OMB-DAQBOARD-3000 Series
Extended Warranty
Program
SM
PCI 1-MHz,16-Bit Multifunction Boards
⻬ Low-Cost, 1-MHz, 16-Bit
Multifunction PCI Boards
⻬ 8 Differential or
16 Single-Ended Analog
Inputs (Software
Selectable per Channel)
⻬ User-Expandable—
Up to 64SE/32DE Analog
Inputs Including
Thermocouple
Measurements
⻬ Four 16-Bit, 1-MHz
Analog Outputs with
Continuous Waveform
Capability
⻬ 24 High-Speed Digital
I/O Lines
⻬ Four 32-Bit Counter
Input Channels with
Quadrature Encoder
Capability
⻬ Ultra Low-Latency
Control Output
Capability (as Low as
2 µs Latency)
⻬ Multiple DMA Channels
⻬ Includes DaqView
Software for Instant
Setup, Real-Time
Viewing, Data Logging,
and Optional Frequency
Domain Analysis
⻬ Support for Visual
Studio and Visual
Studio.NET, Including
Examples for Visual C++,
Visual C#, Visual Basic,
and Visual Basic.NET
⻬ Comprehensive
Drivers for DASYLab
and LabVIEW
⻬ DaqCal Software
Application for Easy
User Calibration
The new OMB-DAQBOARD-3000
Series comprises of highperformance PCI boards offering
16-bit/1-MHz multifunction
synchronous I/O at very competitive
prices. This is accomplished by
incorporating a high level of
integration, while focusing on
features that provide valuable
benefits to users.
The new OMB-DAQBOARD-3000
Series features a 16-bit/1-MHz A/D
converter, 16 analog input channels
(user expandable to 64), up to four
16-bit/1-MHz analog outputs, 24
high-speed digital I/O, 2 timer
outputs, and four 32-bit counters.
All analog I/O, digital I/O, and
counter/timer I/O can operate
synchronously and simultaneously,
guaranteeing deterministic I/O timing
among all signal types. Unique to the
OMB-DAQBOARD-3000 Series is a
high-speed, low-latency, highly
deterministic control output mode
that operates independent of the
PC. In this mode both digital and
analog outputs can respond to
analog, digital, and counter inputs as
fast as 2 µs; at least 1000 times
faster than most other boards that
rely on the PC for decision making.
Other Hardware Features Include:
• Encoder measurements up to
20 MHz, including Z-channel
zeroing
• Frequency and pulse-width
measurements with 20.83 ns
resolution
OMB-DAQBOARD-3000,
shown smaller than actual size
The OMB-DAQBOARD-3000 Series
provides 1-MHz sampling, synchronous
multifunction I/O, analog input
expansion capability and extensive
software support.
• Timing mode that can measure
the time between two counter
inputs to 20.83 ns resolution
• Self calibration
For end-users who would prefer the
same functionality, but with a USB
module, see the OMB-DAQ-3000
Series.
Software
Software support for the
OMB-DAQBOARD-3000 Series
includes support for Visual Studio
and Visual Studio.NET, including
examples for Visual C++, Visual C#,
Visual Basic, and Visual Basic.NET,
plus comprehensive drivers for
DASYLab and LabVIEW.
Also included is DaqView
software for quick and easy setup
and collection of data without
programming, along with DaqCal
software, an application for easy
user calibration.
The new DaqView software that is
included with the OMB-DAQBOARD-3000
Series is a comprehensive
application that enables setup, data
logging, and real-time data viewing
without any programming skills.
The optional DaqView/Pro software
adds features such as direct-toExcel enhancements, FFT analysis,
statistics, etc., for a small,
additional price.
D1
ANALOG INPUT AND
MULTI-FUNCTION CARDS
D1-1
Thermocouple probes
sold separately
TMQSS-125U-12
KMQSS-125U-12
Signal Connections
One 68-pin connector provides
access to the 16SE/8DE analog
input channels, 24 digital I/O lines,
6 counter/timer channels, and up to
4 analog outputs on each
OMB-DAQBOARD-3000 Series board.
An externally accessible HDMI
connector is also provided on the
OMB-DAQBOARD-3000 Series,
enabling a simple connection for the
optional OMB-OMB-PDQ30 analog
channel expansion module.
In addition to standard screw-terminal
options for the OMB-DAQBOARD3000 Series, the OMB-DBK215
BNC connection module can be
used to provide screw-terminal
access to all I/O, plus 16 BNC
connectors that can be user
configured.
Analog Input
The OMB-DAQBOARD-3000 Series
has a 16-bit, 1-MHz A/D coupled with
16 single-ended or 8 differential
analog inputs. Seven softwareprogrammable ranges provide
inputs from ±10 V to ±100 mV full
scale (single-ended ±10 V range on
OMB-DAQBOARD-3006). Each
channel can be software-configured
for a different range, as well as for
single-ended or differential bipolar
input. The hybrid PGIA on the
OMB-DAQBOARD-3000 Series is
guaranteed to settle to the specified
accuracy while operating at the full
1 Msample/s rate.
OMB-DBK215, shown smaller than actual size.
OMB-PDQ30,
shown smaller than
actual size
JMQSS-125U-12
The OMB-DBK215 provides 16 BNC inputs or
outputs and internal screw-terminal connections.
