Omron XPECTIA VISION SYSTEM BROCHURE

XPECTIA VISION SYSTEM

Inspection beyond expectation

»

Flexible platform concept

»

Intuitive user guidance

»

Close to the human eye

Performance in touch with simplicity

Features

• True colour system: 16 million colours

• High resolution cameras: 5 million pixels

• 2D and 3D inspections

Omron‘s Xpectia is defining a new class of vision

systems: real colour sensing, high resolution,

3D functionality and Intuitive User guidance

combined, provides you pure simplicity, no

matter how complex the inspection.

Like the human eye, Xpectia can identify any

object with any colour mix, at any distance and

any size. It features an easy-to-use touchscreen

and “Auto” functions, making vision

• Touch-screen for easy operation

• Industrial-PC platform

Benefits

• Zero defect: real colour increases the total stability

of the inspection

• Economic: simple set-up and maintenance saves time

• Fit for purpose: the right hardware for the application

• Flexible: customize functionality to your needs

• Future-proof: meeting your inspection needs today

and tomorrow

applications simple and straightforward.

Xpectia is available with a range of controllers

with and without the touchscreen, and supports

up to four cameras. By combining the benefits

of a compact system with the power and

flexibility of an industrial PC platform, it is, quite

simply, the best of both worlds.

HIGH RESOLUTION

3D INSPECTION

SIMPLICITY OF USE

REAL COLOUR

Vision performance and ease of use made compatible

High-end vision performance and simplicity are no longer

in contradiction. The powerful functions of Xpectia make all

vision applications simple and straightforward: from now on,

there is only one class of visual inspection. Because with

Xpectia, the complexity of is hidden from the user.

• No colour filtering: objects can be inspected whatever the

colour of the workpiece, using a single tool

• Simple automatic camera adjustment

• Intuitive touch-screen user interface for easy operation

• Simulation tool for testing, pre-configuration and offline

maintenance

Features that make the difference:

• Inspections boosted by real colour:

- Search

- Edge

- Area

- Defect

- OCR/OCV

• Create sequences and decision trees of inspections

• Customization: open and programmable

• Application-specific software packages

• Ethernet communication between PC and PLC using

TCP/IP or EthernetIP

• High-speed 80fps cameras

ECM Search

Edge position

Circle Angle

Character

Inspection

Trapezodial
Correction+

Defect Scan edge

Edge pitch

Gravity and Area

Date Verification

Halation Cut+

Fine matching Scan edge width

Set unit figure

Color Data

Shape Search+

Panorama+ Calibration+

position

Search Flexible Search

Classification

Barcode+

Labeling

2DCode+

Polar

Transformation

Real-colour sensing

Xpectia processes all 256 gradations of RGB colours, enabling

it to sense more than 16 million colours and detect minute

variations in the colour of objects. Without filtering or colour

pick-up Xpectia sees like a human eye.As a result, completely

stable measurements can now be made in conditions where

it used to be impossible:

• on surfaces which require different colour filtering

• in difficult lighting conditions

• on shiny objects

• where there is low contrast between the object and

the background

Inspections: correct position of coloured objects; minute defects
in objects presence, absence and positioning of printed images

Standard system: 256 colours Xpectia: 16.77 million colours

B

Light Dark

GR

Internal processing using the
binary image

Real-colour processing

Standard colour system:

Low contrast -> internal processing using a filtered monochrome image

The intelligent camera offers the flexibility
to change distance, size and light

• auto zoom

• auto lighting

• auto focus and iris

Xpectia:

High contrast -> stable inspections using real-colour sensing

High resolution

To ensure the quality of a workpiece, multiple details usually have to be inspected, requiring

the detection of:

• small and large characteristics at the same time

• small defects on large objects

Meeting these requirements with the same set-up is beyond standard-resolution cameras –

but well within the reach of Xpectia.

