Oricom TP150 User Manual

Care Phone with Emergency Call
Function TP150
WARNINGS
THE CARE PHONE INCLUDING THE EMERGENCY CALL FUNCTION WILL NOT OPERATE UNLESS ALL THE PROCEDURES IN THE USER GUIDE HAVE BEEN COMPLIED WITH. YOU MUST READ THIS USER GUIDE IN FULL.
1 General Information
Warnings
It is very important that you read the User Guide carefully as it contains
detailed information on installation, programming and operational issues which you will need to be aware of to ensure the Care Phone operates properly. If you are not clear about how to install the phone or have any queries on any issue, please contact our Australian Customer Support Service on 1300 889 785. The following is a list of some of the important issues and important warnings which you need to be aware of. This is not a summary of all the important issues and you must still read the User Guide in full.
The emergency call feature will not be activated in the following circumstances:-
the remote pendant is not within the range of up to 30 metres from the phone;
the battery for the remote pendant is not properly installed or is flat;
the phone is not properly connected to power and the telephone line or the phone battery is not properly installed or is flat;
the phone is engaged or off the hook;
No emergency numbers have been stored in the phones memory.
Warnings
Add your emergency message to more than one number to avoid circumstances where the only person contacted is not available.
Inform the person(s) whose number(s) will be stored in the emergency message that they need to acknowledge the call by pressing 0 at the appropriate time.
Ensure the numbers are stored with the area code and in the order in which you want the phone to call them.
Edit the stored phone numbers for persons to be contacted in emergency situations when they change their phone numbers.
Ensure the telephone has charged backup batteries installed at all times.
Test the emergency call feature regularly.
Test the batteries on both the phone and the pendant regularly to ensure they are charged sufficiently to activate the emergency call feature.
The telephone is designed for indoor use only. Do not install the telephone in areas where there is the risk of an explosion, excessive exposure to smoke, dust, vibrations, chemicals, moisture and heat.
Do not use your telephone during an electrical thunderstorm as it is possible to get an electric shock. Refer to information contained in Telstra White pages directory.
The earpiece of the handset may attract small metal objects such as staples and pins. Care should be taken when placing the handset near these items.
Setting the receiver volume to maximum may, under some situations cause ear damage. We suggest returning the handset volume control to the “0” position after each call.
Do not install in damp locations such as a bathroom or laundry, do not expose the unit to direct sunlight.
Notes for operation in New Zealand
The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with the minimum conditions for connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above all, it provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment of a different make or model, nor does it imply that any product is compatible with all of Telecom’s network services. This equipment shall not be set to make automatic calls to the Telecom “111” Emergency Service. This equipment may not provide for the effective hand-over of a call to another device connected to the same line. This equipment should not be used under any circumstances that may constitute a nuisance to other Telecom Customers. If a charge for local calls is unacceptable, the “DIAL“ button should NOT be used for local calls. Only the 7 digits of the local number should be dialled from your telephone. DO NOT dial the area code digit or the “0“ prefix.
REN (RN for New Zealand)
The REN (Ringer Equivalence Number) or (RN) is of significance only if you wish to connect more than 1 telephone to your telephone line. A standard telephone line has a maximum REN capacity of 3 (RN of 5). It is possible to connect 3 devices with a REN of 1 (RN of 1) with no degradation to the product’s performance. Exceeding this limit may cause the volume of the ringer in any phone to decrease or not ring at all.
Caller ID
Customers using non Telecom toll services should not use the dial back feature for local calls as this will incur a charge only the 7 digit number should be dialled. Some of the CID services listed may not be available in New Zealand.
2 Location of controls
1
REPEAT
NEW
2
VOICE
3 4
CALL BACK
5 6
DELETE
M1
7
8 9
3 4 5
10
1. Telephone Line Jack
2. Hook switch
3. Handset Holder
4. Delete Button
5. Call Back Button
6. Memory Buttons (M1, M2)
7. Speaker
8. Keypad
9. Handset volume control
10. Receiver volume LED
11. Power Jack
12. New Call LED
13. Display
14. / Buttons
M2
SPEAKER
11
#
CALL
CLIP
12 13 14 15
SOS
MENU
CID
16 17
18 19
RECALL
MUTE
REDIAL
20 21
22 23
24 25
27 28
26
15. Ringer Hi/Mid/Low Switch
16. SOS Button
17. Menu Button
CID
18.
