Oster SH12, 126954 User Manual

User Manual
Hinged Lid Electric Skillet
Manual de Instrucciones
Sartén Eléctrica Tapa con Bisagras
MODELS/MODELOS
P.N. 126954
Visit us at www.oster.com
For product questions contact:
Jarden Consumer Service
USA: 1.800.334.0759
www.oster.com
©2008 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions.
All rights reserved. Distributed by Sunbeam Products, Inc. doing business as
Jarden Consumer Solutions, Boca Raton, Florida 33431.
Para preguntas sobre los productos llame:
Jarden Consumer Service
EE.UU.: 1.800.334.0759
www.oster.com
©2008 Sunbeam Products, Inc. operando bajo el nombre de
Jarden Consumer Solutions. Todos los derechos reservados.
Distribuido por Sunbeam Products, Inc. operando bajo el nombre de
Jarden Consumer Solutions, Boca Raton, Florida 33431.
Printed in China SPR-022908 Impreso en China
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 24
IMPORTANT SAFEGUARDS
When using your electric skillet, basic safety precautions should always be followed, including the following:
READ ALL INSTRUCTIONS
• Be sure that lid handles are assembled and fastened properly.
• Do not touch hot surfaces, use handles.
• To protect against electric shock, do not immerse the temperature controller, cord or plug in water or other liquids.
• Close supervision is necessary when any appliance is used by or near children.
• Unplug the appliance from the outlet when not in use and before cleaning. Allow appliance to cool before putting on or taking off parts and before cleaning appliance.
• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions, or has been damaged in any manner. Return to an Authorized Service Station for examination, repair or electrical or mechanical adjustment. You can locate the nearest service center by calling 1.800.334.0759.
• The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter or touch hot surfaces.
• Do not place on or near a hot gas or electric burner or in a heated oven.
• Use extreme caution when moving the appliance if it contains hot oil or any other hot liquid.
• Always attach the temperature controller to the appliance first, then plug into the wall outlet. To disconnect, switch off, remove plug from the wall outlet, then remove the temperature controller from the appliance.
• Only use the appliance with the OSTER
®
Temperature Controller.
• Do not use appliance for anything other than its intended use.
• It is recommended that you do not cook with the Electric Skillet standing on temperature sensitive surfaces.
THIS UNIT IS FOR
HOUSEHOLD USE ONLY
EXTENSION CORD USE
A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord may be used if care is exercised in its use. If an extension cord is used, the electrical rating of the cord must be at least as great as the electrical rating of the appliance. The extension cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.
SAVE THESE INSTRUCTIONS
FOR PRODUCTS PURCHASED IN THE U.S. AND CANADA ONLY
To reduce the risk of electrical shock, this appliance has a polarized plug (one blade is wider than the other). This plug fits a polarized outlet only one way; if the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.
DO NOT CHANGE THE PLUG IN ANY WAY.
WELCOME
Congratulations on your purchase of an OSTER®Hinged Lid Electric Skillet! To learn more about OSTER®products, please visit us at www.oster.com.
HINGED LID ELECTRIC SKILLET FEATURES
COOL-TOUCH
WIDE HANDLES
LID LIFTING
HANDLE
PROBE
TEMPERATURE
CONTROL PROBE
QUICK-RELEASE
LATCH
HINGE
REMOVABLE
GLASS LID
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 2
INTRODUCTION
CONDITIONING OF THE NON-STICK COATED PAN
Before using your new appliance, wash the inside of the pan with warm, sudsy water and dry. When washing the skillet, make sure the temperature controller is removed. Rub a film of cooking or salad oil all over the non-stick coating on the inside of the pan. Remove any excess oil with a cloth or paper towel.
The OSTER®Electric Skillet is now ready for use and it is unnecessary to condition it again.
USING THE HINGED LID ELECTRIC SKILLET
1. Push the temperature controller firmly into its socket found at the side of the
appliance. Plug into a standard 120 Volt AC outlet.
2. Set the temperature you want by turning the knob on the temperature
controller. The indicator light will come on. Set the temperature of your choice opposite the indicator light. When the light goes off, the chosen cooking temperature has been reached. During cooking, the light will blink on and off indicating the temperature is being maintained. Guidance in the choice of temperatures is supplied later in this book.
3. The capacity of Model SH12 is 16.75 cups / 4.19 quarts / 3.97 liters.
4. It is recommended that you do not cook with the Hinged Lid Electric Skillet
standing on temperature sensitive surfaces.
5. For simmering, set the temperature control knob to 300°F/150°C or
SIMMER and wait until the liquid boils. Turn the knob toward the WARM setting. Set the dial to this point each time SIMMER is specified in a recipe.
6. Do not use metal utensils in your Hinged Lid Electric Skillet as they may
damage the non-stick coating. Wood or plastic coated spatulas are best. If you use plastic tools, make sure they are suitable for use on hot surfaces.
7. To remove the temperature controller, first unplug from the wall outlet,
then wrap your hand around the temperature controller and the quick release latch and squeeze. The controller will automatically release.
