Repeated tone
FF3 (1-144)# 17# (0 or 1)# PSD Name Display on Large-Sized LCD
Phones FF3 (1-144)# (18-25)# (0 or 1)# Page Group Extensions 0 (None) 3-22 FF3 (1-144)# 26# (0-24/39)# Display When Idle 0 (Prev. menu) 3-23 FF3 (1-144)# 27# (0-24/39)# Display During Intercom Dial Tone 0 (Prev. menu) 3-25 FF3 (1-144)# 28# (0-24/39)# Display When Calling an Extension 0 (Prev. menu) 3-27 FF3 (1-144)# 29# (0-24/39)# Display When Accessing CO Dial Tone 0 (Prev. menu) 3-29 FF3 (1-144)# 30# (0-24/39)# Display When Conversing on a CO Trunk 0 (Prev. menu) 3-31 FF3 (1-144)# 31# (0-24/39)# Display When Receiving a Page 0 (Prev. menu) 3-33 FF3 (1-144)# 32# (0-24/39)# Display After Receiving a
Call Waiting
Tone 0 (Prev. menu) 3-35 FF3 (1-144)# 33# (0-24/39)# Display When Dialing a Busy Extension 0 (Prev. menu) 3-37 FF3 (1-144)# 34# (0 or 1)# Extension Directory Display
(CPC-AII; CPC-B 2.0 or highe r)
FF3 (1-72)# 34# (0 or 1)# VAU Port Assignment
(CPC-A 3.3 or higher)
FF3 (1-144)# 35# (0-8)# Extension Class of Service Assignment
(CPC-AII; CPC-B 3.1 or highe r)
FF3 (1-144)# 35# (0000-9999)# Inbound DID Dial Numbers FF3 (1-72)# 35# (0 or 1)# AEC Disconnect
(CPC-A 3.3 or higher)
(CPC-B 2.0 only)
FF3 (1-144)# 36# (0-2)# Ringback Tone From ML Keys 0 (Ringback, then
FF3 (1-144)# 37# (1-2 or 7-8)# Station Port Class
FF3 (1-144)# 38# (0 or 1)# SLT Hookflash
(CPC-B 4.0 or higher)
(CPC-B 3.1 or higher)
FF3 (1-144)# 39# (0-9)# Extension Ring Pattern 0 (Determined by
FF3 (1-144)# 40# (0 or 1 )# Digital SLT Receiving Volume 0 (Normal) 3-48 FF3 (1-144)# 41# (0001-9999)# Auto Set Relocation Code Not set 3-49 FF3 (1-144)# 42# (0-3)# Permanent Call Forward Type 0 (Off) 3-51 FF3 (1-144)# 43# (10-69 or 100-699)# Permanent Call Forward Extension No assignment 3-52 FF3 (1-144)# 44# (0 or 1)# ML/MCO Separation 0 (MCO keys) 3-53 FF3 (1-144)# 45# (0 or 1)# VAU Hunting Priority 0 (No priority) 3-54 FF3 (1-144)# 46# (0 or 1)# AEC Disconnect 0 (Disabled) 3-55 FF3 (1-144)# 47# (0 or 1)# VAU Port Assignment 0 (Off) 3-56 FF3 (1-144)# 48# (0 or 1)# Hot Dial Pad FF3 (1-144)# 49# (0 or 1)# Auto-Redial on Extensions
higher)
(CPC-AII/B 7.0 or higher)
(CPC-AII/B 7.0 or
1 (Extension is
3-18 included in SMDR report)
3-20 burst)
0 (5 PSD names) 3-21
0 (5 names) 3-39
(see page 3-56)
0 (Class 0; a l l
3-40 features allowed)
No assignment 3-41 0 (Disabled) 3-41
3-42 busy tone)
Automatically
3-43 assigned
0
(Broker’s hold)
3-45
3-46 CO)
0 (Disabled) 3-57 1 (Enabled) 3-58
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-17
Introduction to DBS Programming Section 400-Programming
Program Address Topic Default Page
FF4: Ringing and Hunt Groups
4-1
FF4 1# (1-73/145)# (1-64)# (0 or 1)# CO Day Ring Assignments 0 (No ring) 4-3 FF4 1# (79-86 or 151-158)# (1-64)#
CO Day Ring Assignments for Hunt Groups 0 (No ring) 4-4
(0 or 1)# FF4 2# (1-73/145)# (1-64)# (0 or 1)# CO Night Ring Assignments 0 (No ring) 4-5 FF4 2# (79-86 or 151-158)# (1-64)#
CO Night Ring Assignments for Hunt Groups 0 (No ring) 4-6
(0 or 1)# FF4 3# (1-8)# 1# (11-69 or 101-699)# Hunt Group Pilot Numbers
(CPC-AII; CPC-B 2.0 or highe r)
FF4 3# (1-8)# 1# (0 or 1)# Terminal/Circular Hunt Groups
(CPC-A; CP C- B prior to 2.0)
FF4 3# (1-8)# 2# (0-2)# Hunt Group Type
(CPC-AII; CPC-B 2.0 or higher)
No assignment 4-7
0 (Terminal
4-9
hunting) 0 (Terminal
4-11 hunting)
FF4 3# (1-8)# 2# (1-8)# Call Next Hunt Group FF4 3# (1-8)# (3-10)# (10-69 or
Hunt Group Members
(CPC-A; CPC-B prior to 2.0) (CPC-A; CPC-B prior to 2.0)
No assignment 4-13 No assignment 4-14
100-699)# FF4 3# (1-8)# 3# (10-69 or 100-699)# Transfer Extension FF4 3# (1-8)# 4# (0-32)# Hunt Group Transfer Timer
or higher)
FF4 3# (1-8)# (5-12/20)# (10-69 or 100-699)#
FF4 4# (1-16)# (1-8)# (10-69 or
Hunt Group Members
higher)
Call Coverage Group Members No assignment 4-18
(CPC-AII; CPC-B 2.0 or higher)
(CPC-AII; CPC-B 2.0
(CPC-AII; CPC-B 2.0 or
000 4-15 2 (2 sec) 4-16
No assignment 4-17
100-699)# FF4 5# (1-73/145)# (1-64)# (0 or 1)# CO Delayed Day Ring Assignments 0 (No ring) 4-20 FF4 5# (79-86 or 151-158)# (1-64)#
(0 or 1)#
CO Delayed Day Ring Assignments for Hunt Groups
0 (No ring) 4-21
FF4 6# (1-73/145)# (1-64)# (0 or 1)# CO Delayed Night Ring Assignments 0 (No ring) 4-22 FF4 6# (79-86 or 151-158)# (1-64)#
(0 or 1)#
CO Delayed Night R i ng A ssi gnm ent s fo r H u nt Groups
0 (No ring) 4-23
FF4 7# (1-144)# (1-144)# (0 or 1)# Extension Ring Table 0 (No ring) 4-25 FF4 8# (1-144)# (1-144)# (0 or 1)# Extension Delayed Ring Table 0 (No ring) 4-26 FF4 9# 1# (1-73/145)# (1-64)#
or
(0
1)#
FF4 9# 1# (79-86 or 151-158)# (1-
64)# (0 or 1)#
FF4 9# 2# (1-73/145)# (1-64)# (0 or 1)#
FF4 9# 2# (79-86 or 151-158)# (1-
64)#
CO Night 2 Ring Assignments
(CPC-AII/B 7.0 or higher)
CO Night 2 Ring Assignments for Hunt Groups
(CPC-AII/B 7.0 or higher)
CO Delayed Night 2 Ring Assignments
(CPC-AII/B 7.0 or higher)
CO Delayed Night 2 Ring Assignments for Hunt Groups
(CPC-AII/B 7.0 or higher)
0 (No ring) 4-27
0 (No ring) 4-28
0 (No ring) 4-29
0 (No ring) 4-30
(0 or 1)#
Intro-18 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Program Address Topic Default Page
FF5: FF Key Programming
FF5 (1-144)# (1-24)# CONF (Code)# FF Key Assignments for Extensions No assignment 5-3 FF5 (73-76 or 145-148)# CONF (1-
72)# (Code)#
FF5 (149-152)# (1-32)# CONF (Code)#
FF Key Assignments for DSS Consoles No assignment 5-8
Attendant Feature Package Key Assignments
CPC-B 2.0 to 4.0 with AFP
No assignment 5-10
5-1
Program Address Topic Default Page
FF6: Name and Message Assignments
FF6 1# (1-144)# CONF (up to 10 char.)#
FF6 2# (00-89 or 000-199)# CONF (up to 16 char.)#
FF6 3# (1-144)# (90-99 or 900-909)# CONF (up t o 16 char.)#
FF6 4# (5-9)# CONF (up to 15 char.)# Absence Messages No assignment 6-6 FF6 5# (1-64)# CONF (up to 6 char.)# Trunk Name Assignment No assignment 6-8 FF6 6# (1-8)# CONF (up to 10 char.)# Hunt Group Name Assignment No assignment 6-9 FF6 7# (1-5)# CONF (up to 15 char.)# Call Waiting/OHVA Text Reply No assignment 6-10 FF6 8/9# (1-200)# (1 or 2)# (0000-
9999)# (up to 6 char.)#
Extension Name No assign ment 6-3
System Speed Dial Names No assignment 6-4
Personal Speed Dial Names No assignment 6-5
DID/DNIS Text Name Assignment
(CPC-B 5.0 or higher)
No assignment 6-11
6-1
Program Address Topic Default Page
FF7: Toll Restrictions
FF7 1# 1# (0 or 1)# International Ca lling For TRS Types 3-6 0 (De ny/Check
Country Code Table)
FF7 1# 2# (0 or 1)# DTMF Signaling During Incoming Calls for
TRS Types 0-6
FF7 1# 3# (1-15)# Maximum Dialed Digits For TRS Types 3-6 ** (Unlimited) 7-7 FF7 1# (4-11)# (0 or 1)# 3-Digit Toll Restriction For TRS Types 2-6 0 (Allow) 7-8 FF7 1# (12-16)# (0 or 1)# 7-Digit Toll Restriction For TRS Types 2-6 1 (Check 7-digit
FF7 1# 17# (0 or 1)# Dialing Plan Switch FF7 1# 18# (1-144)# (0 or 1)# Operator Access FF7 1# 19# (1-144)# (0 or 1)# International Calling on Extensions
(CPC-AII/B 6.0 or higher)
(CPC-AII/B 6.0 or higher)
(CPC-AII/B 6.0 or higher)
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-19
1 (Enable DT MF signaling during incoming calls)
table) 0 (Old dial plan) 7-10 0 (Deny) 7-11 0 (Deny) 7-12
7-1
7-5
7-6
7-9
Introduction to DBS Programming Section 400-Programming
Program Address Topic Default Page
FF7 1# 20# (1-10)# (0-999)# Country Code Table FF7 1# 21# (0 or 1)# Equal Access Code Format
(CPC-AII/B 6.0 or higher)
FF7 1# 22# (1-10)# (000-999)# Office Code Restriction Table For TRS Types
2-6
(CPC-AII/B 6.0 or higher)
FF7 2# (3-6)# (000-999)# (0 or 1)# Area Code Table For TRS Types 3-6 0 (Allow) for
FF7 3# (3-6)# (000-999)# (0 or 1)# Office Code Table For TRS Types 3-6 0 (Allow) for
FF7 4# (1-4)# (000-999)# Special Area Code Table For TRS Types 3-6 No assignment 7-18 FF7 5# (1-4)# (000-999)# (0 or 1)# Special Office Code Table For TRS Types 3-6 0 (Allow) for Sp.
FF7 6# (1-50)# (7-digitNo.)# Special 7-Digit Table For TRS Types 2-6 No assignment 7-20 FF7 7# (1-144)# (1-33/65)# (0-7)# Day TRS Types 0-7 for Trunks 7 (TRS type 7--
FF7 8# (1-144)# (1-33/65)# (0-7)# Night TRS Types 0-7 for Trunks 7 (TRS type 7--
FF7 9# (1-4)# (0 or 1)# Area Code Table For TRS Types 3-6 (Global
Copy)
FF7 9# (5-8)# (0 or 1)# Office Code Table For TRS Types 3-6 (Global
Copy)
FF7 9# (9-12)# (0 or 1)# Area & Office Code Table for TRS Types 3-6
(Global Copy)
FF7 9# (13-16)# (0 or 1)# Special Office Code Table For TRS Types 3-6
(Global Copy)
(CPC-AII/B 6.0 or higher)
No assignment 7-13 0 (Old 10XXX
7-14 format)
No assignment 7-15
7-16 TRS types 5 and 6 1 (Deny) for TRS types 3 and 4
7-17 TRS types 4-6 1 (Deny) for TRS type 3
7-19 A/Cs 3-4 1 (Deny) for Sp. A/Cs 1-2
7-21 all calls allowed)
7-22 all calls allowed)
0 (Allow) for
7-23 TRS types 5 and 6 1 (Deny) for TRS types 3 and 4
0 (Allow) for
7-24 TRS types 4, 5 & 6 1 (Deny) for TRS type 3
0 (Allow) for
7-25 TRS types 4, 5 & 6 1 (Deny) for TRS type 3
0 (Allow) for Sp.
7-26 A/Cs 3 and 4 1 (Deny) for Sp. A/Cs 1 and 2
Intro-20 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Introduction to DBS Programming
Program Address Topic Default Page
FF8: Least Cost Routing
FF8 1# (1-15)# (000-999)# (0 or 1)# LCR Area Codes No assignment 8-6 FF8 2# (1-15)# (000-999)# (0 or 1)# LCR Office Codes No assignment 8-7 FF8 3# (1-4)# (000-999)# Special LCR Area Codes No assignment 8-8 FF8 4# (1-4)# (1-15)# (000-999)#
(0 or 1)# FF8 5# (1-15)# (1-48)# (1-8)# Time Priority Route Tables No assignment 8-10 FF8 6# (1-8)# (1-8)# (1-64)# LCR Trunk Groups No assignment 8-12 FF8 7# (1-8)# (up to 16 digits)# LCR Delete Tables No assignment 8-13 FF8 8# (1-8)# (up to 16 digits)# LCR Add Tables No assignment 8-14
Special LCR Office Code Tables No assignment 8-9
8-1
Program Address Topic Default Page
FF9: Copy Program Settings
FF9 1# (1-64)# (1-64)## Trunk Copy Not set 9-3 FF9 2# (1-144)# (1-144)## Extension Copy Not set 9-4 FF9 3# (1-144)# (1-144)## FF Key Copy Not set 9-5
9-1
Program Address Topic Default Page
FF10: Speed Dial Programming
FF10 1# (00-89 or 00 0-1 99)# (up to 16 digits)#
FF10 2# (1-144)# (90-99 or 900-909)# (up to 16 digits)#
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Intro-21
System Speed Dial Numbers Not set 10-3
Personal Speed Dial Numbers Not set 10-5
10-1
Introduction to DBS Programming Section 400-Programming
Intro-22 DBS Manual - Revised April 2000 DBS-2.3/9.2-400

