TURTLE SHELL® 3.0
Hi.
Good call on picking up the Outdoor Tech
Turtle Shell
®
3.0 wireless boom
®
box. Your experience of the universe will soon be enhanced wirelessly and powerfully. This manual exists to help make sure that you use it correctly, so
you’re denitely going to want to relax
for a hot second and look through this.
Kisses,
ANATOMY
Power On / Power Off
Multi Function Button
Skip Backward / Volume Down
Skip Forward / Volume Up
Micro USB Charge Port / 3.5 mm Aux Port
USB Output Charge Port
Microphone
Light Indicator
POWER UP
TO CHARGE
For best results, fully charge your Turtle Shell®
3.0 before use!
1. Connect the included MIcro USB cord to a power source and the charging port on the Turtle Shell light will stay activated. ***Full charge time is about 4-5 hours.
2. When the Turtle Shell the RED light will turn off.
The displayed battery meter is supported for Apple products.
*The Turtle Shell® 3.0’s Bluetooth and music
functions can still operate while charging.
3.0. When charging, the red LED
®
3.0 is fully charged,
®
MUSIC FUNCTIONS
FUNCTION BUTTON ACTION
Answer an
incoming call
Reject an
incoming call
End call Short press once
Siri/Voice activation
Music / Device Controls
Skip backward
Volume down
FUNCTION BUTTON ACTION
Power on Press 3 sec
Power off Press 2 sec
Pairing mode Hold for 3 sec
Manual pairing
mode
Play / Pause Short press once
Volume up Short press once
Volume down Short press once
Skip forward Press & hold for
Skip backward Press & hold for
MFB
Skip forward
Volume up
Hold for 3 sec
2 sec
2 sec
PHONE FUNCTIONS
Device Controls
Skip backward
Volume down
FUNCTION BUTTON ACTION
Answer an
incoming call
Reject an
incoming call
End call Short press once
Siri/Voice activation
MFB
Skip forward
Volume up
Short press once
Press & hold for
2 sec
Press & hold for 2
sec & release
SINGLE PLAY SPEAKER PAIRING
Power On / Off
ON: Hold the Power Button for 2-3 seconds or until the LED light flashes blue and the voice prompt states “Power on”.
OFF: Hold the Power Button for 3-4 seconds or until the LED light flashes blue and the voice prompt states “Power off”.
Enter Pairing Mode
When powered on hold the “-” and “+” buttons simultaneously for 2-3 seconds and you will hear “Pairing” and the LED light will flash blue 3 times then pause and repeat.
Pairing Turtle Shell 3.0 to Device
Open the Bluetooth settings on your device. If you have put your Turtle Shell® 3.0 into pairing mode, it should be listed as “ODT Turtle Shell® 3.0” as an available device to pair. Connect with the Turtle Shell® 3.0. The voice prompt will state “Paired” when the Turtle Shell 3.0 and your device are connected.
DUAL PLAY SPEAKER PAIRING
TS3 #1 TS3 #2
STEP ONE
Turn on TS 3 #1 and wait until the voice prompt states that the speaker is on. Then press & hold the “-” and MFB buttons simultaneously. The Blue LED on the
TS3 #1 will ash 3X then pause and repeat when it’s
in speaker to speaker paring mode.
STEP TWO
Turn on TS3 #2 and wait until the voice prompt states that the speaker is on. Then press & hold the “+” and MFB buttons simultaneously. The Blue LED on the
TS3 #2 will ash 3X then pause and repeat when it’s in
speaker to speaker pairing mode.
STEP THREE
After a few seconds both the TS3 #1 and TS3 #2 will state “Paired.”
STEP FOUR
Press & hold the “-” and “+” plus buttons simultaneously for 2-3 seconds on TS3 #1. The blue LED will flash
3X then pause and repeat and state “paring” when
in speaker to device pairing mode. Open the Bluetooth settings on your device and select ODT Turtle Shell 3.0.
For more functions, go to outdoortech.com/apps to download the Outdoor Tech app.
LISTEN CONTINUED
The built-in microphone means that the Turtle Shell 3.0 can be used as a wireless headset.
*NOTE: The built-in microphone only works when
connected via Bluetooth.
The following are tips on how to use your Turtle Shell 3.0 to speak on the telephone:
Answer a call......... Press the multifunction button.
End a call............... Press the multifunction button.
Decline a call......... Press and hold the multifuntion
button for two seconds.
Make a call............ Use your phone to dial as usual.
Listen and talk through the Turtle Shell® 3.0.
Mute...................... Hold the >> and << buttons for 2
seconds, or until you hear a beep.
FAQ
Hearing Distortion
A. Lower the volume on your Turtle Shell®
3.0® and / or phone /device. B. Make sure it’s charged up. Check for low battery, then charge if necessary.
Not Loud Enough
A. Turn up the volume on your phone / device or your Turtle Shell® 3.0. B. Make sure it’s charged up. C. Plug the Turtle Shell in to your phone / device via 3.5mm stereo cable.
Unable to Pair
A. Conrm your phone / device is Blue tooth compatible. B. Re-Pair: Follow pairing instructions in this guide.
Signal Loss or Dropouts via Bluetooth
A. Move Turtle Shell closer to your phone / device. B. Make sure it’s charged up. C. Turn off your Turtle Shell® 3.0 and phone / device, then power up and reconnect.
SPECS
Rating: IPX7
Bluetooth v 4.2 Bluetooth Profiles: HSP, HFP. A2DP, AVRCP Capatability: Bluetooth v 1.1 and above Operating range: 32 ft Operating range between speakers: 15 ft Device name: ODT TURTLE SHELL 3.0
Power source: Lithium ion rechargeable
battery cell
Battery capacity: 3600mAh / 13.32 Wh Charge Output: 5V / 1A Charge Input: 5V / 2.1A Playing Time: Up to 20 hrs Charge Time: ~4.5 hrs
Operating Temperature: 0~45° C Storage Temperature: -20~60° C RoHS: Fully RoHS compliant
K, bye.
DON’T BE SO ANTISOCIAL
Facebook.com/outdoortechnology Twitter & Instagram: @outdoortech
Questions, comments, complaints, secret desires, or just to say what’s up: email info@outdoortech.com
K bye.