CLEANING THE PAN
UNPLUG CORD AND REMOVE THE TEMPERATURE CONTROL PROBE
Allow the appliance to cool. Wash the pan and lid with hot sudsy water. You can totally immerse the pan or place in the dishwasher. The lid is also dishwasher-safe providing it is placed in the TOP RACK ONLY. DO NOT PLACE LID UPSIDE DOWN IN BOTTOM DISHWASHER RACK. To remove stubborn food residues, use a nylon scourer. NEVER use abrasive powder cleaners or metal scouring pads because these will damage the non-stick coating. After washing, dry the pan thoroughly, while paying particular attention to the electrical socket and pins. DO NOT USE METAL PADS TO CLEAN ELECTRICAL PINS.
STORAGE AND MAINTENANCE
Unplug cord and remove temperature control probe. Allow appliance to cool before storing. Store your Hinged Lid Electric Skillet in a dry location, such as on a tabletop or countertop, or on a cupboard shelf. Wind the electrical cord into a coil and secure with a twist fastener. For convenience, the temperature control probe and cord can then be stored inside the skillet.
Other than recommended cleaning, no further user maintenance should be necessary.
The hinged lid was specially designed to make preparing and serving food easier.
• To attach the lid, be sure to align the lid hinge so that it slides down onto the matching heating base hinge. (see Fig. 1).
• When raising and lowering the lid, always use the lid lifting handle (see Fig. 2). Note: Lid opens away from the steam.
• To remove the lid, use both hands to gently lift up and remove. (see Fig. 3).
Fig. 1 Fig. 2 Fig. 3
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 4
FOOD
BACON EGGS ( Fried) EGGS ( Scrambled) PANCAKES HAMBURGER
(1/2-inch Thick)
HAM
(1/2-inch –1/4 -inch Slices)
POTATOES
(Country Fried) (Crispy Brown)
SAUSAGE FISH PORK CHOPS
(Breaded) (Brown)
CUBE OR MINUTE STEAK LIVER
(Calf’s, Lamb or Tender Beef)
FRENCH TOAST CRUSTY CHICKEN
(Use 4 Tbsp. Oil)
Do Not add wate
r
FOOD CHART
TEMPERATURE
350º F / 175º C
300º F / 150º C
325º F / 162º C
375º F / 190º C
375º F / 190º C
325º F / 162º C
325º F / 162º C 350º F / 175º C
340º F / 170º C
375º F / 190º C
375º F / 190º C 225º F / 110º C
400º F / 205º C
350º F / 175º C
325º F / 162º C
400º F / 200º C 300º F / 150º C
One-Year Limited Lifetime Warranty
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of one year from the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. Replacement will be made with a new or remanufactured product or component.If the product is no longer available, replacement may be made with a similar product of equal or greater value.This is your exclusive warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service centers, or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not cover:Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province, state to state or jurisdiction to jurisdiction.
How To Obtain Warranty Service In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-334-0759 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-667-8623 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection with this product, please write our Consumer Service Department.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE
ADDRESSES OR TO THE PLACE OF PURCHASE.
APPROXIMATE
TIME
5 – 8 Minutes
3 – 5 Minutes
2 – 3 Minutes
1 – 3 Minutes
Rare
4 – 8 Minutes
Well Done
9 – 12 Minutes
10 – 20 Minutes
10 – 12 Minutes 10 – 12 Minutes
12 – 15 Minutes
5 – 8 Minutes
10 – 15 Minutes 30 – 40 Minutes
2 – 4 Minutes
5 – 10 Minutes
4 – 6 Minutes
12 – 18 Minutes 10 – 15 Minutes
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 6
RECIPES
CHEESE AND BACON POTATOES
6 slices bacon
1
/4 cup onion, finely chopped
4 large potatoes, thinly sliced 11/2 cups (6-ounces)
with skins on cheddar cheese, shredded
1 can (4 ounces) chopped
green chilies
Place bacon in cold skillet. Set skillet temperature to 350º F / 180º C. Fry bacon until crisp, remove and drain. Carefully remove grease, reserving 2 tablespoons bacon grease in skillet. Add potatoes to skillet; cover and cook 10 minutes. Turn potatoes and cook an additional 5 minutes. Crumble bacon and combine with green chiles and onion. Sprinkle over potatoes. Top with cheese; cover and cook 5 more minutes.
PASTA WITH PEPPERS AND CHICKEN
1 clove garlic, minced Pinch ground red pepper 1 tablespoon olive oil Salt and ground black pepper to taste 1 whole boneless, skinless 11/2 teaspoons cornstarch
chicken breast, cut into
3
/4 cup chicken broth
1
/2-inch x 2-inch strips 4 ounces linguine or fettuccine,
1 cup sliced red, green or yellow cooled and drained
bell pepper (or combination)
1
/2 teaspoon basil
Set skillet temperature to 350º F / 180º C. Add garlic and oil and sauté 2 minutes. Add chicken; cook and stir for 5 minutes. Stir in bell peppers and allow to cook additional 2minutes or until vegetables are crisp tender and chicken is done. Reduce temperature to 250º F / 120º C. Blend seasonings and cornstarch into chicken broth, stirring until well blended. Pour broth mixture into skillet. Heat, stirring gently, 1 minute or until mixture is hot and thickened. Serve over pasta. Makes 2 servings.
