Orion VCM-X-RNE User Manual

Download

www.orioncontrols.com

VCM-X E-BUS Controller Codes: SS1030, SS1032, SS1033, SS1034

VCM-X / RNE Controller

Operator Interface SD

Technical Guide

VCM-X Controller Code: SS1026

RNE Controller Code: SS1045

VAV/Zone Controller Code: SS1001, SS1005, SS1025

Requires Modular Service Tool SD Code: SS1063

Requires Modular System Manager SD Code: SS1064

IMPORTANT NOTICE

This technical guide provides instructions for using the Modular Service Tool SD and Modular System Manager SD with the VCM-X, VCM-X E-BUS, RNE & VAV/Zone Controllers only. If you are using a different controller, you can download the applicable SD Technical Guide listed below from our website—orioncontrols.com. The technical guides can also be printed from the SD card.

SA E-BUS Controller - AA-SAOISD-TGD VCB-X Controller - OR-VCBXOISD-TGD VCM Controller - OR-VCMOISD-TGD VAV/CAV and MUA II Controllers - OR-VAVCAVMUAOISD-TGD

SD CARD UPDATING INSTRUCTIONS

The Modular Service Tool and Modular System Manager are equipped with an SD memory card. This SD card can be removed and easily updated through a computer by downloading updates, as they become available, from our website to your computer.

In order to perform any updates, your computer needs an SD card drive or you will need to purchase an SD card adapter.

Download instructions are found in Appendix B on page 81 of this manual.

www.orioncontrols.com

WattMaster Controls, Inc. 8500 NW River Park Drive · Parkville , MO 64152 Toll Free Phone: 866-918-1100 PH: (816) 505-1100 · FAX: (816) 505-1101 E-mail: mail@wattmaster.com Visit our website at www.orioncontrols.com

AAON® is a registered trademark of AAON, Inc., Tulsa, OK. WattMaster Controls, Inc. assumes no responsibility for errors or omissions. This document is subject to change without notice. Form: OR-VCMXRNEOISD-TGD-01G Copyright April 2015 WattMaster Controls, Inc.

TABLE OF CONTENTS

OVERVIEW & SYSTEM CONNECTION ...............................................................................5

Modular Service Tool ............................................................................................................................... 5

Modular System Manager SD .................................................................................................................6

MODULAR SERVICE TOOL SD ........................................................................................10

Display Screens and Data Entry Keys ...................................................................................................10

Initialization & Setting the Time & Date ................................................................................................. 11

Setting the Operating Mode & Energy Timer .........................................................................................12

Alarm Search & Override Search ..........................................................................................................13

Schedules & Holidays ............................................................................................................................14

Schedule Override ................................................................................................................................. 15

SYSTEM MANAGER SD ...................................................................................................16

Display Screens and Data Entry Keys ...................................................................................................16

Initialization & Setting the Time & Date .................................................................................................17

Setting the Operating Mode ...................................................................................................................18

Changing Passcodes .............................................................................................................................19

Loop Search and System Alarm Search ................................................................................................20

Unit Alarm Search & Override Search ................................................................................................... 21

Schedules & Holidays ............................................................................................................................22

Schedule Override ................................................................................................................................. 23

PROGRAMMING ...............................................................................................................24

VCM-X Conﬁ guration Screen Index ......................................................................................................24

Conﬁ guring VCM-X Controllers .............................................................................................................25

RNE Conﬁ guration Screen Index ..........................................................................................................34

Conﬁ guring RNE Controllers .................................................................................................................35

VCM-X / RNE Setpoint Screen Index ....................................................................................................44

Conﬁ guring VCM-X / RNE Setpoints .....................................................................................................45

VCM-X / RNE Status Screen Index .......................................................................................................55

VCM-X / RNE Status Screens ...............................................................................................................56

VAV/Zone Conﬁ guration Screens ..........................................................................................................66

VAV/Zone Setpoint Screens ..................................................................................................................69

VAV/Zone Status Screens .....................................................................................................................73

VAV/Zone Damper Force Modes ...........................................................................................................75

MiniLink PD Conﬁ guration Screens .......................................................................................................76

MiniLink PD Status Screens ..................................................................................................................77

TROUBLESHOOTING .......................................................................................................78

VCM-X / RNE Outputs Force .................................................................................................................78

APPENDIX A - SAVING, LOADING, AND COPYING SETPOINTS .....................................80

APPENDIX B - UPDATING THE SD MEMORY CARD ........................................................82

APPENDIX C - UPDATING CONTROLLER & E-BUS MODULE SOFTWARE ......................83

INDEX ..............................................................................................................................85

VCM-X / RNE Operator Interface SD

SYSTEM CONNECTION

Modular Service Tool SD

Zone

Modular Service Tool SD

The OE391-12 Modular Service T ool is a system operator interface that provides a direct link to enable the system operator to view the status, conﬁ gure, and adjust the setpoints of the VAV/CAV, MUA II, VCM, VCM-X, VCM-X E-BUS, RNE, VCB-X, SA E-BUS or VAV/Zone Controller on the control system communications loop. However, this manual only applies to VCM-X, VCM-X E-BUS, RNE, and VAV/Zone Controllers. See note in the inside front cover for the list of manuals that pertain to other controllers.

The Modular Service Tool is housed in an attractive black plastic enclosure. The display area is covered with a clear plastic bezel for protection of the display screen. The Modular Service Tool has a 4-line-by-20-character display panel with adjustable contrast control and a 27-key membrane keypad for data selection and entry. All keypad operations are simple and straight forward, utilizing non-cryptic plain English language messages. Menu-driven programming allows for easy setup and operation without the need for specialized training. The Modular Service T ool is supplied with a programmable 4 Gigabyte SD memory card, with (4) AA 1.5 V batteries, a wall mount a DC power supply, a mini-Din communication cable, and an E-BUS communication cable. The mini-Din cable allows you to connect the Modular Service Tool to any Orion controller which has a mini-Din connector socket for programming, monitoring, and troubleshooting purposes.

The Modular Service Tool is also equipped with an EBC E-BUS port and an RS-485 three conductor terminal block port. The E-BUS port and included E-BUS cable are used for updating E-BUS Module software. The RS-485 port is used for hard-wiring to older controllers that do not have a mini-DIN connector socket.

Figure 1: Modular Service Tool Dimensions

The Modular Service Tool is designed to be hand-carried. Its rugged plastic housing provides superior protection for the electronic components housed inside. The Modular Service Tool is a top-quality service tool that will stand up to the demands of the typical job site environment for many years.

VCM-X / RNE Operator Interface SD

SYSTEM CONNECTION

Modular Service Tool SD

Whether you have a Stand Alone, Interconnected, or Networked Orion Controls System, the Modular Service Tool always connects to the controller or a VAV/Zone Controller via a prefabricated cable that is supplied with the service tool. The Modular Service Tool cable is terminated on both ends with a mini-DIN connector. Attach one end to the Modular Service Tool and the other end to the mini-DIN connector on the controller. If this is an Interconnected System, all controllers that are interconnected with communications cable can be programmed from any controller on the loop. If this is a Networked System, all controllers on the entire Networked System can be programmed from one controller.

Male DIN Connector

Connector Cable

RS-485 Port

Be sure that the Modular Service Tool’s SD memory card is inserted correctly and that the Modular Service T ool has fresh batteries installed or that it is connected to a power source using the supplied power pack before attempting any programming of the controller. See Figur e 2 for connection details.

Female DIN Connector

Typical Controller Board

EBC E-BUS Port

The Modular Service Tool Can Be Connected To Or VAV/Zone Controller By Plugging One End Of The Supplied Cable Into the Modular Service Tool DIN Connector And The Other End Into The DIN Connector On The Controllers.

A Unit Controller

SD Memory Card

Power On Button

Figure 2: Modular Service Tool SD

VCM-X / RNE Operator Interface SD

Modular Service Tool SD

Be Sure The Modular Service Tool Is Connected ToThe Supplied Power Pack Or Has Fresh Batteries Installed Before Attempting Programming Of The Controller. Be Sure The Power Is Turned Off On The Modular Service Tool Before Connecting The Cable To The Controller.

SYSTEM CONNECTION

Modular System Manager SD

Zone

Modular System Manager SD

9.00"

708

DEC

MINUS

ESC

DOWN

ENTER

Figure 3: Modular System Manager SD Dimensions

STATUS

SETPOINTS

SCHEDULES

CLEAR

OVERRIDES

ALARMS

6.25"

1.81"

The OE392-12 Modular System Manager SD provides a direct link to enable you to view the status and adjust the setpoints of the VCM-X, VCM-X E-BUS, VCB-X, RNE, SA E-BUS, VCM, VAV/CAV, MUA II or VAV/Zone Controller on the control system communications loop. The System Manager SD is housed in a beige-colored plastic enclosure. The System Manager has a programmable 4 Gigabyte SD card and is equipped with a 4-line-by-20-character backlighted display panel and a 24-key membrane keypad for data selection and entry. All keypad operations are simple and straight forward, utilizing non-cryptic plain English language messages. Menu-driven programming allows for easy setup and operation without the need for specialized training. The System Manager also has 2 integral LEDs for user notiﬁ cation of system alarm conditions and override initiations. Protection from unauthorized users is provided by the System Manager’s integral multi-level passcode authorization programming.

On a Networked System, the Modular System Manager is connected to the communications and power loop of the system via modular cables that simply plug into the System Manager board and the Power/Comm Distribution Board. This virtually eliminates wiring errors and makes installation fast and easy. When it is to be connected to a Stand-Alone system, a cable with modular connectors on one end and stripped wire ends on the other end is provided to facilitate connecting communications and power to the Modular System Manager from the 24 VAC power source and the HVAC unit controller communication wiring terminals.

The Modular System Manager is designed for wall mounting. Mounting holes are provided to attach the Modular System Manager to a standard handy box. It is recommended that the System Manager be mounted at approximately eye level to allow for ease of programming and reading of the display. The System Manager is typically mounted in the building manager’s or superintendent’s of ﬁ ce or in an equipment room. The attractive enclosure is quite suitable for mounting in any location.

VCM-X / RNE Operator Interface SD

SYSTEM CONNECTION

Modular System Manager SD Network Connection

Network Connection

As previously described, when you are connecting the Modular System Manager to a Networked System, the Modular System Manager is connected to the communications and power loop of the system via modular cables. These cables simply plug into the System Manager board and to any device with modular connectors on any local loop on the system. Devices with modular connectors include the Power/Comm Distribution Board, VAV/Zone controller, and MiniLink Polling Device. By using these plug-in connections, wiring errors are virtually eliminated and system installation is fast and easy. See Figur e 4 below for typical connection information. See Figure 5 on page 8 for typical Power/Comm board wiring and connection information.

Modular System Manager SD Back View

When the System Manager is to be connected to a Stand Alone system, a 12-foot cable with modular connectors on one end and stripped wire ends on the other end is provided for this purpose. This is used to facilitate connecting communications and power wiring to the Modular System Manager from a 24 VAC power source and to the HVAC unit controller communication wiring terminals. See Figure 6 on page 9 for wiring details. If the supplied cable wire is not long enough for your installation, a standard modular cable of the correct length can be purchased through WattMaster and one of the modular connectors can be cut off to allow for the transformer and communication terminal wiring connections. It is recommended that you do not splice the communications wire if at all possible. The transformer should be rated at 6 VA minimum power output.

NOTE: For Stand-Alone Installations (No CommLink or MiniLink), All TERM Jumpers Must Be ON. For All Applications With CommLink(s) Or MiniLink(s), All Jumpers Must Be OFF.

Power/Comm Cables To Power/Comm Board, MiniLink Polling Device Or VAV/Zone Controllers On Local Loop.

Figure 4: Modular System Manager SD - Network

VCM-X / RNE Operator Interface SD

All Modular Power/Comm Cables Are To Be WattMaster Part Number PCC-xx Or PCCE-xx Cables.

Distribution

SYSTEM CONNECTION

Power/Comm Board Wiring

Zone

WARNING!

DO NOT GROUND THE 24V TRANSFORMER THAT IS TO BE USED WITH THE POWER/COMM BOARDS. GROUNDING OF THE TRANSFORMER WILL DAMAGE THE POWER/COMM BOARD AND ALL BOARDS CONNECTED TO IT. A SEPARATE TRANSFORMER MUST BE USED FOR EACH POWER/COMM BOARD. NO EXCEPTIONS. DO NOT CONNECT ANY OTHER DEVICES TO THE TRANSFORMER USED FOR THE POWER/COMM BOARD!

Line Voltage

24VAC

24VAC Transformer (By Others)

4 Amp Slow Blow Fuse

A Power/Comm Connect With The MiniLink PD Instead

2 Conductor Twisted Pair With Shield

Using Cable A Power/Comm

. You Can Also Use Cable To Connect With Board, A System Manager Or A VAV/Zone Controller.

Cable Can Be Used To

Another Power/Comm

Local Loop RS-485

C US

If Desired, Instead Of Using A Power/Comm Cable, You Can Use 2 Conductor Twisted Pair With Shield Cable To Connect To The Power/ Comm Board From The Unit Controller, MiniLink PD, Or Another Power/Comm Board.

All Comm Loop Wiring Is

9600 Baud

Straight Thru

NOTE: Diagram Shown Is For Wiring Of Power/Comm Board When Used For Connecting Local Loop Devices Such As VAV/Zone Controllers, System Manager(s) and Other Power/Comm Boards.

System Manager, Or VAV/Zone Controllers On Local Loop Only.

Figure 5: Typical Power/Comm Board Wiring

Power/Comm Cable To Power/Comm

Other Board(s),

VCM-X / RNE Operator Interface SD

Local Loop RS-485

9600 Baud

Modular System Manager SD Back View

SYSTEM CONNECTION

Stand Alone Connection

NOTE: If Desired A Power/Comm Board As Used With The Networked System Can Be Installed And Wired Instead Of Using The Pigtail Cable Wiring Shown Below. See The Networked System Wiring Diagram For Details.

Use Supplied Modular Cable With Stripped Ends For Connection To Terminal Block And Transformer

WHITE (T) DRAIN WIRE (SHLD) BLACK (R) RED (24 VAC) BROWN (GND) GREEN (GND)

Rated For 6 VA Minimum

Class 2 Transformer

NOTE: For Stand-Alone Installations (No CommLink or MiniLink), All TERM Jumpers Must Be ON. For All Applications With CommLink(s) Or MiniLink(s), All Jumpers Must Be OFF.

T SHLD

Controller Board

Figure 6: Modular System Manager SD - Stand Alone

VCM-X / RNE Operator Interface SD

MODULAR SERVICE TOOL SD

Modular Service Tool Keys

Operator Interfaces

In order to conﬁ gure and program the Orion System controllers, you must have an Operator’s Interface or a personal computer with the Prism II computer front-end software installed. Three different Operator Interfaces are available for programming of the Orion Controls System—the Modular Service T ool SD, the Modular System Manager (VCM-X and VAV/Zone Controllers only), and/or the System Manager TS II. These devices allow you to access the status and setpoints of the controllers on your communications loop. This manual describes the Modular Service Tool SD. If using the Modular System Manager or System Manager TS II, please see the VCM-X / RNE Operator Interfaces Technical Guide or the System Manager TS II T echnical Guide. If using Prism II, please see the Prism II Technical Guide.

The Modular Service T ool allows you to view any input or output status and change any setpoint to ﬁ ne-tune the operations of the total system. All keypad operations are simple and straightforward, utilizing noncryptic plain English messages.

Display Screens & Data Entry Keys

See the chart below for a list of the keypad descriptions and functions.

Keypad

Key Function

Description

ESC

ENTER

Clear

Minus

DEC





Use this key to access the

Setup Screens

Use this key to exit from screens or

from data entry or to return to the

Main Screen from any screen in the

system.

Use this key to enter a new value.

If a data entry mistake is made,

press this key to clear the data entry

ﬁ eld and start over. This key also turns off the power to the Service

Tool when on the

Main Screen

If a setpoint with a negative value

is required, press this key for the

minus sign.

Press this key when entering data

that requires a decimal point.

Use these keys to change values

in the Conﬁ guration Screens as

prompted.

Use these keys to step backward or

forward through the screens.



Mode Selection Buttons

The Modular Service Tool is provided with “Mode Selection Buttons.”

These buttons give you instant access to the speciﬁ c mode desired without

having to scroll through several menu screens to get there.

Button

Description

STATUS

SETPOINTS

SCHEDULES

OVERRIDES

ALARMS

CONFIGURATION

BALANCE-TEST

Notes:

(1) The Modular Service Tool will only search the Overrides one loop at a time. You must enter the Loop number and the MiniLink PD unit ID (60).

Table 2: Button Descriptions

Mode Selection But-

tons

Pressing this button takes you directly

to the controller

“Status” screens.

Pressing this button takes you directly

to the controller

“Setpoints” screens.

Pressing this button takes you directly

to the controller

“Schedules” screens.

Pressing this button takes you directly

to the controller “Overrides” screen.

See the “Override Button” section

on page 13 for a description of this

function.

See Note 1 below.

Pressing this button takes you

directly to the controller “Alarms”

screen. See the “Alarms Button” sec-

tion on page 13 for a

description of this function.

Pressing this button takes you

directly to the controller

“Conﬁ guration” screens.

Pressing this button takes you

directly to the controller “Balance-

Test” screens.

Table 1: Keypad Descriptions

VCM-X / RNE Operator Interface SD

MODULAR SERVICE TOOL SD

Initialization & Setting the Time & Date

Modular Service Tool Initialization

Modular Service Tool Initialization Screen and Setup Screens

After connecting the Service Tool to the controller with the supplied cable, press <ON>. The Initialization Screen will appear followed by the Setup Screens as shown below. If there is no SD card installed, the second screen will display, “No SD Card Connected! Powering Down!”

Initializing

Service Tool vX.XX

WattMaster Controls

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

3) Energy Saving

4) Update Software

NEXT) More Options

ESC) Exit Menu

Although the times are displayed on the Main Screen in a standard 12- hour format, you must program them using the 24-hour military format. If you conﬁ gured the VCM-X or RNE Controller to use its own Internal Schedules, the Occupied/Unoccupied modes are calculated on the basis of the current real time clock reading.

The two screens that follow will appear. To scroll through the ﬁ elds, press

<> or <ENTER>. In order to save a new value, you must press

<ENTER>.

Program Time/Date

Day (Sunday=0): X Enter Hr. (0-23): XX Enter Minutes : XX

Day - Enter the Day of the Week (0 to 6) Sunday = 0

Hours (Hr) - Enter Hours in 24-Hour Military Format (1700 = 5:00 PM)

Minutes - Enter the Minutes (0 to 59)

Programming the Date

NOTE: Once you press <ESC> while at the Setup Screens shown

above, you can access them again by pressing <NEXT> or cycling power.

Setting The Time & Date

The Modular Service Tool is equipped with a real time clock chip allowing it to maintain the correct time. Once you have programmed the correct time and date, the information is broadcast globally to all controllers on the entire system.

NOTE: If you are in a time zone that has daylight savings, you

will need to manually adjust the time twice a year.

Programming the Time

From the Setup Screen shown below, press <1> on your keypad to access the Set Time & Date Screens. (You may have to press <NEXT> to access this screen.).

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

To scroll through the ﬁ elds, press <> or <ENTER>. In order to save a new value, you must press <ENTER>.

Program Time/Date

Month (1-12): XX Day (1-31): XX Year (0-99): XX

Month - Enter the Month (1 to 12) Day - Enter the Day of the Month (1 to 31) Year - Enter the current Year (0 to 99)

When you have ﬁ nished programming the time and date, press <ESC> to return to the Setup Screen shown below.

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

VCM-X / RNE Operator Interface SD

MODULAR SERVICE TOOL SD

Setting the Operating Mode and Energy Saving Timer

Setting the Operating Mode

The Operating Mode is displayed on the last line of the Main Screen as shown below. The factory default setting for the Service Tool is LS (Low Speed) Stand Alone Mode. LS Stand Alone Mode is the correct conﬁ guration for the VCM-X E-BUS Controller or RNE Controller when in Stand Alone Mode.

Service Tool SD vX.XX

Wednesday Operations

01/16/13 02:21 PM

LS Stand Alone *00*

If you are using this Service Tool on a communications loop and have an installed MiniLink PD or CommLink, you will need to change the setting to LS (Low Speed) Network Mode.

If your display indicates a different mode than the one you need, press

<2> at the Setup Screen shown below . Y ou may have to press <NEXT>

to access this screen.

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

The Communications Screen will appear as shown below.

Stand Alone Mode Lo Speed Connection Use Left/Right Arrow To Change Selections

Press <> or <> if you need to change the mode of operation.

Setting the Energy Saving Timer

The Modular Service T ool has a built-in timer that can be programmed to shut the Service T ool off after a speciﬁ ed period of time if no buttons are pressed. This is a very useful feature if you are powering the Service Tool from the internal batteries.

To set the Ener gy Saving T imer, press and

<3> at the second Setup Screen shown below. (You may have to

cycle power to get to these screens).

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

3) Energy Saving

4) Update Software

NEXT) More Options

ESC) Exit Menu

The Energy Saving Screen will appear as shown below:

Energy Saving

Automatic Power Down

Minutes: xx

Press ESC to Exit

Enter the number of minutes you want the Service Tool to stay active before it automatically powers down and press <ENTER>. To cancel the automatic power down, enter <99> and press <ENTER>. After you have entered a number between 1 and 99 minutes, press <ESC> to exit the screen.

The Setup Screen will appear again as shown below:

<NEXT> at the ﬁ rst Setup Scr een

When you have made your selection, press <ENTER>. The following screen will appear.

You Have Changed The

System Mode

Press Any Key To

Continue

Press any key to continue. The Setup Screen will appear as shown below:

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

VCM-X / RNE Operator Interface SD

MODULAR SERVICE TOOL SD

Alarm and Override Search

Modular Service Tool Alarm Search

NOTE: When you press the <ALARMS> button on the Modular

Service T ool, it will search only the unit ID that you have entered; therefore, you must search each unit individually to access all alarms for that controller.

To search for alarms, press < ALARMS>while on any screen but the Setup Screen(s). The Unit Selection Screen will be displayed.

Unit SelectionEnter

Unit ID#

Selected ID#: XXXX

*00*

Enter the Unit ID of the controller the Service T ool is connected to and press <ENTER>. Once communication is established, the *00* message

will go away. Then

NOTE: If the *00* remains, it indicates a communication failure

One of the following screens will appear:

press <>.

to the controller.

Modular Service Tool Override Search

When a space sensor with override option is used with any VAV/Zone or Unit Controller, the Modular Service Tool can determine and report any controllers that are currently operating in an override condition on a speciﬁ c Loop by entering a Loop ID number and then doing a search.

NOTE: When you press the <OVERRIDES> button on the

Modular Service Tool, it will search only the Loop number that you enter; therefore, you must search each loop individually to access all overrides.

To access the Overrides Screen, press Modular Service Tool’s keypad. A screen will appear asking you to enter the unit ID.

Unit Selection Enter Unit ID#

Selected ID#: 160

*00*

Enter the Unit ID for the MiniLink PD (MLPD) of the loop you wish to search. and press <ENTER>. The MLPD is always address 60 on each loop. So the unit ID of any particular MLPD would be the loop number followed by 60. In the example above, Loop 1, address 60 has been entered. Once communication is established, the *00* message

will go away. Then

press <>.

<OVERRIDES> from the

RNE or VCMX V.XXX

NO ALARMS

RNE or VCMX V.XXX

ALARMS PRESENT

SCROLL DOWN TO VIEW

Press <> to scroll through all the alarms for the controller that the Modular Service Tool is connected to.

To clear any alarms that are found, you must ﬁ x the problem indicated in the alarm. Once the problem is ﬁ xed, the alarm will clear from the screen the next time the unit is polled.

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

If communications are successful, one of the following screens will appear:

RNE or VCMX V.XXX

NO OVERRIDES

RNE or VCMX V.XXX

OVERRIDES PRESENT

SCROLL DOWN TO VIEW

After the Service Tool completes its search, it will post a message to tell you if there are overrides present. If there are overrides, press

and all units on the loop will be listed showing ‘Override: Yes or No.’ Press

<OVERRIDES> again to access overrides on a different loop.

Enter the Unit ID of the MLPD of that loop.

<>

VCM-X / RNE Operator Interface SD

MODULAR SERVICE TOOL SD

Schedules and Holidays

Scheduling

You can access the Unit Controller Scheduling Screens by pressing

<SCHEDULES>. The Unit Selection Screen will be displayed.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the Unit ID of the controller the Service T ool is connected to and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established, the *00* at the bottom will disappear.

Then

press <>.

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

Press the ing function you wish to view.

<> button and then press <ENTER> to access the schedul-

RNE Schedule Menu

Schedule Override Week Schedules Holidays

The screens will step through the Start Time and then the Stop Time for each day of the week. You can quit at any point in the process by pressing <ESC>. There are two Start/Stop events available per day, so the screen will show which event is being programmed. If you need only one event, keep Event #2’s times set at ZERO.

All times are in 24-hour military format, so 5:00 PM would be entered as 1700.

If both the Start and Stop Times are ZERO, the schedule is in a continuous OFF mode. (Also, use for Remote Forced Occupied applications

using the Forced Occupied Binary Input.)

If both the Start and Stop Times are 2359, the schedule is in a continuous ON mode.

NOTE: The second line displays which day of the week is cur-

rently being programmed. The day of the week automatically increments as you exit the Event #2 screen for the day and continue to the next day’s Event #1 screen.

CAUTION: The controller ships with all schedules set to

zero so that the controller will not attempt to heat or cool before you have conﬁ gured the system.

Holiday Start/Stop Day Selection

Week Schedules

Event #1

VCM-X Schd

Sunday Event #1 Start Time..: XXXX Stop Time...: XXXX

Event #2

VCM-X Schd

Sunday Event #2 Start Time..: XXXX Stop Time...: XXXX

If you are using the internal scheduling capability of the Unit Controller, set the schedule hours and holiday periods from the menu shown above. You can also force the unit to operate continuously in occupied or unoccupied mode by selecting the Schedule Override menu item and entering the desired command.

If you are using an external contact closure to signal the occupied mode, you must access the Week Schedule Screens and set all start and stop times to zero to prevent the internal schedule from turning the equipment on when you don’t want it to operate.

VCM-X Hldy

Holiday # 1 Start Mon/Day.: XXXX [ July 4

= 704 ]

VCM-X Hldy

Holiday # 1 Stop Mon/Day.: XXXX [ July 5

= 705 ]

The screens will step through the fourteen possible holidays, one period at a time. Line 2 shows which holiday is currently being programmed. Since a holiday period can encompass more than one day, you need to program the day the holiday starts and the day the holiday ends. If your holiday only lasts one day, simply set both the Start Day and the Stop Day to the same value. Remember to combine the month and day into a single four-digit value.

EXAMPLE: 704 = July 4

1225 = December 25

(NOTE: Leading zero not required)

VCM-X / RNE Operator Interface SD

MODULAR SERVICE TOOL SD

Holiday Scheduling and Schedule Override

Holiday Start/Stop Times

VCM-X Hldy

Holiday Schedule Start Event #1: XXXX Stop Event #1: XXXX

VCM-X Hldy

Holiday Schedule Start Event #2: XXXX Stop Event #2: XXXX

The fourteen holidays all use the same Start and Stop times which you program on this screen and the next. You must enter the time in 24-hour military format, the same as a regular week schedule.

Normally, the holidays will operate in an unoccupied mode or a reduced schedule mode. There are two start/stop events available on holidays to match the standard schedule number of events.

Schedule Override

VCM-X Ovrd

Schedule Override Enter Override...: X [0=Auto 1=ON 2=OFF]

If you want to force the unit to operate in a continuous Occupied or Unoccupied mode, select this menu item to activate the desired method. If a Schedule Override is active, all other methods of schedule control are ignored (Push-Button, Internal, and Remote).

As you can see on the last line of the display, enter ously in the Occupied Mode or <2> to run continuously in the Unoccupied Mode. To restore normal schedule operations, enter <0>.

This override remains in effect until canceled and does not time-out like the Output Overrides do after 10 minutes of no communications.

NOTE: Do not use the Force OFF mode in place of setting all

the week schedules to ZERO if you are using a Remote Signal for your scheduling since the Override has priority over the Remote Signal.

<1> to run continu-

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

System Manager SD Keys and Buttons

Zone

Operator Interfaces

In order to conﬁ gure and program the Orion System controllers, you must have an Operator’s Interface or a personal computer with the Prism 2 computer front-end software installed. Three different Operator Interfaces are available for programming of the Orion Controls System—the Modular Service T ool SD, the Modular System Manager SD, and/or the System Manager TS II. These devices allow you to access the status and setpoints of the controllers on your communications loop. This manual describes the Modular System Manager SD. If using the Modular Service Tool SD, please see the Modular Service Tool SD Quick Start Guide. If using the System Manager TS II, please see the System Manager TS II T echnical Guide. If using Prism 2, please see the Prism 2 T echnical Guide.

The Modular System Manager SD allows you to view any input or output status and change any setpoint to ﬁ ne-tune the operations of the total system. All keypad operations are simple and straightforward, utilizing non-cryptic plain English messages.

Display Screens & Data Entry Keys

See the chart below for a list of the keypad descriptions and functions.

Key Function

Keypad

Descrip-

Modular System Manager

tion

ESC

ENTER

Clear

Minus

DEC





Use this key to exit from screens or from data

entry or to return to the Main Screen from

any screen in the system.

Use this key to enter a new value.

If a data entry mistake is made, press this key

to clear the data entry ﬁ eld and start over.

If a setpoint with a negative value is required,

press this key for the minus sign.

Press this key when entering data that re-

quires a decimal point.

Use these keys to change values in the Con-

ﬁ guration Screens as prompted.

Use these keys to step backward or forward

through the screens.



Mode Selection Buttons

The Modular System Manager is provided with “Mode Selection Buttons.” These buttons give you instant access to the speciﬁ c mode desired without having to scroll through several menu screens to get there.

Button

Descrip-

tion

STATUS

SETPOINTS

SCHEDULES

OVERRIDES

ALARMS

Notes:

(1) This button only functions when the system is conﬁ gured for “Network Mode” or “Multiple MGRS Mode.” It will not function in “Stand Alone Mode.”

(2) The “Search for Units” function must be performed on the System Manager upon initial system setup before this function will be available. See the “Network Mode & Multiple Managers Loop Search” on page 20 of this manual for complete instructions on performing a loop search.

Table 4: Button Descriptions

Modular System Manager

Pressing this button takes you directly to

the controller “Status” screens.

Pressing this button takes you directly to

the controller “Setpoints” screens and

“Conﬁ guration” menu.

