Omron S8BA-24D24D120LF, S8BA-24D24D240LF, S8BA-24D24D360LF, S8BA-24D24D480LF User Manual

Download

S8BA-24D24D120LF

S8BA-24D24D240LF S8BA-24D24D360LF/S8BA-24D24D480LF

Uninterruptible Power Supply (UPS)

S8BA-24D24D□□□LF

User's Manual

Introduction

Thank you for purchasing OMRON's Uninterruptible Power Supply (UPS).

This manual contains information that is necessary to use the “Uninterruptible Power Supply (UPS)”. Read this manual carefully and make sure that you understand the functionality and performance of the product before using it in your system.

Keep this manual in a safe place where it will be available for reference during operation.

Intended audience

This manual is intended for: Personnel with knowledge of electric systems (the level of knowledge an electrical engineer has or its equivalent) and at the same time

▪ Personnel in charge of introducing FA systems ▪ Personnel in charge of designing FA systems ▪ Personnel in charge of installing and connecting FA systems ▪ Personnel in charge of managing FA systems and facilities

Applicable products

This manual covers the following products:

▪ Uninterruptible Power Supply (UPS) S8BA Series

・S8BA-24D24D120LF ・S8BA-24D24D240LF ・S8BA-24D24D360LF ・S8BA-24D24D480LF

Important notice

▪ No part of this manual may be copied, reproduced, or used in any form without our permission. ▪ Note that the content of this manual such as the specifications is subject to change for

improvement without prior notice.

▪ We have checked the content of this manual and believe it to be accurate. However, if you find any

errors or have any questions, contact our sales personnel At that time, give the Man. No. (manual number) in the back of your manual.

Trademarks

▪ System names and product names indicated in this manual are registered trademarks or

trademarks of their respective owners.

S8BA-24D24D□□□LF

Procedure from installation to operation

Start

Read “Safety Precautions”

Page 8

Remove the product from the

package and check the contents

2. Preparation

Perform installation and connection

3. Installation and connection

Are you using either of the following functions?

- Automatic shutdown software

- I/O signal functions

6. To perform shutdown processing of the devices when a power failure occurs

7. Using the I/O signal functions

Check the operation

4. Check and start operation

Charge the battery*

Operate

4. Check and start operation

* The battery in the UPS has not been charged prior to shipment. Charge the battery when you use the UPS for the first time.

Perform maintenance and inspection

5. Maintenance and Inspection

Replace the battery

5.2 Replacing the battery

The battery must

be replaced

Installation/connection

Preparation for oper at ion

Operate

Perform maintenance

and inspection

Yes

Procedure from installation to operation

The procedure from installation to operation is shown below.

S8BA-24D24D□□□LF

Table of contents

Introduction .................................................................................................. 1

Procedure from installation to operation ...................................................... 2

Table of contents ......................................................................................... 3

Read and understand this manual ............................................................... 5

Safety precautions ....................................................................................... 8

Regulations and standards ........................................................................ 17

1 Overview of the product .................................................................... 19

1-1 Features of this product ................................................................................. 19

1-2 Specifications ................................................................................................. 20

2 Preparation ....................................................................................... 22

2-1 Unpacking the product ................................................................................... 22

2-2 Checking the contents ................................................................................... 22

2-3 Name of each part ......................................................................................... 24

2-4 Diagram of the Input/output circuit block ....................................................... 29

3 Installation and connection ................................................................ 30

3-1 Installation ...................................................................................................... 30

3-1-1 DIN rail installation ............................................................................................................ 34

3-1-2 Wall or floor mounting procedure ...................................................................................... 36

3-2 Connection ..................................................................................................... 40

3-2-1 Connecting a cable to the input terminal block and the output terminal block ................... 40

3-2-2 Connecting a device to the output terminal block .............................................................. 44

3-2-3 Connecting the input power supply to the input terminal block ......................................... 45

4 Check and start operation ................................................................. 46

4-1 The name and function for the operation and display ...................................... 46

4-1-1 Name of each part ............................................................................................................. 46

4-1-2 Switch ............................................................................................................................... 46

4-1-3 Beep sound ....................................................................................................................... 47

4-2 Start and stop procedures and basic operation ............................................. 48

4-2-1 Start and stop procedures ................................................................................................. 48

4-3 Interpreting beeps and displays ..................................................................... 58

S8BA-24D24D□□□LF

Table of contents

4-4 UPS operation mode settings ........................................................................ 61

4-4-1 Settable items and explanations ........................................................................................ 61

4-4-2 Settings ............................................................................................................................. 64

5 Maintenance and inspection .............................................................. 71

5-1 Checking the battery ...................................................................................... 71

5-1-1 Battery life expectancy ...................................................................................................... 71

5-1-2 Self-diagnosis test ............................................................................................................. 71

5-1-3 Estimated backup time ...................................................................................................... 72

5-2 Replacing the battery ..................................................................................... 74

5-2-1 Notification that the battery needs to be replaced ............................................................. 75

5-2-2 Procedure for replacing the battery ................................................................................... 76

5-3 Cleaning ......................................................................................................... 83

To perform shutdown processing of the devices when a power failure occurs

6-1 The outline on the UPS monitoring software ................................................. 84

6-1-1 What is the Simple Shutdown Software............................................................................. 84

.......... 84

6-1-2 How to connect.................................................................................................................. 84

7 Using the I/O signal functions ............................................................ 87

7-1 I/O signal functions ........................................................................................ 87

7-1-1 Type of output signals ....................................................................................................... 87

7-1-2 Type of input signals .......................................................................................................... 87

7-1-3 I/O signal port (RJ45 connector)........................................................................................ 88

7-1-4 Contact signal ratings ........................................................................................................ 88

7-1-5 Contact signal circuit ......................................................................................................... 88

7-1-6 Precautions and notes for the use of the I/O signal functions ........................................... 89

7-1-7 Example of the use of the Contact Signal circuit ............................................................... 89

8 Troubleshooting ................................................................................. 90

9 References ........................................................................................ 91

9-1 Dimensions .................................................................................................... 91

9-2 Characteristic data ......................................................................................... 94

S8BA-24D24D□□□LF

Read and understand this manual

Unless otherwise specially agreed upon regarding the “OMRON product”, the terms and conditions described in this chapter shall apply regardless of your place of purchase.

Definition

The definitions of terms in this chapter are as follows:

・ “OMRON products”: FA system devices, general-purpose controllers, sensing devices, and

electromechanical components of “OMRON”

・ “Catalogs and other documents”: Catalogs such as the OMRON Best Controllers and the

Electromechanical Components General Catalog, specifications, instruction manuals, and other catalogs and manuals related to “OMRON products”, including those provided in digital form

・ “Application conditions”: Conditions written in “catalogs and other documents” related to “OMRON

products” such as the usage conditions, ratings, performance, operating environment, operation instructions, notes on usage, and prohibitions

・ “Customer's usage”: Use of the “OMRON product” intended by the customer, including embedding

or using the “OMRON product” in a component, electronic substrate, device, facility, or system manufactured by the customer

・ “Suitability of use”: (a) Compliance; (b) operation; (c) non-infringement of third-party property

rights; (d) observance of laws and regulations; and (e) observance of standards regarding the “OMRON product” in the “customer's usage”

Notes on information contained in this manual

For information contained in “catalog and other documents”, note the following:

・ Rated values and performance values are values obtained by stand-alone tests under specific

conditions. They do not guarantee values that are obtained under complex conditions.

・ Supplementary data is provided as reference, not guaranteeing that the unit always operates

correctly within the range of such data.

・ Usage examples are described as reference. “OMRON” shall not guarantee the “suitability” related

to them.

・ For improvements and other reasons, “OMRON” may discontinue the production of “OMRON

products” or change the specifications for “OMRON products”.

S8BA-24D24D□□□LF

Read and understand this manual

Notes when using the product

To adopt and use the product, note the following:

・ Use the unit according to the “application conditions” such as ratings and performance. ・ Confirm the “suitability” on your own to determine whether the “OMRON product” can be used for

your purpose. “OMRON” shall not be responsible for the “suitability of use” of any kind.

・ Be sure to confirm on your own in advance that the “OMRON product” is provided with electrical

power and installed properly for the intended use in your entire system.

・ To use the “OMRON product”, perform the following items: (i) use of the “OMRON product” with an

adequate margin relative to the ratings and performance and safety design such as redundant design; (ii) safety design that minimizes hazards in the “customer's usage” even if the “OMRON product” fails; (iii) formulation of safety measures in the entire system to alert the user; and (iv) periodical maintenance of the “OMRON product” and periodical review of the “customer's usage”.

・ “Our product” is designed and manufactured as a general purpose product for use with a general

industrial product. It is therefore not intended for the purposes listed below. Should you use “our product” for any of such purposes, we shall not guarantee “our product”. Even for any of such purposes, however, the above is not applicable to cases in which our product is intended for the use with a special product “we” intend and special agreement exists.

(a) When a high level of safety is required (such as nuclear control equipment, combustion

equipment, aerospace equipment, railway equipment, elevating equipment, entertainment equipment, medical equipment, safety device, and other use that can cause danger to the life or body of a person)

(b) When a high level of reliability is required (such as a gas, water, or electricity supply system,

24-hour non-stop operation system, payment system, and other use that handles rights and properties)

equipment susceptible to chemical contamination, equipment susceptible to electromagnetic interference, and equipment susceptible to vibration and impact)

(d) When the use conditions or environment is not as written in the “catalog or other documents”

・ Besides the purposes described from (a) to (d) above, “the product described in this catalog or

other documents” is not intended for vehicles (including two-wheel vehicles, and the same applies hereafter). Do not install this product in a vehicle. For products to be installed in vehicles, consult with our sales personnel.

S8BA-24D24D□□□LF

Read and understand this manual

Warranty conditions

The warranty conditions for the “OMRON product” are as follows:

・ Warranty period: For a period of 1 year from the date of purchase

(Unless otherwise described in “catalog or other documents”)

・ Warranty: Any of the following shall be performed on a faulty “OMRON product” at the discretion of

“OMRON”.

(a) In-warranty repair of a faulty “OMRON product” at an OMRON maintenance service center

(note that repair is not applicable to electromechanical components.)

(b) Supply of as many replacement products as the number of faulty “OMRON products” without

charge

・ Outside warranty: If the cause of the failure is any of the following, the failure shall be out of the

scope of warranty.

(a) Use other than the originally designed use of the “OMRON product”

(b) Use not compliant with the “application conditions”

(d) Modification and/or repair not carried out by “OMRON”

(e) Software program introduced not by “OMRON”

(f) Anything that could not be predicted considering the level of science and/or technology at

the time of shipment from “OMRON”

(g) Cause besides the above not attributable to “OMRON” or “OMRON products” (including

force majeure such as disasters)

Limitations of liability

The warranty described in this chapter covers all the warranty related to the “OMRON product”.

“OMRON” and distributors of “OMRON products” shall not be responsible for any damage that occurs and is related to “OMRON products”.

Export controls

To export or provide to non-residents of Japan “OMRON products” or their technical documents, observe the laws and regulations of Japan and other related countries regarding security and export controls. Should you violate any laws or regulations, “OMRON products” or their technical documents may not be provided.

S8BA-24D24D□□□LF

Safety precautions

Additionally, there may be

severe property damage.

result in injuries, mild or moderate, or

●Prohibition of use in locations subject to water such as a

Notice prohibiting installation of the device in locations

leak.

