Oricom Secure 500 User Manual

Baby Monitor

Secure 500

User Guide

TABLE OF CONTENTS

WARNINGS AND SAFETY INFORMATION 1

GETTING STARTED 3

YOUR BABY MONITOR 6

LCD DISPLAY OF BABY MONITOR 10

BASIC OPERATION 11

MENU SETTINGS 18

TROUBLESHOOTING 23

PRODUCT SPECIFICATIONS 24

GUARANTEE 25

WARNINGS AND SAFETY INFORMATION

1

IMPORTANT

Please read this user guide thoroughly before use.

Your ORICOM Baby Monitor is designed to be an aid and
should not be used as a substitute for responsible and
proper adult supervision of a child.

The Baby Monitor has been designed to provide some
added reassurance in the form of sound transmission
for those times when you are not in the same room as
your baby provided you always stay within hearing range
of the baby monitor during use. Your Baby Monitor is
not a medical device, nor a device to prevent cases of
Sudden Infant Death Syndrome (SID'S) or "cot death",
and you should not rely on it for your baby's wellbeing. It is
important that you regularly check on your baby personally.

Make sure the Baby unit, Parent unit and mains adaptor
cables are kept out of reach of your baby and other young
children within the house at all times, at least one metre
away from the baby’s cot.

Never place the baby unit inside your baby’s cot, bed or
playpen.

Never cover the Parent or baby units with clothes, towels
or blankets or any other item.

Do not place the cord in a high "wear and tear" location.
Never use a frayed or compromised cord.

Never use or place your Parent or Baby units in or near
moisture or water (e.g. near bath or pool). Immersing in
water can cause electric shock and even death.

Power requirements

This product requires an electrical supply of 220-240 volts,
single phase alternating current.

CAUTION

!

If you plan to use your Baby monitor whilst travelling
overseas, make sure that the voltage shown on the mains
power adaptor is the same as the local mains power before
connecting to the power supply. Do not use any voltage
converter with the monitor.

Use only the mains power adaptors supplied with this
equipment. Incorrect adaptor polarity or voltage can
seriously damage the unit and/or cause physical harm
and even death. The adaptors may become warm during
use, please take care when handling.
AC Adaptor (Baby unit / Parent unit)
Input: 100-240VAC 50-60Hz
Output: 7.5VDC 500mA

2 WARNINGS AND SAFETY INFORMATION

Battery requirements

Each parent unit requires two rechargeable Ni-MH
batteries, size AA 1.2V 1300mAh.

• Do not dispose of the batteries in a fi re, as they can

explode.

• Do not open, unscrew or temper with any of your
baby monitor units or battery. Always carry out repairs
through your authorised ORICOM representative or
other duly qualifi ed tradesperson.

• Released electrolyte from the battery is corrosive
and can cause damage to the eyes or skin. It can
be toxic and fatal if swallowed. If there is any sign of
poisoning, immediately call emergency 000.

• When your Baby Monitor is not in use, it is recom­mended that you disconnect it from the mains supply
and remove the batteries.

• Observe the proper polarity, or direction, of any
battery. Reverse insertion of the battery cell can
result in leakage or explosion and in turn harm or
even death.

• The Ni-MH batteries supplied with this product may be
able to be recycled once they are unable to recharge
during normal operation. Always observe your local
Council /State regulations regarding the disposal of
your packaging materials, exhausted batteries, and old
equipment.

• Always recycle where possible. Do not use your baby
monitor in an explosive hazard area such as where
there is gas leaking.

• As there is a slight chance that the product could be
damaged by an electrical storm, it is recommended that
users unplug from the mains supply during an electrical
storm.

Cleaning and care

The surface of the case can be cleaned with a dry, soft,
lint-free cloth. Never use cleaning agents, particularly
aggressive solvents. Apart from occasional cleaning of the
case, no other care is necessary.

3GETTING STARTED

Thank you for choosing this monitor from Oricom.

Your Secure 500 Baby Monitor offers the best Digital
Technology.

INTERFERENCE
FREE FREQUENCY

DECT (Digital Enhanced Cordless Telecommunications) is the
most widely used worldwide digital cordless technology, offering
amazingly clear sound, long range and maximum voice security.

