OPPO BDT-101CI User Manual

Page 1
USER MANUAL
READ CAREFULLY BEFORE OPERATION
Blu-ray Disc Player BDT-101CI
Page 2
IMPORTANT INFORMATION ...................................................... 1
Important Safety Instructions .................................................................................... 1
Precautions ................................................................................................................. 2
FCC Statement ............................................................................................................ 2
CE Statement .............................................................................................................. 2
Trademarks ................................................................................................................. 3
Compatible Disc Types ............................................................................................... 3
Discs that cannot be played ............................................................................................................. 4
Notes about BD-ROM compatibility ................................................................................................. 4
Disc care and handling .................................................................................................................... 4
Cinavia Notice ............................................................................................................. 4
Region management information ............................................................................... 4
Accessories ................................................................................................................. 5
INTRODUCTION ......................................................................... 6
Front Panel Controls ................................................................................................... 6
Front Panel Display Windows ..................................................................................... 6
Rear Panel Connectors ............................................................................................... 7
Remote Control ........................................................................................................... 8
Remote Control Buttons ................................................................................................................... 8
Back Side ......................................................................................................................................... 9
Battery Installation ........................................................................................................................... 9
Using the Remote Control ................................................................................................................ 9
Changing the Remote Code .......................................................................................................... 10
Changing the Backlight Method ..................................................................................................... 10
Installation ................................................................................................................ 11
Connecting to a TV via HDMI ........................................................................................................ 11
Connecting to an A/V Receiver via HDMI ...................................................................................... 12
BASIC OPERATIONS ................................................................ 13
Disc Playback ............................................................................................................ 13
OPTION Menu ............................................................................................................ 13
Fast Forward and Reverse ........................................................................................ 14
Pause and Frame-by-Frame ...................................................................................... 14
Slow Playback ........................................................................................................... 15
Blu-ray Disc Menu Navigation ................................................................................... 15
DVD Menu Navigation ............................................................................................... 15
On-Screen Display ..................................................................................................... 16
Volume Control .......................................................................................................... 17
Mute ........................................................................................................................... 17
i
Page 3
Audio Language/Track Selection.............................................................................. 17
Subtitle Selection ...................................................................................................... 18
BD-Live ....................................................................................................................... 18
ADVANCED OPERATIONS ....................................................... 19
Zooming and Aspect Ratio Control .......................................................................... 19
Zoom Levels for HDMI Output ....................................................................................................... 19
Subtitle Shift.............................................................................................................. 21
Repeat Playback ....................................................................................................... 21
Repeat a Selected Section ....................................................................................... 22
Shuffle and Random Playback .................................................................................. 22
Playback by Chapter or Track Number .................................................................... 22
Playback from a Specific Location .......................................................................... 23
DVD and Blu-ray Discs .................................................................................................................. 23
CD and SACD discs ....................................................................................................................... 24
Memory and Automatic Resume............................................................................... 25
Viewing Pictures on DVD-Audio Discs ..................................................................... 25
Pure Audio Mode ....................................................................................................... 25
MEDIA FILE PLAYBACK ........................................................... 27
Playback from a USB Flash Drive ............................................................................. 27
Playback from a Home Network ............................................................................... 28
HOME Menu ............................................................................................................... 29
Playing Music Files ................................................................................................... 29
Playing Movie Files ................................................................................................... 31
Viewing Photo Files .................................................................................................. 32
Adding Background Music ........................................................................................ 32
REFERENCES ........................................................................... 34
Useful Notes .............................................................................................................. 34
Troubleshooting ........................................................................................................ 34
Specifications ........................................................................................................... 36
User Manual Updates Online .................................................................................... 36
Language Code List .................................................................................................. 37
ii
Page 4
IMPORT ANT INFORMA TION
CAUTION:
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
accompanying the appliance.
presence of uninsulated “dangerous voltage” within
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and maintenance (servicing) instruction in the literature
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES SHALL BE PLACED ON THE APPARATUS.
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.
This label is located on the laser protective housing inside the product.
CLASS I LASER
PRODUCT
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched, particularly at plug, receptacle, and the point
where it exits from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
1
Page 5
IMPORTANT INFORMATION
Precautions
Before connecting the AC power cord to the appliance,
make sure the voltage designation of the appliance corresponds to the local electrical supply. If you are unsure of your power supply, contact your local power company. The acceptable power input range is AC ~ 100V-240V, 50/60Hz.
The apparatus with CLASS I construction shall be
connected to a MAINS socket outlet with a protective earthing connection.
The player is still receiving power from the AC power
source as long as it is connected to the wall outlet, even if the player itself has been turned off.
Unplug the power cord if you are not going to use the
product for an extended period of time. Hold the power plug when unplugging. Do not pull on the cord.
The main plug is used as the mechanism for cutting off
power, therefore make sure it is easy to unplug.
For BDT-101CI sold in the U.S.:
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
To ensure proper ventilation around this product, do not
place this product on a sofa, bed or rug. When installing this product on a wall or bookshelf, you need to provide appropriate space: we recommend leaving 4 inches (10 cm) of free space at the top, the sides and the rear.
High temperature will lead to abnormal operation of this
unit. Do not expose this unit or batteries to direct sunlight or near other heating objects.
When moving the player from a cold location to a warm
one, or vice versa, moisture may condense on the laser pickup unit inside the player. Should this occur, the player may not operate properly. In such a case please turn the unit on for 1-2 hours (without a disc) to facilitate moisture evaporation.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
For BDT-101CI sold in Europe:
CE mark
This product compiles with European Low Voltage (2006/95/EC), Electromagnetic Compatibility (2004/108/EC) and Environmentally-fr iendly design of Energy-relate d Products (2009/125/EC) Directives when used and installed according to this instruction manual.
WEEE symbol
Correct Disposal of This Product. (Waste Electrical & Electronic Equipment) Applicable in the European Union and other European countries with separate collection systems. This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.remote handset) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of household waste and recycle them responsibly to promote the sustainable reuse of material resources. Users should contact either the retailer where they purchased this product, or OPPO Digital UK Ltd, for details of where and how they can arrange for environmentally safe recycling.
2
Page 6
IMPORTANT INFORMATION
Trademarks
“Blu-ray Disc”, “Blu-ray 3D”, “BONUSVIEW” and “BD-
Live” are trademarks of Blu-ray Disc Association.
Java and all Java-based trademarks and logos are
trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.
DVD Logo is a trademark of DVD Format/Logo Licensing
Corp., registered in the U.S., Japan and other countries.
Super Audio CD, SACD and the SACD logo are joint
trademarks of Sony Corporation and Philips Electronics N.V. Direct Stream Digital (DSD) is a trademark of Sony Corporation.
“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
Designed for Windows Media, Microsoft, HDCD, and the
HDCD logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
“480p/720p/1080i/1080p” up-converting arrow logo,
“Source Direct” and “True 24p” logos are trademarks of OPPO Digital, Inc.
Compatible Disc Types
Logo Features Manual Icon
“VRS ClearView” and “Video Reference Series” are
trademarks of Silicon Image, Inc.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing Limited. DTS, the Symbol, DTS in combination with the Symbol, the DTS-HD logo, and DTS-HD Master Audio are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing LLC.
“Cinavia” is trademark of Verance Corporation.  All other trademarks are the properties of their
respective owners.
AUDIO
BD: Supports Blu-ray with Bonus View and BD-Live content, including Blu-ray 3D discs. A 3D-capable display with compatible glasses is required for 3D playback. BD-R/RE, both single- and dual-layer are also supported.