1. System Programming (FF1)

This chapter describes DBS system settings using programming key FF1. This chapter covers the following FF1 addresses:
FF1 Address Topic Page
FF1 1# Date and Time Settings 1-3 FF1 2# 1# General System Settings 1-6 FF1 2# 2# Serial Port Parameters (TTY Settings) 1-53 FF1 2# 3# PBX Settings 1-63 FF1 2# 4# External (UNA) Relay Control 1-66 FF1 2# 5# Class of Service 1-68 FF1 2# 6# Account Codes 1-70 FF1 2# 7# Flexible Function Screens 1-73 FF1 2# 8# Caller ID Automatic DISA 1-81 FF1 2# 9# Door Phones FF1 3# System Timers 1-91 FF1 4# thru 7# Programming and DISA Codes 1-127 FF1 8# 1# and 2# New Function Reset 1-132 FF1 8# 3# thru 7# DID/DNIS and T1 Settings
(CPC-AII/B 7.0 or higher)
(CPC-B only)
1-82
1-133
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-1
Page 1-2 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Date and Time Settings

Day/Date Setting

Software Version: All Versions Address: FF1 1# 1# (MMDDYY)#
Description
This program sets the date in the DBS system clock. The day and date are printed on the Station Message Detail Recording
(SMDR) printout. Proper LCR (Least Cost Routing) operation depends on correct date settings. Proper operation of peripheral equipment may also depend on correct date settings.
Programming
Special Programming
For Leap years starting February 2000 and beyond (2004, 2008, etc.), the date
be programmed as described below with small DBS KSUs (VB-42010
must
and VB-42020).
FF1 1# 1# (MMDDYY)#
Month, day, and year in numeric format (for example, January 1, 1995 would be entered as 010195).
The order of the procedure is very important. The date must be programmed first, then the day of the week.
Table 1-1. Date/Day of Week Programming Instructions (YOU MUST USE EXT 10 OR EXT 11).
1
2
3
One touch key No.1 Also called Personal Speed Dial keys. (lower
4
left key)
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-3
Chapter 1. System Programming (FF1) Section 400-Programming
Day of the Week Programming Instructions
(YOU MUST USE EXT 10
( - )
Six-digit date Enter in the YYMMDD format.
5
Example: 000229 is Feb. 29, 2000.
6
7
8
9
10
One touch key No.1 Also called Personal Speed Dial keys. (lower
11
left key)
12
13
14
15
Number
Day of week code:
Monday Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Page 1-4 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Time Setting

Software Version: All Versions Address: FF1 1# 2# (HHMM)#
Description
Programming
This program sets the time in the DBS syste m clock. The time appears on key phones that have LCDs. The time is also recorded in SMDR call records.
Note:
Routing) operation.
Correct time settings are necessary for proper LCR (Least Cost
FF1 1# 2# HHMM#
Time setting in 24-hour format .(for example, 3:00 pm would be entered as 1500).
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-5
Chapter 1. System Programming (FF1) Section 400-Programming

General System Settings

Call Duration Display

Software Version: All Versions Address: FF1 2# 1# 1# (0 or 1)#
Description
This program determines whether call duration will be displayed on telephones with LCDs. By default, call duration will display.
Programming
Related Programming
SMDR Display Start Timer for CO Calls: FF1 2# 1# 2# (0, 1 or 2)# LCD Timer for Caller ID: FF1 2# 1# 38# (0, 1 or 2)#
Notes
No Interaction With SMDR Records.
record generation.
FF1 2# 1# 1# (0 or 1)#
0=Call duration is not displayed.
1=Call duration is displayed.
This setting does not affect SMDR
Timing o f Call Dur ation Display.
Caller ID, the the delay before call duration is displayed, so that Caller ID information can appear first. In versions prior to 6.1, the
CO Calls
Page 1-6 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
LCD Timer for Caller ID
(see next address) controls the delay.
In CPC-AII/B Version 6.1 or higher using
address (FF1 2# 1# 38#) determines
SMDR Display Start Timer for
Section 400-Programming Chapter 1. System Programming (FF1)

