Panasonic CF-48 User Manual

Panasonic

Personal Computer

OPERATING INSTRUCTIONS

Model No. CF-48 Series

Contents

Getting Started

RoaiJ Me FImt

:. Fhst-lime Operatici....................................................B

* I i¥«vi Mm ^irMl

* Key Comblnattorii

...................................................

Rer^remvi* MwimhI

« LEO lndit.vJtHù

^ ^ Starting Up/Shuttiritj Diwrt..................................14

k .

■V

1 ' List or Erra Codes

. V^'Ì- y-■'- DeaUincf with Problems (faitiittwy)

'■¿nLL

[Additional Mainuail

Rdervmv MiinuAil

I rh«K RT.inii.'«) hi: tm yimr civm[vula.

Ritti itìpui4 liiwhowtoìKOMsiheKeterifniirviimiiai

_ . — r" LIMSTEO USE LICENSE AGREEMENTT........

Opefation

l'A'Tbudì Pad (Basic Oiporaticfn)

Reference Manual............................................18

---------------------------------------

RvìlVn’iii'A' MHiiiml

• 'Tduci'i Pad (Advanced;« • nAw/H/induiw

• ¡-'Jlxridlivi'HilwriMliuri » Putì RiiplicatOi'

Funclior/c • Printer

• awr^JNly MHHMJIHN * Eftl>MI l\l»4 Display

• Computing on the • USO Devi««

irnMri • MihJ^iui

• Etiiltti V Power * LAN

• CD Drive • ilHwilJiKk IJffv«

• PC rDùidà * BCIMO Utdliiy

Troubie$tioDtìing

................ ..................................

•d.'ìLi RcinRlnlling SnÌlwaro

• *tdchnleal IrrterrTiatiefli * i «i i rttw t.uxiHH

■ OM^ Viewer * D-iùlinp Wllh PfOWcmt

Appendix

...........................................

Kcfcrcncc Manual

".V, Names and Functions of Ports

iii ' Spocificotioni;,

..........

LIMiTCD WARRANTY

.....................................

............................

{Ai.lv^vii/i.nl)

...........................

.......................................

.....................................

19 21

26 28

PlftftiiA /AAfi Instructions carctully betore iwinp thus prfxiucl Hr«.l wva ìI'iIa niAniiAl for future use.

Customer's Record

Model No.*i

Serial No.

Code No.

Product Key'^

Date of Purchase

*' For the Model No., insert the 12 digit number (for example, CF-48U4JHUPM) located on the

bottom of the computer. For Product Key, write down the number shown on the “Certificate of Authenticity” located on the bottom of the computer.

Dealer’s Name

Dealer's Address

Introduction

Thank you for purchasing the Panasonic computer. Read the operating instructions thoroughly for proper operation of your new computer.

Illustrations and Terminology in this Manual

NOTE: CAUTION: WARNING:

[Start] - [Shut Down]:

i Enter ) :

(HD + C^:

4Wincl5ws[98i 4Wintlows]NTi

(Wmdô^200Q>

Reference

Manual

NOTE provides a useful fact or helpful information. CAUTION indicates a condition that may result in minor or moderate injury. WARNING indicates a hazard that may result in moderate or serious injury.

This illustration means to click [Start], then to click [Shut Down]: (For some applications, you may need to double-click.) This illustration means to press the [Enter] key. This illustration means to press and hold the [Fn] key, then press the [F5] key. Information for Microsoft® Windows® 98 users. Information for Microsoft® Windows NT® Workstation Version 4.0 users. Information for Microsoft® Windows® 2000 Professional users. Where to go for referred information. This illustration means to refer to the Reference Manual, which is available on your computer. Refer to page 18 on how to access this manual.

. 'i

O Some of the illustrations in this manual may differ slightly in shape from the actual items in order to make the explanation

easier to understand.