Button
19. Recall Button
20. Tone Hi/Lo Switch
21. Volume Hi/Lo Switch
22. Mute Button
23. Redial Button
24. Speaker Button
25. Ringer LED
26. Speaker LED
27. Remote pendant Button
28. Remote pendant LED
N13134
The A-Tick symbol indicates that this product complies with all current Australian ACMA standards.
3 Installation
3.1 Installing batteries (supplied) in the phone
Warnings
You must install 4 AA Alkaline batteries in the phone base. The battery back up system will then be able to power the unit for up to 12 hours if there is a mains power failure. If your mains power has been turned off for an extended period or the power supply to the phone has been unplugged from mains power you should replace the batteries with 4 new high quality AA Alkaline batteries. Before opening the battery compartment, make sure the telephone is disconnected from the telephone line and the mains power supply.
1. Use a flat-blade screwdriver or tip of a pen to lift and remove the battery compartment door.
2. Insert four AA batteries into the compartment as indicated by the polarity symbols.
3. Snap the battery compartment door back into place.
When this symbol appears on the display or the display dims, replace the batteries. Always use 4 new high quality Alkaline AA batteries.
3.2 Connecting the mains power supply
Insert the plug of the power supply into the round socket at the back of the telephone and plug the power supply into a working mains power point. The power adaptor must be connected to mains power and the wall switch be turned on at all times.
CAUTION
Use only the mains adapter supplied with this product. Incorrect adaptor polarity or voltage can seriously damage the unit.
Adaptor for base:­Input: 240 VAC 50 Hz Output: 9VDC 200 mA
3.3 Connecting the telephone
1. Plug one end of the telephone cable supplied into the TEL. LINE jack at the back of the telephone base.
2. Plug the other end of the telephone cable into the wall outlet.
3. Plug one end of the curly cord into the socket on the handset.
4. Plug the other end of the curly cord into the left side of the telephone.
3.4 Wall Mounting
Method A. To fit to an existing telephone wall plate with modular connector
simply,
1. Press and lift out the handset holder on base. Rotate it 180°, and snap it into place (see A) so it will hold the handset in place when the phone is mounted on the wall.
2. Insert the mounting bracket’s two tabs into the matching slots on the phone’s base. (see fig B)
3. Then press down and slide the bracket upward until the tabs snap into place.
4. Plug the short telephone line cord (supplied) into the base of the phone and plug the other end into the telephone wall plate socket.
5. Position the mounting holes on the base of the phone over the two protruding screws on the wall plate. Gently push the phone flush against the wall plate then slide the phone downwards locking it into place.
Method B. Attach directly to a wall
1. Drill two holes vertically, one above the other, 83mm apart, and leave the screws protruding from the wall by 5mm.
2. Follow steps 1 and 2 above.
3. Then press down and slide the bracket upward until the tabs snap into place.
4. Plug one end of the telephone cable into the TEL. LINE jack at the back of the base.
5. Plug the other end of the telephone cable into the telephone socket, then align the base’s keyhole slots with the screws and slide the phone downward to secure it.
fig A
fig B
4 Setting Up
4.1 Setting the contrast
1. Press the MENU button. The display shows LCD CONTRAST”.
2. Press the CALL BACK button. The display shows the current contrast setting with values between 1 and 5.
3. Press or to select the contrast level and confirm with CALL BACK button.
4. The display now shows to TIME/DATE”, you can refer to next section to set the time and date or press
4.2 Setting the TIME and DATE
1. Press and release the MENU button until TIME/DATE” is shown.
2. Press the CALL BACK button. The display shows “ENTER TIME” and the hours digit is flashing.
3. Select the current hour using the or and confirm with CALL BACK button. The minutes will now flash in the display.
4. Select the required minutes using the or and confirm with CALL BACK button. The display now shows ENTER DATE and the month digit is flashing.
5. Select the current month using the or and confirm with CALL BACK button. The day will now flash in the display.
6. Select the current day using the or and confirm with CALL BACK button.
7. Exit the set-up mode using the
CID
button to exit the set-up mode.
CID
button.
4.3 Setting country (AUSTRALIA/NEW ZEALAND) mode
The factory preset is AUS.
1. Press and release the MENU button until AUS /NZ is shown.
2. Press the CALL BACK button.
3. Select your location (AUS or NZ) by using or and confirm with CALL BACK button.
4. Press
CID
to exit the set-up mode.
Note: Australia Recall/flash time is 100ms. New Zealand Recall/flash time is 600ms, the unit is now set up to insert 0/00 when receiving CID log in accordance with Telecom NZ requirements.