RECIPES
PORK CHOPS WITH SPANISH RICE
2 to 4 center cut pork chops,
1
/3 cup raw long grain rice
about1/2 - inch thick
1
/2 teaspoon chili powder
1
/3 cup chopped onion 1 can (14
1
/2-ounces)
1
/4 cup chopped green bell pepper whole tomatoes
Set skillet temperature to 350º F / 180º C. Add chops and cook on first side 5 minutes. Turn chops; add onion and green bell pepper. Cook, stirring vegetables occasionally, 2 minutes. Reduce temperature to “WARM”. Add rice, chili powder and tomatoes and stir to blend into vegetables. Cover and cook 25 to 30 minutes, stirring occasionally.
CHICKEN CACCIATORE
2 tablespoons vegetable oil
1
/2 cup chopped green bell pepper
3 to 4 pieces chicken 1 can (4-ounces) sliced mushrooms
(thighs, legs, or halved breasts) drained
1
/3 cup chopped onion 1 bay leaf 1 clove garlic, minced 1 teaspoon italian seasoning 1 can (141/2-ounces) Salt and ground black pepper
peeled, diced tomatoes to taste
Hot Cooked spaghetti or other pasta
Set skillet temperature to 350º F / 180º C. Add oil. Arrange chicken pieces, skin side down in skillet. Cook chicken until browned on the first side, about 5 minutes. Turn chicken. Add onion and garlic around chicken. Cook 3 minutes, or until onion is cooked, but not brown. Reduce temperature to “WARM”. Add remaining ingredients, except spaghetti. Cover and cook 30 to 40 minutes, or until chicken is cooked. Stir sauce and spoon over chicken occasionally. Serve chicken and sauce over spaghetti or other pasta.
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 8
RECIPES
DENVER OMELET
1
/2 cup diced, cooked ham 3 eggs
1
/4 cup chopped green bell pepper 2 tablespoons water
1
/4 cup sliced fresh mushrooms
1
/2 teaspoon salt 1 green onion, sliced Dash cayenne pepper 1 tablespoon butter or margarine
1
/2 cup (1-ounce) cheddar cheese,
shredded
Set skillet temperature to 350ºF / 150ºC. Add ham, green bell pepper, mushrooms, onions and butter. Sauté 2 minutes stirring frequently. Arrange vegetables in an even layer. Lightly beat eggs with water, salt and cayenne pepper; pour egg mixture over ham and vegetables. Cover and cook 4 minutes or until eggs are set. Sprinkle with cheese, cover and cook additional 2 minutes. To serve, slice omelet in half then gently fold each part in half. Lift oldest from skillet with a spatula.
HAM AND CHEESE FAVORITE
1 tablespoon butter or margarine 2 eggs
1
/2 cup chopped onion
1
/2 cup chopped cooked ham 2 tablespoons all-purpose flour
1
/2 cup chopped fresh spinach
1
/4 cup milk
3
/4 cup (3-ounces) swiss cheese,
shredded
Set skillet temperature to 350ºF / 150ºC. Add butter and melt. Add onions and sauté until onions are tender, about 2 minutes, remove onion from skillet and set aside. Combine flour, milk and eggs; beat lightly to blend. Pour egg mixture into pan. Cover and cook 2 minutes. Arrange ham, spinach and cooked onions evenly over eggs. Sprinkle cheese evenly over top. Cover and cook additional 2 minutes. Gently cut into four pie-shaped wedges. Lift each edge onto serving plate.
RECIPES
EASY BEEF FAJITAS
Juice of 2 limes
1
/2 green or red bell pepper, thinly sliced
2 tablespoon olive oil 4 flour tortillas
1
/2 teaspoons ground cumin
1
/2 cup (2-ounces) monterey jack or
1
/4 teaspoon salt cheddar cheese, shredded
1 clove garlic minced Guacamole optional
1
/2 teaspoon red pepper flakes Salsa optional
Freshly ground black pepper Sour cream optional
to taste Chopped tomatoes optional
1
/3 -lb. top round steak,
thinly sliced
1 small onion, thinly sliced
Combine lime juice, 1 tablespoon olive oil, cumin, salt, garlic, red pepper and black pepper in a bowl. Add beef and allow to stand, at room temperature, for 30 minutes. Set skillet temperature to 350º F / 180º C. Add remaining 1 tablespoon olive oil, onion and pepper and stir gently. Cover and cook 1 to 2 minutes or until vegetables are tender. Remove vegetables and keep warm. Drain meat, discard marinade and place meat in skillet, sauté meat 7 to 9 minutes or until done. Meanwhile wrap tortillas in aluminum foil and heat in oven for 5 minutes. To assemble, spoon about 1/4 of meat and vegetables into center of each warmed tortilla. Sprinkle with 2 tablespoons cheese. Roll tortilla and place on serving plate. Garnish, as desired, with guacamole, salsa, sour cream and/or chopped tomatoes.
