Oricom UHF2500 User Manual

Operating Instructions

UHF2500 80 Channel UHF

Citizen Band Radio

Keep this user guide for future reference.

Always retain your proof of purchase in case of warranty service.

Need Help?

If you need assistance setting up or using your Oricom product now or in the future, call Oricom Support.

Australia

1300 889 785 or (02) 4574 8888



www.oricom.com.au



Mon-Fri 8am – 6pm AEST

New Zealand

0800 674 266



www.oricom.co.nz



Mon-Fri 10am – 8pm NZST



Table of Contents

Safety Information and Warnings

.................................... 4

Getting Started...............................................................

9

Controls and Indicators.................................................

13

Operation.....................................................................

14

UHF Channels and Frequencies....................................

23

Express Warranty.........................................................

26

Early in 2011 new AS/NZS Standards came into effect allowing operators to use additional narrowband channels and also use narrowband transmissions on some current wideband channels.

Why did the ACMA increased the number of available UHF CB channels?

To provide additional channel capacity within the UHF CB Band the ACMA has changed the majority of the current wideband 80 channel use to narrowband 80 channel use.

Wideband channel use will be gradually phased out as users upgrade their existing radio’s. This increased the number of channels up to 80, 75 of which are useable voice channels.

This means that the new Oricom narrowband radio you have purchased will have more channels than older wideband radios. Some of these channels are locked and cannot be used, (see the attached channel chart for more information).

What issues may users experience during the transition phase?

When a new narrowband radio receives a transmission from an older wideband radio the speech may sound loud and distorted - simply adjust your radio volume for the best listening performance. When an older wideband radio receives a signal from a new narrowband radio the speech may sound quieter - simply adjust your radio volume for best listening performance. When operating a narrowband radio or Channel 41 - 80 interference is possible from wideband radios transmitting on high power or on adjacent frequency.

The issues described above are not a fault of the radio but a consequence of mixed use of wideband and narrowband radios.

It is expected that as older wideband radios are removed from service that this issue will be resolved. Most radios in use will be narrowband eliminating this issue.

This information is current at time of printing. For further up to date information please visit www.acma. gov.au

Oricom Connecting you now.

R-NZ

This unit complies with all relevant Australian and New Zealand approval requirements AS/NZS 4365: 2011 including radio communications (Electromagnetic Radiation Human Exposure) standard 2003.

3

Safety Information and Warnings

Safety Information and Warnings



Information on Safe Operation

WARNING

Read This Information Before Using Your Oricom Radio.

The operation of your UHF radio in Australia and New





Zealand is subject to conditions in the following licenses:

In Australia the ACMA Radio communications (Citizen Band Radio Stations) and in New Zealand by MED the General User Radio License for Citizen Band Radio.

Radio Antenna

Do not use any radio that has a damaged antenna. If a damaged antenna comes in contact with the skin, a minor burn may result.

Unauthorized antennas, modifications, or attachments could damage the radio and violate compliance. Do NOT change or modify the antenna.

Do NOT hold the antenna when the radio is “IN USE.” Holding the antenna reduces range and may cause bodily harm.

Safety and general use whilst in a vehicle

Check the State and Federal laws and regulations regarding the use of two way radios in the area where you drive, and always obey them.

For Vehicles fitted with Air Bags

Do not place your radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a radio is placed in the air bag deployment area and the air bag inflates, the radio may be propelled with great force and cause serious injury to the occupants of the vehicle.

Read all these Safety Warnings before you install or charge the rechargeable batteries.

Do not dispose of the rechargeable batteries in a fire as they may explode.

Use only the rechargeable batteries supplied with the product. Improper use, or use of unapproved batteries may present a risk of fire, explosion, or other hazard, and may invalidate any approval or warranty.

4







Safety Information and Warnings







• Exercise extreme care when handling batteries in order







not to short the batteries with conducting materials such

WARNING

as rings, bracelets and keys. The batteries or conduction







material may overheat explode and or cause burns.

Never replace or charge the batteries in a potentially explosive atmosphere (such as where gas is leaking) as contact sparking may occur while installing or removing the batteries cause a fire or an explosion.

Do not modify, cut, disassemble, crush, bend, puncture, heat or damage the batteries.

If the batteries leak, do not let the battery liquid touch skin or eyes. If this happens, immediately flush the affected areas with water, and seek medical assistance. Released electrolyte is corrosive and may cause damage to the eyes and skin. It may be toxic if swallowed.

Do not immerse or expose the batteries to water or other liquids.

If you believe the batteries are damaged, remove product from the charger and stop using the product. Contact Oricom for assistance.

Never use damaged batteries as they may explode.

Remove batteries when they are no longer able to hold a charge and when the equipment will not be used for an extended period of time. Dispose of the batteries according to local regulations, never in your household rubbish.

Risk of explosion if battery is replaced by an incorrect type. Only use the AC power adaptor supplied with this product. Using any other AC adaptor will invalidate any approvals and warranty and could be potentially dangerous.

Do not attempt to charge non-rechargeable Alkaline batteries.