Precise inspection:

The compact and fast 2 and 5 MPixel camera (colour/monochrome) allows the inspection of:

• large objects (large field of view) with high accuracy

• small objects (small field of view) with ultra-high accuracy

3D quality inspection

Xpectia combines advanced 3D processing with a simple

calibration. 3D measurements can be made over large

distances (up to two metres). As a result, workpieces with

complex shapes that cannot be laid horizontally are easily

measured, using calculations based on stereo principles.

3D is easy to install and calibrate on Xpectia. At the same

time 2D and 3D inspections can be performed.

Hole positions and diameters Gaps and bumps

Detect gaps and bumps

Measure component orientation

Value added image processing: Panorama and HDR

The Xpectia high-grade model features outstanding measurement items to master challenging tasks.

Panorama: stitching (synthesizing) of images

Larger field of views can be achieved by integrating several

camera images into a single one.

Camera Image

The borders of each image are analyzed for unique

characteristics.

1Camera Image 2 Camera Image 3 HalationCamera Image 4 Underexposure

HDR: compensation of diverse lighting effects

High dynamic range (HDR) minimizes the effect of over- and

underexposure within the same image.

These characteristics are used to generate a seamless

single image.

The surface of the workpiece is accurately reproduced with

a sharp contrast.

1Xpectia

System configuration

Ordering information

FZ3 series

Item Descriptions Model Remarks

Controllers

High grade,
high speed
controllers

Controller integrated
with LCD

Two-camera controllers PNP/NPN FZ3-H705/FZ3-H700 With touch pen
Four-camera controllers PNP/NPN FZ3-H705-10/FZ3-H700-10

Box-type Controller Two-camera controllers PNP/NPN FZ3-H755/FZ3-H750 ---

Four-camera controllers PNP/NPN FZ3-H755-10/FZ3-H750-10

High grade
controllers

Controller integrated
with LCD

Two-camera controllers PNP/NPN FZ3-H305/FZ3-H300 With touch pen
Four-camera controllers PNP/NPN FZ3-H305-10/FZ3-H300-10

Box-type Controller Two-camera controllers PNP/NPN FZ3-H355/FZ3-H350 ---

Four-camera controllers PNP/NPN FZ3-H355-10/FZ3-H350-10

High speed
controllers

Controller integrated
with LCD

Two-camera controllers PNP/NPN FZ3-705/FZ3-700 With touch pen
Four-camera controllers PNP/NPN FZ3-705-10/FZ3-700-10

Box-type Controller Two-camera controllers PNP/NPN FZ3-755/FZ3-750 ---

Four-camera controllers PNP/NPN FZ3-755-10/FZ3-750-10

Standard con­trollers

Controller integrated
with LCD

Two-camera controllers PNP/NPN FZ3-305/FZ3-300 With touch pen
Four-camera controllers PNP/NPN FZ3-305-10/FZ3-300-10

Box-type Controller Two-camera controllers PNP/NPN FZ3-355/FZ3-350 ---

Four-camera controllers PNP/NPN FZ3-355-10/FZ3-350-10

Cameras

Intelligent
cameras

Wide field of vision Color FZ-SLC100 Camera + Zoom, Autofocus Lens + Intel-

ligent Lighting

Narrow field of vision Color FZ-SLC15

Autofocus
cameras

Wide field of vision Color FZ-SZC100 Camera + Zoom, Autofocus Lens
Narrow field of vision Color FZ-SZC15

Digital camer-as300,000 Pixels Monochrome FZ-S Lens required

Color FZ-SC

2 million pixels Monochrome FZ-S2M

Color FZ-SC2M

5 million pixels Monochrome FZ-S5M

Color FZ-SC5M

Small digital
cameras

300,000-pixel
flat type

Monochrome FZ-SF CCTV lens required
Color FZ-SFC

300,000-pixel
pen type

Monochrome FZ-SP
Color FZ-SPC

Controller integrated with LCD

Camera connecter

USB connection

USB connection

To uch pen (accessory attached)

