OPL 9712
Barcode Data Collector
Specifications Manual
All information subject to change without notice.
Document History
Opticon
OPL 9712
Specifications Manual
Model Number:
Edition:
Date:
OPL 9712
1
2007-02-05
Specification Number:
Original Spec Number:
SS06071
SS06050
Copyright 2007 Opticon. All rights reserved.
This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic or
machine readable form without prior written consent of Opticon.
Limited Warranty and Disclaimers
PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE PRODUCT.
Serial Number
A serial number appears on all Opticon products. This official registration number is directly related to the device
purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.
Warranty
Unless otherwise agreed in a written contract, all Opticon products are warranted against defects in materials and
workmanship for two years after purchase. Opticon will repair or, at its option, replace products that are defective in
materials or workmanship with proper use during the warranty period. Opticon is not liable for damages caused by
modifications made by a customer. In such cases, standard repair charges will apply. If a product is returned under
warranty and no defect is found, standard repair charges will apply. Opticon assumes no liability for any direct, indirect,
consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Opticon
has been informed about the possibility of such damages.
Packaging
The packing materials are recyclable. We recommend that you save all packing material to use should you need to
transport your data collector or send it for service. Damage caused by improper packaging during shipment is not covered
by the warranty.
Trademarks
Trademarks used are the property of their respective owners.
Opticon Inc. and Opticon Sensors Europe B.V. are wholly owned subsidiaries of OPTOELECTRONICS Co., Ltd., 5-3,
Tsukagoshi 5-chome, Warabi-shi, Saitama, Japan 335-0002. TEL +81-(0) 48-446-1183; FAX +81-(0) 48-446-1180
SUPPORT
USA Europe
Phone: 800-636-0090
Email: support@opticonusa.com Email: support@opticon.com
Web: www.opticonusa.com Web: www.opticon.com
2
Opticon
OPL 9712
Specifications Manual
Contents
1. Abstract....................................................................................................................................5
2. Overview...................................................................................................................................5
3. Physical Features....................................................................................................................6
3.1. Dimensions ......................................................................................................................6
3.2. Weight ..............................................................................................................................6
4. Environmental Specifications ................................................................................................7
4.1. Operating Temperature and Humidity..............................................................................7
4.2. Storage Temperature and Humidity .................................................................................7
4.3. Ambient Light Immunity....................................................................................................7
5. Electrical Specifications .........................................................................................................8
6. Functionality ............................................................................................................................8
7. Optical Specifications.............................................................................................................8
8. Technical Specifications.........................................................................................................9
8.1. Print Contrast Signal (PCS) .............................................................................................9
8.2. Scan Area and Resolution ...............................................................................................9
8.3. Pitch, Skew, and Tilt.......................................................................................................11
8.3.1. Pitch Angle..............................................................................................................................11
8.3.2. Skew Angle and Dead Zone ...................................................................................................12
8.3.3. Tilt Angle .................................................................................................................................13
8.4. Curvature .......................................................................................................................14
9. Interface Specifications ........................................................................................................15
9.1. Bluetooth Specifications.................................................................................................15
9.2. Frequency ......................................................................................................................16
9.3. Infrared Transmission (IrDA)..........................................................................................16
9.3.1. Specifications..........................................................................................................................16
9.3.2. Transmission speed ...............................................................................................................16
10. Default Settings.....................................................................................................................17
10.1. Default Settings 1: Readable Codes ..............................................................................17
11. Serial Number........................................................................................................................19
12. FCC Labels.............................................................................................................................20
13. Packaging Specifications.....................................................................................................21
13.1. Individual Packaging Specification .................................................................................21
13.2. Labeling..........................................................................................................................22
14. Durability................................................................................................................................23
