Before attempting to operate the DBS 576HD, please read these
instructions completely.
DBS 576 - Version 5.0
Issued September 2001
he contents of this document are subject to change without notice and do not constitute a commitment on
T
the part of Panasonic Telecommunication Systems Company (PTSC). Every effort has been made to ensure
the accuracy of this document. However, due to ongoing product improvements and revisions, Panasonic
cannot guarantee the accuracy of printed material after the date of publication nor can it accept
responsibility for errors or omissions. Panasonic will update and revise this document as needed.
The software and hardware described in this document may be used or copied only in accordance with the
terms of the license pertaining to said software or hardware.
Reproduction, publication, or duplication of this manual, or any part thereof, in any manner, mechanically
electronically, or photographically is prohibited without permission of Panasonic Telecommunication
Systems Company (PTSC).
Copyright 2001 by Panasonic Telecommunication Systems Company (PTSC)
If you are using this manual for a single System, make note of its software version in the following
table. This information may be referenced by technicians or owners of the System.
Software version information for systems shipped with this document
CPC Model: Software Version:
Organization
This manual contains detailed descriptions of features. The feature descriptions are organized
according to the following categories:
Feature CategoriesDescription
System Features
User MaintenanceUser Maintenance Features are used by the end user
Key Telephone FeaturesKey Telephone Features are available to System Key
Digital Single-Line Telephone (DSLT) Features
Single Line Telephone
(SLT) Features
System Features are either available on a systemwide basis or aid in the overall administration of the
System.
to maintain the System. These items include setting
time and date, Personal Speed Dial (PSD) numbers
and names, System Speed Dial (SSD) numbers and
names, extension names, Verified ID codes, Call
Forward ID codes for Voice Mail, Message Key ID
codes, Mode schedule, Special Day mode, Exception Day mode, and Day of Week mode.
phones. System Key phones are proprietary digital
sets that provide feature access through a combination of feature keys and access codes.
DSLT Features are available to Digital Single-Line
Telephones. DSLTs provide digital audio quality and
limited feature key access in a single-line set.
SLT Features are available to industry-standard 2500
sets. Since SLTs are not equipped with feature keys,
most features are accessed by using the dialpad and/
or the switchhook.
Purpose
The purpose of this manual is to provide an overview of feature operations and requirements. Where
applicable, the following types of information are provided for each feature:
Types of informationPurpose
DescriptionProvides an overview of how the feature works and,
in some cases, what it is typically used for
OperationIncludes step-by-step instructions on how to use the
feature
Hardware RequirementsLists any special hardware that is required to use the
feature
576-50-700DBS 576HD (USA) issued September 20011-1
Chapter 7. SLT FeaturesSection 700 - Operation
Related ProgrammingLists the programming subsystems associated with
the feature
ConsiderationsProvides details on feature interactions and limita-
tions
Abbreviation List
ACDAutomatic Call Distributor
ARSAutomatic Route Selection
BGMBackground Music
BLFBusy Lamp Field
BRIBasic Rate Interface
DBSDigital Business System
CFWD Call Forward
COSClass of Service
CTAPI Computer Telephony Application Programming Interface
CTIComputer Telephony Integration
DDIDirect Dial Inward
DIDDirect Inward Dial
DILDirect In Line
DISADirect Inward System Access
DLDirect Line
DNDirectory Number
DNDDo-Not-Disturb
DNISDialed Number Identification Service
DPDial Pulse
DSLT Digital Single Line Telephone
DSSDirect Station Selector
DSUDigital Service Unit
DTMF Dual Tone Multifrequency
FFFlexible Function
HDHigh Density (DBS 576HD)
LCDLiquid Crystal Display
LCRLeast Cost Routing