RGB monitor

PLC

RS-232C connected

Parallel I/O

Ethernet

Analogue RGB

PC

Mouse

Mouse

Input device

Input device

Box-type Controller

Camera connected

USB connection

RGB monitor

PC

PLC

RS-232C connected

Parallel I/O

Ethernet

Analogue RGB

Input device

Mouse

8 Xpectia

2 Vision Sensor

Camera connection

FZD series

Cameras,

peripheral devices

Intelligent camera diffusion plate Wide field of vision FZ-SLC100-DL ---

Narrow field of vision FZ-SLC15-DL --­CCTV Lenses 3Z4S-LE Series --­Extension Tubes
Low-distortion Lenses FZ-LEH5/LEH8/LEH12/LEH16/LEH25/

LEH35/LEH50/LEH75/LEH100

Low distortion lens for 2-million pixel

cameras and 5 million-pixel cameras
Lenses for small camera FZ-LES3/LES6/LES16/LES30 Lens for 300,000-pixel small cameras
Extension Tubes for small camera FZ-LESR Extension Tubes for 300,000-pixel small

cameras

Cables

Camera Cable FZ-VS Cable length: 2 m, 5 m, or 10 m

*1

Bend resistant Camera Cables FZ-VSB Cable length: 2 m, 5 m, or 10 m

*2

Right-angle Camera Cable

*3

FZ-VSL Cable length: 2 m, 5 m, or 10 m

*1

Long-distance camera cable FZ-VS2 Cable length: 15 m

*4

Long-distance right-angle camera cable FZ-VSL2 Cable length: 15 m

*4

Cable extension unit FZ-VSJ Up to two Extension Units and three Ca-

bles can be connected.(Maximum cable

length: 45 m

*5

)
Monitor cable FZ-VM Cable length: 2 m or 5 m
Parallel cable FZ-VP Cable length: 2 m or 5 m

Peripheral
devices

LCD monitor FZ-M08 For Box-type Controllers
USB memory 1GB FZ-MEM1G Capacity: 1 GB
VESA attachment FZ-VESA For installing the LCD integrated-type

controller

Desktop controller stand FZ-DS For installing the LCD integrated-type

controller

Mouse --- Recommended Products (Optical

Mouse)

• Microsoft Corporation: Compact Optical

Mouse, U81 Series
External Lighting 3Z4S-LT Series --­Strobe Controller (for FZ Series Vision Sensors) Manufactured by MORITEX Corporation

3Z4S-LT MLEK-C100E1TS2

Required to control external lighting from

a Controller
Adapter for the strobe controller designed specifically for the 5 million-pixel camera Manufactured by MORITEX Corporation

3Z4S-LT LBK-003

Required to mount a strobe controller on

a 5 million-pixel camera

*1. The 10-m cable cannot be used for the intelligent camera, autofocus camera and 5 million-pixel camera.
*2. The 10-m cable cannot be used for the intelligent camera, autofocus camera 2 million-pixel camera and 5 million-pixel camera.
*3. This Cable has an L-shaped connector on the Camera end.
*4. The 15-m cable cannot be used for the intelligent camera, autofocus camera and 5 million-pixel camera.
*5. The maximum cable length depends on the Camera being connected, and the model and length of the Cable being used.For further information, please refer to

the "Ratings and Specifications" table in page 3.

Type of
camera

Model Resolution Standard controllers

(FZ3-3, FZ3-3-10)

High grade controllers
(FZ3-H3, FZ3-H3 -10)

High speed controllers
(FZ3-7, FZ3-7 -10)

High grade, high speed controllers
(FZ3-H7,FZ3-H7 -10)

Intelligent
cameras

FZ-SLC100 300,000 Pixels

OOO O

FZ-SLC15 300,000 Pixels

OOO O

Autofocus
cameras

FZ-SZC100 300,000 Pixels

OOO O

FZ-SZC15 300,000 Pixels

OOO O

Digital cam­eras

FZ-SC 300,000 Pixels

OOO O

FZ-S 300,000 Pixels

OOO O

FZ-SC2M 2 million pixels

XXO O

FZ-S2M 2 million pixels

XXO O

FZ-SC5M 5 million pixels

X XO

*1

*1. When connecting 5 million-pixel cameras, up to two cameras can be connected.