Pressing this button takes you directly to

the controller “Schedules” screens.

Pressing this button takes you directly to

the controller “Overrides” screen. See the

“Override Button” section on page 21 for a

description of this function.

See Notes 1 & 2 below.

Pressing this button takes you directly to

the controller “Alarms” screen. See the

“Alarms Button” section on page 21 for a

description of this function.

See Notes 1 & 2 below.

Table 3: Keypad Descriptions

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

Initialization & Setting the Time & Date

System Manager SD Initialization

System Manager SD Initialization Screen and Setup Screens

After connecting the System Manager to the controller with the supplied cable, press <ON>. The Initialization Screen will appear followed by the Setup Screens as shown below. If there is no SD card installed, the second screen will display, “No SD Card Connected! Powering Down!”

NOTE: After exiting these screens, you can access them again

by pressing <ESC> and then <> or by cycling power.

INITIALIZING

System Manager SD

vX.XX

WattMaster Controls

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

Programming the Time

From the Setup Screen shown below, press <1> on your keypad to access the

Set Time & Date Screens.

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

Although the times are displayed on the Main Screen in a standard 12-hour format, you must program them using the 24-hour military format. If you conﬁ gured the Unit Controller to use its own Internal Schedules, the Occupied/Unoccupied modes are calculated on the basis of the current real time clock reading.

The two screens that follow will appear. T o scroll through the ﬁ elds, press <> or

<ENTER>. In order to save a new value, you must

press <ENTER>.

Program Time/Date

Day (Sunday=0): X Enter Hr. (0-23): XX Enter Minutes : XX

3) Change Passcodes

4) Loop Search

NEXT) More Options

ESC) Exit Menu

5) Alarm Search

NEXT) More Options

ESC) Exit Menu

Setting The Time & Date

The System Manager SD is equipped with a real time clock chip allowing it to maintain the correct time. Once you have programmed the correct time and date, the information is broadcast globally to all controllers on the entire system.

NOTE: A Level 1 or Level 2 User can set the time and date.

NOTE: If you are in a time zone that has daylight savings, you

will need to manually adjust the time twice a year.

Day - Enter the Day of the Week (0 to 6) Sunday = 0

Hours (Hr) - Enter the Hour (0-23) in 24-Hour Military Format (13 = 1:00 PM)

Minutes - Enter the Minutes (0 to 59)

Programming the Date

To scroll through the ﬁ elds, press <> or <ENTER>. In order to save a new value, you must press

Program Time/Date

Month (1-12): XX Day (1-31): XX Year (0-99): XX

<ENTER>.

Month - Enter the Month (1 to 12) Day - Enter the Day of the Month (1 to 31) Year - Enter the current Year (0 to 99)

VCM-X / RNE Operator Interface SD

When you have ﬁ nished programming the time and date, press <ESC> to return to the Setup Screen.

SYSTEM MANAGER SD

Setting the Operating Mode

Zone

Setting the Operating Mode

The Operating Mode is displayed on the last line of the Main Screen as shown below. The factory default setting for the System Manager is LS (Low Speed) Stand Alone Mode.

System Manager SD

Wednesday Operations

01/16/13 02:21 PM

LS Stand Alone Mode

The System Manager must be conﬁ gured for the correct mode of op- eration for your system. There are 5 modes of operation available for the Orion System—LS (Low Speed) Stand-Alone, HS (High Speed)

Stand-Alone, LS (Low Speed) Network, HS (High Speed) Network, and LS (Low Speed) & HS (High Speed) Multiple MGRS.

If you are using this System Manager on a communications loop that doesn’t have a MiniLink PD or CommLink connected to it and you have a single System Manager on your system, then you need to operate in LS (Low Speed) Stand-Alone Mode. If you are using a VCB-X Controller or GPC-XP Controller that is set for high speed, and you don’t have a MiniLink PD or CommLink connected to the loop, then you will need to change the setting to HS (High Speed) Stand Alone Mode.

If you are using the System Manager on a communications loop and have an installed MiniLink PD or CommLink, you will need to change the setting to LS (Low Speed) Network Mode. If you are using a VCBX Controller or GPC-XP Controller that is set for high speed, and are using a MiniLink PD or CommLink, then you will need to change the setting to HS (High Speed) Network Mode.

THIS ACTION REQUIRES

A SPECIAL HIGH LEVEL

PASSCODE CLEARANCE

Enter: XXXXXXX

Enter the seven digit passcode <2337377> to access the next screen. You will then see the screen below displayed.

Stand Alone Mode Lo Speed Connection Use Left/Right Arrow To Change Selections

Press < > or < > if you need to change the mode of op-

eration to LS (Low Speed) Stand-Alone, HS (High Speed) Stand-Alone, LS (Low Speed) Network, HS (High Speed) Network, LS (Low Speed) Multiple Manager or HS (High Speed) Multiple Manager and then press

<ENTER> to save

your selection. If you are not using Multiple Manager Mode, press

<ESC>

at the screen below and continue scrolling right and left.

Multiple Manager

Unit Address: 0

Press ESC to Exit

If you are using this System Manager on a communications loop, have a MiniLink PD or CommLink installed, and have multiple System Managers, then you need to operate in Multiple MGRS Mode.

If your display indicates a different mode than the one you need, press

<2> at the Setup Screen shown below. You will have to cycle power to

get to this screen or by pressing

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

The Passcode Clearance Screen will appear as shown below.

<ESC> and <PREV>.

For Multiple MGRS Mode, enter the address at which you want this particular System Manager to be set.

When multiple System Managers are used on a local loop, each must be set with a unique address different from any other device on that loop. You must perform this same operation again for each System Manager installed. If you want one of these System Managers to be able to indicate alarms and overrides for the entire system, you must select either LS or HS Network Mode on that particular System Manager.

Once you have the correct number per the display above displayed, press

<ENTER>. The following screen will appear telling you that you have

changed the system mode:

You Have Changed The

System Manager Mode

Press Any Key To

Continue

Press any key on the keyboard to exit this screen.

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

Changing Passcodes

System Manager Passcodes

Changing the mode of operation, updating software, changing schedules, and changing setpoints and conﬁ gurations require passcode clearance. The screen below will appear if this action requires passcode clearance.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

The System Manager has three levels of user access. All users can view Status Screens. Level 1 users are limited to changing the Time and Date and Operating Schedules. Level 2 users have complete system access. Any status or setpoint ﬁ eld can be read or reset from the System Manager.

These two levels of passcodes are programmable by any Level 2 user. The default Level 1 passcode is “ 11 11” and the default Level 2 passcode is “ 2222.”

If you wish to change either Level 1 or Level 2 passcodes, please see the instructions that follow.

From the Main Status Screen, press The following screen will appear:

<ESC> and then press <PREV>.

Passcodes can only be changed by a Level 2 user. Enter the passcode and press

This screen allows you to enter new Level 1 and/or Level 2 passcodes. Passcodes must always be four digits in length, so the usable range of numbers is 1000 to 9999.

<ENTER>. The following screen will appear:

Enter New Passcode

Level 1.....: XXXX

Level 2.....: XXXX

[Must Be 4 Digits]

CAUTION: If you change the Level 2 passcode and can- not remember what it is, you will be locked out of your system!

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

Press <> for the Next Menu. The following screen will be displayed:

3) Change Passcodes

4) Loop Search

NEXT) More Options

ESC) Exit Menu

Press <3> for Change Passcodes. The following screen will be displayed:

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

Loop Search and System Alarm Search

Zone

Network Mode & Multiple Managers Loop Search

When the System Manager is conﬁ gured for Network Mode, a loop search must initially be performed for the System Manager to recognize alarms or overrides. Also, when you have a system that has multiple System Managers and you have one of the System Managers set to (63) Network Mode for alarm and override indication, you must also perform a loop search for that System Manager. This allows the System Manager to be aware of all alarms and overrides for all local loops on the entire system.

To access the Loop Search Screen, from the Setup Screen Scr een, press

<ESC> and then press <PREV>.

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

Press <> for Next Menu. The following screen will be displayed:

3) Change Passcodes

4) Loop Search

NEXT) More Options

ESC) Exit Menu

System Alarm Search

The System Manager can be used to search for all active alarms on the system. You must conﬁ gure the MiniLink PD to allow for “ Alarm Poll- ing” for each controller you want polled for alarms. See the MiniLink PD programming section on page 75 of this manual for setting information.

This option will alert you of the number of alarms present on individual units, but will not tell you what type of alarm are present. Y ou will have to perform and individual unit alarm search for detailed alarm information.

To access the Alarm Search Screen, from the Setup Screen Scr een, press

<ESC> and then press <PREV>.

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

Press <> for Next Menu. The following screen will be displayed:

3) Change Passcodes

4) Loop Search

NEXT) More Options

ESC) Exit Menu

Press <4> for Loop Search. The following screen will be displayed:

Loop Search Current Loop = XX Loops Found = XX

Searching

The System Manager will now proceed to search all loops to ﬁ nd the MiniLink PDs that are connected to the system. The screen will display the current loop being searched and the number of loops currently found.

Once the search is completed, the following screen will be displayed:

Loop Search

Finished

Loops Found = XX

Press ESC to Exit

The screen will display the number of loops found on your system. The information will be saved into the System Manager’s memory . No further loop searches will be required unless you add an additional MiniLink PD to the Network System.

Press <> for Next Menu. The following screen will be displayed:

5) Alarm Search

NEXT) More Options

ESC) Exit Menu

Press <5> for Alarm Search. The entire system is searched from this point. The following screen will be displayed:

Alarm Screen

SEARCHING!

Once the Alarm Search is complete, one of the following screens will display:

Alarm Screen

XX ALARMS ON UNIT XX

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

Unit Alarm Search and Override Search

Alarm Screen

NO ALARMS DETECTED

To check controllers individually for alarms, use the <ALARMS> button on the Main Display.

Unit Alarm Search

The System Manager can be used to search for all active alarms one controller at a time.

Press <ALARMS>. The Unit Selection Screen below will be displayed.

Unit Selection *00*

Enter Unit ID#

Selected ID#: XXXX

Enter the Unit ID of the controller you wish to search and press <EN-

TER>. Y ou must type in the number , even if it is “1”. Once communica-

tion is established, the *00* at the top will disappear. Then

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

The following screen will appear. The System Manager will search for any active alarms on the unit and one of the following screens will appear:

press <>.

System Manager Override Search

NOTE: In order for the Override Search to work, a Loop Search

must be performed ﬁ rst. See page 20 for details.

When a space sensor with override option is used with any VAV/Zone Controller or Unit Controller, the System Manager can determine and report any controllers that are currently operating in an override condition. This function requires that a MiniLink PD is installed on each loop where the controllers may be located. The MiniLink PD must be conﬁ gured to allow for “Alarm Polling” for each controller that Override Polling Enabled is desired for this function to work. See the MiniLink PD programming section on page 75 of this manual for setting information.

To access the Space Sensor Overrides Screen, press The following screen will appear.

Overrides Screen

SEARCHING!

After the System Manager completes its search, it will list the ﬁ rst unit on the system that is currently in the override mode. Press the

button to scroll through all units that are in the Override Mode.

Overrides Screen

Loop = 1 Unit = 59

OVERRIDE FOUND

<OVERRIDES>,

<>

CONTROLLER V.XXX

NO ALARMS

CONTROLLER V.XXX

ALARMS PRESENT

SCROLL DOWN TO VIEW

Press <> to scroll through all the alarms for the controller that the Modular Service Tool is connected to.

To clear any alarms that are found, you must ﬁ x the problem indicated in the alarm. Once the problem is ﬁ xed, the alarm will clear from the screen the next time the unit is polled.

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

Schedules and Holidays

Zone

Scheduling

Y ou can access the Controller Scheduling Screens by pressing <SCHED-

. The screen below will appear because Scheduling requires

ULES>

passcode clearance. A Level 1 or 2 passcode can change schedules.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection*00*

Enter Unit ID#

Selected ID#: XXXX

Enter the Unit ID of the controller you wish to change schedules for

press <ENTER>. Once communication is established, the *00*

and message will go away. Then

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

The Unit Schedule Menu will be displayed.

Schedule Menu Schedule Override Week Schedules

Holiday Schedules

press <>.

Week Schedules

From the Unit Schedule Menu, select Week Schedules. The following two screens will appear in order:

Event #1

Schd

Sunday Event #1 Start Time..: XXXX Stop Time...: XXXX

Event #2

Schd

Sunday Event #2 Start Time..: XXXX Stop Time...: XXXX

If you are using the internal scheduling capability of the Controller, set the schedule hours and holiday periods from the menu shown above. Y ou can also force the unit to operate continuously in occupied or unoccupied mode by selecting the Schedule Override menu item and entering the desired command.

Press the <> button until the cursor is on the desired option and then

press <ENTER>.

All times are in 24-hour military format, so 5:00 PM would be entered as 1700.

If both the Start and Stop Times are ZERO, the schedule is in a continuous OFF mode. (Use for Remote Signal Contact.)

If both the Start and Stop Times are 2359, the schedule is in a continuous ON mode.

NOTE:

The second line displays which day of the week is currently being programmed. The day of the week automatically increments as you exit the Event #2 screen for the day and continue to the next day’s Event #1 screen.

CAUTION: The controller ships with all schedules set to

zero so that the controller will not attempt to heat or cool before you have conﬁ gured the system.

VCM-X / RNE Operator Interface SD

SYSTEM MANAGER SD

Holiday Scheduling and Schedule Override

Holiday Start/Stop Day Selection

From the Unit Schedule Menu, select Holiday Schedules. The following four screens will appear in order:

Hldy

Holiday # 1 Start Mon/Day.: XXXX [ July 4

Stop Mon/Day.: XXXX [ July 5

EXAMPLE: 704 = July 4

= 704 ]

Hldy

Holiday # 1

= 705 ]

(NOTE: Leading zero not required) 1225 = December 25

Schedule Override

From the Unit Schedule Menu, select Schedule Override. The following screen will appear:

Ovrd

Schedule Override Enter Override...: X [0=Auto 1=ON 2=OFF]

As you can see on the last line of the display, enter <1> to run continu- ously in the Occupied Mode or cupied Mode. To restore normal schedule operations, enter

This override remains in effect until canceled and does not time-out like the Output Overrides do after 10 minutes of no communications.

NOTE:

Do not use the Force OFF mode in place of setting

<2> to run continuously in the Unoc-

<0>.

all the week schedules to ZERO if you are using a Remote Signal for your scheduling since the Override has priority over the Remote Signal.

Holiday Start/Stop Times

Hldy

Holiday Schedule Start Event #1: XXXX Stop Event #1: XXXX

Hldy

Holiday Schedule Start Event #2: XXXX Stop Event #2: XXXX

The fourteen holidays all use the same Start and Stop times which you program on this screen and the next. You must enter the time in 24-hour military format, the same as a regular week schedule.

Normally, the holidays will operate in an unoccupied mode or a reduced schedule mode. There are two start/stop events available on holidays to match the standard schedule number of events.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screen Index

Zone

VCM-X Conﬁ guration Screen Index

NOTE: For RNE Conﬁ guration Screens, see page 34.

The available Conﬁ guration Screens for the VCM-X Controller are listed on the next few pages by sequential screen number. When each VCM-X Controller is conﬁ gured for the ﬁ rst time, it is best to start with screen #1 and proceed to each screen in numerical order until you have viewed all available Conﬁ guration Screens. This ensures that you have seen all the available VCM-X Controller conﬁ guration possibilities and have the opportunity to change or accept the defaults for each screen.

Once the unit is conﬁ gured and you decide to change one of the screen options, it is helpful to know what screen number contains the conﬁ gu- ration you wish to change. With this in mind, the following is a list of all the VCM-X Conﬁ guration Screens in numerical order with a brief listing of the conﬁ guration feature available on each screen.

Screen #1 Duct Static Pressure Control Screen #2 Supply Fan Cycle Mode Screen #3 HVAC Mode Enable Screen #4 HVAC Reset Source Screen #5 Reset Interval Rate Screen #6 Dehumidiﬁ cation Control Screen #7 Dehumidiﬁ cation Priority Screen #8 Dehumidiﬁ cation Unoccupied Screen #9 Outdoor Humidity Sensor Screen #10 Indoor Humidity Sensor Screen #11 Heat During Dehumidify Screen #12 Economizer Control Screen #13 Title 24 Economizer Screen #14 Proof of Flow Input Screen #15 Modulating Cooling/Heating Screen #16 Modulating Heat Output Signal Screen #17 Modulating Heat Reverse Acting Screen #18 Modulating Heat Proportional Window Screen #19 Modulating Cooling Output Signal Screen #20 Digital Compressor Signal Screen #21 Modulating Cooling Reverse Acting Screen #22 Modulating Cool Proportional Window Screen #23 Head Pressure Module Installed

(VCM-X E-BUS)

Screen #24 Type of Head Pressure Module: 1 or 2 Condenser (VCM-X E-BUS)

Screen #25 Full Digital Module Installed/WSHP with Multiple Digital Scroll Compressors OR Dual Digital Module/WSHP with Two Digital Scroll Compressors Installed (VCM-X E-BUS)

Screen #26 Type of Airﬂ ow Station Screen #27 Monitor Outdoor Air CFM Screen #28 Control Outdoor Air CFM Screen #29 Outdoor Duct/Damper Size Screen #30 Monitor Return Air CFM Screen #31 Return Duct/Damper Size Screen #32 Monitor Supply Air CFM Screen #33 Supply Duct/Damper Size Screen #34 CO Screen #35 CO Screen #36 Building Pressure Modulating Control Screen #37 Building Pressure Reverse Acting Screen #38 Building Pressure Output Signal Screen #39 Heat Pump Control

Screen #40 Reversing Valve Active For Heat/Cool Screen #41 Emergency Shutdown Input Screen #42 Return Air Bypass Control Screen #43 Broadcast Outdoor Temperature Screen #44 Broadcast Outdoor Humidity Screen #45 Broadcast Supply Temperature Screen #46 Broadcast Status Fan & Heat Screen #47 Broadcast Internal Time Clock Screen #48 Broadcast Internal Schedule Screen #49 Broadcast VAV Boxes Force to Max Screen #50 Broadcast VAV Boxes Force to Fixed Screen #51 1 HVAC Unit w/Boxes on Multiple Loops Screen #52 Unit Uses R410A Refrigerant Screen #53 Main Fan Maximum Voltage Screen #54 Micro Channel Condensers Screen #55 Preheat-X Controller Installed Screens #56-59 Cooling & Heating Staging Delays Screens #60-79 Relay Conﬁ guration Screens

Sensor Output Signal

Sensor Maximum Scale

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Conﬁ guration Screens

In order to correctly set up the VCM-X Controller, you must ﬁ rst con- ﬁ gure several parameters in regard to the type of HV AC unit and system

you have installed. Most of these values and operating parameters are only set once at the initial system setup and are never changed.

Modular Service Tool SD Instructions

No matter what screen or menu you’re in, press <CONFIGURATION>. The Unit Selection Scr een will appear , shown below, requesting that you enter the unit ID number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the correct unit ID number of the VCM-X Controller you want to conﬁ gure and then press <ENTER>. Y ou must type in the number , even if it is “1”. Once communication is established, the *00* at the bottom

will disappear. Then Screen #1. Press

scroll through the screens.

press <>. You will then see Unit Conﬁ guration

<ENTER> to save entered data and press <> to

The following screen will be displayed:

Change Setpoints

Configure Unit

Save/Copy/Restore

Scroll down to the ‘Conﬁ gure Unit’ option and press <ENTER>. This will take you to the ﬁ rst Conﬁ guration Screen shown below.

Conﬁ guration Screen #1 - Duct Static Pressure

VCM-X Cnfg ID 59

Duct Static Pressure

Control: YES

Use < Or > To Change

If the HVAC unit has a Supply Fan that delivers a Constant Volume of air, select NO. If the HVAC unit has a Supply Fan that delivers a Variable Volume of Air using a VFD or a Bypass Damper, select YES. Default is YES.

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection *00*

Enter Unit ID#

Selected ID#: XXXX

Enter the Unit ID of the controller you wish to change schedules for and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established, the *00* at the top will disappear.

Then

press <>.

Conﬁ guration Screen #2 - Supply Fan Cycle

VCM-X Cnfg ID 59 Supply Fan Cycle

Mode: NO

Use < Or > To Change

If you want the HVAC unit’s Supply Fan to run during Heating, Cooling, or Dehumidiﬁ cation Modes, select YES. If you want the HVAC unit’s Supply Fan to run continuously while in the Occupied Mode, regardless of the Heating, Cooling, or Dehumidiﬁ cation Modes, select NO. Default is NO.

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Zone

Conﬁ guration Screen #3 - HVAC Mode Enable

VCM-X Cnfg ID 59 HVAC Mode Enable

Supply Air

Use < Or > To Change

Select the T emperature Sensor that will determine the Heating, Cooling, or Vent Mode of operation. The selections are:

 Supply Air

This is typical for VAV applications. Occupied Cooling with Morning Warm-up.

 Outdoor Air

This is for 100% Outdoor Air (MUA) units. Dehumidiﬁ cation utilizes a Dewpoint Calculation if equipped with an Outdoor Air Humidity Sensor.

 Space Temperature

This is for any unit that conditions a space and is not 100% Outdoor air. Occupied/Unoccupied Heating, Cooling, and Vent Modes of operation.

 Return Air

This selection can be used when an Average Building Temperature (the Return Air Temperature) needs to determine Heating, Cooling, and Vent Modes of operation.

 Supply Air/Tempering

This selection is for VAV “cooling only” applications where because of cold outdoor temperatures, even at minimum damper position, you may need to enable heat to maintain the cooling near its Cooling Supply Air Setpoint. When heat is enabled during this sequence, it will control to a non-adjustable setpoint that is 2ºF less than the Cooling Supply Air Setpoint. Includes a Morning Warm-up sequence.

Conﬁ guration Screen #4 - HVAC Reset Source

VCM-X Cnfg ID 59

HVAC Reset Source

No Reset

Use < Or > To Change

Conﬁ guration Screen #5 - Reset Interval Rate

VCM-X Cnfg ID 59

Reset Interval

Rate...: 20 s

[1-255 Seconds]

If you selected Space or Return Air Temperature Reset in Screen #4, enter a value in seconds between 1-255. This value determines how fast the Supply Air Temperature Setpoint is adjusted as the Reset Source changes. Default is 20 seconds.

Conﬁ guration Screen #6 - Dehumidiﬁ cation Control

VCM-X Cnfg ID 59 Dehumidification

Control: NO

Use < Or > To Change

Select YES if your system requires Dehumidiﬁ cation Control. Default is NO.

Conﬁ guration Screen #7 - Dehumidiﬁ cation Priority

VCM-X Cnfg ID 59 Dehumidification

Priority: NO

Use < Or > To Change

Select YES if Dehumidiﬁ cation is a Priority during the Occupied Mode. Priority means that the Cooling stages will activate based on Coil T emperature and Reheat will be used regardless of Heating, Cooling, or V ent Modes of Operation. Default is NO.

Conﬁ guration Screen #8 - Dehumidiﬁ cation Unoccupied

The Supply Air Heating and Cooling Temperature Setpoints can be reset using various input sources. Default is No Reset. Select the desired Reset Source for Supply Air Temperature Reset. The Single Zone VAV option should be selected in applications where the Supply Fan VFD speed is reset based on the Space Temperature. If you select No Reset, then neither the Supply Air Setpoint nor the Supply Fan VFD Reset will occur. The selections are:

 No Reset  Fan VFD Percentage  Space Sensor  Outdoor Sensor  Return Air Sensor  Single Zone (SZ) VAV  Remote Reset Signal  SZ VAV with CV Heating

VCM-X Cnfg ID 59 Dehumidification

Unoccupied: NO

Use < Or > To Change

Select YES if Dehumidiﬁ cation is required during the Unoccupied mode. Unoccupied Dehumidiﬁ cation is activated based on Indoor Air Humidity only. Default is NO.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Conﬁ guration Screen #9 - Outdoor Humidity Sensor

VCM-X Cnfg ID 59

Outdoor Humidity

Sensor: NO

Use < Or > To Change

Select YES if the HVAC unit is equipped with an Outdoor Air Humidity Sensor. Default is NO.

Conﬁ guration Screen #10 - Indoor Humidity Sensor

VCM-X Cnfg ID 59

Indoor Humidity

Sensor: NO

Use < Or > To Change

Select YES if the HVAC unit is equipped with an Indoor Air Humidity Sensor. Default is NO.

Conﬁ guration Screen #11 - Heat During Dehumidify

Conﬁ guration Screen #13 - Title 24 Economizer

VCM-X Cnfg ID 59

Title 24

Economizer: NO

Use < Or > To Change

If this unit has Title 24 Economizer operation, this option should be conﬁ gured as YES. Default is NO.

Conﬁ guration Screen #14 - Proof of Flow Input

VCM-X Cnfg ID 59

Proof Of Flow

Input: NO

Use < Or > To Change

Select YES if the unit is equipped with a Proof of Flow Switch and it is connected to the VCM-X. If selected as YES and the Proof of Flow Switch is open, only the Supply Fan Relay will be active. If any other relays such as Heating Stages or Cooling Stages are active, they will be deactivated when the Proof of Flow Switch input is lost. Default is NO.

Conﬁ guration Screen #15 - Modulating Cooling/ Heating

VCM-X Cnfg ID 59

Heat During

Dehumidify: NO

Use < Or > To Change

Select YES if your application needs to use unit heat during Dehumidiﬁ cation to supplement Reheat. If Reheat is not available, this selection will allow unit heat to operate in place of Reheat. Default is NO.

Conﬁ guration Screen #12 - Economizer Control

VCM-X Cnfg ID 59

Economizer

Control: NO

Use < Or > To Change

Select YES if the VCM-X is controlling the Economizer . Default is NO.

VCM-X Cnfg ID 59

Mod Cooling: NO Mod Heating: NO

Use < Or > To Change

Select YES if the HVAC unit is controlling Modulating Heating or Modulating Cooling or both. If your HV AC unit is going to use a Modulating Chilled Water Valve or is equipped with a Digital Compressor, you must select YES for Modulating Cooling. If your HVAC is using a Modulating Hot Water Valve, Modulating Steam Valve, or a SCR Controlled Electric Heater, you must select YES for Modulating Heating. This conﬁ guration does not apply to MODGAS using the MODGAS Controller. Default is NO.

Conﬁ guration Screen #16 - Modulating Heating Output Signal

VCM-X Cnfg ID 59

Mod Heating

Output Signal.: 0-10V

Use < Or > To Change

Select 0-10 VDC or 2-10 VDC as the output signal for a Modulating Heat Source such as a Hot W ater Valve or SCR Electric Heater. Default is 0-10 VDC.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Zone

Conﬁ guration Screen #17 - Modulating Heating Reverse Acting

VCM-X Cnfg ID 59

Mod Heating

Rev Acting: NO

Use < Or > To Change

Select YES if the Modulating Heat Source requires 0 VDC to open and 10 VDC to close. Default is NO.

Conﬁ guration Screen #18 - Modulating Heating Proportional Window

VCM-X Cnfg ID 59

Mod Heating

Prop. Window.: 10ºF

Time Period..: 5 s

The Modulating Heating Proportional Window is the control range of the Modulating Signal above and below the Active Supply Air Setpoint. The larger the Modulating Heating Proportional Window, the smaller the signal adjustment per Time Period will be for each ºF the supply air is from the Active Supply Air Temperature Setpoint. The Time Period is the delay before another signal increase or decrease can be made and is user-adjustable. Short Time Periods may cause hunting of the Modulating Signal. Defaults are 10ºF and 5 seconds.

Conﬁ guration Screen #21 - Modulating Cooling Reverse Acting

VCM-X Cnfg ID 59

Mod Cooling

Rev Acting: NO

Use < Or > To Change

Select YES if the Modulating Cooling Source requires 0 VDC to open and 10 VDC to close. You cannot use a Reverse Acting Signal if a Digital Compressor is being used. Default is NO.

Conﬁ guration Screen #22 - Modulating Cooling Proportional Window

VCM-X Cnfg ID 59 Mod Cooling Prop. Window.: 10ºF Time Period..: 30 s

The Modulating Cooling Proportional Window is the control range of the Modulating Signal above and below the Active Supply Air Setpoint. The larger the Modulating Cooling Proportional Window, the smaller the signal adjustment per Time Period will be for each ºF the supply air is from the Active Supply Air Temperature Setpoint. The Time Period is the delay before another signal increase or decrease can be made and is user-adjustable. Short Time Periods may cause hunting of the Modulating Signal. Defaults are 10ºF and 30 seconds.

Conﬁ guration Screen #19 - Modulating Cooling Output Signal

VCM-X Cnfg ID 59

Mod Cooling Output Signal: 0-10V Use < Or > To Change

Select 0-10 VDC as the output signal for a Modulating Cool source such as a Chilled Water Valve. Select 2-10 VDC as the output signal to a Chilled Water Valve. Default is 0-10 VDC.

Conﬁ guration Screen #20 - Digital Compressor Signal

VCM-X Cnfg ID 59

Digital Compressor

Signal 1-5V : NO

Use < Or > To Change

Select YES if the HVAC unit is equipped with a Digital Compressor. Default is NO.

Conﬁ guration Screen #23 - Head Pressure Module Installed

VCMX-M/HP Cnfg ID 102

Head Pressure

Module: NO

Use < Or > To Change

Select YES if you have a Head Pressure Module installed. This screen only applies if using the VCM-X E-BUS Controller. Default is NO.

Conﬁ guration Screen #24 - Type of Head Pressure Module Installed

VCMX-M/HP Cnfg ID 102

Type of Head Pr.

Module: 1 Condenser

Use < Or > To Change

Select 1 Condenser or 2 Condenser if you have a Head Pressure Module installed. This screen only applies if using the VCM-X E-BUS Controller. Default is 1 Condenser.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Conﬁ guration Screen #25 - Full Digital Module/ WSHP w/Multiple Digital Scroll Compressors OR Dual Digital Module/WSHP w/2 Digital Scroll Compressors Installed

VCMX-M/HP Cnfg ID 102

Full Digital Module

Installed: NO

Use < Or > To Change

If a VCM-X E-BUS Controller is being used, this screen will appear. Select YES if you have either a Full Digital Module installed or if you have a Water Source Heat Pump Module installed and in both cases all the compressors in the unit are Digital Scroll Compressors (2 Digital Compressors only or all 4 Digital Compressors). If you have a combination of Digital Compressors and Fixed Compressors, select NO.

VCMX-M/HP Cnfg ID 102

Dual Digital Module

Installed: NO

Use < Or > To Change

If a VCM-X E-BUS Controller is being used, this screen will appear. Select YES if you have a Dual Digital Module installed or if the VCM-X WSHP Controller has two Digital Scroll Compressors.