MCOMultiple CO (Pooled Trunk Access)
MISManagement Information System
MOHMusic On Hold
PNPDNPhantom Non-Primary Directory Number
PRI Primary Rate Interface
PSDPersonal Speed Dial
SLT Single Line Telephone
SMDR Station Message Detail Recorder
SPIService Provider Interface
SSD System Speed Dial
TAPITelephony Application Programming Interface
TRSToll Restriction Service
1-2DBS 576HD (USA) issued September 2001576-50-700
Chapter 2. List of Features
This chapter contains the following tables which list the features available with the system:
TablePage
System Features
Maintenance Features
Extension Features
2-2
2-3
2-4
576-50-700DBS 576HD (USA) issued September 20012-1
Chapter 7. SLT FeaturesSection 700 - Operation
Table 1.System Features
TopicPage
AEC Disconnect
Attendant Groups
Automatic Call Distributor
Automatic Route Selection
Automatic Trunk to Trunk Transfer
Background Music/MOH Separation
Battery Backup
Call Progress Tones
Caller ID
Caller ID Alpha Tagging
Centrex/PBX Compatibility
Class of Service
CO Ringing Types
CO Trunk Interface
Computer Telephony Integration Capability
Data Security
Daylight Saving Time
Day/Night System Mode
Digital Pad
Direct Inward System Access
Distinctive Ringing
Door Box
Extension Interface
Flexible Numbering Plan
Free Slot
Hunting Groups
Internal Hold Tone
LAN TAPI
MCO Tenant Group
Music-on-Hold
Music-on-Hold
Name Assignments
Network BLF
Network Facilities
Non-Blocking Architecture
3-3
3-4
3-5
3-6
3-7
3-7
3-8
3-8
3-9
3-9
3-10
3-11
3-16
3-19
3-21
3-22
3-22
3-23
3-27
3-28
3-29
3-29
3-30
3-32
3-33
3-33
3-35
3-36
3-36
3-37
3-37
3-37
3-44
3-44
3-47
2-2DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
TopicPage
Power On Maintenance
Programming Devices
QSIG ISDN Lines
Ringing Modes
System Speed Dial TRS Override
Station Message Detail Recording
T1 Line
Toll Restriction Service
Trunk Access Groups
Vir tual Port
Voice Mail
3-47
3-47
3-48
3-49
3-52
3-52
3-55
3-56
3-56
3-57
3-58
Table 2.Maintenance Features
TopicPage
Set Absence Messages
Set Call Forward Busy Destination Extension
Set Call Forward ID Codes for Voice Mail
Set Call Forward No Answer Destination Extension
Set Caller ID Logging Extensions
Set Day of Week Mode
Set Exception Day Mode
Set Extension Names
Set Message Key ID Code
Set Mode Schedule
Set Personal Speed Dial Names
Set Personal Speed Dial Numbers
Set Send Text Messages
Set Special Day Mode
Set System Date/Time/Day
Set System Speed Dial Names
Set System Speed Dial Numbers
Set Text Message Replies
Set Verified Account Codes
Set Walking TRS Codes
4-3
4-5
4-6
4-7
4-8
4-9
4-11
4-13
4-14
4-15
4-17
4-22
4-23
4-24
4-31
4-34
4-35
4-37
4-38
4-40
576-50-700DBS 576HD (USA) issued September 20012-3
Chapter 7. SLT FeaturesSection 700 - Operation
Table 3.Extension Features
TopicPage
Absence Message
Account Codes
Attendant Group Calls
Auto Repeat Dial
Background Music
Busy Override
Callback Request
Call Forwarding
Call Hold
Call Hold
Call Pickup
Call Transfer
Caller ID Call Log
Camp-on (Call Waiting)
Conference Calls
Directory Numbers
Display Information
Do-Not-Disturb
DP to DTMF Signal Conversion
DSS/72 Console
EM/24 Console
Flash
Flexible Function Keys
Handsfree Answerback
Handsfree Operation
Headset Operation
Hot Dial Pad
Hot Line
Intercom Calling
Last Number Redial
Line Appearances
Message Key
Message Waiting/Callback
Mute Function
Offhook Monitor
5-4
5-6
5-9
5-9
5-10
5-11
5-12
5-14
5-18
5-21
5-23
5-27
5-30
5-31
5-34
5-35
5-39
5-42
5-43
5-44
5-44
5-45
5-45
5-52
5-52
5-53
5-54
5-54
5-55
5-56
5-57
5-60
5-61
5-63
5-63
2-4DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
TopicPage
Offhook Signaling
Offhook Voice Announce
One-Touch Keys
Onhook Dialing
Paging
Reset Call
Ringing Line Preference
Room Monitoring
Silent Monitor
Speed Dialing
Station Lockout
Timed Reminder Call
Trunk Access
Trunk Queuing
Universal Night Answer to Page
Var ia bl e M od e
Voice Recognition
Vo l u me Co n tr o l
Walking TRS Class of Service
Zip Mode
5-64
5-65
5-67
5-69
5-70
5-72
5-72
5-73
5-75
5-77
5-87
5-89
5-90
5-93
5-94
5-95
5-97
5-98
5-99
5-100
576-50-700DBS 576HD (USA) issued September 20012-5
Chapter 7. SLT FeaturesSection 700 - Operation
This page intentionally left blank.