O

*1

FZ-S5M 5 million pixels

X XO

*1

O

*1

Small digital
cameras

FZ-SFC 300,000 Pixels

OOO O

FZ-SF 300,000 Pixels

OOO O

FZ-SPC 300,000 Pixels

OOO O

FZ-SP 300,000 Pixels

OOO O

Item Description Model Remarks

Controllers Controller integrated with LCD PNP/NPN FZD-505-10/FZD-500-10 –

Box-type Controller PNP/NPN FZD-555-10/FZD-550-10

Cameras 3D Vision Camera Color FZD-STC2M Integrated Camera (installation distance: 24 cm max.)

Digital Camera Monochrome FZ-S2M 2-million-pixels (lens required)

Color FZ-SC2M 2-million-pixels (lens required)

3D Camera Base Plate Short-distance Version FZD-CBS Installation distance of up to 30 cm

Medium-distance Version FZD-CBM Installation distance of 30 cm to 1 m

Long-distance Version FZD-CBL Installation distance of 1 m to 2 m

3D Calibration Tool FZD-CAL –

High-luminance
lighting

Line pattern FZD-LTW White LEDs

Custom pattern FZD-LTPW White LEDs

Item Descriptions Model Remarks

9Vision Sensor

3Xpectia

Ratings and Specifications

Controllers

Note: Do not install the firmware for FZ2 in any High Grade High Speed or High Grade controller of the FZ3 series. It will lead to the failure of the controller. For software

download, please contact your Omron representative.

Model NPN Output FZ3-700 FZ3-700-10 FZ3-H700 FZ3-H700-10 FZ3-750 FZ3-750-10 FZ3-H750 FZ3-H750-10

PNP Output FZ3-705 FZ3-705-10 FZ3-H705 FZ3-H705-10 FZ3-755 FZ3-755-10 FZ3-H755 FZ3-H755-10

Connected Camera Please refer to the "Camera connection" table in page 2.

No. of Cameras

*1

*1. When connecting 5 million-pixel cameras, up to two cameras can be connected.

24 2 4 24 2 4

Processing
resolution

When connected to a 300,000-pixel camera 640(H)×480(V)

When connected to a 2 million-pixel camera 1600(H)×1200(V)

When connected to a 5 million-pixel camera 2448(H)×2044(V)

No. of scenes 32

Number of
logged im­ages

*2

*2. The number of logged images will vary when connecting multiple Cameras with different models.

When connect­ed to a 300,000­pixel camera

Connected to 1 camera Color camera: 250, Monochrome Camera: 252

Connected to 2 cameras Color camera: 125, Monochrome Camera: 126

Connected to 3 cameras Color camera: 83, Monochrome Camera: 84

Connected to 4 cameras Color camera: 62, Monochrome Camera: 63

When connect­ed to a 2 million­pixel camera

Connected to 1 camera Color camera: 40, Monochrome Camera: 40

Connected to 2 cameras Color camera: 20, Monochrome Camera: 20

Connected to 3 cameras Color camera: 13, Monochrome Camera: 13

Connected to 4 cameras Color camera: 10, Monochrome Camera: 10

When connect­ed to a 5 million­pixel camera

Connected to 1 camera Color camera: 11, Monochrome Camera: 11

Connected to 2 cameras Color camera: 5, Monochrome Camera: 5

Codes that can be read with FZ3 < Bar Codes > JAN/EAN/UPC (including add-on codes), Code 39, Codabar (NW-7), ITF (Interleaved 2

of 5), Code 93, Code 128, GS1-128, GS1 DataBar (RSS-14 / RSS Limited / RSS Expanded)
< 2D Codes > Data Matrix (ECC200), QR Code

Operation Touch pen, mouse, etc. Mouse or similar device

Settings Create series of processing steps by editing the flowchart (Help messages provided).