SMDR Display Start Timer for CO Calls

Software Version: All Versions Address: FF1 2# 1# 2# (0, 1, or 2)#
Description
Programming
This address determines the delay between the start of a call and the beginning of the SMDR record (5 seconds by default). In CPC-AII/B versions prior to 6.1, it also controls the delay before call duration is displayed on LCD phones.
•
For Incoming Calls:
answers an incoming trunk call. If the user hangs up before the Timer ends, the system will not generate an SMDR record for the call.
•
For Outgoing Calls:
the outgoing phone number. This allows time for the CO to connect the call, or the called party to answer, before beginning the SMDR record.
An incoming call starts when the extension user
An outgoing call starts after the extension user dials
FF1 2# 1# 2# (0, 1, or 2)#
0= SMDR record begins after 5 seconds.
1= SMDR record begins after 16 seconds. 2= SMDR record begins after 30 seconds.
Related Programming
Call Duration Display: FF1 2# 1# 1# (0 or 1)# SMDR Communications Parameters: FF1 2# 2# (1# thru 9#) SMDR Report (including the extension in): FF3 (ExtPort)# 14# (0 or 1)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-7
Caller ID Interaction.
the SMDR Display Start Timer does not control when call duration starts displaying on LCD phones. Instead, the controls when the display begins.
Settings In Older DBS Versions.
3.1, the SMDR Display Start Timer has only two settings -- “0” (16 seconds) or “1” (30 seconds).
In CPC-AII/B Version 6.1 or higher using Caller ID,
LCD Timer for Caller ID
In CPC-A and CPC-B versions prior to
address
Chapter 1. System Programming (FF1) Section 400-Programming

Least Cost Routing (LCR) Access

Software Version: All Versions Address: FF1 2# 1# 3# (0 or 1)#
Description
This program specifies whether Least Cost Routing (LCR) is used when “9” is dialed to make an outside call.
Programming
Related Programming
Forced Least Cost Routing: FF3 (ExtPort)# 4# (0 or 1)# LCR Settings: all FF8 programs
Notes
Restriction With Call Forward-Outside Feature (in CPC-AII and CPC-B Version 7.0 and above).
feature. If LCR is activated (the above address is set to “1”), extensions set to Call Forward-Outside must use trunk groups 1-6 (trunk group “9” cannot be used). See
FF1 2# 1# 3# (0 or 1)#
0=“9” indicates a pooled-trunk call.
1=“9” indicates an LCR call.
LCR will not work with the Call Forward-Outside
Section 700-Feature Operation
for more information.
Required Hardware Setting.
See
Section 300-Installation
FCC Registration.
should be used to identify the DBS system. Both registration numbers -- one for the DBS as a PBX system (S1 is cut), and one for the DBS as a KSU (S1 is not cut) -- are printed on a label in the main cabinet. See
Installation
Page 1-8 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
for more information.
If strap S1 is cut, a different FCC registration number
Cut strap S1 on the CPC card to enable LCR.
for instructions.
Section 300-
Section 400-Programming Chapter 1. System Programming (FF1)

Override Toll Restriction With SSD Numbers

Software Version: All Versions Address: FF1 2# 1# 4# (SSD)#
Description
Programming
This address allows you to set a range of System Speed Dial (SSD) codes that will override Toll Restriction Service (TRS) types 2-6.
The number entered in this address is the lower boundary for SSD codes that will override TRS. In other words, all SSD numbers higher than the one entered will also override TRS types 2-6.
To set a range of SSD numbers to override TRS settings (enter the lowest SSD code in the range) ...
FF1 2# 1# 4# (00-89 or 000-199)#
Lowest SSD Code that will override TRS
(all SSDs above this number will also override TRS)
=SSD code range for CPC-A (all versions),
00-89
CPC-AII and CPC-B versions prior to 7.0
000-199
Version 7.0 or higher
=SSD code range for CPC-AII and CPC-B
To reset to the default value ...
By default, SSD numbers do not override TRS types 2-6. To reset to default:
FF1 2# 1# 4# CONF ON/OFF
Related Programming
TRS Settings: all FF7 programs SSD Numbers: FF10 1# (SSD)# (PhoneNo.)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-9
SLT Audio Delay.
executed on an SLT phone, there is a 15-second delay before audio is passed to the receiver.
If “Override Toll Restriction With SSD Numbers” is
Chapter 1. System Programming (FF1) Section 400-Programming

SSD Display Restriction

Software Version: All Versions Address: FF1 2# 1# 5# (0 or 1)#
Description
Programming
This address determines whether the telephone’s LCD will display the phone number actually sent by the DBS when an SSD code is dialed (or redialed with the REDIAL key). By default, the phone number will display.
This address affects SSD codes 80-89 (or 160-199, in CPC-AII/B Version 7.0 or higher). The phone numbers associated with SSD codes 00-79 (or 000-
159) will always display during dialing, regardless of the setting here. If SSD Display Restriction is enabled (set to “1” in this address), the text
assigned to the SSD code will display, but the dialed digits will not.
FF1 2# 1# 5# (0 or 1)#
0=DBS-dialed digits of SSD are displayed.
1=DBS-dialed digits are not displayed (only the SSD name is displayed).
SSD Codes Affected By This Address -­ 80-89 (all CPC versions prior to 7.0) or 160-199 (CPC-AII/B Version 7.0 or higher)
Related Programming
Override TRS With SSD Numbers: FF1 2# 1# 4# (SSD)# SSD Name Display: FF1 2# 1# 19# (0 or 1)# SSD Names: FF6 2# (SSD)# CONF (Name)# SSD Numbers: FF10 1# (SSD)# (PhoneNo.)#
Page 1-10 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Auto Flash Redial

Software Version: All Versions Address: FF1 2# 1# 6# (0 or 1)#
Description
This address determines whether the DBS will send a “flash” signa l to the CO on loop-start trunks when the REDIAL key is pressed. By default, the REDIAL key sends a flash before redialing a number.
If your DBS system is connected to a PBX, set this address to “0” (sending a flash may place the line to the PBX on hold).
Programming
Related Programming
CO Flash Timer: FF1 3# 13# (0-15)# PBX Flash Timer: FF1 3# 18# (0-10)# Trunk Port Type: FF2 (Trunk)# 10# (1 or 2)#
FF1 2# 1# 6# (0 or 1)#
0=REDIAL does not send “flash”.
1=REDIAL sends “flash”.
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-11
Flash Timi ng.
a flash when REDIAL is pressed.
Ground-Start Trunk Restriction.
functional for ground-start trunks. See information.
The CO Flash Timer (FF1 3# 1 1#) determines the duration of
The Flash and Redial features are not
Technote 13
(March 1992) for more
Chapter 1. System Programming (FF1) Section 400-Programming

One Touch Dial

Software Version: All Versions Address: FF1 2# 1# 7# (0 or 1)#
Description
The One-Touch Dial feature enables users to dial an extension by pressing a single programmable key. This feature is enabled regardless of the program setting (One-Touch Dial cannot be deactivated).
Page 1-12 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Onhook Transfer

Software Version: All Versions Address: FF1 2# 1# 8# (0 or 1)#
Description
This address determines whether a call can be transferred without pressing the PROG key.
• If Onhook Transfer is enabled (default setting), the user can transfer a call by placing the call on hold, dialing the extension number , and then hanging up.
• If Onhook Transfer is disabled, the user places the call on hold, dials the extension number, then presses PROG (or “8” if using an SLT or DSLT phone) and hangs up to transfer the call.
Programming
Related Programming
FF1 2# 1# 8# (0 or 1)#
0=Onhook Transfer is disabled.
1=Onhook Transfer is enabled.
Attendant Transfer Recall Timer for CO Calls: FF1 3# 4# (0-12)# Extension Transfer Recall Timer for CO Calls: FF1 3# 5# (0-12)# Attendant Transfer Recall Timer for Intercom Calls: FF1 3# 24# (0-12)# Extension Transfer Recall Timer for Intercom Calls: FF1 3# 25# (0-12)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-13
Call Transfer Limitation With CPC-A.
can be onhook-transferred to other extensions. In CPC-AII and CPC-B, both trunk and intercom calls can be onhook-transferred.
Transfer Recalls.
answered, it will automatically transfer to the attendant. Timing for the attendant transfer is controlled by the Attendant Call Reversion Timer (FF1 3# 10# 0-12#).
VAU Interaction.
Transfer to allow the VAU to transfer calls.
If a transferred call recalls to an extension and is not
If a VAU (Voice Announce Unit) is used, enable Onhook
In CPC-A versions, only trunk calls
Chapter 1. System Programming (FF1) Section 400-Programming

Key Bank Hold

Software Version: All Versions Address: FF1 2# 1# 9# (0 or 1)#
Description
Programming
Use this address to enable or disable the Key Bank Hold feature in the DBS system.
• If Key Bank Hold is enabled:
- a phone user can switch back and forth between trunk calls (by pressing the FF key for each trunk) without placing the current trunk on hold.
- an Attendant phone can press a DSS/BLF key to automatically transfer a trunk call to an extension without pressing HOLD first.
In both cases, the DBS will automatically place the current trunk call on System Hold (anyone can pick up the call) when the phone user presses the FF key or DSS/BLF key.
• If Key Bank Hold is disabled (default setting), the phone user must press HOLD before accessing a second trunk or transferring a call.
FF1 2# 1# 9# (0 or 1)#
0=Key Bank Hold is disabled.
1=Key Bank Hold is enabled.
Page 1-14 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Non-Appearing Trunk Hold