●Do-not-touch prohibition

in injury.

Safety precautions

Important information for safe operation is described.

Be sure to read it before installation and start of use.

The safety symbols and their meaning used in this manual are as follows:

If you fail to use the product prop erly, it may result in injuries, mild or moderate, and may

Warning

Caution

*Property damage means damage to houses/household effects, livestock, and pets.

lead to death.

If you fail to use the product prop erly, it may

damage on property.

●General inhibition

Notice prohibiting an unspecified general action.

●General instruction

Notice instructing an unspecified general action.

●Do-not-disassemble prohibition

Notice prohibiting disassembly because disassembling the device may cause such an accident as an electric shock.

bathroom and shower room.

subject to water, because if a device not made water-proof is used in such locations, injury may occur due to an electric

Notice prohibiting touching the device because touching a certain part of the device under certain conditions may result

●Explosion alert

Notice alerting the user to the possibility of explosion under certain conditions.

Note that events categorized as a caution required matter also may cause more serious results under certain conditions. The information described here is very important and must be strictly observed.

S8BA-24D24D□□□LF

Safety precautions

incorrect operation.

er” switch to stop the output, and stop the supply of

When performing maintenance on the connected devices, follow the above

Warning

(for use of this product)

Provide safety measures outside the UPS to ensure safety in the entire system even if the UPS is damaged or an abnormality occurs due to an external factor. Not doing so may result in serious accidents due to

Caution

(for installation and connection)

Carry the unit considering its weight and balance, and place it on a stable and robust base.

▪ If you drop the unit, the battery or the battery protection mechanism may be broken,

and it may result eventually in a fluid leak, abnormal heating, smoke, rupture or fire.

▪ If you drop the unit, stop using it and have it inspected and repaired. For repair,

contact our sales personnel.

Keep plastic package bags out of reach of children.

▪ Children may suffocate if they place their heads into plastic bags.

Make sure to connect the “input power supply” to the DC power supply device with a rated voltage (DC24V).

▪The input voltage ranges for the UPS are as shown below. Check that the output

voltage of the DC power supply device connected to the input terminal of the UPS is within any of the voltage ranges below.

▪ DC24V±10% (Input sensitivity setting: When standard sensitivity is set) ▪ DC24V±12.5% (Input sensitivity setting: When low voltage sensitivity is set) ▪ DC±5% (Input sensitivity setting: When high voltage sensitivity is set)

▪Connecting to a DC or AC power supply device with a different voltage may result in

malfunction in or damage to the UPS, or cause a fire.

When an abnormality (unusual sound or smell) occurs, turn OFF the unit’s “Pow commercial power.

▪

instructions to ensure safety.

When installing the input cable, make sure to perform the connection as specified.

Make sure to stop the primary power supply before connecting the unit to the input power supply terminal.

▪ When connecting a cable to the terminal block, use a cable that complies with the

input current specification of the UPS. Failure to do so may result in electric shock or ground fault.

Do not disassemble, repair , or modify the unit.

▪ Doing so may cause an electric shock or a fire.

S8BA-24D24D□□□LF

Safety precautions

Doing so may cause a failure or malfunction of the unit.

places where there is flammable or corrosive gas, places with large amounts of

Doing so may cause the cable to be damaged or heated, which may cause an

Caution

(for installation and connection)

Do not install the un it in other than specified orientations.

▪ Dropping or toppling the unit may cause injury. ▪ If you install the unit in an orientation other than specified, the internal temperature

may rise, eventually damaging the UPS or deteriorating the battery.

Do not use the unit where the maximum temperature exceeds 55°C.

▪ The battery deteriorates rapidly. ▪ If the battery's resin separator is damaged, the battery may be short-circuited

inside, and may cause an abnormal heating, smoke, rupture or fire.

▪

Do not exceed the ranges specified for environmental conditions during use/storage.

Do not install or store the unit in the places listed below.

▪ Do not store in places where the humidity is lower than 10% or higher than 90%. ▪ Do not use the unit in places where the ambient temperature is lower than 0°C or

higher than 55°C. (With no condensation)

▪ Do not use in places where the humidity is lower than 10% or higher than 90%.

Do not install/store the unit in closed places such as cabinets with no clearance,

▪

dust, places exposed to direct sunlight, places exposed to shock or vibration, salty or wet places, or outdoors.

▪ Installation or storing the unit in such a place may cause a fire.

When you use plug strip and other plugs to connect additional devices, do not connect devices that exceed the current capacity of the available plugs.

▪ The current protection of the unit may operate, which may stop the output. ▪ The cable heats up, which may cause a fire.

Do not pinch or sharply bend the cable. Do not fold or knot the cable.

▪

electric shock or a fire.

▪ If the cable is damaged, stop using the unit and have the cable repaired. ▪ For repair, contact our sales personnel.

Do not connect any devices other than rate d voltage is DC24V.

▪ The rated output voltage of this unit is DC24V. ▪ Overvoltage or overcurrent may damage the connected devices.

All of the included accessories are designed to be used with the unit. Do not use the accessories with other devices.

▪ Doing so may compromise the safety of devices.

S8BA-24D24D□□□LF

Safety precautions

nd install the breaker where it is easy to

above the top and below the bottom each..

temperature

25°C

10 years

Caution

(for installation and connection)

Include a breaker b etween the “input power supply” of this unit and the DC power supply device. A operate.

When this product is used in compliance with CE marking, please use under 2m communication cable.

Do not block the air vents (upper and lower).

▪ Doing so will cause the internal temperature to rise, which may cause the unit to fail

and the battery to deteriorate.

▪

For stationary installation, leave a space of 50 mm or more above the top, and for

installation using a DIN rail and screw clamps, leave a space of 50 mm or more

Do not connect the RS232C port or the CONTACT port to a LAN device using a LAN cable.

▪ Connection to a LAN device may result in malfunction in or damage to the UPS or

the LAN device.

Caution

(for use)

Do not allow the unit to come in contact with water. If you drop the unit, stop using it.

▪ Doing so may cause an electric shock or a fire. ▪ Doing so may cause an abnormal heating, smoke, rupture, or fire on the battery. ▪ If the unit becomes wet or is dropped, immediately stop using it, disconnect the

input power supply from the wall outlet (commercial power source) and have it inspected and repaired.

▪ For repair, contact our sales personnel.

When the battery is dead, replace it immediately or stop using the unit.

▪ Continuing the use of it may cause fire or electric shock due to liquid leaks.

Ambient

50°C 2.5 years

40°C 5 years

Expected life

*The values in the table are the expected life under

standard use conditions and are not guaranteed.

Occasionally, wipe off dust on the input terminal block and the output terminal block with a dry cloth.

▪ Accumulated dust may cause a fire. ▪ Before wiping off dust, stop all connected devices and the unit, and stop the supply

of commercial power.

S8BA-24D24D□□□LF

Safety precautions

If you notice something unusual such as abnormal sound or smell,

A readily accessible disconnect device shall be incorporated external to the equipment.

your doctor. The fluid may damage your eye if your eye is left untreated.

control circuit is

input power

power output of his unit does not stop and power is supplied from the battery.

Caution

(for use)

Do not use the unit in a closed place and d o n o t cover the unit.

▪ Doing so may cause abnormal heating or a fire.

discoloration, deformation, and heating, turn OFF the unit's “Power” switch to stop the output and stop the supply from the “input power supply”.

▪ Using the unit under such conditions may cause an abnormal heating, rupture or

fire.

▪ If you notice such a condition, stop using the unit and contact our sales personnel

for inspection and repairs.

▪

If fluid leaks from the interior, do not touch the fluid.

▪ Doing so may cause blindness or burns. ▪ If the fluid contacts your eyes or skin, wash it out with lots of clean water and consult

Do not place any objects on the unit, and do not drop heavy objects onto the unit.

▪ Doing so may cause distortion/damage to the case or a failure of the internal circuit,

which may cause a fire.

The unit is equipped with a bypass circuit which i s able to supply electric power to connected devices even when the inner broken down by defects or malfunctions.

If you want to stop the output, stop the source of the “ supply”.

▪ Output is continuing even when all indicators of the front panel are off. ▪ Output ON/OFF cannot be controlled with the “Power” switch on the front panel.

When charging the battery, if the battery cannot be charged completely even after the predetermined charg ing time, turn OFF the “Power” switch of the unit to stop charging the battery.

▪ Otherwise, it may cause an abnormal heating, smoke, rupture or fire on the battery.

Caution

(for maintenance)

When maintaining the connected equipment, turn OFF the unit ʼs “Power” switch to stop the output, and stop the supply of the “input power supply”.

▪ Even if the input power supply to the UPS is stopped while it is in operation, the

S8BA-24D24D□□□LF

Safety precautions

The battery's protection board may be damaged due to a short-circuit.

rupture or fire on the battery.

Caution

(for maintenance)

Do not disassemble, repair , or modify the unit.

▪ Doing so may cause an electric shock or a fire.

If fluid leaks from the interior, do not touch the fluid.

▪ Doing so may cause blindness or burns. ▪ If the fluid contacts your eyes or skin, wash it out with lots of clean water and consult

your doctor.

Do not throw the unit into fire.

▪ Since the battery is incorporated in the unit, the insulator may melt, the gas exhaust

valve or protection mechanism may be damaged, or the electrolyte may catch fire, and it may result eventually in an abnormal heating, smoke, rupture or fire.

Do not insert metal objects into the input terminal block and the output terminal block of the UPS.

▪ Doing so may result in electric shock.

Do not insert metal objects into the battery connectors. Do not short between the connector terminals.

▪ Doing so may result in electric shock. ▪

Caution

(for battery replacement)

Risk of explosion if battery is replaced by an incorrect type.

▪ Not doing so may cause a fire. ▪ Battery pack for; product model: S8BA-B120L.

Do not replace the battery in a place where there is flammable gas.

▪ Spark may occur when connecting the battery, which may cause an explosion or

fire.

If fluid leaks from the battery, do not touch the fluid.

▪ Doing so may cause blindness or burns. ▪ If the fluid contacts your eyes or skin, wash it out with lots of clean water and consult

your doctor.

Do not disassemble or modify the battery.

▪ A safety mechanism and protection mechanism to prevent danger are embedded

into the battery. If they are damaged, it may cause an abnormal heating, smoke,

S8BA-24D24D□□□LF

Safety precautions

Some electrical energy still remains inside the spent battery.

The insulator inside the battery may melt, the gas exhaust valve or protection

Remove battery grounds during installation and maintenance to reduce

Caution

(for battery replacement)

Do not drop the battery and do not expose it to strong impact.

▪ Doing so may cause a leakage, abnormal heating, smoke, rupture or fire on the

battery. And, if the battery's protection mechanism is broken, the battery may be charged at an abnormal current or voltage, an abnormal chemical reaction may occur inside the battery, and it may result eventually in an abnormal heating, smoke, rupture or fire.

Do not short the battery with metal objects.

▪ Doing so could cause an electric shock, fire or burn. ▪

Do not dispose of batteries in a fire.

▪

mechanism may be damaged, or the electrolyte may catch fire, and it may result eventually in abnormal heating, smoke, rupture or fire.

Do not use a new battery and an old battery at the same time.

▪ The battery may be excessively discharged while being used or excessively

charged while being charged, an abnormal chemical reaction may occur inside the battery, and it may result eventually in an abnormal heating, smoke, rupture or fire.

