Panasonic CF-VEB342 User Manual
Specifications and Main Features
- Use Only Specified AC Adapter Model Cf-Aa1527: Power Supply Input: Dc 15.1 v.
- Expansion Bus Connector: Female 100-pin.
- Parallel Port: Female Dsub 25 Pin.
- Display Port: Mini Dsub 15 Pin Female.
- Serial Port: Male Dsub 9 Pin.
- Microphone Jack: Miniature Jack, 3.5 Dia, Use Only Mono Condenser Microphone.
- Headphone Jack: Miniature Jack, 3.5 Dia.
- Keyboard Port: Mini Din 6 Pin Female.
- Mouse Port: Mini Din 6 Pin Female.
- Usb Port: 4 Pin.
- Fdd Port: 26 Pin Female For External Floppy Disk Drive Cf-Vfdu01.
- Physical dimensions: 229 Mm X 138 Mm X 76 M (9.02” X 5.43" X 2.99”).
- Weight: 0.85 Kg 1.87 Lb approximately.
- Operating environment between: Temperature from 5 Degrees Celsius to 35 Degrees Celsius, Humidity from 30% RH to 80% RH no condensation old.
Frequently Asked Questions
Q: What Is The Input Voltage For The Mini Port Replicator?
A: The input voltage is DC 15.1 V.
Q: Do I Need To Use some Sort Of Ac Adapter If I Am Using The Mini Port Replicator?
A: No, you must use the specified AC adapter model CF-AA1527.
Q: Are There Any Microphones I Cannot Connect To The Microphone Jack?
A: You can connect only a monaural condenser microphone.
Q: What are the mini port replicator's physical characteristics?
A: Its dimensions stand at 229 mm x 138 mm x 76 mm (9.02” x 5.43" x 2.99”) in size.
Q: What are the measurements on a mini port replicator?
A: The product in question has an approximation weight of 0.85 kg (1.87 lb).
Q: What is the operating temperature decryption for the mini port replicator?
A: The working temperature limit is 5 °C to 35 °C (41 °F to 95 °F).
Q: Is it possible to plug in the mini port replicator when the computer is running?
A: No mini port replicator should be plugged in and unplugged whilst the computer is switched on.