14.1. Shock .............................................................................................................................23
3
Opticon
OPL 9712
Specifications Manual
14.2. Vibration Strength ..........................................................................................................23
14.3. Dust and Drip Proof........................................................................................................23
15. Reliability................................................................................................................................23
16. Regulatory Compliance ........................................................................................................24
16.1. Laser Safety ...................................................................................................................24
16.2. Product Safety................................................................................................................24
16.3. EMC ...............................................................................................................................24
16.4. R&TTE ...........................................................................................................................25
16.4.1. Export Regulations .................................................................................................................25
16.5. RoHS..............................................................................................................................25
16.6. State of California: Perchlorate Best Management Practices ........................................25
17. Safety......................................................................................................................................26
17.1. Shock .............................................................................................................................26
17.2. Temperature Conditions.................................................................................................26
17.3. Foreign Materials ...........................................................................................................26
17.4. Other ..............................................................................................................................26
18. Mechanical Drawing..............................................................................................................27
Table of Figures
Figure 1: Reading a barcode. ......................................................................................................6
Figure 2: Ambient Light Immunity ................................................................................................7
Figure 3: The depth of field ..........................................................................................................9
Figure 4: Pitch............................................................................................................................11
Figure 5: Skew and dead zone ..................................................................................................12
Figure 6: Tilt angle .....................................................................................................................13
Figure 7: Curvature ....................................................................................................................14
Figure 8: Serial number diagram ...............................................................................................19
Figure 9: FCC label....................................................................................................................20
Figure 10: Individual packaging .................................................................................................21
Figure 11: Labels .......................................................................................................................22
Figure 12: Shock test .................................................................................................................23
Figure 13: Mechanical drawing ..................................................................................................27
4
Specifications Manual
1. Abstract
This manual provides specifications for the OPL 9712 barcode data collector (hereafter
referred to as “data collector”).
2. Overview
This scanner uses laser technology. To start a scan, press the trigger switch. Do not allow the
scanner to directly touch the surface of a barcode when scanning.
Operating the scanner via a trigger switch enables low-power operation and longer battery life.
Supported symbologies:
Linear (1D) 2D
JAN/UPC/EAN (WPC), incl. add-on MicroPDF417*
Chinese Post PDF417*
Codabar/NW-7
Code 11
Code 39
Code 93
Code 128: EAN-128
Composite Codes*: UCC/EAN-128 (incl. CC-A/B/C)
IATA
Industrial 2of5
Interleaved 2of5
ISBN-ISSN
Korean Postal Authority Code
Matrix 2of5
MSI/Plessey – UK/Plessey
RSS (all, incl. CC-A/B*); RSS-14/RSS-Limited/ RSS-Expanded
S-Code
Telepen
Tri-Optic
Opticon
OPL 9712
* Require use of an external library.
Using the built-in clock function, you can add a time stamp to the scanned data.
The scanner uses rechargeable lithium-ion batteries, which can be charged by setting the
scanner on its cradle (part number CRD 9722).
To transmit data between this product and a PC, use Bluetooth. Alternatively the cradle
dedicated to this product (part number CRD-9723-RS232C) can be used.
5
Opticon
OPL 9712
Specifications Manual
Applications can be developed for this product using the Software Development Kit (SDK).
Software can be developed in the C programming language. These development tools are
available as accessories.
Figure 1: Reading a barcode.
3. Physical Features
3.1. Dimensions
W 129 mm x D 44 mm x H 22.3 mm
3.2. Weight
105 grams (with lithium-ion batteries installed).
6
4. Environmental Specifications
4.1. Operating Temperature and Humidity
Temperature: 0 to 40° C
Humidity: 20 to 85%
4.2. Storage Temperature and Humidity
Temperature: -20 to +60° C
Humidity: 20 to 90%
4.3. Ambient Light Immunity
Decoding performance is guaranteed when the range of illumination on a barcode
surface is between zero and the following values:
Incandescent light 3,000 lx
Fluorescent light 3,000 lx
Sunlight 50,000 lx
Opticon
OPL 9712
Specifications Manual
Figure 2: Ambient Light
Immunity
Conditions
Barcode Sample: OPTOELECTRONICS Test Sample
PCS: 0.9
Resolution: 0.25 mm
Symbology: 8-digit Code 39
Quiet Zone: 10 mm
N/W Ratio: 1:2.5
Direct light or specular reflection light from a source should be prevented from entering
the acceptance area.