DVD: Plays commercially-released DVDs, as well as finalized DVD±R/RW.
DVD-A: High-resolution stereo or multi-channel audio. Some DVD-Audio discs
also contain a DVD-Video portion.
SACD: High-resolution stereo or multi-channel audio. Note: some SACDs use a hybrid format with both a CD and a high resolution DSD layer.
CD: Supports standard Red Book CDs, as well as HDCD and CD-R/RW.
AVCHD: High-definition digital video camera format, often in the form of a
DVD±R or flash memory.
DVD-A
SACD
3
Page 7
IMPORTANT INFORMATION
Discs that cannot be played
Ultra HD (UHD) Blu-ray  BDs with cartridge  DVD-RAMs  HD-DVDs  Data portion of CD-Extras  DVDs / Blu-Rays with a region code not matching the
player’s region code
Some Dual-Discs: A Dual-Disc is a two-sided disc with
DVD-video on one side and digital audio on the other side. The digital audio side does not meet the technical specifications of the Red Book CD format so playback is not guaranteed.
Audio discs with copy-protection may not be playable.
Notes about BD-ROM compatibility
Since the Blu-ray Disc specifications are new and evolving, some discs may not play properly depending on the disc type, version and encoding. It is possible that a Blu-ray Disc manufactured after the player uses new features of the Blu-ray Disc specifications. To ensure the best possible viewing experience, the player may need a firmware or software update from time to time. Please visit OPPO Digital’s web site (US: www.oppodigital.com, UK: www.oppodigital.co.uk) to check if updates are available.
Disc care and handling
To keep the disc clean from scratches or fingerprints,
handle the disc by its edge. Do not touch the recorded surface.
Blu-ray Discs record data in very high density and the
recorded layer is very close to the disc surface. For this reason, Blu-ray Discs are more sensitive to dust and fingerprints than DVD. Should you encounter playback problems and see dirty spots on the disc surface, clean the disc with a cleaning cloth. Wipe the disc from the center out along the radial direction. Do not wipe the disc in a circular motion.
Do not use record cleaning sprays or solvents such as
benzene, thinner and anti-static spray.
Do not attach labels or stickers to discs as this may
cause the disc to warp or become too thick, resulting in playback issues and a potentially stuck disc.
Avoid exposing the discs to direct sunlight or heat
sources.
Do not use the following discs:
o Discs with exposed adhesive from removed stickers
or labels. The disc may get stuck inside the player.
o Warped or cracked discs. o Irregularly shaped discs, such as heart or business
card shapes.
Cinavia Notice
This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be disp layed and playback or copy ing will be interrupted.
More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www .cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing add ress to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA.
Region management information
This player is designed and manufactured to respond to the region management information. If the region number of a BD-Video or DVD disc does not correspond to the region number of this player, this player cannot play the disc.
For BDT-101CI sold in the U.S.: BD-Video: Blu-Ray Discs with marks containing the region code A.
4
Page 8
IMPORTANT INFORMATION
DVD-Video: DVDs with marks containing the region code 1 and ALL.
For BDT-101CI sold in Europe: BD-Video: Blu-Ray Discs with marks containing the region code B.
DVD-Video: DVDs with marks containing the region code 2 and ALL.
Accessories
Please check that the following parts are included in your BDT-101CI package:
User Manual
Power Cable, about 4.5 feet
HDMI Cable, about 6 feet
Remote Control with AA Batteries
5
Page 9
INTRODUCTION
Front Panel Controls
1
2
3 5 76 84
1. POWER Button
2. POWER Status Indicator
3. USB Input
4. Front Panel Display Window
5. Disc Tray
6. IR Sensor Window
Front Panel Display Windows
1 2 6 7 8 954 10 11 13 15 163 1412
1. Mute Icon – Indicates that the audio is muted
2. Disc Type Indication – Indicates the currently playing disc type
3. Audio Channel Indication – Indicates whether the audio being played is 2ch stereo or multi-channel surround
4. Track – When illuminated, the displayed time applies to a track
5. Title – When illuminated, the displayed time applies to a title
6. Group – When illuminated, the displayed time appli es to a group
7. Chapter – When illuminated, the displayed time applies to a chapter
8. Total – When illuminated, the displayed time applies to the total play time
7. OPEN/CLOSE Tray Button
8. Playback Control and Navigation Buttons
9. Remaining – When illuminated, the displayed time is the remaining play time
10. Main Display – Text messages and numeric display
11. Playback Status – Indicates playback status such as Play, Pause, Repeat, Repeat All, Random/Shuffle, and A-B Repeat
12. Angle Icon – Indicates that the scene contains additional camera angle(s) that can be selected
13. HDMI – Indicates that the HDMI output is active
14. Audio Type Indication – Indicates the type of audio tracks being played
15. Ethernet – Indicates that an active Ethernet cable is attached
16. Wireless – Indicates that the player is connected to a wireless network
6
Page 10
INTRODUCTION
Rear Panel Connectors
142
3
5 6 7 8
10
9
11
12 13
14
GND
15 16
1. Ethernet LAN Port
2. USB Input
3. USB Input
4. HDMI 1 Output
5. Diagnostic Video Output
6. Coaxial Digital Audio Output
7. Optical Digital Audio Output
8. RS-232C Serial Control Port
9. IR (Infrared) Sensor
10. IR Switch
11. Trigger Output 1
12. Trigger Output 2
13. Trigger Input
14. Ground
15. Stereo Audio Output
16. AC Power Inlet
The AC power inlet is the IEC60-320 C14 type. Only the inclu ded AC power cord or an ap proved power co rd with an IEC60-320 C14 type plug should be used.
Depending on the optional audio and video out put modules t hat your unit is eq uipped with, the actu al rear panel connectors may differ slightly from the above illustration.
7
Page 11
INTRODUCTION
Remote Control
Remote Control Buttons
1. POWER: Toggle power STANDBY and ON
2. PURE AUDIO: Turn off/on video
3. NUMBER Buttons: Enter numeric values
4. CLEAR: Clear numeric input
5. TOP MENU: Show BD top menu or DVD title menu
6. ARROW and ENTER Buttons: Navigate menu selection
7. OPTION: Brings up the context-related menu
8. COLOR Buttons: Function varies by content
9. PLAY: Start playback
10. STOP: Stop playback
11. REV: Fast reverse play
12. PREV: Skip to previous
13. AUDIO: Change audio language or channel
14. SUBTITLE: Change subtitle language
15. SETUP: Enter the player Setup Menu
16. A-B REPLAY: Repeat play the selected section
17. RESOLUTION: Switch output resolution
18. OPEN: Open/close the disc tray
19. MUTE: Mute audio
20. VOLUME +/-: Increase/Decrease volume
21. HOME: Go to Home Menu to select media source
22. PAGE UP/DOWN: Show the previous/next page
23. INFO: Show/hide the On-Screen Display
24. GOTO: Play from a specified location
25. POP-UP MENU: Show BD pop-up menu or DVD menu
26. RETURN: Return to the previous menu or mode
27. PAUSE: Pause playback
28. FWD: Fast forward play
29. NEXT: Skip to the next
30. DIMMER: Dim the front panel display
31. ZOOM: Zoom in/out and adjust aspect ratio
32. PIC: Quick access to the picture adjustment menu
33. REPEAT: Repeat play
34. LIGHT: Activate the back light for the remote control
NOTE
When a button is pressed but its function is invalid or unavailable at the moment, the TV screen displays a circle with a diagonal line:
8
Page 12
INTRODUCTION
Back Side
1
2
3
With Battery Cover Battery Cover Removed
Battery Installation
1. Index Finger Notch 1: When your index finger is placed at this notch while holding the remote control, your thumb is within easy reach of the navigation buttons (ARROW, ENTER, TOP MENU and POP-UP MENU).