Conﬁ guration Screen #28 - Control Outdoor Air CFM

VCM-X Cnfg ID 59

Control Outdoor

Air CFM: NO

Use < Or > To Change

Select YES if you want to control the Outdoor Air Damper to a CFM setpoint. Default is NO.

Conﬁ guration Screen #29 - Outdoor Duct/ Damper Size

VCM-X Cnfg ID 59

Outdoor Duct/Damper

Size: 0.00

[Area in sq. ft.]

For the controller to properly calculate the outside air CFM you need to enter the inside area (sq. ft.) of the outdoor air duct/damper. When measuring the outdoor air damper area, be sure to measure the inside dimensions of the damper. The more accurate the measurements, the more accurate the CFM reading will be. This value needs to be accurate to 2 decimal places. Default is 0.00.

Conﬁ guration Screen #26 - Type of Airﬂ ow Station

VCM-X Cnfg ID 59

Airflow Station:

Paragon

Use < Or > To Change

Select the type of Airﬂ ow Monitoring Station you are using, if any. Selections are Paragon or Ebtron. Choose Ebtron for Greentrol. Default is Paragon.

Conﬁ guration Screen #27 - Monitor Outdoor Air CFM

VCM-X Cnfg ID 59

Monitor Outdoor

Air CFM: NO

Use < Or > To Change

Select YES if you have an Airﬂ ow Monitoring station measuring the CFM of the Outdoor airﬂ ow stream of this unit. Default is NO.

Conﬁ guration Screen #30 - Monitor Return Air CFM

VCM-X Cnfg ID 59

Monitor Return

Air CFM: NO

Use < Or > To Change

Select YES if you have an airﬂ ow monitoring station measuring the CFM of the return airﬂ ow stream of this unit. Default is NO.

Conﬁ guration Screen #31 - Return Duct/ Damper Size

VCM-X Cnfg ID 59

Return Duct/Damper

Size: 0.00

[Area in sq. ft.]

For the controller to properly calculate the return air CFM, you need to enter the area in square feet of the return air duct/damper . When measur ing the return air damper area, be sure to measure the inside dimensions of the damper. The more accurate the measurements, the more accurate the CFM reading will be. This value needs to be accurate to 2 decimal places. Default is 0.00.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Zone

Conﬁ guration Screen #32 - Monitor Supply Air CFM

VCM-X Cnfg ID 59

Monitor Supply

Air CFM: NO Use < Or > To Change

Select YES if you have an airﬂ ow monitoring station measuring the CFM of the supply airﬂ ow stream of this unit. Default is NO.

Conﬁ guration Screen #33 - Supply Duct/ Damper Size

VCM-X Cnfg ID 59

Supply Duct/Damper

Size: 0.00

[Area in sq. ft.]

For the controller to properly calculate the supply air CFM, you need to enter the area in square feet of the supply air duct/damper. When measuring the supply duct damper area, be sure to measure the inside dimensions of the damper. The more accurate the measurements, the more accurate the CFM reading will be. This value needs to be accurate to 2 decimal places. Default is 0.00.

Conﬁ guration Screen #34 - CO2 Sensor Output Signal

VCM-X Cnfg ID 59

CO2 Sensor

Output Signal: None

Use < Or > To Change

The VCM-X needs to know what type of CO2 sensor signal output is being provided. Select either 0-10 VDC (standard sensor used) or 4-20 mA as the CO Default is None.

sensor signal. Select None if no CO2 sensor is used.

Conﬁ guration Screen #36 - Building Pressure Modulating Control

VCM-X Cnfg ID 59

Building Pressure

Mod Control: NO

Use < Or > To Change

Select YES if Modulating Building Pressure Control is needed. Modulating Building Pressure Control is used for a VFD Exhaust Fan or a Modulating Exhaust Fan Damper Actuator for Direct Acting Building Pressure Control. Modulating Building Pressure Control is also used for a modulating outdoor air damper actuator for Reverse Acting Building Pressure Control. Select NO if Modulating Building Pressure Control is not needed when using a Constant Volume Exhaust Fan for On/Off Control. Default is NO.

Conﬁ guration Screen #37 - Building Pressure Reverse Acting

VCM-X Cnfg ID 59

Building Pressure

Rev Acting: NO

Use < Or > To Change

Select YES if Reverse Acting Building Pressure control is needed. Reverse Acting Building Pressure Control can either be On/Off or Modulating Control. Modulating Control is normally used for this conﬁ guration. On a drop in Building Pressure, below the Building Static Pressure Setpoint, the Outdoor Air Damper will modulate open to increase pressure. Default is NO.

Conﬁ guration Screen #38 - Building Pressure Output Signal

VCM-X Cnfg ID 59

Building Pressure Output Signal: 0-10V Use < Or > To Change

Conﬁ guration Screen #35 - CO2 Sensor Maximum Scale

VCM-X Cnfg ID 59

CO2 Sensor Maximum

Scale: 2000 PPM

Enter 0 If No Sensor

The VCM-X needs to know the CO2 Sensor scaling for proper reading of the CO2 Sensor output. The Standard CO2 Sensor should be scaled to 2000 PPM. Select None if no CO2 sensor is used. Default is 2000 PPM.

This Screen is used to conﬁ gure the Building Pressure Output Signal voltage needed for your application. Select either a 0-10 VDC signal (default) or a 2-10 VDC signal as required by the device you are using to control the pressure. Default is 0-10 VDC.

Conﬁ guration Screen #39 - Heat Pump Control

VCM-X Cnfg ID 59

Heat Pump

Control: NO

Use < Or > To Change

Select YES if the HVAC unit is a Heat Pump. Default is NO.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Conﬁ guration Screen #40 - Reversing Valve Active During Heat/Cool

VCM-X Cnfg ID 59

Rev. Valve Active

For: Heat

Use < Or > To Change

Select Heat if your Heat Pump unit activates its Reversing Valve during Heating operation. Select Cool if your Heat Pump unit activates its Reversing Valve during Cooling operation. Default is Heat.

Conﬁ guration Screen #41 - Emergency Shutdown Input

VCM-X Cnfg ID 59

Emergency Shutdown

Input: NO

Use < Or > To Change

Select YES if a Smoke Detector/Firestat or other Emergency Shutdown input is connected to the binary input. If the Emergency Shutdown input is active, the Supply Fan, Heating and Cooling Relay Outputs will be disabled. Default is NO.

Conﬁ guration Screen #42 - Return Air Bypass Control

VCM-X Cnfg ID 59

Return Air Bypass

Control: NO

Use < Or > To Change

Select YES if your HVAC unit requires Return Air Bypass Control for Dehumidiﬁ cation Reheat. Default is NO.

Conﬁ guration Screen #43 - Broadcast OA Temp

VCM-X Cnfg ID 59

Broadcast Outdoor

Temperature: NO

Use < Or > To Change

Conﬁ guration Screen #44 - Broadcast OA Humidity

VCM-X Cnfg ID 59

Broadcast Outdoor

Humidity: NO

Use < Or > To Change

The VCM-X can broadcast its Outdoor Air Humidity reading to other HVAC units if they are not equipped with their own Outdoor Air Humidity sensors. A network communications device is required in order for this feature to operate. Select YES to Broadcast Outdoor Humidity. Default is NO.

Conﬁ guration Screen #45 - Broadcast Supply Temperature

VCM-X Cnfg ID 59 Broadcast Supply Temperature: YES

Use < Or > To Change

This broadcast sends the VCM-X’s Supply Air Temperature to all controllers on its local loop. This broadcast needs to be conﬁ gured on a VA V or Zoning System using the VCM-X with Orion VA V/Zone Controllers. A network communications device is required in order for this feature to operate. Select YES to Broadcast Supply Temperature. Default is YES.

Conﬁ guration Screen #46 - Broadcast Status Fan & Heat

VCM-X Cnfg ID 59 Broadcast Status

Fan & Heat: NO

Use < Or > To Change

This broadcast sends the VCM-X’s Supply Fan and Heating Status to all controllers on its local loop. This broadcast needs to be conﬁ gured on a VAV or Zoning System using the VCM-X with Orion VAV/Zone Controllers. A network communications device is required in order for this feature to operate. Select YES to Broadcast Status Fan & Heat. Default is NO.

The VCM-X can broadcast its Outdoor Air Temperature Reading to other HVAC units if they are not equipped with their own Outdoor Air Temperature sensors. A network communications device is needed in order for this feature to operate. Select YES to Broadcast Outdoor Temperature. Default is NO.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Zone

Conﬁ guration Screen #47 - Broadcast Internal Time Clock

VCM-X Cnfg ID 59

Broadcast Internal

Time Clock: NO

Use < Or > To Change

This broadcast sends the time from the VCM-X’s Internal Time Clock to all controllers on its local loop. This broadcast needs to be conﬁ gured on a VAV or Zoning System using the VCM-X with Orion VAV/Zone controllers. A network communications device is required in order for this feature to operate, but can also be used to synchronize all controllers on the local loop. Select YES to Broadcast Internal Time Clock. Default is NO.

Conﬁ guration Screen #48 - Broadcast Internal Schedule

VCM-X Cnfg ID 59

Broadcast Internal

Schedule: NO

Use < Or > To Change

Select YES to have all VAV/Zone controllers connected to this VCM-X Controller forced to their “Fixed Airﬂ ow” Position during the Morning Warm-up Mode of operation. See the VAV/Zone Controller Setpoint Screens for setting of the “Fixed Airﬂ ow” position. Default is NO.

Conﬁ guration Screen #51 - 1 HVAC Unit with Boxes on Multiple Loops

VCM-X Cnfg ID 59

1 HVAC Unit w/ Boxes

On Multi. Loops: NO

Use < Or > To Change

Select YES to have all broadcasts that have been conﬁ gured on Conﬁ gu- ration Screens 43 through 48 sent to all local loops on the entire system, not just the local loop the VCM-X Controller is on. This is normally only required if you have a large HVAC unit that requires more than the 58 VAV/Zone Controllers normally allowed on the local loop. This allows other VA V/Zone Controllers connected on additional local loops to receive the required broadcasts. This only is allowed when you have a single VCM-X Controller with VAV/Zone Controllers on multiple loops. Other VCM-X or add-on devices may be connected but no other VCM-X with VAV/Zone Controllers can be connected on the system. Default is NO.

This is always required when you have VA V/Zone controllers connected to this VCM-X Controller. This will broadcast the Occupied and Unoccupied Condition of the VCM-X Controller to all VA V/Zone controllers on the local loop. Select YES to Broadcast Internal Schedule. Default is NO.

Conﬁ guration Screen #49 - Broadcast VAV Boxes Force to Max

VCM-X Cnfg ID 59

Broadcast VAV Boxes

Force To Max: NO

Use < Or > To Change

This broadcast is to ensure the VAV/Zone Controllers will drive their dampers to the Max Airﬂ ow Damper Position during Morning Warm- up. This is important to allow the proper amount of airﬂ ow for Heating in the HVAC unit. Select YES to Broadcast VAV Boxes Force to Max. Default is NO.

Conﬁ guration Screen #50 - Broadcast VAV Boxes Force to Fixed

VCM-X Cnfg ID 59

Broadcast VAV Boxes

Force To Fixed: NO

Use < Or > To Change

Conﬁ guration Screen #52 - Uses R410A Refrigerant

VCM-X Cnfg ID 59

Unit Uses R410A Refrigerant: NO

Use < Or > To Change

Select YES if your HVAC unit uses R410A Refrigerant. Default is NO.

Conﬁ guration Screen #53 - Main Fan Maximum Voltage

VCM-X Cnfg ID 59

Max Main Fan Aout

Voltage: 10.0 VDC

[ 0 VDC - 10 VDC ]

Enter a value between 0.0 and 10.0 VDC for the main fan’s maximum output voltage. The Static Pressure and Output % Status Screen will display 0% to 100%, but the output will range from 0 VDC to the value set in this screen. Default is 10.0 VDC.

This screen will appear if using a VCM-X E-BUS Controller.

VCM-X / RNE Operator Interface SD

VCM-X CONFIGURATION

VCM-X Conﬁ guration Screens

Conﬁ guration Screen #54 - Micro Channel Condensers

VCM-X Cnfg ID 59

Micro Channel

Condensers: NO

Select YES if your HVAC unit is using Micro Channel Condensers. Default is NO.

Conﬁ guration Screen #55 - PREHEAT-X Controller Installed

VCBX Cnfg ID 101 Preheat-X Module

Installed: NO

Use < Or > To Change

If you have a PREHEA T -X Controller installed, this conﬁ guration option should be conﬁ gured as YES. Default is NO.

Conﬁ guration Screens #56-59 - Cooling & Heating Stage Delays

VCM-X Cnfg ID 59

Cooling Stage Delays Staging Up...: 3 Min Staging Down : 1 Min

Both modes have their own set of Staging and Run Delay Times. The Heating Timer Screens look exactly the same as the Cooling Timer Screens except they reference the Heating settings instead of the Cooling settings.

See the Sequence of Operation Manual for information on how these Delays and Run Times are used.

Description Minimum Default Maximum

Cooling Stage Up 3 Min 3 Min 15 Min

Cooling Stage Down 1 Min 1 Min 15 Min

Cooling Min Run Time 5 Min 5 Min 15 Min

Cooling Min Off Time 3 Min 3 Min 15 Min

Heating Stage Up 3 Min 3 Min 15 Min

Heating Stage Down 1 Min 1 Min 15 Min

Heating Min Run Time 2 Min 2 Min 15 Min

Heating Min Off Time 1 Min 1 Min 15 Min

Conﬁ guration Screens #60-79 - Relay Conﬁ guration Screens

VCM-X Cnfg ID 59

Relay Configurations

Rly xx: Not Used

Use < Or > To Change

Relay #1 is not conﬁ gurable as it is reserved for the Supply Air Fan. Relays #2-#21 are conﬁ gurable for the following options:

• Not Used • Pre-Heater

VCM-X Cnfg ID 59

Cooling Stage Delays

Min Run Time: 5 Min Min Off Time: 3 Min

VCM-X Cnfg ID 59

Heating Stage Delays Staging Up...: 3 Min Staging Down : 1 Min

VCM-X Cnfg ID 59

Heating Stage Delays

Min Run Time: 2 Min Min Off Time: 1 Min

Both the Heating Stages and the DX Cooling Stages utilize Staging Up and Down Delay Periods between stages and Minimum Run Times and Off Times.

VCM-X / RNE Operator Interface SD

• Heat Stage • Alarm

• Cool Stage • Override

• Warmup Mode • Occupied

• Rev V alve • OA Damper

• HGR • Heat Wheel

• Exhaust Fan • Emerg. Heat

Relays #2 through #21 can be individually conﬁ gured. By using the 4 relay outputs available on the VCM-X Controller, the 4 relays on the VCM-X Expansion Module, and the 12 relays on the 12 Relay Expansion Module, you have the ability to conﬁ gure up to a combined total of 20 Heating Stages, Cooling Stages, and the rest of the options listed above. Only the Heating and Cooling relays can be conﬁ gured with multiple outputs. If any other option is selected more than once, it will simply activate redundant relays, but no multiple staging will occur. Default is “Not Used.”

RNE CONFIGURATION

RNE Conﬁ guration Screen Index

NOTE: For VCM-X Conﬁ guration Screens, see page 24.

The available Conﬁ guration Screens for the RNE Controller are listed on the next few pages by sequential screen number. When each RNE Controller is conﬁ gured for the ﬁ rst time, it is best to start with screen #1 and proceed to each screen in numerical order until you have viewed all available Conﬁ guration Screens. This ensures that you have seen all the available RNE Controller conﬁ guration possibilities and have the opportunity to change or accept the defaults for each screen.

Once the unit is conﬁ gured and you decide to change one of the screen options, it is helpful to know what screen number contains the conﬁ gu- ration you wish to change. With this in mind, the following is a list of all the RNE Controller Conﬁ guration Screens in numerical order with a brief listing of the conﬁ guration feature available on each screen.

Screen #1 Duct Static Pressure Control Screen #2 Supply Fan Cycle Mode Screen #3 HVAC Mode Enable Screen #4 HVAC Reset Source Screen #5 Reset Interval Rate Screen #6 Dehumidiﬁ cation Control Screen #7 Dehumidiﬁ cation Priority Screen #8 Dehumidiﬁ cation Unoccupied Screen #9 Outdoor Humidity Sensor Screen #10 Indoor Humidity Sensor Screen #11 Heat During Dehumidify Screen #12 Economizer Control Screen #13 Title 24 Economizer Screen #14 Proof of Flow Input Screen #15 Modulating Heating Screen #16 Modulating Heat Output Signal Screen #17 Modulating Heat Reverse Acting Screen #18 Modulating Heat Proportional Window Screen #19 Modulating Cooling Type Screen #20 RNE Tonnage Screen #21 Water Source Heat Pump Installed Screen #22 Modulating Cooling Reverse Acting

Screen #23 Modulating Cool Proportional Window Screen #24 Head Pressure Module Installed Screen #25 Type of Head Pressure Module: 1 or 2

Condenser Screen #26 Airﬂ ow Monitoring Station Screen #27 Monitor Outdoor Air CFM Screen #28 Control Outdoor Air CFM Screen #29 Outdoor Duct/Damper Size Screen #30 Monitor Return Air CFM Screen #31 Return Duct/Damper Size Screen #32 Monitor Supply Air CFM Screen #33 Supply Duct/Damper Size Screen #34 CO Screen #35 CO Screen #36 Building Pressure Modulating Control Screen #37 Building Pressure Reverse Acting Screen #38 Building Pressure Output Signal Screen #39 Air to Air Heat Pump Control

Screen #40 Reversing Valve Active For Heat/Cool Screen #41 Emergency Shutdown Input Screen #42 Return Air Bypass Control Screen #43 Broadcast Outdoor Temperature Screen #44 Broadcast Outdoor Humidity Screen #45 Broadcast Supply Temperature Screen #46 Broadcast Status Fan & Heat Screen #47 Broadcast Internal Time Clock Screen #48 Broadcast Internal Schedule Screen #49 Broadcast VAV Boxes Force to Max Screen #50 Broadcast VAV Boxes Force to Fixed Screen #51 1 HVAC Unit w/Boxes on Multiple Loops Screen #52 Unit Uses R410A Refrigerant Screen #53 Main Fan Maximum Voltage Screens #54-57 Cooling & Heating Staging Delays Screens #58-77 Relay Conﬁ guration Screens

Sensor Output Signal

Sensor Maximum Scale

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screens

In order to correctly set up the RNE Controller, you must ﬁ rst conﬁ gure several parameters in regard to the type of HVAC unit and system you have installed. Most of these values and operating parameters are only set once at the initial system setup and are never changed.

Modular Service Tool SD Instructions

No matter what screen or menu you’re in, press <CONFIGURATION>. The Unit Selection Scr een will appear , shown below, requesting that you enter the unit ID number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the correct unit ID number of the RNE Controller you want to conﬁ gure and then press <ENTER>. Y ou must type in the number , even if it is “1”. Once communication is established, the *00* at the bottom

will disappear. Then Screen #1. Press

scroll through the screens.

press <>. You will then see Unit Conﬁ guration

<ENTER> to save entered data and press <> to

The following screen will be displayed:

Change Setpoints

Configure Unit

Save/Copy/Restore

Scroll down to the ‘Conﬁ gure Unit’ option and press <ENTER>. This will take you to the ﬁ rst Conﬁ guration Screen shown below.

Conﬁ guration Screen #1 - Duct Static Pressure

RNE Cnfg ID 101

Duct Static Pressure

Control: YES

Use < Or > To Change

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection *00*

Enter Unit ID#

Selected ID#: XXXX

Then

press <>.

Conﬁ guration Screen #2 - Supply Fan Cycle

RNE Cnfg ID 101

Supply Fan Cycle

Mode: NO

Use < Or > To Change

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #3 - HVAC Mode Enable

RNE Cnfg ID 101

HVAC Mode Enable

Supply Air

Use < Or > To Change

Select the T emperature Sensor that will determine the Heating, Cooling, or Vent Mode of operation. The selections are:

 Supply Air

This is typical for VAV applications. Occupied Cooling with Morning Warm-up.

 Outdoor Air

This is for 100% Outdoor Air (MUA) units. Dehumidiﬁ cation utilizes a Dewpoint Calculation if equipped with an Outdoor Air Humidity Sensor.

 Space Temperature

This is for any unit that conditions a space and is not 100% Outdoor air. Occupied/Unoccupied Heating, Cooling, and Vent Modes of operation.

 Return Air

This selection can be used when an Average Building Temperature (the Return Air Temperature) needs to determine Heating, Cooling, and Vent Modes of operation.

 Supply Air/Tempering

Conﬁ guration Screen #4 - HVAC Reset Source

RNE Cnfg ID 101

HVAC Reset Source

No Reset

Use < Or > To Change

Conﬁ guration Screen #5 - Reset Interval Rate

RNE Cnfg ID 101

Reset Interval

Rate...: 20 s

[1-255 Seconds]

Conﬁ guration Screen #6 - Dehumidiﬁ cation Control

RNE Cnfg ID 101

Dehumidification

Control: NO

Use < Or > To Change

Select YES if your system requires Dehumidiﬁ cation Control. Default is NO.

Conﬁ guration Screen #7 - Dehumidiﬁ cation Priority

RNE Cnfg ID 101

Dehumidification

Priority: NO

Use < Or > To Change

Conﬁ guration Screen #8 - Dehumidiﬁ cation Unoccupied

The Supply Air Heating and Cooling Temperature Setpoints can be reset using various input sources. Default is No Reset. Select the desired Reset Source for Supply Air Temperature Reset. The Single Zone V AV option should be selected in applications where the Supply Fan VFD speed is reset based on the Space Temperature. If you select No Reset, then neither the Supply Air Setpoint nor the Supply Fan VFD Reset will occur. The selections are:

 No Reset  Fan VFD Percentage  Space Sensor  Outdoor Sensor  Return Air Sensor  Single Zone (SZ) VAV  Remote Reset Signal  SZ VAV with CV Heating

RNE Cnfg ID 101

Dehumidification

Unoccupied: NO

Use < Or > To Change

Select YES if Dehumidiﬁ cation is required during the Unoccupied mode. Unoccupied Dehumidiﬁ cation is activated based on Indoor Air Humidity only. Default is NO.

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #9 - Outdoor Humidity Sensor

RNE Cnfg ID 101

Outdoor Humidity

Sensor: NO

Use < Or > To Change

Select YES if the HVAC unit is equipped with an Outdoor Air Humidity Sensor. Default is NO.

Conﬁ guration Screen #10 - Indoor Humidity Sensor

RNE Cnfg ID 101

Indoor Humidity

Sensor: NO

Use < Or > To Change

Select YES if the HVAC unit is equipped with an Indoor Air Humidity Sensor. Default is NO.

Conﬁ guration Screen #11 - Heat During Dehumidify

RNE Cnfg ID 101

Heat During

Dehumidify: NO

Use < Or > To Change

Conﬁ guration Screen #12 - Economizer Control

Conﬁ guration Screen #14 - Proof of Flow Input

RNE Cnfg ID 101

Proof Of Flow

Input: NO

Use < Or > To Change

Select YES if the unit is equipped with a Proof of Flow Switch and it is connected to the RNE. If selected as YES and the Proof of Flow Switch is open, only the Supply Fan Relay will be active. If any other relays such as Heating Stages or Cooling Stages are active, they will be deactivated when the Proof of Flow Switch input is lost. Default is NO.

Conﬁ guration Screen #15 - Modulating Heating

RNE Cnfg ID 101 Mod Heating: NO

Use < Or > To Change

Select YES if the HVAC unit is controlling Modulating Heating. If your HVAC is using a Modulating Hot Water Valve, Modulating Steam Valve, or a SCR Controlled Electric Heater, you must select YES for Modulating Heating. This conﬁ guration does not apply to MODGAS using the MODGAS II Controller. Default is NO.

Conﬁ guration Screen #16 - Modulating Heating Output Signal

RNE Cnfg ID 101

Mod Heating

Output Signal.: 0-10V

Use < Or > To Change

RNE Cnfg ID 101

Economizer

Control: NO

Use < Or > To Change

Select YES if the RNE is controlling the Economizer. Default is NO.

Conﬁ guration Screen #13 - Title 24 Economizer

RNE Cnfg ID 101

Title 24

Economizer: NO

Use < Or > To Change

If this unit has Title 24 Economizer operation, this option should be conﬁ gured as YES. Default is NO.

VCM-X / RNE Operator Interface SD

Select 0-10 VDC or 2-10 VDC as the signal for a Modulating Heat Source such as a Hot W ater Valve or SCR Electric Heater. Default is 0-10 VDC.

Conﬁ guration Screen #17 - Modulating Heating Reverse Acting

RNE Cnfg ID 101

Mod Heating

Rev Acting: NO

Use < Or > To Change

Select YES if the Modulating Heat Source requires 0 VDC to open and 10 VDC to close. Default is NO.

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #18 - Modulating Heating Proportional Window

RNE Cnfg ID 101

Mod Heating

Prop. Window.: 10ºF Time Period..: 5 s

Conﬁ guration Screen #19 - Modulating Cooling Type

RNE Cnfg ID 101

Mod Cooling Type

None

Use < Or > To Change

Select the desired Modulating Cooling Type. Default is None. The selections are:

 None  VFD Half  VFD Full  0-10 VDC CW  2-10 VDC CW

Conﬁ guration Screen #22 - Modulating Cooling Reverse Acting

RNE Cnfg ID 101

Mod Cooling

Rev Acting: NO

Use < Or > To Change

Select YES if the Modulating Cooling Source requires 0 VDC to open and 10 VDC to close. You cannot use a Reverse Acting Signal if a VFD Compressor is being used. Default is NO.

Conﬁ guration Screen #23 - Modulating Cooling Proportional Window

RNE Cnfg ID 101 Mod Cooling Prop. Window.: 10ºF Time Period..: 30 s

Conﬁ guration Screen #24 - Head Pressure Module Installed

Conﬁ guration Screen #20 - RNE Tonnage

RNE Cnfg ID 101

RNE Tonnage

55–75 Tons

Use < Or > To Change

Select the desired Tonnage. Default is 55–75 Tons. The selections are:

 55–75 Tons  95–105 Tons  120–140 Tons

Conﬁ guration Screen #21 - Water Source Heat Pump Installed

RNE Cnfg ID 101

Water Source

Heat Pump: NO

Use < Or > To Change

Select YES if this is a Water Source Heat Pump. Default is NO.

RNE Cnfg ID 101

Head Pressure

Module: NO

Use < Or > To Change

Select YES if you have a Head Pressure Module installed. Default is NO.

Conﬁ guration Screen #25 - Type of Head Pressure Module Installed

RNE Cnfg ID 101

Type of Head Pr.

Module: 1 Condenser

Use < Or > To Change

Select 1 Condenser or 2 Condenser if you have a Head Pressure Module installed. Default is 1 Condenser.

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #26 - Type of Airﬂ ow Station

RNE Cnfg ID 101

Airflow Station:

Paragon

Use < Or > To Change

Select the type of Airﬂ ow Monitoring Station you are using, if any. Selections are Paragon or Ebtron. Default is Paragon.

Conﬁ guration Screen #27 - Monitor Outdoor Air CFM

RNE Cnfg ID 101 Monitor Outdoor

Air CFM: NO

Use < Or > To Change

Select YES if you have an Airﬂ ow Monitoring station measuring the CFM of the Outdoor airﬂ ow stream of this unit. Default is NO.

Conﬁ guration Screen #28 - Control Outdoor Air CFM

Conﬁ guration Screen #30 - Monitor Return Air CFM

RNE Cnfg ID 101

Monitor Return

Air CFM: NO

Use < Or > To Change

Select YES if you have an airﬂ ow monitoring station measuring the CFM of the return airﬂ ow stream of this unit. Default is NO.

Conﬁ guration Screen #31 - Return Duct/ Damper Size

RNE Cnfg ID 101

Return Duct/Damper

Size: 0.00

[Area in sq. ft.]

For the Controller to properly calculate the return air CFM, you need to enter the area in square feet of the return air duct/damper . When measur ing the return air damper area, be sure to measure the inside dimensions of the damper. The more accurate the measurements, the more accurate the CFM reading will be. This value needs to be accurate to 2 decimal places. Default is 0.00.

RNE Cnfg ID 101 Control Outdoor

Air CFM: NO

Use < Or > To Change

Select YES if you want to control the Outdoor Air Damper to a CFM setpoint. Default is NO.

Conﬁ guration Screen #29 - Outdoor Duct/ Damper Size

RNE Cnfg ID 101

Outdoor Duct/Damper

Size: 0.00

[Area in sq. ft.]

For the Controller to properly calculate the outside air CFM you need to enter the inside area (sq. ft.) of the outdoor air duct/damper. When measuring the outdoor air damper area, be sure to measure the inside

dimensions of the damper. The more accurate the measurements, the more accurate the CFM reading will be. This value needs to be accurate to 2 decimal places. Default is 0.00.

Conﬁ guration Screen #32 - Monitor Supply Air CFM

RNE Cnfg ID 101

Monitor Supply

Air CFM: NO

Use < Or > To Change

Select YES if you have an airﬂ ow monitoring station measuring the CFM of the supply airﬂ ow stream of this unit. Default is NO.

Conﬁ guration Screen #33 - Supply Duct/ Damper Size

RNE Cnfg ID 101

Supply Duct/Damper

Size: 0.00

[Area in sq. ft.]

For the Controller to properly calculate the supply air CFM, you need to enter the area in square feet of the supply air duct/damper. When measuring the supply duct damper area, be sure to measure the inside dimensions of the damper. The more accurate the measurements, the more accurate the CFM reading will be. This value needs to be accurate to 2 decimal places. Default is 0.00.

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #34 - CO2 Sensor Output Signal

RNE Cnfg ID 101

CO2 Sensor

Output Signal: None

Use < Or > To Change

The RNE needs to know what type of CO2 sensor signal output is being provided. Select a 0-10 VDC CO2 sensor signal (standard sensor used) or a 4-20 mA CO2 sensor signal. Select None if no CO2 sensor is used. Default is None.

Conﬁ guration Screen #35 - CO2 Sensor Maximum Scale

RNE Cnfg ID 101

CO2 Sensor Maximum

Scale: 2000 PPM

Use < Or > To Change

Default is 2000 PPM. The RNE needs to know the CO2 Sensor scaling for proper reading of the CO should be scaled to 2000 PPM. Select None if no CO2 sensor is used. Default is 2000 PPM.