7
5. Electrical Specifications
Item Specifications Remarks
Main battery 600 mAh lithium-ion battery
Main battery life Rechargeable: 300 times
Backup battery 3.4 mAh lithium-ion battery
1 mA or less At standby Current consumption
150 mA or less When operating
Usable time
Data hold time 72 hours or more After main battery discharged
24 hours or more 1 scan/5s
50 hours or more 1 scan/5s
6. Functionality
Opticon
OPL 9712
Specifications Manual
Without backlight, with Bluetooth communication
Without backlight, no communication
Item Specifications Remarks
Control section
External memory
Display section
Clock section Real time clock
MPU 16-bit CISC CPU
Clock frequency 14.74 MHz
Flash ROM 512 KB For BIOS/AP
SRAM 512 KB For WORK/DATA
LCD Semi-transparent dot matrix LCD
DPI 112 x 64 dpi
Backlight Installed
Functions
7. Optical Specifications
Parameter Specification Unit
Light-emitting element Red laser diode -
Emission wavelength 650 ±10 (25° C) nm
Light output 1.0 or less mW
Scanning method Bi-directional vibration mirror -
Scanning speed 100 ±20 scans/s
Resolution 0.15 or more mm
Clock time, battery power, failure notification,
function settings
Counts year, month, date, hour, minute of the
current time and corresponding to leap years
Scan angle: 54 ±5 ° Scan angle
Read angle: 44 (Min) °
Manufactured by
Toshiba
8
Specifications Manual
8. Technical Specifications
The conditions for technical specifications are as follows, unless otherwise specified in each
section.
Conditions
Ambient temperature and humidity Room temperature (5–35° C) and room humidity
(45% RH–85% RH)
Ambient light 500 to 900 lx
Background Barcode = black
Space = white
Margin = white
Background of label = black
8.1. Print Contrast Signal (PCS)
0.45 or higher (over 70% of reflectivity of space and quiet zone).
PCS is determined by: Reflectance of white bar – Reflectance of black bar / Reflectance
of white bar
Opticon
OPL 9712
8.2. Scan Area and Resolution
The depth of field is measured from the edge of the data collector. The scanning range is
within the circular arc centered on the scan origin.
35
40
60
365
240
145
Reso lu t ion 0 .25
75
DEF
MNO
3
6
WXYZ
9
ﾟ
4
4
52
Minimum read ing d is tan ce
Reso lu t ion 0 .15
CLR
JKL
TUV
ABC
2
8
5
BS
GHI
PQRS
1
4
7
Shi f t
ENT
-
0.
*...
Reso lu t ion 0 .5
Reso lu t ion 1 .0
Figure 3: The depth of field
The depth of field is measured from the front edge of the data collector.
9
Opticon
OPL 9712
Specifications Manual
The scanning range follows a rectilinear path and expands in the shape of an arc while
centering (focusing) on a distant virtual reference point.
PCS Resolution (mm) Decode Depth (mm)
0.9 1.0 60–300
0.5 35–210
0.25 35–120
0.15 35–70
Resolution Symbology PCS Digit
1.0 mm Code 39 0.9 1
0.5 mm Code 39 0.9 3
0.25 mm Code 39 0.9 8
0.15 mm Code 39 0.9 10
Conditions
Scan angle 54° (reading range is 44°)
Detect angle 40°
Barcode sample Resolution 0.25 mm: OPTOELECTRONICS test sample. Code 39,
9 digits
Distance Within 90 mm from the minimum scannable distance
Note: dirt or scratches on the mask will degrade scanning performance. Always handle
the data collector carefully.
Barcode Sample: OPTOELECTRONICS Test Sample
N/W Ratio: 1:2.5
Angle: α = 0°, β = 15°, γ = 0°
Curvature: R = ∞
10
8.3. Pitch, Skew, and Tilt
8.3.1. Pitch Angle
Scanning performance is guaranteed at α±25°.
Opticon
OPL 9712
Specifications Manual
Figure 4: Pitch
11
8.3.2. Skew Angle and Dead Zone
Skew angle: β = ±50° (Excluding dead zone)
Dead zone: β = ±8° (There are some areas in which decoding fails due to
specular reflection)
(Depth of field: Within 90 mm from the minimum scannable distance).