2-6DBS 576HD (USA) issued September 2001576-50-700
Chapter 3. System Features
System Features are either available on a system-wide basis or aid in the overall administration of the
System.
This chapter contains detailed descriptions of the following System Features:
TopicPage
AEC Disconnect3-3
Attendant Groups3-4
Automatic Call Distributor3-5
Automatic Route Selection3-6
Automatic Trunk to Trunk Transfer3-7
Background Music/MOH Separation3-7
Battery Backup3-8
Call Progress Tones3-8
Caller ID3-9
Caller ID Alpha Tagging 3-9
Centrex/PBX Compatibility3-10
Class of Service3-11
Class of Service - Trunk/Tie3-11
Class of Service - Ext/Ext Restriction3-12
Class of Service - Extension Feature3-12
Class of Service - T1 Trunk Ring Back Service Tone3-14
Class of Service - Trunk to Trunk Restriction3-14
Class of Service - Extension (Station) Timers3-15
CO Ringing Types3-16
DID Ringing3-16
DIL Ringing3-17
DIL Delayed Incoming Ring Enhancement3-18
DISA Ringing3-19
Multiple Ringing3-19
CO Trunk Interface3-19
CO Trunk Interface - DID3-20
CO Trunk Interface - Ground Start3-20
CO Trunk Interface - ISDN BRI3-20
CO Trunk Interface - ISDN-PRI3-21
CO Trunk Interface - Loop Start3-21
Computer Telephony Integration Capability3-21
Data Security3-22
576-50-700DBS 576HD (USA) issued September 20013-1
Chapter 7. SLT FeaturesSection 700 - Operation
TopicPage
Daylight Saving Time3-22
Day/Night System Mode3-23
Manual Day/Night Mode3-24
Automatic Day/Night Mode3-26
Digital Pad3-27
Direct Inward System Access3-28
Distinctive Ringing3-29
Door Box3-29
Door Box Sensor3-30
Extension Interface3-30
Digital Key Telephones3-30
Analog Device Capability3-31
DP/DTMF SLTs3-31
ISDN/BRI S-Point Interface3-32
ISDN/PRI S-Point Interface3-32
Flexible Numbering Plan3-32
Free Slot3-33
Hunting Groups3-33
Internal Hold Tone3-35
LAN TAPI3-36
MCO Tenant Group3-36
Music-on-Hold3-37
Name Assignments3-37
Extension Name Assignments3-38
Speed Dial Name Assignments3-42
Network BLF3-44
Network Facilities3-44
Network Attendant Reversion3-45
Network Call Routing3-45
Network Call Transfer3-45
Network Centralized Attendant3-45
Network Centralized Voice Mail3-45
Network Extension Calling3-46
Network Flash Transfer3-46
Network Hold3-46
Network Paging3-46
Network Transfer Recall3-46
3-2DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
TopicPage
Tandem Connection3-46
Non-Blocking Architecture3-47
Power On Maintenance3-47
Programming Devices3-47
DBS 576 Manager3-48
QSIG ISDN Lines3-48
Ringing Modes3-49
Day 1/ Day 2/Night Ringing3-49
Day 1/ Day 2/Night Delayed Ringing3-50
DID Day/Night Ringing3-50
DID Day/Night Busy/Delayed Ringing3-50
Busy Lamp Field Ringing3-51
Busy Lamp Field Delayed Ringing3-51
Slide Ringing3-51
Alarm Ringing3-52
System Speed Dial TRS Override3-52
Station Message Detail Recording3-52
T1 Line3-55
Trunk Access Groups3-56
Virtual Port3-57
Virtual Port used for Floating Hold3-58
Virtual Port used for Virtual Extension3-57
Voice Mail3-58
PanaVOICE -- Panasonic’s Digital Voice Mail System3-58
Third-Party Voice Mail Support3-59
AEC Disconnect
Description
This feature allows the System to send a disconnect signal of 1 second to an analog device indicating
that the calling party has hung up (terminated the call). This feature is useful with a Third-party Voice
Mail or an Answering Machine. By default this feature is disabled.