Software Version: All Versions Address: FF1 2# 1# 10# (0 or 1)#
Description
Programming
This address determines who can pick up trunk calls that are on hold. It applies to DBS phones that don’t have dedicated key appearances for trunk calls (the phone user can’t tell which trunk is being used for incoming or outgoing calls).
Choose one of the following:
•
Exclusive Hold:
was placed on hold.
•
System Hold (default setting):
The call can be retrieved only on the extension where it
Any extension can pick up the call.
FF1 2# 1# 10# (0 or 1)#
0=Exclusive Hold is used for non-appearing trunk calls.
1=System Hold is used for non-appearing trunk calls.
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-15
Applicable Phone Types.
telephones.
Number of Trunks That Can Be Held Without Key Appearances.
that do not have a key appearance for trunk calls can only hold one trunk at a time.
VAU Interaction.
Appearing Trunk Hold to “Exclusive Hold” to prevent other extensions from picking up calls being handled by the VAU.
If a VAU (Voice Announce Unit) is used, set Non-
This feature applies to both single-line and digital
Phones
Chapter 1. System Programming (FF1) Section 400-Programming

SLT Flash Control

Software Version: All Versions Address: FF1 2# 1# 11# (0 or 1)#
Description
Table 1-2. SLT Hookflash Control Settings
This address determines how the DBS will respond to a second hookflash during a call transfer on an SLT (Single-Line Telephone). By default, the second hookflash will retrieve the held call.
To transfer a call on an SLT, the user hookflashes to place the call on hold, then dials the extension number to transfer the call to. If the extension is busy or not answered, the SLT user can hookflash again to either return to dial tone or retrieve the held call, depending on the setting (“0” or “1”, respectively) in this address.
The following table further explains the SLT call transfer process for both settings:
If SLT Flash Control Is Set to “0” ... If SLT Flash Control Is Set to “1” ...
-- The user hookflashes to place a call on hold.
-- The user dials an extension number to transfer the call. The extension is busy or does not answer.
-- The user hookflashes to place a call on hold.
-- The user dials an extension number to transfer the call. The extension is busy.
-- The user hookflashes a second time to receive dial tone.
-- The user dials another extension*.
-- When the extension rings, the user hangs up to transfer the held call.
* Or, the user can hookflash a third
time to retrieve the held call.
NOTE:
SLT user is listening to dial tone.
This address does not affect how the hookflash functions when the
-- The user hookflashes a second time to retrieve the held call.
-- The user can then hookflash a third time to place the call on hold and receive dial tone.
-- The user dials another extension.
-- When the extension rings, the user hangs up to transfer the held call.
Page 1-16 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)
Programming
FF1 2# 1# 11# (0 or 1)#
0=A second SLT hookflash results in dial tone.
1=A second SLT hookflash retrieves a held call.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-17
Chapter 1. System Programming (FF1) Section 400-Programming

Extension Number Digits

Software Version: All Versions Address: FF1 2# 1# 12# (0 or 1)##
Description
This address determines whether the DBS will use 2-digi t or 3-digit extension numbers.
• If
2-digit numbers
available for assignment. Number Range: 10 thru 69.
• If
3-digit numbers
numbers are available. Number Range: 100 thru 699.
Programming
Related Programming
are used, a maximum of 60 extension numbers are
are used (default setting), a maximum of 600 extension
FF1 2# 1# 12# (0 or 1)# (# or *)
0=2-digit numbers
1=3-digit numbers
A second “#” is required to confirm the new numbering plan. (Or, enter “*” to cancel the new numbering plan.)
Notes
Extension Numbers: FF3 (ExtPort)# 1# (10-69 or 100-699)#
Interaction With Larger Systems.
your system, use 3-digit extension numbers. Sites with fewer than 60 phones can use either 2-digit or 3-digit extension numbers.
Interaction With Voice Mail.
numbers in order to match extensions with Voice Mail boxes.
Precaution for Changing Extension Number Digits.
can adversely affect other DBS settings that are based on extension numbers, such as entries for DSS/BLF keys and Call Forwarding.
If more than 60 phones are installed in
If your system uses Voice Mail, use 3-digit
Changing this setting
Page 1-18 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Alternate Attendant

Software Version: CPC-A and CPC-B Versions Prior to 2.0 Address: FF1 2# 1# 13# (0 or 1)#
Description
Use this address to enable or disable the use of an Alternate Attendant phone. By default, the Alternate Attendant is enabled.
When enabled, the Alternate Attendant phone receives overflow intercom calls from the Primary Attendant. The Alternate Attendant also has full access to Attendant features.
Programming
Related Programming
Attendant Overflow for Primary Attendant (CPC-B Version 1.0 only): FF1 2# 1# 22# (1-15)#
Extension Numbers (assigning to ports): FF3 (ExtPort)# 1# (ExtNo.)#
FF1 2# 1# 13# (0 or 1)#
0=Disables the Alternate Attendant.
1=Enables the Alternate Attendant.
Terminal Type: FF3 (ExtPort)# 2# (Type)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-19
Alternate Attendant Phone Settings In Later DBS Versions.
Version 2.0 and above, and in all CPC-AII versions, you can program Second, Third, and Fourth Attendant phones instead of just one Alternate Attendant. See FF1 2# 1# 24# thru 26# for more information.
Limitations on Assigning Attendant Phones.
recognizes the Primary Attendant location at extension port 1, with extension number 10 or 100; this cannot be changed. However, you can change the assignment of the Alternate Attendant -- but it is recommended that you leave its default extension number at 11 or 101, so that a DSS/BLF console can be used with it. (The Alternate Attendant is assigned by default to port 2, but it can be reassigned to another port -- as long as extension 11 or 101 is assigned to the new port.)
The DBS system always
In CPC-B
Chapter 1. System Programming (FF1) Section 400-Programming

Attendant Intercom Calling

Software Version: All Versions Address: FF1 2# 1# 14# (0 or 1)#
Description
Use this address to determine how intercom calls from an Attendant phone are announced at extension phones -- by ringing the extension, or by immediately establishing a voice path over the extension loudspeaker. By default, a voice path is established when an Attendant dials an extension.
After the connection is established, the Attendant can change from voice to ring (or vice versa) by dialing “1”.
Programming
Related Programming
Alert Tone for Voice Calls: FF1 2# 1# 16# (0 or 1)#
FF1 2# 1# 14# (0 or 1)#
0=Ring tone intercom calling from Attendant.
1=Voice intercom calling from Attendant.
Notes
Page 1-20 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Interaction With VAU.
a VAU is used, the VAU will not answer a call from an Attendant unless the Attendant dials a “1” after dialing the VAU.
If this address is set to “Voice intercom calling” and
Section 400-Programming Chapter 1. System Programming (FF1)

Extension Intercom Calling

Software Version: All Versions Address: FF1 2# 1# 15# (0 or 1)#
Description
Use this address to determine how intercom calls from another extension will be announced at extension phones -- by ringing the extension, or by immediately establishing a voice path over the extension loudspeaker. By default, a voice path is established when an extension dials another extension
-- the called party can hear and talk to the caller without lifting the handset. After the connection is established, the caller can switch from voice to ring
(or vice versa) by dialing “1”.
Programming
Related Programming
Alert Tone for Voice Calls: FF1 2# 1# 16# (0 or 1)#
FF1 2# 1# 15# (0 or 1)#
0=Tone intercom calling from extension.
1=Voice intercom calling from extension.
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-21
Interaction With VAU.
a VAU is used, the VAU will not answer a call from an extension unless the extension dials a “1” after dialing the VAU.
If this address is set to “Voice intercom calling” and
Chapter 1. System Programming (FF1) Section 400-Programming

Alert Tone for Voice Calls

Software Version: All Versions Address: FF1 2# 1# 16# (0 or 1)#
Description
Use this address to determine whether voice intercom calls are preceded by an initial alert (“splash”) tone. By default, the alert tone is enabled.
The alert tone (if enabled) will be sounded for 0.5 seconds before the caller’s voice path is established.
Programming
Related Programming
Attendant Intercom Calling: FF1 2# 1# 14# (0 or 1)# Extension Intercom Calling: FF1 2# 1# 15# (0 or 1)#
FF1 2# 1# 16# (0 or 1)#
0=Alert tone is disabled.
1=Alert tone is enabled.
Page 1-22 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Alert Tone for Busy Override & OHVA

Software Version: All Versions Address: FF1 2# 1# 17# (0 or 1)#
Description
This address determines if Attendant Override, Busy Override, and Offhook Voice Announce (OHVA) calls are preceded by an alert tone. By default, the alert tone is disabled.
This feature is governed by state law -- some states require the alert tone.
Programming
Related Programming
Busy Override Send: FF3 (ExtPort)# 9# (0 or 1)# Busy Override Receive: FF3 (ExtPort)# 10# (0 or 1)# Page Group Extensions: FF3 (ExtPort)# 18# thru 25# (0 or 1)#
FF1 2# 1# 17# (0 or 1)#
0=Alert tone is disabled.
1=Alert tone is enabled.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-23
Chapter 1. System Programming (FF1) Section 400-Programming