Sensor output. The Standard CO2 Sensor

Conﬁ guration Screen #36 - Building Pressure Modulating Control

RNE Cnfg ID 101

Building Pressure

Mod Control: NO

Use < Or > To Change

Conﬁ guration Screen #37 - Building Pressure Reverse Acting

RNE Cnfg ID 101

Building Pressure

Rev Acting: NO

Use < Or > To Change

Conﬁ guration Screen #38 - Building Pressure Output Signal

RNE Cnfg ID 101

Building Pressure Output Signal: 0-10V Use < Or > To Change

This Screen is used to conﬁ gure the Building Pressure Output Signal voltage needed for your application. Select a 0-10 VDC signal (default) or 2-10 VDC signal as required by the device you are using to control the pressure. Default is 0-10V.

Conﬁ guration Screen #39 - Heat Pump Control

RNE Cnfg ID 101

Air to Air Heat Pump

Control: NO

Use < Or > To Change

Select YES if the HVAC unit is a Heat Pump. Default is NO.

Conﬁ guration Screen #40 - Reversing Valve Active During Heat/Cool

RNE Cnfg ID 101

Rev. Valve Active

For: Heat

Use < Or > To Change

Select Heat if your Heat Pump unit activates its Reversing Valve during Heating operation. Select Cool if your Heat Pump unit activates its Reversing Valve during Cooling operation. Default is Heat.

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #41 - Emergency Shutdown Input

RNE Cnfg ID 101

Emergency Shutdown

Input: NO

Use < Or > To Change

Conﬁ guration Screen #42 - Return Air Bypass Control

RNE Cnfg ID 101

Return Air Bypass

Control: NO

Use < Or > To Change

Select YES if your HVAC unit requires Return Air Bypass Control for Dehumidiﬁ cation Reheat. Default is NO.

Conﬁ guration Screen #43 - Broadcast OA Temp

RNE Cnfg ID 101

Broadcast Outdoor

Temperature: NO

Use < Or > To Change

Conﬁ guration Screen #45 - Broadcast Supply Temperature

RNE Cnfg ID 101

Broadcast Supply

Temperature: YES

Use < Or > To Change

This broadcast sends the RNE’s Supply Air Temperature to all Controllers on its local loop. This broadcast needs to be conﬁ gured on a VAV or Zoning System using the RNE with Orion VA V/Zone Controllers. A network communications device is required in order for this feature to operate. Select YES to Broadcast the Supply Air Temperature. Default is YES.

Conﬁ guration Screen #46 - Broadcast Status Fan & Heat

RNE Cnfg ID 101

Broadcast Status

Fan & Heat: NO

Use < Or > To Change

This broadcast sends the RNE’s Supply Fan and Heating Status to all Controllers on its local loop. This broadcast needs to be conﬁ gured on a V AV or Zoning System using the RNE with Orion VA V/Zone Controllers. A network communications device is required in order for this feature to operate. Select YES to Broadcast the Fan & Heat Status. Default is NO.

Conﬁ guration Screen #47 - Broadcast Internal Time Clock

The RNE can broadcast its Outdoor Air Temperature Reading to other HVAC units if they are not equipped with their own Outdoor Air Temperature sensors. A network communications device is needed in order for this feature to operate. Select YES to Broadcast the Outdoor Temperature. Default is NO.

Conﬁ guration Screen #44 - Broadcast OA Humidity

RNE Cnfg ID 101

Broadcast Outdoor

Humidity: NO

Use < Or > To Change

The RNE can broadcast its Outdoor Air Humidity reading to other HVAC units if they are not equipped with their own Outdoor Air Humidity sensors. A network communications device is required in order for this feature to operate. Select YES to Broadcast the Outdoor Humidity. Default is NO.

VCM-X / RNE Operator Interface SD

RNE Cnfg ID 101

Broadcast Internal

Time Clock: NO

Use < Or > To Change

This broadcast sends the time from the RNE’s Internal T ime Clock to all Controllers on its local loop. This broadcast needs to be conﬁ gured on a V AV or Zoning System using the RNE with Orion VA V/Zone Controllers. A network communications device is required in order for this feature to operate, but can also be used to synchronize all Controllers on the local loop. Select YES to Broadcast the Internal Time Clock. Default is NO.

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screen #48 - Broadcast Internal Schedule

RNE Cnfg ID 101

Broadcast Internal

Schedule: NO

Use < Or > To Change

This is always required when you have VA V/Zone Controllers connected to this RNE Controller. This will broadcast the Occupied and Unoccupied Condition of the RNE Controller to all VA V/Zone Controllers on the local loop. Select YES to Broadcast the Internal Schedule. Default is NO.

Conﬁ guration Screen #49 - Broadcast VAV Boxes Force to Max

RNE Cnfg ID 101

Broadcast VAV Boxes

Force To Max: NO

Use < Or > To Change

Conﬁ guration Screen #51 - 1 HVAC Unit with Boxes on Multiple Loops

RNE Cnfg ID 101

1 HVAC Unit w/ Boxes

On Multi. Loops: NO

Use < Or > To Change

Select YES to have all broadcasts that have been conﬁ gured on Con- ﬁ guration Screens 42 through 47 sent to all local loops on the entire

system, not just the local loop the RNE Controller is on. This is normally only required if you have a large HVAC unit that requires more than the 58 VA V/Zone Controllers normally allowed on the local loop. This allows other VA V/Zone Controllers connected on additional local loops to receive the required broadcasts. This only is allowed when you have a single RNE Controller with VA V/Zone Controllers on multiple loops. Other RNE or add-on devices may be connected but no other RNE with VAV/Zone Controllers can be connected on the system. Default is NO.

Conﬁ guration Screen #52 - Uses R410A Refrigerant

RNE Cnfg ID 101 Unit Uses R410A Refrigerant: NO

Use < Or > To Change

Select YES if your HVAC unit uses R410A Refrigerant. Default is NO.

Conﬁ guration Screen #50 - Broadcast VAV Boxes Force to Fixed

RNE Cnfg ID 101

Broadcast VAV Boxes

Force To Fixed: NO

Use < Or > To Change

Select YES to have all VAV/Zone Controllers connected to this RNE Controller forced to their “Fixed Airﬂ ow” Position during the Morning Warm-up Mode of operation. See the VAV/Zone Controller Setpoint Screens for setting of the “Fixed Airﬂ ow” position. Default is NO.

Conﬁ guration Screen #53 - Main Fan Maximum Voltage

RNE Cnfg ID 101

Max Main Fan Aout Voltage: 10.0 VDC [ 0 VDC - 10 VDC ]

VCM-X / RNE Operator Interface SD

RNE CONFIGURATION

RNE Conﬁ guration Screens

Conﬁ guration Screens #54-57 - Cooling & Heating Stage Delays

RNE Cnfg ID 101 Cooling Stage Delays Staging Up...: 3 Min Staging Down : 1 Min

RNE Cnfg ID 101 Cooling Stage Delays

Min Run Time: 5 Min Min Off Time: 3 Min

RNE Cnfg ID 101 Heating Stage Delays Staging Up...: 3 Min Staging Down : 1 Min

RNE Cnfg ID 101 Heating Stage Delays

Min Run Time: 2 Min Min Off Time: 1 Min

Both the Heating Stages and the DX Cooling Stages utilize Staging Up and Down Delay Periods between stages and Minimum Run Times and Off Times.

Conﬁ guration Screens #58-77 - Relay Conﬁ guration Screens

RNE Cnfg ID 101

Relay Configurations

Rly xx: Not Used

Use < Or > To Change

Relay #1 is not conﬁ gurable as it is reserved for the Supply Air Fan. Relays #2-#21 are conﬁ gurable for the following options:

• Not Used • Pre-Heater

• Heat Stage • Alarm

• Cool Stage • Override

• Warmup Mode • Occupied

• Rev V alve • OA Damper

• HGR • Heat Wheel

•

Exhaust Fan • Emerg. Heat

Relays #2 through #21 can be individually conﬁ gured. By using the 4 relay outputs available on the RNE Controller, the 4 relays on the VCM-X Expansion Module, and the 12 relays on the 12-Relay Expansion Module, you have the ability to conﬁ gure up to a combined total of 20 Heating Stages, Cooling Stages, and the rest of the options listed above. Only the Heating and Cooling relays can be conﬁ gured with multiple outputs. If any other option is selected more than once, it will simply activate redundant relays, but no multiple staging will occur. Default is “Not Used.”

See the Sequence of Operation Manual for information on how these Delays and Run Times are used.

Description Minimum Default Maximum

Cooling Stage Up 3 Min 3 Min 15 Min

Cooling Stage Down 1 Min 1 Min 15 Min

Cooling Min Run Time 5 Min 5 Min 15 Min

Cooling Min Off Time 3 Min 3 Min 15 Min

Heating Stage Up 3 Min 3 Min 15 Min

Heating Stage Down 1 Min 1 Min 15 Min

Heating Min Run Time 2 Min 2 Min 15 Min

Heating Min Off Time 1 Min 1 Min 15 Min

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screen Index

Setpoint Screen Index

The available Setpoint Screens for the VCM-X or RNE Controller are listed on the next few pages by sequential screen number. When each VCM-X or RNE Controller is conﬁ gured for the ﬁ rst time, it is best to start with screen #1 and proceed to each Setpoint Screen in numerical order until you have viewed all available Setpoint Screens. This ensures that you have seen all of the available VCM-X or RNE Controller Setpoint possibilities and have the opportunity to change or accept the defaults for each screen. Once the unit Setpoints are conﬁ gured and you decide to change one of the screen options, it is helpful to know what screen number contains the conﬁ guration you wish to change. With this in mind, the following is a list of all the VCM-X or RNE Setpoint Screens in numerical order with a brief listing of the Setpoint feature available on each screen:

Setpoint Screen #1 HVAC Mode Setpoints Setpoint Screen #2 HVAC Mode Select Deadband Setpoint Screen #3 Unoccupied Setbacks Setpoint Screen #4 SAT Cooling Setpoints Setpoint Screen #5 Cool Reset Source Setpoints Setpoint Screen #6 SAT Heating Setpoints Setpoint Screen #7 Heat Reset Source Setpoints Setpoint Screen #8 Stage Control Window Setpoint Screen #9 Outdoor Air Lockouts Setpoint Screen #10 Cutoff Temperatures Lo SAT

& Hi SAT Setpoint Screen #11 Minimum Supply Fan VFD Speed

For Heating Setpoint Screen #12 Morning W arm-up Target Temp &

Max Length Setpoint Screen #13 Dehumidiﬁ cation Indoor RH & OA

Dewpoint Setpoint Screen #14 Dehumidiﬁ cation Coil Temperature Setpoint Screen #15 Cooling Head Pressure Setpoint

(VCM-X E-BUS/RNE) Setpoint Screen #16 Reheat Head Pressure Setpoint

(VCM-X E-BUS/RNE) Setpoint Screen #17 Economizer Setpoints OAT/WB Enable Setpoint Screen #18 Economizer Setpoints Min Position &

Control Rate

Setpoint Screen #19 Outdoor Air CFM Min & Max Control Setpoint Screen #20 Outdoor Air CFM Deadband Setpoint Screen #21 Maximum Economizer Position if High

CO Setpoint Screen #22 CO

Reset Range Setpoint Screen #23 Static Setpoint, Deadband & Control

Rate Setpoint Screen #24 Building Pressure Setpoint & Deadband Setpoint Screen #25 Return Air Bypass Damper Factor

Setpoint Setpoint Screen #26 Fan Starting Delay Timer Setpoint Screen #27 Mechanical Heat Cool Failures Occur

After No Change For Setpoint Screen #28 Preheat/Low Ambient Temperature

Setpoint Screen #29 Max OA Damper Tempering Limit Setpoint Screen #30 HVAC Schedule Setpoint Screen #31 Push-Button Override Duration Setpoint Screen #32 HVAC Mode Sensor Slide Offset Setpoint Screen #33 Heat Pump Auxiliary Heating Delay Setpoint Screen #34 Heat Pump Defrost Temp and

Defrost Timer (VCM-X E-BUS/RNE) Setpoint Screen #35 Adaptive Defrost Adjustment

(VCM-X E-BUS/RNE) Setpoint Screen #36 Heat Wheel Defrost Setpoint Screen #37 Internal Schedule Optimal Start Soak

Multiplier Setpoint Screen #38 Trend Log Interval Setpoint Screen #39 Preheat-X Setpoints - Cooling &

Heating Mode (VCM-X Modular E-BUS)

Setpoint Screen #40 Preheat-X Setpoint - Venting Mode (VCM-X Modular E-BUS)

Setpoint Screen #41 Sensor Calibration For SPC & SAT Setpoint Screen #42 Sensor Calibration For RAT & OAT Setpoint Screen #43 Sensor Calibration For Coil

Level Occurs

Protection Limit Max Level &

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoints

Modular Service Tool Instructions

From any menu screen, press <SETPOINTS>. The Unit Selection Screen, shown below, will appear requesting that you enter the unit

ID number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the correct unit ID number of the VCM-X or RNE Controller you want to change Setpoints for and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established, the

*00* at the bottom will disappear. Then Setpoint Screen #1. Press <ENTER> to save entered data and press

<> to scroll through the screens.

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

press <>. You will then see

The following screen will be displayed:

Change Setpoints Configure Unit Save/Copy/Restore

Scroll to the ‘Change Setpoints’ option and press <ENTER>. This will take you to the ﬁ rst Setpoints Screen shown below.

Setpoint Screen #1 - HVAC Mode Setpoints

VCM-X / RNE Spts

HVAC Mode Setpoints

Cooling......: 75ºF

Heating......: 70ºF

These Setpoints are used to determine the Heating, Cooling, or Vent Modes of operation in reference to the HVAC Mode Enable Sensor. If the Supply Air Sensor is conﬁ gured to be the HVAC Mode Enable, these Setpoints are used in conjunction with the Unoccupied Setbacks if equipped with a Space Temperature Sensor.

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection *00*

Enter Unit ID#

Selected ID#: XXXX

Enter the Unit ID of the controller you wish to change schedules for and press <ENTER>. Once communication is established, the *00*

message will go away. Then

NOTE: If the *00* remains, it indicates a communication

press <>.

failure to the controller.

Description Minimum Default Maximum

HVAC Mode Setpoints Cooling 0ºF 75ºF 99ºF

HVAC Mode Setpoints Heating 0ºF 70ºF 99ºF

Setpoint Screen #2 - HVAC Mode Select Deadband

VCM-X / RNE Spts HVAC Mode Select

Deadband....: 1.0ºF

This Setpoint is added to and subtracted from the HV AC Mode Setpoints. It provides you with ﬂ exibility on when the Heating and Cooling Modes should be active above or below the HVAC Mode Setpoints.

Description Minimum Default Maximum

HVAC Mode Select Deadband 0ºF 1ºF 10ºF

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #3 - Unoccupied Setbacks

VCM-X / RNE Spts

Unoccupied Setbacks

Cooling.........: 30ºF

Heating.........: 30ºF

During the Unoccupied Mode of Operation, these Setpoints spread the HV AC Mode Setpoints out by a user -adjustable amount. Use only positive numbers for these Setpoints. If you do not want Cooling or Heating to operate during the Unoccupied Mode, use the default setting of 30°F for these setpoints.

Description Minimum Default Maximum

Unoccupied Setbacks Cooling 0ºF 30ºF 30ºF

Unoccupied Setbacks Heating 0ºF 30ºF 30ºF

Setpoint Screen #4 - SAT Cooling Setpoints

VCM-X / RNE Spts SAT Cooling Spts

Cooling..: 55ºF Rst Limit: 55ºF

If no Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then this setpoint will be the Supply Air Temperature Cooling Setpoint. Line 4 will be blank. If a Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then Line 4 will read Rst Limit. Reset is always upward from the SAT setpoint to the Reset Limit setpoint. So, the SAT will be the lowest temperature the Supply Air Setpoint can be reset to and Reset Limit will be the highest temperature the Supply Air Setpoint can be reset to. The Cooling Supply Air Temperature Setpoint will automatically be reset warmer or colder within this range as the Reset Source (next screen) moves within its range.

Description Minimum Default Maximum

SAT Cooling Setpoint 40ºF 55ºF 80ºF

Cooling Reset Limit 40ºF 55ºF 150ºF

Setpoint Screen #5 - Cool Reset Source

VCM-X / RNE Spts

Cool Rst Source Spts

SpcHi: 75 SAT: 55º SpcLo: 75 RST: 55º

If no Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then this screen will read Cool Rst Not Conﬁ g and will not be used. If a Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then the names of the values on the left side of this screen will correspond to the Reset Source that was conﬁ gured. This screen will then allow you to input the upper and lower limits for the range of values of the Reset Source on the left side of the screen and will show the corresponding Cooling Supply Air SAT and Rst Limit values that were entered on the previous screen. Single Zone VA V Reset of the Supply Fan VFD is addressed in the last paragraph.

Please note that the SAT and Rst Limit values on the right side of this screen cannot be changed on this screen; they are simply displayed from what was entered on the Setpoint Screen #4. For each line, the value on the left corresponds to the value on the right. So, if the Space T emperature Sensor has been conﬁ gured as the Reset Source, then when the Space Temperature is at or above the SpcHi T emperature Setpoint, the Supply Air Cooling Setpoint will be reset to its lowest value, the SA T Setpoint. If the Space T emperature is at or below the SpcLo Setpoint, the Supply Air Cooling Setpoint will be reset to its highest value, the Cooling Rst Limit. Then, as the Space Temperature moves from its low value to its high value, the Supply Air Cooling Setpoint will be proportionally reset from its high value to its low value.

Depending on whether reset has been conﬁ gured or not, the options for the names of the values on the left side of the screen are SpcHi, SpcLo, OatHi, OatLo, RatHi, RatLo, VLT, VFD, NoRST.

In the examples that follow, the desired Space Temperature in Cooling Mode is 75ºF:

Space Temperature Cool Reset:

Space Temperature (SPC Hi) = 75ºF SAT Setpoint (SAT) = 55ºF Space Temperature (SPC Lo) = 74ºF SAT Setpoint (Rst) = 65ºF

VFD Percentage Cool Reset:

VFD Percentage (VFD) = 70% SAT Setpoint (SAT) = 55ºF VFD Percentage (VFD) = 30% SAT Setpoint (Rst) = 65ºF

Input Voltage Cool Reset:

Input Voltage (VLT) = 0 Volts SAT Setpoint (SAT) = 55ºF Input Voltage (VLT) = 10 Volts SAT Setpoint (Rst) = 65ºF

In the Cooling Mode in a Single Zone VA V application, the Supply Fan VFD speed will proportionally modulate as the Space T emperature rises within the range set on this screen. Upon entering the Cooling Mode, the fan will start at 30% and modulate up to 100% as the Space T emperature rises from the SpcLo Setpoint to the SpcHi Setpoint. The SpcLo Setpoint should be the same as the Space Cooling Setpoint (Mode Enable Setpoint) from Setpoint Screen #1. The SAT and RST Setpoints on the right side of the screen are not used.

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #6 - SAT Heating Setpoints

If no Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then this setpoint will be the Supply Air Temperature Heating Setpoint. Line 4 will be blank. If a Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then Line 4 will read Rst Limit. Reset is always upward from the SAT setpoint to the Reset Limit setpoint. So, the SAT will be the lowest temperature the Supply Air Setpoint can be reset to and Reset Limit will be the highest temperature the Supply Air Setpoint can be reset to. The Heating Supply Air T emperature Setpoint will automatically be reset warmer or colder within this range as the Reset Source (next screen) moves within its range.

VCM-X / RNE Spts

SAT Heating Spts

Heating..: 120ºF Rst Limit: 120ºF

Description Minimum Default Maximum

SAT Heating Spt 40ºF 120ºF 200ºF

Reset Limit Spt 40ºF 120ºF 200ºF

Setpoint Screen #7 - Heat Reset Source

Depending on whether reset has been conﬁ gured or not, the options for the names of the values on the left side of the screen are SpcHi, SpcLo, OatHi, OatLo, RatHi, RatLo, VLT, VFD, NoRST.

In the examples that follow, the desired Space T emperature in Heating Mode is 71ºF:

Space Temperature Heat Reset:

Space Temperature (SPC Hi) = 71ºF SAT Setpoint (SAT) = 90ºF Space Temperature (SPC Lo) = 70ºF SAT Setpoint (Rst) = 120ºF

VFD Percentage Heat Reset:

VFD Percentage (VFD) = 30% SAT Setpoint (SAT) = 90ºF VFD Percentage (VFD) = 70% SAT Setpoint (Rst) = 120ºF

Input Voltage Heat Reset:

Input Voltage (VLT) = 0 Volts SAT Setpoint (SAT) = 90ºF Input Voltage (VLT) = 10 Volts SAT Setpoint (Rst) = 120ºF

In the Heating Mode in a Single Zone VA V application, the Supply Fan VFD speed will proportionally modulate as the Space T emperature falls within the range set on this screen. Upon entering the Heating Mode, the fan will start at 50% and modulate up to 100% as the Space T emperature falls from the SpcHi Setpoint to the SpcLo Setpoint. The SpcHi Setpoint should be the same as the Space Heating Setpoint (Mode Enable Setpoint) from Setpoint Screen #1. The SAT and RST Setpoints on the right side of the screen are not used.

VCM-X / RNE Spts

Heat Rst Source Spts SpcHi: 70 SAT: 120º SpcLo: 70 RST: 120º

If no Reset Source has been conﬁ gured in Conﬁ guration Screen #4, then this screen will read Heat Rst Not Conﬁ g and will not be used. If a Reset Source has been conﬁ gured in Conﬁ guration Screen #6, then the names of the values on the left side of this screen will correspond to the Reset Source that was conﬁ gured. This screen will then allow you to input the upper and lower limits for the range of values of the Reset Source on the left side of the screen and will show the corresponding Heating Supply Air SAT and Rst Limit values that you entered on the previous screen. Single Zone VAV Reset of the Supply Fan VFD is addressed in the last paragraph.

Please note that the SAT and Rst Limit values on the right side of this screen cannot be changed on this screen; they are simply displayed from what was entered on the Setpoint Screen #6. For each line, the value on the left corresponds to the value on the right. So if the Space T emperature Sensor has been conﬁ gured as the Reset Source, then when the Space Temperature is at or above the SpcHi T emperature Setpoint, the Supply Air Heating Setpoint will be reset to its lowest value, the SAT Setpoint. If the Space T emperature is at or below the SpcLo Setpoint, the Supply Air Heating Setpoint will be reset to its highest value, the Heating Rst Limit. Then, as the Space Temperature moves from its low value to its high value, the Supply Air Heating Setpoint will be proportionally reset from its high value to its low value.

Setpoint Screen #8 - Stage Control Window

VCM-X / RNE Spts

Stage Control Window

Cooling.........: 5ºF

Heating.........: 5ºF

When the Unit Controller is in Cooling Mode, if the Supply Air Temperature drops below the Active Supply Air Temperature Setpoint minus the Cooling Stage Control Window value, a Cooling Stage will be deactivated after its Minimum Run Time. In the Heating Mode, if the Supply Air Temperature rises above the Active Supply Air T emperature Setpoint plus the Heating Stage Control Window value, a Heating stage will be deactivated after its Minimum Run Time. This staging window is also used for the coil temperature during Dehumidiﬁ cation Mode.

Description Minimum Default Maximum

Stage Control Window Cooling 5ºF 5ºF 30ºF

Stage Control Window Heating 5ºF 5ºF 30ºF

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #9 - Outdoor Air Lockouts

VCM-X / RNE Spts

Outdoor Air Lockouts

Cooling......: 50ºF

Heating......: 70ºF

The Unit Controller will Lockout Mechanical Heating or Cooling when the Outdoor Air (OA) Temperature is above or below these Setpoints.

On Air to Air Heat Pump units, Compressor Cooling and Heating can only operate if the OA Temperature is above the Outdoor Air Cooling Lockouts. If using the VCM-X WSHP (Water Source Heat Pump) Controller, the OA Cooling Lockout is ignored. Since Emergency Heat can only be used below the Compressor Lockouts, Emergency Heat is therefore not available on WSHP units using the VCM-X WSHP Controller.

Description Minimum Default Maximum

OA Lockouts Cooling 0ºF 50ºF 100ºF

OA Lockouts Heating 50ºF 70ºF 150ºF

Setpoint Screen #10 - Cutoff Temperature

VCM-X / RNE Spts

Cutoff Temperatures

Lo SAT.......: 40ºF

Hi SAT.......: 170ºF

The Unit Controller will temporarily disable Heating or Cooling if while in Heating or Cooling Mode the Supply Air Temperature rises above the High SA T Cutoff Temperature Setpoint or falls below the Low SAT Cutoff Temperature Setpoint. See the VCM-X Controller Technical

Guide, VCM-X Modular E-BUS Controller Technical Guide, or RNE Controller Technical Guide for detailed information on the Low and

High Supply Air Temperature Cutoff sequence of operation.

Description Minimum Default Maximum

Lo SAT Cutoff 0ºF 40ºF 250ºF

Hi SAT Cutoff 0ºF 170ºF 250ºF

Setpoint Screen #11 - Minimum Supply Fan VFD Speed For Heating

VCM-X / RNE Spts

Minimum Supply

Fan VFD Speed

For Heating..: 30%

If the Supply Fan VFD Signal falls below the Minimum Supply Fan VFD Speed For Heating Setpoint, Heating will be disabled.

Description Minimum Default Maximum

Min Supply Fan VFD

Speed For Heating

0% 30% 100%

Setpoint Screen #12 - Morning Warm Up Temp

VCM-X / RNE Spts

Morning WarmUp

Target Temp: 72º F

Max Length.: 60 Min

When the Unit Controller is conﬁ gured for VAV operation and the con- troller enters the Occupied Mode, the controller looks at the Return Air Temperature to determine if the unit should initiate Morning Warm-up Mode. If the Return Air Temperature is below the Morning Warm-up Tar get T emperature and the Max Length is greater than “0,” the controller will initiate Heating. This is considered Morning W arm-up and will run until the Return Air Temperature rises above the Morning Warm-up Target Temperature or until the Max Length Setpoint time expires.

Description Minimum Default Maximum

Morning Warm Up

Target Temp

Morning Warm Up

Max Length

50ºF 72ºF 90ºF

0 Min 60 Min 240 Min

Setpoint Screen #13 - Dehumidiﬁ cation Indoor RH & OA Dewpoint

VCM-X / RNE Spts

Dehumidification Spt

Indoor RH....: 50%

OA Dewpoint..: 55ºF

On VA V or CAV conﬁ gured units that are not using 100% Outdoor Air , when the Indoor Relative Humidity percentage rises above the Indoor RH Setpoint, the unit will start operating in Dehumidiﬁ cation Mode.

If an Indoor Humidity Sensor is installed, the unit will reset the Coil Suction Temperature Setpoint as needed to maintain this Indoor RH Setpoint. This includes VAV, CAV and MUA applications.

On MUA conﬁ gured units that are using 100% Outdoor Air, when the Outdoor Air Dewpoint Temperature rises above the OA Dewpoint Setpoint, the unit will start operating in Dehumidiﬁ cation Mode.

Description Minimum Default Maximum

Dehumidiﬁ cation Setpoint

Indoor RH

Dehumidiﬁ cation Setpoint

OA Dewpoint

1% 50% 100%

35ºF 55ºF 80ºF

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #14 - Dehumidiﬁ cation Coil Temperature

VCM-X / RNE Spts

Dehumidification

Coil Temperature

Setpoint.....: 45ºF

During the Dehumidiﬁ cation Mode, the Unit Controller uses the cal- culated Coil Temperature to activate DX Cooling based on this Dehumidiﬁ cation Coil Temperature Setpoint. The controller uses a Suction Pressure Transducer to read Suction Pressure (the Saturation Vapor Pressure of the Refrigerant) and converts this Suction Pressure reading to a Coil Temperature value. This calculation is based on using R22 or R410A refrigerant only and will not work with any other refrigerant. This setpoint determines the number of compressor stages that need to be activated to maintain the Dehumidiﬁ cation Coil T emperature Setpoint.

Description Minimum Default Maximum

Dehumidiﬁ cation Coil Temperature Setpoint

35ºF 45ºF 70ºF

Setpoint Screen #15 - Cooling Head Pressure Setpoint

VCM-X / RNE Spts

Cooling

Head Pressure

Setpoint: 315PSI

based on the highest head pressure reading of up to 4 Head Pressure Sensors. This screen only applies if using the VCM-X E-BUS Controller, or RNE Controller.

See the One Condenser Head Pressure Module Technical Guide, the

Two Condenser Head Pressure Module Technical Guide, or the RNE Controller Technical Guide for detailed information.

Description Minimum Default Maximum

Reheat Head Pressure

Setpoint

200 PSI 400 PSI 400 PSI

Setpoint Screen #17 - Economizer OAT/WB Enable

VCM-X / RNE Spts

Economizer Setpoints

OAT/WB Enable: 55ºF

If an Outdoor Air Humidity Sensor is not connected to the Unit Controller and the Outdoor Air Temperature falls below this Setpoint, the Economizer can be used for Free Cooling. If an Outdoor Air Humidity Sensor is connected to the controller, then a Wetbulb Temperature will be calculated and used instead of the Outdoor Air Drybulb Temperature to determine when Free Cooling can be used.

Description Minimum Default Maximum

Economizer Setpoints

OAT/WB Enable

0ºF 55ºF 80ºF

If you are using the Head Pressure Module, this is the Cooling Setpoint for control of the condenser fan speed. This is based on the highest head pressure reading of up to 4 Head Pressure Sensors. This screen only applies if using the VCM-X E-BUS Controller, or RNE Controller .

See the One Condenser Head Pressure Module Technical Guide, the

Two Condenser Head Pressure Module Technical Guide, or the RNE Controller Technical Guide for detailed information.

Description Minimum Default Maximum

Cooling Head Pressure

Setpoint

200 PSI 315 PSI 400 PSI

Setpoint Screen #16 - Reheat Head Pressure Setpoint

VCM-X / RNE Spts

Reheat

Head Pressure

Setpoint: 400PSI

If you are using the Head Pressure Module, this is the Reheat Setpoint for control of the condenser fan speed during dehumidiﬁ cation. This is

Setpoint Screen #18 - Economizer Minimum Position & Control Rate

VCM-X / RNE Spts

Economizer Setpoints Min Position.: 10 % Control Rate.: 90

The Economizer (OA Damper) Min Position Setpoint is maintained during the Occupied Mode even if the Economizer is disabled due to the OA Temperature or Wetbulb Temperature being above the Economizer Enable Setpoint. The Control Rate Setpoint allows you to adjust the Economizer to modulate the OA Damper Actuator faster or slower as desired. The Control Rate Setpoint range is 10-99. Larger numbers make the Economizer Outdoor Air Damper Actuator modulate faster, smaller numbers make the Outdoor Air Damper Actuator modulate slower.