Hardware Requirements
•AEC port
576-50-700DBS 576HD (USA) issued September 20013-3
Chapter 7. SLT FeaturesSection 700 - Operation
Related Programming
•FF3-0: Loop Disconnect Signal
Considerations
•The 1 second time duration of the disconnect signal is fixed. (It cannot be changed.)
Attendant Groups
Description
An attendant phone is often used as a central answering point for other extensions. In addition,
attendant phones frequently have special capabilities for monitoring and programming extensions.
You can reach the assigned attendant group by dialing the feature access code for Attendant Calls
(usually 0). If an attendant phone is available but does not answer within a set time, the call will move
to the next available attendant phone. If all members of the attendant group are busy for a specified
time, the call can be forwarded to other extensions or another hunt group. The system allows up to 20
extensions to be included in an attendant group.
Hardware Requirements
•N/A
Related Programming
•FF5-0-01: Attendant Hunt Pilot Number
•FF5-0-02: Day 1 Attendant Hunting
•FF5-0-03: Day 2 Attendant Hunting
•FF5-0-03: Night Attendant Hunt
•FF2: Ring Type
Considerations
•The System allows one attendant group for each system mode (Day 1, Day 2, and Night).
•An attendant group can contain both real extensions and virtual extensions. If virtual, several
phones can be made to ring at the same time.
•Attendant groups can use only Pilot Terminal Hunt Group or Pilot Distributed Hunt Group. For
more information, see “Hunting Groups” on page 3-33.
•The pilot number for an attendant group is flexible (i.e., any extension number can be designated
as the pilot [not a real extension]).
•If a member of the attendant group has Do-Not-Disturb (DND) or Call Forwarding - All set, that
phone is temporarily removed from the attendant group.
•If a member of the attendant group has Call Forwarding - Busy set and the extension is busy, the
call goes to the next phone in the attendant group.
•If all members are busy for the duration of the busy queuing timer, the call can be forwarded to
another hunt group or another extension.
•Attendant groups support the following call types:
• Direct Inward Dialing (DID) / Dialed Number Identification Service (DNIS) / Direct
Dial Inward (DDI)
• Direct Inward System Access (DISA)
3-4DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
• Extension calls
• Private network attendant calls
• Call reversion
• Call forwarded to Attendant Hunt Group
Automatic Call Distributor
Description
The System provides an optional Automatic Call Distributor (ACD) for efficient presentation,
handling, and management of incoming calls to one or more groups of specialized users.
This optional Built-in ACD is contained on a single circuit card that is installed in the System. This
“built-in” capability eliminates the need for custom wiring and other installation.
Each specialized user is known as an ACD agent. Each agent position is equipped with a large display
telephone (VB-44225) that provides Liquid Crystal Display (LCD) messages to assist the agent in
handling calls.
The Built-in ACD provides:
•Up to 3 agent groups (ACD Version 3.0 and higher)
•Up to 2 agent groups (ACD Version below 3.0)
•Up to 32 agent IDs per group
•Up to 64 agent IDs per system (ACD Version 2.0 and higher)
•Up to 32 agents
•Up to 6 supervisor IDs per system (ACD Version 3.0 and higher)
•Up to 2 supervisor IDs per system (ACD Version below 3.0)
•Up to 4 voice ports per group
•Up to 4 voice ports per system
•1 Music-On-Hold (MOH) source (Main System MOH source)
•1 Management Information System (MIS) Monitor Port (RS-232C)
•Abandoned Call Report counter available with MIS reports (This is not the same as the
Abandoned Call Timer added to the Station Message Detail Recorder [SMDR] reports.)