Opticon
OPL 9712
Specifications Manual
Figure 5: Skew and dead zone
12
8.3.3. Tilt Angle
Scanning performance is guaranteed when γ = ±20°
°
0
2
=
γ
0°
2
=
γ
Opticon
OPL 9712
Specifications Manual
Figure 6: Tilt angle
Conditions
Barcode Sample: OPTOELECTRONICS Test Sample
Distance: 90 mm from the edge of the data collector
Label:
Angle: Curvature: R = ∞, Skew Angle = β +15° (for measuring Pitch Angle and Tilt Angle)
Pitch, Skew Angle
PCS = 0.9, Resolution = 0.25 mm, Symbology = 9-digit Code 39,
Quiet Zone = 10 mm, N/W Ratio = 1:2.5
Dead Zone, Tilt Angle
PCS = 0.9, Resolution = 0.26 mm, Symbology = 13-digit JAN, Quiet Zone = 10 mm
13
Specifications Manual
8.4. Curvature
With 8-digit JAN/UPC/EAN barcodes, decoding performance is guaranteed when
R≥15 mm.
With 13-digit JAN/UPC/EAN barcodes, decoding performance is guaranteed when
R≥20 mm.
Opticon
OPL 9712
Figure 7: Curvature
Conditions
Barcode Sample: OPTOELECTRONICS Test Sample
PCS = 0.9, Resolution = 0.26 mm, Quiet Zone = 10 mm
Distance: 90 mm from the edge of the data collector
Angle: Skew Angle β = +15°
The scanning range will vary according to the depth of field.
14
9. Interface Specifications
9.1. Bluetooth Specifications
Bluetooth® is a registered trademark owned by its proprietor and used by
OPTOELECTRONICS Co., Ltd. under license.
Feature Description
Version 1) 2.0
Supported protocol stack 1) RF (Radio Frequency Protocol)
Supported profile 1) SPP (Serial Port Profile)
Opticon
OPL 9712
Specifications Manual
BB (Base Band Protocol)
LM (Link Manager Protocol)
L2CAP (Logical Link Control and Adaptation Protocol)
SDP (Service Discovery Protocol)
RFCOMM (serial port emulation)
DUN (Dial-up Network Profile)
Communication configuration 2) 1 to 1 – one OPL 9712 to one host system
(Do not connect multiple scanners to one host system.)
Scanner operating mode while
connected to the host system
Security mode Authentication enabled: These settings can be configured using menu
Encryption Encryption is linked to the authentication setting and cannot be
Communication range 3) Approximately 10 meters
Frequency 2400 MHz to 2483.5 MHz
Transmission power 2.5mW (4dBm) or less
Comm. range 10 m
Baud rate 115.2 kbps
Antenna 1/4λ (surface mounted)
Master or Slave mode
barcodes.
enabled or disabled separately.
Notes
1. The OPL 9712 complies with Bluetooth standards. The device that communicates
with the OPL 9712 must support the same SPP. For other Bluetooth devices with
other profiles we cannot guarantee a connection before the products have been
tested.
2. The communication speed and range of the OPL 9712 may vary due to obstacles
and radio wave conditions between the OPL 9712 and the device to which the
OPL 9712 is connected. Conditions on the host device may also affect the
communication speed and communication range of the OPL 9712.
3. The prospective distance may vary based on environmental characteristics. Also
note the following frequency description.
15
Specifications Manual
9.2. Frequency
Bluetooth devices use the 2.4 GHz frequency band.
Scientific, medical, and industrial devices, including microwaves, wireless security
(camera) systems and WLAN use the same frequency band as this scanner. Other radio
stations also use this frequency for mobile object identification, including local private
radio stations that require a license (for example, manufacturing lines at factories),
specific power-saving radio stations requiring no license, and amateur radio stations.
Interference from other devices may affect the communication speed or communication
range of this scanner or vice versa.
9.3. Infrared Transmission (IrDA)
9.3.1. Specifications
Thee CRD-9723 cradle enable the OPL 9712 to perform infrared transmission of
data with IrDA Ver1.2 low power specification.
Opticon
OPL 9712
9.3.2.
Transmission speed
Default transmission speed is set at 115.2 kbps. However, you can easily change
the transmission rate to 57.6 kbps, 38.4 kbps, 19.2 kbps, 4.8 kbps, or 2.4 kbps.