Description Minimum Default Maximum

Economizer Min Position 0% 10% 100%

Economizer Control Rate 10 90 99

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #19 - Outdoor Air CFM Control

VCM-X / RNE Spts

OA CFM CONTROL Min CFM.: 0.10 Kcfm Max CFM.: 0.10 Kcfm

If controlling the Outdoor Air Damper to a CFM setpoint, this screen allows you to set the design Minimum and Maximum required Outdoor Airﬂ ow CFM values for the Air Handler. The OA Max CFM limits the damper operation during CO2 override conditions. K = 1000

Description Minimum Default Maximum

OA Minimum CFM 0.10 Kcfm .10 Kcfm 200 Kcfm

OA Maximum CFM 0.10 Kcfm .10 Kcfm 200 Kcfm

Setpoint Screen #20 - Outdoor Air CFM Deadband

VCM-X / RNE Spts

OA CFM CONTROL OA CFM DB...: 10CFM

Setpoint Screen #22 - CO2 Protection Limit

VCM-X / RNE Spts

CO2 Protection Limit Max Level.: 900 PPM Reset Rnge: 100 PPM

When the CO2 level rises above the CO2 Protection Limit Max Level, the Economizer’s Minimum Position will begin to reset open proportionally between the CO2 Protection Limit Max Level Setpoint and the Reset Range Setpoint. The Reset Range value is added to the Max Level value. If the CO Range, the Economizer will be opened to its Maximum Economizer

levels are equal to or above the Max Level plus the Reset

Position if high CO2 levels occur.

Description Minimum Default Maximum

CO2 Protection Limit

Max Level

CO2 Protection Limit

Reset Range

0 PPM 900 PPM 3000 PPM

0 PPM 100 PPM 1500 PPM

Setpoint Screen #23 - Static Setpoint, Deadband & Control Rate

The is the deadband above and below the OA CFM Control Setpoint which helps prevent hunting.

Description Minimum Default Maximum

OA CFM Deadband 0 CFM 10 CFM 20,000 CFM

Setpoint Screen #21 - Economizer Maximum Position if High CO

Maximum Economizer

Position if High CO2

Level Occurs.: 100%

This Setpoint allows you to set the Maximum Position the Economizer will open if high CO Economizer Position Setpoint is used to limit the amount of Outdoor Air that will be introduced to the HVAC unit in order to ensure the unit is operating within its Heating and Cooling design limitations. As shown in the table below, the Minimum setting for this Setpoint is the value previously set for the Economizer Min Position Setpoint.

Description Minimum Default Maximum

Maximum Economizer

Position If High CO2

Level Occurs

Level

VCM-X / RNE Spts

conditions occur in the space. The Maximum

Economizer

Minimum

Position

100% 100%

VCM-X / RNE Spts Static Spt...: 0.50”

Deadband.....: 0.10”

Control Rate.: 10 s

For VA V units, a Supply Fan VFD or Bypass Damper Actuator is used to maintain the Duct Static Pressure Setpoint. The Static Pressure Output Signal varies to control the Static Pressure Setpoint. If the Duct Static Pressure is above the Static Setpoint plus the Deadband, the Static Pressure Output Signal will be reduced at every Control Rate interval. If the Static Pressure is below the Static Setpoint minus the Deadband, the Output signal will be increased at every Control Rate interval.

The Duct Static Pressure Control Output Signal is a non-conﬁ gurable Direct Acting Signal (0-10 VDC). This can be used to directly connect to a Supply Fan VFD without any modiﬁ cations.

When you are using a Bypass Damper Actuator to control the Duct Static Pressure, you must set up the Bypass Damper Actuator or the Bypass Damper so that it is Reverse Acting in operation. The Output Signal increases (closes Bypass Damper) if the Duct Static Pressure is below the Duct Static Pressure Setpoint by the Deadband amount and the Output Signal decreases (opens Bypass Damper) if the Static Pressure is above the Setpoint by the Deadband amount.

Description Minimum Default Maximum

Static Spt 0.10″ WG 0.50″ WG 3.0″ WG

Deadband 0.10″ WG 0.10″ WG 1.0″ WG

Control Rate 1 Sec 10 Sec 30 Sec

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #24 - Building Pressure

VCM-X / RNE Spts

Building Pressure

Setpoint....: 0.10”

Deadband....: 0.02”

Direct Acting Control

If an Exhaust Fan Relay is conﬁ gured, when the Building Static Pres- sure rises above the Building Pressure Setpoint plus the Deadband, the Exhaust Fan Relay will activate. It will remain on until the Building Pressure falls below the Building Pressure Setpoint minus the Deadband. If Modulating Building Pressure is conﬁ gured, when the Building Static Pressure rises above the Building Pressure Setpoint plus the Deadband, the Building Pressure Output Signal will increase until the Building Static Pressure falls within the Deadband. If the Building Static Pressure falls below the Building Pressure Setpoint minus the Deadband, the Building Pressure Output Signal will decrease until the Building Static Pressure rises within the Deadband. The Building Pressure Output Signal is conﬁ gurable for 0-10 or 2-10 VDC. For more detailed operation information, see the VCM-X Controller Technical Guide, VCM-X Modular E-BUS Controller Technical Guide, or RNE Controller Technical Guide for the complete Building Pressure Control Sequence of Operation.

Reverse Acting Control

The Building Pressure Output Signal remains a Direct Acting 0-10 or 2-10 VDC signal, but the logic is reversed. On a drop in Building Static Pressure below the Building Pressure Setpoint minus the Deadband, the Building Pressure Output Signal will increase.

Description Min. Default Max.

Building Pressure Spt -0.20″ WG 0.10″ WG 0.20″ WG

Building Pressure

Deadband

0.01″ WG 0.02″ WG 0.10″ WG

Decreasing this percentage decreases the airﬂ ow through the Return Air Bypass Damper by causing the Return Air Damper to move further towards its open position in relation to the Return Air Bypass Damper moving towards its closed position.

Description Minimum Default Maximum

Return Air Bypass

Damper Factor

0% 40% 100%

Setpoint Screen #26 - Supply Fan Starting Delay Timer

VCM-X / RNE Spts

Fan Starting Delay

Timer...: 255 s

This is the Supply Fan Starting Delay Timer initiated whenever the Unit Controller initiates Supply Fan operation. This is useful when you are using multiple HVAC units and want to be sure that all the units do not start at exactly the same time when the Occupied schedule occurs. Each Unit Controller should be set with staggered Fan Starting Delay Timer Setpoint values. When the 255 Second default setpoint is used, it multiplies each Unit Controller’s address by 5 and uses this value in seconds as the Fan Starting Delay Time. This provides a staggered start for each Unit Controller on the system without having to individually set each Unit Controller for its own time delay. For an MUA unit, this should be set to a minimum of 60 seconds to let the OA Damper open.

Description Minimum Default Maximum

Fan Start Delay Timer 0 Sec 255 Sec 255 Sec

Setpoint Screen #27 - Mechanical Heat/Cool Failure Time Period

Setpoint Screen #25 - RAB Damper Factor

VCM-X / RNE Spts

Return Air Bypass

Damper Factor

Setpoint..: 40%

This setpoint is used when your HVAC unit is conﬁ gured for Return Air Bypass Damper control. The Return Air Bypass Damper Factor Setpoint is a percentage value that is used to calculate the Return Air Damper position in relation to the Return Air Bypass Damper position. This provides a method for adjusting the airﬂ ow through the Return Air Bypass Damper.

Increasing this percentage increases the airﬂ ow through the Return Air Bypass Damper by causing the Return Air Damper to move further towards its closed position in relation to the Return Air Bypass Damper moving towards its open position.

VCM-X / RNE Operator Interface SD

VCM-X / RNE Spts

Mechanical Heat/Cool Failures Occur After No Change In 15 Min

When Heating or Cooling Mode is initiated and staging is activated, if the Supply Air Temperature does not rise or fall 5°F within the Mechanical Heat/Cool Failures Occur After No Change For Setpoint time period, a Mechanical Heating or Cooling failure alarm will be generated. The Alarm is for Status Reporting only. The HVAC unit will continue to run.

Description Minimum Default Maximum

Mechanical Heat/Cool

Failures Occur After

No Change For

0 Min 15 Min 255 Min

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #28 - Preheat/ Low Ambient Temperature

VCM-X / RNE Spts

Preheat/Low

Ambient Temperature

Setpoint: 0ºF

For cold climates where freezing temperatures may be experienced, a Pre-Heater relay output can be activated based on the Outdoor Air Temperature to prevent freezing of Water Coils. One of the VCM-X / RNE Relay Outputs must be conﬁ gured for the Pre-Heater control. When conﬁ gured, if the Outdoor Air Temperature falls below the Low OAT Ambient Protection Temperature Setpoint and the HVAC unit is in Occupied Mode, the Pre-Heater relay will activate. This setpoint will also be used to enable the Preheater if the PREHEAT-X Controller is being used in conjunction with the VCM-X Controller.

Description Minimum Default Maximum

Preheat/Low Ambient

Temperature

0ºF 0ºF 70ºF

Setpoint Screen #29 - Max OA Damper Tempering Limit

VCM-X / RNE Spts

Max OA Damper Tempering Limit Setpoint: 50%

The Maximum OA Damper Tempering Limit Setpoint allows you to set the maximum damper position the economizer can open to while the heat is running during the VAV Supply Air tempering mode in this sequence (to prevent potential wasting of energy).

Description Minimum Default Maximum

Maximum Outdoor Air

Damper Tempering Limit

0% 50% 60%

Setpoint Screen #30 - HVAC Schedule

Setpoint Screen #31 - Push-Button Override Duration

VCM-X / RNE Spts

Push-Button Override

Duration....: 2.0 Hr

If the Unit Controller has a Space T emperature Sensor installed and it has the Override Button option, the HV AC unit will initiate Occupied Mode any time the Override Button is pressed and held for less than 3 seconds. The Push-Button Override Duration Setpoint allows you to adjust the amount of time the Override will remain in effect when the Override Button is pressed. T o cancel the Override before the Override Duration time period expires, press the Override Button for 5 to 10 seconds.

Description Minimum Default Maximum

Push-Button

Override Duration

0.0 Hr 2.0 Hr 8.0 Hr

Setpoint Screen #32 - HVAC Mode Sensor Slide Offset

VCM-X / RNE Spts

HVAC Mode Sensor

Slide Offset: 0ºF

If the Unit Controller has a Space Temperature Sensor with the Slide Adjust option installed, the HVAC Mode Enable Heating and Cooling Setpoints can be offset by the HVAC Mode Sensor Slide Offset Setpoint value. When the Slide Adjust bar is in the middle, no of fset will occur. If the Slide Adjust bar is moved all the way to the top of the Sensor , the Heating and Cooling Setpoints will be raised by the Setpoint value you have entered. If the Slide Adjust bar is moved all the way down to the bottom of the Sensor, the Heating and Cooling Setpoints will be lowered by the Setpoint value you have entered.

Description Minimum Default Maximum

HVAC Mode Sensor

Slide Offset

0ºF 0ºF 10ºF

VCM-X / RNE Spts

HVAC Schedule...: 0 [ 0 = Internal ] [1-5 = External ]

The VCM-X / RNE has an Internal Scheduler. If you want the VCM-X or RNE to use its own Internal Schedule to schedule the HVAC unit, enter

<0> for Internal. T o use the External Schedule option, you must have a

GPC Plus controller installed and operating on your system. T o use one of the (5) External Schedules available on the GPC Plus controller, enter the number of the GPC Plus Schedule (1 through 5) you wish to use.

Description Minimum Default Maximum

HVAC Schedule 0 0 5

Setpoint Screen #33 - Heat Pump Auxiliary Heating Delay

VCM-X / RNE Spts

Heat Pump

Auxiliary Heating

Delay: 3 Min

If the Unit Controller is conﬁ gured to operate as a Heat Pump, the Heat Pump Auxiliary Heating Delay Setpoint can be conﬁ gured to provide a time delay period before Auxiliary Heating Stages can be activated once activation of the Compressor Heating Stages have been initiated.

VCM-X / RNE Operator Interface SD

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Description Minimum Default Maximum

Heat Pump

Auxiliary Heating Delay

0 Min 3 Min 30 Min

Setpoint Screen #34 - Heat Pump Defrost Setpoints

VCM-X / RNE Spts

Heat Pump Defrost

Defrost Tmp: 30ºF Defrost Tmr: 30 Min

The Defrost Temp Setpoint is the Coil Suction Temperature at which the unit will go into Defrost Mode during Heat Pump Heating operation. This unit will operate in the Defrost Mode for 10 minutes or until the Head Pressure reaches 450 PSI. The Defrost Timer determines the length of time between Defrost Modes. The length of the Defrost Timer can be automatically be adjusted by the Adaptive Defrost Adjustment described in Setpoint Screen # 35. This Defrost Mode is only available if using the VCM-X E-BUS Controller or RNE Controller and a Head Pressure Module. A Suction Pressure Transducer is also required. This screen only applies if using the VCM-X E-BUS Controller or RNE Controller with a Suction Pressure Sensor, a Head Pressure Module, and Head Pressure Transducer(s). This screen does not apply if using the VCM-X WSHP Controller and a WSHP Module.

Description Minimum Default Maximum

Heat Pump Defrost Temp 0ºF 30ºF 50ºF

Heat Pump Defrost Timer 10 Min 30 Min 90 Min

Setpoint Screen #35 - Adaptive Defrost Adj. Setpoint

VCM-X / RNE Spts Adaptive Defrost

Adj. Setpoint: 0 MIN

Setpoint Screen #36 - Heat Wheel Defrost

VCM-X / RNE Spts

Heat Wheel Defrost

Setpoint: 32ºF

The unit will go into Heat Wheel Defrost Mode when the Outdoor Air is below this setpoint.

Description Minimum Default Maximum

Heat Wheel Defrost 0ºF 32ºF 50ºF

Setpoint Screen #37 - Internal Schedule Optimal Start Soak Multiplier

VCM-X / RNE Spts

Internal Schedule

Optimal Start Soak

Multiplier: 0.0

The Internal Schedule Optimal Start Soak Multiplier Setpoint is a multiplier that if set to a number greater than 0 will be used as a multiplier for calculating the Optimal Start Time for the HVAC unit. This multiplier is only applied if the unit has been off for more than 24 hours. See the

VCM-X Controller T echnical Guide, VCM-X Modular E-BUS Controller T echnical Guide, or RNE Controller T echnical Guide for more detailed

information regarding the Optimal Start. This multiplier is only applied if you are using the Unit Controller Internal Schedule.

Description Minimum Default Maximum

Internal Schedule Optimal

Start Soak Multiplier

0.0 0.0 5.0

Setpoint Screen #38 - Trend Log Interval

Once initiated, the Defrost Mode is active until the Head Pressure reaches 450 PSIG or until a 10 minute timer has expired. Enter a value greater than zero to enable the Adaptive Defrost Adjustment of the Heat Pump Defrost Timer (Screen #34). This adjustment value will be subtracted from the Heat Pump Defrost Timer if the Defrost Mode lasts the entire 10 minutes. A proportion of this adjustment value will be added to the Heat Pump Defrost Timer if the Defrost Mode only lasts between 8 minutes and 0 minutes. This screen only applies if using the VCM-X Modular Controller or RNE Controller with a Suction Pressure Sensor, a Head Pressure Module, and Head Pressure Transducer(s). This screen does not apply if using the VCM-X WSHP Controller and a WSHP Protection Module.

Description Minimum Default Maximum

Adaptive Defrost Adj. 0 Min 0 Min 30 Min

VCM-X / RNE Operator Interface SD

VCM-X / RNE Spts

Trend Log

Interval: 15 MIN

An internal Trend Log is constantly updated at a rate equal to this value.

Description Minimum Default Maximum

Trend Log Interval 1 Min 15 Min 60 Min

VCM-X / RNE SETPOINTS

VCM-X / RNE Setpoint Screens

Setpoint Screen #39 - PREHEAT-X Cooling Mode and Heating Mode Setpoints

VCM-X / RNE Spts

Preheat-X Spts

Cooling Mode: 40.0ºF

Heating Mode: 60.0ºF

If using the Preheat-X Controller with the VCB-X, this screen allows you to set the Preheat setpoint you want to control to during the Cooling and the Heating Modes.

Description Minimum Default Maximum

Preheat-X Cooling Mode Setpoint

Preheat-X Heating Mode Setpoint

35.0ºF

(1.66ºC)

35.0ºF

(1.66

ºC)

40.0ºF

(4.5ºC)

60.0ºF

(15.5ºC)

90.0ºF

(32.2ºC)

90.0ºF

(32.2ºC)

Setpoint Screen #40 - PREHEAT-X Venting Mode Setpoint

VCM-X / RNE Spts

Preheat-X Spts Venting Mode:

50.0ºF

Setpoint Screen #42 - Sensor Calibration for RAT & OAT

VCM-X / RNE Spts

Sensor Calibration

RAT: XX.Xº 0.00º OAT: XX.Xº 0.00º

If the Return Air or Outdoor Air T emperature Sensors are reading incor rectly, you can use this option to enter an offset temperature to adjust the Sensor’s Temperature. Enter a positive Sensor Calibration value to raise the Return Air T emperature and/or Outdoor Air T emperature Sensor reading and a negative value to lower the Sensor reading.

Description Minimum Default Maximum

Sensor Calibration RAT -100.0ºF 0.0ºF +100.0ºF

Sensor Calibration OAT -100.0ºF 0.0ºF +100.0ºF

Setpoint Screen #43 - Sensor Calibration for COIL

VCM-X / RNE Spts

Sensor Calibration

COIL: XX.Xº 0.00º

If using the Preheat-X Controller with the VCB-X, this screen allows you to set the Preheat setpoint you want to control to during the Vent Mode.

Description Minimum Default Maximum

Preheat-X Venting Mode Setpoint

35.0ºF

(1.66ºC)

50.0ºF

(10.0ºC)

90.0ºF

(32.2ºC)

Setpoint Screen #41 - Sensor Calibration for SPC & SAT

VCM-X / RNE Spts

Sensor Calibration

SPC: XX.Xº 0.00º SAT: XX.Xº 0.00º

If the Space or Supply Air Temperature Sensors are reading incorrectly, you can use this option to enter an offset temperature to adjust the Sensor’s T emperature. Enter a positive Sensor Calibration value to raise the Space T emperature and/or Supply Air Temperature Sensor reading and a negative value to lower the Sensor reading.

Description Minimum Default Maximum

Sensor Calibration SPC -100.0ºF 0.0ºF +100.0ºF

Sensor Calibration SAT -100.0ºF 0.0ºF +100.0ºF

If the Coil T emperature reading is too high, enter a negative calibration offset to decrease the reading. If it is too low, enter a positive value to increase the reading.

Description Minimum Default Maximum

Sensor Calibration COIL -30.0ºF 0.0ºF +30.0ºF

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screen Index

Status Screen #1 HVAC Mode Status Screen #2 Cooling/Heating/Economizer Status Status Screen #3 Mode Enable Temperature and

Cooling and Heating Setpoints Status Screen #4 Current SAT Temperature and Setpoint Status Screen #5 Space Temperature, Return Air

Temperature, and Slide Adjust Status Screen #6 VCM-X Leaving Water Temperature A

OR RNE Leaving Water Temperature 1 Status Screen #7 VCM-X Leaving Water Temperature B

OR RNE Leaving Water Temperature 2 Status Screen #8 Coil Temperature or Lowest Coil and

Coil Temperature Setpoint Status Screen #9 Current Outdoor Air Temperature and

Current Outdoor Air Relative Humidity Status Screen #10 Current Calculated Outdoor Air

Dewpoint and Current Dewpoint Temperature

Status Screen #11 Current Indoor RH Percentage and Current Indoor RH Setpoint Percentage

Status Screen #12 Current Static Pressure and Output Percentage

Status Screen #13 Economizer Percentage, Outdoor Air Wetbulb/Drybulb, and Current CO Level

Status Screen #14 Title 24 Economizer Feedback Status Status Screen #15 Outdoor Air CFM & Outdoor Air

Setpoint Status Screen #16 Supply Air CFM & Return Air CFM Status Screen #17 Current Building Pressure & Output

Percentage Status Screen #18 MODGAS Output Percentage &

MHGRV Output Percentage

Status Screen #19 Current Modulating Heating & Cooling Output Signal Percentage

Status Screen #20 VCM-X Coil Temperatures for Full Digital,Water Source Heat Pump or Dual Digital OR RNE Coil Temperatures for Full Digital or Water Source Heat Pump

Status Screen #21 VCM-X Coil Temperatures for Full Digital,Water Source Heat Pump or Dual Digital OR RNE Coil Temperatures for Full Digital or Water Source Heat Pump

Status Screen #22 VCM-X Full Digital Module Signal, Water Source Heat Pump Module Signal or Dual Digital Module Signal OR RNE Full Digital Module Signal or Water Source Heat Pump Module Signal

Status Screen #23

Reheat Setpoint

Status Screen #24 Head Pressure and Condenser Fan #1 Speed

Status Screen #25 Head Pressure and Condenser Fan #2 Speed

Status Screen #26 Head Pressure and Condenser Fan #3 Speed

Status Screen #27 Head Pressure and Condenser Fan #4

Speed Status Screen #28 Current Preheat-X Leaving Air

Temperature and Entering Air Temperature

Status Screen #29 Current Preheat-X Modulating Position and Active Stages

Status Screen #30 Return Air Bypass Damper Signal & Bypass Damper Signal

Status Screens #31-51 Supply Fan and Other Relays Alarm Status Screems Alarm Conditions

Current Head Pressure Cooling or

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status

From any menu screen, press <STATUS>. The Unit Selection Scr een, shown below, will appear requesting that you enter the unit ID number.

Unit Selection

Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the correct unit ID number of the VCM-X or RNE Controller you want to view and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established, the *00* at the bottom

will disappear. Then Press

<ENTER> to save entered data and press <> to scroll through

the screens.

NOTE: If the *00* remains, it indicates a communication failure

Status Screen 1 - Mode

Line 2 Displays one of the following:

Unoccupied Mode Remote FRC Occupied Occupied Mode Override Mode Holiday Mode Zone Demand! Forced Schedule Mode OUTPUT FORCE MODE! SUPPLY AIR CUTOFF! High CO2 Level Mode!

Line 3 Displays one of the following: Off Mode Dehumid. Mode Defrost Mode Vent Mode Cool Dehumid. Mode Cool Mode Heat Dehumid. Mode Heat Mode Warm Up Mode

Line 4 Displays one of the following:

MM/DD/YY HH:MM XX (XX = AM or PM) Fan Starting Delay and then time will display xx Left in WarmUp (Number of Minutes Left)

press <>. You will then see Setpoint Screen #1.

to the controller.

VCM-X / RNE v1.00

Occupied Mode

Vent Mode

02/15/10 05:00 PM

Status Screen 2 - Cooling, Heating, Economizer

VCM-X / RNE v1.00

Cooling Enabled Heating Enabled

Economizer Disabled

Line 2 Displays one of the following:

Cooling Enabled Cooling Disabled

Line 3 Displays one of the following:

Heating Enabled Heating Disabled

Line 4 Displays one of the following:

Economizer Enabled Economizer Disabled

NOTE: On a non-Heat Pump unit conﬁ gured for Make-Up Air

Control, the Heating and Cooling Lockouts are ignored, so Heating and Cooling will always show enabled.

Status Screen 3 - Mode Enable Temperature & Mode Cooling and Heating Setpoints

VCM-X / RNE v1.00

Enable Tmp.: XX.XºF Cool Spt: XX.XºF Heat Spt: XX.XºF

Line 2 Mode Enable Temperature Can be the Supply Air Temperature, Return Air

Temperature, Outdoor Air Temperature, or Space Temperature, depending on which one has been conﬁ gured as the Mode Enable Sensor.

Line 3 Cooling Mode Setpoint Based on the current Occupied/Unoccupied Mode

of operation.

Line 4 Heating Mode Setpoint

Based on the current Occupied/Unoccupied Mode of operation.

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 4 - Supply Air Temperature & Setpoint

VCM-X / RNE v1.00

Supply Air.: XX.XºF Supply Spt.: XX.XºF

Line 2 Current Supply Air Temperature

The Supply Air Temperature is always required. If a Supply Air Temperature Sensor is not installed, the VCM-X / RNE Controller will not operate correctly and will display 0°F.

Line 3 Current Active Supply Air Setpoint This is the Supply Air Setpoint for the mode that the

unit is currently operating in. If the Supply Air Reset is conﬁ gured, this is the calculated setpoint based on the current Reset Source conditions.

Status Screen 5 - Space Temp, Return Air & Slide Adjust

VCM-X / RNE v1.00

Space Tmp.: XX.XºF Return Air.: XX.XºF Slide Adj.: XX.XºF

Line 2 Space Temperature

If you are using a Space Temperature Sensor, this line will display the current Space Temperature during the Occupied or Unoccupied Mode.

Line 3 Return Air Temperature

This sensor is optional. If a Return Air Temperature Sensor is not used, it will display 0°F.

Line 4 Slide Adjust

This is the current value of the Space Temperature offset based on the position of the slide adjust switch on the Space Sensor.

Line 2-3 Leaving Water Temperature A

If using the VCM-X Controller and you have a Water Source Heat Pump Unit installed, this screen will appear and display the Leaving Water Temperature of the unit. If this unit has two leaving water temperature sensors, this is

the Leaving Water Temperature of System A.

Status Screen 6 / RNE - Leaving Water Temperature 1

RNE v1.00

Leaving Water 1

Temp A: 0.0ºF Temp B: 0.0ºF

Line 2 Leaving Water Temperature 1 If using the RNE Controller and you have a Water Source

Heat Pump Module installed or if there are two Water Source Heat Pump Modules installed and this is the ﬁ rst Module, then this screen will display Water Temperatures of this Module. If not, this screen will display 0°F.

Line 3 Leaving Water Temperature A

This line will display the Leaving Water Temperature of the ﬁ rst Leaving Water Temperature Sensor on a Water Source Heat Pump Module. If using (2) Water Source Heat Pump Modules, this will be the ﬁ rst sensor on the Module with address 1.

Line 4 Leaving Water Temperature B

This line will display the Leaving Water Temperature of the second Leaving Water Temperature Sensor on a Water Source Heat Pump Module. If using (2) Water Source Heat Pump Modules, this will be the second sensor on the Module with address 1.

Status Screen 7 / VCM-X - Leaving W ater Temperature B

VCM-X v1.00

Leaving Water

Temp B: 0.0ºF

Status Screen 6 / VCM-X - Leaving Wa ter Temperature A

VCM-X v1.00

Leaving Water

Temp A: 0.0ºF

VCM-X / RNE Operator Interface SD

Line 2-3 Leaving Water Temperature B

If using the VCM-X Controller and you have a Water Source Heat Pump Unit installed with two leaving water temperature sensors, this screen will display the Leaving Water Temperature of System B.

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 7 / RNE - Leaving Water Temperature 2

RNE v1.00

Leaving Water 2

Temp A: 0.0ºF Temp B: 0.0ºF

Line 2 Leaving Water Temperature 2 If using the RNE Controller and a second Water Source

Heat Pump Module has been installed and conﬁ gured, this screen will display Water Temperatures. If not, this screen will display 0°F.

Line 3 Leaving Water Temperature A

Line 4 Leaving Water Temperature B

Status Screen 9 - Outdoor Air Temperature & Outdoor Air Relative Humidity

VCM-X / RNE v1.00

Outdoor Tmp: XX.XºF Outdoor RH.: XX.X%

Line 2 Current Outdoor Air Temperature

If an Outdoor Air Temperature Sensor has been installed and conﬁ gured on the unit or if an Outdoor Air Broadcast has been conﬁ gured on another Unit Controller on the system, the Outdoor Air Temperature will appear on this line. If not, this line will display a temperature that is half way between the Cooling and Heating Lockout Setpoints.

Line 3 Current Outdoor Air Relative Humidity

If an Outdoor Humidity Sensor has been installed and conﬁ gured on the Unit Controller, the Outdoor Air Relative Humidity Percentage will appear on this line. If not, this line will display 0%.

Status Screen 10 - OA Dewpoint & Dewpoint Temp

Status Screen 8 - Coil Temp & Setpoint

VCM-X / RNE v1.00

Coil Tmp...: XX.XºF Coil Tmp Spt: XX.XºF

Line 2 Coil Temperature or Lowest Coil

If a Suction Pressure Transducer has been installed and conﬁ gured on the unit, the calculated Evaporator Coil Temperature will appear on this line. If not, this line will display 0°F.

If this unit has multiple digital scroll compressors and has a Full Digital Module or Dual Digital Module installed, this line will display Lowest Coil and will display the lowest of the multiple suction temperatures. The coil temperatures of all the coils will be displayed on Status Screens 19 & 20.

Line 3 Coil Temperature Setpoint

During dehumidiﬁ cation, the Coil Suction Temperature Setpoint is automatically reset based on the current space humidity conditions. This is the current calculated Coil Temperature Setpoint based on that reset.

VCM-X / RNE v1.00

OA Dewpoint.: XX.XºF Dewpoint Spt: XX.XºF

Line 2 Current Calculated Outdoor Air Dewpoint Temperature

If both an Outdoor Humidity Sensor and an Outdoor Air

Temperature Sensor have been installed and conﬁ gured on the unit, the calculated Outdoor Air Dewpoint Temperature will appear on this line. If not, this screen displays 0°F.

Line 3 Current Outdoor Air Dewpoint Setpoint The user adjustable Outdoor Air Dewpoint Temperature

Setpoint will appear on this line.

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 11 - Indoor RH & Indoor RH Setpoint

VCM-X / RNE v1.00

Indoor RH....: XXX%

Indoor RH Spt: XXX%

Line 2 Current Indoor Relative Humidity Percentage

If an Indoor Humidity Sensor has been installed and conﬁ gured on the unit, the current Indoor Air Relative Humidity Percentage will appear on this line. The installed Indoor Humidity Sensor can be either a Wall Mounted type or a Return Air Mounted type. If an Indoor Humidity Sensor is not installed, this line will display 0%.

Line 3 Current Indoor Relative Humidity Setpoint Percentage

This is the adjustable Indoor Air Relative Humidity Setpoint Percentage that has been set by the user.

Status Screen 12 - Static Pressure & Output %

VCM-X / RNE v1.00

Static Pr...: X.XX”

Press Output: XXX%

[Optional Output]

Line 2 Current Static Pressure

Requires the installation and wiring of a Duct Static

Pressure Sensor. If you do not have a Duct Static Pressure Sensor correctly installed and wired to the controller, this line will display “0.0”.