2. Index Finger Notch 2: When your index finger is placed at this notch while holding the remote control, your thumb is within easy reach of the playback control buttons (STOP, PLAY, PAUSE, PREV, NEXT, REV, FWD).
3. Battery Cover: Remove to replace batteries or set remote code.
4
4. Batteries: Use 2 AA or LR6 batteries.
5. Remote Code Switch: Adjust the position of the switch to set the remote control to use the indicated remote code (see details on page 10).
5
1. Remove the battery compartment cover
2. Insert batteries
3. Replace the battery compartment cover
Using the Remote Control
When using the remote control, the front window of the remote co ntrol should be point ed to the infrared sensor on the front panel within an angle of ±30° and a range of about 26 ft.
9
Page 13
INTRODUCTION
Changing the Remote Code
The remote control contains three OPPO remote codes. The default is “Code 1”. If you hav e other OPPO products placed close to the BDT-101CI, they may inadvertently respond to the BDT-101CI remote control. To prevent this, you can select a different remote code.
To select a new remote code, open the battery com partment cov er of the remote co ntrol, and then use a b all point pen to flip the switch to one of the positions marke d as “1”, “2”, or “3”. Close the battery compartment cover. Make sure that the BDT-101CI play er is turned on and that the disc tray is ejected. Aim the remote control at the player. Press and hold the ENTER button for 5 seconds. The play er will start usin g the new remote code.
Battery Compartment
Remote Code Switch
Changing the Backlight Method
The remote control supports one of two backlight methods. By default, pressing the LIGHT button will turn on the backlight, and pressing any other button within 10 seconds will keep the backlight on. The alternative method will activate the backlight whenever any button is pressed; in this mode, the light will stay on for 10 seconds, and pressing any other button will keep the backlight on. To switch between these two backlight methods, press and hold the LIGHT button for 5 seconds.
CAUTION
Never drop the remote control or expose it to moisture.  Never expose the infrared remote sensor on the front panel to direct sunlight or other
strong light sources.
Remote may not operate consistently when batteries become low. Replace them if
operation deteriorates.
If the remote control will not be used for a long time, please remove the batteries.  Use the batteries correctly to avoid possible leakage and corrosion. Do not leave the
batteries exposed to direct sunlight or in a high temperature environment for a long period of time. Do not heat or expose to flame. Do not mix old and new batteries. Do not use batteries of different types at the same time. Do not attempt to recharge the batteries.
If battery leakage occurs, do not touch the liquid with bare hands. Wipe out any liquid
inside the battery compartment, and insert new batteries.
10
Page 14
INTRODUCTION
Installation
The BDT-101CI is normally sold and in stalled by Cust om Installation au dio/video dealers (hence the CI suffix in the model number). Your Custom Installation professi onal should h ave install ed and pre- configured you r OPPO Blu-ray player for optimized performance in your home theat er system. You may skip t his section of the user manual - all you need to do is to turn on the playe r and other com ponents in the home theater system, and enjoy pristine audio and video.
In case you are performing a self-installation, the follo wing two connection metho ds are the most co mmon ways of integrating the OPPO Blu-ray player into a hom e theater sy stem. Should your sy stem require additional connections, please refer to the BDT-101CI Installer Manual available from the BDT -101CI product support page on the OPPO Digital web site.
Connecting to a TV via HDMI
GND
If your TV has an HDMI input, you can use the included HDMI cable to connect the player directly
to the TV. This connection method delivers both video and audio in a pure digital format via a single cable. The HDMI output of the player allows for the highest possible video quality and audio resolution.
You may remove the HDMI cable and connect the DIAG (diagnostic) output to the TV through a
regular composite video cable (not included) when there is a problem with HDMI video. Only the Setup Menu will be visible on the TV when using this connection, so it is limited to troubleshooting purposes only.
NOTE
This connection method will output sound via the TV’s speakers. For optimal sound quality, it is recommended that audio be transferred from the BDT-101CI to an A/V receiver with connected speakers.
11
Page 15
INTRODUCTION
GND
Connecting to an A/V Receiver via HDMI
If you have an HDMI-capable receiver that can support HDMI audio, you can simply run an HDMI
cable from the player to your receiver and enable HDMI audio on the receiver (see your receiver’s owner’s manual for more information). The receiver usually has an HDMI output that you can connect to your TV to pass the video signal.
The HDMI output terminal on the rear panel of the BDT-101CI can be conne cted to your receiver.
NOTE
HDMI (High-Definition Multimedia Interface) is a single cable that can transport both audio and video from your player to your display. Be aware, however, that HDMI is an evolving standard, and there may be compatibility issues. A receiver that supports audio input over HDMI is required. Some receivers offer HDMI ports solely for video switching. If your receiver does not have audio input capability, please read the following sections regarding other connection method s.
In order to play multi-channel audio for all formats, the receiver must support HDMI v1.1 or later. For Blu-ray Discs, a receiver that supports HDMI v1.4 with decoding capability for Dolby TrueHD and DTS-HD Master Audio is preferred. Please check the specifications of your receiver to ensure that it meets these requirements.
12
Page 16
BASIC OPERA TIONS
Disc Playback
OPTION Menu
DVD-A
1 Press the POWER button to turn on the player. 2 Press the OPEN/CLOSE button to eject the disc tray. 3 Place the disc with the label side facing up and the
recorded side facing down.
4 Press the OPEN/CLOSE button again to retract the tray. 5 The player will read the disc information and begin
playback.
6 Depending on the content of the disc, a menu or
navigation screen may appear. Use the navigation ARROW and SELECT buttons to select the content to
play. 7 To stop playback, press the STOP button. 8 To turn off the player, press the POWER button.
DVD-A
SACD
SACD
The OPTION MENU selections may vary depending on content being played. A summary of the selections and their functionality is described as follows:
During Music File Playback:
Shuffle/Random: Activate Shuffle or Random mode. See details on page 22.  Repeat: Repeat the track or all tracks. See details on page 21.  Add to playlist: Add the highlighted music file to the Playlist. This function is only available when
accessing external USB storage.
Goto playlist: Access the music files added to the playlist.  Song Location: Return to the MUSIC interface and highlight the music file currently playing.  Program Play: Play the audio tracks in the preferred sequence (only available in CD playback).  Gapless Play: Enable Gapless Playback mode. This is an experimental feature and only supports
APE, WAV and FLAC files stored on external USB storage.
During Video Discs (DVD, BD) and Video File Playback:
Subtitle Adjustment: Set the subtitle display options.
o Color: Set subtitle text color (only available on external subtitle files).
1. During media file navigation and playback, press the OPTION button on the remote to open the OPTION MENU, which allows you to conveniently access various settings and playback features.
2. When the OPTION MENU is displayed, press the LEFT/RIGHT ARROW buttons on the remote to highlight a particular item, then press the ENTER button to confirm.