Analog Channel Expansion
Adding additional analog input channels
for the OMB-DAQBOARD-3000
Series is easy using the optional
OMB-PDQ30 expansion module.
The OMB-PDQ30 connects to the
OMB-DAQBOARD-3000 Series
card via an OMB-CA-266-3
cable and does not occupy
a PCI slot. The OMB-PDQ30
provides an additional
48SE/24DE analog inputs or 24
thermocouple inputs, software
configured on a per-channel basis.
The total channel capacity with an
OMB-PDQ30 attached is 64 singleended or 32 differential inputs. The
measurement speed of OMB-PDQ30
channels is the same 1 Msample/s
as with on-board channels.
When configured to measure
thermocouple channels, the system
sample rate is 10 kHz per channel.
This reduction in sample rate
ensures that temperature
measurements are accurate,
low noise, and stable.
The OMB-DAQBOARD-3000
Series also
supports up
to 4 boards
installed into
one PC,
effectively
quadrupling the
number
of channels that can
be attached to one PC.
D1-2
The OMB-TB-100, termination board with
screw terminals, provides access to all
OMB-DAQBOARD-3000 Series I/O. The OMB-TB-100
can be panel mounted or 19” rack mounted using
optional OMB-RACK3 mounting kit.
Synchronous I/O
The OMB-DAQBOARD-3000 Series
can make analog measurements
and read digital and counter inputs,
while synchronously generating up
to 4 analog outputs as well as
digital pattern outputs. Additionally,
digital and counter inputs do not
affect the overall A/D rate because
they use no time slot in the
scanning sequencer.
For example, one analog input
channel can be scanned at the full
1-MHz A/D rate along with digital
and counter input channels. The 1MHz A/D rate is unaffected by the
additional digital and counter
channels. Many other data
acquisition boards provide no
capability to scan digital/counter
channels along with analog
channels, in which case digital and
counter channels must be read
asynchronously, which leads to a
non-deterministic collection of data.
OMB-CA-266-3,
OMB-DAQBOARD-3000
to OMB-PDQ30 cable
Input Scanning
OMB-DAQBOARD-3000 Series Scanning Example
1
µs
t
Programmable,
from 1
µs
up to
6 hours
Scan group
All channels within a scan group are
measured at a fixed 1
µs/channel
All digital and counter channels
sampled at start of scan
Gain can be programmed for
each channel dynamically by
the sequencer
Channels can be sampled
dynamically by the sequencer
t
Channel #2 #4 #3 #2 #5 #6 #8 #12
Gain x1 x10 x5 x2 x5 x20 x50 x100
SE DE DE SE SE DE DE SE or DE
The OMB-DAQBOARD-3000 has
several scanning modes to address
a wide variety of applications. A
512 location scan buffer can be
loaded by the user with any
combination of analog input
channels. All analog input channels
in the scan buffer are measured
sequentially at 1 µs per channel.
The user can also specify that the
sequence repeat immediately, or
repeat after a programmable delay
from 0 to 19 hours, with 20.83 ns
resolution. For example, in the
fastest mode, with a 0 delay, a
single analog channel can be
scanned continuously at
1 Msamples/s; two analog channels
can be scanned at 500 Ksamples/s
each; 16 analog input channels can
be scanned at 62.5 Ksamples/s.
OMB-DAQBOARD-3000 digital
inputs and counter inputs can be
read in several modes. First, via
software the digital inputs or
counter inputs can be read
asynchronously at any time before,
during, or after an analog input scan
sequence. This mode is not
deterministic as to exactly when the
digital or counter input was read
relative to an analog input channel.
In either of the two synchronous
modes, the digital inputs and/or
counter inputs are read with
deterministic time correlation to the
analog inputs. In the once-per-scan
mode, all of the enabled digital
inputs and counter inputs are read
during the first analog
measurement of an
analog input scan
sequence. The
advantage of this
mode is that the digital
and counter inputs do
not occupy an analog
input time slot
and therefore do not
reduce the
available bandwidth
for making analog
input measurements.
For example, assume
all 24 bits of digital
input are enabled, all
four 32-bit counters
are enabled, and eight channels
of analog inputs are in the scan
sequence at the full 1 µs/channel
rate. At the beginning of each
analog input scan sequence, which
would be 8 µs in total duration, all
digital inputs and counter inputs will
be measured and sent to the PC
during the first µs of the analog
scan sequence.
In the other synchronous mode,
digital inputs are scanned every
time an analog input channel is
scanned. For example, if eight
analog inputs are scanned at 1 µs
per channel continuously, and 24
bits of digital inputs are enabled,
then the 24 bits of digital inputs will
be scanned at 24 bits per 1 µs. If
counters are enabled in this mode,
they will be scanned at once per
scan, in the same manner as in
the prior example.
OMB-DAQBOARD-3000,
$899, attached to an
OMB-PDQ30 expansion
module, via an
OMB-CA-266-3 cable,
all shown smaller than
actual size
Output Timing
The digital and analog outputs on
the OMB-DAQBOARD-3000 can be
updated asynchronously or
synchronously in several modes.
In the asynchronous mode, digital
and analog outputs can be updated
at any time before, during, or after
an analog input sequence. The
maximum update rate in this mode is
non-deterministic and is entirely
dependent on the PC processor
speed, the operating system, and
the programming environment.