Line 3 Current Static Pressure Output Signal Percentage

Indicates the output signal percentage being supplied to the VFD Controller or Bypass Damper Actuator when you have conﬁ gured one of these options for your HVAC unit.

Line 2 Current Economizer Open Percentage

The Economizer is optional. This shows the Outdoor Air Damper open percentage. If Economizer Control is not conﬁ gured, it will display 0%.

Line 3 Current Wetbulb/Drybulb Temperature

The Outdoor Air Wetbulb Temperature is optional. To display the Outdoor Air Wetbulb Temperature, you must install an Outdoor Air Temperature Sensor (or an Outdoor Air Temperature Broadcast) and an Outdoor Air Relative Humidity Sensor. If these conditions exist, this line will display the calculated Outdoor Air Wetbulb Temperature. If these conditions do not exist, it will display 0°F.

Line 4 Current CO

The CO CO2 Sensor to display the CO2 Level. If a CO2 Sensor is not installed and conﬁ gured, this line will display 0 PPM.

Level

Level is optional. You must install and conﬁ gure a

Status Screen 14 - Title 24 Economizer Feedback Sta tus

VCM-X / RNE v1.00

Economizer

Feedback X%

[Only For Title 24]

Line 3 Economizer Feedback Open Percentage

This shows the Outdoor Air Damper open percentage, whether the unit is conﬁ gured for Title 24 Economizer Control or simply has a Minimum Outdoor Air Damper position conﬁ gured. If Title 24 Economizer Control is not conﬁ gured, it will display 0%.

Line 4 Indicates That This is Only For Title 24 Economizer

Status Screen 15 - Outdoor Air CFM & Setpoint

If you have not conﬁ gured Duct Static Pressure Control, this line will display [No Press Out Confg].

Line 4 Indicates That This is An Optional Output This output may or may not have live data to display.

Status Screen 13 - Economizer %, OA Wetbulb, and CO2 Level

VCM-X / RNE v1.00

Economizer.: XXX % OA Wetbulb.: XX.XºF CO2 Level.: XXXXPPM

VCM-X / RNE Operator Interface SD

VCM-X / RNE v1.00 OA CFM: 0.00 K OA Sp.: 0.00 K

[Optional Input]

Line 2 Outdoor Air CFM

If an outdoor air airﬂ ow monitoring station is being used, this is the current CFM reading of that device. K = 1000

Line 3 Outdoor Air Setpoint

If control of the OA Damper based on CFM is conﬁ gured, this is the controlling setpoint. K = 1000

Line 4 Indicates That This is An Optional Input This input may or may not have live data to display.

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 16 - Supply Air & Return Air CFM

VCM-X / RNE v1.00 SA CFM: 0.00 K RA CFM: 0.00 K

[Optional Inputs]

Line 2 Supply Air CFM

If a supply air airﬂ ow monitoring station is being used, this is the current CFM reading of that device.

Line 3 Return Air CFM

If a return air airﬂ ow monitoring station is being used, this is the current CFM reading of that device. K = 1000

Line 4 Indicates That These are Optional Inputs These inputs may or may not have live data to display.

K = 1000

Status Screen 17 - Building Pressure & Output %

VCM-X / RNE v1.00 Building Pr..: X.XX” Press Output: XXX%

[ Optional Outputs ]

Line 2 Current Building Pressure

Indicates the current Building Pressure. This display

requires the installation of a Building Pressure Sensor. If you don’t have a Building Pressure Sensor correctly

installed and wired to the controller, this line will display “0.0”.

Line 3 Current Building Pressure Output Signal Percentage

Indicates the output signal percentage being supplied to the Exhaust Fan VFD controller or Exhaust Damper Actuator when you have conﬁ gured one of these options for your HVAC unit.

If you have not conﬁ gured Building Pressure Control, this line will display [No Press Out Confg].

Line 4 Indicates That These Are Optional Outputs This output may or may not have live data to display.

Status Screen 18 - MODGAS Output % & MHGRV Output %

VCM-X / RNE v1.00

MODGAS Pos..: XXX% MHGRV Pos...: XXX% [Optional Equipment]

Line 2 Current MODGAS Heating Output Signal

Indicates the percentage of the output signal being supplied

to the MODGAS Controller when you have one connected to your HVAC unit. If you do not have a MODGAS controller connected to your Unit Controller, this screen will indicate [MODGAS NOT CONNECTED].

Line 3 Current MHGRV Reheat Valve Output Signal Percentage

Indicates the percentage of the output signal being supplied to the MHGRV controller when you have one connected to your Unit Controller. If you do not have an

MHGRV controller connected to your Unit Controller, this screen will indicate [MHGRV NOT CONNECTED].

Line 4 Optional Equipment

Indicates that these outputs are optional and therefore may or may not have live data to display.

Status Screen 19 - Mod Heating & Cooling %

VCM-X / RNE v1.00 Mod Cooling: XXX% Mod Heating: XXX%

[ Optional Outputs ]

Line 2 Current Modulating Cooling Output Signal Percentage

Indicates the percentage of the output signal being supplied to a Modulating Cooling device when you have conﬁ gured this option for your HVAC unit. If reverse acting is conﬁ gured, this percentage will be reversed. See the following examples for clariﬁ cation:

Standard Operation:

0-10 VDC 0% = 0 VDC 100% = 10 VDC 2-10 VDC 0% = 2 VDC 100% = 10 VDC

1.5-5.0 VDC 0% = 1.5 VDC 100% = 5.0 VDC Reverse Acting Operation: 0-10 VDC 0% = 10 VDC 100% = 0 VDC 2-10 VDC 0% = 10 VDC 100% = 2 VDC

If you do not have a Modulating Cooling device connected to your HVAC unit and conﬁ gured, this screen will indicate [No Mod Cool Conﬁ g].

If this unit has a Dual Digital Module, Full Digital Module, or Water Source Heat Pump with multiple Digital Scroll Compressors, this line will be blank.

Line 3 Current Modulating Heating Output Signal Percentage

Indicates the percentage of the output signal being supplied to a Modulating Heating device when you have conﬁ gured this option for your HVAC unit. If Reverse Acting operation is conﬁ gured, this percentage will be Reversed. See the following examples for clariﬁ cation:

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

Standard Operation: 0-10 VDC 0% = 0 VDC 100% = 10 VDC 2-10 VDC 0% = 2 VDC 100% = 10 VDC Reverse Acting Operation: 0-10 VDC 0% = 10 VDC 100% = 0 VDC 2-10 VDC 0% = 10 VDC 100% = 2 VDC If you do not have a Modulating Heating device conﬁ gured,

this screen will indicate [No Mod Heat Conﬁ g].

Line 4 Indicates That These Are Optional Outputs

These outputs may or may not have live data to display.

Status Screen 20 / VCM-X - Full Digital Module OR Dual Digital Module

VCM-X / RNE Status Screens

VCMX-M/HP Cnfg ID 102

Dual Digital Temp

Circuit A: X.Xº F Circuit B: X.Xº F

Line 2 Dual Digital Temperature If using a VCM-X E-BUS Modular Controller

with a Dual Digital Module ( OE370-23-DD) or if you are using the VCM-X E-BUS WSHP Controller with two Digital Scroll Compressors, this screen will appear.

Line 3 Circuit A Temperature

This is the current Coil Suction Temperature of Circuit A.

Line 4 Circuit B Temperature

This is the current Coil Suction Temperature of Circuit B.

VCMX-M/HP Cnfg ID 102

Full Digital Temp

Coil A1: X.Xº F Coil A2: X.Xº F

Line 2 Full Digital Temperature If using a VCM-X E-BUS Modular Controller

with a Full Digital Module ( OE370-23-FD-A) or if you are using the VCM-X E-BUS WSHP Controller with multiple Digital Scroll Compressors, this screen will appear.

Line 3 Coil A1 Temperature

This is the current Coil Suction Temperature of Compressor A1.

Line 4 Coil A2 Temperature

This is the current Coil Suction Temperature of Compressor A2.

Status Screen 20 / RNE - Full Digital Module

RNE Cnfg ID 102

Full Digital Temp

Coil A1: X.Xº F Coil A2: X.Xº F

Line 2 Full Digital Temperature If using a Full Digital Module ( OE370-23-FD-A) or

Water Source Heat Pump Module (OE334-23-WPM-A), this screen will appear.

Line 3 Coil A1 Temperature

This is the current Coil Suction Temperature of Compressor A1.

Line 4 Coil A2 Temperature

This is the current Coil Suction Temperature of Compressor A2.

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 21 / VCM-X - Full Digital Module

VCMX-M/HP Cnfg ID 102

Full Digital Temp

Coil B1: X.Xº F Coil B2: X.Xº F

Line 2 Full Digital Temperature If using a VCM-X E-BUS Modular Controller

with a Full Digital Module (OE370-23-FD-A) or if you are using the VCM-X E-BUS WSHP Controller with at least two Digital Scroll Compressors, this screen will appear. Values will show zero if not using 4 Digital Scroll Compressors.

Line 3 Coil B1 Temperature

This is the current Coil Suction Temperature of Compressor B1.

Line 4 Coil B2 Temperature

This is the current Coil Suction Temperature of Compressor B2.

Status Screen 21 / RNE - Full Digital Module

Status Screen 22 / VCM-X - Full Digital Signal OR Dual Digital Signal

VCMX-M/HP Cnfg ID 102

Full Digital

Stage 1 Sig: 0% Stage 2 Sig: 0%

Line 2 Full Digital Signal If using a VCM-X E-BUS Modular Controller

with a Full Digital Module ( OE370-23-FD-A) or if you are using the VCM-X E-BUS WSHP Controller with at least two Digital Scroll Compressors, this screen will appear.

Line 3 Stage 1 Signal Percentage

This is the modulating signal percentage for Compressor 1 (A1) if there are two Digital Scroll Compressors, or for Compressors 1 (A1) and 3 (B1) if there are four Digital Scroll Compressors.

Line 4 Stage 2 Signal Percentage

This is the modulating signal percentage for Compressor 2 (A2) if there are two Digital Scroll Compressors, or for Compressors 2 (A2) and 4 (B2) if there are four Digital Scroll Compressors.

RNE Cnfg ID 102

Full Digital Temp

Coil B1: X.Xº F Coil B2: X.Xº F

Line 2 Full Digital Temperature

If using a Full Digital Module ( OE370-23-FD-A) or Water Source Heat Pump Module (OE334-23-WPM-A), this screen will appear. If not using (2) Full Digital Modules, this screen will show no values.

Line 3 Coil B1 Temperature

This is the current Coil Suction Temperature of

Compressor B1.

Line 4 Coil B2 Temperature

This is the current Coil Suction Temperature of

Compressor B2.

VCMX-M/HP Cnfg ID 102

Dual Digital

Comp A Sig: 0% Comp B Sig: 0%

Line 2 Dual Digital Signal

with a Dual Digital Module ( OE370-23-DD) or if you are using the VCM-X E-BUS WSHP Controller with two Digital Scroll Compressors, this screen will appear.

Line 3 Compressor A Signal

This is the modulating signal percentage for Circuit A Compressor 1 (A1).

Line 4 Compressor B Signal

This is the modulating signal percentage for Circuit B Compressor 1 (B1).

If using a VCM-X E-BUS Modular Controller

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 22 / RNE - Full Digital Signal

RNE Cnfg ID 102

Full Digital

Stage 1 Sig: 0% Stage 2 Sig: 0%

Line 2 Full Digital Signal If using a Full Digital Module ( OE370-23-FD-A) or

Water Source Heat Pump Module (OE334-23-WPM-A) this screen will appear.

Line 3 Stage 1 Signal Percentage

This is the modulating signal percentage for Compressor 1 if there are two Compressors, or for the ﬁ rst two Compressors if there are four Compressors.

Line 4 Stage 2 Signal Percentage

This is the modulating signal percentage for Compressor 2 if there are two Compressors, or for the last two Compressors if there are four Compressors.

Status Screen 23 - Head Pressure Setpoint

Line 2 Condenser Fan #1 or #2 If you are using the VCM-X E-BUS, VCM-X WSHP or

RNE Controller and have a One Condenser or Two Condenser Head Pressure Module attached to the unit, this line displays Condenser Fan #1 or #2.

Line 3 Head Pressure This line indicates the highest of up to 4 current Head

Pressure readings on a One Condenser Head Pressure Module. If using a Two Condenser Head Pressure Module, this line indicates the highest of the ﬁ rst 2 current Head Pressure readings on that module.

Line 4 Condenser Fan Speed

This line displays the speed of the associated Condenser Fan (0-100%) that is currently necessary to maintain the Head Pressure Setpoint.

Status Screen 26 & 27 - Head Pressure Condenser Fan #3 & #4

VCMX-M/RNE Cnfg ID 102 Cond. Fan Sect. #3

Head Pr.....: 0PSI

Cond Fan Spd: 0%

VCMX-M/RNE Cnfg ID 102 Current Head Pr Sp: 0 PSI

Line 2-3 Current Head Pressure Cooling or Reheat Setpoint

If you are using the VCM-X E-BUS Modular, VCM-X E-BUS WSHP, or RNE Controller and have a One Condenser or Two Condenser Head Pressure Module attached to the unit, the Head Pressure Cooling or Reheat Setpoint will display, depending on what mode the Module is in. This status value will show 0 if not in the Cooling or Dehumidiﬁ cation Mode.

Status Screens 24 & 25 - Head Pressure Condenser Fan #1 & #2

VCMX-M/RNE Cnfg ID 102 Cond. Fan Sect. #1

Head Pr.....: 0PSI

Cond Fan Spd: 0%

VCMX-M/RNE Cnfg ID 102 Cond. Fan Sect. #4

Head Pr.....: 0PSI

Cond Fan Spd: 0%

Line 2 Condenser Fan #3 or #4 If you are using the VCM-X E-BUS, VCM-X WSHP or

RNE Controller and have a second Two Condenser Head Pressure Module attached to the unit, this line displays Condenser Fan #3 or #4.

Line 3 Head Pressure This line indicates the highest of the second two Head

Pressure readings of the Two Condenser Head Pressure Module.

Line 4 Condenser Fan Speed

This line displays the speed of the associated Condenser Fan (0-100%) that is currently necessary to maintain the Head Pressure Setpoint.

VCMX-M/RNE Cnfg ID 102 Cond. Fan Sect. #2

Head Pr.....: 0PSI

Cond Fan Spd: 0%

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens

Status Screen 28 - PREHEAT-X Controller Current Leaving Air and Entering Air Temperature

VCM-X / RNE v1.00

Preheat-X Temps Leaving Air: XX.XX Entring Air: XX.XX

Line 3 Current PREHEAT-X Leaving Air Temperature If a Leaving Air Temperature Sensor(s) has been installed

and conﬁ gured on the PREHEAT-X, this screen will display the current Pre-Heat Leaving Air Temperature. If these conditions do not exist, it will display 0°F.

Line 4 Current PREHEAT-X Entering Air Temperature If an Entering Air Temperature Sensor has been installed

and conﬁ gured on the PREHEAT-X, this screen will display the current Pre-Heat Entering Air Temperature. If these conditions do not exist, it will display 0°F.

Status Screen 29 - PREHEAT-X Controller Modulating Position and Active Stages

Status Screen 30 - Return Air Damper Signal & Bypass Damper Signal

VCM-X / RNE v1.00 Return Dmp..: XXX% Bypass Dmp..: XXX%

[Optional Outputs]

Line 2 Current Return Air Damper Signal

Indicates the current Output Signal percentage being sent to

the Return Air Damper Actuator. If you haven’t conﬁ gured a Return Air Bypass Damper, [No Return Dmp Confg] will be displayed instead.

Line 3 Current Return Air Bypass Damper Signal

Indicates the current Output Signal percentage being sent to

the Return Air Bypass Damper Actuator. If you haven’t conﬁ gured a Return Air Bypass Damper, [No Bypass Dmp Confg] will be displayed instead.

Line 4 Indicates That These Are Optional Outputs This output may or may not have live data to display.

Status Screens 31-51 - Supply Fan Relay

VCM-X / RNE v1.00

Preheat-X Status

Mod Pos......: XXX%

Active Stages: X

Line 3 Current PREHEAT-X Modulating Position

VCB-X Controller and are using Modulating Heat, this is the current modulating position of the gas valve

Line 4 Current PREHEAT-X Active Stages

VCB-X Controller, this is the number of Active Stages that have been conﬁ gured in the PREHEAT-X Controller’s # of Heat Stages Conﬁ guration Screen.

If you do have a PREHEAT-X Controller connected to the

If you have a PREHEAT-X Controller connected to the

VCM-X / RNE v1.00

Fan Relay: OFF Cool Stage: OFF Heat Stage: OFF

Line 2 Current Supply Fan Relay Status The letters FRC will appear before the colon if this Relay is

in a Force Mode. On screens 31 to 51, this line will indicate the relays use and the ON/OFF condition for that relay. Possible options are as follows:

Not Used Pre-Heater Heat Stage Alarm Relay

Cool Stage Override Warmup Mode Occupied Rev Valve Economizer (OA Damper) Gas Re-Heat ( HGR Relay) Heat Wheel Exhaust Fan Emergency Heat

Line 3 Current relay status and description of what it is conﬁ gured for

The letters FRC will indicate the relay is forced to its current condition.

Line 4 Current relay status and description of what it is conﬁ gured for

The letters FRC will indicate the relay is forced to its current condition.

VCM-X / RNE Operator Interface SD

VCM-X / RNE STATUS

VCM-X / RNE Status Screens & Alarms

Alarm Status

Press <ALARMS>. The Unit Selection Scr een will be displayed. Enter the Unit ID of the controller you wish to search and press <ENTER>. You must type in the number, even if it is “1”. Once communication is

established, the *00* at the top will disappear. Then The System Manager or Service Tool will search for any active alarms

on the unit and the following screen will appear:

VCM-X / RNE v1.00

NO ALARMS OR

ALARMS PRESENT

SCROLL DOWN TO VIEW

Line 2-3 NO ALARMS! OR ALARMS PRESENT If alarms are present, select VCMX /RNE Alarms or

Module Alarms. Press

alarms.

The screens that follow will display one or more of the following:

VCM-X ALARMS NO SUPPLY AIR TEMP NO OUTDOOR AIR TEMP SPACE SENSOR FAILURE RETURN SENSOR FAILURE MODULE ALARM MECH COOLING FAILURE MECH HEATING FAILURE FAN PROVING ALARM DIRTY FILTER ALARM EMERGENCY SHUTDOWN LO SUPPLY AIR ALARM HI SUPPLY AIR ALARM LOW CONTROL TEMP HIGH CONTROL TEMP CO2 SENSOR FAILURE BAD OUTDOOR AIR CFM TITLE 24 ECONOMIZER AIR TEMP SENSOR FAIL TITLE 24 ECONOMIZER DAMPER FAIL TITLE 24 ECONO ECONOMIZING BUT SHOULDN’T TITLE 24 ECONOMIZER EXCESS OUTDOOR AIR TITLE 24 ECONO NOT ECONOMIZING WHEN IT SHOULD

<> to scroll through all active

press <>.

MODULE ALARMS Head Pressure 1

Head Pressure 2 Full Digital 1 Full Digital 2 WSHP Module 1 WSHP Module 2

Press scroll through all active alarms.

For Alarm Deﬁ nitions, see the VCM-X Modular E-BUS or the RNE Controller Technical Guide.

<ENTER> to select the module. Press <> to

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Conﬁ guration Screens

VAV Zone Conﬁ guration

In order to correctly set up the VAV/Zone Controller, you must ﬁ rst conﬁ gure several parameters in regard to the type of system and operat- ing parameters for the VAV/Zone Controller you have installed. Most of these values and operating parameters are only set once at the initial system setup and are never changed.

Modular Service Tool Instructions

From any Menu Screen, press the <CONFIGURATION> button. The Unit Selection Screen, shown below, will appear requesting that you

enter the unit ID number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the correct unit ID number of the VAV/Zone controller you want to conﬁ gure, and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established, the *00* at the bottom

will disappear. Then Screen #1. Press

scroll through the screens.

NOTE: If the *00* remains, it indicates a communication failure

press <>. You will then see Unit Conﬁ guration

<ENTER> to save entered data and press <> to

to the controller.

The following screen will be displayed:

Change Setpoints Configure Unit Save/Copy/Restore

Scroll down to the ‘Conﬁ gure Unit’ option and press <ENTER>. This will take you to the ﬁ rst Conﬁ guration Screen shown below.

Conﬁ guration Screen #1 - Box Conﬁ guration

XX Box Cnfg IDXXXX

Box Configuration

COOLING ONLY BOX

Use < Or > To Change

This Box Control Code will operate in one of four possible modes. The box designation will display on the top line of all screens. Select one of the following options:

0 = COOLING ONLY BOX (will display as CO Box) 1 = H/C CHANGEOVER BOX (will display as HC Box) 2 = SERIES FAN BOX (will display as SF Box) 3 = PARALLEL FAN BOX (will display as PF Box)

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection *00*

Enter Unit ID#

Selected ID#: XXXX

Then

press <>.

Conﬁ guration Screen #2 - Damper Operation

XX Box Cnfg IDXXXX

Damper Operating

Mode: DIRECT ACTING

Use < Or > To Change

Select Direct Acting or Reverse Acting. If the damper opens in a

clockwise direction, it is DIRECT ACTING. If the damper opens in a counter-clockwise direction, it is REVERSE ACTING.

CAUTION: If you change this setting, you MUST cycle power to the controller to allow it to re-calibrate the damper feedback positions for its new direction of control!

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Conﬁ guration Screens

Conﬁ guration Screen #3 - Voting Zone

XX Box Cnfg IDXXXX

Is This Box a

Voting Zone..: YES

Use < Or > To Change

Select YES if this is a Zoned System so that the box can be included as a voting zone.

Conﬁ guration Screen #4 - Pressure Independent Airﬂ ow Constant

XX Box Cnfg IDXXXX

Pr Independent Boxes

Airflow @ 1” WG

Constant..: 1200 CFM

If this is a Pressure Independent Box, you must enter this airﬂ ow constant so that the CFM readings can be correctly calculated. This airﬂ ow constant is provided by the box manufacturer and depends on the diameter of the duct.

Conﬁ guration Screen #5 - Expansion Relays Heating Stages

Conﬁ guration Screen #7 - Box Heat Allow

XX Box Cnfg IDXXXX Allow Box Heat With

HVAC Heat....: NO

Use < Or > To Change

Select YES to allow the Heating Relay’ s Controlling Box Heat to remain on even when the HVAC unit is in Supply Air Heating Mode. This is used as a method to provide supplemental heat if for some reason the HVAC heat cannot satisfy the heating demand.

Conﬁ guration Screen #8 - Main Fan Status

XX Box Cnfg IDXXXX

This Unit Needs Main

Fan Status...: NO

Use < Or > To Change

This setting only applies to the unoccupied mode of operation. Select YES to activate the heating stages only when the main fan is operating on non-fan terminal units. For series fan terminal units, if this setting is set to YES, the series box fan will only run when the main HVAC unit fan is running or when a space heating demand is made. For series fan terminal units, if this setting is set to NO, the series box fan will only run when a space heating demand is made. This setting has no effect on the parallel ﬂ ow fan terminal unit.

XX Box Cnfg IDXXXX

Expansion Relays

[Optional]

Steps of Reheat.: 2

If you require the VAV/Zone Controller to control reheat for the zone it is installed in, you must include a relay expansion board and then conﬁ gure the number of heating stages (1, 2, or 3) that it will be control- ling whenever there is a heating demand in the space. Enter <0> if you don’t require this option.

Conﬁ guration Screen #6 - Proportional Heating Signal

XX Box Cnfg IDXXXX Proportional Heating Signal..: 0 - 10 VDC Use < Or > To Change

Select 0-10 VDC or 2-10 VDC as the range of the proportional heat output.

Conﬁ guration Screen #9 - Push-Button Override

XX Box Cnfg IDXXXX

Push-Button Override

Group ID #: 1

During Unoccupied Mode, all zones with a corresponding Group ID # will resume Occupied operation whenever any of the zones in that group has its push-button depressed to initiate an override condition. This allows you to group zones in various areas of the building. For example, individual tenants with several ofﬁ ces could restore occupied mode for just their zones and not affect other zones in the building.

The default group ID number for all VA V/Zone Controllers is set at the factory to 1. If you don’t want a speciﬁ c zone(s) to be part of that group, you must give each one a distinct Group ID number between 2 and 16. Setting a zone’s Group ID number to 0 will disable the Space Sensor Override Button function.

If you don’t want a speciﬁ c zone to be a part of any group, enter for its Group ID #.

<0>

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Conﬁ guration Screens

Conﬁ guration Screen #10 - Dump Zone

XX Box Cnfg IDXXXX

Is This A Dump Zone

(No Actuator): NO

Use < Or > To Change

A “Dump Zone” is used when you want to control a duct heater or baseboard heater independently. A VAV/Zone Controller board with a relay expansion board is used for this purpose. No damper or actuator is used. If you need to control an auxiliary heater, select YES; otherwise, select NO.

Conﬁ guration Screen #11 - HVAC Unit is on Separate Loop

XX Box Cnfg IDXXXX

HVAC Unit is on

Separate Loop: NO

Use < Or > To Change

If this system has 1 HVAC unit controlling boxes on multiple loops and the HVAC unit is on a different loop than this box, select YES; otherwise, select NO.

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Setpoint Screens

VAV/Zone Controller Setpoints

Modular Service Tool Instructions

From any menu screen, press <SETPOINTS>. The Unit Selection Screen, shown below, will appear requesting that you enter the unit ID

number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

*00* at the bottom will disappear. Then Setpoint Screen #1. Press <ENTER> to save entered data and press

<> to scroll through the screens.

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

press <>. You will then see

The following screen will be displayed:

Change Setpoints

Configure Unit

Save/Copy/Restore

Scroll to the ‘Change Setpoints’ option and press <ENTER>. This will take you to the ﬁ rst Setpoints Screen shown below.

Setpoint Screen #1 - Occupied Setpoints

XX Box Spts IDXXXX Occupied Setpoints

Cooling.....: XXºF

Heating.....: XXºF

Enter the Occupied Cooling Setpoint as the maximum temperature you would like the zone to reach before modulating the damper open to bring in more cold air to cool the space. Enter the Occupied Heat- ing Setpoint as the minimum temperature you would like the zone to reach before activating the Reheat Stages on the optional Expansion Relay board. If this is a Cooling Only box that doesn’t contain reheat, this setpoint will be ignored.

Description Minimum Default Maximum

Cooling Setpoint 50ºF 74ºF 90ºF

Heating Setpoint 50ºF 70ºF 90ºF

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection*00*

Enter Unit ID#

Selected ID#: XXXX

Then

press <>.

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

VCM-X / RNE Operator Interface SD

Setpoint Screen #2 - Unoccupied Setbacks

XX Box Spts IDXXXX

Unoccupied Setbacks

Cooling SetUp: XXºF Heating SetBk: XXºF

During unoccupied hours, the Occupied Cooling Setpoint is adjusted up by the amount entered for the Cooling SetUp. The Occupied Heating Setpoint is adjusted down by the amount entered for the Heating SetBk.

Description Minimum Default Maximum

Cooling SetUp 0ºF +10ºF +30ºF

Heating SetBk 0ºF -10ºF -30ºF

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Setpoint Screens

Setpoint Screen #3 - AHU Heat Call Space Temp

XX Box Spts IDXXXX

AHU Heat Call

Space Temp...: XXºF

This setpoint allows you to set a Space Temperature that will cause the V AV/Zone Controller to send a call for heat to the HV AC unit. This only occurs in the Unoccupied Mode.

Description Minimum Default Maximum

AHU Heat Call Space Temp 50ºF 70ºF 90ºF

Setpoint Screen #4 - Auxiliary Heat Setpoint

XX Box Spts IDXXXX

Auxiliary Heat

Setpoint..: XXºF

This setpoint allows you to set a Space Temperature that will enable the Auxiliary Heat Relay (Relay 4) on the VAV/Zone Controller Reheat Expansion Board for heating options other than box heat, such as baseboard heat or an external duct heater. This could control a stage of electric heat or an on/off hot water valve. The Auxiliary Heat Relay will energize at .5˚F below this setpoint and will de-energize at .5˚F above this setpoint. The Auxiliary Heat will continue to function regardless of the HVAC Mode the unit is in and at any airﬂ ow condition.

Description Minimum Default Maximum

Auxiliary Heat Setpoint 50ºF 70ºF 90ºF

Description Minimum Default Maximum

Integral 0 0 100

Setpoint Screen #6 - Damper Airﬂ ow Max & Vent Min

XX Box Spts IDXXXX Damper/Airflow Spt

Maximum..: XXX %

Vent Min.: XXX %

The VA V/Zone Controller will not allow the damper or airﬂ ow calcula- tion to exceed the Maximum setpoint while it is allowing the damper to modulate. During V ent mode when there is no heating or cooling demand, the damper or airﬂ ow will maintain at least the Vent Min amount of airﬂ ow into the zone for ventilation.

Description Minimum Default Maximum

Maximum 0% or 0 CFM 100% or

1000 CFM

Vent Min 0% or 0 CFM 25% or

250 CFM

100% or

30000 CFM

100% or

30000 CFM

Setpoint Screen #7 - Damper Airﬂ ow Cool/ Heat Minimum

XX Box Spts IDXXXX Damper/Airflow Spt

Cool Min.: XXX %

Heat Min.: XXX %

Setpoint Screen #5 - Damper Airﬂ ow Integral

XX Box Spts IDXXXX Damper/Airflow Spt

Integral [Ki]..: XXX

The VAV/Zone Controller normally opens its damper based on a Proportional Error from Setpoint. That means if the zone temperature is 4°F from setpoint, the damper would be 100% open, or it would be modulating to provide the Maximum CFM on Pressure Independent boxes. If the error is less than 4°F, the damper may stagnate at that position and never satisfy the zone. If you add Integral into the damper calculation process, this will cause the damper or airﬂ ow calculations to continue to increase as long as the zone temperature is still above the setpoint. That means it can provide 100% or Maximum CFM before the 4°F error is achieved, bringing the zone under control faster than it normally would. Start with a small (5 or 10) value, if you use this, and monitor the effect it has. If you enter too large a value, you can create “hunting” situations that can cause the damper actuator to prematurely wear out.

During Supply Air Cooling Mode, if the space being served by this damper is satisﬁ ed and has no cooling demand, the damper will close to this Cool Min setting. This provides a minimum amount of airﬂ ow into the space for ventilation, even if the space does not require additional cooling. During Supply Air Heating Mode, if the space being served by this damper is satisﬁ ed and has no heating demand, the damper will close to this Heat Min setting. This provides a minimum amount of airﬂ ow into the space for ventilation, even if the space does not require additional heating.