SHRIMP AND VEGETABLE STIR-FRY
3
/4 -lb. raw shrimp, 2 stalks celery shelled and deveined 1 small sweet red bell pepper, in thin strips 2 tablespoons light soy sauce 1 cup broccoli flowerets 2 tablespoons dry sherry
1
/2 medium onion, thinly sliced 2 teaspoons cornstarch 5 large fresh mushrooms, sliced 2 teaspoons grated gingerroot
1
/2 package (3 ounces) frozen 1 tablespoon vegetable oil snowpeas, thawed
Place cleaned shrimp in a bowl. Combine soy sauce, sherry, cornstarch, and gingerroot; pour over shrimp. Preheat skillet to 400ºF / 200ºC. Add oil to skillet. Stir-fry celery, red bell pepper, broccoli and onions for 2 minutes. Add shrimp with marinade and stir-fry additional 2 minutes or until shrimp turn pink. Add mushrooms and snow peas. Stir-fry until heated through.
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 10
PRECAUCIONES IMPORTANTES
Obedezca siempre las precauciones elementales de seguridad cuando vaya a hacer uso de su tostadora, incluyendo las siguientes:
LEA TODAS LAS INSTRUCCIONES
ANTES DE USAR
• Asegúrese que los mangos de la sartén estén montados y ajustados adecuadamente.
• No toque superficies calientes, utilice agarraderas.
• Como protección contra choques eléctricos, no sumerja el controlador de la temperatura, el cable o el enchufe en agua u otros líquidos.
• Nunca deje la unidad sin supervisión si la utilizan los niños o si la misma se utiliza cerca de ellos.
• Desenchufe el electrodoméstico del tomacorriente cuando no esté en uso y antes de limpiar. Deje que la unidad se enfríe antes de quitar o agregar piezas y antes de limpiarla.
• No opere ningún electrodoméstico que tenga el cable o enchufe dañado, si la unidad no funciona correctamente o se ha dañado de alguna manera. Envíelo a un Centro de Servicio autorizado para que lo revisen, reparen o para un ajuste eléctrico o mecánico. Para ubicar el centro de servicio más cercano, llame al
1.800.334.0759.
• El uso de accesorios no recomendados por el fabricante del electrodoméstico puede causar heridas.
• No lo use al aire libre.
• No permita que el cable cuelgue por sobre el mostrador o la mesa ni toque superficies calientes.
• No lo coloque cerca o sobre una estufa a gas o eléctrica o en el horno caliente.
• Use suma precaución al desplazar el electrodoméstico si contiene aceite caliente o cualquier otro líquido caliente.
• Siempre coloque el controlador de temperatura en el electrodoméstico primero, luego enchúfelo al tomacorriente de la pared. Para desconectar, páguelo, quite el enchufe del tomacorriente de la pared y quite el controlador de temperatura del electrodoméstico.
• Sólo use el electrodoméstico con el Controlador de Temperatura OSTER®.
•No use el electrodoméstico para un propósito distinto para el cual fue diseñado.
• Es recomendable no cocinar con la Sartén Eléctrica colocada sobre superficies sensibles al calor.
ESTA UNIDAD ES SÓLO PARA
USO
DOMÉTICO
NOTES
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 12
INTRODUCCIÓN
CONDICIONAMIENTO DE LA SARTÉN CON RECUBRIMIENTO ANTIADHERENTE
Antes de usar el electrodoméstico nuevo, lave el interior de la sartén con agua y jabón tibia y seque. Antes de lavar la sartén, debe quitar el controlador. Frote una película de aceite de cocina o para ensalada sobre el recubrimiento antiadherente dentro de la sartén. Quite el exceso de aceite con un paño o toalla de papel.
La Sartén Eléctrica OSTER®está ahora lista para usar y no es necesario acondicionarla nuevamente.
CÓMO USAR LA SARTÉN ELÉCTRICA
1. Introduzca el controlador de temperatura firmemente en su enchufe en la
parte lateral del electrodoméstico. Enchufe en un tomacorriente de 120 Voltios de CA.
2. Para fijar la temperatura deseada gire la perilla del controlador de
temperatura. Se encenderá la luz indicadora. Fije la temperatura de su preferencia en el lado opuesto a la luz indicadora. Se apagará la luz cuando se ha alcanzado la temperatura deseada. Durante la cocción, la luz titilará intermitentemente para indicarle que se mantiene la temperatura. Este libro ofrece una guía para la elección de la temperatura.
3. La capacidad del Modelo 3001 es de 16.75 tazas / 4.19 quartos / 3.97 litros.
4. No se recomienda usar la Sartén Eléctrica Tapa con Bisagras sobre
superficies sensibles a la temperatura.
5. Para cocinar a fuego lento, coloque la perilla de control de la temperatura en
300°F/150°C o FUEGO LENTO (SIMMER) y espere que el líquido hierva. Gire la perilla hacia el selector TIBIO (WARM). Coloque la perilla en este punto cada vez que la receta indique FUEGO LENTO.