DECT operates on the 1.8Ghz frequency which eliminates potential
interference from other common wireless devices such as cordless
telephones, wireless networks (Wi-Fi), Bluetooth and cordless
computer devices.

Pack Contents

• Parent unit (receiver)

• Baby unit (sender)

• Mains adaptor with charger pod

• 2 x NiMH rechargeable batteries (type AA, 1300mAh)

• Mains adaptor with power cord

• Wall mounting bracket for the baby unit

• Purple travel bag

Installation and Charger

For the Parent Unit

1. Remove the battery cover
on the back of the Parent
Unit by pressing and
sliding it down. Insert the
rechargeable batteries as
marked on the unit and
close the cover again.

2. Place the Parent Unit into
the Charger Pod.

3. Plug the mains adaptor into a mains power socket.

The red charger light on the charger pod will illuminate

indicating that the Parent Unit is charging.

(the light will remain on to ensure

optimum charge is maintained).

WARNING

!

DO NOT USE STANDARD/ALKALINE BATTERIES
IN THE PARENT UNIT, AS THERE IS A RISK OF
EXPLOSION AND/OR INJURY. USE ONLY Ni-MH
RECHARGEABLE BATTERIES AS SUPPLIED.

4

GETTING STARTED

4. Press [ ] to turn the Parent Unit on.

• Before fi rst use, or if it has been out of use for a long

time, the Parent Unit will need to be charged for 14
hours. During this time, the Parent Unit will operate
from the Charger pod when switched on. Note that the
Parent Unit cannot be used without batteries, even if it
is placed in the charger pod.

For the Baby Unit

1. In event of a power failure, your Baby Monitor can
switch to battery power. It is therefore recommended
that you insert non-rechargeable batteries in the
Baby Unit.

2. Remove the battery cover
on the back of the Baby
Unit by pressing and sliding
it down. Insert 4 alkaline
batteries of the type AA
(not provided) as marked
on the unit and close the
cover again. Do not use
rechargeable batteries in
the Baby Unit.

3. Plug the power cord into the power input at the side of
the Baby Unit and plug the adaptor plug into a mains
power socket.

Battery lock

Child tamper proof lock for
the battery compartment.

4. Press and hold [ ] key to turn on the baby unit.

• The Baby Unit should be placed about 1 metre
to 1.5 metres away from the baby's cot on a flat
surface. Never place the Baby Unit inside the cot,
bed or playpen. Make sure the unit, cords and mains
adaptor are out of reach of the baby and other
young children. Never place either Unit on antique
or polished surfaces (as slippage or scuffing may
occur). The unit may cause harm if it falls onto baby
or other young children.

Note:

If you place the Parent and Baby units too close together
you will hear a high pitched noise called "feedback", this is
normal. The units are designed to be located in separate
rooms.

To prevent feedback, do not take the Parent unit into the
nursery/baby's room.

Do no Press Talk button when the Baby unit and Parent
unit are positioned in the same room. Feedback will be
generated if the talk button is pressed when the Baby unit
and Parent unit are within 3 metres of each other.

5GETTING STARTED

Wall mounting the Baby Unit

Use the following wall mount diagram to locate and install
the mounting pins/screws if you prefer to wall mount your
base unit. The dimensions are shown in millimeters (mm).

58.00

Ø 4.00

Ø 7.55

1. Insert screws into the wall through the wall mount.

The recommended mounting screw size is diameter

3mm and length 20mm,the diameter of the screw
head and the screw should not be greater than

7.55mm and 4mm respectively.

2. Put the base unit down into wall mount directly.

Note:

Other wall mounting methods are not recommended and
may damage the product.

6 YOUR BABY MONITOR

Baby unit (Sender)

Press to switch Night Light on or

Night Light

off.

Brightness

Press to adjust the Night Light

brightness (once Night Light is

switched on). There are three levels.

Page

Press to page the Parent unit

– useful for fi nding when it is

misplaced.

Record

Used to record your voice to

comfort your baby and to delete

the recorded message.

Power on/off

Press to switch on or off.

Microphone

Link light

Green when linked to Parent

unit. Flashes if not linked - fi rst

30 seconds. Flashes when Talk

is pressed on Parent unit. Red

fl ashing if not linked longer than

30 seconds.

Up/Register

Increase speaker volume.
Use to enter registration mode.

Down/Default

Decrease speaker volume.
Used to restore original settings.