• Circular media such as CD-ROM and DVD-ROM are described as “discs”. © In the ease of a model with a DVD-ROM drive or a model with a CD-R/RW drive or DVD-ROM & CD-R/RW drive,

change “CD-ROM drive” to read “DVD-ROM drive”, “CD-R/RW drive” or DVD-ROM & CD-R/RW drive, respectively.

Copyright

reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd. No patent liability is assumed with respect to the use of the information contained herein.

Disclaimer

Computer specifications and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. assumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals.

Trademarks

PS/2^^ is a trademark of International Business Machines Corporation. Intel, Pentium and SpeedStep are either registered trademarks or trademarks of Intel Corporation. Microsoft®, MS-DOS® and Windows® are registered trademarks of Microsoft Corporation of the United States and/or other countries.

Pentium® are registered trademarks of Intel Corporation.

Adobe® and Acrobat® are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Panasonic® is a registered trademark of Matsushita Electric Industrial Co., Ltd.

Read Me First

For U.S.A.

Federal Communications Commission Radio Frequency Interference Statement

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the u.ser is encouraged to try to correct the interference by one or more of the following measures;

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the Panasonic Service Center or an experienced radio/TV technician for help.

Warning

To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any

changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

FCC RF Exposure Warning: This computer is provided with PC Card slots that could be used with wireless transmitter(s), which will be specifically recommended, when they become available. Other third-party wireless transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including

interference that may cause undesired operation.

Responsible Party; Matsushita Electric Corporation of America

One Panasonic Way Secaucus, NJ 07094

Tel No:l-800-LAPTOP-5 (1-800-527-8675)

FCC Regulation Notice for modem

This equipment contains a FCC approved modem.

Manufacturer of modem: AMBIT Microsystems Corporation Model No. J07.017.C.00 .

Tested To Comply |>C5r With FCC Standards FOR HOME OR OFFICE USE

1. This equipment complies with Part 68 of the FCC rules. On the computer is a label that contains, among other informa tion, the FCC registration number and ringer equivalence number (REN) for this equipment. If required, this informa tion must be provided to the téléphoné company.

2. An FCC compliant telephone cord and modular plug is pro vided with this equipment; This equipment is designed to be

connected to the telephone network or premises wiring using

a compatible modular jack which is Part 68 compliant. See Installation Instructions for details.

3. The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all area, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company.

4. If your telephone equipment cause harm to the telephone net

work, the telephone company will notify you in advice that temporary discontinuance of service may be required. But if advice notice isn’t practical, the telephone company will no tify the customer as soon as possible. Also, you will be ad vised of your right to file a complaint with the FCC if you believe it is necessary.

5. The telephone company may take changes in it’s facilities, equipment, operations or procedures that could affect the op eration of the equipment. If this happens the telephone com pany will provide advance notice in order for you to make necessary modifications to maintain uninterrupted service.

6. If trouble is experienced with this equipment, for repair or warranty information, please contact Matsushita Electric Corporation of America at DIAL TOLL FREE 1-800LAPTOP5 ( 1 -800-527-8675). If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.

7. There are no user serviceable parts contained in this equipment.

8. This equipment may not be used on coin service provided by

the telephone company. Connection to party lines is subject to state t^iffs.

9. The Telephone Consumer Protection Act of 1991 makes it

unlawful for any person to use a computer or other electronic device to send any message via a telephone fax machine un less such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entry, or other individual sending the message and the telephone number of the sending machine or such business, other entity, of individual. In order to program this information into your fax software, you should refer to the manual of the Fax software being used.

10. According to the FCC’s electrical safety advisory, we recom mend that you may install an AC surge arrestor in the AC outlet to which this equipment is connected. Telephone companies re port that electrical surges, typically lighming transients, are very destructive to customer terminal equipment connected to AC power sources and that this is a major nationwide problem.