Description Minimum Default Maximum

Cool Min 0% or

0 CFM

Heat Min 0% or

0 CFM

10% or

1000 CFM

10% or

100 CFM

100% or

30000 CFM

100% or

30000 CFM

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Setpoint Screens

Setpoint Screen #8 - Damper Airﬂ ow Night Min and Fan On Min

XX Box Spts IDXXXX

Damper/Airflow Spt Night Min.: XXX % Fan On Min.: XXX %

The Night Min is the position the damper will move to when the system is in Override Mode and this particular damper is not part of the override group. This Night Min position only affects non-fan powered boxes. The Fan On Min is the minimum damper or airﬂ ow setting used to activate the parallel fan if installed. Pressure Independent = CFM. Pressure Dependent = %.

Description Minimum Default Maximum

Night Min 0% or

0 CFM

Fan On Min 0% or

0 CFM

0% or

0 CFM

25% or

250 CFM

100% or

9999 CFM

100% or

9999 CFM

Setpoint Screen #9 - Damper Airﬂ ow Reheat Min

XX Box Spts IDXXXX

Damper/Airflow Spt Reheat Min.: XXX %

Setpoint Screen #11 - SAT HV AC Mode Deadband

XX Box Spts IDXXXX

SAT HVAC Mode

Deadband.: XXºF

If the supply air temperature is above the space temperature by this amount, the VA V/Zone Controller enters the Supply Air Heating Mode. It will remain in the Supply Air Heating Mode until the supply air drops to 2ºF above the space temperature. At that point the unit enters the Supply Air Vent Mode and remains there until the supply air drops this deadband below the space temperature. At that point the VAV/Zone Controller enters the Supply Air Cooling Mode and will remain there until the supply air temperature rises to 2ºF below the space temperature.

Description Minimum Default Maximum

SAT HVAC Mode

Deadband

0ºF 10ºF 20ºF

Setpoint Screen #12 - Zone Alarm Offsets

XX Box Spts IDXXXX Zone Alarm Offsets

Hi Zone......: XXºF

Lo Zone......: XXºF

The Reheat Min is the damper or airﬂ ow setting used during the Space Reheat Mode of operation.

Description Minimum Default Maximum

Reheat Min 0% or

0 CFM

0% or

0 CFM

100% or

30000 CFM

Setpoint Screen #10 - Damper Airﬂ ow Fixed Position

XX Box Spts IDXXXX

Damper/Airflow Spt Fixed Pos: XXX %

Many times while troubleshooting a system, it is useful to have the zone damper set to a speciﬁ c damper position or airﬂ ow setting. This setpoint can be used to determine where the damper/airﬂ ow will remain when the VA V/Zone Controller receives a For ce to Fixed Position command.

Description Minimum Default Maximum

Fixed Pos 0% or

0 CFM

0% or

0 CFM

100% or

9999 CFM

The VA V/Zone Controller can be setup to generate an alarm anytime the box goes into the Occupied Mode and the Zone Temperature exceeds the user-deﬁ ned alarm limits for a user-deﬁ ned period of time. A High Temperature Alarm Setpoint is created by adding the Hi Zone Alarm offset to the current Cooling Setpoint. The Low Temperature Alarm Setpoint is created by adding the Lo Zone Alarm offset to the current Heating Setpoint. If the zone temperature exceeds either of these limits for a period deﬁ ned by the Alarm Delay setpoint, the controller can gen- erate an alarm callout if all the optional hardware components required for this to occur are installed.

Description Minimum Default Maximum

Hi Zone Alarm +1ºF +30ºF +50ºF

Lo Zone Alarm -1ºF -30ºF -50ºF

VCM-X / RNE Operator Interface SD

Zone

VAV/ZONE CONTROLLER PROGRAMMING

VAV/Zone Setpoint Screens

Zone

Setpoint Screen #13 - Zone Alarm Delay

XX Box Spts IDXXXX

Zone Alarm Delay

Must Be Out Of

Limits For.: XXX Min

As mentioned above, if you conﬁ gure the controller to generate zone temperature alarms, this is the amount of time after the box goes into the Occupied Mode that the temperature must be outside the alarm limits before an alarm is generated.

Description Minimum Default Maximum

Out of Limits 1 Min 30 Min 300 Min

Setpoint Screen #14 - Day/Night Schedule

XX Box Spts IDXXXX

Day/Night Schedule

Control #: X

0=AHU 1-5=Scheduler

This screen allows you to set the VAV/Zone Controller to operate on a remote schedule instead of the schedule that is contained in the VCM-X or RNE Controller. Enter <0> to operate on the AHU schedule. Enter <1-

5> to use an external schedule. A GPC Plus is required for schedules 1-5.

Description Minimum Default Maximum

Schedule Control Number 0 0 1 to 5

Setpoint Screen #16 - Push-Button Override Duration

XX Box Spts IDXXXX Push-Button Override Duration : X.X Hr

If the Flush Mount Wall Sensor has the optional Push-Button Override, this is the amount of the VAV/Zone Controller will resume using its Occupied Setpoints during unoccupied mode. This will generate a call for the Air Handler to start its fan and provide heating or cooling, depending on how you conﬁ gure the Air Handler.

Description Minimum Default Maximum

Duration 0.0 Hr 0.0 Hr 8.0 Hr

Setpoint Screen #17 - Maximum EMS Offset

XX Box Spts IDXXXX

Maximum EMS Setpoint

Offset...: XXºF

If the Energy Management System (EMS) is activated, the heat and cool setpoints can be spread apart by this amount.

Description Minimum Default Maximum

Maximum EMS Setpoint

Offset

0ºF 0ºF 30ºF

Setpoint Screen #15 - Maximum Slide Offset

XX Box Spts IDXXXX

Maximum Slide Offset

Effect on Spt.: XºF

If the Flush Mount Wall Sensor has the optional Setpoint Slide Adjust, this is the maximum amount you can adjust the heating and cooling setpoints up or down as the slide is moved from the center position to its full up or down position.

Description Minimum Default Maximum

Effect on SP 0ºF 0ºF 6ºF

Setpoint Screen #18 - Sensor Calibration for Space Temp and Supply Air Temp

Sensor Calibration

SPC: XXX.Xº XXX.Xº SAT: XXX.Xº XXX.Xº

[SAT Only if Sensor]

The Thermistor Type III sensor readings can be calibrated. Enter a Positive value to increase a reading and a Negative value to decrease a reading.

NOTE: The Supply Air T emperature calibration offset only oper-

ates on the reading when the VAV/Zone Controller has its own Supply Air Temperature sensor installed on the AUX2 input. If the supply temperature is received from a global broadcast, you will need to go to the air handler to calibrate the temperature reading.

Description Minimum Default Maximum

SPC (Space Temp) -100ºF 0ºF +100ºF

SAT (Supply Air) -100ºF 0ºF +100ºF

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER STATUS

VAV/Zone Status Screens

VAV/Zone Status

Status Screen #1 - Mode of Operation

XX Box v4.01 IDXXXX

Occupied Mode

Vent Mode

Belongs to Group # 1

Line 2 Unoccupied Mode Occupied Mode Override Mode Override Pending* Damper Calibration Group Override

Line 3 OFF Mode Vent Mode Cooling Mode Heating Mode Sensor Fail Mode**

Status Screen #3 - Slide Offset & H/C Demand

XX Box v4.01 IDXXXX

Slide Offset: XXºF H/C Demand.: XX.XºF

Line 2 If the optional Setpoint Slide Adjust is installed on the Flush Mount Wall Sensor, this line will display the current amount the Slide Offset is affecting the Heating and Cooling Setpoints.

Line 3 Current Heating or Cooling Demand in the Zone based on the current Heating and Cooling Setpoints when compared to the current Zone Temperature.

Line 4 Blank

Status Screen #4 - Supply Air Temperature & Box Air Temperature

XX Box v4.01 IDXXXX

Supply Air: XX.XºF Box Air..: XX.XºF

Line 4 Belongs to Group # xx No Group Afﬁ liation

* Not displayed when using a Digital Room Sensor. ** Displays for either a temperature sensor failure or an airﬂ ow

sensor failure.

Status Screen #2 - Zone Temperature and Cooling/ Heating Setpoints

XX Box v4.01 IDXXXX

Zone Temp..: XX.XºF Cooling Spt: XX.XºF Heating Spt: XX.XºF

Line 2 Current Zone Temperature Line 3 Currently active Cooling Setpoint based on the current

Occupied / Unoccupied mode of operation. Line 4 Currently active Heating Setpoint based on the current

Occupied / Unoccupied mode of operation.

Line 2 Current Supply Air T emperatur e received via broadcast from the DX Air Handler or from the Box Controller’ s own installed Box Air T emperature Sensor connected to the AUX input of the VAV/Zone Controller board.

Line 3 Current Box Air Temperature If you have conﬁ gured the VCM-X or RNE Controller to broadcast the Supply Air Temperature to the VAV/ Zone Controller and don’t have a Box Air T emperature Sensor attached to the AUX input on the VAV/Zone Controller board, this line will display the Supply Air Temperature the same as line 2.

If you have a Box Air Temperature Sensor attached to the AUX input on the VA V/Zone Controller board, this line will display the Box Air Temperature at the location where the Box Air Temperature Sensor is installed.

Line 4 Blank

VCM-X / RNE Operator Interface SD

VAV/ZONE CONTROLLER STATUS

VAV/Zone Status Screens

Zone

Status Screen #5 - Zone Damper Position, Airﬂ ow, and Desired CFM

XX Box v4.01 IDXXXX

Damper FRC: XXX %

Airflow : XXXX CFM Desired : XXXX CFM

Line 2 Current Zone Damper Position If you entered a FORCE command, the letters FRC will appear. If this is normal damper operation, the FRC will not be displayed.

Line 3 If this is a Pressure Independent box, the current Airﬂ ow will be displayed. If not, this line will display the desired damper position.

Line 4 If this is a Pressure Independent box, this line will display the Desired CFM the box would like to provide to the zone. If not, this line will display [Controls to +/- 3%] to indicate how accurately the damper will maintain the desired position.

Status Screen #6 - Fan Status & Reheat Stages

Examples: “1 Reheat Stages On” or “2 Reheat Stages On” or “3 Reheat Stages On” If proportional heating is used (you have no relays

conﬁ gured for heat), this line will display “Heating Signal: xxx %”.

Line 4 If your VAV/Zone Controller has been conﬁ gured to control reheat stages, this line reﬂ ects the On/Off Status of the second stage of Reheat. If you have 3 stages of reheat as explained on line 2, this line will be blank.

Status Screen #7 - Alarm Status

XX Box v1.04 IDXXXX

NO ALARMS!

XX Box v.104 IDXXXX

XX Box v1.04 IDXXXX Fan Status : OFF Heating Relay#1 : OFF Heating Relay#2 : OFF

Line 2 If this is a Fan Powered box, this line will display the Fan On/Off Status. On non-fan powered boxes, this line will display [Exp Relay 1 Not Used].

Line 3 If your VAV/Zone Controller has been conﬁ gured to control reheat stages, this line reﬂ ects the On/Off Status of the ﬁ rst stage of Reheat. If you have 3 stages of reheat, this line will display the total number of active heating stages.

ALARMS PRESENT

SCROLL DOWN TO VIEW

Line 2 Blank Line 3 NO ALARMS! OR ALARMS PRESENT

If there are one or more alarms active, the possible messages are shown below:

SPACE SENSOR FAILURE CFM SENSOR FAILURE DAMPER OPENING ALARM DAMPER CLOSING ALARM HI SPACE TEMP ALARM LO SPACE TEMP ALARM DPR FEEDBACK FAILURE

Press <> to scroll through all active alarms.

For Alarm Deﬁ nitions, see the VCM-X Controller

Technical Guide, the VCM-X Modular E-BUS Controller Technical Guide, or the RNE Controller Technical Guide.

VCM-X / RNE Operator Interface SD

VAV/ZONE DAMPER FORCE

VAV/Zone Damper Force Modes

Damper Force Modes

Damper Force Modes are available for testing or balancing the system. These Force Modes can be accessed and programmed from either the System Manager or Modular Service Tool.

Modular Service Tool Instructions

When using the Modular Service T ool, simply press the <BALANCE -

TEST>

key. You will then see the Unit Selection Screen. Enter the unit ID of the controller you wish to access and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established,

the *00* at the bottom will disappear. Then

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

The following screen will be displayed:

Damper Force Para Blocks Load / Save / Copy

With the cursor on Damper Force, press <ENTER> to access the Damper Force Mode Screen.

press <>.

1 = Open This setting will force the dampers to their fully- open position.

2 = Clsd This setting will force the damper to its fully- closed position.

3 = Max This setting will force the damper to its Maximum Position Setpoint. See VAV/Zone Controller Setpoint Screen #5 on page 69 for complete setpoint information.

4 = Min This setting will force the damper to its Minimum Position Setpoint. See VAV/Zone Controller Setpoint Screen #5 on page 69 for complete setpoint information.

5 = Fixed This setting will force the damper to a ﬁ xed position based on the Fixed Position Setpoint. See VAV/Zone Controller Setpoint Screen #8 on page 70 for complete setpoint information.

CAUTION: The Damper Force Modes should only be used

by qualiﬁ ed service personnel. Serious damage to the ductwork could result if the dampers are all forced closed and the HVAC unit fan is operating.

Dampers Force Mode Screen

If the unit ID you entered is for a VCM-X or RNE Controller that has V AV/Zone Controllers connected to its communication loop, the Damper Force Mode will act as a “Global” Damper Force Mode. That is, all VA V/ Zone Controllers on that VCM-X or RNE Controller’s communication loop will be forced to the same Damper Force Mode setting. If the unit ID you entered is for a VAV/Zone Controller, the Damper Force Mode setting will only apply to that VAV/Zone Controller.

Damper Force Enter Force Mode: 0 0=Auto 1=Open 2=Clsd 3=Max 4=Min 5=Fixed

Set the appropriate Damper Force Mode by entering numbers 0 through

5. Following is a list of the force modes and their meaning:

0 = Auto This is the default setpoint. With this setting, the damper will operate normally and modulate according to the controller setpoints.

VCM-X / RNE Operator Interface SD

MINILINK PD STATUS

MiniLink PD Conﬁ guration Screens

MiniLink PD Conﬁ guration

In order to correctly setup the MiniLink PD, you must ﬁ rst conﬁ gure sev- eral parameters in regard to the type of system and operating parameters for the system it is installed on. Most of these values and operating parameters are only set once at the initial system setup and are never changed.

Modular Service Tool Instructions

From any menu screen, press <SETPOINTS>. The Unit Selection Screen, shown below, will appear requesting that you enter the unit ID number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

All MiniLink PDs are set at address 60. Enter the correct unit loop number for the loop the MiniLink Polling Device is connected to (for Loop 1 you would enter <160>) and press <ENTER>. You must type in the number, even if it is “1”. Once communication is established, the *00*

at the bottom will disappear. Then

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

You will then see Setpoint Screen #1. Press data and

press <> to scroll through the screens.

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

press <>.

<ENTER> to save entered

The following screen will be displayed:

Change Setpoints

Configure Unit

Save/Copy/Restore

Scroll to the ‘Change Setpoints’ option and press <ENTER>. This will take you to the ﬁ rst Setpoints Screen shown below.

Conﬁ guration Screen #1 - System Type

Polling Unit Config

System Type

Selection: ZONING

Use < Or > To Change

Select VAV or ZONING. This screen allows you to select whether you want the system to behave as a VAV system or a Zoning System. If you select VAV, this will allow tenant logging for your VAV system.

Conﬁ guration Screen #2 - Last Polled Zone

Polling Unit Config

Last Polled Zone

Address: XX

[Enter Last Zone]

This zone is the last zone on the local loop of your zoning system that is to be included in zone voting. Valid entry is 1 to 25.

Conﬁ guration Screen #3 - Mode Changeover Time

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection*00*

Enter Unit ID#

Selected ID#: XXXX

press <>.

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

Polling Unit Config

Mode Changeover Time

Minutes: XX

[Enter Period Time]

This is the amount of time that you want to allow between changeover from heating to cooling modes. Valid entry is 5 to 60 minutes.

VCM-X / RNE Operator Interface SD

MINILINK PD PROGRAMMING

MiniLink PD Conﬁ guration and Status Screens

Conﬁ guration Screen #4 - Optimal Start Target Zone

Polling Unit Config

Optimal Start

Target Zone..: XX

[Enter Target Zone]

This is the unit ID of the Zone that you want to be satisﬁ ed by the normally scheduled start time. If you enter “-1” into this box, it will average all zones instead of picking a speciﬁ c zone. If you do not require Optimal Start, enter “0”. Valid entry is -1 to 58.

Conﬁ guration Screen #5 - Maverick Testing

Polling Unit Config

Maverick Testing

Disabled: YES

Use < Or > To Change

Select YES or NO. Disabling the Maverick T esting allows known troubled zone(s) to continue voting without causing a Maverick alarm. In other words, all zones are included in the voting regardless of whether they are more than four degrees from setpoint.

Conﬁ guration Screens #6-65 - Alarm Polling

MiniLink PD Status

Status Screen #1 - Schedule Mode, System Status, and Minutes Left

Polling Device

System Occupied

Venting Mode

XXX Min Left in Mode

Line 2 Current Schedule Mode Can be System Occupied or System Unoccupied.

Line 3 Currently System Status Can be Vent Mode, Cooling Mode, or Heat Mode.

Line 4 Minutes Left In Mode The number of minutes left in the current mode of operation before it can switch modes. This value is user-adjustable. See Conﬁ guration Screen #3.

Status Screen #2 - Mode Priority, Cool Total, and Heat Total

Polling Device

No Mode Priority

Cool Total.: XX.XºF Heat Total.: XX.XºF

Polling Unit Config

Enable Alarm Polling

Unit XX: YES

Use < Or > To Change

Select YES or NO. Enabling Alarm Polling allows any alarm from the loop to be polled. You must set this for each controller on the loop.

Line 2 Mode Priority

Can be Heat Priority or Cool Priority. This is based on the voting zones and their demand.

Line 3 Cool Total

Total cooling temperature demand from all zones.

Line 4 Heat Total

Total heating temperature demand from all zones.

VCM-X / RNE Operator Interface SD

TROUBLESHOOTING

VCM-X / RNE Outputs Force

Outputs Force

Outputs Force settings are available for testing or troubleshooting the system. These Force settings can only be accessed and programmed from the Modular Service Tool. The System Manager does not allow for programming of this function.

Zone

Supply Fan Override Auto

Use < Or > To Change

CAUTION: The Outputs Force settings should only be applied

by qualiﬁ ed service personnel. Serious damage to the HVAC unit could result from improper use of these Outputs Force settings.

To access the Outputs Force settings, simply press the

- TEST> button on the Modular Service Tool. You will then see the

Unit Selection Screen.

Unit Selection*00*

Enter Unit ID#

Selected ID#: XXXX

Enter the unit ID of the VCM-X or RNE Controller you wish to access and press <ENTER>. Once communication is established, the *00*

message will go away. Then shown below. Press

scroll through the screens.

NOTE: If the *00* remains, it indicates a communication failure

to the controller.

NOTE: The Outputs Force settings are only available for the

VCM-X or RNE Controller. They are not supported for the VAV/Zone Controllers or other Add-on controllers.

Para Blocks Save / Load / Copy

press <>. You will then see the screen

<ENTER> to save entered data and press <> to

Outputs Force

<BALANCE

The ﬁ rst Outputs Force Screen allows the AHU fan relay to be set for Auto, Force On, or Force Off. The default setting is Auto. After you complete all troubleshooting or testing procedures, all relays should be changed back to this setting. The Force On setting will force the relay to the ON (energized) position. The Force Off selection will force the relay to the OFF (de-energized) position.

The next screen displays the Relay Overrides for Relay 2. After press- ing

<ENTER> to save any changes, press <> to have the next relay

displayed. All 20 Relay Override Scr eens (including the AHU fan relay) are available by pressing

<ENTER>.

After the screen for relay 21 is displayed, the ﬁ rst Analog Output Over- ride Screen will be displayed.

The default setting for normal operation is -1.0 volts. Voltages between 0 to 10.0 can be set for any of the Analog Output Overrides. Press

<ENTER> after making a setting change and then press <> and the

next Analog Output Override Screen will be displayed.

<> after each setting is saved by pressing

Relay Overrides Relay 2 Override Auto

Use < Or > To Change

Analog Output 1 Screen

Economizer Overrides

Analog Output #1

Override Volts: -1.0

[-1.0=Auto]

Place the cursor on Outputs Force and press <ENTER> to access the Outputs Force Screen.

Analog Output 2 Screen

Supply VFD Override

Analog Output #2

Override Volts: -1.0

[-1.0=Auto]

VCM-X / RNE Operator Interface SD

TROUBLESHOOTING

VCM-X / RNE Outputs Force

Analog Output 3 Screen

Exhaust VFD Override

Analog Output #3

Override Volts: -1.0

[-1.0=Auto]

Analog Output 4 Screen

Mod Heating Override

Analog Output #4

Override Volts: -1.0

[-1.0=Auto]

Analog Output 5 Screen

Mod Cooling Override

Analog Output #5

Override Volts: -1.0

[-1.0=Auto]

Analog Output 6 Screen

RA Damper Override

Analog Output #6

Override Volts: -1.0

[-1.0=Auto]

Analog Output 7 Screen

RA Bypass Override

Analog Output #7

Override Volts: -1.0

[-1.0=Auto]

VCM-X / RNE Operator Interface SD

APPENDIX A - SAVE, LOAD, COPY SETPOINTS

Saving Setpoints

Modular Service Tool Instructions

From any menu screen, press <BALANCE-TEST>. The Unit Selection Screen will appear requesting that you enter the unit ID number.

Unit Selection Enter Unit ID#

Selected ID#: XXXX

*00*

Enter the network unit ID for the controller you want to save the setpoints from. Example, ‘102’ for Loop 1 / Unit 2. Then press <ENTER>. Y ou must type in the number, even if it is “1”. Once communication is established, the *00* at the bottom will disappear. After a brief pause,

press

<> to get to the Balance - Test Screen shown below.

Outputs Force

Para Blocks

Save/Copy/Restore

Scroll down to the ‘Save/Copy/Restore’ option and press <ENTER>. This will take you to the Save Setpoints screen.

System Manager SD Instructions

From any Main screen, press <SETPOINTS>. The screen below will appear because this option requires passcode clearance. Only a Level 2 passcode can change setpoints.

The following screen will be displayed:

Change Setpoints Configure Unit Save/Copy/Restore

Scroll down to the ‘Save/Copy/Restore’ option and press <ENTER>. This will take you to the Save Setpoints screen.

Save Setpoints - Network Mode

From the Save Setpoints Screen shown below:

Save Setpoints Press Enter To Save

Press <ENTER> and a setpoint ﬁ le will be saved to the SD card. You will receive a message that the save was successful. This ﬁ le is speciﬁ c to this controller on this loop.

THIS ACTION REQUIRES

PASSCODE CLEARANCE

Enter Passcode: XXXX

If the correct passcode was entered, the Unit Selection Screen will be displayed.

Unit Selection*00*

Enter Unit ID#

Selected ID#: XXXX

Then

press <>.

NOTE: If the *00* remains, it indicates a communication

failure to the controller.

VCM-X / RNE Operator Interface SD

APPENDIX A - SAVE, LOAD, COPY SETPOINTS

Copying & Restoring Previously Saved Setpoints

Copy Setpoints - Network Mode

To copy a saved setpoints ﬁ le to other controllers on the network do the following:

From the Save Setpoints Screen shown below:

Save Setpoints

Press Enter To Save

Press <> once to access the Copy Setpoints Screen shown below.

Copy Setpoints From Loop 1 From Unit 2 Press Enter to Copy

In the ‘From Loop’ ﬁ eld, enter the Loop of the controller you want to copy the setpoints from. In this example it is ‘1’. Then press <ENTER>.

In the ‘From Unit’ ﬁ eld, enter the Unit ID of the controller you want to copy the setpoints from. In this example it is ‘2’. Then press

<ENTER>.

Restore Setpoints - Network or Stand-Alone Mode

The Restore Setpoints feature is used to reload a saved setpoints ﬁ le from one controller back to itself. This could be useful if setpoints or conﬁ gurations were changed and need to be reset.

You can perform this function on a networked system; however, the Modular Service Tool needs to be directly connected to the controller you wish to restore previously saved setpoints to.

From the Save Setpoints Screen shown below:

Save Setpoints

Press Enter To Save

Press <> four times to access the Restore Setpoints Screen shown below.

Restore Setpoints

Press Enter to Load

Now your cursor will be on the last line, and you can press <ENTER> once more to copy the setpoint ﬁ le from unit 102 to unit 103.

You will receive a conﬁ rmation that the copy was successful.

Save & Copy Setpoints - Stand-Alone Mode

The instructions for Stand-Alone Mode are exactly the same as Network Mode, except that there is no need to enter a Loop number in the Unit ID number ﬁ eld and in the Copy Setpoints Screen, enter a zero in the ‘From Loop’ ﬁ eld.

Press <ENTER>. This will reload the setpoints from the saved ﬁ le. You will receive conﬁ rmation that the setpoints were loaded successfully.

VCM-X / RNE Operator Interface SD

APPENDIX B - UPDATING THE SD CARD

SD Memory Card Update

Updating The SD Memory Card

You may need to update the SD memory card from time to time, either for a new release or to add data for another Controller.

Follow the instructions below to download the update ﬁ le from our tech support webpage:

1. Insert the SD memory card in your computer’s SD drive and open the drive’s window.

2. Open your browser and type in the address: http://wattmaster.com/techsupport.

3. On the Tech Support webpage, locate the ﬁ le Modular_HH_Screens.zip and double-click on it.

4. Click and then click <OK>. This option will save the ﬁ le to the “Downloads” folder on your PC.

<Save File> when asked to save or open the ﬁ le

6. Once you unzip the ﬁ le, you will see a window similar to the one below.

7. Press window—App, Manuals & Scr. Press <CTRL> <C> to copy the folders.

<CTRL> <A> to highlight the folders in the

5. Open the “Downloads” folder in Windows Explorer. You will ﬁ nd a folder labeled, “Modular_HH_Screens. zip” Right-click on the folder and choose “Extract All” from the options list. NOTE: Any compression software can be used to extract the zip folder’s contents, for example, Winzip.

8. Paste the folders into the SD memory card drive’s window by pressing

9. Remove the SD Memory Card from your computer and reinsert it in the Modular Hand Held Service Tool or Modular System Manager.

<CTRL> <V>.

VCM-X / RNE Operator Interface SD

APPENDIX C - UPDATING CONTROLLERS & MODULES

Updating Controller & E-BUS Module Software

Updating Controller & E-BUS Module Software Using the Modular Service Tool SD

To update the software for various WattMaster controllers and E-BUS modules, follow these simple steps.

1. Update your SD memory card with the new software ﬁ le for the controller or module you need to update. Follow the steps on page 81 for Updating the SD memory card.

2. Connect the Modular Service Tool to the device you wish to update using the mini DIN communication cable or EBC E-BUS cable provided.

3. Power up the controller or E-BUS module you wish to update.

4. Apply power to the Modular Service Tool SD and press the

5. After initialization of the Modular Service Tool SD,

press <NEXT> at the ﬁ rst Setup Screen and <4> at the

second Setup Screen shown below.

<ON> button.

WattMaster Controllers

1. Press <1> to update a WattMaster Controller. The following screen will appear:

Enter Board Address

Esc) Exit Menu

2. Enter the address of the controller you are updating and then press <ENTER>.

3. The Software Version Screen will appear as shown below. Enter the number of an older version given to you by Technical Support. Then press

<0> for the latest software version or enter

<ENTER>.

Software Version Enter 0 for Latest

Esc) Exit Menu

1) Set Time & Date

2) Communications

NEXT) More Options

ESC) Exit Menu

3) Energy Saving

4) Update Software

NEXT) More Options

ESC) Exit Menu

6. The Update Software Screen will appear as shown below:

Select Communication

1) WattMaster Comm

2) E-BUS Module ESC) Exit Menu

7. Follow the instructions for WattMaster Controllers or E-BUS Modules.

4. The screen will display the following messages: “Resetting Unit” “Load Sys Info”

5. If communications are successful, the screen will display, the name of the HEX ﬁ le on the top line, “Flash Memory Erased” on the second line, and the progress percentage on the third line.

NOTE: If communications are not successful, the screen

will display, “Press Any Key to Continue. Cannot Load Sys Info.” Make sure you have the right address and the right software version on your SD card. If these two items are correct and you still experience a problem, contact Technical Support.

6. When updating is complete, the screen will display, “Finish Download.”

VCM-X / RNE Operator Interface SD

APPENDIX C - UPDATING CONTROLLERS & MODULES

Updating Controller & E-BUS Module Software

E-BUS Modules

1. Press <2> to update an E-BUS Module. The following screen will appear:

Enter Board Address

Esc) Exit Menu

2. Enter the address of the E-BUS module you are updating and then press <ENTER>. The following is the list of Module addresses:

WSHP-X - address 17 MHGRV-X - address 132 MODGAS-X - address 138

3 . The Software Version Screen will appear as shown

below. Enter the number of an older version if given to you by Technical Support. Then press <ENTER>.

<0> for the latest software version or enter

5. If communications are successful, the screen will display, the name of the HEX ﬁ le on the top line, “Flash Memory Erased” on the second line, and the progress percentage on the third line.