13
Page 17
BASIC OPERATIONS
o Outline color: Set the outline color for subtitle text (only available on external subtitle files). o Size: Set subtitle text size (only available on external subtitle file). o Position: Set subtitle display position. o Sync: Adjust the timing of the subtitles (only available on external subtitle files). o Defaults: Reset all subtitle options to their default values.
3D: Enable 2D->3D conversion or bring the 3D adjustment menu.  Zoom: Opens the image zoom level menu. See details on page 19.  Angle: Changes the viewing angle. Thi s fun ct i o n i s o nl y ava ilable when the DVD/BD is recorded with
multiple angles.
During Photo File Playback:
Zoom: Displays the image at different zoom levels.  Rotate – Left / Right / Mirror / Flip: Rotates the image on the screen.  3D: Enable 2D->3D conversion or open the 3D adjustment menu..
Fast F orward and Rev erse
DVD-A
SACD
You may fast forward or reverse during playback.
1. Pressing the FWD button on the remote control to start fast forwarding playback. Each press of the FWD button increases the playback speed in the following increments:
123 4 5
2. Pressing the REV button on the remote control starts fast reverse playback. Each press of the REV button reverses the playback speed in the following increments:
NOTE
Certain Blu-ray Discs utilizing BD-Java technology may have their own fast forwarding and reversing control. The actual speed varies by disc, and a progress scale may be displayed by the disc.
DVD-A
Pause and F rame-by-Frame
SACD
PLAY
PREV
PAU SE
NEXT
1. During playback, pressing the PAUSE button temporarily pauses the program. In this mode, a PAUSE icon will appear on the TV screen.
2. While a DVD or Blu-ray Disc is paused, pressing the PREV or NEXT button reverses or advances the video frame-by-frame.
3. Pressing the PLAY button resumes normal playback.
14
Page 18
BASIC OPERATIONS
Slow Playback
To play the video in slow-motion, follow these steps:
PLAY
REV
PAU SE
FWD
1. Press the PAUSE button on the remote control to pause playback.
2. Press the FWD button to select a forward slow playback speed. Each press of the FWD button increases the playback speed in the following increments:
1/16 1/8
1/41/2
3. Press the REV button to select a reverse slow playback speed. Each press of the REV button reverses the playback speed in the following increments:
1/16 1/8
1/41/2
4. To exit the slow playback mode, press the PLAY button.
NOTE
Certain Blu-ray Discs utilizing BD-Java technolo gy may not support slow playback.
Blu-ray Disc Menu Navigation
DVD Menu Na vigation
1. Blu-ray Discs usually contain a Top Menu and a Pop-up Menu. The Top Menu normally appears at the beginning of
playback, after the previews and copyright messages. The Pop-up Menu can be accessed during the movie without interrupting playback.
2. During playback, press the POP-UP MENU button to access the Pop-up Menu. Press the TOP MENU button to access the Top Menu.
3. Navigate the menu using the ARROW buttons, and then press the ENTER button to make a selection.
4. Some menus make use of the COLOR buttons. You can select menu functions by pressing the corresponding COLOR button on the remote control.
1. Some DVDs contain title menu or chapter menu functions.
2. During playback, press the TOP MENU button to return to the disc title menu. Press the POP-UP MENU button to display the chapter menu. Depending on the disc, one or both menus may not exist.
3. Navigate the menu using the ARROW buttons, and then press the ENTER button to make the selection.
4. Press the RETURN button to return to the previous menu. The return location varies by disc.
DVD-A
15
Page 19
BASIC OPERATIONS
INFO
On-Screen Display
DVD-A
1. During the playback of a DVD or Blu-ray Disc, press the
SACD
INFO button on the remote control to show its status information. For CDs and SACDs, the status information is shown automatically.
2. When the status information is shown, press the PAGE UP/DOWN buttons to scroll through several different display formats. The playback time information displayed on the front panel changes together with the on-screen display.
3. Press the INFO button again to hide the on-screen display. The playback time information display on the front panel will remain in the selected format.
The following display formats are available: DVD and Blu-ray Disc:
- Title elapsed time
- Title remaining time
- Chapter elapsed time
- Chapter remaining time
CD and SACD:
- Track elapsed time
- Track remaining time
- Disc elapsed time
- Disc remaining time
In addition to the playback time, the on-screen display may also contain the following information about the content currently playing:
Playback status: an icon indicating play, pause, and fast forward/reverse status.  Bit rate meter: an indication of the bit rate of the audio and video stream.  Current and total title numbers. (DVD and Blu-ray Discs)  Current and total chapter numbers of the current title. (DVD and Blu-ray Discs)  Current and total tracks. (CDs and SACDs)  Audio information: current and total available number of audio tracks, language, format, and
channels.
Subtitle information: current and total available number of subtitle tracks and language.  Video format information: encoding type, frame rate and original aspect ratio.  HDMI output information: connection status, video resolution, frame rate, color space, audio format
and channels.
16
Page 20
BASIC OPERATIONS
A
V olume Control
Mute
DVD-A
SACD
1. On the BDT-101CI, the volume control only affects the analog audio output. It does not apply to digital audio output (HDMI, Coaxial and Optical) either in raw bitstream format or in LPCM format.
2. The VOL +/- buttons on the player remote control are provided as an alternative way of controlling the audio volume. It is recommended that you use this control to make the audio volume from the player the same as from other sources, such as TV programs or a VCR.
Press the VOL – button to decrease the volume. Press the VOL + button to increase the volume.
DVD-A
SACD
1. Press the MUTE button on the remote control during content playback to turn off audio output. The TV screen displays a mute icon. The front panel MUTE indicator will also light up.
2. Press the MUTE button again to resume audio output.
NOTE
Check the MUTE status on the front panel display of the player when there is no audio output. You may also press the MUTE button to verify the MUTE status.
DVD-A
Audio Language/Track Selection
1. To select the audio language or track, press the AUDIO button on the remote control during playback.
UDIO
2. Repeat pressing the AUDIO button or use the UP/DOWN ARROW buttons to choose from all available language or
audio tracks.
NOTE
Availability of languages and audio channels varies by disc. Some DVD-Audio discs allow audio track selection with the AUDIO button, while others require the user to choose from the audio setup menu of the disc. When playing an SACD with both multi-channel and stereo contents, the AUDIO button can be used to switch between the two formats.
SACD
17
Page 21
BASIC OPERATIONS
Subtitle Selection
1. When playing a DVD, Blu-ray Disc or other video programs recorded with subtitles, press the SUBTITLE button on the
SUBTITLE
remote control to select the desired subtitle.
2. Repeatedly press the SUBTITLE button or use the UP/DOWN ARROW buttons to choose from all available subtitles.
3. To turn off subtitles, select Off from the list.
BD-Live
Some Blu-ray Disc titles are released with the BD-Live feature. BD-Live offers extra downloadable content and additional online inte ractive pro grams. BD-Live content vari es by disc and studio, and may include addition al subtitles, commenta ries, preview traile rs, games,
and online chat. A Broadband internet connecti on is required to enjoy BD-Live content. Depending on how the studios orga nize their BD -Live content, some Blu-ray Discs may sta rt downloading BD-
Live content when playback starts, have a BD-Live selection on the main menu, sh ow a prompt aski ng whether you would like to start downloading, or ask you to si gn up for a memb ership or account. Please fo llow the instructions that come with the disc to enjoy BD-Live contents.
Your Internet connection speed and the capacity of t he BD-Live content servers can all affect how fast BD­Live content is downloaded. If you encounter slow downloadin g or intermittent playback, ple ase play the disc without accessing the BD-Live features, or try again at a different time.