Play/Stop

Press to play lullaby, press
again to stop.

Lullaby

Press to select lullaby 1, 2, 3
or Play All.

Display

Power saving backlight
switches off 15 seconds
after last button push.

Back of Baby unit

Auxiliary input socket

Use to plug in an external
audio source, e.g. MP3
player so you can play
your own choice of
music to baby.

Temperature sensor

Power socket

For connection
to mains power.

7YOUR BABY MONITOR

Underside

Battery lock

Child tamper proof
lock for the battery
compartment.

8

YOUR BABY MONITOR

Parent unit

From the Parent unit you can listen to your baby and
operate the Baby unit by remote control.

Talk (on side of unit)

Press to talk to your baby.

Power saving backlight switches off

15 seconds after last button push.

Increase speaker volume.

Scroll up through menu options.

Press to open the menu.

Press and hold to exit the menu.

Press to switch the speaker off,

press again to switch it back on.

Display

Up

Menu

Mute

LED Link indicator

Green On – Linked to Baby unit
Green fl ashing – Not linked to Baby unit
– fi rst 30 seconds
Red Flashing – Not linked to Baby unit
– for longer than 30 seconds.

Sensitivity / Volume level LEDs

During use, lights indicate:
– Sensitivity level
– Volume level

Torch (on side of unit)

Press and hold to switch on.
Press to switch off.

Select

Press to confi rm the menu option displayed.
When lullaby is playing, press to pause or resume.

Power on/off

Press and hold to switch the power on or off.

Microphone

Decrease speaker volume.

Scroll down through menu options.

Used to restore original settings.

Down/Default

Back of Parent unit

Charging light

Indicates parent
unit is charging.

Power socket

For connection
to mains power.

YOUR BABY MONITOR

9

10

LCD DISPLAY OF BABY MONITOR

Parent unit display iconsBaby unit display icons

Battery full (icon not
displayed when using
mains power).

Battery half full.

Battery low.

Displayed when the
Night Light is on.

Displayed when a
lullaby is being played.

On when the
temperature is normal.
Flashing when it is
too hot or too cold for
baby.

Speaker is switched off.

Sound alert is on.

Full battery

Mid charge

Low charge

Empty

Scrolling bars when
charging.

Night Light is on.

Lullaby is playing.

Temperature is within
normal levels.

Timer is on.

Vibrate alert is on.

11BASIC OPERATION

Once you have set up your Baby Monitor, you will be able
to hear the sounds in your baby's room through the Parent
Unit. And also see the green and red sensor lights around
the top of the Parent Unit rise and fall with the sound levels.

• If the connection between the Parent and Baby
Units is broken at any time the green Link light on
the Parent Unit will flash slowly, the parent unit will
beep to alter you that the link has been lost and the
green and red sensor lights will cease to react to any
sounds. Move closer to the baby unit or follow the
directions in chapter "Troubleshooting" to re-establish
the link.

Power On/Off

Baby Unit

• Press [ ] key to switch on the unit.

• The Green Link light comes on to show that the unit
is within range of the Parent unit.

• To switch Off, press [ ] key until the display goes
blank and the link light goes off.

Parent Unit

• Press and hold [ ] key. The Link LED on the far left
will illuminate.

• Keep pressing the button until the 3 LEDs to the
far right illuminate as well. The Parent unit is now
switched on and will search for and link itself to the
Baby unit.

• Green LINK Light is lit while unit searches for the
baby unit.

• To switch Off, press [
blank and the link light goes off.

] key until the display goes

Changing Baby unit from battery to
mains power

• To conserve battery power on the Baby unit or when

the batteries are low or fl at, plug the Baby unit into the
mains. If currently running on batteries and switched
on, changing from battery to mains power will be instant
and will not affect any of the settings.

• You can use the Parent unit to monitor baby while it is
charging.

Monitoring

• Position the baby unit accordingly. It should be placed
at least 1 metre away from the baby.

• Take the parent unit to monitor.

12 BASIC OPERATION

• Audio picked up by the baby unit microphone is depicted
on the 7 Lights on the parent unit (4 green and 3 red).
The more audio is picked up, the more Lights will be lit.
When no audio is picked up, all 7 Lights will be off.

• If the volume of the Parent Unit is turned off, an alert will
sound and the unit will vibrate if the vibrator is set to on.