In the synchronous output modes,
the outputs can be updated directly
from memory in the PC, or as the
direct result of an input from either
an analog channel, digital channel,
or counter channel. When updated
from memory in the PC (via DMA),
the rate by which the output can be
specified in 20.83 ns intervals, and
all outputs can be updated
synchronously at a maximum rate
of 1 µs. For example, all four 16-bit
analog outputs can be generating
different waveforms from PC
memory with a 1 µs per channel
update rate, while up to 16 bits of
digital pattern could be generated
from PC memory concurrently at
the 1 µs per 16-bit update rate.
Outputs can also be specified to
update concurrently with inputs, so
there is an exact timing correlation
between inputs and outputs.
D1
ANALOG INPUT AND
MULTI-FUNCTION CARDS
The other synchronous method of
output control is where an output,
either digital or analog, is
associated with any input—analog,
digital, or counter.
D1-3
OMB-DAQBOARD-3000,
attached to an
OMB-DBK215 BNC
and screw-terminal
module.
The state or level of the output is
determined by the level or state of
an associated input. For example, a
digital output could be programmed
to be a logic 1 when an analog input
exceeds a certain value, or when a
frequency input exceeds a certain
rate. In addition, hysteresis can be
programmed for each limit to
ensure the output is stable near the
transition point. Up to 8 digital
outputs and 4 analog outputs can
be programmed to respond to any
analog, digital, or counter input.
When analog or digital outputs are
used in this mode, the user can
specify two output values,
determined by whether the input is
above or below the limit.
The slowest rate at which an analog
output can respond to an input is
4 µs plus the time period of a scan
sequence. For example, if
4 channels of analog input are
scanned continuously at 4 µs per
scan, then the maximum latency
between an analog input satisfying
a limit, and the output responding,
is 4 + 4 or 8 µs max. The worst-case
response time can also be
improved in several ways.
For example, if a digital output is
correlated to a digital input, then the
worst-case latency can be reduced
to 2 µs total if all digital inputs are
scanned at the 1 µs rate without a
delay period at the end of each scan.
In addition, an output status
channel can be specified in the
input scan sequence buffer so that
users can correlate output state
changes to their respective input
channels within their data buffers
and files. Adding the status channel
takes no additional scan time and
has no effect on the overall
acquisition rate. The status channel
can also be read asynchronously at
any time during an acquisition for
monitoring of the control outputs.
The advantage of this mode is that
the response time can be in the
range of 2 to 20 µs, vs. 1000 or
more microseconds when using
other suppliers’ boards.
Triggering
The OMB-DAQBOARD-3000 Series
supports a full complement of
trigger modes to accommodate any
measurement situation.
Hardware Analog Triggering. The
OMB-DAQBOARD-3000 Series
uses true analog triggering,
whereby the trigger level
programmed by the user sets an
analog DAC, which is then
compared in hardware to the analog
input level on the selected channel.
The result is analog trigger latency
that is guaranteed to be less than
1 µs, significantly shorter than most
data acquisition boards. Any analog
channel can be selected as the trigger
channel, including OMB-PDQ30
expansion channels. The user can
program both the trigger level, as
well as the edge (rising or falling)
and hysteresis.
Digital Triggering. A separate
digital trigger input line is provided,
allowing TTL-level triggering with
latencies guaranteed to be less
than 1 µs. Both the logic levels
(1 or 0), as well as the edge (rising
or falling), can be programmed for
the discrete digital trigger input.
Pattern Triggering. The user can
specify a 16-bit digital pattern to
trigger an acquisition, including the
ability to mask or ignore specific
bits.
Software-Based Channel Level
Triggering. This mode differs from
the modes described previously
because the readings analog,
digital, or counter are interrogated
by the PC in order to detect the
trigger event. Triggering can also be
programmed to occur when one of
the counters reaches, exceeds, or
is within a programmed window.
Any of the built-in counter/totalizer
channels can be programmed as a
trigger source. Triggers can be
detected on scanned digital input
channel patterns as well.
Normally, software-based triggering
results in long latencies, from the
time a trigger condition is detected
until the actual capturing of data
commences. However, the
OMB-DAQBOARD-3000 Series
circumvents this undesirable
situation by use of pre-trigger data.
Specifically, when software-based
triggering is employed, and the PC
detects that a trigger condition has
occurred (which may be thousands
of readings later than the actual
occurrence of the signal), the
DaqBoard driver automatically looks
to the location in memory where the
actual trigger-causing measurement
occurred. The acquired data that is
presented to the user actually
begins at the point where the
trigger-causing measurement
occurs. The maximum latency in
this mode is equal to one scan period.
Stop Trigger. Any of the software
trigger modes described previously,
including scan count, can also be
used to stop an acquisition. Thus an
acquisition can be programmed to
begin on one event, such as a
voltage level, and stop on another
event, such as a digital pattern.