6. No use utensilios de metal en su Sartén Eléctrica Tapa con Bisagras, ya que
pueden dañar el recubrimiento antiadherente. Se recomienda usar espátulas de madera o plástico. Si usa utensilios de plástico, verifique que sean aptos para superficies calientes.
7. Para remover el controlador de temperatura, primero desenchufe del
tomacorriente de la pared, ponga su mano alrededor del controlador de temperatura, la traba de apertura rápida y apriete. El controlador se liberará automáticamente.
CÓMO USAR UN CABLE ELÉCTRICO CORTO
Un cable eléctrico corto se provee para reducir riesgos resultantes de enredarse o tropezar con un cordón largo. Un cable de extensión puede usarse con cuidado. Si el cable de extensión es usado, la potencia eléctrica marcada en el cable de extensión, debe ser por lo menos igual o mayor a la potencia eléctrica del aparato. El cable de extensión debe colocarse de manera que no cuelgue del mostrador o de la mesa, donde pueda ser jalado por niños o donde puede tropezarse con él accidentalmente.
GUARDE ESTAS INSTRUCCIONES
PARA PRODUCTOS COMPRADOS EN ESTADOS UNIDOS Y
CANADÁ ÚNICAMENTE
Para reducir el riesgo de descargas eléctricas, este aparato cuenta con una clavija polarizada (una cuchilla es más ancha que otra). Como medida de seguridad, esta clavija entra sólo de una manera en un enchufe polarizado. Si la clavija no encaja en el enchufe simplemente colóquela al revés. Si aun así no encaja llame a un electricista calificado.
DE NINGUNA MANERA INTENTE MODIFICAR ESTA MEDIDA DE
SEGURIDAD. NO MODIFIQUE EL ENCHUFE EN NINGUNA FORMA.
BIENVENIDOS
¡Felicitaciones en su compra de una Sartén Eléctrica OSTER®. Para aprender más sobre productos OSTER®, por favor visítenos en www.oster.com!
PIEZAS DE LA SARTÉN ELÉCTRICA
MANGOS ANCHOS
FRÍOS AL TACTO
MEDIDOR
MEDIDOR PARA
CONTROLAR LA
TEMPERATURA
TRABA DE APERTURA
RÁPIDA
MANGO DE
TAPA
BISAGRA
TAPA DE VIDRIO
REMOVIBLE
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 14
CARTA DE COMIDA
CÓMO LIMPIAR LA SARTÉN
DESENCHUFE EL CABLE Y REMUEVA EL MEDIDOR PARA CONTROLAR
LA
TEMPERATURA
Deje enfriar el electrodoméstico. Lave la sartén y la tapa con agua jabonosa caliente. Puede sumergir totalmente la sartén o colocarla en el lavaplatos. La tapa también se puede lavar en el lavaplatos, siempre y cuando la coloque EN EL ESTANTE SUPERIOR SOLAMENTE. NO COLOQUE LA TAPA DADA VUELTA EN EL ESTANTE INFERIOR DEL LAVAPLATOS. Para quitar restos de comida que quedaron adheridos, use una esponja de nylon. NUNCA use polvos abrasivos o esponjas de metal, porque dañarán el recubrimiento antiadherente. Luego de lavar, seque la sartén por completo, prestando atención al enchufe eléctrico y pernos. NO USE ESPONJAS DE METAL PARA LIMPIAR LOS PERNOS ELÉCTRICOS.
ALMACENAMIENTO Y MANTENIMIENTO
Desenchufe el cable y remueva el medidor para controlar la temperatura. Deje enfriar el electrodoméstico antes de guardarlo. Guarde la Sartén Eléctrica Tapa con Bisagras en un lugar seco, por ejemplo sobre la mesa de cocinar o en un estante del armario. Enrosque el cable eléctrico en una bobina y sujételo con un gancho. Para su conveniencia, el medidor para controlar la temperatura y el cable pueden ser guardados dentro de la sartén.
Salvo por la limpieza recomendada, no se requiere ningún mantenimiento especial.