When you use the BD-Live feature, the player or disc I D and your IP (I nternet Protocol) ad dress may be se nt to the content provider via the Internet. Generally, no personal ly identifiable inform ation is sent. Ho wever technologies exist to match your IP address to a certain geographical area or service provider. Your Int ernet service provider also has the knowledge of who is u sing a particular IP address. If the BD-Live content provider requires you to log in using a membership or account, the content provider will have access to your membership or account information. Check with your Intern et service provider a nd the BD-Live cont ent providers for their privacy policy.
BD-Live network access can be turned off or re stricted. Please check with your Cu stom Installation professional for details.
18
Page 22
AD V ANCED OPERA TIONS
Zooming and Aspect Ratio Control
This feature zooms in and out of the displayed frame and also changes the aspect ratio (image width vs. height).
ZOOM
To change the zoom level, press the ZOOM button on the remote control. Each press of the ZOOM button will switch the zoom level in sequence.
Zoom Levels for HDMI Output
The available zoom levels depend on the TV Aspect Ratio setting in the Setup Menu and the encoded aspect ratio on the BD/DVD Disc:
1:1 (No zoom), Stretch/Compress, Full Screen, Under Scan, 1.2X, 1.3X, 1.5X, 2X, 1/2X
The zoom level is reset to 1:1 when the disc is ejected, or when the player is turned off. The following zoom levels may be useful for specific applications:
1) Playing 16:9 BD or DVD when TV Aspect Ratio is set to 16:9 Wide or 16:9 Wide/Auto Stretch – The image is vertically stretched 1.33 times. For movies with 2.35:1 aspect ratio, this zo om
level cuts off the black borders at the top and bottom of the image. Users of a projector with an anamorphic lens may find this mode helpful.
Original 2.35:1
Widescreen Movie
“Stretch” Zoom Projected through
an Anamorphic Lens
Full Screen – The image is stretched by 1.33 times for both vertic al and horizontal directions. For
movies with 2.35:1 aspect ratio, this zoom level cuts off the black borders at the top and bottom of the image while maintaining the correct aspect ratio. The left/right sides of the image are slightly cropped.
Original 2.35:1 Widescreen Movie “Full Screen” Zoom
2) Playing 4:3 BD or DVD when TV Aspect Ratio is set to 16:9 Wide
19
Page 23
ADVANCED OPERATIONS
1:1 - The image fills up the entire 16:9 screen but is horizontally stretched. Figures may look shorter
and wider than they should be.
Compress – The player maintains the correct 4:3 aspect ratio and adds borde rs to the left and right
sides of the image.
Full Screen – This zoom level maintains the correct aspect ratio but crops the top and bottom slightly
in order to fit the 4:3 image to the 16:9 screen.
1:1 “Compress” Zoom “Full Screen” Zoom
3) Playing 4:3 BD or DVD when TV Aspect Ratio is set to 16:9 Wide/Auto 1:1 – The player maintains the correct 4:3 aspect ratio and adds borders to the left and right sides of
the image.
Stretch – The image is horizontally stretched 1.33 times. This zoom level fills up the 16:9 scre en, but
figures may look shorter and wider than they should be.
Full Screen – This zoom level maintains the correct aspect ratio but crops the top and bottom slightly
in order to fit the 4:3 image to the 16:9 screen.
1:1 “Stretch” Zoom “Full Screen” Zoom
The “Under Scan” zoom level shrinks the image by 5%. This zoom level may be used to compen sate for TVs that over scan, so the viewer can see the entire image area with no cropping. All other zoom levels are indicated by their respective zoom ratio.
NOTE
Some early DVD titles (released from 1997 until early 2000’s) use a 4:3 non-anamorphic
widescreen aspect ratio. When played on a 16:9 display, the content is shown in a small window with black borders on all four sides. The top and bottom borders are encoded into the video. The left and right borders are added by the player to maintain the correct aspect ratio. For these types of discs, the Full Screen zoom mode can be used to eliminate the borders.
The ZOOM feature may not be available when certain DVD or Blu-ray Discs are played if the
disc’s author has chosen to disable ZOOM.
20
Page 24
ADVANCED OPERATIONS
Subtitle Shift
For customers using a 2.35:1 “Constant Image Height” video projection system, subtitles may get cut off because they are positioned outside of the active video area.
SUBTITLE
The Subtitle Shift feature can be used to shift subtitles up or down so they are displayed within the active video area.
To shift the display position of subtitles, please follow these steps:
1. When playing a DVD, Blu-ray Disc or other video programs recorded with subtitles, select the desired subtitle from the disc menu or by using the remote. (Refer to page 18 for more information.)
2. Press and hold the SUBTITLE button on the remote control until the Shift Subtitle Position prompt appears on the screen.
3. Wait until subtitle text is shown on the screen, and then use the UP/DOWN ARROW buttons to move the subtitle text to the desired position.
4. Press the ENTER button to set the subtitle display position.
Once the Subtitle Shift position is set, it is saved by the player in the Playback Setup > Subtitle Shift setup menu option. The setting will be applied to subtitles of all future DVD and Blu-ray Discs. You can also change the setup menu item directly.
Repeat Playbac k
DVD-A
SACD
To repeat a certain chapter, title, track or disc, press the REPEAT button on the remote control.
Each press of the REPEAT button changes the repeat mode using
REPEAT
the following sequence:
DVD and DVD-Audio:
Repeat Chapter Repeat Title Repeat OffRepeat All
Blu-ray Disc:
Repeat Chapter Repeat Title Repeat Off
CD and SACD:
Repeat One Repeat All Repeat Off
NOTE
Certain Blu-ray Discs may not allow for repeating.
21
Page 25
ADVANCED OPERATIONS
A
Repeat a Selected Section
To repeatedly play a specific section, please follow these steps:
DVD-A
SACD
1. During normal playback, press the AB REPLAY button on the remote at the desired beginning point (Point A) for the repeat play. The TV screen displays “A-”.
B REPLAY
2. When playback reaches the desired ending point (Point B) for the repeat play, press the AB REPLAY button again. The player now repeatedly plays back the specified section (A-B). The TV screen displays “A-B”.
3. Press the AB REPLAY button for the third time to resume normal playback.
NOTE
Not available for all disc formats or content. Certain Blu-ray Discs may not allow for repeating.  If pressing the AB REPLAY button twice within 1 second, video playback will be automatically
rewound 10 seconds.
Shuffle and Random Playback
SACD
When playing a CD or SACD, press the BLUE button on the remote control to activate the Shuffle and Random modes. Each press of t he BLUE button switches the playback mode in the following sequence:
Shuffle Random Normal
In normal playback mode, each track is played back in sequential order. As the name implies, the Random playback mode randomly selects a track to play. The Shuffle mode also plays back th e tracks in random order, but it ensures that each track is played only once.
Selecting the Shuffle or Random mode cancels any Repeat mode you may be using. Similarly, selecting a Repeat mode cancels any Shuffle or Random mode.
Playback by Chapter or Track Number
NUMBER
BUTTONS
During the playback of a disc, you can use the NUMBER buttons on the remote control to directly jump to a specified chapter or track
DVD-A
SACD
number. For example:
To select the seventh track, press the [7] button.
To select the 16th track, press [1] followed by [6] in quick
succession:
+
NOTE
22
Page 26
ADVANCED OPERATIONS
INFO
Certain DVD-Audio and Blu-ray Discs may not allow for direct chapter selection.