OMB-DAQBOARD-3000 Series Selection Chart and OMB-PDQ30 Expansion Capabilities
Model Number Inputs Ranges I/O Outputs Timers
OMB-DAQBOARD-3006 16 SE 1 24 0 4/2
OMB-DAQBOARD-3005 16SE/8DE 7 24 0 4/2
OMB-DAQBOARD-3000 16SE/8DE 7 24 2 4/2
OMB-DAQBOARD-3001 16SE/8DE 7 24 4 4/2
OMB-DAQBOARD-3005 & OMB-PDQ30 64SE/32DE 7 24 0 4/2
OMB-DAQBOARD-3000 & OMB-PDQ30 64SE/32DE 7 24 2 4/2
OMB-DAQBOARD-3001 & OMB-PDQ30 64SE/32DE 7 24 4 4/2
Analog Input Digital Analog Counters/
D1-4
Pre- and Post-Triggering Modes.
DAC OUT
SIGNAL
I/O
32-bit
data and
address bus
PC (PCI) Bus
ANALOG IN
DIGITAL
CONTROL
DIGITAL I/O
24
Three 8-bit digital I/O ports
6
Four 32-bit counter inputs;
Two 16-bit timer outputs
2
One TTL trigger input;
One analog input pacer clock
16
Input
protection
FIFO
data
buffer
Programmable
sequencer timebase
1 µs to 24 hours for
analog channels and
83.33 ns to 24 hours
for digital channels
System
controller
Configurable
PLD
PCI
controller
Configurable
EEPROM
Four 16-bit
digital-to-analog
converters
8 DE/16 SE
analog input
512-step
random access
channel/gain
sequencer
1-MHz
input clock
x1, 2, 5, 10
Programmable
gain amplifier
x20, 50, 100*
Sequencer reset
16-bit, 1-MHz
analog-to-digital
converter
MUX
A
1-MHz
output
clock
Two or four 16-bit digital-to-analog
converters; not included on
OMB-DAQBOARD-3005 or 3006
ANALOG
CONTROL
A
68-pin SCSI
connector
A
Expansion
HDMI
interface
* OMB-DAQBOARD-3006 has
±10 V input range only
(not included with /3006)
Six modes of pre- and posttriggering are supported, providing
a wide variety of options to
accommodate any measurement
requirement. When using pretrigger, the user must use softwarebased triggering to initiate an
acquisition.
No Pre-Trigger, Post-Trigger Stop
Event. This mode acquires data
upon receipt of the trigger and stops
acquiring upon receipt of the
stop-trigger event.
OMB-DAQBOARD-3000 Series Block Diagram
Fixed Pre-Trigger with PostTrigger Stop Event. In this mode,
the user specifies the number of
pre-trigger readings to be acquired,
after which acquisition continues
until a stop-trigger event occurs.
No Pre-Trigger, Infinite Post-Trigger.
No pre-trigger data is acquired in
this mode. Instead, data is acquired
beginning with the trigger event and
is terminated when the operator
issues a command to halt the
acquisition.
Fixed Pre-Trigger with Infinite
Post-Trigger. The user specifies
the amount of pre-trigger data to
acquire, after which the system
continues to acquire data until the
program issues a command to halt
acquisition.
Variable Pre-Trigger with Post
Trigger Stop Event
(Driver Support Only). Unlike the
previous pre-trigger modes, this
mode does not have to satisfy the
pre-trigger number of readings
before recognizing the trigger event.
Thus the number of pre-trigger
readings acquired is variable and
dependent on the time of the trigger
event relative to the start.
Voltage Range* ± (% of Reading + % Range) ± (ppm of Reading + ppm Range) /°C Noise*
-500 mV to 500 mV 0.031% + 0.018% 14 + 18 4.0
-200 mV to 200 mV 0.036% + 0.012% 14 + 12 5.0
-100 mV to 100 mV 0.042% + 0.018% 14 + 18 9.0
* Specifications assume differential input single channel scan, 1-MHz scan rate, unfiltered, CMV=0.0V, 30 minute warm-up,
** Noise reflects 10,000 samples at 1-MHz, typical, differential short, OMB-CA-G56
In this mode, data continues to be
acquired until the stop trigger event
is detected.
system, without destroying the
factory calibration supplied with the
board. This is made possible by
having 3 distinct calibration tables in
Variable Pre-Trigger with Infinite
Post Trigger (Driver Support Only).
This mode is similar to the mode
described above, except that the
acquisition is terminated upon
receipt of a command from the
program to halt the acquisition.
the OMB-DAQBOARD-3000 Series
on-board EPROM, one that
contains the factory cal and two that
are available for user calibration.
The user can select any of the 3 cal
tables provided: factory, user- or
self-cal tables by API call or within
the software provided.
Calibration
Every range on the
OMB-DAQBOARD-3000 is
calibrated from the factory using a
Accuracy Temperature Coefficient
23°C, ±10°C, 1 Year 0 to 13°C and , 33 to 60°C (cts RMS)
-10 V to 10 V 0.031% + 0.008% 14 + 8 1.5
-5 V to 5 V 0.031% + 0.009% 14 + 9 2.0
-2 V to 2 V 0.031% + 0.010% 14 + 10 1.6
-1 V to 1 V 0.031% + 0.012% 14 + 12 2.5
digital NIST-traceable calibration
method. This method works by
storing a correction factor for each
range on the unit at the time of
calibration. Users can adjust the
calibration of the board while in their
D1-5
Included with each
OMB-DAQBOARD-3000 is DaqCal
software, an easy-to-operate
package that allows users to
calibrate their boards. Two
calibration modes are supported in
DaqCal. Self-cal, a user cal mode
for analog inputs, can be performed
automatically in minutes with
D1
ANALOG INPUT AND
MULTI-FUNCTION CARDS
included software and without the
use of external hardware or
instruments. Self-cal derives its
traceability through an on-board
reference that has a stability of
0.005% per year. The second
mode, user-cal, is for users who
require traceability to international
standards such as NIST. A 61⁄2 digital
multimeter is required and
user-calibration software is included
with step-by-step instructions for full
calibration. A 2-year calibration
period is recommended for the
OMB-DAQBOARD-3000 Series.