•2-week memory for MIS reports
•Up to 6 recorded messages (flexible length, max. 96 sec. per system) (ACD Version 3.0 and
higher)
•In Version 3.5 and higher, the Silent Monitor feature has been added. This feature allows an
ACD supervisor to monitor a call between an ACD agent and a caller without the knowledge
of either party. For more information, See “Silent Monitor” on page 5-75., Section 400 Programming, and Section 520 - Built-In ACD Reference Manual.
•In addition to MOH, ACD Version 3.5 provides up to eight analog extension ports that can be
connected to a recorded announcement device. See Section 520 - Built-In ACD Reference Manual.
•Up to 6 recorded messages (max. 14 sec. per message) (ACD Version below 3.0)
•Zip Tone which automatically answers calls when an agent is using the Headset mode (CPC
Version 2.5 and higher)
576-50-700DBS 576HD (USA) issued September 20013-5
Chapter 7. SLT FeaturesSection 700 - Operation
•Wrap Mode which allows an agent to complete any paperwork before becoming available to
take another call.
Hardware Requirements
•See Section 520 - Built-In ACD Reference Manual.
Related Programming
•See Section 520 - Built-In ACD Reference Manual.
Considerations
•For more information, see Section 520 - Built-In ACD Reference Manual.
Automatic Route Selection
Description
When Automatic Route Selection (ARS) is enabled, the system follows a preselected route for calls.
Usually the selected routing is the least cost route.
ARS works in conjunction with Toll Restriction Service (TRS). Calls can be denied based on the
programmed TRS level for the originating party. (For more information, see “Ringing Modes” on
page 3-49.)
•Three levels of ARS checking are available based on the dialed number following the ARS
access code:
• Direct Route Selection: The simplest form of ARS routing that upon ARS entry
(enter 9) directly selects the trunk group and any dialed number modification.
• Route List Selection: A more complex routing that includes up to 5 alternative
levels of route selection and includes TRS level checking.
• Time List Selection: The most complex routing that determines the appropriate
route list based upon the day and time.
•Forced ARS is available on an Extension Class of Service (COS) basis.
•A special day list provides tailored ARS routing for up to 20 holidays, vacation days, etc.
•Automatic modification of dialed numbers is available. This includes deleting up to 24 prefix
digits and adding up to a 10-digit prefix and a 10-digit suffix. The modification of dialed
numbers can include pauses, Dual Tone Multifrequency (DTMF) conversion, itemized code
(extension number) and an authorization code. (Itemized code and authorization are not used
in some areas.)
•Up to 8 authorization codes are available.
•For more information on ARS/TRS, see Appendix A “ARS and TRS Operation” on page -1.
Hardware Requirements
•N/A
Related Programming
•N/A
Considerations
•N/A
3-6DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
Automatic Trunk to Trunk Transfer
Description
The System can be set to automatically transfer trunk calls out to another trunk without requiring the
call to be answered internally. This transfer may be either trunk based or extension based (i.e., call
forward outside).
Hardware Requirements
•N/A
Related Programming
•N/A
Considerations
•N/A
Background Music/MOH Separation
Description
Separate inputs are provided for Background Music (BGM)and Music-on-Hold (MOH). This allows
one music or sound source to be used for background music and another music or sound source to be
used for music on hold.
A typical advantage of this is playing a pre-recorded promotional tape to held parties (since many
may be customers) while providing a selected background music for use in the office.
Note:
CPC-HS has only one input that is used for both BGM and MOH.
Hardware Requirements
•Both Background Music and Music on Hold (if using external MOH) require a sound source.
Related Programming
•N/A
Considerations
•N/A
576-50-700DBS 576HD (USA) issued September 20013-7
Chapter 7. SLT FeaturesSection 700 - Operation
Battery Backup
Description
When backup batteries are installed, the System will continue to operate in the event of a power
failure. If using Battery Backup, backup batteries must be installed in each cabinet.