Note:

Do not position the baby unit and the parent unit close to
each other or in the same room as a high-pitched feedback
noise may be generated. User can press [
temporarily turn off the speaker. Press [
will turn on the speaker.

Mute

] key to

Mute

] key again

Sensitivity

You can adjust the sensitivity on the Parent Unit to monitor
the sound from the Baby Unit. For example, if your baby is
a particularly quiet sleeper, you can increase the sensitivity
levels so that you are sure to hear if baby disturbs or
becomes uncomfortable.

There are 5 different levels. Level 5 is the most sensitive
and the microphone in the Baby unit is always on. At levels
1-4, the microphone will be voice activated by the noise
baby makes.

• Press [Menu] key and use [ ] or [ ] key to scroll to

Sensitivity. Press [ ] key.

• Press [ ] or [ ] to select the desired level. For
example, when the current sensitivity level is level 3,
digit "3" will be displayed.

• There are fi ve levels of sensitivity: level 5 represents
the highest sensitivity, level 1 represents the lowest
sensitivity.

• Press [

• Press [Menu] key to return to the standby display.

] key to confi rm.

Adjusting Volume

There are 5 volume levels on each Unit and an Off setting
on the Parent Unit.

On the Parent Unit,

• Press [ ] key to increase the volume or [ ] to decrease the
volume. The volume level is shown on the display bars.

On the Baby Unit,

• Press [+] key to increase the volume or [–] key to
decrease the volume.

Note:

You cannot switch the volume off on the Baby Unit.
Changing the volume setting on the Baby Unit will also

affect the volume when you use the talk back feature or
when playing a lullaby.

13BASIC OPERATION

Talk Back

You can use the talk back feature to talk to your baby.

Whilst using Talk Back you will not be able to hear your
baby until you release the [Talk] key.

• Press and hold [TALK] key on the Parent unit to speak
to baby.

• "Talk" is shown on the display and the green link lights
on both Units fl ash.

• Talk into parent unit microphone.

• Release [TALK] key to hear your baby again.

Note:

Do not press [TALK] key when the baby unit and the parent unit
are in the same room as a high-pitch noise will be generated.

If the Parent Unit volume is off, the Parent Unit volume will
reset to the default volume setting.

Paging

If the Parent Unit is misplaced, you can use the page
button on the Baby Unit to locate the Parent Unit.

• Press [Page] key on the Baby Unit. The paging alert will
sound.

• "PAGING" is shown on the LCD display of both units.

• To stop the Page alert, press any button on the Parent
Unit, or press [Page] key again on the Baby Unit.

Note:

If no button is pressed, the paging tone will stop after 2 minutes.
If the Parent Unit volume is off, after paging operation, the

Parent Unit volume will reset to the default volume setting.

Torch

Press [TORCH] key on the parent unit to switch the torch
on and off.

Night Light

The Night Light on the baby unit can be turned on or off
from either the baby unit or the parent unit. You can set
a comforting Night Light with a choice of three brightness
levels.

Baby Unit

• Press [ ] key to turn Night Light on or off.

• Press [ ] key repeatedly to select the brightness
settings.

Parent Unit

If the Night Light on the baby unit is off,

• Press [Menu] key and use [ ] or [ ] key to scroll to
"Night Light".

14 BASIC OPERATION

• Press [ ] to confi rm and use [ ] or [ ] key to set the

Night Light on or off.

Sound Alert

Sound alerts are played only on the Parent Unit. You can
turn on/off the sound alerts through the menu.

Follow "Sound Alert setting" on the Menu Setting to set the
sound alert.

Vibrate Alert

Vibrate alert is only available on the Parent Unit. You can
turn on/off the vibrate alert through the menu.

Follow "Vibrate Alert" on the Menu Setting to set the sound alert.

Temperature

It is very important for your baby's health to ensure that
they are kept at a safe temperature. This includes the
room temperature, baby's temperature, baby clothing and
bedding (contact your local health authority to ensure you
are aware of the current guidelines). Your Baby Monitor
can show the current room temperature on the Baby Unit
and the Parent Unit, and can even be set to alert you if the
temperature falls outside of a defi ned range.

Follow the "Temperature setting" on the Menu Setting
section to set the temperature range and temperature alert.