Analog Output
(OMB-DAQBOARD-3000 and
OMB-DAQBOARD-3001 only)
Two or four 16-bit, 1-MHz analog
output channels are built into the
OMB-DAQBOARD-3000 Series with
an output range of -10 V to 10 V.
Through the use of bus mastering
DMA, each D/A output can
continuously output a waveform at
up to 1 MHz, which can be read
from PC RAM or a file on the hard
disk. In addition, a program can
asynchronously output a value to
any of the D/As for non-waveform
applications, assuming the D/A is
not already being used in the
waveform output mode. Lastly, each
of the analog outputs can be used in
a control mode, where their output
level is dependent on whether an
associated analog, digital, or
counter input is above or below a
user-specified limit condition.
When used to generate waveforms,
the D/As can be clocked in several
different modes. Each D/A can be
separately selected to be clocked from
one of the sources described below.
Asynchronous Internal Clock.
The on-board programmable clock
can generate updates ranging from
once every 19 hours to 1 MHz,
independent of any acquisition rate.
Synchronous Internal Clock. The
rate of analog output update can be
synchronized to the acquisition rate
derived from 1 MHz to once every
19 hours.
Asynchronous External Clock. A
user-supplied external input clock
can be used to pace the D/A,
entirely independent of analog
inputs.
Synchronous External Clock.
A user-supplied external input clock
can pace both the D/A and the
analog input.
Digital I/O
Twenty-four TTL-level digital I/O
lines are included in the
OMB-DAQBOARD-3000 Series.
Digital I/O can be programmed in
8-bit groups as either inputs or
outputs and can be scanned in
several modes (see Input
Scanning). Ports programmed as
inputs can be part of the scan group
and scanned along with analog
input channels, or they can be
asynchronously accessed via the
PC at any time, including when a
scanned acquisition is occurring.
Two synchronous modes are
supported when scanned along with
analog inputs. In the first mode, the
digital inputs are scanned at the
start of each scan sequence, which
means the rate at which they are
scanned is dependent on the
number of analog input channels
and the delay period. For example,
if 8 analog inputs are enabled with 0
delay period, then the digital inputs
in this mode would be scanned at
once per 8 µs, which is 125 kHz.
In the other synchronous mode, the
enabled digital inputs are scanned
synchronously with every analog
input channel. So in the example
above, the digital inputs would be
scanned at once per µs, or 1 MHz.
If no analog inputs are being
scanned, the digital inputs can be
scanned at up to 12 Msamples/s.
OMB-DAQBOARD-3000,
shown smaller than actual size
The OMB-DAQBOARD-3000 Series
provides 1-MHz sampling, synchronous
multifunction I/O, analog input
expansion capability and extensive
software support.
OMB-CA-G56, 68-conductor
shielded cable from
OMB-DAQBOARD-3000 Series to
OMB-TB-100 or OMB-DBK215.
Digital Outputs and Pattern
Generation
Digital outputs can be updated
asynchronously at any time before,
during, or after an acquisition. Two
of the 8-bit ports can also be used
to generate a 16-bit digital pattern at
up to 12 MHz. The
OMB-DAQBOARD-3000 Series
supports digital pattern generation
via bus mastering DMA. In the same
manner as analog output, the digital
pattern can be read from PC RAM
or from a file on the hard disk.
Digital pattern generation is clocked
in the same four modes as previously
described for analog output.
The ultra low-latency digital output
mode allows a digital output to be
updated based on the level of an
analog, digital, or counter input. In
this mode, the user associates a
digital output bit with a specific input
and specifies the level of the input
where the digital output changes
state.
D1-6
The response time in this mode
depends on the number of input
channels being scanned and can
typically be in the range of
2 to 20 µs.
Counter Inputs
Four 32-bit counters are built into
the OMB-DAQBOARD-3000 Series.
Each of the four counters will accept
frequency inputs of up to 20 MHz,
and each counter channel can be
configured in a variety of modes,
including counter, period, pulse
width, time between edges, or multiaxis quadrature encoder. The
counters can concurrently monitor
time periods, frequencies, pulses,
and other event-driven incremental
occurrences from encoders, pulse
generators, limit switches, proximity
switches, and magnetic pick-ups.
As with all other inputs to the
OMB-DAQBOARD-3000 Series,
the counter inputs can be read
asynchronously under program
control, or synchronously as part
of an analog and digital scan group
based either on an internal
programmable timer or an external
clock source.
The OMB-DAQBOARD-3000
supports quadrature encoders with
up to 2 billion pulses per revolution;
20 MHz input frequencies; and
x1, x2, x4 count modes. With only
A phase and B phase signals,
2 channels are supported. With A
phase, B phase, and Z index
signals, 1 channel is supported.