System Installation Area Code

Software Version: All Versions Address: FF1 2# 1# 18# (0 or 1)#
Description
This address determines if the DBS site requires a “1” to be dialed before the area code to make long-distance calls. This setting will affect the way the DBS handles Toll Restriction (TRS) and Least Cost Routing (LCR) for long­distance calls.
In almost all cases, the default setting (“1” must be dialed) should not be changed.
Programming
Related Programming
Toll Restrictions: FF7 Least Cost Routing: FF8
FF1 2# 1# 18# (0 or 1)#
0=“1” is not required before a long-distance call.
1=“1” must be dialed before a long-distance call.
Notes
Page 1-24 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Interaction W ith TRS and LCR .
before a long-distance call), the system will look at the first three digits of the number dialed, whether it’s a “1” or not. This would severely limit the capability of TRS and LCR, which are based on 3-digit area codes.
If “1” is selected (“1” system will ignore the first dialed digit (could be “0” or “1”) and look at the next three digits dialed as the area code.
required before dialing a long-distance call), the
is
If “0” is selected above (“1” is
required
not
Section 400-Programming Chapter 1. System Programming (FF1)

SSD Name Display

Software Version: All Versions Address: FF1 2# 1# 19# (0 or 1)#
Description
Use this address to determine how many SSD (System Speed Dial) names can be displayed at a time on large-display phones, whenever an SSD menu is displayed.
When 5 names are displayed (default setting), the maximum length for each name is 16 characters. When 10 names are displayed, the maximum length for each name is 7 characters.
Programming
Related Programming
Override TRS with SSD Numbers: FF1 2# 1# 4# (SSD)# SSD Display Restriction: FF1 2# 1# 5# (0 or 1)#
FF1 2# 1# 19# (0 or 1)#
0=Displays 5 SSD names.
1=Displays 10 SSD names.
SSD Menu display during call states: FF3 (ExtPort)# 26# thru 33# 3# System Speed Dial Names: FF6 2# (SSD)# CONF (Name)# System Speed Dial Numbers: FF10 1# (SSD)# (DialedNo.)#
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-25
Chapter 1. System Programming (FF1) Section 400-Programming

API/AEC Slot Assignment

Software Version: Address: FF1 2# 1# 20# (2-9 or 2-18)#
CPC-A Version 3.3 or higher; CPC-AII; and CPC-B Version 5.0 or higher
Description
Programming
This program is only used with third-party API applications. Its purpose is to designate which Analog Extension Card (AEC) is used for voice channel connections to the API product.
FF1 2# 1# 20# (2-9 or 2-18)#
Analog Extension Slot used for voice paths to a third-party API product.
NOTE:
must be a digital port).
Valid Ranges -­ CPC-A and CPC-AII: 2-9 CPC-B: 2-18
Default:
Do not set this to “1” (slot 1
** (no assignment)
Related Programming
Voice Mail Busy Tone: FF1 2# 1# 21# (0 or 1)# Terminal Type: FF3 (ExtPort)# 2# (21-28, 31-38 or 41-48)#
Notes
Page 1-26 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Third-Party Voice Mail Systems Not Integrated With the DBS.
systems, the API card is not required. Set up Call Forward ID codes so that the DTMF codes will be sent to the appropriate Voice Mail box (ON/OFF ­PROG - AUTO - * - [Ext] - [up to 16 char.] - HOLD). See
Feature Operation
for more information.
In these
Section 700-
Section 400-Programming Chapter 1. System Programming (FF1)

Voice Mail Busy Tone

Software Version: All Versions Address: FF1 2# 1# 21# (0 or 1)#
Description
This address determines what is sent to a voice-mail port at the conclusion of a call -- either silence or a busy tone. By default, the DBS sends silence.
Programming
Related Programming
API/AEC Slot Assignment: FF1 2# 1# 20# (2-18)#
FF1 2# 1# 21# (0 or 1)#
0=Silence.
1=Busy tone.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-27
Chapter 1. System Programming (FF1) Section 400-Programming

Analog Transfer Ring Pattern

Software Version: CPC-A Only (Version 3.21 or higher) Address: FF1 2# 1# 22# (0-6)#
Description
Programming
This address determines which ringing pattern is used for transferred calls to devices connected to analog extension ports. By default, the ringing pattern is .4 seconds on / 3.6 seconds off.
This setting is typically used to assign specific ringing patterns for calls transferred to a modem, or for SLTs that require distinctive ringing for transferred calls.
FF1 2# 1# 22# (0-6)#
Setting (in seconds):
0= .4 on / 3.6 off
1= .8 on / .2 off / .8 on / .2 off / .8 on / .2 off / 1 off 2= .8 on / .2 off / .8 on / 2.2 off 3= .8 on / 2.2 off 4= .8 on / 3.2 off 5= .8 on / 5.2 off 6= .8 on / 3.2 off / .8 on / 7.2 off
Notes
Page 1-28 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Analog Transfer Ring Pattern Setting for CPC-AII and CPC-B.
Analog Transfer Ring Pattern for CPC-AII (all versions) and CPC-B (Version
2.11 or higher) is set in FF1 2# 1# 31#.
The
Section 400-Programming Chapter 1. System Programming (FF1)

Attendant Overflow for Primary Attendant

Software Version: CPC-B Version 1.0 only Address: FF1 2# 1# 22# (1-15)#
Description
Programming
This address determines the maximum number of trunk calls that can be stacked at the Primary Attendant phone. By default, up to 8 calls can be stacked at a time.
Calls exceeding the set limit ar e automatically transferred to other extensions. To determine which extensions receive overflow trunk calls, use the Day and Night Delayed Ring tables (FF4 5#, FF4 6#, and FF4 9# 2#).
The following types of calls can be stacked at the Primary Attendant:
• Incoming trunk calls.
• Hold recalls.
• Transferred recalls.
• Hunt group recalls.
• Call reversions.
FF1 2# 1# 22# (1-15)#
Number of Calls That Can Be Stacked (default: 8)
Related Programming
Attendant Hold Recall Timer: FF1 3# 2# (0-12)# Extension Hold Recall Timer: FF1 3# 3# (0-12)# Attendant Transfer Recall Timer: FF1 3# 4# (0-12)# Extension Transfer Recall Timer: FF1 3# 5# (0-12)# Attendant Hunt Group Recall Timer: FF1 3# 6# (0-12)# Extension Hunt Group Recall Timer: FF1 3# 7# (0-12)# Attendant Call Reversion Timer: FF1 3# 10# (0-12)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-29
Overflow Intercom Calls.
Alternate Attendant, if enabled in FF1 2# 1# 13#.
Intercom calls will automatically overflow to the
Chapter 1. System Programming (FF1) Section 400-Programming

Delayed Ring

Software Version: CPC-AII (all versions) and CPC-B Version 2.0 or higher Address: FF1 2# 1# 23# (0 or 1)#
Description
This address determines if delayed ringing is allowed for CO trunks. By default, delayed ringing is disabled.
Delayed ringing is an automatic transfer of unanswer ed calls -- if an incoming call is not answered at one extension, the system will send the call to another extension (the first extension will cease ringing).
Programming
Related Programming
CO Delayed Ring Timer (CPC-AII and CPC-B Ver 3.1 or higher): FF1 3# 26# (0-15)#
FF1 2# 1# 23# (0 or 1)#
0=Delayed ringing is disabled.
1=Delayed ringing is enabled.
CO Delayed Day Ring Assignments: FF4 5# (ExtPort)# (Trunk)# CO Delayed Day Ring Assignments for Hunt Groups: FF4 5# (HuntGrp)#
(Trunk)# CO Delayed Night 1 Ring Assignments : FF4 6# (ExtPort)# (Trunk)# CO Delayed Night 1 Ring Assignments for Hunt Groups: FF4 6#
(HuntGrp)# (Trunk)# CO Delayed Night 2 Ring Assignments: FF4 9# 2# (ExtPort)# (Trunk)# CO Delayed Night 2 Ring Assignments for Hunt Groups: FF4 9# 2#
(HuntGrp)# (Trunk)#
Page 1-30 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

AEC Disconnect Signal Duration

Software Version: CPC-A Version 3.3 or higher Address: FF1 2# 1# 23# (0-15)#
Description
Programming
Use this address to set the AEC card (VB-43621A) to provide a positive disconnect signal, and determine the duration of the signal. By default, the disconnect signal is not sent.
If set, analog extension ports will provide a disconnect signal (open loop) upon hangup. Sending this signal allows quick disconnect from third-party voice mail systems.
FF1 2# 1# 23# (0-15)#
0=No disconnect signal.
1=100 ms signal will be sent. 2=200 ms signal will be sent. 3=300 ms signal will be sent. 4=400 ms signal will be sent. 5=500 ms signal will be sent. 6=600 ms signal will be sent. 7=700 ms signal will be sent. 8=800 ms signal will be sent. 9=900 ms signal will be sent. 10=1-second signal will be sent. 11=1.5-second signal will be sent. 12=2-second signal will be sent. 13=2.5-second signal will be sent. 14=3-second signal will be sent. 15=3.5-second signal will be sent.
Related Programming
AEC Disconnect (CPC-A 3.3 or higher): FF3 (ExtPort)# 35# (0 or 1)# AEC Disconnect (CPC-AII/B 5.0 or higher): FF3 (ExtPort)# 46# (0 or 1)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-31
AEC Disconnect Signal Duration for CPC -B Versions.
5.0 and higher, the AEC Disconnect Signal Duration is set in FF1 2# 1# 35#.
For CPC-B Version
Chapter 1. System Programming (FF1) Section 400-Programming