Lullaby

Your baby can be soothed to sleep by a gentle lullaby from
the Baby Unit. Each lullaby is played repeatedly for 15
minutes. Select one of the fi ve melodies or select Play All
for a medley of all 5 lullabies for 15 minutes. The lullaby
feature can be turned on and off from both the Baby Unit
and the Parent Unit and is indicated on both by a musical
note icon. The icon and the lullaby name will be shown on
both displays when the lullaby is playing. The lullabies will
play for 15 minutes.

You can also record your own lullaby or story lasting up to
2 minutes. To play your own recorded lullaby, select Own
from the menu list.

You can also plug in an external audio source like an MP3
or CD player and play music or audiobooks of your own
choice. The auxiliary port is on the back of the Baby unit.

Playing the Lullaby

Baby Unit

• Press [ ] key. The lullaby name is shown on the LCD
display.

15BASIC OPERATION

• Press [ ] key repeatedly to select different lullabies.

• Press [

] key to play.

Parent Unit

• Press [Menu] key and use [ ] key to scroll to "Lullaby".

• Press [ ] key to confi rm. "Play?" is shown on the display.

• Press [ ] key to play the Lullaby.

• Or press [ ] key to select "Select New" and press [ ] key.

• Use [ ] or [ ] key to select "Lullaby 1-5", "Own", " Aux"
or "Play All" and press [ ] key. The selected lullaby will
be played.

Stopping the Lullaby Playing

Baby Unit

When a lullaby is playing,

• Press [ ] to stop playback.

Parent Unit

When a lullaby is playing,

• Press [Menu]. The display shows "Stop Lullaby?".

• Press [ ] to stop the lullaby.

If an auxiliary player is connected, you must also switch off
the auxiliary player.

Temporarily Stopping the Lullaby Play

You can stop the lullaby play temporarily. This operation is
only available on the parent unit.

When lullaby is playing,

• Press [

icon fl ashes on both units.

• Press [ ] again will resume the lullaby play.

• If lullaby play is not resumed within 60 seconds, lullaby
will stop automatically.

] to pause. "Paused" is displayed and the " "

Record a lullaby

Record your own Lullaby or story words up to 2 minutes long.

1. Press and hold [Rec] key on the Baby Unit. You can
start recording after the beep. REC and the recording
time are shown on the display.

2. To end recording, release [Rec].

To play your recorded lullaby, follow the steps for Playing
the Lullaby and select "Own".

Note:

Recording is only available when the memory is empty
(after it is deleted).

The baby unit will stop monitoring during lullaby recording.

16 BASIC OPERATION

Delete a recorded lullaby

1. Press and hold [Rec]. After 2 seconds the display
shows "Deleted".

2. Release [Rec].

• To avoid deleting a recorded message, press [
the Baby unit to check whether the Own prompt is
displayed. If Own is displayed in the lullaby list, there is
a recorded message.

] on

Connect to an auxiliary player

Plug another player into your Baby unit, to play songs or
stories.

On the Parent Unit:

1 Press [Menu] and use [ ] or [ ] to select "Lullaby".
2 Press [ ], "Play Lullaby?" is shown on the display.
3 Use [ ] or [ ] to select "Select New" and press [ ].
4 use [ ] or [ ] to select "Aux" and press [ ].
You can now use the external player.

On the Baby unit:

1 Plug your player to the auxiliary input socket on the

back of the Baby unit.

2 Press the [ ] key repeatedly until you reach the AUX

menu.

3 You can now use the external player.

Out of Range

When the baby and parent units have no link with each
other (eg. Out of range, parent unit or baby unit is not
powered on), the green Link LED fl ashes. If there is no link
for more than 30 seconds, "Not Linked" will be displayed
on both units. The link break alert will also be emitted from
the speaker of the Parent Unit every 30 seconds. The red
Link LED will flash. When the units are linked, the green
Link LED will be steadily lit.

Note:

Link break alert cannot be manually set on or off, but it can
be suppressed for 4 minutes by pressing any button.

There is only visual alert shown on the Baby Unit.

Low Battery

Baby Unit

When the unit is running on battery power and reaches low
battery level, the display will show Low Battery. Once the
low battery level is reached, the baby unit should still be
able to operate for approximately 30 minutes.

