Omron E3X-DRT21-S DATASHEET
Communication Unit
For Digital Type Sensor
E3X-DRT21-S (DeviceNet)
User's Manual
Cat. No. Z223-E1-03
Introduction
This manual provides information regarding functions, performance and operating
methods that are required for using Communication Unit for Digital Type Sensor
E3X-DRT21-S (DeviceNet).
This communication unit is a communication unit to be used for Digital Type Sensor
E3X-DA-S Series, E3X-MDA Series, Digital Separate Amplifier Laser Sensor E3C-LDA
Series, and Digital Separate Amplifier Proximity Sensor E2C-EDA Series, which had
been developed with Omron's advanced technologies and successful experience.
Intended Audience
This manual is intended for the following personnel, who must also have knowledge
of electrical systems (an electrical engineer or the equivalent).
Personnel in charge of installing FA systems.
Personnel in charge of designing FA systems.
Personnel in charge of managing FA systems and facilities.
Note that this product must be used in the range of the general specifications.
Version Upgrades
The software version will be upgraded as required. Versions are indicated in the model number as
follows: E3X-DRT21-S Ver.@.
Copyrights and Trademarks
DeviceNet is a registered trademark of the ODVA (Open DeviceNet Vendor Association).
Other product names and company names used in this manual are the trademarks or registered
trademarks of the respective companies. The copyright to the Communication Unit for Digital Type
Sensor belongs to OMRON Corporation.