▪ A battery can present a risk of electrical shock and high short circuit current. ▪ Contact with any part of a grounded battery can result in electrical shock. ▪ The following precautions should be observed when working on batteries:

(a) Remove watches, rings, or other metal objects.

(b) Use screwdrivers with insulated handles.

(d) Do not lay tools or metal parts on top of batteries.

(e)

likelihood of shock. Remove the connection from ground if any part of the battery is determined to be grounded.

Dispose of or collect (recycle) the battery according to your own rules set for that purpose or as instructed by laws and regulations.

▪ Do not dispose of it in fire. Otherwise, it could explode.

S8BA-24D24D□□□LF

Safety precautions

Notes

■ Before using

Charge the battery soon after purchasing the unit.

▪ If you do not use the unit for a long time after the purchase, the battery may deteriorate and

the battery may become unusable.

▪

Connect this unit to the input power supply and turn ON the “Power” switch to charge the

battery.

When moving the unit fro m a col d p lace to a warm place, leave it for sev eral h our s b ef ore using it.

▪

If the unit is promptly turned ON after being moved to a warmer place, condensation may

form inside the unit and cause it to fail.

Take measures for handling unforeseen accidents, such as data backup and system redundancy.

▪ The output may stop when there is failure in this unit.

■ Connecting

Do not short the output lines of the unit to each other, and do not short the output lines to the ground.

▪

The unit may fail.

In the event you transfer or sell this unit to a third party, please include all of the documentation that came with the unit. This is to ensure that the unit is used in line with the conditions described in the included documentation.

▪

This manual contains important safety-related information. Please read and understand the

contents of the manual before beginning operation. If this manual is misplaced, download the manual from our website.

S8BA-24D24D□□□LF

Safety precautions

■ Using

Before stopping the input power supply to the unit, turn OFF the “Power” switch of the unit.

▪ The unit enters Battery Mode when input power supply is stopped. ▪

If the frequency of backup operation becomes high, the battery life may be significantly

reduced.

Do not use for an application that frequently requires Battery Mode.

▪ The battery will deteriorate and fail to maintain the specified backup time.

If you want the UPS to stand by in a UPS startup state, set 3 months or less for the input power supply stop period.

▪ This UPS startup state means either of the following states:

(a) A state of waiting for startup triggered by a remote ON/OFF or BS signal. (b) A state of waiting for startup when cold start is enabled.

▪

If the UPS is left unused in the above state for 3 months or longer, the battery goes into

overdischarge state, and the backup time may become shorter or the battery may become unusable.

■ Storing

Storing the battery in UPS for a long term, store at an environment less than 25°C and recharge 10 to 15 minutes the battery within 1 year.

▪ The battery self-discharges even when it not being used, and it goes into overdischarge

state if it is left for a long period of time. The backup time may become shorter or the battery may become unusable.

▪ We recommend keeping the temperature 25°C or less when storing the unit for long periods

of time.

▪

Turn OFF the unit’s “Power” switch when storing it.

Do not install or store the unit in a place exposed to direct sunlight.

▪ The rise of temperature may cause the built-in battery to deteriorate rapidly and become

unusable.

S8BA-24D24D□□□LF

Regulations and standards

Use overseas

To export (or provide to non-residents of Japan) a model of this product that is categorized as a merchandise (or technology) requiring the export permission and approval stipulated by the Foreign Exchange and Foreign Trade Law, the export permission and approval (or service transaction permission) in accordance with the said law are required.

Conformance to EC Directives

●Applicable directives

▪ EMC Directives

●Principles regarding conformance

OMRON electronic devices that comply with EC Directives also conform to the related EMC standards so that they can be more easily built into other devices or the overall machine. The actual products have been checked for conformity to EMC standards*.

Whether the products conform to the standards in the system used by the customer, however, must be checked by the customer. EMC-related performance of the OMRON devices that comply with EC Directives will vary depending on the configuration, wiring, and other conditions of the equipment or control panel on which the OMRON devices are installed. The customer must, therefore, perform the final check to confirm that devices and the overall machine conform to EMC standards.

*Applicable EMC (Electromagnetic Compatibility) standards are as follows: EMS (Electromagnetic

Susceptibility): EN 61000-6-2, EMI (Electromagnetic Interference): EN 61000-6-4, and EN 61000-6-4 Radiated emission: 10-m regulations

●Conformance to EC Directives

This product complies with EC Directives. To ensure that the machine or device in which the this product is used complies with EC Directives, the product must be installed as follows:

▪ This product must be installed within a control panel. ▪ You must use reinforced insulation or double insulation for the DC power supply connected to this

product.

▪ Models of this product that comply with EC Directives also conform to the Common Emission

Standard. Radiated emission characteristics (10-m regulations), in particular, may vary depending on the configuration of the control panel used, other devices connected to the control panel, wiring, and other conditions. Therefore, even when using a model of this product that complies with EC Directives, you must confirm and ensure the compliance to EC Directives of the entire machine or equipment.

▪ This is a Class A product (for industrial environments). In a residential environment, it may cause

radio interference. If radio interference occurs, the user may be required to take appropriate measures.

S8BA-24D24D□□□LF

Regulations and standards

●Conformance to UL

▪ This product must be installed within a control panel with an internal heater or other unit to protect

against the formation of condensation (Standard mounting only).

▪ Gaps in the door to the control panel must be completely filled or covered with gaskets or other

material.

▪ For use as a UL compliant device, the specifications for S8BA-24D24D480LF are as follows:

・ Maximum input current: 20A ・ Rated output current/capacity: 16.7A/400W

▪ For use in Pollution Degree 2 Environment. ▪ Surrounding Air Temperature, 55°C. ▪ Make sure to connect the device with Class 2 output to the USB port.

S8BA-24D24D□□□LF

1-1 Features of this product

1 Overview of the product

1-1 Features of this product

▪ The Uninterruptible Power Supply (UPS) protects such devices as PLC and IPC* from power

failures, voltage variations, and instantaneous voltage drops.

▪ Under normal conditions, the UPS outputs DC24V of electrical power from the DC power supply

as-is. When an abnormality is detected in the DC24V power supply such as a power failure and voltage variation, the UPS switches to battery supply to continue to provide DC24V of electrical power.

▪ For the specifications of PLC and IPC for power supply input and operation in the event of

momentary power interruptions, check the respective manuals. *IPC: Industrial PC (Industrial use computer)

S8BA-24D24D□□□LF

1 Overview of the product

1-2 Specifications

Rated input voltage

DC24V

When standard sensitivity is set)

sensitivity is set

When low voltage sensitivity is set

current

Input terminal

Push-in Terminal block

Input protection

Fuses

Input protection capacity

10A

15A

30A

12A or less

0.1ms or less

or less

0.1ms or less

Rated current

for rated output voltage

10A

15A

20A

Switching time

Uninterrupted

Normal operation

Output of input voltage as-is

Backup operation

24V±5%

Output terminal

Push-in Terminal block

Alarm display at a load level of 110% or over (Normal operation)

(Backup operation)

Alarm display cancellation at a load equal to or below the rated capacity (Normal operation, Backup operation)

Type

Lithium-ion battery

Rated voltage

DC14.4V

parallel

Expected battery life*1

10 years (25°C), 5 years (40°C), 2.5years (50°C)

Replacement by user

Yes (Hot swapping)

Auto battery check function

Yes

Battery life counter function

Yes

Charging time

4hours

Backup time (25°C, initial characteristics)

6min.

Dimensions (W×D×Hmm)

94×100×100

148×100×100

270×100×100

Weight of unit

Approx. 0.8kg

Approx. 1.3kg

Approx. 2.0kg

Approx. 2.3kg

Cooling method

Natural cooling

Operating ambient temperature/humidity

0°C〜55°C／10％〜90％RH with no condensation

Storage ambient temperature/humidity

−20°C〜55°C／10%〜90%RH with no condensation

JIS C 60068-2-6 compliant／5〜8.4Hz amplitude: 3.5mm, 8.4

(Sweep time: 10min.×Sweep count 10 times

Total: 100min.)

Shock resistance

JIS C 60068-2-27 compliant: 147m/s

X, Y, and Z directions three times

voltage

／Leak current: 10mA or less

500 VDC megger)

standard

Safety standard

UL508／CE／C22.2 No.107.1-01

electromagnetic field strength

Internal power consumption (normal*

/ maximum*

)

7W／22W

11W ／41W

14W／60W

18W／80W

cation

RS232C (Interface terminal)

Yes (RJ45)

I/O signal

Yes (RJ45)

1-2 Specifications

Description Capacity 120W 240W 360W 480W

DC24V±10%

Input voltage range

When low voltage

DC24V±12.5%

※

DC input

DC output

Battery

Input maximum

Inrush current

Output voltage

Overload protection

Rated capacity

DC24V±5%

for rated input voltage 5.9A 11.7A 17.5A 23.3A

14A

16A or less 0.1ms or less

Alarm display at a load level of 110% or over, output voltage drop

1600mAh×1

※

1600mAh×2

1600mAh×3

1600mAh×4

※

Structure

Environment

Insulation and withstand

Compliance to

Vibration resistance

Voltage resistance

Insulation resistance

EMI

Radiated disturbance

Serial communi-

USB (Interface terminal) Yes (B connector)

*1 An estimated value for standard mounting. Not a guaranteed value.

150Hz acceleration rate: 9.8m/s

／X, Y, and Z directions: 100min.

〜

＝

／

Between DC external and GR terminals: AC1000V 50/60Hz 1min.

Between DC external and GR terminals: 20MΩ or more (Using a

EN61000-6-4

S8BA-24D24D□□□LF

1-2 Specifications

1 Overview of the product

*2 Conditions: With rated loads connected, at a rated input voltage, and with the battery fully charged.

*3 Conditions: With rated loads connected, at a rated input voltage, and at the maximum battery

charging current.

*4 20A for use as a UL compliant device.

*5 16.7A for use as a UL compliant device.

*6 400W for use as a UL compliant device.

*7 When using in an environment at a high temperature, charging may be paused by charging

temperature protection, then the charging time will be longer than specified time. "CS" will be displayed when charging temperature protection is operated.

S8BA-24D24D□□□LF

2 Preparation

2-1 Unpacking the product

it on a

Description

Quantity

Instruction manual

USB cable

Instruction manual

USB cable

2 Preparation

2-1 Unpacking the product

Open the package box and take out the UPS and accessories.

 Caution for installation and connection

Carry the unit considering its weight and balance, and place stable and robust base.

▪ If you drop the unit, the battery or the battery protection mechanism may be broken,

and it may result eventually in a fluid leak, abnormal heating, smoke, rupture or fire.

▪ If you drop the unit, stop using it and have it inspected and repaired. For repair,

contact our sales personnel.

2-2 Checking the contents

Check whether all the package contents are included and there is no damage found on their appearance. If you should notice defects or anything wrong, contact our sales personnel.

■ Accessories related to the main unit

S8BA-24D24D□□□LF

2-2 Checking the contents

2 Preparation

Description

Model number

Replacement battery pack

S8BA-B120L*

Connection cable (RS232C)

S8BW-C01

Connection cable (CONTACT)

S8BW-C02

Connection cable�

(RS232C)

Connection cable�

(CONTACT)

Replacement

battery pack

■ Related products

* Battery pack (S8BA-B120L) information:

▪Rated voltage: DC14.4V ▪Rated capacity: 1600mAh ▪Weight: 0.3kg

S8BA-24D24D□□□LF

2 Preparation

2-3 Name of each part

①

②

③

⑤

⑥

⑦

④

①Operation panel ②DC output terminal block ③DC input terminal block ④GR terminal（）

⑤USB port ⑥RS232C port ⑦CONTACTport

2-3 Name of each part

This section describes the name of each part of the UPS.