Second Attendant Position

Software Version: CPC-AII (all versions) and CPC-B Ve rsion 2.0 or higher Address: FF1 2# 1# 24# (11-69 or 101-699)#
Description
Programming
This address assigns an extension number as the Second Attendant position. By default, the Second Attendant position is extension 101.
When all line appearances at the Primary Attendant are busy, calls will transfer in sequence to the Second, Third, and Fourth Attendants. If all line appearances are busy on all Attendants, calls will transfer to the Attendant Transfer Extension (if assigned).
To assign a Second Attendant position ...
FF1 2# 1# 24# (11-69 or 101 to 699)#
Extension Number
(default:
To clear the Second Attendant position ...
11
or
101
)
FF1 2# 1# 24# CONF ON/OFF
Related Programming
Extension Number Digits: FF1 2# 1# 12# (0 or 1)## Third Attendant Position: FF1 2# 1# 25# (11-69 or 101-699)# Fourth Attendant Position: FF1 2# 1# 26# (11-69 or 101-699)# Attendant Transfer Extension: FF1 2# 1# 27# (11-69 or 101-699)# Extension Numbers (assigning to ports): FF3 (ExtPort)# 1# (ExtNo.)#
Notes
Programming Restrictions.
Attendant port before its extension number can be programmed or cleared. Also, use another phone to program or clear its extension number (e.g., you can’t use ext. 101’s phone to program ext. 101 as the Second Attendant position).
Limitations on Assigning Attendant Phones.
leave the Second Attendant at the default assignment (extension 11 or 101), so that a DSS/BLF console can be used. System default for the Primary Attendant phone is extension 10 or 100, assigned to port 1 -- and Primary Attendant assignments cannot be changed.
A telephone must be plugged into the Second
It is recommended that you
Page 1-32 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Third Attendant Position

Software Version: CPC-AII (all versions) and CPC-B Ve rsion 2.0 or higher Address: FF1 2# 1# 25# (11-69 or 101-699)#
Description
Programming
This address assigns an extension number as the Third Attendant position. By default, no extension is assigned as the Third Attendant.
When all line appearances at the Primary Attendant are busy, calls will transfer in sequence to the Second, Third, and Fourth attendants. If all line appearances are busy on all Attendants, calls will transfer to the Attendant Transfer Extension (if assigned).
To assign a Third Attendant position ...
FF1 2# 1# 25# (11-69 or 101 to 699)#
Extension Number
(default:
To clear the Third Attendant position ...
no Third Attendant assigned
)
FF1 2# 1# 25# CONF ON/OFF
Related Programming
Extension Number Digits: FF1 2# 1# 12# (0 or 1)## Second Attendant Position: FF1 2# 1# 24# (11-69 or 101-699)# Fourth Attendant Position: FF1 2# 1# 26# (11-69 or 101-699)# Attendant Transfer Extension: FF1 2# 1# 27# (11-69 or 101-699)# Extension Numbers (assigning to ports): FF3 (ExtPort)# 1# (ExtNo.)#
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-33
Programming Restrictions.
Attendant port before its extension number can be programmed or cleared. Also, use another phone to program or clear its extension number (e.g., you can’t use ext. 102’s phone to program ext. 102 as the Third Attendant position).
Limitation on Assigning the Third Attendant.
allow you to assign extension 10 or 100 as the Third Attendant position. This is the system default for the Primary Attendant phone, which cannot be changed.
A telephone must be plugged into the Third
The DBS system will not
Chapter 1. System Programming (FF1) Section 400-Programming

Fourth Attendant Position

Software Version: CPC-AII (all versions) and CPC-B Ve rsion 2.0 or higher Address: FF1 2# 1# 26# (11-69 or 101-699)#
Description
Programming
This address assigns an extension number as the Fourth Attendant position. By default, no extension is assigned as the Fourth Attendant.
When all line appearances at the Primary Attendant are busy, calls will transfer in sequence to the Second, Third, and Fourth Attendants. If all line appearances are busy on all Attendants, calls will transfer to the Attendant Transfer Extension (if assigned).
To assign a Fourth Attendant position ...
FF1 2# 1# 26# (11-69 or 101 to 699)#
Extension Number
(default:
To clear the Fourth Attendant position ...
no Fourth Attendant assigned
)
FF1 2# 1# 26# CONF ON/OFF
Related Programming
Extension Number Digits: FF1 2# 1# 12# (0 or 1)## Second Attendant Position: FF1 2# 1# 24# (11-69 or 101-699)# Third Attendant Position: FF1 2# 1# 25# (11-69 or 101-699)# Attendant Transfer Extension: FF1 2# 1# 27# (11-69 or 101-699)# Extension Numbers (assigning to ports): FF3 (ExtPort)# 1# (ExtNo.)#
Notes
Page 1-34 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Programming Restrictions.
Attendant port before its extension number can be programmed or cleared. Also, use another phone to program or clear its extension number (e.g., you can’t use ext. 103’s phone to program ext. 103 as the Fourth Attendant position).
Limitation on Assigning the Fourth Attendant.
allow you to assign extension 10 or 100 as the Fourth Attendant position. This is the system default for the Primary Attendant phone, which cannot be changed.
A telephone must be plugged into the Fourth
The DBS system will not
Section 400-Programming Chapter 1. System Programming (FF1)

Attendant Transfer Extension

Software Version: CPC-AII (all versions) and CPC-B Version 2.09 or higher Address: FF1 2# 1# 27# (11-69 or 101-699)#
Description
Programming
Notes
If all line appearances are busy on all Attendants (Primary, Second, Third and Fourth), calls will transfer to the extension assigned in this address.
To assign an Attendant Transfer Extension ...
FF1 2# 1# 27# (11-69 or 101-699)#
Extension Number
(default:
To clear the Attendant Transfer Extension ...
no Transfer Extension assigned
)
FF1 2# 1# 27# CONF ON/OFF
Pilot Number Restriction.
extension -- it cannot be a hunt group pilot number.
The overflow position must be an installed
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-35
Chapter 1. System Programming (FF1) Section 400-Programming

Attendant Override

Software Version: CPC-AII (all versions) and CPC-B Version 2.09 or higher Address: FF1 2# 1# 28# (0 or 1)#
Description
Use this address to enable or disable the Attendant Override feature, which allows an Attendant phone to “barge into” a trunk or intercom call in progress on any extension -- even if the extension has been programmed to block barge-ins. By default, Attendant Override is enabled.
When a barge-in occurs, all three parties can hear and talk to each other.
Programming
Related Programming
Alert Tone for Busy Override & OHVA: FF1 2# 1# 17# (0 or 1)#
FF1 2# 1# 28# (0 or 1)#
0=Disables Attendant Override.
1=Enables Attendant Override.
Page 1-36 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Attendant LED Alarm Indication

Software V ersion: CPC-B Versions 2.09 to 4.0 (requi res Attendant Feature Package) Address: FF1 2# 1# 29# (0 or 1)#
Description
Use this address to allow or disallow the Alarm feature (LED lights to indicate an alarm condition) to be assigned to an FF key on an Attendant phone. By default, the Alarm feature can be assigned.
NOTE:
Version 5.0.
The Attendant Feature Package (AFP) was discontinued in CPC-B
Programming
Related Programming
AFP Key Assignments: FF5 (149-152)# (1-72)# (FF12 4)#
FF1 2# 1# 29# (0 or 1)#
0=Alarm feature cannot be assigned to Attendant FF key.
1=Alarm feature can be assigned to Attendant FF key.
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-37
Installing AFP.
EPROM Chip 1 on the CPC-B card with an AFP chip. Make sure the new chip is installed in the proper direction. See complete information.
Installation of the AFP software requires the replacement of
Technote 4 (September 1991)
for
Chapter 1. System Programming (FF1) Section 400-Programming

Extension (BLF) Delayed Ring

Software Version: CPC-AII (all versions) and CPC-B Ve rsion 2.0 or higher Address: FF1 2# 1# 30# (0 or 1)#
Description
Use this address to enable or disable Delayed Ringing for intercom calls. By default, Extension (BLF) Delayed Ringing is disabled.
Delayed Ringing is a call-forwarding feature for unanswered calls -- if an incoming call is not answered at one extension, the system will send the call to another extension.
NOTE:
key.
The extension to which the call is forwarded must have a DSS/BLF
Programming
Related Programming
FF1 2# 1# 30# (0 or 1)#
0=Extension Delayed Ringing is disabled.
1=Extension Delayed Ringing is enabled.
Extension Delayed Ring Table: FF4 8# (ExtPort)# (ExtPort)# (0 or 1)# Extension Delayed Ring Timer (CPC-B 2.0 or higher): FF1 3# 27# (0-15)# Call Forward-No Answer Timer (CPC-B prior to 2.0): FF1 3# 19# (0-15)#
Page 1-38 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Analog Transfer Ring Pattern

Software Version: CPC-AII (all versions) and CPC-B Version 2.11 or higher Address: FF1 2# 1# 31# (0-6)#
Description
Use this address to choose a distinctive ringing pattern for calls transferred to analog SLT phones. This setting is typically used for calls transferred to a modem, or for SLT phones requiring distinctive ringing for transferred calls.
There are 7 different patterns (numbered 0-6) to choose from. The pattern for each setting depends on the analog connection --
• an SLT phone connected directly to an AEC card;
• an SLT phone connected to an OPX Adapter; or
• an SLT phone connected to an SLT-A (4-port Adapter).
Programming
FF1 2# 1# 31# (0-6)#
Transfer Ring Pattern setting (see table below)
Table 1-3 Analog Transfer Ring Patterns (vary depending on analog connection)
Address
Setting
0
1 2
3 4 5 6
Ring Pattern (no. of seconds on/off) for SLT phones connected to ... AEC Card OPX Adapter SLT Adapter (SLT-A)
.5 on / 4 off .5 on / 3.5 off .25 on / .25 off / .25 on / 3.5 off
1 on / .25 off / 1 on / .25 off / 1 on / 2 off
1 on / .25 off / 1 on / 3 off 2 on / 2 off 1 on / 3.5 off 1 on / 2 off 1 on / 2 off 1 on / 3 off 1 on / 3 off 1 on / 3.5 off 1 on / 7 off 1 on / 6 off 1 on / 5 off .5 on / 7 off 1 on / 4 off / 1 on / 7 off 1 on / 7 off .25 on / .25 off / .25 on / 7 off
3 on / 1 off .25 on / 3.5 off
Related Programming
Analog Transfer Ring Pattern
(CPC-A 3.21 or higher)
Terminal Type: FF3 (ExtPort)# 2# (Type)# Extension Ring Pattern: FF3 (ExtPort)# 39# (0-9)#
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-39
: FF1 2# 1# 22# (0-6)#
Chapter 1. System Programming (FF1) Section 400-Programming