Serial communications RS-232C/422A:1CH

Network communications Ethernet 100BASE-TX/10BASE-T

Parallel I/O 11 inputs (RESET, STEP, DSA, and DI 0 to 7), 26 outputs (RUN, BUSY, GATE, OR, READY, ERROR,

STGOUT 0 to 3, and DO 0 to 15)

Monitor interface Integrated Controller and LCD 12.1 inch TFT color

LCD (Resolution: XGA 1,024 × 768 dots)

Analog RGB video output, 1 channel
(Resolution: XGA 1,024 × 768 dots)

USB interface 4 channels (supports USB 1.1 and 2.0)

Power supply voltage 20.4 to 26.4 VDC

Current
consump­tion

*3

*3. When the strobe controller is connected to the lights, the controller uses power as much as it does when connected to the intelligent camera.

When connected to a intelligent or autofo­cus camera

5 A max. 7.5 A max. 5 A max. 7.5 A max. 5 A max. 7.5 A max. 5 A max. 7.5 A max.

When connected to a 300,000-pixel camera 3.7 A

max.

4.9 A max. 3.7 A max. 4.9 A max. 3.7 A
max.

4.9 A max. 3.7 A max. 4.9 A max.

When connected to a 2 million-pixel camera

When connected to a 5 million-pixel camera

Ambient temperature range Operating: 0 to 45°C, 0 to 50°C *4, Storage: 20 to 65°C (with no icing or condensation)

*4. The operating mode can be switched from the Controller Menu settings.

Ambient humidity range Operating and storage: 35% to 85% (with no condensation)

Weight Approx.

3.2 kg

Approx.

3.4 kg

Approx.

3.2 kg

Approx.

3.4 kg

Approx.

1.8 kg

Approx.

1.9 kg

Approx.

1.8 kg

Approx.

1.9 kg

Accessories Touch pen (one, inside the front panel), Please

Read First, Instruction Manual (Setup), 6 mounting
brackets

Please Read First, Instruction Manual (Setup)

10 Xpectia

4 Vision Sensor

Cameras

Intelligent camera, autofocus camera

Digital cameras

Small digital cameras

FZ-SLC100 FZ-SLC15 FZ-SZC100 FZ-SZC15

Image elements Interline transfer reading all pixels, 1/3-inch CCD image elements

Color/Monochrome Color

Effective pixels 640(H)×480(V)

Pixel size 7.4×7.4 µm

Shutter function Electronic shutter; select shutter speeds from 1/10 to 1/50,000 s

Partial function 12 to 480 lines

Frame rate (image
read time)

80 fps(12.5 ms)

Field of vision

*1

*1. The length of the visual field is the lengths along the Y axis.

13 to 100 mm

*2

*2. Tolerance: ±5% max.

2.9 to 14.9 mm

*2

13 to 100 mm

*2

2.9 to 14.9 mm

*2

Installation distance 70 to 190 mm

*2

35 to 55 mm

*2

77.5 to 197.5 mm

*2

47.5 to 67.5 mm

LED class*3 (lighting)

*3. Applicable standards: IEC 60825-1: 1993 + A1: 1997 + A2-2001, EN 60825-1: 1994 + A1: 2002 + A2: 2001

Class 2 ---

Ambient temperature
range

Operating: 0 to 50°C
Storage: 25 to 65°C (with no icing or condensation)

Ambient humidity
range

Operating and storage: 35% to 85% (with no condensation)