“Caution: To reduce the risk of fire, use only No.26 AWG or larger telecom munication line cord.” “ATTENTION; Pour réduire le risque d'incendie, utiliser uniquement des conducteurs de télécommunications 26 AWG ou de section supérieure,"

Notice for the products using LCD

This product uses one or more fluorescent lamps containing a small amount of mercury. It also contains lead in some compo nents. Disposal of these materials may be regulated in your com munity due to environmental considerations. For disposal or re cycling information please contact your local authorities, or the Electronics Industries Alliance: <

http://www.eiae.org.>

Read Me First

For Canada

Industry Canada (1C) Notice for modem

This equipment contains an Industry Canada approved modem unit. The Industry Canada label is affixed on the modem unit..

EQUIPMENT ATTACHMENT LIMITATIONS

“NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it

' is permissible to be connected to the facilities of the local

telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.

' Repairs to certified equipment should be coordinated by a

representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution hiay be particularly

important in rural areas. Caution; Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician,

■ as appropriate.” “NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the

maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers

• of all the devices does not exceed 5.” REN; See bottom of the computer

RESTRICTIONS CONCERNANT LE RACCORDEMENT DE MATÉRIEL

“AVIS: L’étiquette d’industrie Canada identifie le matériel homologué. Cette étiquette certifie que le matériel est conforme aux normes de protection, d’exploitation et de sécurité des réseaux de télécommunications, comme le prescrivent les documents concernant les exigences techniques relatives au matériel terminal. Le Ministère n’assure toutefois pas que le matériel fonctionnera à la satisfaction de l’utilisateur. Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux installations de l’entreprise locale de télécommunication. Le matériel doit également être installé en suivant une méthode acceptée de raccordement. L’abonné ne doit pas oublier qu’il est possible que la conformité aux conditions énoncées ci-dessus n’empêche pas la dégradation du service dans certaines situations. Les réparations de matériel homologué doivent être coordonnées par un représentant désigné par le fournisseur. L’entreprise de télécommunications peut demander à futilisateur de débrancher un appareil à la suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de mauvais fonctionnement. Pour sa propre protection, l’utilisateur doit s’assurer que tous

les fils de mise à la terre de la source d’énergie électrique,

des lignes téléphoniques et des canalisations d’eau

métalliques, s’il y en a, sont raccordés ensemble. Cette

précaution est particulièrement importante dans les régions

rurales. Avertissement: L’utilisateur ne doit pas tenter de faire ces raccordements lui-même; il doit avoir recours à un service d’inspection des installations électriques, ou à un électricien, selon le cas.”

“AVIS: L’indice d’équivalence de la sonnerie (lES) assigné

à chaque dispositif terminal indique le nombre maximal de

terminaux qui peuvent être raccordés à une interface. La

terminaison d’une interface téléphonique peut consister en

une combinaison de quelques dispositifs, à la seule condition

que la somme d’indices d’équivalence de la sonnerie de touts

les dispositifs n’excède pas 5.”

lES: Voir sous le fond de l’ordinateur

Important Safety Instructions / Importantes Mesures De Sécurité

When using your telephone equipment, basic safety pre cautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the fol lowing:

1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) dur ing an electrical storm. There may be a remote risk of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicin ity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special dis posal instructions.

SAVE THESE INSTRUCTIONS

Certaines mesures de sécurité doivent être prises pendant

l’utilisation de matérial téléphonique afin de réduire les

risques d’incendie, de choc électrique et de blessures. En

voici quelquesunes:’

1. Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol humide ou près d’une piscine.

2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pendant un orage électrique..Ceci peut présenter un risque de choc électrique causé par la foudre.

3. Ne pas utiliser l’appareil téléphonique pour signaler une fuite de gaz s’il est situé près de la fuite.

4. Utiliser seulement le cordon d’alimentation et le type de piles indiqués dans ce manual. Ne pas jeter les piles dans le feu; elles peuvent exploser. Se conformer aux règlements pertinents quant à l’élimination des piles.

CONSERVER CES INSTRUCTIONS

Lithium Battery

Precautions

Lithium Battery!

This computer contains a lithium battery to enable the date, time,

and other data to be stored. The battery should only be exchanged by authorized service personnel. Warning! A risk of explosion from incorrect installation or mis application may possibly occur.

