TUIS
{
TWO:EES
}
ULTRA HI-FI
HEADPHONES
Hi.
Good call on picking up the Outdoor Tech
Tuis wireless speakers. Your experience
of the universe will soon be enhanced
wirelessly. This manual exists to help make
sure that you use them correctly, so you’re
denitely going to want to relax for a hot
second and look through this.
Kisses,
CONTENTS
Anatomy
Power Up
Pairing
Talk
Specs
FAQ
Care & Maintenance
1
3
4
5
7
8
9
ANATOMY
Multifunction Button (MFB)
Track Control
Volume Control
Built-in Mic
Charging Jack
LED Indicator
Line-in Jack
ANATOMY
Function Action
Play/Pause/
Answer/Hang Up
Raise Volume
Lower Volume
Skip Forward
Skip Back
Voice Command/Siri
Press the MFB
Press the volume up button
Press the volume down button
Press the skip forward button
Press the skip back button
Short Press the MFB &
volume up button
simultaneously
POWER UP
For best results, fully charge your Tuis before use.
For a full charge, plug the Tuis into your wall charger or
computer via micro USB cable.
The LED indicator located below the right ear piece will
flash red to indicate a low battery.
NOTE: It takes 3 hours to give your Tuis a full charge.
Power On/Off
ON: Press and Hold the MFB until you see a blue
LED flashing to power on the device.
OFF: In standby mode, hold the MFB until you see
the red LED flashing to power off the device.
PAIRING
Entering Pairing Mode
1. When the headset is off, press and hold the MFB
down until the LED flashes red and blue alternately.
2. Release “button,” you are now in pairing mode.
Pair
Go to your device’s Bluetooth settings
ADD or SEARCH devices.
When “ODT TUIS” appears, select it.
*If asked for a pass code: Enter “0000”
After successfully connecting, the blue LED will flash
twice every 4 seconds.
You should now be able to play music & make/receive
calls using the headset. Hooray.
Reconnecting
Automatic: Every time the headset is turned on, it will
connect to its most recent device automatically.
Manual: If it doesn’t connect on standby short press
any button once to connect.
TALK
The following are tips on how to use your Tuis to talk
on the phone:
Answer/ Cancel a call
End a call
Decline a call
Make a call
Mute/cancel mute
Transfer conversation
to mobile phone/
headset during a call
Volume up during a call
Volume down during a call
Voice dial
Redial last number
Press the MFB
Press the MFB
Press & hold the MFB
Use your phone to dial
as usual. Listen & talk
through the Tuis.
Press & hold the volume
up button
Press and hold the
MFB
Press the volume up
button
Press the volume down
button
Press the skip back &
volume down button
simultaneously
Double click the MFB
TALK (THE FANCY STUFF)
You’re popular. What happens when you’re on a call
with your girlfriend and your mom calls?
Answer new call
& end current call:
Answer new call
& retain current call:
Switch calls:
End current call &
switch retained call:
Press the MFB
Double click the MFB
Double click the MFB
Press the MFB
SPECS
Battery Life: Continuous talk/music time 15 hours,
Standby time/230 hours
*Battery life varies subject to different playing
circumstances such as music type and volume.
Bluetooth Version: V4.0
Bluetooth Profiles: A2DP, aptX, AVRCP
Operating distance: 30 feet
Dimensions: 176 x 160 x 55 mm
Weight: 173g
FAQ
1. Why is the LED flashing red twice every 30 seconds?
The battery is low. Recharge it.
2. Why is the red LED off when charging?
A. Make sure the connection between the charging
cable and the Tuis is tight.
B. If the Tuis haven’t been used in awhile, the light
may not come on immediately. Charge the battery
for at least 30 minutes.
3. Why cant I pair my Tuis?
Your Bluetooth device and the chips must both be in
pairing mode.
4. Why can’t I hear the sound on the headset?
A. Make sure the Tuis are on.
B. Make sure the volume is not too low or muted.
C. Make sure the Tuis are properly connected
with your device.
D. Make sure the Tuis are within range of your device.
5. Why can’t I hear the sound clearly on the headset?
A. Move your Tuis closer to your device.
B. Make sure your Tuis are charged up.
C. Turn off your Tuis and device, then power
up and reconnect.
6. Why the pause/play, last/next song not function
when playing music?
Make sure your Bluetooth device supports AVRCP
(Audio/Video Remote Control profile)
CARE & MAINTENANCE
- Keep the Tuis dry.
- Keep the Tuis away from direct sunlight or hot
places. High temperatures will shorten the life of
electronic devices, destroy the battery or distort
certain plastic parts.
- Do not try to disassemble the Tuis.
- Do not let the Tuis fall onto the floor or other
hard surfaces. The internal circuit board may
get damaged.
- Do not use intensive chemical products or detergent
to clean the product.
- Do not scratch the surface with sharp things.
DON’T BE SO ANTISOCIAL
Facebook.com/outdoortech
Twitter & Instagram: @outdoortech
Questions, comments, complaints, secret desires,
or just to say what’s up: email info@outdoortech.com
K bye.
outdoortech.com