Playback from a Specific Location
DVD-A
SACD
DVD and Blu-ray Discs
1. Title time search. Searches for a specific time within the currently playing title. Press the GOTO button to bring up the on-screen display. The cursor will be positioned at the
Time Counter. Use the NUMBER or ARROW buttons to enter the hours, minutes and seconds for your specific search and press the ENTER button.
During the playback of a DVD or Blu-ray Disc, you may specify a location to start playback by entering the title, chapter or time directly. Press the GOTO button to bring up the on-screen display.
1 / 7 5 / 25 00:22:14 00:40:06
On top of the video screen, the on-screen display information has the following components (from left to right): Playing Status, Title, Chapter, Time Counter, Progress Indicator, and Total Time. After pressing the GOTO button for the first time, the cursor will be positioned at the Time Counter. This is the Time Search mode. Each subsequent press of the GOTO button will switch the search mode in the following sequence:
(Title or Chapter) Time Search Chapter Search
On-Screen Display
Title Search
2. Chapter time search. Searches for a specific time within the currently playing chapter. Press the INFO button to bring up the on-screen display. Use the PAGE UP or PAGE DOWN
button to switch the display to Chapter Time mode (note the icon placed on the left of the Time Counter changes from the Title icon to the Chapter icon). Press the GOTO button to position the cursor at the Time Counter, then use the NUMBER or ARROW buttons to enter the hours, minutes and seconds for your specified search and press the ENTER button.
3. Chapter search. Allows you to search for a particular chapter.
Repeatedly press the GOTO button until the cursor is positioned at the Chapter location. Use the
NUMBER or ARROW buttons to enter or select the chapter number and press the ENTER
button.
23
Page 27
ADVANCED OPERATIONS
4. Title search. Allows you to search for a particular title.
Repeatedly press the GOTO button until the cursor is positioned at the Title location. Use the
NUMBER or ARROW buttons to enter or select the title number an d press the ENTER button.
1 / 7 5 / 25 00:22:14 00:40:06
NOTE
Some discs may prohibit the search operation. You will not be able to select a search location,
or you may get an “invalid operation” icon after specifying a search location.
Some Blu-ray Discs feature their own search function. Follow the on-screen instructions to use
the search function provided by such discs.
CD and SACD discs
You may specify a point to start playback by entering the disc elapsed time, track elapsed time or track number directly. When playing CDs and SACDs, the on-screen display automatically shows on the TV screen:
1 / 8 00:08:16 00:12:33
The on-screen display has the following components (from left to right): Playing Status, Track Number, Time Counter, Progress Indicator, and Total Time.
To specify a playback location using one of the following search modes, press the GOTO button. Each press of the GOTO button switches the search mode in the following sequence:
(Track or Disc)Time Search Track Search
On-screen Display
1. Track time search. Searches for a specific time within the currently playing track.
Press the GOTO button to place the cursor on the track Time Counter. Use the NUMBER or
ARROW buttons to enter the hours, minutes and seconds for your specified sea rch and press the ENTER button.
1 / 8 00:12:3300:08:16
2. Disc time search. Navigates you to a particular timestamp.
While the on-screen display is shown, press the PAGE UP or PAGE DOWN button to switch the
Time Counter to Disc Time mode. Press the GOTO button to place the cursor at the Disc Time Counter. Use the NUMBER or ARROW buttons to enter the hours, minutes and seconds for your specified search and press the ENTER button.
3. Select a track. To navigate to a particular track: Repeatedly press the GOTO button until the cursor is placed on the Track Number position. Use
the NUMBER or ARROW buttons to enter or select the track number and pres s the ENTER button.
24
Page 28
ADVANCED OPERATIONS
Memory and Automatic Resume
DVD-A
SACD
1. The player automatically saves the current position when playback is interrupted. Operations such as STOP, OPEN, and POWER cause the player to save the current playing position.
2. This position is saved even after turning off the unit or changing the disc.
3. The next time a disc with a saved playing position is inserted, the player will resume playback from that point. If you wish to cancel the automatic resume and start playback from the beginning, you must press the STOP button when prompted.
4. The player can save the playback position for up to 5 discs. When the position from the sixth disc is saved, the oldest saved position is replaced.
NOTE
Some Blu-ray Discs do not support resuming and will always play from the beginning.
Viewing Pictures on DVD-Audio Discs
DVD-A
Some DVD-Audio discs contain static pict ures, such as photo s of the
PAG E UP/DOWN
band as well as album narration. When a DVD-Audio track i s playing, you may use the PAGE UP button to select the previous picture or the PAGE DOWN button to select the next picture.
NOTE
Availability of static pictures depends on the DVD-Audio disc.
Pure Audio Mode
You can enjoy higher quality audio by turning off the vid eo processing and output. The Pure Audio mode reduces any potential interference between the video and audio signals.
1. Press the PURE AUDIO button on the remote control to turn off video and enter Pure Audio mode. Video output will cease, the power light will dim and the front panel displays will turn off.
2. Press the PURE AUDIO button again to resume video and cancel Pure Audio mode.
DVD-A
SACD
NOTE
25
Page 29
ADVANCED OPERATIONS
Pure Audio mode is automatically canceled when the unit is switched off or when playback is
stopped.
Because HDMI carries audio together with video, the HDMI video signal cannot be completely
turned off. A black screen is transmitted instead to minimize any potential interference.
26
Page 30
MEDIA FILE PLA YB ACK
In addition to playing standard disc-based formats such as Blu-ray, DVD, CD and SACD, the BDT-101CI can play media files. You can enjoy digital music, movies and photos stored on a data disc (recordable CD, DVD or Blu-ray) or an external USB drive. Due to the variation of media, encoding software and techniques used, compatibility cannot be guaranteed for all user-created or downloaded content. Support for such content is on a best effort basis.
Playback from a USB Flash Drive
The BDT-101CI is equipped with three USB port s: one on the front pa nel and two on the back. Y ou may use any of the available USB ports to plug in a USB drive.
The USB ports are rated to provide a maximum of 5V, 1000mA power to the USB drive. It is sufficient for USB thumb drives and flash memory card readers, but may not be suffi cient for USB hard disks. It i s recommended to check with your drive manufacturer for powe r requirement s, or use an external power supply.
NOTE
This unit supports “USB Mass Storage Class Bulk-Only Transport” devices only. Most USB
thumbs drives, portable hard disk drives and card readers conform to this device class. Other USB devices such as MP3 players, digital cameras, and mobile phones may not be compatible.
Supported USB drives can be formatted with the FAT (File Allocation Table), FAT32 or NTFS
(New Technology File System) file system.
In some cases, an incompatible USB device may cause the player to stop responding. If this
occurs, simply turn off the power, remove the USB device, and turn the player back on.
In order to minimize the risk of data corruption, it is recommended that you only unplug the
USB device when playback is completely stopped.
27
Page 31
MEDIA FILE PLAYBACK
Playback from a Home Network
The BDT-101CI can remotely play back music, photo, an d video files st ored on computers or NAS (Network Attached Storage) devices that are connected to the same home network. The computer or NAS need to run server software that supports media sharing protocols such as DLNA, SMB/CIFS or NFS. To play media files shared on your home net work, press the HO ME button on the rem ote to bring the Home Menu, select the Network icon and press the ENTER button to show the list of available servers.
The BDT-101CI player can play media files on the hom e network in on e of the following thre e ways:
As a digital media player (DMP): the player can actively search, access and pull content from
local media servers which supports DLNA.