TIPO DE ALIMENTO
TOCINO HUEVOS ( Fritos) HUEVOS ( Revueltos) PANQUEQUES HAMBURGUESAS
(1/2-Pulgada de Grosor)
JAMÓN
(1/2-pulg. a
1
/4 -pulg. en Fetas)
PAPAS
(papas fritas en cubos
estilo desayuno)
(Doradas y Crocantes)
SALCHICHA PESCADO CHULETAS DE CERDO
(empanizadas) (doradas)
BISTEC EN CUBOS O BISTEC DELGADO
HÍGADO
(Bife de Ternero, Cordero o Tierno)
TOASTADA FRANCESA POLLO CROCANTE
(Use 4 Cu. de Aceite)
No Agregue Aguar
TEMPERATURA
350ºF / 175ºC
300ºF / 150ºC
325ºF / 162ºC
375ºF / 190ºC
375ºF / 190ºC
325ºF / 162ºC
325ºF / 162ºC
350ºF / 175ºC
340ºF / 170ºC
375ºF / 190ºC
375ºF / 190ºC 225ºF / 110ºC
400ºF / 205ºC
350ºF / 175ºC
325ºF / 162ºC
400ºF / 200ºC 300ºF / 150ºC
TIEMPO
APROXIMADO
5 – 8 Minutos
3 – 5 Minutos
2 – 3 Minutos
1 – 3 Minutos
Poco Cocida
4 – 8 Minutos
Bien Cocida
9 – 12 Minutos
10 – 20 Minutos
10 – 12 Minutos
10 – 12 Minutos
12 – 15 Minutos
5 – 8 Minutos
10 – 15 Minutos 30 – 40 Minutos
2 – 4 Minutos
5 – 10 Minutos
4 – 6 Minutos
12 – 18 Minutos 10 – 15 Minutos
La tapa con bisagras fue diseñada especialmente para preparar y servir la comida con mayor facilidad
• Para colocar la tapa, asegúrese de alinear la bisagra de la tapa de forma que pueda deslizarse hacia abajo encajando dentro de la bisagra de la base que calienta. (ver Fig.1).
• Cuando levante y baje la tapa, utilice siempre la perilla que eleva la tapa (ver Fig. 2)
Nota: La tapa abre fuera del alcance del vapor.
• Para sacar la tapa, utilice ambas manos para levantarla suavemente y sacarla. (ver Fig. 3).
Fig. 1 Fig. 2 Fig. 3
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 16
RECETAS
CHULETAS DE PUERCO CON ARROZ ESPAÑOL
2 a 4 centros de chuletas de puerco,
1
/3 tazas de arroz crudo de granos
grandes alrededor de
1
/2 - pulg. de espesor
1
/2 cdita. de chile en polvo
1
/3 taza de cebolla picada 1 lata de tomates enteros (141/2 oz.)
1
/4 de pimientos verdes picados
Ajuste la temperatura de la Sartén a 350 º F / 180 º C. Añada las chuletas y cocine por un lado durante 5 minutos. Voltee las chuletas; agregue la cebolla y los pimientos. Cocine, revolviendo los vegetales ocasionalmente, 2 minutos. Reduzca la temperatura a “WARM”. Añada el arroz, el chile en polvo y los tomates y revuelva todo junto con los vegetales. Tape y cocine 25 a 30 minutos, revolviendo ocasionalmente.
POLLO CACCIATORE
2 cdas.de aceite vegetal ½ taza de de pimientos verdes picados
3 a 4 presas de pollo rebanados 1 lata ( 4 oz.) de champiñones (muslos, patas o pechugas ) colados
1/3 taza de cebolla picada 1 hoja de laurel
1 diente de ajo, machacado 1 cdita. de aderezo italiano
1 lata de tomates enteros Sal y pimiaenta negra molida al (14
1
/2 oz.) gusto
Spaghetti u otra pasta cocinados y caliente
Ajuste la temperatura de la Sartén a 350 º F / 180 º C. Agregue el aceite. Arregle las presas de pollo, con la piel para abajo en la sartén. Cocine el pollo hasta que esté dorado de un lado, alrededor de 5 minutos. Voltee el pollo. Agregue la cebolla y el ajo alrededor del pollo. Cocine 3 minutos, o hasta que las cebollas estén cocidas pero no doradas. Reduzca la temperatura a “WARM”. Agregue los ingredientes restantes, excepto el spaghetti. Tape y cocine de 30 a 40 minutos, o hasta que el pollo esté cocido. Revuelva la salsa y bañe el pollo ocasionalmente con la misma. Sirva el pollo con su salsa sobre spaghetti u otra pasta
Garantía Limitada de 1 Año
Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions, o en Canadá, Sunbeam Corporation (Canada) Limited operando bajo el nombre de Jarden Consumer Solutions,(en forma conjunta, “JCS”), garantiza que por un período de un año a partir de la fecha de compra, este producto estará libre de defectos de materiales y mano de obra. JCS, a su elección, reparará o reemplazará este producto o cualquier componente del mismo que presente defectos durante el período de garantía.El reemplazo se realizará por un producto o componente nuevo o reparado.Si el producto ya no estuviera disponible, se lo reemplazará por un producto similar de valor igual o superior. Ésta es su garantía exclusiva.No intente reparar o ajustar ninguna función eléctrica o mecánica de este producto. Al hacerlo elimínará ésta garantía.
La garantía es válida para el comprador minorista original a partir de la fecha de compra inicial y la misma no es transferible. Conserve el recibo de compra original. Para solicitar servicio en garantía se requiere presentar un recibo de compra. Los agentes y centros de servicio de JCS o las tiendas minoristas que venden productos de JCS no tienen derecho a alterar, modificar ni cambiar de ningún otro modo los términos y las condiciones de esta garantía.