For information on the function of each part, refer to “2 Preparation” and “3 Installation and connection” that provides the details.

■ Meanings of the symbols

Indicates that the power is turned ON.

Indicates that the power is turned OFF.

Indicates that the beeper is stopped.

Indicates the noise-resistance improved grounding.

■ Front view

● S8BA-24D24D120LF

S8BA-24D24D□□□LF

2-3 Name of each part

2 Preparation

①

②

③

⑤

⑥

⑦

④

①Operation panel ②DC output terminal block ③DC input terminal block ④GR terminal（）

⑤USB port ⑥RS232C port ⑦CONTACTport

①

②

③ ④

⑤

⑥

⑦

①Operation panel ②DC output terminal block ③DC input terminal block ④GR terminal（）

⑤USB port ⑥RS232C port ⑦CONTACTport

● S8BA-24D24D240LF

● S8BA-24D24D360LF/S8BA-24D24D480LF

S8BA-24D24D□□□LF

2 Preparation

2-3 Name of each part

⑧

⑨

⑩

⑧“Status indicator” digital indicator (Green) ⑨“Beep Stop/Test” switch (Black) ⑩“Power” switch (Gray)

■ Enlarged view of the operation panel

S8BA-24D24D□□□LF

2-3 Name of each part

2 Preparation

⑪

⑫

⑪DIN rail mounting hook ⑫DIN rail mounting groove

⑪

⑪ ⑪

⑫

⑪DIN rail mounting hook ⑫DIN rail mounting groove

■ Rear view

● S8BA-24D24D120LF

S8BA-24D24D□□□LF

● S8BA-24D24D240LF

2 Preparation

2-3 Name of each part

⑪ ⑪

⑪⑪⑪

⑫

⑪DIN rail mounting hook ⑫DIN rail mounting groove

● S8BA-24D24D360LF/S8BA-24D24D480LF

S8BA-24D24D□□□LF

2-4 Diagram of the Input/output circuit block

2 Preparation

Normal operation：ON

Backup operation：OFF

DC24V

Imput

。。

DC24V

Imput

Normal operation：ON

Backup operation：OFF

Normal operation：ON

Backup operation：OFF

Battery

DC/DC Converter

FET

Normal operation

Backup operation

FET

Charge/

Discharge

*In normal operation, 24 VDC is output as-is for charging the battery and from the input power supply.

If the 24 VDC from the input power supply becomes lower, the operation automatically switches to backup operation, and 24 VDC is output from the battery.

2-4 Diagram of the Input/output circuit block

S8BA-24D24D□□□LF

3 Installation and connection

3-1 Installation

WhenyouinstalldevicesotherthantheUPSontheleftorthe rightoftheUPS,leavethespacespecifiedbyeachdevice.

Leave 50 mm of space between the upper and lower.

Leave 50 m

m of space between the upper and lower.

3 Installation and connection

3-1 Installation

This section describes how to install the UPS.

For cautions when installing the UPS, refer to “Caution (for installation and connection)” shown in the “Safety precautions” of the beginning of this manual.

The UPS permits the following installing methods. Choose the one best suited for the environment.

 Notes

Before installing this device, make a record of the serial number of this device. The product serial number is required when contacting us about the device. The product serial number is written on the sticker attached to the side of the UPS.

■ Correct positions

● Standard mounting (Mounting to the DIN rail)

S8BA-24D24D□□□LF

3-1 Installation

3 Installation and connection

To mount UPS on floor with its back away from you,mount it so that its back is in contact with wall. (Because PCB is partially exposed in its back side, and UPS may be affected by static electricity for that reason.)

To mount UPS on floor with its top away from you,mount it so tha

t its top is kept away

50 mm or more from wall.

Leave 50 mm of wall

● Stationary mounting

● Face-up mounting

S8BA-24D24D□□□LF

3 Installation and connection

3-1 Installation

Mount UPS upside down

DIN rail is placed vertically

■ Incorrect positions

● Mounting to the DIN rail

S8BA-24D24D□□□LF

3-1 Installation

3 Installation and connection

Do not stack.

Do not mount on floorwith front down.

To mount UPS on floor with its top away fr om you, ensure that its top is not in contact with wall.

● Stationary installation

S8BA-24D24D□□□LF

3 Installation and connection

3-1 Installation

DIN rail mounting hooks

①

②

DIN rail mounting groove

DINrail

DIN rail

3-1-1 DIN rail ins tallation

■ How to mount to the DIN rail

1. Open the “DIN rail mounting hooks” in the back of the UPS.

2. Hook the “DIN rail mounting groove” in the back of the UPS onto the DIN rail. Put a

hook on the groove on one end (①), and put the other hook on the groove on the other end (②).

S8BA-24D24D□□□LF

3-1 Installation

3 Installation and connection

DIN rail mounting hooks

DIN rail

3. Close the “DIN rail mounting hooks” in the back of the UPS.

● Mounting on the floor

S8BA-24D24D□□□LF

3 Installation and connection

3-1 Installation

DIN rail mounting hooks

Screw

3-1-2 Wall or floor mounting procedure

1. Open the “DIN rail mounting hooks” in the back of the UPS.

2. Use the screw holes of the “DIN rail mounting hooks” to fix the UPS to the floor or wall

with screws.

S8BA-24D24D□□□LF

3-1 Installation

3 Installation and connection

Screw

● Mounting on the floor

S8BA-24D24D□□□LF

3 Installation and connection

3-1 Installation

2-M4

100

110

3-M4

100

110

148

● 120W Fix with screws

● 240W Fix with screws

S8BA-24D24D□□□LF

3-1 Installation

3 Installation and connection

3-M4

170

270

100

110

● 480W Fix with screws

S8BA-24D24D□□□LF

3 Installation and connection

3-2 Connection

Solid wire / Stranded wire

0.5mm2

AWG

AWG20

Solid wire / Stranded wire

0.75mm2

AWG

AWG16

Solid wire / Stranded wire

1.25mm2

AWG

AWG14

Solid wire / Stranded wire

2.0mm2

AWG

AWG12

Temperature rating for recommended cable

90°C

3-2 Connection

This section describes how to connect the UPS.

For cautions when connecting the UPS, refer to “Caution (for installation and connection)” shown in the “Safety precautions” of the beginning of this manual.

3-2-1 Connecting a cable to the input terminal block and the

output terminal block

For details about the connectable sizes and recommended cable sizes, see the following table.

Connectable sizes Cable

Recommended sizes

Stripped cable length

10A

15A

20A

Solid wire

Stranded wire

AWG

0.2〜4.0mm

0.2〜2.5mm AWG24〜12

8〜10mm

S8BA-24D24D□□□LF

3-2 Connection

3 Installation and connection

Imput terminal

Output terminal

GR terminal

■ Connecting a cable to the terminal block

1. Insert the tip of a flat blade screwdriver with a 3 mm or less thin blade into a square hole

at the right of the terminal block. Then, the cable lock is released.

2. With the tip of the flat blade screwdriver in the hole, insert a cable into a round hole at

the left of the terminal block.

S8BA-24D24D□□□LF

3 Installation and connection

3-2 Connection

3. Pull out the flat blade screwdriver. Then, the cable is locked.

S8BA-24D24D□□□LF

3-2 Connection

3 Installation and connection

■ Removing a connected cable from the terminal block

1. Insert the tip of a flat blade screwdriver with a 3 mm or less thin blade into a square hole

at the right of the terminal block and pull out the cable.

2. Pull out the flat blade screwdriver.

S8BA-24D24D□□□LF

3 Installation and connection

3-2 Connection

DC power supply device

(DC24V)�

Connected device

UPS

3-2-2 Connecting a device to the output terminal block

1. Connect devices you want to back up to output terminals of this unit.

2. When using the UPS monitoring software or the I/O signal, connect the unit to the target

device with a connection cable. For details about the connection procedure, see “5 Maintenance and inspection”, and “6 To perform shutdown processing of the devices when a power failure occurs”.

S8BA-24D24D□□□LF

3-2 Connection

3 Installation and connection

DC power supply

device (DC24V)

Connected deviceUPS

3-2-3 Connectin g t he inp ut power supply to the inpu t t erminal block

1. Connect an input cable to the input terminal block of the unit.

2. Connect the input cable to the DC power supply device.

Turn the input power supply ON and turn the “Power” switch ON, and power output operation starts, and at the same time, battery charging operations starts; the battery will be completely charged in about 4 hours.

 Notes

Note that the battery in this unit has not been charged prior to shipment. Charge the battery when you use the UPS for the first time.

S8BA-24D24D□□□LF

4 Check and start operation

4-1 The name and function for the operation and display

⑧

⑨

⑩

⑧“Status indicator” digital indicator (Green) ⑨“Beep Stop/Test” switch (Black) ⑩“Power” switch (Gray)

figure

⑨

“Beep Sto p/ Te s t ” switch

▪Stop the beeper: Hold down for 0.5 seconds or longer.

seconds or longer (enabled only when the power is

Additional Information: When input power is being

charging operation starts.

4 Check and start operation

4-1 The name and function for the operation and display

4-1-1 Name of each part

4-1-2 Switch

Sign

of the

⑩

Label Name Description

“Power” switch ▪Turn the power ON: Hold down for 3 seconds or longer

▪ Perform the self-diagnostic test: Hold down for 5

turned ON).

▪Shift to battery replacement mode: Hold down for 10

seconds or longer.

when the power is turned OFF, and the power output starts.

▪Turn the power OFF: Hold down for 3 seconds or longer

when the power is turned ON, and the power output stops.

supplied to the unit and the power is turned ON, battery

S8BA-24D24D□□□LF

4-1 The name and function for the operation and display

4 Check and start operation

OFF

sec

0.2sec

OFF

sec

0.2sec

OFF

0.2

sec

OFF

Continuous

“Beep Stop/Test” switch

OFF

0.5

sec

0.2

sec

4-1-3 Beep sound

■ Type of beep sound

● Intermittent

0.5-second intervals:

1-second intervals:

● Continuous

■ Stopping the beep sound

When the beep is sounding, you can stop it by pressing and holding the “Beep Stop/Test” switch for 0.5 seconds or longer. You cannot cancel the pause. Be careful.

2-second intervals:

4-second intervals:

S8BA-24D24D□□□LF

4 Check and start operation

4-2 Start and stop procedures and basic operation

Power supply output terminal

Outputs power (connected devices are powered)

4-2 Start and stop procedures and basic operation

4-2-1 Start and stop procedures

For cautions when operating the UPS, including start and stop, refer to “Caution (for use)” shown in the “Safety precautions” of the beginning of this manual.

■ Start procedure

Hold down the “Power” switch of the unit for 3 seconds or longer.

▪ A few seconds after the switch is turned ON, the power output from the input power

supply starts as-is (Status indicator “

”).

▪ The status indicator displays “

Mode for about 10 seconds. If the battery level is low, the self-diagnostic test is not performed. It is automatically executed after the battery is charged.