As a digital media renderer (DMR): the player plays content received (“pushed”) from a digital
media controller (DMC). A DMC-capable media server is required. Refer to the server’s respective user instructions for correct configuration and operation.
As a SMB/CIFS/NFS client: the player can directly access files shared through SMB/CIFS/NFS
servers over the network, as if accessing an external USB hard drive. Most computers, especially those installed with Windows, already support SMB clients. Please refer to respective OS instructions to set up the SMB/CIFS/NFS shared file/folder.
NOTE
NAS is a networked appliance that provides file-based data storage services to other devices
on the network. Commercial products are available on the market.
SMB (Server Message Block) or CIFS (Common Internet File System) is mostly known as
Microsoft Windows Network. It does not require an extra media server or perform any media format transcoding, which reduces the processing load and keeps the original content quality.
Compatibility with local network sharing hardware/software is on a best effort basis with no
guarantee, due variations in NAS devices, media servers and their configurations. OPPO Digital does not offer technical support via email or phone for this feature. The OPPO Wiki located at wiki.oppodigital.com can be a useful resource to learn about this feature
28
Page 32
MEDIA FILE PLAYBACK
HOME Menu
The BDT-101CI presents a Home Menu to assist you in navigating and playi ng media files from a n inserted optical disc, USB flash drive, external hard drive, home network sh aring. Basically, the Home Menu is the starting point for accessing media files.
You can bring up the Home Menu with the HOME button on the remote control. Currently there are six selections:
Disc enables the player to start playback of an inserted optical disc.  Music, Movie and Photo allow you to access corresponding type of media files from a
connected USB drive and inserted data disc.
Network enables the player to stream audio, video and photos from media servers on the home
network. Capable hardware and software may be required.
Setup brings the player’s Setup Menu, just like pressing the SETUP button on the remote. The
Setup Menu is explained in detail in the BDT-101CI Installer Manual. OPPO Digital does not recommend end users to change the settings pre-configured by your Custom Installation professional.
Playing Music Files
To play digital music files stored on an opti cal disc or USB drive, select Music from the Home Menu. A file browser will appear to assist you in navigating the files and folders.
The first step is to select the Data Disc or USB device that contains the music files. The player will take a moment to read the media and list the folders and music files.
29
Page 33
MEDIA FILE PLAYBACK
In the music browser, you can perform the following operations:
Press the UP/DOWN ARROW or PAGE
UP/DOWN buttons to move the cursor and
select music files.
Press the OPTION button to access
features such as adding to a playlist and going to a playlist. Details can be found on page 13.
Press the TOP MENU button to move the cursor to the category menu in the top of the screen. This
menu contains the following choices:
o Source – Allows you to switch between different connected storage devices. o View – Allows you to switch between List View and Folder View modes. o Sort – Lists music files/folders by different categories, such as Song name, Artist, Album
and Genre.
When a music file is highlighted by the cursor, press the ENTER or PLAY button to start playback.
NOTE
When a data disc or USB drive is inserted, the player automatically starts to index files and
build a database in the background. Depending on the number and size of files, this process could take up to several minutes. Customers can only access the Category list (Artist, Album and Genre) when the database has been built, otherwise, a warning message will appear.
If a music file starts playing and there is no other user operation, the Now Playing screen will appear after a few seconds. You can also get to this screen by pressing the OPTION button and then selecting Now Playing. This screen provides the following information:
Shows playback status: Play, Stop, Pause, Track and Time.  Display and change playback mode: Shuffle/Random, Repeat One/All.  Music information: Displays information like album art and tags embedded in the original file.
The following operations are available while the Now Playing screen is shown:
Normal playback control: PLAY,
STOP, PAUSE, PREV/NEXT, REV, and FWD
Special playback modes: REPEAT
and Shuffle/Random (BLUE color button)
Press the OPTION button to access
the Option menu. (More details on page 13)
Return to the Browser without
stopping the music: RETURN
Stop playback and return to the
Browser: Press STOP.
30
Page 34
MEDIA FILE PLAYBACK
Playing Movie Files
To play movie files stored on an optical disc or USB drive, select Movie from the Home Menu. A file browser will appear to assist you in navigating through the files and folders.
The first step is to select the Data Disc or USB device that contains the movie files. The player will take a moment to read the media and list the folders and movie files.
In the movie browser, you can perform the following operations:
Press the UP/DOWN ARROW or PAGE
UP/DOWN buttons to move the cursor and
select movie files.
Press the TOP MENU button to move the
cursor to the category menu in the top of the screen. This menu functions the same as the one discussed in
Playing Music Files on page 30.
When a movie file is highlighted by the cursor, press the ENTER or PLAY buttons to start
playback.
Once a movie file starts playing, the normal playback control functions are available:
To stop the movie and return to the file browser, press the STOP button. You can also
press the HOME button at any time to stop the playback and return to the Home Menu.
Press the OPTION button to access features such as Subtitle Shift, 3D and Picture
Zooming. Details can be found on page 14.
31
Page 35
MEDIA FILE PLAYBACK
Viewing Photo Files
To view digital photo files stored on an optical disc or USB drive, select Photo from the Home Menu. A file browser will appear to assist you in navigate the fil es and folders.
The first step is to select the Data Disc or USB device that contains the photo files. The player will take a moment to read the media and list the folders and photo files.
In the photo browser, you can perform the following operations:
Press the UP/DOWN ARROW or PAGE
UP/DOWN buttons to move the cursor and select
photo files.
Press the TOP MENU button to move the cursor
to the category menu in the top of the screen.
When a photo file is highlighted by the cursor, press the ENTER or PLAY button to play
back the photos as a full screen slideshow.
The following operations are available during the photo slideshow:
Display the help screen: INFO Normal playback controls: PLAY, STOP, PAUSE, and PREV/NEXT  Adjust slideshow speed: REV and FWD  Zoom: ZOOM. Once zoomed in, the ARROW buttons can be used to pan around the photo. Reflect (flips the photo horizontally to make it upside-down): UP ARROW Mirror (flips the photo vertically to make it a mirror image): DOWN ARROW Rotate left (counterclockwise): LEFT ARROW Rotate right (clockwise): RIGHT ARROW  Repeat: REPEAT Switch between view modes: Red color button. Show EXIF information: GREEN color button Play in random sequence: BLUE color button Change slideshow transition effect: YELLOW color button.  Press the OPTION button to access to features like Image Zooming and Image Rotation.
Details can be found on page 14.
Adding Background Music
You can also add background music t o the photo sli deshow. To do so, you will need to prep are digital musi c files. The music files can be st ored on the same disk as the photos, or on a differe nt USB drive. Start music
32
Page 36
MEDIA FILE PLAYBACK
playback first by selecting Music from the Home Menu. Once the mu sic is playing, press th e HOME button to get back to the Home Menu, and start the photo slideshow by selecti ng Photo in the usual manner.
33
Page 37
REFERENCES
Useful Notes
In order to prolong the life of your player, it is recommended that you wait at least 30 seconds
before you power it on after switching it off.
Remove discs and turn the power off after operation.  Some functions of the player may not be applicable to certain discs.  Some discs with special features may not be fully supported by the player. This is not a
malfunction of the unit.
In the case of player malfunction, please turn it off, wait for 30 seconds and turn it back on. If
the problem still exists, please follow the troubleshooting instructions or contact an OPPO Digital service center.