Pile au lithium!

Le micro-ordinateùr renferme une pile au lithium qui permet de sauvegarder certaines données comme la date et l’heure notamment. Elle ne devra être remplacée que par un technicien qualifié. Avertissement! Risque d’explosion en cas de non respect de cette mise en garde!

CD Drive Caution

CAUTION!

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS/ADJUSTMENTS OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL

AVERTISSEMENT! .

CET APPAREIL UTILISE UN LASER.

L’UTILISATION DE COMMANDES OU DE RÉGLAGES OU

L’EXÉCUTION DE PROCÉDURES AUTRES QUE CELLES

SPÉCIFIÉES ICI PEUVENT PROVOQUER UNE EXPOSITION Л

DES RADIATIONS DANGEREUSES. '

NE PAS OUVRIR LES COUVERCLES NI ESSAYER DE RÉPARER

SOI-MÊME.

CONFIER TOUT TRAVAIL D’ENTRETIEN À UN PERSONNEL

QUALinÉ. . ^ •. . .

Usage

Avoid Extreme Heat and Cold

Do not store or use the computer in locations exposed to heat, direct sunlight, or extreme cold. Avoid moving the computer between locations with large temperature difference. Operation: 5 "C to 35,"C {41 "F to 95 “F}

Storage: -20 °C to 60 “C {-4 “F to 140 ”F}

Avoid Direct Sunlight on the LCD Panel

The LCD panel should not be exposed to direct

sunlight or ultraviolet light.

Avoid Humidity, Liquids and Dust

Do not store or use the computer in locations exposed to high humidity, liquids (including rain) or dust.

Prevent Shock

Avoid subjecting the computer to severe vibrations or impact. Do not place the computer inside a car trunk.

Avoid Radio Frequency Interference

Do not place the computer near a television or ra dio receiver.

Avoiding low-temperature burns

Avoid more than casual contact with any heat pro

ducing area of the notebook computer, AC adap

tor, and any option or accessory you use with it. Even low heat, if warmer than body temperature,

can cause a bum, if the skin is exposed to the heat

source for a long enough period of time.

Handling

Avoid Magnetic Fields

Keep the computer away from magnets.

Avoid Stacking

Do not place heavy objects on top of the computer.

Bottom

Keep Small Objects Away

Do not in.sert paper clips or other small objects into the computer.

Do Not Disassemble the Computer

Do not attempt to disassemble your computer.

Avoid Excessive Force on the Display

Do not apply excessive downward force on the display when it is completely opened, especially when plugs and/or cables are connected to the rear of the computer.

Peripherals

Incorrectly using peripheral devices may lead to a decrease in

performance, an increase in temperamre and/or damage your computer. For more information on peripheral devices, refer to the Reference Manual.

Cables

Use of an interface cable longer than 3 m (9.84 feet) is not rec ommended.

Read Me First

Precautions (Battery Pack)

• Care should be exercised with regard to the following in or der to avoid the possibility of overheating, fire or damage.

Avoid Heat

Do not throw the battery pack into a fire or ex pose it to excessive heat.

Keep Articles Away

Do not place the battery pack together with articles such as necklaces or hairpins when carrying or stor ing.

Do Not Disassemble

Do not insert sharp objects into the battery pack, expose it to bumps or shocks, deform, disassemble, or modify it.

Do Not Short

Do not short the positive (+) and negative {-) con tacts.

Avoid Extreme Heat, Cold and Direct Sunlight

Do not charge, use or leave the battery pack for ex

tended periods where it will be exposed to direct

sunlight, in a hot place (in an automobile on a sunny

day, for example), or in a cold place.

Do Not Use With Any Other Computer

The battery pack is rechargeable and was intended

for the specified computer or charger. Do not use it with a computer other than the one for which it was designed.

Do Not Put into a Microwave

Do not put the battery pack into a microwave oven or a pressurized chamber.