A fully loaded System will operate at least 15 minutes with the DBS 576HD.
Hardware Requirements
•Back-up battery unit (VB-44026)
Related Programming
•N/A
Considerations
•Any device connected to the System but that does not derive its power from the System must
have a backup power source to operate. These devices include any System Message Detail
Recording (SMDR) printer (or recorder), fax machine, answering machine, modem, cordless
telephone, etc.
Call Progress Tones
Description
The System supplies a full array of call progress tones. These tones provide audible indications of the
status of calls and include dial tone, busy tone, ringback tone, error tone, confirmation tone, and
splash tone. The complete specification for these tones may be found in Section 300 - Installation.
In addition to call progress tones, Direct Station Select (DSS) LEDs and the display provide
additional indication of the status of calls.
Hardware Requirements
•N/A
Related Programming
•N/A
Considerations
•N/A
3-8DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
Caller ID
Description
A properly equipped system supports Caller ID, a service offered by the network telephone service
provider. The CO sends calling number information to the system after the first ring. Users with
display telephones can see Caller ID information as incoming calls ring at their extension. They can
also access previous calls via the Caller ID Call Log feature. The Caller ID number is recorded in
SMDR.
With Version 5.0, the caller name (if available) can be displayed for a calls received from an
ISDN PRI line (ISDN / PRI NI II standard only).
Hardware Requirements
•Loop-start trunk card (8) (VB-44510) with Caller ID circuit card (8) (VB-44513), Loop-start
trunk card (4) (VB-44514) with Caller ID circuit card (4) (VB-44515), ISDN (PRI = VB-44540,
BRI = VB-44530).
Related Programming
•FF2-0: Caller ID
•FF2-0: Caller ID Ring Control
•FF3-0: Call Duration Display
•FF1-0-01: Alpha Tagging (Name/No. Display)
•ISDN (PRI/BRI - T Point) can get calling party information.
•Caller ID service must be ordered from the local telephone operating company or the
interexchange carrier.
•Caller ID data is usually sent between the first and the second rings of the incoming trunk call.
The trunk may be programmed to immediately ring at the station or wait until after the Caller ID
digits are received before ringing at the station. If the trunk is programmed to ring immediately,
the Caller ID digits will not display until after they are received and processed.
•Caller ID numbers may be denied from being sent for some callers (private). Some long distance
carriers may not provide Caller ID data (out of area).
•Prior to Version 3.5, Caller ID supported only the number format. Version 3.5 and higher
supports selection of the number or
•In Version 3.5, Caller ID displays the highest ringing priority call (call queued to ring at the target extension immediately after the present call terminates).
name.
Caller ID Alpha Tagging
Description
If the received Caller ID phone number matches any number in the System Speed Dials (SSD000SSD199), then the associated System Speed Dial name can be displayed as the Caller ID information.
Alternatively, the DID name may be displayed instead.
In Version 3.5 and higher, Caller ID information will be shown on the second
when an incoming call rings a display phone with a conversation already in progress. Second
incoming calls include extension Camp-on, extension Call Wait, queued DIL, both Appearance and
non-Appearance calls (CO, MCO, virtual or DN, recall, BLF).
576-50-700DBS 576HD (USA) issued September 20013-9
line of the LCD display
Chapter 7. SLT FeaturesSection 700 - Operation
Hardware Requirements
•ISDN (PRI = VB-44540, BRI = VB-44530)
•FF1-0-01: System (Alpha Tagging)
Considerations
•The system may be set to display Caller ID in one of two priorities as follows:
Priority Choice 1
• CID name (future feature)
• Alpha tagging if matched
• DID name
Priority Choice 2
• DID name
• CID name (future feature)
• Alpha tagging if matched
•Currently Caller ID only supports the single format (number only). Multiple format (number and
name) is not currently available but is planned as a future feature.
•Caller ID Call Logging only shows the CID number.
Centrex/PBX Compatibility
Description
Centrex/PBX Compatibility allows the System to be connected behind centrex or PBX lines.