BASIC OPERATION

17

Parent Unit

When the batteries on the Parent Unit reach a low level, the
display will show Low Battery. The low battery alert tone will
be emitted from the speaker every 60 seconds. Once the
low battery level is reached, the parent unit should still be
able to operate for approximately 1 hour and 30 minutes.
The low battery alert message and alert tone will be turned
off when fully charged batteries have been replaced.

Charging the Battery

Place the parent unit on its charge cradle to charge the
battery. When charging, the red LED on the charger will
light steadily. The bars in the battery icon on the Parent
Unit will scroll. When the battery is full, the battery icon
shows three bars and stops scrolling.

Note:

The Parent Unit must never be operated on the charging
cradle without batteries.

The parent unit can be used on or off the charger pod.
When on the charger pod, the batteries will be recharged
at the same time. However, the time it takes to charge the
batteries to full will be longer when the unit is charged and
used at the same time.

Rechargeable batteries in the Parent unit give up to 12
hours continuous usage. Please note however, that new
batteries do not reach full capacity until they have been in
normal use for several days.

Running rechargeable batteries right down at least once a
week will help them last as long as possible. The charge
capacity of rechargeable batteries will reduce with time as
they age, so reducing the performance time of the parent
unit. Eventually they will need to be replaced.

Restore to Default Setting

You can return the baby and parent units to factory default
settings.

1 Press [ ] to switch the unit off.
2 Press [ ] again to switch the unit back on.
3 While the unit is switching on, press and hold the [ ] key

on the parent unit or the [–] key on the baby unit until
you hear a beep. RESET is showed on the display. The
unit will restore all the original factory settings.

Note:

If [

] or [–] is not pressed within 4 seconds, the unit

returns to idle mode.
If you want to restore the factory default settings on the

baby monitor, you will need to restore factory default
setting on the Baby Unit or on the Parent Unit individually.

18 MENU SETTINGS

Note:

All Menu setting operations are only available on the
Parent unit.

During setting, press [Menu] key to exit.

Night Light Setting

You can turn on or off the Night Light on the baby unit via
the parent unit.

1. Press [Menu] key on the parent unit. The display is
shown below:

Light On?

2. Press [ ] key to select Night light on or off.

Lullaby Setting

You can play lullaby on the baby unit via the parent unit.

Press [Menu] key on the parent unit and use [ ] or [ ] to
select "Lullaby". The display is shown below:

Lullaby

Start playing

1. Press [ ] key, "Play?" is shown, press [ ] key to play
the lullaby.

2. To stop lullaby, press [Menu], "Stop Lullaby?" is shown
and press [

] to stop lullaby.

Selecting lullaby

1. Press [ ] key and use [ ] or [ ] key to select "Select
New".

2. Press [ ] key and use [ ] or [ ] key to select "Lullaby
1-5", "Own", " Aux" or "Play All" .

3. Press [ ] key. The selected lullaby will be played.

Sound Alert Setting

You can turn on/off the sound alerts on the Parent unit.

1. Press [Menu] and use [
alert". The display is shown as the fi gure:

Sound Alert

2. Press [ ], "Alert On?" or "Alert Off?" is shown on the
display.

3. Press [ ] to confi rm.

] or [ ] key to select "Sound

19MENU SETTINGS

Sensitivity Setting

You can adjust the sensitivity on Parent Unit to monitor the
sound from the Baby Unit. For example, if your baby is a
particularly quiet sleeper, you can increase the sensitivity
levels so that you are sure to hear if baby disturbs or
becomes uncomfortable.

1. Press [Menu] key on the parent unit and use [
[ ] key to select "Sensitivity". The display is shown below:

Sensitivity

2. Press [ ] key and then use [ ] or [ ] key to select the
sensitivity level. There are 5 levels.

3. Press [ ] key to confi rm.

] or

Temperature Setting

You can monitor the temperature in the baby's room. The
room temperature is constantly displayed on both Units.

An alert will sound when the room temperature is raised or
dropped out of the pre-set temperature range.

Please note the baby monitor cannot manipulate the
temperature in your baby’s room, it only provides a
temperature reading.

Press [Menu] and use [
the display is shown below:

] or [ ] to select "Temperature",

Temperature

Setting Temperature Alert

You can set the temperature alert on the Parent Unit when
the temperature goes above or below these settings. If this
happens, the display will show "High" or "Low" as appropriate.