▪ When the self-diagnosis test finishes normally, the unit enters the normal operating

state.

▪ When the self-diagnostic test is not performed, the unit enters immediately the normal

operation.

▪ During operation, the battery is charged automatically.

Status indicator

”, and the self-diagnostic test is performed in Battery

S8BA-24D24D□□□LF

4-2 Start and stop procedures and basic operation

4 Check and start operation

Standby mode

Normal operation

Startup proces s

OFF

High

Low

OFF

0.5 sec

OFF

Normal operation

Backup operation

Self-diagnostictest

Normal operation

10 sec 10 sec

1 sec

D-1

Battery restorage

Output from UPS

Display of “status indicator” indicator

Beep

UPS operating mode

”Power” swit ch (Remote ON/OFF)

Input power supply

BL signal (OUT)*

BS signal (IN)*

BU signal (OUT)*

＜Note＞ D-1: Display the latest UPS fault mode（E0, ES, E1 or --） (If there is no record for UPS error, UPS display the "--") *For details, see 7-1 I/O signal functions.

■ Startup sequence

This section describes the startup sequence.

● To start the UPS when in standby mode by turning on the Power switch.

This unit starts up immediately when the “Power” switch is turned ON.

S8BA-24D24D□□□LF

4 Check and start operation

4-2 Start and stop procedures and basic operation

0.2 sec

4 sec

*For details, see 7-1 I/O signal functions.

OFF

Durling power failure

High

Low

Empty

OFF

Battery restorage

Output from UPS

Display of “status indicator” indicator

Beep

UPS operating mode

“Power” switch (Remote ON/OFF)

Input power supply

BL signal (OUT)*

BS signal (IN)*

BU signal (OUT)*

Normal operation

Backup operation

■ The backup sequence when power failure/voltage drop

(instantaneous voltage drop) occures

Explains the backup sequence when a power failure occurs.

●

When the input power supply recovers while the battery level is sufficiently high

S8BA-24D24D□□□LF

4-2 Start and stop procedures and basic operation

4 Check and start operation

Durling power failure

OFF

High Low

Empty

OFF

*For details, see 7-1 I/O signal functions.

Battery restorage

Output from UPS

Display of “status indicator” indicator

UPS operating mode

“Power” switch (Remote ON/OFF)

Input power supply

BL signal (OUT)*

BS signal (IN)*

BU signal (OUT)*

Beep

Normal operation

Backup operation

0.2 sec

4 sec

1 sec

● When the input power supply recovers while the battery level is Low

S8BA-24D24D□□□LF

4 Check and start operation

4-2 Start and stop procedures and basic operation

Durling power failure

*For details, see 7-1 I/O signal functions.

OFF

High

Low

Empty

OFF

Normal operation

Backup operation

0.2 sec

4 sec

1 sec

3 sec

●

When the input power supply does not recover until the battery becomes empty

S8BA-24D24D□□□LF

4-2 Start and stop procedures and basic operation

4 Check and start operation

Durling power failure

OFF

High Low

mpt

OFF

Battery restorage

Output from UPS

Display of “status indicator” indicator

Beep

UPS operating mode

“Power” switch (Re

mote ON/OFF)

Input power supply

BL signal (OUT)*

BS signal (IN)*

BU signal (OUT)*

Normal operation

Backup operation

0.2 sec

4 sec

*For details, see 7-1 I/O signal functions.

You can set a time from when a BS signal is detected until the UPS is stopped in the range from 0 minute (factory default setting) to 10 minutes. See the BS signal delay time setting: 4-4-2 Settings

● For shutdown by a BS signal

S8BA-24D24D□□□LF

4 Check and start operation

4-2 Start and stop procedures and basic operation

OFF

High

Low

Empty

OFF

Battery restorage

Output from UPS

Display of “status indicator” indicator

Beep

UPS operating mode

“Pow

er” switch

(Remote ON/OFF)

Input power supply

BL signal (OUT)*

BS signal (IN)*

BU signal (OUT)*

Normal operation

Backup operation

■ Operation sequence when the "Power" switch is turned OFF

● When the "Power" switch is turned OFF during normal operation

S8BA-24D24D□□□LF

4-2 Start and stop procedures and basic operation

4 Check and start operation

OFF

High

Low

Empty

OFF

Durling power failure

0.2 sec

4 sec

Battery restorage

Output from UPS

Display of “status indicator” indicator

Beep

UPS operating mode

“Power” swit ch (Remote ON/OFF)

Input power supply

BL signal (OUT)*

BS signal (IN)*

BU signal (OUT)*

Normal operation

Backup operation

● When the "Power" switch is turned OFF during backup operation

S8BA-24D24D□□□LF

4 Check and start operation

4-2 Start and stop procedures and basic operation

<4ms

When high voltage sensitivity is set

When standard voltage sensitivity is set*

When low voltage sensitivity is set*

Input voltage

<4ms

power failure or input voltage drop

DC24V

DC21.6V（-10%

）

DC20.4V（-15%

）

DC19.8V（-17.5%

）

DC voltage

（

Factory default

）

Switching power supply：S8VK-G48024

UPS：S8BA-24D24D240LF

Load：Rated load

When power failure occurs on the AC input side of the sw itching power supply

*For details, see “4-4 UPS operation mode settings ” , “Input sensitivity setting”

■ I

nput and output voltage time chart when shifting to backup operation

Explains the operation when shifting to backup operation due to power failure or input

voltage drop.

S8BA-24D24D□□□LF

4-2 Start and stop procedures and basic operation

4 Check and start operation

Status indicator

Output

Description

Backup operation is in progress due to power failure or input

■ Operation after a power failure

If a power failure or input power supply error occurs, the operation automatically switches to backup operation to continue the power output by using electrical power from the battery.

power supply error.

（

: indicates blinking)

ON Backup is operating due to power failure or AC input error.

Battery level is low, so output will stop soon.

OFF Battery is dead, so output stopped.

■ Operation when power is restored

● When power is restored during backup operation

When power is restored during backup operation, the output from input power supply automatically starts again and the output operation continues. In addition, the battery charging operation starts.

● When power is restored after the power supply output stops

If the power supply output stops due to empty battery, the unit automatically restarts and resumes the power supply output when power is restored. And the battery charging operation starts.

 Reference

Using operation mode settings, you can set whether to automatically restart when power is restored ("restart" is set by factory default).

S8BA-24D24D□□□LF

4 Check and start operation

4-3 Interpreting beeps and displays

When the “Power” switch is turned OFF, the battery charging operation stops.

supply

mode settings)

"Power" switch "ON"

operation

indicates blinking

indicates the display is ON

indicates the display is OFF

■ Operation when stopping

Hold down the “Power” switch of the unit for 3 seconds or longer, and the power is turned OFF and the output stops.

 Reference

4-3 Interpreting beeps and displays

No.

Status

indicator

UPS

output

OFF OFF --- OFF OFF

OFF OFF --- OFF ON

OFF OFF --- OFF NG

Beep

Charge/ Discharge

“Power”

switch

OFF OFF --- OFF NG

OFF OFF Charge ON ON

Input

power

Description Procedures

No DC input Paused

DC input "Power" switch "OFF"

Error: DC input voltage higher than the specified range

Error: DC input voltage lower than the specified range

Waiting to start up due to low battery.

---

Use in the DC input voltage range described in the specification.

Continue charging the battery. When the set battery level is reached, the UPS automatically restarts. The setting can be changed by the operation mode. (See 4-4

UPS operation

ON OFF Charge ON ON

ON OFF

Discharge

ON ON

Normal operation * Dot at bottom right lit during charging

Self-diagnosis test in progress

---

S8BA-24D24D□□□LF

4-3 Interpreting beeps and displays

4 Check and start operation

supply

only)

continued.

only)

UPS main body's life

only).

indicates blinking

indicates the display is ON

indicates the display is OFF

No.

Status

indicator

UPS

output

ON --- ---

Beep

Intermitte

nt, at 2s intervals

Intermitte

nt, at 2s intervals

Intermitte

nt, at 4s

intervals

Intermitte

nt, at 1s intervals

Charge/

Dischar

Charge ON ON

Discharge

“Power”

switch

ON／

OFF

Input

power

OFF/

Description Procedures

Battery deterioration detected by self-diagnosis test. (Displayed during normal operation

Battery life counter counted up to limit (Displayed during normal operation

Battery replacement mode activated.

Backup operation due to power failure or DC input error. Output stops if backup operation is

(Same as above) Output stops soon Battery level low.

Replace the battery. Get an optional replacement battery, and you can replace the battery on your own (see 5-2 Replacing the battery).

Replace the battery. (See 5-2 Replacing the battery).

Process the termination of the connected devices you are using, and then stop the devices.

S8BA-24D24D□□□LF

ON OFF --- ON

ON OFF --- ON ON

ON OFF Charge ON ON

Intermitte

nt, at 0.5s

intervals

Charge/ Discharge

Output stopped due

OFF/

to low battery

(displayed for a few seconds only).

Ambient temperature 55°C or higher or 0°C or lower detected, and battery charging operation stopped. (Displayed during normal operation

counter counted up to limit (displayed during normal operation

Overcurrent (110% or higher) detected

ON/

because connections

OFF

exceeded capacity limit.

Charge the battery.

Set the ambient temperature within the range from 0°C to 55°C.

Replace the UPS.

Reduce connected devices until the display condition becomes as shown in No.6.

4 Check and start operation

4-3 Interpreting beeps and displays

supply

Turn OFF all the

connected devices.

Stopped due to

limit significantly.

Check that the DC input

capacity.

Charging stopped

(Up).

Charging stopped

(Down).

of self diagnosis test.

SMbus.

indicates blinking

indicates the display is ON

indicates the display is OFF

No.

Status

indicator

UPS

output Beep

OFF

Continuous

Charge/

Dischar

Discharge

Charging

stopped

“Power”

switch

ON OFF

--- ON ON

--- ON

ON ON

Input

power

ON/ OFF

Description Procedures

Overcurrent (115% or higher) and output voltage drop detected because connections exceeded capacity limit.

short-circuit on connected device side or due to connections exceeding capacity

Output voltage error (Up).

Output voltage error (Down).

due to battery charging voltage error

"Power" switches on the UPS and connected devices, reduce the connected devices, and turn ON the "Power" switches on the UPS and remaining

of any of the connected devices is not short-circuited and that connections did not exceed the rated

Continuous

Charging

stopped

--- ON

--- ON ON

--- ON

ON ON

due to battery charging voltage error

ON/

Internal temperature

OFF

error (overheat).

Error detected by

ON/

inverter circuit check

OFF

Charging current error (overcurrent).

Unable to communicate with

ON/

battery through

OFF

Turn OFF all the "Power" switches on the UPS and connected devices, and turn ON the "Power" switch on the UPS only again.

S8BA-24D24D□□□LF

4-4 UPS operation mode settings

4 Check and start operation

Item

Description

Beeper setting

Lets you set the beeper operation during backup operation or when an error occurs.

“Disable beeper” is set by factory default.

“Enable auto restart” is set by factory default.

Auto test setting

Lets you set the operation for automatically executing a self diagnosis test.

“Enable test for all timings” is set by factory default.

4-4 UPS operation mode settings

4-4-1 Settable items and explanations

You can set the UPS operation mode by operating switches on the operation panel. The following table shows the settable items and their explanations.