Each input can be debounced from
500 ns to 25.5 ms (total of 16 selections)
to eliminate extraneous noise or
switch-induced transients. Encoder
input signals must be within -15 V to
15 V and the switching threshold is
TTL (1.3 V). Power is available for
encoders, 5 V at up to 500 mA.
in the same PC. The serial number
on each OMB-DAQBOARD-3000 is
used to differentiate one from
another, and a user-selected name
can be assigned to each board for
easy program documentation. When
multiple boards are installed, all
boards can be operated
synchronously by designating one
board as the master. All of the other
boards are then slaves, and are
synchronized to the master via the
pacer clock, which is externally
routed to the designated slave
boards.
Specifications
General Power Consumption
(per board): 3 W
Operating Temperature:
0 to 60°C (32 to 140°F)
PCI Bus: PCI r2.2 compliant,
universal 3.3 V/5 V signaling
support, compatible with PCI-X
Storage Temperature:
-40 to 80°C (-40 to 176°F)
Relative Humidity:
0 to 95% non-condensing
Vibration:
MIL STD 810E cat 1 and 10
Signal I/O Connector: 68-pin
standard “SCSI Type III” female
connector
Dimensions:
165 W x 15 x 108 mm H
(6.5 x 0.6 x 4.2")
Weight: 160 g (0.35 lb)
DAQVIEW software included with the OMB-DAQBOARD-3000 Series
ANALOG INPUTS
Channels: 16 single-ended (SE)
or 8 differential (DE), programmable
on a per-channel basis as singleended or differential (except for
OMB-DAQBOARD-2006, which is
limited to 16 SE analog inputs with
a fixed range of 10 V)
Expansion: An additional 48
analog inputs per board via
optional OMB-PDQ30 module;
expansion channels have
identical features as the main
board channels (except for
OMB-DAQBOARD-2006, which
is limited to 16 SE analog inputs
with a fixed range of 10 V)
Expansion Connector:
HDMI connector (except for
OMB-DAQBOARD-2006, which
is limited to 16 SE analog inputs
with a fixed range of 10 V)
Over-Voltage Protection:
±30 V without damage
Ranges: Software- or sequencerselectable on a per channel basis,
±10 V, ±5 V, ±2 V, ±1 V, ±0.5 V,
±0.2 V, ±0.1 V (except for
OMB-DAQBOARD-2006, which is
limited to 16 SE analog inputs with
a fixed range of 10V)
Input Impedance: 10 MΩ
single-ended; 20 MΩ differential
Total Harmonic Distortion:
-80 dB type for ±10 V range,
1 kHz fundamental
D1
ANALOG INPUT AND
MULTI-FUNCTION CARDS
Timer Outputs
Two 16-bit timer outputs are built
into the OMB-DAQBOARD-3000,
each capable of generating different
square waves with a programmable
frequency range from 16 Hz to 1 MHz.
Multiple DaqBoards per PC
All of the features described for the
OMB-DAQBOARD-3000 can be
replicated with up to four
OMB-DAQBOARD-3000s installed
D1-7
OMB-DAQBOARD-3000,
attached to an
OMB-TB-100 terminal
board.
Signal to Noise and Distortion:
72 dB type for ±10 V range,
1 kHz fundamental
Bias Current:
40 pA typical (0 to 35°C)
Crosstalk: -75 dB typical DC to
60 Hz; -65 dB typical @10 kHz
Common Mode Rejection:
-70 dB typical DC to 1 kHz
A/D Specifications
Type: Successive approximation
Resolution: 16 bit
Maximum Sample Rate: 1 MHz
Non-Linearity (Integral):
±2 LSB maximum
Non-Linearity (Differential):
±1 LSB maximum
Input Sequencer
Analog, digital, and frequency inputs
can be scanned synchronously,
based on either an internal
programmable timer or an external
clock source. Analog and digital
outputs can be synchronized to
either of these clocks.
Scan Clock Sources: 2
The maximum scan clock rate is the
inverse of the minimum scan period.
The minimum scan period is equal
to 1 µs times the number of analog
channels. If a scan contains only
digital channels, then the minimum
scan period is 83 ns times the
number of digital channels.
1. Internal, programmable
analog channels from 1 µs
to 19 hours in 20.83 ns steps;
digital channels and counters
from 83.33 ns to 19 hours in
20.83 ns steps
2. External, TTL level input
analog channels down to
1 µs min; digital channels and
counters down to 83 ns min
Programmable Parameters per
Scan: Channel (random order), gain
Depth: 512 locations
On-Board Channel-to-Channel
Scan Rate:
Analog: 1 MHz maximum
Digital: 12 MHz if no analog
channels are enabled, 1 MHz
with analog channels enabled
External Acquisition Scan Clock
Input Maximum Rate: 1.0 MHz
Clock Signal Range: Logical zero
0 V to 0.8 V; logical one 2.4 V to 5.0 V
Minimum Pulse Width:
50 ns high, 50 ns low
TRIGGERING
Trigger Sources: 6, individually
selectable for starting and stopping
an acquisition. Stop acquisition can
occur on a different channel than
start acquisition; stop acquisition
can be triggered via modes 2, 4, 5,
or 6 described below.
