Oster FPSTFP1355 Instruction Manual

For product questions contact:

Sunbeam Consumer Service USA : 1.800.334.0759 Canada : 1.800.667.8623 www.oster.com

©2014 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights reserved. Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.

Para preguntas sobre los productos llame:

Sunbeam Consumer Service EE.UU.: 1.800.334.0759 Canadá : 1.800.667.8623

www.oster.com

©2014 Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions. Todos los derechos reservados. Distribuido por Sunbeam Products, Inc. operando bajo el nombre de Jarden Consumer Solutions, Boca Raton, Florida 33431.

TOTAL PREPTM 10-CUP FOOD PROCESSOR PROCESADOR DE ALIMENTOS TOTAL PREPTM DE 10 TAZAS

User Guide/ Guía del Usuario:

FPSTFP1355

Safety

Seguridad

How to use

Cómo usar

Cleaning

Cuidado y Limpieza

Recipes

Recetas

Warranty

Garantía

P.N. 158387 Rev AFPSTFP1355_14ESM2

Printed in China GCDS-OST36491-SL

FPSTFP1355_14ESM2.indd 28-1 17/10/14 8:54 AM

Impreso en China

www.oster.com

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

1. Read all instructions before use.

2. To protect against risk of electrical shock, do not put food processor in water or any other liquid. This may cause personal injury or damage to the product.

3. Close supervision is necessary when using this appliance near children.

4. Unplug from outlet when not in use, before putting on or taking o parts and before cleaning.

5. Do not contact moving parts.

6. Do not operate food processor with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest authorized service center for examination, repair or mechanical adjustment.

7. The use of attachments not recommended or sold by the manufacturer may cause re, electrical shock or injury.

8. Do not let cord touch hot surfaces or hang over table edges or counters.

9. Do not use your food processor if any part is broken.

10. Do not use outdoors or for commercial purposes.

11. Keep hands and utensils away from moving blades or discs while processing food to reduce the risk of severe injury to persons or damage to the food processor. A scraper may be used but must be used only when the food processor is not running.

12. Blade and processing disc are sharp. Handle carefully.

13. To reduce the risk of injury to persons, never place cutting blade on motor base without rst putting container properly in place.

14. Be certain container cover is securely locked in place while operating appliance.

15. Never feed food into food chute by hand, always use the food pusher.

16. Be sure to turn o the food processor after each use.

17. Do not use this appliance for other than its intended use.

18. Do not attempt to defeat the cover interlock mechanism.

19. The small pusher should only be used in combination with the large pusher. Do not use this piece by itself.

THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.

This appliance has a polarized alternating current plug (one blade is

wider than the other). To reduce the risk of electric shock, as a safety feature, this plug will t in a polarized outlet only one way. If the plug does not insert fully in the outlet, reverse the plug. If it still fails to t, contact a qualied electrician. Do not modify the plug in any way.

DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.

EXTENSION CORD USE

A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord may be used if care is exercised in its use. If an extension cord is used, the electrical rating of the cord must be at least as great as the electrical rating of the appliance. The extension cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

Thank you for purchasing the Oster® TOTAL PREP

PROCESSOR. Before you use this product for the rst time, please take a few moments to read these instructions and keep it for reference. Pay particular attention to the Safety Instructions provided. Please review the product service and warranty statements. Please do not return to the place of purchase. To learn more about Oster® products, please visit us at www.oster.com or call us at 1-800-334-0759.

10-CUP FOOD

SAVE THESE INSTRUCTIONS

FPSTFP1355_14ESM2.indd 2-3 17/10/14 8:54 AM

www.oster.com

LEARNING ABOUT YOUR 10 CUP FOOD PROCESSOR

Small Food Pusher

Large Food Pusher

Food Chute Lid

Reversible Slice/Shred Disc

Disc Stem

Dough Blade

Multi-purpose Blade

Bowl

Base

Control panel

BEFORE USING YOUR OSTER® FOOD PROCESSOR

• When unpacking the product and removing packing material, handle

the chopping blade and slice/shred discs carefully; they are very sharp.

• Wash all parts except the Base in hot, soapy water. Rinse them dry.

These parts can also be placed in the dishwasher. Be sure to read the Care & Cleaning Section of this manual to learn the correct methods for taking the unit apart and cleaning.

LEARNING ABOUT YOUR FOOD PROCESSOR:

Using Your Food Processor

NOTE: Do not attempt to chop ice in this food processor; it will damage the bowl, dull the Chopping Blade. This unit will not whip cream, beat egg whites, grind coee beans, spices or other items with high oil content, or slice or shred hard-cooked eggs, marshmallows, or soft cheeses.

CAUTION: For your protection, this unit has an interlock system. The processor will not operate unless the bowl is properly locked onto the base, cover is properly locked onto the bowl and large food pusher is engaged in chute. Do not attempt to operate the unit without the bowl lid, bowl and food chute correctly in place. Be sure base is on a at, dry and clean surface before you begin processing.

1 Using the PULSE control: You can control

the texture of processed foods better

FPSTFP1355_14ESM2.indd 4-5 17/10/14 8:54 AM

by using the PULSE button on your food processor. Simply press and release to quickly turn the food processor on and o. This allows you to check processed results and control the consistency. For longer processing, continue pressing the PULSE button.

2 Using the additional buttons: Add ingredients through the feed tube;

remove the pusher and ll the feed tube as directed (see How to Slice or Shred). Engage the pusher and press the desired function button. The motor will start. Press the Pusher rmly down until all ingredients have passed into the work bowl. Remove the Pusher and rell ingredients as needed. Press the OFF button when nished.

3 OFF Setting: Press the OFF button in between jobs to stop the food processor.

When not in use, the appliance should always be unplugged.