Weight Approx. 670 g Approx. 700 g Approx. 500 g

Accessories Instruction Sheet and hexagonal wrench

FZ-S FZ-SC FZ-S2M FZ-SC2M FZ-S5M

FZ-SC5M

Image elements Interline transfer reading all pixels,

1/3-inch CCD image elements

Interline transfer reading all pixels,
1/1.8-inch CCD image elements

Interline transfer reading all pixels,
2/3-inch CCD image elements

Color/Monochrome Monochrome Color Monochrome Color Monochrome

Color

Effective pixels 640(H)×480(V) 1600(H)×1200(V) 2448(H)×2044(V)

Pixel size 7.4×7.4 µm 4.4×4.4 µm 3.45×3.45 µm

Shutter function Electronic shutter;

select shutter speeds from 1/10 to 1/50,000 s

Electronic shutter;
select shutter speeds from 1/10 to 1/50,000 s

Electronic shutter;
select shutter speeds from 1/10 to 1/50,000 s

Partial function 12 to 480 lines 12 to 1200 lines 12 to 2044 lines

Frame rate (image
read time)

80 fps(12.5 ms) 30 fps(33.3 ms) 16 fps(62.5 ms)

Field of vision,
installation distance

Selecting a lens according to the field of vision and installation distance

Ambient temperature
range

Operating: 0 to 50°C
Storage: 25 to 65°C (with no icing or conden­sation)

Operating: 0 to 40°C
Storage: 25 to 65°C (with no icing or conden­sation)

Operating: 0 to 40°C
Storage: 25 to 65°C (with no icing or conden­sation)

Ambient humidity
range

Operating and storage: 35% to 85% (with no condensation)

Weight Approx.55 g Approx. 76 g Approx.140 g

Accessories Instruction manual

FZ-SF FZ-SFC FZ-SP FZ-SPC

Image elements Interline transfer reading all pixels, 1/3-inch CCD image elements

Color/Monochrome Monochrome Color Monochrome Color

Effective pixels 640(H)×480(V)

Pixel size 7.4×7.4 µm

Shutter function Electronic shutter; select shutter speeds from 1/10 to 1/50,000 s

Partial function 12 to 480 lines

Frame rate
(image read time)

80 fps(12.5 ms)

Field of vision, instal­lation distance

Selecting a lens according to the field of vision and installation distance

Ambient temperature
range

Operating: 0 to 50°C (camera amp)
0 to 45°C (camera head)
Storage: 25 to 65°C (with no icing or condensation)

Operating: 0 to 50°C (camera amp)
0 to 45°C (camera head)
Storage: 25 to 65°C (with no icing or condensation)

Ambient humidity
range

Operating and storage: 35% to 85% (with no condensation) Operating and storage: 35% to 85% (with no condensation)

Weight Approx.150 g Approx.150 g

Accessories Instruction manual, installation bracket, Four mounting brackets(M2) Instruction manual

11Vision Sensor

OMRON EUROPE B.V.

OMRON EUROPE B.V.

Wegalaan 67-69, NL-2132 JD, Hoofddorp, The Netherlands. Tel: [phone] Fax: [phone] www.industrial.omron.eu

Wegalaan 67-69, NL-2132 JD, Hoofddorp, The Netherlands. Tel: [phone] Fax: [phone] www.industrial.omron.eu

Austria

UNITED KINGDOM

Tel: [phone]

Omron Electronics Ltd

www.industrial.omron.at

Opal Drive, Fox Milne, Milton Keynes, MK15 0DG, UK
Tel: [phone]

Belgium

Fax: [phone]