Multiple DID/DNIS

Software Version: CPC-B Version 4.0 or higher Address: FF1 2# 1# 32# (0 or 1)#
Description
Programming
Use this address to enable or disable Multiple DID for analog trunks, or Multiple DID and DNIS for T1 trunks. By default, Multiple DID/DNIS is disabled.
With Multiple DID/DNIS enabled, one DID or DNIS number can be assigned to multiple extensions, which will simultaneously ring whe n an outside cal ler dials the DID or DNIS number.
•
•
stands for “Direct Inward Dialing.” DID can be used only in systems
DID
using analog trunks exclusively (no other types of trunks are used in the system). Up to 500 DID numbers can be assigned to extension numbers in FF1 8# 3# (0000-9999)# (ExtNo.)#.
stands for “Dialed Number Identification Service.” DNIS is
DNIS
available only with the T1 Interface. You can use DID and DNIS simultaneously in a T1 system. Up to 500 DNIS numbers can be assigned to extension numbers in FF1 8# 4# 7# (0000-9999)# (10-69 or 100-699)#, in addition to the 500 DID numbers allowed.
FF1 2# 1# 32# (0 or 1)#
0=Disables Multiple DID/DNIS ringing.
1=Enables Multiple DID/DNIS ringing.
Related Programming
Inbound DID Dial Numbers: FF1 8# 3# (0000-9999)# (100-699)# DID/DNIS (enabling trunks for): FF1 8# 4# 6# (Trunk)# 2# (0-2)# DNIS Number Setting: FF1 8# 4# 7# (0000-9999)# (10-69 or 100-699)# DID Flexible Ringing Assignments: FF1 8# 5# (DIDNo.)# (ExtNo.)#
(000000-111111)# DNIS Flexible Ringing Assignments: FF1 8# 6# (DNISNo.)# (ExtNo.)#
(000000-111111)# Extension Numbers (assigning to ports): FF3 (ExtPort)# 1# (ExtNo.)#
Page 1-40 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)
Notes
Restriction For CPC-B Version 3.1.
This address is also present in CPC-B Version 3.1; however, it only controls Multiple DID (DNIS cannot be used with this version).
DID Hardware and Power Requirements.
The DID trunk card is required; each card provides 8 ports. The card requires dial-pulse dialing and an external, -48V power supply. See
Section 300-Installation
for cabling
instructions.
DID/DNIS Digit Length Requirement.
The DBS only supports 4-digit DID/
DNIS numbers.
Central Office Requirement.
When the CO sends a DID/DNIS call to the DBS, it first receives a wink from the DBS before sending the digits. Once the wink is received, the CO should wait at least 200 ms before sending the digits.
Trunk Requirement.
Individual trunks must be enabled for DID or DNIS
(see FF1 8# 4# 6# Trunk# 2#).
Simultaneous Ringing.
If Multiple DID/DNIS is enabled, all extensions assigned the same DID/DNIS number will ring for the incoming DID/DNIS call. If you later disable Multiple DID/DNIS, only the extension at the lowest-numbered port will ring for the DID/DNIS call.
Call Forwarding Interaction.
If Multiple DID/DNIS is enabled, and the DID/DNIS extensions are programmed to call-forward to different extensions, the simultaneous ringing will also apply to the call-forward destination extensions. In other words, all call-forward paths will be followed simultaneously for the same DID/DNIS call, until someone picks it up. If you later disable Multiple DID/DNIS, only the call-forwarding path assigned to the extension at the lowest-numbered port will be followed.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-41
Chapter 1. System Programming (FF1) Section 400-Programming

Page Duration

Software Version: CPC-AII (all versions) and CPC-B Version 3.1 or higher Address: FF1 2# 1# 33# (0 or 1)#
Description
Programming
This address determines whether the DBS system will a utomatically c lose the paging circuit 60 seconds after a page is initiated. By default, the paging circuit is left open indefinitely, until the paging person closes the circuit by hanging up.
FF1 2# 1# 33# (0 or 1)#
0=The page circuit remains open indefinitely.
1=The paging circuit remains open for 60 seconds before the system closes it.
Page 1-42 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

SLT DISA Ring Pattern

Software Version: CPC-AII (all versions) and CPC-B Version 3.1 or higher Address: FF1 2# 1# 34# (0 or 1)#
Description
Use this address to specify a distinctive ring pattern for DISA calls on SLT phones, or follow the Analog Transfer Ring Pattern setting. By default, the pattern is 1 second on / 3 seconds off.
Programming
Related Programming
Analog Transfer Ring Pattern
FF1 2# 1# 34# (0 or 1)#
0=1 second on / 3 seconds off.
1=Same as the Analog Transfer Ring Pattern.
(CPC-AII and CPC-B)
: FF1 2# 1# 31# (0-6)#
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-43
Chapter 1. System Programming (FF1) Section 400-Programming

AEC Disconnect Signal Duration

Software Version: CPC-AII (all versions) and CPC-B Version 5.0 or higher Address: FF1 2# 1# 35# (0-15)#
Description
Use this address to set the duration of a positive disconnect signal sent from analog extension ports (VB-43621A version of the AEC card). Sending this signal allows quick disconnect from third-party voice mail systems. By default, no disconnect signal is sent.
This address applies to CPC-AII and CPC-B. The AEC Disconnect Signal Duration address for CPC-A (Version 3.3 or higher) is FF1 2# 1# 23# (0-
15)#. The sending of the AEC disconnect signal can be enabled or disabled on
individual extensions using FF3 (ExtPort)# 46#.
Programming
FF1 2# 1# 35# (0-15)#
Table 1-4. AEC Disconnect Signal Duration values
AEC Disconnect Signal Duration setting
Default: (see table below)
0 (no signal sent)
Setting Value
0 No disconnect signal sent
1 100 ms 2 200 ms 3 300 ms 4 400 ms 5 500 ms 6 600 ms 7 700 ms 8 800 ms
9 900 ms 10 1 second 11 1.5 seconds 12 2 seconds 13 2.5 seconds
Page 1-44 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)
Setting Value
14 3 seconds 15 3.5 seconds
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-45
Chapter 1. System Programming (FF1) Section 400-Programming

DID/DNIS to a Voice Mailbox

Software Version: CPC-B Version 6.0 or higher Address: FF1 2# 1# 36# (0, 1 or 2)#
Description
Programming
This address determines whether (and how many) final digits of a DID/DNIS phone number are transmitted to Voice Mail, in cases where the DID/DNIS trunk is assigned to ring directly to Voice Mail (not to a DBS extension phone). This address allows DID/DNIS calls to be routed to a Voice Mailbox system that is not connected to a physical extension.
To implement this feature, assign the DID/DNIS trunks to ring at the Voice Mail system (using FF4 ring assignment addresses). Once Voice Mail answers, the DBS sends a DID/DNIS Answer Code that signals the Voice Mail system to open the appropriate mailbox, plus the final DID/DNIS digits (if any) specified in this address.
FF1 2# 1# 36# (0, 1 or 2)#
0=No DID/DNIS digits are transmitted (only the Answer Code).
1=Answer Code, then final 4 DID/DNIS digits are transmitted. 2=Answer Code, then final 3 DID/DNIS digits are transmitted.
Related Programming
DID/DNIS Answer Code: FF1 2# 1# 37# (NNNNNN)# DID/DNIS (enabling trunks for): FF1 8# 4# 6# (Trunk)# 2# (0-2)# Inbound DID Dial Numbers: FF1 8# 3# (0000-9999)# (100-699)# DNIS Number Setting: FF1 8# 4# 7# (0000-9999)# (10-69 or 100-699)# Terminal Type: FF3 (ExtPort)# 2# (Type)# Ringing Assignments (trunks to extensions): FF4 addresses
Notes
DID/DNIS Digit Transmission.
that are assigned as Voice Mail.
Voice Mail Ports and Hunt Groups.
specific Voice Mail port or a Voice Mail hunt group.
Second Hunt Group.
programmed to transfer calls to a second hunt group, the DID/DNIS call will not be transferred to the second hunt group.
The DID/DNIS digits are sent only to ports
The DID/DNIS digits can be sent to a
If the DID/DNIS call rings into a hunt group that is
Page 1-46 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)
Third-Party Voice Mail.
This feature can be used with Panasonic’s Voice Mail system or with third-party Voice Mail systems. If the feature is used with third-party Voice Mail systems, the Voice Mail can be connected through analog extension ports or OPX ports.
Call Forward ID Code for DID/DNIS Calls To An Extension.
If a DID/ DNIS call is assigned to ring an extension, and the extension is programmed to forward to Voice Mail, only the Call Forward ID Code will be transmitted to Voice Mail (the DID/DNIS digits will not).
DID/DNIS Data Transmission.
The DID/DNIS digits are transmitted over
the API link using the existing API key code packet.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-47
Chapter 1. System Programming (FF1) Section 400-Programming