Stop Using

Should the battery emit an abnormal odor, become hot to the touch, become discolored, change shape, or become in any way different from normal, re

move it from the computer and stop using it.

If the battery pack will not be used for a long period of time (a month or more), charge or discharge (use) the battery pack until the remaining battery level becomes 30% to 40% and

store it in a cool, dry place. This computer prevents overcharging of the battery by re charging only when the remaining power is less than approx. 95% of capacity. The battery pack is not charged when the computer is first purchased. Be sure to charge it before using it for the first time. When the AC adaptor is connected to the computer, charging begins automatically.

Should the battery leak and the fluid get into your eyes, do not rub your eyes. Immediately flush your eyes with clear water and see a doctor for medical treatment as soon as possible.

Anote>

The battery pack may become warm during recharging or normal use. This is completely normal. Recharging will not commence outside of the allowable temperature range (0 °C to 45 '’C {32°F to 113 '’F}) O’ “Battery Power”. Once the allowable range requirement is satisfied, charging begins automatically. Note that the recharging time varies based on the usage conditions. (Recharging takes longer than usual when the temperature is 10 °C {50 °F} or less.) If the temperature is low, the operating time is shortened. Only use the computer within the allowable temperature range. The battery pack is a consumable item. If the amount of time the computer can be run off a particular battery pack becomes dramatically shorter and repeated recharging do not restore its performance, the battery pack should be replaced with a new one.

When a spare battery pack is to be carried in a pocket or bag, it is recommended that it be placed in a plastic bag so that its contacts are protected. Always power off the computer when it is not in use. Leav ing the computer on when the AC adaptor is not connected will exhaust the remaining battery capacity.

Do not touch the terminals on the battery pack. The bat tery pack may no longer function properly if the contacts

are dirty or damaged.

Do not expose the battery pack to water, or allow it to become wet.

Saving Data on the Hard Disk

Do not expose your computer to shock.

Use care when handling your computer, shock may damage your hard disk or make your software appli cations and data unusable.

Do not power down your computer while software applications are running or hard disk drive indicator is on.'

Properly shut Windows* down to avoid problems ([Start] - [Shut Down] ).

Save all valuable data to disks.

Backing up data to disks will limit damage should trouble occur to your computer or should you inad vertently change or erase data. Use the security function for all important data. “Security Measures”)

4 Windows 98 >

This computer uses Microsoft® Windows® 98 Second Edition. This computer use.s Microsoft* Windows NT*. This computer uses Microsoft* Windows* 2000 Professional.

-Hard-Disk-Lockn

When the Hard Disk Lock is set to [Enable], it is impossible to read/write data from/to the hard disk when the hard disk is installed in a different computer, since a password is also set for the hard disk. When the hard disk is returned to the original computer, you can read/write data as before. In this case, however, make the settings in the Setup Utility exactly the same as they were before the hard disk was removed. (Note that this Hard Disk

Lock does not guarantee the complete protection of data.) “Security Measures”)

Saving Data on Floppy Disks

► Do not power down your computer or press the floppy disk drive eject button while the floppy disk

drive indicator ([^) is on.

Doing so may damage the data on the floppy disk and render the floppy disk useless.

^ Use care when handling floppy disks.

To protect the data on your floppy disks or to prevent a floppy disk from becoming stuck in your com puter, avoid the following:

• Sliding the shutter on the floppy disk manually.

• Exposing the floppy disk to a magnetic field.

• Storing the floppy disk in locations prone to high temperatures, low pitched noise, dampness, or dust.

• Applying more than one label on the floppy disk.

i Confirm the contents of. a floppy disk before formatting it.

Confirm that no important data is on the floppy disk, because all data on the floppy disk will be erased.

> Use the write-protect tab.

This is a must for preserving important data. ~ Write-protect Tab

This prevents your data from being erased or over- ' written.

Write Enable

Write Disable

Computer Viruses

Users are advised to purchase the latest versions of vims protection software and use them regularly.

We recommend you run the software:

• When booting your computer.