Figure 1

www.oster.com

How to Assemble the Bowl

WARNING: Be sure the unit is unplugged before putting on or taking o any parts. Put the bowl on top of the food processor base,

with the work bowl handle to the right. Turn the bowl clockwise until the bowl clicks into place. The handle should now be to the right of the control panel. (Figure 2)

Select the appropriate attachment and assemble onto food processor as directed in the chopping, kneading or slicing/shredding sections. Place food or dough in bowl if using multipurpose blade or dough blade.

NOTE: There is only one position for the bowl to lock onto the base. The unit will not operate if the bowl does not lock onto the base.

How to Lock the Cover

Place the lid on the bowl. Turn clockwise until the lid clicks into place; the arrow on the lid will line up with the arrow on the handle. Your food processor features a safety interlock system. The unit will not operate unless the bowl and bowl cover are properly aligned and locked into place and the large food chute is engaged. (Figure 3)

NOTE: Bowl must be locked into base before cover can be locked into position.

Figure 2

Figure 3

How to Chop

CAUTION: Make sure the unit is turned OFF and unplugged before use. Never use hand to push food into processor. Do not use the processor continuously for more than 3 minutes at a time.

Multipurpose Blade: Use multipurpose blade for chopping, mixing, blending, pureeing and preparing pu pastry, crumbs and short crust pastry.

1 Lock the bowl onto base.

(See “How to Assemble the Bowl”)

2 Take the disc stem and slide it onto the center post.

Then grasp the multipurpose blade by its stem and slide over the disc stem. (Figure 4)

CAUTION: Chopping Blade is very sharp, use caution when handling.

3 Place food into bowl. 4 Lock cover onto bowl. (See “How to Lock the Cover”)

Figure 4

5 Place the food pusher into the feed tube. 6 Plug the cord into an electric outlet.

Use the Food Guide to prepare food for chopping.

7 Press the Slice/Shred, Mix/Knead, or

Chop/Pulse button. When using the Chop/Pulse setting, hold down the Chop/Pulse button for about 2–3 seconds at a time, check results and repeat if desired.

8 When nished processing, press the OFF button and allow the chopping

blade to stop rotating.

9 Twist the cover counter-clockwise to remove lid. 10 Hold the disc stem with multi purpose blade attached by its stem and

remove. Unlock the bowl by turning it counter- clockwise towards the UNLOCK mark, and lift o. Empty the processed food.

FPSTFP1355_14ESM2.indd 6-7 17/10/14 8:54 AM

www.oster.com

How to Knead Dough

NOTE: Never try to process dough that is too sti to knead comfortably by hand. CAUTION: Make sure the unit is turned OFF and unplugged before use. Never

use hand to push food into processor. Do not use the processor continuously for more than 3 minutes at a time.

Dough Blade: Use the dough blade for kneading bread dough and for mixing batters and cake mixtures.

1 Lock the bowl onto base.

(See “How to Assemble the Bowl”)

2 Take the disc stem and slide it onto the center post.

Then grasp the dough blade by its stem and slide over the disc stem (Figure 5).

CAUTION: Dough blade is sharp; handle with care. 3 Place all the dry ingredients into the bowl. 4 Lock cover onto bowl.

(See “How to Lock the Cover”)

5 Place the food pusher into the feed tube. 6 Plug the cord into an electric outlet. 7 Press the Mix/Knead for continuous processing or

the Chop/Pulse button for short processing tasks. When using the Chop/Pulse setting, hold down the PULSE button for about 2-3 seconds at a time, check results and repeat if desired.

NOTE: All liquid ingredients should be added through the food chute while unit is processing. Add liquid in a slow, steady stream for even distribution. It is important to add enough liquid to make the dough soft enough to knead. Kneading dough that is too sti can strain the machine.

8 When nished processing, press the OFF button and allow the dough blade

to stop rotating.

9 Twist the cover counter-clockwise to remove lid. 10 Hold the disc stem with dough blade attached by its stem and remove.

Unlock the bowl by turning it counter- clockwise towards the UNLOCK mark, and lift o. Empty the processed food.

Figure 5

How to Slice or Shred

CAUTION: Make sure the unit is turned OFF and unplugged before use. Never use hand to push food into processor. Do not use the processor continuously for more than 3 minutes at a time.

Reversible Slicing and Shredding Disc: Use these discs for slicing and shredding meats, fruits, vegetables, cheeses and more.

1 Lock the bowl onto base.

(See “How to Assemble the Bowl”)

2 Slide the Disc Stem onto the center post of the

base. With the desired side facing up (slicing or shredding), push the slice/shred disc onto the disc stem (Figure 6).

CAUTION: Use caution when handling disc, blades are extremely sharp.

3 Lock cover onto bowl.

(See “How to Lock the Cover”)

4 Plug the cord into an electric outlet. Turn machine

on by pressing the HIGH or LOW buttons.

5 Put ingredients in the feed tube and press the food

pusher lightly onto the ingredients (Figure 7). The small pusher should only be used in combination with the large pusher. Do not use this piece by itself.

7 When nished processing, press the OFF button

and allow the disc to stop rotating. Twist the cover counter-clockwise to remove lid.

8 Carefully remove the Shredding Disc. Unlock the

bowl by turning it counter- clockwise towards the UNLOCK mark and lift o. Empty the processed food.

NOTE: Use GENTLE force to press down on the food pusher. Excessive force could cause damage to the disc.

• Press the ingredients down slowly and steadily with the pusher.

• When necessary, precut large chunks of food to t the size of the feed tube.

• For best results, ll the feed tube evenly.

• When processing large quantities, process small batches at a time and empty

the bowl between batches.

Figure 6

Figure 7

FPSTFP1355_14ESM2.indd 8-9 17/10/14 8:54 AM