1. Press [MENU] key and use [ ] or [ ] key to scroll to
"Temperature". Press [ ].

2. "Alert on/off" is displayed, press [ ].

3. Use [ ] or [ ] to select "Alert On?" or "Alert Off?".

4. Press [ ] to confi rm.

Note:

If the vibrator is set to on, the Parent Unit will also vibrate
when the temperature is too high or too low.

Pressing any button can suppress the alert sound until
temperature goes beyond further 2 degrees.

20 MENU SETTINGS

Setting Temperature Range

You can select your own minimum and maximum room
temperatures. The minimum temperature can be anywhere
between 10˚C and 19˚C and the maximum temperature
anywhere between 22˚C and 30˚C. Note the default setting
is 14˚C min. and 23˚C max.

1. Press [MENU] key to scroll to "Temperature". Press [

2. Press [ ], use [ ] or [ ] key to select "Range".

3. Press [ ]. Press [ ] or [ ] to change the minimum
temperature setting.

4. Press [ ] to confi rm.

5. Press [ ] or [ ] to change the maximum temperature
setting.

6. Press [ ] to confi rm.

Note:

If the temperature goes beyond the minimum or maximum
level, "Low" or "High" indication displays and the current
temperature flashes in the displays of both Units. If the
Temperature alert is set to On, an alert will be sound on
the Parent Unit. The alert sound will go off automatically
when the temperature falls within the pre-set range.

].

Timer Setting

Set countdown timer

The timer can be set to countdown from 1 minute to 99
hours 59 minutes. The TIMER icon [ ] is displayed along
with the countdown time.

Press [Menu] key and use [ ] or [ ] key to select "Timer",
the display is shown below:

Timer

1. Press [ ] key, "Countdown" is shown on the display.
Press [ ] key.

2. Press [ ] or [ ]. "Set Time" is shown on the display.

3. Press [ ], then use [ ] or [ ] key to set the hour.

4. Press [ ], then use [ ] or [ ] key to set the minutes.

Start or cancel countdown Timer

1. In the Timer setting menu, press [ ].

2. "Countdown" is shown on the display. Press [ ].

3. "Timer On?" or "Timer Off?" is shown on the display.
Press [ ].

21MENU SETTINGS

Activate count up timer

The timer can count up from 1 second to 99 hours 59
minutes.

The TIMER icon [
time.

1. In the Timer setting menu, Press [ ].

2. Use [ ] or [ ] key to select "Count up". Press [ ].

3. "Timer On?" is shown on the display, Press [ ] to

confi rm.

] is displayed along with the countup

Start, Stop and Reset the count up timer

Parent Unit

When count up is activated,

1. When it stops and displays 00:00:00, press [ ] to start,
it will count from 00:00:00;

2. When it is counting, press [ ] to stop. Counted time is
displayed steadily;

3. When it stops and displays a counted time, press
[ ] to reset it to 00:00:00;

4. Press [ ] again to restart it.

Cancel count up timer

1. Press [Menu] and use [ ] or [ ] key to select "Timer".
Press [ ].

2. Use [ ] or [ ] key to select "Count up". Press [ ].

3. "Timer Off?" is shown on the display, press [

confi rm.

If countdown is currently running, the count up timer will not
be available, and vice versa. Only one of the timers can be
used at one time.

] to

Set clock

This sets the clock on both units.

1. Press [Menu] and use [ ] or [ ] key to select "Timer".
Press [ ].

2. Use [ ] or [ ] key to select "Clock" and press [ ].

3. "Set Time" is shown on the display. Press [ ].

4. Press [ ] or [ ] to set the time then press [ ] to
confi rm.

5. If you set the time format to 12 hour, you should set the
AM or FM. Press [ ] or [ ] to set AM/PM for 12 hours
then press [ ].

Set 12 or 24 hour Format

Time format menu is available only after Clock is activated.

1. Press [Menu] and use [ ] or [ ] key to select "Timer".
Press [ ].

2. Use [ ] or [ ] key to select "Clock" and press [ ].

3. Use [ ] or [ ] key to select "Format" and press [ ].

4. Press [ ] or [ ] to select 12 or 24 hours and press [ ].

22 MENU SETTINGS

Vibrate Alert Setting

Vibrate alert is only available on the Parent Unit. You can
turn on/off the vibrate alert through the menu.