• After receiving data. We recommend that you check data received on disks or from external sources, such as data downloaded from the Internet, e-mail, etc. (For compressed files, uncompress them before running a check).

System File Checker 4win'dowsl98

Microsoft Corporation has announced that, with a computer in which Internet Explorer 5.01 is installed, if the [System File Checker] in [System Information] is executed, the following may occur.

• The message [System File Checker identified that the following file may be corrupted] may appear for normal files.

• In such cases, there is the possibility that the system will become unstable if the file is repaired with the System File Checker.

In this computer, since Internet Explorer 5.01 is the default browser, do not use the System File Checker.

Read Me First

Usage Environment

Handling

9 Environment

Humidity: 30% to 80% RH (No condensation)

Not in use: Temperature: -20 °C to 60 '’C {-4 “F to 140 “F}

Humidity: 30% to 90% RH (No condensation)

9 Places not to use your computer

Areas with electronic equipment

These areas may interfere with your display or cause your computer to produce strange sounds.

Areas with extremely high/low temperatures

computer may become warm.

but no warranty is provided against such trouble. Therefore, as a precision instrument, be

extremely careftil in the handling. © Do not drop or hit your computer against solid objects. © Do not carry your computer when it is on. © Remove all cables before transporting your computer. O We recommend preparing a fully charged battery.

When transporting spare batteries inside a package, briefcase, etc., it is recommended that

the batteries be stored in a plastic bag. © Do not place the computer upright or allow it to tip over. When the computer receives

extremely strong shock after falling, the hard disk or floppy disk drive, etc., may become

inoperable. © Do not carry the computer while the display is open, or carry it by gripping the display. © Do not put anything (e.g., a piece of paper) between the display and keyboard. © Always carry your computer with you. Never check it in with luggage. For use of the

computer inside an aircraft, we recommend asking the airlines regarding their policy on this

issue. . . © It is a good idea to make backup copies on disks and carry them with you. © Do not leave a disk in the drive while transporting your computer.

Touch Pad

Maintenance

page 17

In addition, do not use commercially-available household cleaners and cosmetics, as they may contain compo nents harmful to the surface.

work improperly or be damaged.

Display

Avoid using water when cleaning the panel. Ingredients included in water may leave residue and reduce readability of the screen. <When cleaning dust/dirt>

Avoid rubbing off dust/dirt with cloth since it may leave scratch on the screen. Sweep dust/dirt with fine brush, then wipe it with “dry” soft cloth used for cleaning glasses.

<When cleaning oily surfaco

Apply camera lens cleaner on a soft gauze and clean it with gentle force. Then, wipe with dry soft cloth used for cleaning glasses.

Areas excluding the display

Wipe these areas with a soft cloth, after applying water or detergent diluted with water to the soft cloth and firmly wringing out excess water.

First-time Operation

Read the steps below to help you leam what parts are included, and to gain an understanding of some basic computer-related operations.

1 Confirm the inclusion of all parts

Make sure the parts shown in the figure have been supplied. If any of these items are

missing or is not working properly, contact Panasonic Technical Support.

Latch

AC adaptor

Mode) No;CF-AA1639A

ModemTelephone

Cable......................1

Operating Instructions (This book) Windows® Book

AC Cord

iWindowsV98|

............................

Product Recovery CD-ROM

Battery Pack

Model No :CF-VZSU18

(KHDCKBM)

.........

Write down the Product Key

Write down the number shown on the “Certificate of Authenticity” located on the bottom of the computer in the “Customer’s Record” section on page 2 of this manual.

Read the LIMITED USE LICENSE AGREEMENT {cépage 26)

Before removing the seal covering the power switch, read the LIMITED USE LI CENSE AGREEMENT.

Insert the battery pack

CX) Turn your computer over.

@ Slide the latch, and then without releasing it, slide and remove the cover.

Put the battery pack into the computer and firmly attach the pack to the connector.

@ Match the mark on the cover to the body of the computer and slide the cover back

into place. Be sure the tab does not get caught when closing the cover.