DID/DNIS Answer Code

Software Version: CPC-B Version 6.0 or higher Address: FF1 2# 1# 37# (Code)#
Description
Use this address to specify a DID/DNIS Answer Code. The Answer Code is used for routing DID/DNIS calls to a Voice Mailbox system that is not connected to a physical extension.
To implement this feature, assign DID/DNIS trunks to ring directly to the Voice Mail system using FF4 ring assignment addresses. Once Voice Mail answers, the DBS sends the DID/DNIS Answer Code, which signals the Voice Mail system to open the appropriate mailbox.
Programming
Related Programming
FF1 2# 1# 37# (NNNNNN)#
DID/DNIS Answer Code
Valid Entries: 0-9, *, #, or REDIAL (pause)
(up to 6 characters)
Notes
DID/DNIS to a Voice Mailbox: FF1 2# 1# 36# (0, 1 or 2)# DID/DNIS (enabling trunks for): FF1 8# 4# 6# (Trunk)# 2# (0-2)# Inbound DID Dial Numbers: FF1 8# 3# (0000-9999)# (100-699)# DNIS Number Setting: FF1 8# 4# 7# (0000-9999)# (10-69 or 100-699)# Terminal Type: FF3 (ExtPort)# 2# (Type)# Ringing Assignments (trunks to extensions): FF4 addresses
Assigning the DID/DNIS Answer Code When Not In Programming Mode.
The DID/DNIS Answer Code may be entered from an Attendant phone, or from a key phone where the programming access code has been entered. Press up to 6 characters, including 0-9, *, #, or REDIAL (for “pause”).
DID/DNIS Digit Transmission.
that are assigned as Voice Mail.
PROG #95 NNNNNN HOLD
-- where
The DID/DNIS digits are sent only to ports
“NNNNNN”
is the Answer Code of
Page 1-48 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)
Voice Mail Ports and Hunt Groups.
The DID/DNIS digits can be sent to a
specific Voice Mail port or a Voice Mail hunt group.
Second Hunt Group.
If the DID/DNIS call rings into a hunt group that is programmed to transfer calls to a second hunt group, the DID/DNIS call will not be transferred to the second hunt group.
Third-Party Voice Mail.
This feature can be used with Panasonic’s Voice Mail system or with third-party Voice Mail systems. If the feature is used with third-party Voice Mail systems, the Voice Mail can be connected through analog extension ports or OPX ports.
Call Forward ID Code for DID/DNIS Calls To An Extension.
If a DID/ DNIS call is assigned to ring an extension, and the extension is programmed to forward to Voice Mail, only the Call Forward ID Code will be transmitted to Voice Mail (the DID/DNIS digits will not).
DID/DNIS Data Transmission.
The DID/DNIS digits are transmitted over
the API link using the existing API key code packet.
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-49
Chapter 1. System Programming (FF1) Section 400-Programming

LCD Timer for Caller ID

Software Version: CPC-AII and CPC-B, Version 6.1 or higher Address: FF1 2# 1# 38# (0, 1 or 2)#
Description
The LCD Timer determines how long the DBS waits before displaying call duration timing on the phone’s LCD. This Timer allows Caller ID information (if available) to appear before the call duration timing is displayed.
For example, if the LCD Timer is set to 5 seconds (default), call duration timing will start displaying on the phone’s LCD 5 seconds after an outgoing number is dialed, or 5 seconds after an incoming call is answered.
Programming
Related Programming
Call Duration Display: FF1 2# 1# 1# (0 or 1)#
FF1 2# 1# 38# (0, 1 or 2)#
0=5 seconds
1=16 seconds 2=30 seconds
SMDR Display Start Timer for CO Calls: FF1 2# 1# 2# (0, 1 or 2)#
Notes
Page 1-50 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
SMDR Interaction
The system begins the actual SMDR recording of the call according to the SMDR Start Timer address (FF1 2# 1# 2#). In order for call duration to be displayed, the LCD Timer has to means the LCD Timer setting must be equal to or greater than the SMDR Start Timer.
Caller ID Interaction.
time that Caller ID information is displayed before the LCD changes to call duration timing. However, the T imer also controls when call duration display begins for
all
. The LCD Timer only affects the
expire
The LCD Timer setting will be the actual length of
types of trunk calls, not just Caller ID calls.
after the SMDR Start T imer - - which
display
of call duration.
Section 400-Programming Chapter 1. System Programming (FF1)

Internal Hold Tone

Software Version: CPC-AII and CPC-B, Version 7.0 or higher Address: FF1 2# 1# 39# (0 or 1)#
Description
Programming
Notes
Use this address to enable or disable Internal Hold Tone, which is a double­beep heard every 7 seconds by a caller on hold.
FF1 2# 1# 39# (0 or 1)#
0=Disabled (no Internal Hold Tone)
1=Enabled (Internal Hold Tone heard)
MOH Override.
(Music-On-Hold) sound source installed.
Internal Hold Tone (if enabled) will override any MOH
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-51
Chapter 1. System Programming (FF1) Section 400-Programming

Door Opener Access Code Required

Software Version: CPC-AII and CPC-B, Version 7.0 or higher Address: FF1 2# 1# 40# (0 or 1)#
Description
This address determines whether a Door Opener Access Code must be entered on an extension to unlock the Door Box. This applies to Door Boxes connected to digital extension ports (not trunk ports).
Programming
Related Programming
Door Phone Extensions: FF1 2# 9# (1-4)# 1# (ExtPort)# Door Opener Access Code: FF1 2# 9# (1-4)# 3# (0000-9999)#
Notes
Unlocking the Door Box During a Door Phone Call.
“1” (Required), an extension user answering a door phone call would unlock the door by pressing “0” (Not required), the extension user answering the door phone call would simply press
#3*
FF1 2# 1# 40# (0 or 1)#
#3 NNNN *
.
0=Not required
1=Required
If this address is set to
(where NNNN=Access Code). If set to
Unlocking the Door Box From Another Extension.
unlocked from any other extension not engaged in a door phone call. If this address is set to “1” (Required), dial extension (where XXX=Door Box extension number, and NNNN=Access Code) to unlock the door. If set to “0” (Not required), dial
XXX *
Hardware Requirement.
phone devices connected to the VB-43711 Door Phone Adaptor, which connects the Door Box to a digital extension port. Door Boxes connected to trunk ports use another Adaptor (VB-43701), and do not utilize the Access Code.
Page 1-52 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
to unlock the door.
The Door Opener Access Code applies to door
ON/OFF #3 XXX NNNN *
The door can also be
on any
ON/OFF #3
Section 400-Programming Chapter 1. System Programming (FF1)

API Port Type

Software Version: CPC-AII and CPC-B, Version 7.0 or higher Address: FF1 2# 1# (41 or 42)# 1# (0 or 1)#
Description
Use this address to configure the appropriate API port for TSAPI protocol. Only one API port should be configured for TSAPI.
Programming
Related Programming
API Baud Rate: FF1 2# 1# (41 or 42)# 2# (0 or 1)#
FF1 2# 1# (41 or 42)# 1# (0 or 1)#
API Port Number: 41=API Port 1 42=API Port 2
Port Type:
0=Standard API protocol
1=TSAPI protocol
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-53
Chapter 1. System Programming (FF1) Section 400-Programming

API Baud Rate

Software Version: CPC-AII and CPC-B, Version 7.0 or higher Address: FF1 2# 1# (41 or 42)# 2# (0 or 1)#
Description
The baud rate for the TSAPI port can be set to either 9600 or 19200 bps.
Programming
Related Programming
API Port Type: FF1 2# 1# (41 or 42)# 1# (0 or 1)#
Notes
Using Both API Ports.
must be set to 9600 bps.
FF1 2# 1# (41 or 42)# 2# (0 or 1)#
API Port Number: 41=API Port 1 42=API Port 2
If both API ports are being used, both baud rates
Baud Rate:
0=9600 bps
1=19200 bps
Page 1-54 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Section 400-Programming Chapter 1. System Programming (FF1)

Serial Port Parameters (TTY Settings)

Parity Check

Software Version: All Versions Address: FF1 2# 2# 1# (0 or 1)#
Description
This address determines whether the DBS checks parity over serial port CN6. By default, parity checking is turned on.
If parity checking is activated, select the parity count -- “Even” or “Odd” -- in FF1 2# 2# 2#.
Serial Port CN6 is normally used for SMDR.
Programming
Related Programming
Odd/Even Parity: FF1 2# 2# 2# (0 or 1)#
FF1 2# 2# 1# (0 or 1)#
0=Turns off the parity check.
1=Turns on the parity check.
Notes
DBS-2.3/9.2-400 DBS Manual - Revised April 2000 Page 1-55
Checking Communications Parameters.
value, be sure to check all Serial Port addresses -- FF1 2# 2# 1# thru 9# -- to make sure they are set properly.
If you later change this address
Chapter 1. System Programming (FF1) Section 400-Programming

Odd/Even Parity

Software Version: All Versions Address: FF1 2# 2# 2# (0 or 1)#
Description
Programming
Notes
If parity checking for Serial Port CN6 was activated in FF1 2# 2# 1#, this address (Odd/Even Parity) determines whether the check is based on an even count or an odd count. By default, the parity count is even.
FF1 2# 2# 2# (0 or 1)#
0=Odd parity.
1=Even parity.
Checking Communications Parameters.
value, be sure to check all Serial Port addresses -- FF1 2# 2# 1# thru 9# -- to make sure they are set properly.
If you later change this address
Page 1-56 DBS Manual - Revised April 2000 DBS-2.3/9.2-400
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