1. Press [Menu], and use[
The display is shown below:

Vibrate

2. Press [ ], "Vibrate On?" or "Vibrate Off?" is shown on
the display.

3. Press [ ] to confi rm.

] or [ ] key to select "Vibrate".

Problem Possible cause(s)

The red Power lights do not light on when you plug in.

The green Link light on the Parent Unit is fl ashing and
cannot hear the sounds from your baby's room.

23TROUBLESHOOTING

1. Check if the units are properly connected to the power
supply.

2. Check if the power is turned on. If not, Press [
on the power.

1. You may have moved out of range −move closer to the
Baby Unit and wait 5 seconds for the Link to establish.

2. You may need to re−establish the Link between the two
units. Turn both units off by pressing and holding the
[ ] and then turn on again by pressing the [ ].

] to turn

Can't hear your baby on the Parent Unit but the Link light
is still glowing steadily.

The Red Power light is fl ashing on the Parent Unit.

A high pitched ear piercing noise can be heard from the
units (feedback).

Talk back feature is not working Check that the volume is loud enough at the baby unit.

Check if the volume is turned up on the Parent Unit.

Check if the rechargeable batteries are running low. Place
the Parent Unit on the Charger Pod to recharge them.

Check if the Parent and Baby Units are too close together.
Move them further apart.

24 PRODUCT SPECIFICATIONS

Feature Specifi cations

Operating Frequency 1.8 GHz

Up to 300 m under optimum conditions. The range is

Range

reduced in buildings (up to 50 m) as a result of walls, doors
etc.

Power supply (Baby Unit/Parent Unit)

Non rechargeable batteries, baby unit

(not included in the package contents)

Transmitting power Average: 10 mW Maximum: 250 mW

Re-chargeable batteries (Parent Unit) Type: AA, 1.2 V, 1300 mAh NiMH

Operating time with charged battery Approx. 12 hours

Input: 100-240 V

Output: 7.5 VDC, 500 mA,

Type: AA, 1.5 V Alkaline

50-60 Hz

AC

Warranty (Australia)

25GUARANTEE

(a) Warranty Oricom International Pty Ltd (Oricom) warrants that

the product is free from defects in materials and workmanship
for a period of 12 months effective from the date of purchase.
This warranty in no way affects your statutory warranty under
the Trade Practices Act 1974 or any other similar legislation. It
is important that you read the Warranty Card as it contains full
and additional details of the warranty, limitation of warranty
and conditions for receiving the warranty services during the
warranty period. The Warranty Card is located in the package.

(b) Exclusion and limitation of liability. Oricom will not be in

breach of a warranty or condition expressly stated in this User
Guide or the Warranty Card or implied by the Trade Practices
Act and excludes any liability arising under any statutory or
common law for damages or any other remedy if the damage
occurs as a result of:

(i) Failure by you to follow the instructions in the User Guide

for the installation and proper functioning of the product;
(ii) Negligence on your part or misuse by you of the product;
(iii) Any un-controlled external cause to the product not

functioning including but not limited to electricity failure,

lighting, over voltage;
(iv) Non adherence by you to the warnings in the User Guide

and the User Guide generally; and
(v) Modification to the product or services carried out to the

product by anyone other than Oricom or on Oricom's

behalf.

Oricom will not be liable for consequential losses including loss of
profits arising from a cause of action in contract, tort or any other
statutory or common law (except where a statute or any law prohibits
this exclusion). The warranty does not extend to damage caused by
misuse, negligence, excessive voltage or lightning. This warranty in
no way affects your statutory rights. Full details of the warranty are
contained in the enclosed warranty card.

Customer Support

If you feel this product is not working correctly please consult
the user guide and ensure that you are using the product in
accordance with the instructions.

To order spare parts additional parent units, replacement parts
and in case of any technical issues you may have with this
product please consult our website for further information or send
us an email for a prompt response to your enquiry.

In the unlikely event of a fault developing, please contact us
for assistance. If the product is then found to be faulty you will
be asked to return it directly to us with a copy of the purchase
receipt.

Australia

Oricom International Pty Ltd
Locked Bag 658
South Windsor, NSW 2756

Customer Support

Email: [e-mail]
Web: www.oricom.com.au
Phone: [phone]
Fax: [phone]