Esta garantía no cubre el desgaste normal de las piezas ni los daños que se produzcan como resultado de uso negligente o mal uso del producto, uso de voltaje incorrecto o corriente inapropiada, uso contrario a las instrucciones operativas, y desarme,reparación o alteración por parte de un tercero ajeno a JCS o a un Centro de Servicio autorizado por JCS.Asimismo, la garantía no cubre actos fortuitos tales como incendios, inundaciones, huracanes y tornados.
¿Cuál es el límite de responsabilidad de JCS?
JCS no será responsable de daños incidentales o emergentes causados por el incumplimiento de alguna garantía o condición expresa, implícita o legal.
Excepto en la medida en que lo prohíba la ley aplicable, cualquier garantía o condición implícita de comerciabilidad o aptitud para un fin determinado se limita, en cuanto a su duración, al plazo de la garantía antes mencionada.
JCS queda exenta de toda otra garantías, condiciones o manifestaciones,expresa, implícita, legal o de cualquier otra naturaleza.
JCS no será responsable de ningún tipo de daño que resulte de la compra, uso o mal uso del producto, o por la imposibilidad de usar el producto, incluidos los daños incidentales, especiales, emergentes o similares, o la pérdida de ganancias, ni de ningún incumplimiento contractual, sea de una obligación esencial o de otra naturaleza, ni de ningún reclamo iniciado contra el comprador por un tercero.
Algunas provincias, estados o jurisdicciones no permiten la exclusión o limitación de los daños incidentales o emergentes ni las limitaciones a la duración de las garantías implícitas, de modo que es posible que la exclusión o las limitaciones antes mencionadas no se apliquen en su caso.
Esta garantía le otorga derechos legales específicos y es posible que usted tenga otros derechos que varían de un estado, provincia o jurisdicción a otro
Cómo solicitar el servicio en garantía En los Estados Unidos
Si tiene alguna pregunta sobre esta garantía o desea recibir servicio de garantía, llame al 1-800-334-0759 y podrá obtener la dirección del centro de servicio que le resulte más conveniente
En Canadá
Si tiene alguna pregunta sobre esta garantía o desea recibir servicio de garantía, llame al
1-800-667-8623 y podrá obtener la dirección del centro de servicio que le resulte más conveniente
En los Estados Unidos, esta garantía es ofrecida por Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions, Boca Ratón, Florida 33431. En Canadá, esta garantía es ofrecida por Sunbeam Corporation (Canada) Limited operando bajo el nombre de Jarden Consumer Solutions, 20 B Hereford Street, Brampton, Ontario L6Y 0M1. Si usted tiene otro problema o reclamo en conexión con este producto, por favor escriba al Departamento de Servicio al Consumidor.
POR FAVOR NO DEVUELVA ESTE PRODUCTO A NINGUNA DE ESTAS
DIRECCIONES NI AL LUGAR DE COMPRA
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 18
RECETAS
FAJITAS DE CARNE FÁCILES
Jugo de 2 limones fino
1
/2 pimiento verde o rojo, rebanado
2 cdas. de aceite de oliva 4 tortillas de harina
1
/2 cdita. de comino molido
1
/2 taza ( 2 oz.)de queso monterey jack
1
/4 cdita. de sal o cheddar, rallado
1 diente de ajo Guacamole (opcional)
1
/2 cdita de pimienta roja Salsa (opcional) desmenuzada Crema agria (opcional) Pimienta negra fresca molida Tomates en cuadritos (opcional) al gusto
1
/3 de libra de carne cortada en
1 cebolla pequeña, rebanada fino lonjas finas
Mezcle el jugo de limón, 1 cda. de aceite de oliva, comino, sal, ajo, pimienta roja y pimienta negra en un recipiente. Añada la carne y déjela reposar a temperatura ambiente, por 30 minutos. Ajuste la temperatura de la sartén a 350 º F / 180 º C. Agregue la cucharada de aceite de oliva restante, la cebolla, pimientos y revuelva suavemente. Tape y cocine 1 a 2 minutos o hasta que los vegetales estén tiernos. Remueva los vegetales y manténgalo caliente. Escurra la carne, desechando los ingredientes que la marinaron y colóquela en la sartén, sofría la carne 7 a 9 minutos o hasta que esté listo, mientras tanto envuelva las tortillas en papel de aluminio y caliéntelas en el horno por 5 minutos. Para su preparación, ponga cucharadas de ¼ de carne y vegetales en el centro de cada tortilla caliente. Espolvoree con 2 cdas. de queso. Enrolle la tortilla y colóquela en un plato de servir. Adorne, si desea, con guacamole, salsa, crema agria y /o tomate en cuadritos.
LANGOSTINOS Y VEGETALES STIR-FRY (SALTEADOS)
3
/4 -lb. langostinos crudos, 2 tallos de celery sin concha y limpios 1 pimiento pequeño rojo dulce, 2 cdas. de salsa de soya ligera en tiras finas 2 cdas. de jerez seco 1 taza de brócoli sin tallos 2 cditas. de maicena
1
/2 cebolla mediana, rebanada fina 2 cditas. de jengibre rallado 5 champiñones frescos grandes descongelados rebanados 2 cucharaditas de jenjibre rallado
1
/2 paquete ( 3 oz. ) guisantes 1 cda. de aceite vegetal
PColoque los langostinos en un recipiente. Mezcle la salsa de soya, jerez, maicena y jengibre; viértalo sobre los langostinos. Precaliente la sartén a 400ºF/200ºC. Agregue aceite a la sartén. Saltee celery, pimientos rojos, brócoli y cebollas por 2 minutos. Añada los langostinos marinados y saltee 2 minutos adicionales o hasta que los langostinos se vuelvan rosados. Agregue los champiñones y guisantes. Saltee hasta que todo se caliente.