1. SINGLE-CHANNEL ANALOG
HARDWARE TRIGGER
Any analog input channel can
be software programmed as
the analog trigger channel,
including any of the analog
expansion channel
Input Signal Range:
-10 to 10 V max
Trigger Level:
Programmable (12-bit resolution)
Hysteresis:
Programmable (12-bit resolution)
Latency:
350 ns typ, 1.3 µs max
Accuracy:
±0.5% of reading, ±2 mV offset
Noise: 2 mV RMS
The OMB-TB-100,
termination board with screw
terminals, provides access to all
OMB-DAQBOARD-3000 Series I/O.
The OMB-TB-100 can be panel
mounted or 19” rack mounted using
optional OMB-RACK3 mounting kit.
2. SINGLE-CHANNEL ANALOG
SOFTWARE TRIGGER
Any analog input channel,
including any of the analog
expansion channels, can be
selected as the software trigger
channel. If the trigger channel
involves a calculation, such as
temperature, then the driver
automatically compensates for
the delay required to obtain the
reading, resulting in a maximum
latency of one scan period.
Input Signal Range: Anywhere
within range of the selected
trigger channel
Trigger Level: Programmable
(16-bit resolution), including
“window triggering”
Latency: One scan period max
3. SINGLE-CHANNEL DIGITAL
TRIGGER
A separate digital input is
provided for digital triggering.
Input Signal Range:
-15 V to 15 V
Trigger Level: TTL
Minimum Pulse Width:
50 ns high, 50 ns low
Latency: 100 ns typ,
1.1 µs max
4. DIGITAL PATTERN TRIGGERING
8- or 16-bit pattern triggering on
any of the digital input ports.
Programmable for trigger on
equal, above, below or
within/outside of a window.
Individual bits can be masked
for “don’t care” condition.
Latency: One scan period max
5. COUNTER/TOTALIZER
TRIGGERING
Counter/totalizer inputs can
trigger an acquisition. User can
select to trigger on a frequency
or on total counts that are
equal, above, below, or
within/outside of a window.
Latency: One scan period, max
6. SOFTWARE TRIGGERING
Trigger can be initiated under
program control.
D1-8
ANALOG OUTPUTS
(OMB-DAQBOARD-3000 and
OMB-DAQBOARD-3001 only)
Analog output channels are updated
synchronously relative to scanned
inputs and clocked from either an
internal on-board clock or an
external clock source. Analog
outputs can also be updated
asynchronously, independent of any
other scanning in the system. Bus
mastering DMA provides CPU and
system-independent data transfers,
ensuring accurate outputs that are
irrespective of other system
activities. Streaming from disk or
memory is supported, allowing
continuous, nearly infinite length,
waveform outputs (limited only by
available PC system resources).
Channels: 2
4 (OMB-DAQBOARD-3001)
Resolution: 16-bits
Data Buffer: PC-based memory
Output Voltage Range: ±10 V
Output Current: ±10 mA
Offset Error: ±0.0045 V max
Digital Feedthrough:
<10 mV when updated
DAC Analog Glitch:
<12 mV typical at major carry
Gain Error: ±0.01%
Update Rate: 1 MHz max,
19 hours min (no minimum with
external clock), resolution 20.83 ns
Settling Time: 2 µs max to 1 LSB
for full-scale step
Clock Sources: 4, programmable
1. On-board D/A clock,
independent of scanning
input clock
2. Onboard scanning input clock
3. External D/A input clock,
independent of external
scanning input clock
4. External scanning input clock
DIGITAL I/O
Channels: 24
Ports: 3 x 8-bit, each port is
programmable as input or output
Input Scanning Modes:
2 programmable
1. Asynchronous, under
program control at any
time relative to input scanning
2. Synchronous with input
scanning
(OMB-DAQBOARD-3000);
OMB-CA-G55, 68-conductor
low-cost cable.
Input Characteristics: 10 KΩ
pull up to 5V, 20 pF to common
Input Protection:
±15 kV ESD clamp diodes
Input Levels:
Low: 0 to 0.8 V
High: 2.0 V to 5.0 V
Output Levels:
Low: <0.8 V
High: >2.0 V
Output Characteristics:
Output 12 mA per pin, 200 mA
total continuous
Sampling/Update Rate:
12 MHz max
PATTERN GENERATION OUTPUT
Two of the 8-bit ports can be
configured for 16-bit pattern
generation. The pattern can also be
updated synchronously with an
acquisition at up to 12 MHz.
Counter:
Each of the 4 high-speed, 32-bit
counter channels can be configured
for counter, period, pulse width, time
between edges, or multi-axis
quadrature encoder modes. Counter
inputs can be scanned
synchronously along with analog
and digital scanned inputs, based
on an internal programmable timer
or an external clock source.