Troubleshooting
Use this chart to resolve general operational problems. If there are any problems that you cannot resolve, please contact your OPPO Digital service center.
Symptom Possible Cause Solution
Mute is activated Press the MUTE button to cancel the mute. 17 Volume is too low Press the VOL + button to increase the volume to 100. 17
No audio
No picture
“No Disc” or “Unknown Disc” error
Remote control failure
Temporary function failure
SACD is played and the audio connection is coaxial or optical digital audio DVD-Audio is played and the audio connection is coaxial or optical digital audio Input selection is incorrect on the A/V receiver Audio cable is not properly connected TV input is not correctly selected “Pure Audio” mode engaged Press the PURE button to cancel this mode. 25 Video output format is not support by the TV Video cable is not properly connected No disc or incompatible disc loaded in player Dirty disc recording surface Eject the disc and clean any dirt or fingerprints. 4
Disc not properly loaded Condensation on the Laser
pick-up head Remote control is out of range Use the remote control within the effective range. 9 Low battery Replace the batteries. 9
Incorrect remote control code Scratched or damaged disc is
used Some functions are not available during playback
Interference from other devices
This is not supported due to copyright restrictions of SACD. Please use the analog or HDMI audio output.
This is not supported due to copyright restrictions of DVD-Audio. Please use the analog or HDMI audio output.
Select the input to which the player is connected. Check with your Custom Installation professional to
arrange repair service. Select the input to which the player is connected.
Press the RESOLUTION button multiple times until “AUTO” is displayed on the front panel Check with your Custom Installation professional to arrange repair service.
Eject disc and check. 13
Eject disc and make sure the label side is facing up and the record side is facing down. Turn on the player, eject the disc and leave the player on for about an hour.
Open the disc tray. Aim the remote at the player. Press and hold the ENTER button on the remote for 5 seconds to set the remote code.
Replace the disc. 13 Stop playback completely, then try again. 13
Identify interference by turning off other devices, and then relocate or replace the offending device
Reference Page
11-12
13 2
10
2
34
Page 38
REFERENCES
Some Setup Menu items are grayed out
“Connection Test” fails
“Network” shows no server
Some setup options cannot be changed while a disc is playing. Some setup options may be mutually exclusive with other setup options.
No internet connection. No network connection. Media
server not properly configured. Connected to wrong network.
Fully stop playback, eject the disc and try the Setup Menu again.
Verify that your router has a connection to the internet. Try power cycling the modem and router. Try a direct Ethernet connection if possible.
Consult your media server’s documentation to ensure proper configuration.
35
Page 39
REFERENCES
Specifications
Designs and specifications are subject to change without notice.
Disc Types* BD Profile BD-ROM Version 2.5 Profile 5 (also compatible with Profile 1 Version 1.0 and 1.1)
Output (Base Configuration)
BD-Video, Blu-ray 3D, DVD-Video, DVD-Audio, AVCHD, SACD, CD, HDCD, Kodak Picture CD, CD-R/RW, DVD±R/RW, DVD±R DL, BD-R/RE
Analog Audio: stereo. Coaxial/Optical Audio: up to 2ch/192kHz PCM, Dolby Digital, DTS. HDMI Audio: up to 7.1ch/192kHz PCM, up to 5.1ch DSD, Bitstream. HDMI Video: 480i/480p/576i/576p/720p/1080i/1080p/1080p24/UHD, 3D frame-packing 720p/1080p24.
Audio Characteristics**
General Specification
Operating Temperature
Operating Humidity
Frequency: 20Hz – 20kHz (±0.2dB), 20Hz – 96kHz (-3.5dB ~ +0.05dB) Signal-to-Noise Ratio: >105dB (A-weighted, Unmute) THD+N: < 0.0012% (1kHz at 0dBFS, 20kHz LPF)
Power Supply: ~100V – 240V, 50/60Hz AC Power Consumption: 40W (Standby: 0.5W in Energy Efficient Mode) Dimensions: 16.9 x 11.3 x 4.1 inches (430mm x 287mm x 105mm) Mass: 9.9 lbs (4.5kg)
41°F - 95°F 5°C - 35°C
15% - 75% No condensation
* Compatibility with user-encoded contents or user-creat ed discs is on a best effort basis with n o guarantee due to the variation of media, software and techni ques used.
**Nominal specification.
User Manual Updates Online
An updated version of the User Manual may be available online at the OPPO Digital web site (US:
www.oppodigital.com, UK: www.oppodigital.co.uk). To read or download the latest online User Manual,
please visit the product support page for the BDT-101CI model. Occasional updates are needed to reflect new features added to the player since the User Manual was
printed. As future firmware updates brings in new features and functions, the online version of the User Manual will be updated accordingly.
36
Page 40
REFERENCES
Language Code List
Code Language Name
6565 Afar 6566 Abkhazian 6570 Afrikaans 6577 Amharic 6582 Arabic 6583 Assamese 6588 Aymara 6590 Azerbaijani 6665 Bashkir 6669 Byelorussian 6671 Bulgarian 6672 Bihari 6678 Bengali, Bangla 6679 Tibetan 6682 Breton 6765 Catalan 6779 Corsican 6783 Czech 6789 Welsh 6865 Danish 6869 German 6890 Bhutani 6976 Greek 6978 English 6979 Esperanto 6983 Spanish 6984 Estonian 6985 Basque 7065 Persian 7073 Finnish 7074 Fi jian 7079 Faroese 7082 French 7089 Frisian 7165 Irish 7168 Scots Gaelic 7176 Galician 7178 Guarani 7185 Gujarati 7265 Hausa 7273 Hindi 7282 Croatian
Code Language Name
7285 Hungarian 7289 Armenian 7365 Interlingua 7378 Indonesian 7383 Icelandic 7384 Italian 7387 Hebrew 7465 Japanese 7473 Yiddish 7487 Javanese 7565 Georgian 7575 Kazakh 7576 Greenlandic 7577 Cambodian 7578 Kannada 7579 Korean 7583 Kashmiri 7585 Kurdish 7589 Kirghiz 7665 Latin 7678 Lingala 7679 Laothian 7684 Lithuanian 7686 Latvian,Lettish 7771 Malagasy 7773 Maori 7775 Macedonian 7776 Malayalam 7778 Mongolian 7779 Moldavian 7782 Marathi 7783 Malay 7784 Maltese 7789 Burmese 7865 Nauru 7869 Nepali 7876 Dutch 7879 Norwegian 7982 Oriya 8065 Panjabi 8076 Polish 8083 Pashto, Pushto
Code Language Name
8084 Portuguese 8185 Quechua 8277 Rhaeto-Romance 8279 Romanian 8285 Russian 8365 Sanskrit 8368 Sindhi 8372 Serbo-Croatian 8373 Singhalese 8375 Slovak 8376 Slovenian 8377 Samoan 8378 Shona 8379 Somali 8381 Albanian 8382 Serbian 8385 Sundanese 8386 Swedish 8387 Swahili 8465 Tamil 8469 Telugu 8471 Tajik 8472 Thai 8473 Tigrinya 8475 Turkmen 8476 Tagalog 8479 Tonga 8482 Turkish 8484 Tatar 8487 Twi 8575 Ukrainian 8582 Urdu 8590 Uzbek 8673 Vietnamese 8679 Volapuk 8779 Wolof 8872 Xhosa 8979 Yoruba 9072 Chinese 9085 Zulu
37
Page 41
51980838 V1.1
38