5

Safety Information and Warnings



Potentially Explosive Atmospheres

WARNING

Turn your radio OFF when in any area with a potentially

explosive atmosphere. Sparks in such areas could cause





an explosion or fire resulting in injury or even death.

NOTE: Areas with potentially explosive atmospheres are often, but not always clearly marked. They include fueling areas such as below deck on boats; fuel or chemical transfer or storage facilities; areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle engine.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn your radio OFF near electrical blasting caps or in a “blasting area” or in areas posted: “Turn off the two way radio.” Obey all signs and instructions.

Exposure to Radio Frequency Energy

Your Oricom two-way radio complies with Australian Communications Authority Radio communications (Electromagnetic Radiation-Human Exposure) Standard, 2003.

To assure optimal radio performance and make sure human exposure to radio frequency electromagnetic energy is within the guidelines set out in the above standards always adhere to the following procedures.

Transmit and Receive Procedure

Your two-way radio contains a transmitter and a receiver. To control your exposure and ensure compliance with the general population/uncontrolled environment exposure limits, always adhere to the following procedure:

Transmit no more than 50% of the time.

To receive calls, release the PTT button.

To transmit (talk), press the Push to Talk (PTT) button.

Transmitting 50% of the time, or less, is important because the radio generates measurable RF energy exposure only when transmitting (in terms of measuring standards compliance).

Always hold the radio approximately 5cm in front of your mouth with the antenna pointing away from your head.

6

Safety Information and Warnings



Radio Operation and EME Exposure

WARNING

Unauthorized antennas, modifications, or attachments

could damage the radio and violate compliance.



Do NOT hold the antenna when the radio is “IN USE.” Holding the antenna reduces the effective range.

Do not use the radio if the antenna is damaged. If a damaged antenna makes contact with your skin, a minor burn can result.

If you wear a radio on your body when transmitting, always fit the radio on the belt clip (supplied). Always ensure the radio and it's antenna are at least 5cm from your body when transmitting.

Electromagnetic Interference/Compatibility

Nearly every electronic device is susceptible to electromagnetic interference (EMI). To avoid the possibility of electromagnetic interference and/or compatibility conflicts, turn off your radio in any location where posted notices instruct you to do so such as health care facilities.

Aircraft

When instructed to do so, turn off your radio when onboard an aircraft. Any use of a radio must be in accordance with applicable regulations per airline crew instructions.

Medical Devices - Pacemakers

The Advanced Medical Technology Association recommends that a minimum separation of 6 inches (15cm) be maintained between a handheld wireless radio and a pacemaker. These recommendations are consistent with the independent research by and recommendations of the U.S. Food and Drug Administration.

People with pacemakers should:

ALWAYS keep the radio more than 15cm from their pacemaker when the radio is turned ON.

Not carry the radio in the breast pocket.

Use the ear opposite the pacemaker to minimize the potential for interference.

Turn the radio OFF immediately if there is any reason to suspect that interference is taking place.

7

Safety Information and Warnings



Medical Devices - Hearing Aids

WARNING

Some radios may interfere with some hearing aids.

In the event of such interference, you may want to consult





your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

General warnings

Keep the radio out of reach of babies and young children.

Waterproof: IPX7

Oricom’s UHF2500 radio is designed to meet the water proofing standard IPX7.

The UHF2500 is designed to float when in water, the LED light will flash and LCD backlight to assist you in locating the radio when in water.

The IPX7 means:

Being defined as having no ingress of water when immersed at 1 meter for 30 minutes. (To meet the IPX7 waterproof rating, the

accessory socket cover must be in place, the battery must be fitted correctly)

NOTE: DO NOT submerge the transceiver in water if there is any reason to suspect the waterproof protection may not be effective. For example, in cases where the battery cover or external jack cap rubber seal is damaged, the transceiver/battery cover/jack cap is cracked or broken, or the transceiver has been dropped, or when the battery cover or Jack cap are detached form the transceiver.

8







Getting Started

Pack Contents





Model No. UHF2500-1

Model No. UHF2500-2

1

UHF2500 Handheld Radio

2

UHF CB Handheld Radios

3

1200mAH AA Ni-MH

6

1200mAH AA Ni-MH



Rechargeable Batteries



Rechargeable Batteries

1

AC Adaptor

1

AC Adaptor

1

USB Cable

1

USB Y Cable for Charging

1

Oricom Carabiner

1

Twin Charging Pod

1

Belt Clip

2

Oricom Carabiners





2

Belt Clips

Accessories and spare parts can be purchased directly from Oricom. Visit www.oricom.com.au or call 1300 889 785 or (02) 4574 8888.

Installation

Installing the Batteries

Figure 3 Figure 4

Caution: Observe the proper battery polarity orientation when installing batteries. Incorrect positioning can damage both the batteries and the unit.

a.Unlock two screws.

b.Install the rechargeable batteries (supplied) by following the orientation as shown in Figure 3.

c.Replace the Battery Compartment Cover. Tighten the screws see Figure 4. NOTE: You can use Alkaline batteries if required, however YOU MUST NOT

PLACE THE RADIOS ON THE CHARGER WITH ALKALINE BATTERIES INSERTED as this will damage the radio.

9