▪Disable beeper: Do not generate beep sound. ▪Enable beeper for error only: Generate beep sound when an error occurs. ▪Enable beeper for all timings: Generate beep sound during backup operation and

when an error occurs.

2 Auto restart setting Used to set the auto restart operation to be performed when power is restored after

UPS shutdown.

▪Enable auto restart: Automatically restart when power is restored. ▪Disable auto restart: Do not automatically restart when power is restored.

▪Enable test for all timings: Automatically execute a test at UPS startup and once

every 4 week s.

▪Enable test for startup only: Automatically execute a test at UPS startup. ▪Enable test for once every 4 weeks only: Automatically execute a test once every

4 weeks.

▪Disable test: Do not automatically execute a test.

S8BA-24D24D□□□LF

4 Check and start operation

4-4 UPS operation mode settings

Item

Description

Auto restart mode

Used to set the operation mode to be activated when the UPS automatically restarts

supply is

d backup operation is being

ON OFF ON OFF ON OFF ON OFF

※1

AC imput

BS signal

※

Power supply output (When "modeB" is set)

Power supply output (When "modeA" is set)

operation is being

※1

ON OFF

Power

OFF

Starts up when BS sign

al* is OFF

Starts up when input power supply turns from OFF to ON

AC imput

BS signal

※

Power supply output (When "modeB" is set)

Power supply output (When "modeA" is set)

sensitivity

operation (high)

commercial operation (high)

commercial operation (low)

operation (low)

Logic of Remote

Lets you set the logic of remote ON/OFF signal.

“Stop when circuit is closed” is set by factory default.

setting

after its shutdown. ▪Mode A: Restart immediately when detecting that the input power

turned ON after the UPS stops.

▪Mode B: Restart when detecting that the input power supply turns from OFF to

ON after the UPS stops.

“Mode A” is set by factory default.

【Description of operation】 (1) W hen the input power supply is turned OFF an

performed, a BS signal* is input.

(2) When the input power supply is turned ON and normal

performed, a BS signal* is input.

5 Input sensitivity

setting

Lets you set the voltage sensitivit y by which the UPS can detect an input power supply error. ▪Standard voltage sensitivity: Perform backup operation when the input voltage is

not in the specified range ±10%.

▪Low voltage sensitivi ty: Perform backup operation when the input voltage is not in

the specified range ±12.5%.

▪High voltage sensitivity: Perform backup operation when the input voltage is not

in the specified range ±5%.

“Standard voltage sensitivity” is set by factory default.

Voltage sensitivity

Voltage for shifting to backup

Voltage for returning to

Voltage for shifting to backup

ON/OFF signal setting

▪Stop when circuit is closed: Stop the UPS when the circuit between the terminals

is closed.

▪Stop when circuit is open: Stop the UPS when the circuit between the terminals is

open.

Low

Standard

High

15% 12.50% 10%

12.50% 10% 5%

-12.50% -10% -5%

-17.50% -15% -10%

S8BA-24D24D□□□LF

4-4 UPS operation mode settings

4 Check and start operation

Item

Description

Cold start setting

Lets you set the cold start operation. The cold start refers to a function to start up

“Disable cold start” is set by factory default.

“Enable battery life counter” is set by factory default.

“Immediately power OFF” is set by factory default.

“No setting (∞)” is set by factory default.

“0%” is set by factory default.

BS signal* delay

Lets you set the delay time from when a BS signal* input is detected until the UPS is

OFF

AC imput

BS signal

※

Power supply output

Power output stop delay time

BU signal* delay

Lets you set the delay time in the event of power failure from when backup

“0 second” is set by factory default.

I/O signal test

Lets you test an I/O signal at the “CONTACT” port of the UPS.

indicator and beep.

the UPS in backup operation when the input power supply is turned OFF. ▪Disable cold start: Can start the UPS only when the input power supply is turned

ON.

▪Enable cold start: Can start the UPS even when the input power supply is turned

OFF.

8 Battery life counter

setting

9 Power switch

function setting

10 Maximum backup

time setting

11 Startup battery level

setting

time setting

Lets you set the battery life counter operation. The battery life counter refers to a function to send notification when battery replacement becomes necessary.

▪Enable battery life counter: Enable the battery life counter. ▪Disable battery life counter: Disable the battery life counter.

Lets you set the operation to be performed when the power is turned OFF by pressing the “Power” switch. ▪Immediately power OFF: Turn the power OFF immediately when the “Power”

switch is pressed.

▪Power OFF after PC shutdown: Send a false power failure signal to the PC when

the “Power” switch is pressed. The shutdown operation is the same as when a power failure occurs.

Lets you set the maximum backup time. In backup operation, when the specified period of time elapses, the output is stopped and the power is turned OFF. ▪Setting range: No setting (∞) or 0.2 to 90 minutes

Lets you set the lower limit for the battery level for automatic restart after UPS shutdown. Restart operation is not performed until the battery level becomes equal to or higher than the specified value. Used if you want to start the system after charging the battery. ▪Setting range: 0 to 90%

stopped. ▪Setting range: 0 to 10 minutes “0 minute” is set by factory default.

time setting

*For details, see 7-1 I/O signal functions.

S8BA-24D24D□□□LF

operation starts until the BU signal* output is turned ON.

▪Setting range: 0 to 90 seconds

▪Four types of output signals can be forcibly turned ON. ▪

The ON/OFF status of two types of input signals can be checked using the status

4 Check and start operation

4-4 UPS operation mode settings

4-4-2 Settings

With the “Beep Stop/Test” switch held down, turn the “Power” switch to move to the UPS operation mode setting.

*While the setting mode is active, the output power supply is turned OFF.

S8BA-24D24D□□□LF

4-4 UPS operation mode settings

4 Check and start operation

(B)

(C)

(A) (D)

(C)

(B)

(C)

(B)

Enable beeper for error only

Disable beeper (default)

Disable auto restart

Enable test for all timings (dafault)

Enable test for startup only

Enable auto restart (default)

Enable test for once every four weeks only

Disable test for all timings

Mode A (default)

Mode B

Auto restart setting

Display

current

setting

Enable beeper for all timings

Beeper setting

Display

current

setting

Display

current

setting

Auto test setting

Display

current

setting

Auto restart mode

setting

(next page)

DC input

"Power" switch "OFF"�

(NO.2)

Operation (A): pressing the “Beep Stop/Test” switch and turn on the “Power” switch. Operation (B): pressing the “Beep Stop/Test” switch below 1 second and then release it. Operation (C): pressing the “Beep Stop/Test” switch 1 second or more and then release it. Operation (D): turning off the “Power” switch.

S8BA-24D24D□□□LF

4 Check and start operation

4-4 UPS operation mode settings

(C)

(B)

(

(B)

(C)

(B)

(C)

(B)

Display

current

setting

(next page)

Display

current

setting

Display

current

setting

Display

current

setting

(previous page)

Battery life counter

setting

Standard voltage sensitivity (default)

High voltage sensitivity

Stop when circuit is closed (default)

Stop when circuit is open

Enable cold start

Enable battery life counter (default)

Disable battery life counter

Disable cold start (default)

Low voltage sensitivity

Logic of Remote

ON/OFF signal setting

Input sensitivity

setting

Cold start setting

S8BA-24D24D□□□LF

4-4 UPS operation mode settings

4 Check and start operation

(C)

(B)

(C)

(B)

Power switch function

setting

Display

current

setting

Immediately power OFF (default)

Power OFF after PC shutdown

(previous page)

0.2 minutes

1 minute

2 minutes

10 minutes

(1 min. step)

Maximum backup time

setting

(0.1 min. step)

Display

current

setting

0.9 minutes

No setting (∞) (Default)

20 minutes

90 minutes

(10 min. step)

(next page)

ion (D): turning off the “Power” switch.

S8BA-24D24D□□□LF

4 Check and start operation

4-4 UPS operation mode settings

(C)

(B)

(C)

(B)

BS signal delay time

setting

Display

current

setting

20%

90%

0% (Default)

(10% step)

10%

Delay 0 minute (default)

Delay 0.2 minutes

Delay 0.5 minutes

Delay 1 minute

Delay 2 minutes

Delay 10 minutes

(1 min. step)

Startup battery level

setting

Display

current

setting

(previous page)

(next page)

S8BA-24D24D□□□LF

4-4 UPS operation mode settings

4 Check and start operation

(C)

(B)

(C)

(B)

1 second delay

2 seconds delay

9 seconds delay

0 second delay (default)

BU signal delay time

setting

Display current

setting

20 seconds delay

10 seconds delay

(1 sec. step)

TR signal* test

BU signal* test

WB signal* test

BL signal* test

I/O signal test

Display

Remote ON/OFF test

BS signal* test

90 seconds delay

(10 sec. step)

(previous page)

*For details, see 7-1 I/O signal functions.

ion (D): turning off the “Power” switch.

S8BA-24D24D□□□LF

4 Check and start operation

4-4 UPS operation mode settings

OFF

Battery Low signal (BL)

Trouble signal (TR)

Backup signal (BU)

Deteriorated battery signal (WB)

Backup power supply stop signal (BS)

Remote ON/OFF signal

Beep

Output signal

Input signal

While the signal is being input, these status indications blink and the beep sounds.

I/O signal test starts I/O signal test ends

Display

I/O signal test operation chart

S8BA-24D24D□□□LF

5-1 Checking the battery

5 Maintenance and inspection

50°C

2.5 years

5 Maintenance and inspection

For cautions when maintaining the UPS, refer to “Caution (for maintenance)” shown in the “Safety precautions” of the beginning of this manual.

5-1 Checking the battery

The battery used in the unit has a limited lifespan. (The life varies depending on your storage/use environment and backup frequency.)

The nearer the end of the life is, the more rapidly deterioration proceeds.

5-1-1 Battery life expectancy

Ambient temperature Battery life expectancy

40°C 5 years

25°C 10 years

*Not a guaranteed performance.

5-1-2 Self-diagnosis test

This test performs a failure diagnosis on the unit and performs a test to check for battery deterioration. Use the procedure below to check whether a circuit failure has occurred inside the unit and whether battery replacement is required.

There are two, automatic testing and manual testing, in the self-diagnosis test as follows.

■ Automatic testing

The self-diagnosis test is automatically performed at the factory settings, at the following timing in the state that the UPS is connected to a commercial power source and the charge of the battery has been completed. User’s operation to start the test is unnecessary.

▪ When the UPS is started up by pressing the “Power” switch ▪ When power has been supplied for four weeks

If the battery is not sufficiently charged, the self-diagnostic test is not performed. The test is automatically performed when the battery is charged completely.

S8BA-24D24D□□□LF

5 Maintenance and inspection

5-1 Checking the battery

When the battery replacement alert “ ” is displayed, the battery needs to be

W = A × 24

■ Manual testing

Press and hold the “Beep Stop/ Te s t ” switch of the UPS for 5 seconds or longer. When the beeper begins to sound intermittently, release the switch.

If the battery is not sufficiently charged, the self-diagnostic test is not performed. The test is not automatically performed even when the battery is charged completely.

By performing the self-diagnosis test, backup operation is started automatically. (“ UPS automatically returns to the normal operation.

 Reference

replaced. Perform replacement by taking the procedures in “5-1 Checking the battery” and “

5-2 Replacing the battery”.

” is displayed during test.) After the test is completed,

5-1-3 Estimated backup time

The backup time varies depending on the capacity of connected devices. After calculating the total capacity of connected devices, refer to the graph of the backup time to obtain an estimation of the initial value of the backup time. (This is also applied to checking the battery.)