RECETAS
PAPAS CON QUESO Y TOCINO
6 rebanadas de tocino
1
/4 taza de cebolla picada muy fino
4 papas grandes, rebanadas 1
1
/2 tazas (6 oz.) queso cheddar
delgadas con piel rallado
1 lata ( 4 oz. ) de chiles
verdes picados
Coloque las rebanadas de tocino en la sartén fría. Ajuste la temperatura de la Sartén a 350 º F / 180 º C. Fría el tocino hasta que esté crocante, remueva y cuele. Cuidadosamente remueva la grasa, reservando 2 cucharadas de la grasa dentro de la sartén. Agregue las papas a la sartén; cubra y cocine por 10 minutos. Voltee las papas y cocine otros 5 minutos. Desmenuce el tocino y mézclelo con los chiles y la cebolla. Espolvoréelos sobre las papas. Cubra con el queso; tape y cocine 5 minutos más
PASTA CON PIMIENTOS Y POLLO
1 diente de ajo, machacado Una pizca de pimienta roja molida
1 cda. de aceite de oliva Sal y pimienta negra molida al gusto
1 pechuga de pollo entera, sin piel, 1
1
/2 cdita de maicena
sin huesos, cortadas en tiras de
3
/4 taza de caldo de pollo
1
/2 x 2 pulgadas 4 de linguine o fettucccine enfriados 1 taza de pimientos rojos, verdes y escurridos o amarillos ( o combinados )
1
/2 cdita. de albahaca
Ajuste la temperatura de la sartén a 350 º F / 180 º C. Añada el ajo y el aceite y sofría 2 minutos. Agregue el pollo; cocine y revuelva por 2 minutos. Incorpore los pimientos revolviendo y cocine 2 minutos más o hasta que los vegetales estén tiernos y crocantes y el pollo cocido. Reduzca la temperatura a 250 º F/ 120 ºC. Aparte mezcle los aderezos y la maicena dentro del caldo de pollo, revolviendo hasta que estén bien disueltos. Vierta la mezcla del caldo dentro de la sartén. Caliente, revuelva suavemente por 1 minuto o hasta que la mezcla esté caliente y espesa. Sirva sobre pasta. Alcanza para 2 porciones.
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 20
NOTASRECETAS
TORTILLA DENVER
1
/2 taza de jamón cocido en cuadritos 3 huevos
1
/4 taza de pimiento verde picado 2 cdas. de agua
1
/4 taza de champiñones
1
/2 cdita. sal frescos rebanados 1 cebollín en rueditas una pizca de pimienta de cayena 1 cda. de mantequilla o margarina
1
/2 taza ( 1 oz. ) de queso cheddar,
rallado
Ajuste la temperatura de la sartén a 350 º F / 180 º C. Agregue el jamón, pimientos, champiñones, cebollas y la mantequilla. Sofría 2 minutos revolviendo frecuentemente. Arregle los vegetales en una capa uniforme. Bata ligeramente los huevos con el agua, sal, y la pimienta de cayena; vierta la mezcla de huevo sobre el jamón y los vegetales. Tape y cocine 4 minutos o hasta que los huevos estén listos. Espolvoree con queso, tape y cocine 2 minutos adicionales. Para servir, corte la tortilla por la mitad y luego doble suavemente cada parte sobre su otra mitad. Utilice una espátula para levantarlas de la sartén.
FAVORITOS DE JAMÓN Y QUESO
1 cda. de mantequilla o margarina 2 huevos
1
/2 taza de cebolla picada
1
/2 taza de jamón cocido picado
2 cdas. de harina
1
/2 taza de espinaca fresca
1
/4 taza de leche
3
/4 taza ( 3 oz. ) de queso suizo
rallado
Ajuste la temperatura de la sartén a 350º F / 180º C. Agregue mantequilla y derrita. Añada la cebolla y sofría hasta que la cebolla esté tierna, alrededor de 2 minutos, retire la cebolla de la sartén y ponga aparte. Mezcle la harina, leche y huevos; bata ligeramente para mezclarlos. Vierta la mezcla de huevo dentro de la sartén. Tape y cocine 2 minutos. Arregle el jamón, la espinaca y las cebollas cocidas uniformemente sobre los huevos. Espolvoree con queso el tope. Tape y cocine por 2 minutos más. Corte suavemente en cuatro trozos en forma de pie. Levante cada borde sobre un plato de servir.
SH12_IB.qxd:Layout 1 5/2/08 2:07 PM Page 22
Loading...