If the cover is not attached properly, the battery may fall out while the com puter is being carried.

First-time Operation

Connect your computer to a power outlet

Be sure the AC adaptor is connected until completing Step 10 on page 13.

Handling the AC adaptor

• Do not twist or pull the AC power cord forcefully. Doing so may damage the connections.

• Use only the specified AC adaptor with your computer. Using an AC adaptor other than the one supplied might damage the battery and/or the computer.

• When the DC plug is not connected to the computer, disconnect the AC cord from your AC wall outlet.

• Problems such as sudden voltage drops may arise during periods of thunder and lightning. Since this could adversely affect your computer, an uninterruptible power source (UPS) is highly recommended unless the battery pack is installed.

-----

Open the display

To open the display, slide the latch located at the front and lift open the display.

------------------------------------

Turn your computer on

Press the power switch and hold it for approximately one second until the power indicator turns on before releasing it.

---------------------------------------------------------------------------------------------------------------------------------

• Do not press the power switch repeatedly.

• Once the computer is powered off, you must wait at least ten seconds before pow ering it on again.

The power saving function is factory set, so if there is no input from a key, the touch pad or an external mouse (when one is connected) for a certain interval of time, the power to the LCD and hard disk may be turned off. The LCD will resume operation when the touch pad or an external mouse (when one is connected) is used or a key is pressed. ' • ' The power to the LCD may be turned off while Windows is setting up or even when an

application software is being installed. In this case, because it is conceivable that a selection dialog box will be shown, do not press ( to resume from this condition as doing so may trigger a selection, but instead, press a key unrelated to the direct triggering of a selection, like( Ctrl ).

(KBD'CKSHD

In addition, when the computer is left alone, it automatically enters the standby* mode (Q= “Standby/Hibemation Functions”). The computer will resume by press ing the power switch.

Space ) or C Enter ) to attempt

--------------------------------------

—

iWindow5'2000V

standby or hibernation

iWindo^2000)

cWlteiimin?!

Select the Operating System

Windows 2000 and Windows NT are preinstalled on this computer. After one of them is

selected with the following procedure, only that Operating System can be used, (T) At the screen for the agreement of the selection of the Operating System, select [YJ. @ With the number keys, select either Windows 2000 or Windows NT.

(The selection of the Operating System is only performed the first time the computer is started up. A change cannot be made after the selection.)

@ At the confirmation message, select [Y]. The Operating System preparation will start,

during which the computer will restart several times.

C'AUiTilON

.(i

Do not touch the keyboard. If you accidentally touch the keyboard and the cancel confirmation menu is displayed, do not cancel.

@ When the screen indicating the completion of the Operating System preparation is

displayed, press any key The computer will restart.

D -

........................

•

Setup Windows

Moving the cursor (/^) or clicking buttons can be performed with the touch pad.

4Winclowsl98l

(T) Select settings for your region and your keyboard layout, then select [Next].

(for U.S.A.: United States 101)

Enter your name and select [Next]. Select [Skip] at the [Using Your Modem to Connect].

Select [Yes] at the [Cancel Dialing], then select [Next]. The License Agreement will be displayed. After reading the agreement, select [I accept this agreement] or [I do not accept the

agreement], then select [Next].

NOTE>

If [I do not accept the agreement] is selected, the Windows setup will be aborted.

Select [Finish].

(?) Input the correct date, time and time zone and select [Close]. You can also complete

these settings at a later time.

4Windows>2000|

Do not press any key or move the touch pad until [Windows 2000 Professional Setup] is displayed.

V________________________________________________________________________________________________

G) At the [Welcome to the Windows 2000 Setup Wizard], select [Next].

After reading the agreement, select [I accept this agreement] or [1 don't accept this

agreement], then select [Next].

NOTE

If [I don’t accept this agreement] is selected, the Windows setup will be aborted.

Select settings for your region, then select [Next].

(4) Enter your name and organization and select [Next].

(To next page)

■)

+ 25 hidden pages