1. Convert the total capacity (power consumption) of the connected devices to watts (W).

The indicator can show values in two different ways: amperes (A), and watts (W).

Example 1: DC24V, 145W Example 2: DC24V, 1.8A

For devices that use the A indication, convert the capacity

into W.

Example : 1.8 (A) = 1.8 × 24 (W) = 43.2 (W)

Indication Value

2. Add the values converted into W to obtain the total capacity of the connected devices.

S8BA-24D24D□□□LF

5-1 Checking the battery

5 Maintenance and inspection

100

110

120

0 60 120

180 240

300 360

420 480

120W

240W

360W

480W

Capacity (W)

Backup time (Minutes)

3. Calculate the initial value of the backup time for the total capacity of the connected

devices from the graph below.

▪ Graph of backup time (graph of initial values for products that have not been used

at 25°C). The backup time becomes shorter than the graph (table) below when temperature is lower.

S8BA-24D24D□□□LF

▪ The smaller the capacity of connected devices becomes, the longer the backup

time becomes.

Backup time table (Time unit: minutes)

Capacity（Watt)

Model

30 60 90 120 180 240 300 360 420 480

120W 29 14 9 6

240W 58 29 19 15 9 6

360W 87 43 28 22 14 10 8 6

480W 119 59 39 29 19 15 11 9 8 6

*These backup times are for reference only. Times may vary according to battery life and

external environmental conditions (temperature, etc).

5 Maintenance and inspection

5-2 Replacing the battery

▪Do not replace the battery while the UPS is operating in backup mode. Output will

▪ If an input power supply error such as a power failure occurs when replacing the

5-2 Replacing the battery

This UPS supports hot swapping. Battery replacement is possible both when the power is turned OFF (while the power output is OFF) and when the power is turned ON (while the power output is ON).

 Notes

▪For battery replacement, hold down the “Beep Stop/Test” switch on the unit for 10

seconds or longer to activate the battery replacement mode. Resetting is complete when “ * Perform a reset with the “input power supply” ON.

If you replace the battery without activating the battery replacement mode, the

battery life may not be detected accurately because the battery life counter is not reset.

stop.

” is displayed.

 Reference

battery while in operation, backup cannot be performed and output stops.

▪ When the battery replacement LED lights “ ” up/blinks and beeper sounds, press

the “Beep Stop/ Te s t ” switch for 0.5 seconds to stop the beeper. (Lighting/blinking of the battery replacement LED lights “

” does not disappear.)

S8BA-24D24D□□□LF

5-2 Replacing the battery

5 Maintenance and inspection

The battery used in the unit has a limited lifespan. The life varies depending on The battery deteriorates even if it is stored. The higher the temperature is, the

temperature

starting use

passed after starting use

after starting use

passed after starting use

For the first 3 years

after starting use

When 3 years or more have

passed after starting use

For the first 6 years

after starting use

When 6 years or more have

passed after starting use

5-2-1 Notification that the battery needs to be replaced

When battery replacement becomes necessary, the status indicator starts displaying “ ”.

The battery life is determined by the counter function. The battery life counter operates while input power is supplied after shipment. (When the ambient temperature of the battery is higher than 25°C, the value of the counter will be incremented at a faster pace.)

 Notes

your use environment and backup frequency.

▪ The nearer the end of the life is, the more rapidly deterioration proceeds.

shorter the life becomes.

■ Guidelines for how often to check the battery

Average

ambient

6-month check 3-month check

55°C

50°C

40°C

25°C

For the first year after

For the first 1.5 years

When 1 year or more have

When 1.5 years or more have

S8BA-24D24D□□□LF

5 Maintenance and inspection

5-2 Replacing the battery

5-2-2 Procedure for replacing the ba ttery

For cautions when replacing the battery of the UPS, refer to “Caution for battery replacement)” shown in the “Safety precautions” of the beginning of this manual.

 Notes

Be sure to activate the battery replacement mode before replacing the battery.

▪ For battery replacement, hold down the “Beep Stop/Test” switch on the unit for 10

seconds or longer to activate the battery replacement mode. When the battery replacement mode is activated, the battery life counter is reset. If the battery life counter is not reset, a battery deterioration alarm may occur before the expected life of the battery expires.

S8BA-24D24D□□□LF

5-2 Replacing the battery

5 Maintenance and inspection

“Beep Stop/Test” switch

1. For battery replacement, hold down the “Beep Stop/Test” switch on the unit for 10

seconds or longer to activate the battery replacement mode. When “

▪ Stopping (“Power” switch “OFF”): When the switch is pressed and the beeper

▪ Normal operation (“Power” switch “ON”): When the switch is pressed and the

” is displayed, the activation is completed.

starts sounding continuously, it signals that 10 seconds have elapsed.

beeper starts sounding continuously after sounding intermittently, it signals that 10 seconds have elapsed.

S8BA-24D24D□□□LF

5 Maintenance and inspection

5-2 Replacing the battery

Battery cover's clamp

Battery cover

Battery cover's clamp

2. Push down the battery cover's clamp with a 5 mm or less blade screwdriver.

Push down also the clamp at the opposite side in the same way and remove the battery cover by pulling it toward you.

S8BA-24D24D□□□LF

5-2 Replacing the battery

5 Maintenance and inspection

Lever

Insert a tool such as a screwdriver into the hole and push the battery out toward you

Hole

3. Pull up the lever of the battery control board toward you.

4. Insert a tool such as a screwdriver into the hole (the clamp that keeps the battery in

place) located on the top of the main body and push the battery out a little toward you.

S8BA-24D24D□□□LF

5 Maintenance and inspection

5-2 Replacing the battery

Pullout handle

5. Hold the lever of the battery control board and the handle for pulling out the battery

pack and pull them to remove the battery pack and control board.

6. Arrange a new battery pack for replacement. Make sure that the new battery is

connected to the connector of the battery board in place.

● Replacement battery pack: S8BA-B120L

S8BA-24D24D□□□LF

5-2 Replacing the battery

5 Maintenance and inspection

Pullout handle

Lever

Grooves

Lever

7. Mount the new battery and battery board by inserting them together into the back of the

unit. At that time, align the battery and the PCB with the grooves on the main body.

8. Push down the lever.

S8BA-24D24D□□□LF

5 Maintenance and inspection

5-2 Replacing the battery

Clamp

“Beep Stop/Test” switch

9. Hook the lower clamp of the battery cover onto the main unit.

10. To finish the replacement operation, hold down the “Beep Stop/Test” switch on the

unit for 10 seconds or longer to cancel the battery replacement mode. When “

” or “ ” is displayed, the reset process is completed.

・Stopping (“Power” switch “OFF”): When the switch is pressed and the beeper starts

・Normal operation (“Power” switch “ON”): When the switch is pressed and the

sounding continuously, it signals that 10 seconds have elapsed.

beeper starts sounding continuously after sounding intermittently, it signals that 10 seconds have elapsed.

Battery replacement is now complete.

S8BA-24D24D□□□LF

5-3 Cleaning

5 Maintenance and inspection

5-3 Cleaning

1. Cleaning the UPS

Moisten a soft cloth with water or detergent, squeeze it tightly, and wipe the product

lightly. Do not use chemicals such as thinner and benzene. (They cause deformation or discoloration.)

2. Removing dust from the input terminal block and the output terminal block terminal

blocks of the UPS

Stop all the connected devices and the UPS and turn the “input power supply” OF F.

Then, remove dust with a dry cloth and turn the “input power supply” ON again.

*For information on the connection procedure, see “3-2 Connection”.

S8BA-24D24D□□□LF

6 To perform shutdown processing of the devices when a power failure occurs

6-1 The outline on the UPS monitoring software

Connect to USB port on UPS

Connector

6 To perform shutdown pr ocessing of the

devices when a power failure occurs

6-1 The outline on the UPS monitoring software

6-1-1 What is the Simple Shutdown Software

“Simple Shutdown Software” allows you to automatically shut down the PC when a power failure occurs.

For more information, refer to the manual of this software.

6-1-2 How to connect

1. Connect the UPS to a computer.

▪USB connection: The USB cable that comes with the product can be used. ▪RS232C connection: An optional connection cable (S8BW-C01) is required.

● USB connection

S8BA-24D24D□□□LF

6-1 The outline on the UPS monitoring software

6 To perform shutdown processing of the devices when a power failure occurs

Connect to RS232C port on UPS

Connector

Connect to the RS232C port.

Connector

Connect to the RS232C port of your computer

【

UPS side

】

【

PC side

】

I/O

RJ45

Name

TXD

GND

RXD

1 2 3 4 5 6 7 8

S8BW-C01

Connection

1 2 3 4 5 6 7 8 9

Dsub-9pin

Name

DCD

RxD TxD DTR

SG DSR RTS CTS

I/O

I O O

I O

● RS232C connection

2. Install “Simple Shutdown Software” in your computer.

* For details, see the manual for the above software.

● Cable pin configuration

S8BA-24D24D□□□LF

6 To perform shutdown processing of the devices when a power failure occurs

6-1 The outline on the UPS monitoring software

When the power is restored while auto shutdown processing is being performed

 Notes

▪ If a power failure occurs and then the power is restored while auto shutdown is still

in progress, UPS output will stop temporarily after the set time elapses. After shutdown is finished, do not turn on the computer until the UPS has finished restarting.

S8BA-24D24D□□□LF

7-1 I/O signal functions

7 Using the I/O signal functions

Signal

Description

Backup signal output (BU)

Stays ON during backup operation at a power failure.

at a power failure.

battery life counter expires.

off-scale.

Signal

Description

Input of the UPS stop signal (BS)

When the BS signal is ON (High), the output of the UPS is stopped after the time period specified in advance has elapsed*.

Remote ON/OFF signal

Remote ON/OFF signals can be used to start and stop the UPS, by

the UPS stops operation when this is

use this function.

7 Using the I/O signal functions

7-1 I/O signal functions

● About contact signal

You can develop your unique system based on the following specifications to automate the process at a power failure. You can perform power-failure processing by allowing the system to detect the backup signal (BU) and also perform system shutdown processing by allowing the system to detect the low battery level signal (BL). Also, by inputting the backup stop signal (BS) from the system, you can stop the UPS with a sufficient battery level to prepare for the next occurrence of a power failure.

7-1-1 Type of output signals

The UPS has 4 kinds of output signals.

The output circuit consists of an open collector circuit using a photo coupler.

Low battery level signal output (BL) Goes ON when the battery becomes weak during backup operation

Trouble signal output (TR ) Goes ON when an internal failure of the UPS occurs or when the

Battery replacement signal output (W B) Goes ON when the test determines that battery replacement is

7-1-2 Type of input signals

The UPS has 2 kinds of input signals.

*BS signal delay time

It is possible to set the period of time from when a BS signal is received until the output of the UPS is stopped. The output of the UPS can be stopped by inputting the voltage signal (High).

necessary due to deterioration or when the battery life counter goes

using either an externally connected contact or the ON/OFF status of the open collector circuit. When signal is OFF, the UPS will be turned on. When signal is ON, the UPS will be turned off. In the factory settings, short-circuited. In addition, it is necessary to turn on the “Power” switch of UPS to

S8BA-24D24D□□□LF

7 Using the I/O signal functions

7-1 I/O signal functions

number

Backup signal output (BU)

Remote ON/OFF input (-)

Trouble signal output (TR)

COMMON (COM)

Battery LOW signal output (BL)

Backup stop signal input (BS)

Battery Replacement Signal output (WB)

Remote ON/OFF input (+)

Signal

Description

▪Maximum current: 360mA

▪Current when closed: 10mA max.