The System supports up to 6 access codes for dialing centrex or a PBX. These access codes allow the
System, System Message Detail Recording (SMDR) output to exclude the number dialed to reach a
centrex or PBX line.
When connected behind a PBX or Centrex, Toll Restriction Service (TRS) can be used to restrict
calls.
The System also supports transmission of a flash signal over the centrex or PBX link.
Hardware Requirements
•N/A
Related Programming
•N/A
Considerations
•N/A
3-10DBS 576HD (USA) issued September 2001576-50-700
Section 700 - OperationChapter 7. SLT Features
Class of Service
Description
A Class of Service (COS) allows or restricts access to a group of features or functions. For instance,
an Extension COS may allow Call Forwarding features. In the System, both extensions and trunks use
classes of service.
The System supports the following COSs for trunks and extensions:
•COS - Trunk/Tie
•COS - Ext/Ext Restriction
•COS - Extension Feature
•COS - Trunk to Trunk Restriction
Class of Service - Trunk/Tie
Tie/Trunk COS allows or restricts access to various features. Each trunk is assigned to one of 16 trunk
classes of service (00-15).
The following table shows the features that can be enabled/disabled for each trunk COS.
Table 3-1. Trunk COS
NumberFeature
1Intercom Ringing Tone (CO or intercom ring tone)
2Dial Tone to Tie Lines (Enable/Disable)
3Forced Recover on Fast-Busy Tone (Send fast busy or disconnect line)
4DID/DDI Dialed Number Conversion Table (DID/DNIS Table A or B)
5Paging on DISA/Tie-Line Call (Allow/Restrict)
6DISA Security Code Verification
7Network Flash Forwarding (Version 2.0 or higher)
8Network Flash Receive (Version 2.0 or higher)
9Brokers Hold for Network Calls (Version 2.0 or higher)
10Priority Message-Waiting Set/Cancel (Version 2.0 or higher)
11Network-to-Network Transfer (Version 2.0 or higher)
12Camp-On for Tie-Lines (Version 2.0 or higher)
13T1 Trunk Ring Back Service Tone (Version 3.5 or higher)
Hardware Requirements
•N/A
Related Programming
•N/A
Considerations
•N/A
576-50-700DBS 576HD (USA) issued September 20013-11
Chapter 7. SLT FeaturesSection 700 - Operation
Class of Service - Ext/Ext Restriction
Ext/Ext Restriction COS allows or restricts calls placed to other extensions based upon the Extension
COS. Each Extension COS is programmed to either originate or not originate calls to another
Extension COS.
Hardware Requirements
•N/A
Related Programming
•FF1-0-03: Class of Service - Extension
•FF1-0-10: Ext - Ext Restriction
•FF2: Extension COS Assignment
Considerations
•N/A
Class of Service - Extension Feature
Extension COS allows or restricts access to certain extension features. (The extension features are
described later in this manual.) Each extension is assigned to one of 16 classes of service (00-15).
The following table shows the features that can be enabled/disabled for each Extension COS.
Table 3-2. Extension COS
Class of Service Features
NumberFeature
1
2
3
4
5
6
7
8
9
10
11
12
13
Intercom Call Type (Tone/Voice)
Onhook Transfer at Ringback (Allow/Restrict)
Onhook Transfer at Talk (Allow/Restrict)
On-Hook Transfer at Camp-On (Allow/Restrict)
Exclusive Hold for Non-Appearing CO (System/Exclusive)
Exclusive Hold on SLTs (System/Exclusive)
Brokers Hold on SLTs (3-Party Conference/Brokers)
Hookflash During Talk on SLTs (Allow/Restrict)
SSD Assignment (Allow/Restrict)
SSD Assignment to MCO Tenant Groups (Allow/Restrict)
SSD Dialing (Allow/Restrict)
Intercom Redialing (Allow/Restrict)
Direct Trunk Access (Allow/Restrict)
14
15
3-12DBS 576HD (USA) issued September 2001576-50-700
MCO Incoming Call Answer (Allow/Restrict)
Paging (Allow/Restrict)