Tel: [phone]

www.industrial.omron.co.uk

www.industrial.omron.be

Czech Republic

Tel: [phone]
www.industrial.omron.cz

Denmark

Tel: [phone]
www.industrial.omron.dk

Finland

Tel: [phone]
www.industrial.omron.fi

France

Tel: [phone]
www.industrial.omron.fr

Germany

Tel: [phone]
www.industrial.omron.de

Hungary

Tel: [phone]
www.industrial.omron.hu

Italy

Tel: [phone]
www.industrial.omron.it

Netherlands

Tel: [phone]
www.industrial.omron.nl

Norway

Tel: [phone]
www.industrial.omron.no

Poland

Tel: [phone]
www.industrial.omron.pl

Austria

Tel: [phone]
www.industrial.omron.at

Belgium

Tel: [phone]
www.industrial.omron.be

Czech Republic

Tel: [phone]
www.industrial.omron.cz

Denmark

Tel: [phone]
www.industrial.omron.dk

Finland

Tel: [phone]
www.industrial.omron.fi

France

Tel: [phone]
www.industrial.omron.fr

Germany

Tel: [phone]
www.industrial.omron.de

Portugal

Tel: [phone]
www.industrial.omron.pt

Russia

Tel: [phone]
www.industrial.omron.ru

South-Africa

Tel: [phone]
www.industrial.omron.co.za

Spain

Tel: [phone]
www.industrial.omron.es

Sweden

Tel: [phone]
www.industrial.omron.se

Switzerland

Tel: [phone]
www.industrial.omron.ch

Hungary

Tel: [phone]
www.industrial.omron.hu

Italy

Tel: [phone]
www.industrial.omron.it

Netherlands

Tel: [phone]
www.industrial.omron.nl

Norway

Tel: [phone]
www.industrial.omron.no

Poland

Tel: [phone]
www.industrial.omron.pl

Portugal

Tel: [phone]
www.industrial.omron.pt

Russia

Tel: [phone]
www.industrial.omron.ru

Turkey

South-Africa

Tel: [phone]

Tel: [phone]

www.industrial.omron.com.tr

www.industrial.omron.co.za

United Kingdom

Spain

Tel: [phone]

Tel: [phone]

www.industrial.omron.co.uk

www.industrial.omron.es

Sweden

Tel: [phone]
www.industrial.omron.se

Switzerland

Tel: [phone]
www.industrial.omron.ch

Turkey

Tel: [phone]
www.industrial.omron.com.tr

More Omron representatives

www.industrial.omron.eu

More Omron representatives

www.industrial.omron.eu

Authorised Distributor:

Authorised Distributor:

KPP_XPECTIA_01_EN_INT02

KPP_XPECTIA_01_EN02

Control Systems

Control Systems

• Programmable logic controllers • Human-machine interfaces • Remote I/O

• Programmable logic controllers • Human-machine interfaces • Remote I/O

Motion & Drives

Motion & Drives

• Motion controllers • Servo systems • Inverters

• Motion controllers • Servo systems • Inverters

Control Components

Control Components

• Temperature controllers • Power supplies • Timers • Counters • Programmable relays

• Temperature controllers • Power supplies • Timers • Counters • Programmable relays

• Digital panel indicators • Electromechanical relays • Monitoring products • Solid-state relays

• Digital panel indicators • Electromechanical relays • Monitoring products • Solid-state relays

• Limit switches • Pushbutton switches • Low voltage switch gear

• Limit switches • Pushbutton switches • Low voltage switch gear

Sensing & Safety

Sensing & Safety

• Photoelectric sensors • Inductive sensors • Capacitive & pressure sensors

• Photoelectric sensors • Inductive sensors • Capacitive & pressure sensors

• Cable connectors • Displacement & width-measuring sensors • Vision systems

• Cable connectors • Displacement & width-measuring sensors • Vision systems

• Safety networks • Safety sensors • Safety units/relay units • Safety door/guard lock switches

• Safety networks • Safety sensors • Safety units/relay units • Safety door/guard lock switches

Although we strive for perfection, Omron Europe BV and/or its subsidiary and affiliated companies do not warrant

Although we strive for perfection, Omron Europe BV and/or its subsidiary and affiliated companies do not warrant
or make any representations regarding the correctness or completeness of the information described in this document.

or make any representations regarding the correctness or completeness of the information described in this document.
We reserve the right to make any changes at any time without prior notice.

We reserve the right to make any changes at any time without prior notice.