16
10. Default Settings
10.1. Default Settings 1: Readable Codes
Opticon
OPL 9712
Specifications Manual
Symbology Read Transmit
Code
Transmit
CD
Length
UPC-A
UPC-A Add-on X X
UPC-E
UPC-E Add-on X X
EAN-13
EAN-13 Add-on X X
EAN-8
EAN-8 Add-on X X
Chinese Post X X
Codabar / NW-7
Code 11 X X X
X
X
X
X
X
Calculate
CD
X
X
Set
Prefix
—
—
—
—
—
—
—
—
—
—
—
Set
Other
Suffix
CR
CR
CR
CR
CR
CR
CR
CR
CR
CR Not transmit
ST/SP
CR
Code 39
Code 93
Code 128
EAN-128 X X X
IATA
Industrial2of5
Interleaved2of5
Korean Postal Code
(Code 3of5)
Matrix2of5 X X
MicroPDF417 X X
PDF417 X X
MSI/Plessey
UK/Plessey
X X X
X
X X
X X
X
X
X
X CD1 CD1
X
— — —
— — —
X
X
X
X
X
—
—
—
—
—
—
—
—
—
—
—
CR Not transmit
ST/SP
CR
CR
CR
CR
CR
CR
CR
CR
CR
CR
CR
CR
17
Opticon
OPL 9712
Specifications Manual
Symbology Read Transmit
Code
Transmit
CD
Length
RSS-14 X X
RSS-limited X X
RSS-expanded X X
S-Code
Telepen
Trioptic
X
X X
X
— — —
Notes:
• In the “Reading” column, “
” means “Enable reading” and “X” means “Disable
reading.”
• In the “Transmit code length” column, “
means “Do not transmit code length.”
• In the “Transmit CD” column, “
” means “Transmit check digit” and “X” means
“Do not transmit check digit.”
Calculate
CD
X
” means “Transmit code length” and “X”
Set
Prefix
—
—
—
—
—
Set
Other
Suffix
CR
CR
CR
CR
CR
CR Not transmit
ST/SP
• In the “Calculate CD” column, “
” means “Calculate check digit” and “X” means
“Do not calculate check digit.”
• “— “ means “not supported.”
• In the “Prefix” column, “—“ means “there is no prefix setting.”
18
Specifications Manual
11. Serial Number
The serial number shown on the right is written on silver matte with black paper affixed to the
backside of the OPL 9712.
Opticon
OPL 9712
Figure 8: Serial number diagram
19
Specifications Manual
12. FCC Labels
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Opticon
OPL 9712
Figure 9: FCC label
20
13. Packaging Specifications
13.1. Individual Packaging Specification
Place the OPL 9712 in a protection bag E, and pack it in the provided box. Then place
the accessories into the box.
Accessories:
• 1 lithium-ion battery
• 1 hand strap
Close the box and affix a label to the side of the box.
Size of the package (after assembly: 245 (W) x 112 (D) x 39 (H) mm
Opticon
OPL 9712
Specifications Manual
Figure 10: Individual packaging
21
13.2. Labeling
Opticon
OPL 9712
Specifications Manual
Figure 11: Labels
When packing 50 pre-packaged data collectors, select a box size equal to 560 mm (W)
by 490 mm (D) by 195 mm (H).
Note: The “RO” mark labeled on the package tray or package box guarantees that the
applicable product has passed our test of RoHS restrictions compliance (the restriction of
the use of certain hazardous substances in electrical and electronic equipment, 2002/95
EC). However, this document does not have any legal weight in the European Union.
22
14. Durability
14.1. Shock
There was no damage to the data collector structure or data collector operation after
dropping the data collector from a height of 1.5 meters onto a concrete floor. Each side
of the data collector impacted the floor three times.
Opticon
OPL 9712
Specifications Manual
Figure 12: Shock test
14.2. Vibration Strength
No malfunction occurred after the following vibration test.
Vibration test: Increase the frequency of the vibration from 12Hz to 100Hz with
accelerated velocity 19.6m/s2 (2G) for 6 minutes in non-operating state. Repeat this
routine 10 times in each of X, Y, Z direction for a total of 180 minutes.