NOTE: If communications are not successful, the screen

6. When updating is complete, the screen will display, “Finish Download.”

Software Version Enter 0 for Latest

Esc) Exit Menu

4. The screen will display the following messages: “Resetting Unit” “Load Sys Info”

VCM-X / RNE Operator Interface SD

INDEX

A-D

0-10 VDC CW.........38

2-10 VDC CW.........38

24-Hour Military Format.........14,22

55 - 75 Tons.........38

95 - 105 Tons.........38

120 - 140 Tons.........38

1111.........19

2222.........19

2359.........14

,22

Adaptive Defrost Timer

Adjustment.........53

AHU Heat Call Space Temperature

VAV/Zone.........69

Airﬂ ow

, VAV/Zone Status.........73

Alarm Relay Conﬁ guration.........33,43

Alarms

Button.........10,16

Clearing.........13,21

MiniLink Polling.........20,76

Modular Service Tool.........13

VAV/Zone Status.........73

Alarms for VCM-X.........64

Analog Output Override Screen.........77

Arrow Keys

Deﬁ ned.........10

Auto Damper Force Mode.........74

Automatic Power Down.........12

,12,16,18

Balance-Test Button, Deﬁ ned.........10

Box Air Temperature

VAV/Zone Status.........72

Box Conﬁ guration, VAV/Zone.........65

Box Heat Allow Broadcast

Internal Schedule Screen.........32

Internal Time Clock Screen.........32,41

Outdoor Air Humidity Screen.......31,41

Outdoor Air Temperature Screen..31,41

Status Fan & Heat Screen.........31,41

Supply Temperature Screen.........31,41

VAV Boxes Force to Fix Screen...32

VAV Boxes Force to Max

Broadcast to Multiple Loops.........32,42

Building Pressure

Deadband Setpoint.........51

Modulating Control Screen.........30,40

Output %.........60

Output Signal Screen.........30

Reverse Acting Control Screen....30,40

Setpoint.........51

VCM-X Status.........60

Bypass Damper.........25,35

Bypass Damper Signal.........64

, VAV/Zone.........66

Screen....32,42

,40

,42

CFM, Outdoor Air.........29,39

CFM, Return Air.........29

CFM, Supply Air.........29

Change Passcodes.........19

Circuit A.........62

Circuit A T emperature.........61

Circuit B.........62

Circuit B Temperature.........61

Clear Alarms.........13

Clear Key, Deﬁ ned.........10,16

Closed, Damper Force Mode.........74

Level.........59

Protection Limit Max Level.........50

Protection Limit Reset Range.........50

Protection Limit Setpoint.........50

Sensor Maximum Scale Screen....30,40

Sensor Output Signal Screen........30,40

Coil 1 Temperature.........62

Coil 2 Temperature.........62

Coil A1 Temperature.........61

Coil A2 Temperature.........61

Coil B1 Temperature.........62

Coil B2 Temperature.........62

Coil Suction Temperature.........61

Coil Temperature.........58

Coil Temperature Setpoint.........58

Coil Temperature Status.........61

Communications Screen.........12,18

Compressor A1.........61

Compressor A2.........61

Compressor A Signal.........62

Compressor B1.........62

Compressor B2.........62

Compressor B Signal.........62

Condenser Fan Speed.........63

Conﬁ guration.........65

Button.........10

Reset Interval Rate.........26

Screen Index.........24

Conﬁ guring

Main Fan Maximum Voltage........32,42

Connection Diagram

Modular Service Tool.........5

Continuous OFF Mode.........14

,42

Continuous ON Mode.........14,22

Controlling Outdoor Air CFM.........50

Control Outdoor Air CFM.........29,39

Controllers, Updating...........82

Cooling Head Pressure Setpoint.........49

Cooling & Heating Stage Delays

Screens.........33

Cooling Min Off Time.........33,43

Cooling Min Run Time.........33

COOLING ONLY BOX

VAV/Zone.........65

Cooling Setpoints

VAV/Zone Status.........72

Cooling Stage Relay.........64

,21

,43

,39

,62

,22

,43

,36

Cooling Stage Relay Conﬁ guration.......33

Cooling Status, VCM-X Controller.........56

Cool Total

MiniLink PD Status.........76

Copy Setpoints.........80

Current Active Supply Air Setpoint.........57

Current CO

Current Economizer Open Percentage........59

Current Supply Air Temperature.........57

Current W etbulb Temperature.........59

Cutoff T emperature Setpoints.........48

Level.........59

,43

Damper Airﬂ ow

Cool/Heat Minimum.........69

Fan On Min.........70

Fixed Position.........70

Integral.........69

Maximum.........69

Night Minimum.........70

Reheat Minimum.........70

Vent Minimum.........69

Damper Force

Modes.........74

Damper Operation

VAV/Zone.........65

Dampers Forced Closed.........74

Data Entry Keys

Described.........10

Date, Programming.........11,17

Day/Night Schedule

VAV/Zone.........71

Deadband

Outdoor Air CFM.........50

DEC Key

Defrost Adaptive Timer.........53

Defrost Heat Wheel Setpoint.........53

Dehumidiﬁ cation

Desired CFM

Dewpoint Temp

Digital Compressor Signal Screen.........28

Digital Scroll Compressor.........29

Dimensions

Direct Acting Control.........51

Display Screen

Dual Digital Module.........55,61,62

, Deﬁ ned.........10,16

Coil Temperature Setpoint.........49

Control Screen.........26

Indoor RH & OA Dewpoint

Setpoints.........48

Priority Screen.........26,36

Unoccupied Screen.........26,36

VAV/Zone Status.........73

VCM-X Status.........58

Modular Service Tool.........4

System Manager.........6

Described.........10

Status Screen.........55,61

,16

,36

,62

,16

VCM-X / RNE Operator Interface SD

INDEX

D-M

Dual Digital Module Screen.........29

Dual Digital Signal.........62

Dual Digital Temperature.........61

Duct/Damper Size

Outdoor.........39

Return.........39

Supply Air.........39

Duct/Damper Size, Outdoor.........29

Duct/Damper Size, Return.........29

Duct/Damper Size, Supply Air.........30

Duct Static Pressure Screen.........25

Dump Zone, VAV/Zone.........67

,35

Economizer

Control Screen.........27

Maximum Position if High CO

Setpoint.........50

OAT/WB Enable Setpoint.........49

Overrides.........77

Relay Conﬁ guration.........33,43

Status.........56

Economizer %.........59

Economizer Open Percentage.........59

Economizer Relay.........64

Emergency Heat Conﬁ guration.........33

Emergency Shutdown Input.........31

Energy Saving Timer.........12

Enter, Key.........10,16

ESC Key, Deﬁ ned.........10,16

Exhaust

VFD Override.........78

Exhaust Fan Relay.........64

Exhaust Fan Relay Conﬁ guration.........33

Expansion Relays Heating Stages

VAV/Zone.........66

,37

Level

,43

,41

Fan On Min.........70

Fan Status........73

Fan VFD Percentage.........26,36

Firestat Input.........31,41

Fixed Damper Force Mode.........74

Fixed Position

Free Cooling.........49

Full Digital Module.........61,62,63

Coil Temperature Status.........61

Signal Status.........63

Status Screen.........61

Full Digital Module Installed.........39

Full Digital Module Screen.........29

Full Digital Signal.........62

Full Digital Temperature.........61

Damper Airﬂ ow.........70

,63

Gas Reheat Relay.........64

H/C Changeover Box

VAV/Zone........65

Head Pressure Condenser Fan #1

Status.........63

Head Pressure Condenser Fan #2

Status.........63

Head Pressure Cooling Setpoint

Status Screen.........55

Head Pressure Module Screen.........28

Head Pressure Reheat Setpoint

Status Screen.........55,63

Head Pressure Setpoint Cooling.........49

Head Pressure Setpoint Reheat.........49

Heat During Dehumidify Screen.........27

Heating

Min Off Time.........33

Min Run Time.........33

Setpoints.........72

Stage Down.........33,43

Stage Up.........33,43

Status.........56

Heating/Cooling Demand

VAV/Zone Status.........72

Heating Stage Relay.........64

Heating Stage Relay Conﬁ guration........33

Heat Pump

Auxiliary Heating Delay.........52

Control Screen.........30

Heat Pump Defrost Setpoints.........53

Heat Pump Defrost Temperature.........53

Heat Pump Defrost Timer.........53

Heat Reset Source Setpoints.........47

Heat Total

,43

Heat Wheel Defrost Setpoint.........53

Heat Wheel Relay.........64

HGR Relay.........64

Hi SAT Cutoff.........48

Holidays

HVAC Mode

HVAC Mode Enable

HVAC Reset Source.........26,36

, MiniLink PD Status.........76

, Programming.........14

Start/Stop Times.........15

Cooling Setpoints.........45

Heating Setpoints.........45

Reset Source Screen.........26,36

Schedule Setpoint.........52

Select Deadband Setpoint.........45

Sensor Slide Offset Setpoint.........52

Setpoints.........45

Screen.........26

Fan VFD Percentage.........26

No Reset.........26,36

Outdoor Air Temperature

Sensor.........26

Remote Reset Signal.........26,36

Return Air Temperature

Sensor.........26,36

Single Zone VAV.........26,36

Space Temperature Sensor.........26

,36

,63

,36

,43

,40

,23

,36

,38,39

,37

,43

,36

Indoor, Humidity Screen.........27,37

RH Setpoint.........59

Initialization

Screen.........11

Internal Schedule Optimal Start Soak

Multiplier

,17

Setpoint.........53

Keys, Described.........10,16

Last Polled Zone, MiniLink PD.........75

Leaving W ater Temperature.........57

Level 1 User

Level 2 User, Deﬁ ned.........19

Loop Search.........20

Lo SAT Cutoff.........48

Lowest Coil.........58

, Deﬁ ned.........19

Main Fan.........32,42

Main Fan Maximum Voltage.........32,42

Main Fan Status, VAV/Zone.........66

Maverick Testing, MiniLink PD.........76

Maximum

Damper Force Mode.........74

EMS Offset VAV/Zone.........71

Slide Offset VAV/Zone.........71

Maximum Outdoor Air CFM.........50

Maximum Voltage.........32

Maximum Voltage for Main Fan.........32,42

Max OA Damper Tempering Limit.........52

Mechanical Heat/Cool Failure Time

Period Setpoint.........51

MHGRV Output % VCM-X Status.........60

Min

Damper Force Mode.........74

MiniLink PD Conﬁ guration.........75

Alarm Polling.........76

Last Polled Zone.........75

Maverick Testing.........76

Mode Changeover Time.........75

Optimal Start Target Zone.........76

System Type.........75

MiniLink PD Status

Adding Additional.........20

Cool Total.........76

Heat Total.........76

Minutes Left.........76

Mode Priority.........76

Schedule Mode.........76

System Status.........76

Minimum Outdoor Air CFM.........50

Minimum Run Times and Off

Times.........33

,42

,43

VCM-X / RNE Operator Interface SD

INDEX

M-R

Min Supply Fan VFD Speed

for Heating Setpoint.........48

Minus Key, Deﬁ ned.........10,16

Minutes Left Mod

Mode

MODGAS Output % Modular Service Tool

Modular System Manager

Modulating

Modulating Cooling Type

Modulating Cooling Type Screen.........38

Modules, Updating............82

Monitor Supply Air CFM.........29

Month.........11

Morning W arm Up

, MiniLink PD Status.........76

Cooling %.........60,63

Cooling Override.........78

Heating %.........60

Heating Override.........78

Changeover Time.........75

Cooling Setpoint.........56

Enable Temperature.........56

Heating Setpoint.........56

of Operation.........12

Priority.........76

Selection Buttons Deﬁ ned.........10,16

VCM-X Status Screen.........56

Alarms Button.........13

Alarm Search.........13

Connection Diagram.........5

Deﬁ ned.........4

Dimensions.........4

Energy Saving Timer.........12

Initialization Screen.........11

Mode Selection Buttons.........10,16

Override Search.........13

Overrides Tool.........13

VCM-X Setpoints.........45

Connection Diagram.........7

Deﬁ ned.........6

Dimensions.........6

Network Connection.........7

Stand-Alone Connection.........9

Cooling/Heating Screen.........27

Cooling Output Signal Screen.........28

Cooling Proportional Window

Screen.........28,38

Cooling Reverse Acting

Screen.........28

Heating Output Signal Screen.......27,37

Heating Proportional Window

Screen......28,38

Heating Reverse Acting Screen....27

0-10 VDC CW.........38

2-10 VDC CW.........38

VFD Full.........38

VFD Half.........38

,17

Max Length.........48

Tar get Temp.........48

Temp Setpoint.........48

,18,72

, VCM-X Status.........60

,17

,37

,38

,39

Multiple Loops.........32

Multiple MGRS.........18

,42

Network Connection

Modular System Manager.........7

Night Minimum, Damper Airﬂ ow.........70

No Reset.........26

,36

OA Dewpoint, VCM-X Status.........58

Occupied

Mode.........15,23

Setpoints.........68

Occupied Relay.........64

Occupied Relay Conﬁ guration.........33

OE332-23-VCMX-MOD-A.........

OE332-23-VCMX-MOD-C.........

OE370-23-DD.........61,62

OE370-23-FD-A.........61,62,63

OE391-11.........4

OE392-07.........6

OFF Mode

ON Mode, Continuous.........14,22

Open Damper Force Mode.........74

Optimal Start Target Zone

Outdoor

Outdoor Air

Outdoor Air Airﬂ ow

Outdoor Air CFM.........50

Outdoor Air CFM Deadband.........50

Outdoor Air Setpoint.........59

Outdoor Air Temperature Sensor.........26,36

Outdoor Duct/Damper Size.........29,39

Outputs Force.........77

,37

Override Relay.........64

Override Relay Conﬁ guration.........33

Overrides, Button.........10,16

, Continuous.........14,22

MiniLink PD.........76

Humidity Sensor Screen.........27

Temperature.........58

Conﬁ guration.........26,36

Cooling & Heating Lockouts

Setpoints.........48

Relative Humidity.........58

Temperature.........58

VCM-X Output.........59

,59

Screen.........77

Screen.........13

Search.........13

,21 ,21

PARALLEL FAN BOX

VAV/Zone.........65

,43

,37

,43

Passcode

1111.........19

2222.........19

Clearance.........18

Codes.........19

Enter New.........19

System Manager.........19

Power/Comm Board Wiring.........8

Power Down.........12

Preheat Ambient Temperature.........52

Pre-Heater Relay.........64

Pre-Heater Relay Conﬁ guration.........33

Pressure Independent Airﬂ ow Constant

VAV/Zone.........66

Programming

Conﬁ guring RNE.........35

Date.........11

Day of Week.........11,17

Holidays.........14

Holiday Start/Stop Times.........15

Month.........11,17

Time & Date.........11,17

Year.........11,17

Proof of Flow Input Screen.........27

Proportional Heating Signal

VAV/Zone.........66

Push-Button Override

Duration.........71

Duration Setpoint.........52

VAV/Zone.........66

,17

,37

R22 Refrigerant.........49

R410A Refrigerant Screen.........32,42

RA Bypass Override.........78

RA Damper Override.........78

Real Time Clock.........11

Refrigerant.........49

Reheat Stages.........73

Reheat Head Pressure Setpoint.........49

Reheat Minimum

Re-Heat Relay.........64

Reheat Relay Conﬁ guration.........33,43

Relay Conﬁ guration Screens.........33,43

Overrides.........77

Relay Conﬁ guration

Alarm.........33

Cooling Stage.........33,43

Economizer.........33,43

Emergency Heat.........33

Exhaust Fan.........33,43

Occupied.........33,43

Override.........33,43

Pre-Heater.........33,43

Reheat.........33

Reversing Valve.........33,43

Warm-up Mode.........33,43

Relays.........64

,17

Damper Airﬂ ow.........70

,43

,23

VCM-X / RNE Operator Interface SD

INDEX

R-S

Remote

Signal Contact.........14,22

Remote Reset Signal.........26,36

Reset Source.........26

,36

Cooling Setpoint.........46

Reset Interval Rate Screen.........26,36

Restore Setpoints.........80

Return Air

Bypass Control Screen.........31

,41

Bypass Damper Factor Setpoint.........51

Conﬁ guration.........26,36

Return Air CFM Status.........60

Return Air Damper Signal.........64

Return Air Temperature.........57

Return Air Temperature Sensor.........26

Return Duct/Damper Size.........29,39

Reverse Acting Control.........51

Reversing Valve Active During Heat/

Cool.........31

,40

Reversing Valve Relay.........64

Reversing Valve Relay

Conﬁ guration.........33,43

RNE Controller

Conﬁ guration Screens.........35

Leaving W ater Temperature.........57

RNE Tonnage

55 - 75 Tons.........38

95 - 105 Tons.........38

120 - 140 Tons.........38

RNE Tonnage Screen.........38

SAT Heating Setpoints.........47

Saturation Vapor Pressure.........49

Schedule

Button.........10,16

Mode.........76

Override.........14

Time & Date.........11,17

Scheduling

VCM-X Controller.........14

Screens

1 HVAC Unit w/Boxes on Multiple

Loops.........32,42

Adaptive Defrost Adjustment

Setpoint.........53

Analog Output Override Screen.........77

Broadcast Internal Schedule

Screen.........32

Broadcast Internal Time Clock

Screen.........32

Broadcast Outdoor Air Humidity

Screens.........31,41

Broadcast Outdoor Air Temperature

Screen.........31

Broadcast Status Fan & Heat

Screens.........31,41

Broadcast Supply Temperature

Screen.........31,41

,15,22,23

,22

,42

,41

,36

Broadcast VAV Boxes Force to Fixed

Screen.........32

,42

Broadcast VAV Boxes Force to Max

Screen.........32

,42

Building Pressure Deadband Set-

point.........51

Building Pressure Modulating Control

Screens.........30,40

Building Pressure Output Signal

Screens.........30

,40

Building Pressure Reverse Acting

Screens.........30,40

Building Pressure Setpoint.........51

Protection Limit Setpoint.........50

Sensor Maximum Scale

Screen.........30,40

CO2 Sensor Output Signal

Screen.........30,40

Communications Screen.........12

,18

Conﬁ guration Screens.........24

Control Outdoor Air CFM.........29,39

Cooling & Heating Stage Delays

Screens.........33,43

Cool Reset Source Setpoints.........46

Cutoff T emperature Setpoints.........48

Damper Force Mode Screen.........

Dehumidiﬁ cation Coil Temperature

Setpoints.........49

Dehumidiﬁ cation Control

Screens.........26

,36

Dehumidiﬁ cation Indoor RH & OA

Dewpoint Setpoints.........48

Dehumidiﬁ cation Priority

Screen.........26

,36

Dehumidiﬁ cation Unoccupied

Screens.........26,36

Digital Compressor Signal

Screen.........28

Dual Digital.........29

Duct Static Pressure Screen.........25

,35

Economizer Control Screen.........27,37

Economizer Maximum Position if High

Level Setpoint.........50

Economizer Minimum Position &

Control Rate Setpoints.........49

Economizer OAT/WB Enable

Setpoint.........49

Economizer Overrides.........77

Emergency Shutdown Input.........31

,41

Exhaust VFD Override.........78

Full Digital Module.........29

Head Pressure Module.........28,38,39

Head Pressure Setpoint

Cooling.........49

Head Pressure Setpoint Reheat.........49

Heat During Dehumidify

Screen.........27

,37

Heat Pump Auxiliary Heating

Delay.........52

Heat Pump Control.........30,40

Heat Pump Defrost Setpoints.........53

Heat Reset Source.........47

Heat Wheel Defrost Setpoint.........53

Holiday Schedule.........15

,23

HVAC Mode Enable Screen.........26

HVAC Mode Select Deadband

Setpoints.........45

HVAC Mode Sensor Slide Offset

Setpoint.........52

HVAC Mode Setpoints.........45

HVAC Reset Source.........26

,36

HVAC Schedule Setpoint.........52

Indoor Humidity Sensor

Screen.........27,37

Initialization for Modular Service

Tool.........11

,17

Internal Schedule Optimal Start Soak

Multiplier Setpoint.........53

Loop Search Screen.........20

Max OA Damper Tempering

Limit.........52

Mechanical Heat/Cool Failure Time

Period Setpoints.........51

MiniLink PD Conﬁ guration.........75

Minimum Supply Fan VFD Speed for

Heating Setpoint.........48

Mod Cooling Override.........78

Mod Heating Override.........78

Modulating Cooling/Heating

Screen.........27

,37

Modulating Cooling Output

Signal.........28

Modulating Cooling Proportional

Window Screen.........28

,38

Modulating Cooling Reverse Acting

Screens.........28,38

Modulating Cooling Type.........38

Modulating Heating Output Signal

Screen.........27

,37

Modulating Heating Proportional

Window Screen.........28,38

Modulating Heating Reverse Acting

Screen.........27

,37

Monitor Outdoor Air CFM.........29,39

Monitor Return Air CFM.........29,39

Monitor Supply Air CFM.........29,39

Morning W arm Up Temp

Setpoint.........48

Outdoor Air CFM Deadband Set-

point.........50

Outdoor Air CFM Setpoint.........50

Outdoor Air Cooling & Heating

Lockouts Setpoints.........48

Outdoor Duct/Damper Size.........29

,39

Outdoor Humidity Sensor

Screen.........27,37

Outputs Force Screen.........77

Overrides Screen.........13

,21

Preheat/Low Ambient Temperature

Setpoint.........52

Proof of Flow Input Screen.........27,37

,36

VCM-X / RNE Operator Interface SD

INDEX

S-U

SCREENS, CONT.

Push-Button Override Duration Set-

point.........52

RA Bypass Override.........78

RA Damper Override.........78

Relay Conﬁ guration Screens.........33

Relay Overrides.........77

Return Air Bypass Control

Screens.........31

,41

Return Air Bypass Damper Factor

Setpoint.........51

Return Duct/Damper Size.........29,39

Reversing Valve Active During Heat/

Cool.........31,40

RNE Conﬁ guration Screens.........35

RNE Tonnage.........38

SAT Cooling Setpoints.........46

Schedule Override.........15

,23

Sensor Calibration for COIL.........54

Sensor Calibration for RAT &

OAT.........54

Sensor Calibration for SPC &

SAT.........54

Set Time & Date Screens.........11

Space Sensor Overrides Screen.........21

Split Condenser.........

Stage Control Window Set-

points.........47

Static Setpoint, Deadband & Control

Rate Setpoints.........50

Supply Duct/Damper Size.........30

Supply Fan Cycle Screen.........25

Supply Fan Starting Delay Timer Set-

point.........51

Supply VFD Override.........77

Trend Log Interval Setpoint.........53

Unit Selection Screens.........25

56,65,68,75,77,79 Unoccupied Cooling & Heating

Setbacks Setpoints.........46

Uses R410A.........32

,42

VAV/Zone Box Conﬁ guration.........65

VAV/Zone Conﬁ guration.........65

VAV/Zone Controller Setpoints.........68

VAV/Zone Damper Force Modes.........

VAV/Zone Damper Operation.........65

VAV/Zone Status.........72

VCM-X Conﬁ guration Screens.........25

Water Source Heat Pump

Installed.........38

Week Schedules.........14

,22

WSHP Protection Module.........29

For Loops.........20

For Overrides.........21

Selection Buttons

Deﬁ ned.........10

,16

Sensor, RAT & OAT Setpoint.........54

Sensor Calibration

COIL.........54

Space Temperature.........71

,17

,39

,35

,35,45,

SPC & SAT Setpoint.........54

Supply Air Temperature.........71

SERIES FAN BOX

VAV/Zone.........65

Setpoints.........49

,43

Button.........10

,16

Cool Reset Source.........46

Defrost Heat Wheel.........53

SAT Heating Setpoints.........47

Setting

Date.........11

,17

Day of Week.........11,17

Month.........11

Year.........11

,17

Signal Percentage.........63

Signal Status.........63

Single Zone VAV Mode.........26

Slide Adjust.........57

Slide Offset

VAV/Zone Status.........72

Smoke Detector Input.........31,41

Space Sensor Overrides Screen.........21

Space Temperature.........57

Conﬁ guration.........26,36

Space Temperature Return Air and Slide

Adjust

VCM-X Status.........57

Space Temperature Sensor.........26,36

Split Condenser Screen.........

Stage 1 Signal Percentage.........62,63

Stage 2 Signal Percentage.........62

Stage Control Window Setpoint.........47

Staging Up and Down Delay

Periods.........33

,43

Stand-Alone Connection.........9

Start and Stop Times

2359.........14,22

ZERO.........14,22

Static Pressure

Output % VCM-X Status.........59

VCM-X Output.........59

Static Spt, Deadband & Control Rate

Setpoints.........50

Status

Key.........10,16

Status Screens

Dual Digital Module.........55

Full Digital Module.........61

Head Pressure Condenser Fan

#1.........63

Head Pressure Condenser Fan

#2.........63

Outdoor Air CFM.........59

Supply Air & Return Air CFM.........60

Suction Pressure.........49

Suction Pressure Transducer.........49

Supply Air

Conﬁ guration.........26,36

Temperature.........72

Supply Air CFM

Status.........60

Supply Air & Return Air CFM.........60

Supply Air Temperature Reset.........26

Supply Air Temperature & Setpoint.........57

,36

,63

,61

,36

Supply Air with Supply Air

Tempering.........26

,36

Supply Duct/Damper Size.........30,39

Supply Fan

Cycle Screen.........25,35

Relay.........64

Starting Delay Timer Setpoint.........51

Supply Fan VFD.........26

,36

Supply VFD Override.........77

System

Status.........76

Type.........75

System A.........57

System A Signal.........62

System A Signal Percentage.........62

,63

System B.........57

System B Signal.........62

,63

System B Signal Percentage.........62,63

System Manager

Dimensions.........6

Override Search.........21

Passcodes.........19

System Manager TS.........10

,16

Temperature

Circuit A.........61

Circuit B.........61

Coil B1.........62

Coil B2.........62

Dual Digital.........61

Full Digital.........61

Testing the System

Outputs Force.........77

Time

, 24-Hour Military Format.........14,22

Time & Date.........11,17

Touch Screen System Manager.........10,16

Trend Log Interval.........53

Troubleshooting the System

Outputs Force.........77

Two Condenser Head Pressure

Module.........63

Type of Head Pressure Module

Installed.........28

,38

Unit Selection Screen.........25,35,45,

56,65,68,75,77,79

Unoccupied

Cooling & Heating Setbacks

Setpoints.........46

Mode.........15

Setbacks.........68

Updating Controllers & Modules.........82

,23

VCM-X / RNE Operator Interface SD

INDEX

V-Z

VAV/Zone

AHU Heat Call Space

Temperature.........69

Box Heat Allow.........66

Conﬁ guration.........65

Controllers.........65

COOLING ONLY BOX.........65

Damper Airﬂ ow

Cool/Heat Minimum.........69

Integral.........69

Maximum.........69

Vent Minimum.........69

Damper Airﬂ ow Fixed Position.........70

Damper Airﬂ ow Night

Minimum.........70

Damper Airﬂ ow Reheat

Minimum.........70

Day/Night Schedule.........71

Dump Zone.........67

Expansion Relays Heating

Stages.........66

H/C CHANGEOVER BOX.........65

Main Fan Status.........66

Maximum EMS Offset.........71

Maximum Slide Offset.........71

Occupied Setpoints.........68

PARALLEL FAN BOX.........65

Pressure Independent Airﬂ ow

Constant.........66

Proportional Heating Signal.........66

Push-Button Override.........66

Push-Button Override Duration.........71

Sensor Calibration for Space

Temperature.........71

Sensor Calibration for Supply Air

Temperature.........71

SERIES FAN BOX.........65

Unoccupied Setbacks.........68

Voting Zone.........66

Zone Alarm Delay.........70

Zone Alarm Offsets.........70

VAV/Zone Conﬁ guration

Damper Operation.........65

VAV/Zone Setpoints

AHU Heat Call Space

Temperature.........69

Damper Airﬂ ow

Cool Minimum.........69

Heat Minimum.........69

Integral.........69

Maximum.........69

Vent Minimum.........69

Damper Airﬂ ow Fixed Position.........70

Damper Airﬂ ow Night

Minimum.........70

Damper Airﬂ ow Reheat

Minimum.........70

Day/Night Schedule.........71

Fan On Min.........70

,74

Maximum EMS Offset.........71

Maximum Slide Offset.........71

Occupied Setpoints.........68

Push-Button Override Duration.........71

Sensor Calibration for Space

Temperature.........71

Sensor Calibration for Supply Air

Temperature.........71

Unoccupied Setbacks.........68

Zone Alarm Delay.........70

Zone Alarm Offsets.........70

VAV/Zone Status

Airﬂ ow.........73

Alarm Status.........73

Box Air Temperature.........72

Cooling Setpoints.........72

Desired CFM.........73

Fan Status.........73

Heating/Cooling Demand.........72

Heating Setpoints.........72

Mode of Operation.........72

Reheat Stages.........73

Screens.........72

Slide Offset.........72

Supply Air Temperature.........72

Zone Damper Position.........73

Zone Temperature.........72

VCM-X Controller

Alarm Conditions.........64

Analog Output Override.........77

Building Pressure Output %.........60

Bypass Damper Signal.........64

Coil Temperature.........58

Conﬁ guration Screens.........25

Cooling.........56

Damper Force Modes.........74

Date.........11

Dewpoint Temp.........58

Economizer.........56

Economizer Overrides.........77

Exhaust VFD Override.........78

Heating.........56

Holidays.........14

Holiday Start/Stop Times.........15

Indoor RH Setpoint.........59

Leaving W ater Temperature.........57

MHGRV Output %.........60

Mod Cooling %.........60

Mod Cooling Override.........78

Mode.........56

Mode Cooling Setpoint.........56

Mode Enable Temperature.........56

Mode Heating Setpoint.........56

MODGAS Output %.........60

Mod Heating %.........60

Mod Heating Override.........78

OA Dewpoint.........58

Occupied Mode.........15

Outdoor Air Relative Humidity.........58

Outdoor Air Temperature.........58

Outputs Force.........77

,17

,63

,23

RA Bypass Override.........78

RA Damper Override.........78

Relay Overrides.........77

Return Air Damper Signal.........64

Schedule Override.........15

Scheduling.........14

Space Temperature Return Air and

Slide Adjust.........57

Static Pressure Output %.........59

Supply Air Temperature &

Setpoint.........57

Supply Fan Relay.........64

Supply VFD Override.........77

Time & Date.........11

Unoccupied Mode.........15

Week Schedules.........14,22

VCM-X Modular

Controller.........29,61,62,63

VCM-X Schedule Holidays.........14

VCM-X WSHP Controller .........61,62

VFD.........25,35

VFD Full.........38

VFD Half.........38

Voltage

Maximum for Main Fan.........32

Voting Zone Conﬁ guration.........66

,23

,22

,17

,23

,22

,42

Warm-up Mode Relay.........64

Warm-up Mode Relay

Conﬁ guration.........33,43

Water Source Heat Module

Coil Temperature Status.........61

Signal Status.........63

Water Source Heat Pump.........61

Water Source Heat Pump Installed

Screen.........38

Week Schedules

VCM-X Controller.........14

W etbulb Temperature.........59

Wiring

Power/Comm Board.........8

WSHP Protection Module Screen.........29

,22

Year.........11,17

Zone Alarm

Delay.........70

Offsets.........70

Zone Damper Position

VAV/Zone Status.........73

Zone Temperature

VAV/Zone Status.........72

VCM-X / RNE Operator Interface SD

NOTES

VCM-X / RNE Operator Interface SD

Form: OR-VCMXRNEOISD-TGD-01G Printed in the USA April 2015 All rights reserved. Copyright 2015 WattMaster Controls Inc.  8500 NW River Park Drive  Parkville, MO  64152 Phone: 866-918-1100 www.orioncontrols.com Fax (816) 505-1101

Orion VCM-X-RNE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