▪Input current: 1.7 to 5.1mA

Signal output (BL, TR, BU, WB)

UPS Stop Signal input (BS)

COM

4.7kΩ

680Ω

Remote ON/OFF (+)

Remote ON/OFF (-)

7-1-3 I/O signal port (RJ45 connector )

Outlook of the connector

7-1-4 Contact signal ratings

Item

Signal output (BL, TR, BU, WB) ▪Photo coupler ratings

Remote ON/OFF input ▪Voltage between terminals: DC5V

UPS Stop Signal input (BS) ▪Input voltage: HIGH(ON) DC 8 to 24 V

7-1-5 Contact signal circuit

▪Applicable voltage: DC50V or less

LOW(OFF) DC0.5V or less

Remote ON/OFF input

S8BA-24D24D□□□LF

7-1 I/O signal functions

7 Using the I/O signal functions

and the connected circuit

Relay

Connection cable (Twisted or shielded)

System sideUPS side

COM

24V

4.7kΩ

Internal circuit

Output display LED

［

PLC side

］

OUTPUT UNIT

［

UPS side

］

OUT

Connect the relay output or PNP

type transistor output.

COM

24V

［

UPS side

］

Internal circuit

Input display LED

2.4kΩ

+COM

560Ω

1000pF

［

PLC side

］

INPUT

UNIT

Connect the 24 VDC bipolar input

or NPN input.

7-1-6 Precautions and notes for the use of the I/O signal functions

 Notes

When connecting a device such as a relay that generates counter electromotive force to the signal output circuit, connect diodes that prevent counter electromotive force to both ends of the relay.

Example of BU signal output circuit

7-1-7 Example of the use of the Contact Signal circuit

BS signal example of connection with PLC BU signal example of connection with PLC

S8BA-24D24D□□□LF

8 Troubleshooting

Problem

Check and remedy

is turned ON.

Backup is not possible.

The battery may not be fully charged.

When the “Power” switch is turned OFF, the battery charging operation does not start.

switching.

is pressed.

The battery replacement alert

▪Battery replacement alert “ ” blinks: The battery is judged to be deteriorated in the

See “5-2-1 Notification that the battery needs to be replaced”.

displayed.

possible.

at 0.5-second intervals.

The status indicator blinks

Output stopped due to exceeded connection capacity.

“ ” is displayed on the status indicator.

8 Troubleshooting

Perform the checks shown below if the unit is operating abnormally.

The unit does not start operation. The LED does not appear when the AC input is connected to commercial power and the “Power” switch

The computer stops when a power failure occurs.

Backup is performed too frequently. Frequent switching is performed although a power failure does not occur. You hear the sound of

The power is not turned ON even when the “Power” switch

“ ” is displayed.

Make sure the AC input is securely connected to commercial power. If the status indicator does not display properly after you perform the above operation, there is a problem with the unit. See “4-3 Interpreting beeps and displays”.

Perform the test after charging the battery for at least 4hours. The battery can be charged just by connecting the AC input to a wall outlet. The “Power” switch can be either ON or OFF. When input power supply is connected to the unit and the power is turned ON, battery charging operation starts.

Variations (decrease) in the input power occur frequently. Or, noise may be included that significantly distorts the voltage waveform of the input power. ▪Try and check what happens when connecting the unit to a different wall outl et (commercial

power) located som e distance away from the device consuming a large amount of power.

▪This problem may occur also when you connect many devices to a plug strip or extension cord

connected to the UPS if it is a long or thin cable.

If the status indicator displays “ ” or “ ”, check the voltage of the input power supply.

self-diagnosis test. Backup operation lasts only for a short period of time. Replace the battery. See “

5-1 Checking the battery”.

▪Battery replacement alert “

The battery has been used up to its end-of-life. Replace the battery.

” turned ON: The battery life counter has counted up to the limit.

The UPS life alert “ ” is

The status indicator shows “

”, and the beeper sounds

“ ”, and the beeper sounds continuously.

The UPS has been used up to its end-of-life. Replace the UPS with a new one as soon as

There are too many connected devices. Reduce the number of connected devices until “ ” is displayed on the status indicator.

Turn OFF all power to the unit and connected devices, and reduce the number of connected devices. Then, turn the power to the unit and connected devices back ON and check whether

S8BA-24D24D□□□LF

9-1 Dimensions

9 References

10094

21002.5

9 References

9-1 Dimensions

■ S8BA-24D24D120LF

*Unit: mm / Tolerance:±1mm

S8BA-24D24D□□□LF

9 References

9-1 Dimensions

100

148

1002.5

100270

21002.5

■ S8BA-24D24D240LF

■ S8BA-24D24D360LF／S8BA-24D24D480LF

S8BA-24D24D□□□LF

9-1 Dimensions

9 References

4.5

15 25 25

10 10

1,000（500）＊

25 25 15（5）＊

±0.3

7.3

±0.15

*PFP-50Ndimensionsare

giveninpar ent hes es .

4.5

15 25 25

10 10

1,000

25 25 15

1 1.5

29.2242735

±0.3

11.5 10

M4×8 Panheadscrew

M4springwasher 4.8

1.3

1.8

6.2

1.8

35.5 35.3

■Optional items for rail mounting

●Support rail (Alminum)

PFP-100N PFP-50N

●Support rail (Alminum) PFP-100N2

●Fastening plate (End plate)

PFP-M

Note 1: If the DIN rail is subjected to vibration or shocks, scrap metal can be produced

Note 2：If the product slides sideways, attach an end plate (PFP-M) on both sides of the

S8BA-24D24D□□□LF

because of aluminum abrasion. In such a case, use a steel DIN rail instead.

main body.

9 References

9-2 Characteristic data

20%

40%

60%

80%

100%

0 10 20 30 40 50 60

＜

S8BA-24D24D480LF

＞（

Load rate100%＝480W

）

Load rate

Ambient temperature

（℃）

A：Standard mounting

B：F

ace-up mounting, stationary mounting

20%

40%

60%

80%

100%

0 10 20 30 40 50 60

Ambient temperature

（℃）

Load rate

＜

S8BA-24D24D360LF

＞（

Load rate100%＝360W

）

A：Standard mounting

B：Face-up mounting, stationary mounting

20%

40%

60%

80%

100%

0 10 20 30 40 50 60

A：

＜

S8BA-24D24D120LF

＞（

Load rate100%＝120W

）

＜

S8BA-24D24D240LF

＞（

Load rate100%＝240W

）

Load rate

Ambient temperature

（℃）

Standard mounting, face-up mounting, stationary mounting

9-2 Characteristic data

● Derating curve (Use as a non-UL compliant device)

S8BA-24D24D□□□LF

9-2 Characteristic data

9 References

20%

40%

60%

80%

100%

0 10 20 30 40

A：

＜

S8BA-24D24D480LF

＞（

Load rate100%＝400W

）

Load rate

Ambient temperature

（℃）

Standard mounting

20%

40%

60%

80%

100%

0 10 20 30 40 50 60

A：

＜

S8BA

-24D24D360LF

＞（

Load rate100%＝360W

）

Load rate

Ambient temperature

（℃）

Standard mounting

20%

40%

60%

80%

100%

0 10 20 30 40 50 60

A：

＜

S8BA-24D24D120LF

＞（

Load rate100%＝120W

）

＜

S8BA-24D24D240LF

＞（

Load rate100%＝240W

）

Load rate

Ambient temperature

（℃）

Standard mounting

● Derating curve (Use as a UL compliant device)

S8BA-24D24D□□□LF

9 References

9-2 Characteristic data

100

0 20 40 60 80 100 120

* In backup operation

Output voltage (%)

Output current (%)

*1 In backup operation, the output voltage drops at a load rate of

110% or highe r.

2 In normal operation, the output stops when the input protection

fuse blows out.

＜

120W, 240W, 360W, 480W

＞

● Overcurrent protection curve

S8BA-24D24D□□□LF

OMRON Corporation Industrial Automation Company

Kyoto, JAPAN

Regional Headquarters

OMRON EUROPE B.V.

Wegalaan 67-69, 2132 JD Hoofddorp The Netherlands Tel: (31)2356-81-300/Fax: (31)2356-81-388

OMRON ASIA PACIFIC PTE. LTD.

No. 438A Alexandra Road # 05-05/08 (Lobby 2), Alexandra Technopark, Singapore 119967 Tel: (65) 6835-3011/Fax: (65) 6835-2711

Contact: www.ia.omron.com

OMRON ELECTRONICS LLC

2895 Greenspoint Parkway, Suite 200 Hoffman Estates, IL 60169 U.S.A. Tel: (1) 847-843-7900/Fax: (1) 847-843-7787

OMRON (CHINA) CO., LTD.

Room 2211, Bank of China Tower, 200 Yin Cheng Zhong Road, PuDong New Area, Shanghai, 200120, China Tel: (86) 21-5037-2222/Fax: (86) 21-5037-2200

Authorized Distributor:

In the interest of product improvement, specifications are subject to change without notice.

Cat. No. U702-E1-02

0915

Omron S8BA-24D24D120LF, S8BA-24D24D240LF, S8BA-24D24D360LF, S8BA-24D24D480LF User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Procedure from installation to operation

Table of contents

Read and understand this manual

Safety precautions

Regulations and standards

1-1 Features of this product

1 Overview of the product

1-2 Specifications

2 Preparation

2-1 Unpacking the product

2-2 Checking the contents

2-3 Name of each part

2-4 Diagram of the Input/output circuit block

3 Installation and connection

3-1 Installation

3-1-1 DIN rail ins tallation

3-1-2 Wall or floor mounting procedure

3-2 Connection

3-2-2 Connecting a device to the output terminal block

3-2-3 Connectin g t he inp ut power supply to the inpu t t erminal block

4 Check and start operation

4-1 The name and function for the operation and display

4-1-1 Name of each part

4-1-2 Switch

4-1-3 Beep sound

4-2 Start and stop procedures and basic operation

4-2-1 Start and stop procedures

4-3 Interpreting beeps and displays

4-4 UPS operation mode settings

4-4-1 Settable items and explanations

4-4-2 Settings

5-1 Checking the battery

5 Maintenance and inspection

5-1-1 Battery life expectancy

5-1-2 Self-diagnosis test

5-1-3 Estimated backup time

5-2 Replacing the battery

5-2-1 Notification that the battery needs to be replaced

5-2-2 Procedure for replacing the ba ttery

5-3 Cleaning

6 To perform shutdown processing of the devices when a power failure occurs

6-1 The outline on the UPS monitoring software

6-1-1 What is the Simple Shutdown Software

6-1-2 How to connect

7-1 I/O signal functions

7 Using the I/O signal functions

7-1-1 Type of output signals

7-1-2 Type of input signals

7-1-3 I/O signal port (RJ45 connector )

7-1-4 Contact signal ratings

7-1-5 Contact signal circuit

7-1-6 Precautions and notes for the use of the I/O signal functions

7-1-7 Example of the use of the Contact Signal circuit

8 Troubleshooting

9-1 Dimensions

9 References

9-2 Characteristic data