14.3. Dust and Drip Proof
IP 54
15. Reliability
MTBF (Mean Time Between Failures) of this product, except for the laser diode and the mirror
motor scan unit, is 8 years.
MTBF of the laser scan engine (includes the life cycle of the laser diode and mirror motor) is
10,000 hours.
Keypad operating life: The keypad expected usability is 1,000,000 uses (cycles) when the key
is pressed with 1 kgf force.
The estimate of MTBF is based on standard operation of the product within the recommended
temperature range and without extreme electronic or mechanical shock.
23
16. Regulatory Compliance
16.1. Laser Safety
The data collector emits laser beams.
• JIS C6802: 2005: Laser class 1
• IEC60825-1: Laser class 1
• CDRH Laser class I. Complies with 21 CFR 1040.10 and 1040.11 except for
deviations pursuant to laser notice No. 50 dated June 24, 2007.
Class 1 laser devices are not considered to be hazardous when used for their intended
purpose. Avoid staring into the laser beam.
16.2. Product Safety
EN60950-1: 2001
IEC60950-1: 2001
Opticon
OPL 9712
Specifications Manual
16.3. EMC
EN55022
EN55024
VCCI Class B: This is a Class B product, to be used in a domestic environment based on
the Technical Requirement of the Voluntary Control Council for Interference from
Information Technology Equipment (VCCI). If this is used near a radio or television
receiver in a domestic environment, it may cause radio interference. Please install and
use the equipment according to the instruction manual.
FCC Part 15 Subpart B Class B
FCC Part 15 Subpart B Class C: This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC ID: UFOOPL9712
24
Specifications Manual
16.4. R&TTE
This scanner conforms to the following standards of the Radio and Telecommunications
Terminal Equipment (R&TTE) directive from the EU.
EN300 328
EN301 489-1
IEC60950-1
EN60950-1
The scanner qualifies as radio equipment for low-power radio stations (2.4 GHz band
advanced data communication systems) as specified in the Radio Law 38-24-1.
The scanner has obtained the Certification for Construction Design of Specified Radio
Equipment. It does not have a radio station license in Japan.
The following activities are prohibited under the Radio Law:
• Remodeling and disassembly
Opticon
OPL 9712
• Peeling off the certificate label
16.4.1.
Export Regulations
This product is subject to the strategically controlled exports regulated under
Foreign Exchange and Foreign Trade Laws. Export of this product may require
export permission from the Japanese government
16.5. RoHS
RoHS: The restriction of the use of certain hazardous substances in electrical and
electronic equipment, 2002/95 EC
16.6. State of California: Perchlorate Best Management Practices
The batteries on some Opticon products may contain Perchlorate. To comply with
California Perchlorate Best Practice Regulations and the Law for the Promotion of
Utilization of Recyclable Resources (Japan), products that may contain Perchlorate
materials should be properly labeled on the exterior of all outer shipping packages and/or
in locations that otherwise satisfy the California Perchlorate Best Management Practices.
25
17. Safety
Handle this product carefully. Do not deliberately subject it to any of the following.
17.1. Shock
• Do not throw or drop the data collector.
• Do not place heavy objects on the cables.
17.2. Temperature Conditions
• Do not use the data collector at temperatures outside the specified range.
• Do not pour boiling water on the data collector.
• Do not throw the data collector into the fire.
• Do not forcibly bend the cables at low temperatures.
17.3. Foreign Materials
• Do not immerse the data collector in liquids.
Opticon
OPL 9712
Specifications Manual
• Do not subject the data collector to chemicals.
17.4. Other
• Do not plug/unplug the connectors before disconnecting the power.
• Do not disassemble this product.
• Do not use the data collector near a radio or a TV receiver. It may cause reception
problems.
• The data collector may be damaged by voltage drops.
• The data collector may not perform properly in environments when placed near a
flickering light, such as a computer monitor, television, etc.
26
18. Mechanical Drawing
Opticon
OPL 9712
Specifications Manual
129
OP T ICON
44
20
22 .3
MNO
3
CLR
ABCDEF
2
BS
1
Sh i f t
ENT
6
WXYZ
9
-
JKL
TUV
8
5
0.
*...
GHI
PQRS
4
7
20 .4
Figure 13: Mechanical drawing
27
Loading...