Channels: 4 x 32 bit
Input Frequency: 20 MHz max
Input Signal Range: -15 V to 15 V
Input Characteristics: 10 KΩ
pull-up, ±15 kV ESD protection
Trigger Level: TTL
Minimum Pulse Width:
25 ns high, 25 ns low
Debounce Times: 16 selections
from 500 ns to 25.5 ms; positive or
negative edge sensitive; glitch
detect mode or debounce mode
Time Base Accuracy:
30 ppm (0 to 50°C)
Five Programmable Modes:
Counter, period, pulsewidth,
timing, encoder
Counter Mode Options:
Totalize, clear on read,
rollover, stop at all Fs, 16- or
32-bit, any other channel can
gate or decrement the counter
Period Mode Options:
Measure x1, 10, 100 or
1000 periods; 16- or 32-bit;
4 different time bases to
choose from: 20.83 ns, 208.3 ns,
2.083 µs, 20.83 µs, any other
channel can gate the period
measurement
Pulsewidth Mode Options:
16- or 32-bit values; 4 different
time bases to choose from:
20.83 ns, 208.3 ns, 2.083 µs,
20.83 µs, any other channel
can gate the pulsewidth
measurement
Timing Mode Options:
16- or 32-bit values;
4 different time bases to choose
from: 20.83 ns, 208.3 ns,
2.083 µs, 20.83 µs
Encoder Mode Options:
x1, 2, 4 options; 16- or 32-bit
values; Z-channel clearing of
counter; any other channel can
gate the counter
Power Available for Encoders:
5 V @ 500 mA max
Multi-Axis Quadrature
Encoder Inputs:
1 channel with A (phase)
B (phase) and Z (index)
2 channel with A (phase) and
B (phase)
x1, x2 and x4 count modes
Single-ended TTL
Frequency/Pulse Generators
Channels: 2 x 16-bit
Output Waveform: Square wave
Output Rate: 1 MHz base rate
divided by 1 to 65535 (programmable)
High-Level Output Voltage:
2.0 V min @ -1.0 mA; 2.9 V min
@ -400 µA
Low-Level Output Voltage:
0.4 V max @ 400 µA
OMB-PDQ30 EXPANSION MODULE
See the OMB-PDQ30 data sheet for
complete specifications
D1
ANALOG INPUT AND
MULTI-FUNCTION CARDS
D1-9
OMB-CA-G56,
68-conductor shielded cable from
OMB-DAQBOARD-3000 Series to
OMB-TB-1000 or OMB-DBK215.
The OMB-DAQBOARD-3000 Series provides 1-MHz sampling,
synchronous multifunction I/O, analog input expansion capability
and extensive software support.
ALL MODELS AVAILABLE FOR FAST DELIVERY!
To Order Visit omega.com/omb-daqboard-3000 fpr Pricing and Details
Model No. Description
OMB-DAQBOARD-3006 16-bit, 1-MHz PCI data acquisition board with 16 analog inputs with a
OMB-DAQBOARD-3005 16-bit, 1-MHz PCI data acquisition board with 8DE/16SE analog inputs, 7 input
OMB-DAQBOARD-3000 Same as OMB-DAQBOARD-3005 but with two 16-bit, 1-MHz analog outputs
OMB-DAQBOARD-3001 Same as OMB-DAQBAORD-3005 but with four 16-bit, 1-MHz analog outputs
OMB-PDQ30 Analog input expansion module, adds 48SE/24DE channels to
Accessories
Model No. Description
OMB-TB-100 Termination board with screw terminals for access to OMB-DAQBOARD-3000
OMB-RACK3 Rack-mount kit for OMB-TB-100
OMB-DBK215 BNC termination module with 16 BNC connectors and internal screw-terminal
OMB-CA-G55 68-conductor ribbon expansion cable from OMB-DAQBOARD-3000 Series
OMB-CA-G56 68-conductor shielded cable from OMB-DAQBOARD-3000 Series boards to
OMB-CA-G56-6 68-conductor shielded cable from OMB-DAQBOARD-3000 Series boards to
OMB-CA-266-3 HDMI cable, connects OMB-PDQ30 to OMB-DAQBOARD-3000 Series, 0.9 m (3 ft)
Each OMB-DAQBOARD-3000 Series board is supplied with DaqView software, software drivers and complete operator’s manual on CD ROM.
Ordering Example: OMB-DAQBOARD-3005,16-bit, 1-MHz PCI data acquisition board with 8DE/16SE analog inputs, 7 input ranges from
100 mV to 10 V full-scale, 24 digital I/O, four counters and two timers, OMB-TB-100 termination board, OMB-CA-G56 shielded cable
and OMEGACARESM1-year extended warranty for OMB-DAQBOARD-3005 (adds 1 year to standard 1-year warranty).
single-ended 10 V range (not expandable with OMB-PDQ30), 24 digital I/O, four
counters, and two timers; includes DaqView; support for Visual Studio and
Visual Studio.NET, including examples for Visual C++, Visual C#, Visual Basic
and Visual Basic.NET; drivers for DASYLab, and LabVIEW; and DaqCal
software application for easy user-calibration
ranges from 100 mV to 10 V full-scale, 24 digital I/O, four counters and two
timers; includes DaqView; support for Visual Studio and Visual Studio .NET,
including examples for Visual C++, Visual C#, Visual Basic and Visual Basic .NET;
drivers for DASYLab, and LabVIEW; and DaqCal software application
for easy user-calibration
OMB-DAQBOARD-3000 Series; connects via an OMB-CA-266-3 cable
Series I/O; connects via an OMB-CA-G55, OMB-CA-G56 or OMB-CA-G56-6 cable
connections; connects via an OMB-CA-G55, OMB-CA-G56 or OMB-CA-G56-6 cable
boards to OMB-TB-100 or OMB- DBK215, 0.9 m (3 ft)
OMB-TB-100 or OMB-DBK215, 0.9 m (3 ft)
OMB-TB-100 or OMB-DBK215, 1.8 m (6 ft)
D1-10
Loading...
