User’s Guide

http://www.omega.com

e-mail: [e-mail]

CN34

PC Configuration Editor Software

M-???? 0599

1 Introduction

This sheet provides all the information needed to install the PC Configurator
software, including start-up instructions and how to connect the instrument to a
PC.

2 Items Supplied

a) 3.5 in. Installation disk (qty. 5)
b) Configurator cable
c) Instruction sheet

3 PC Requirements

System – A 486 class machine (minimum) with at least 16Mb hard disk space is

required to run this software. Performance depends upon the graphics adaptor,
driver and video mode selected.

Memory – A minimum of 8Mb is required.
MS Windows – Windows 3.xx, 95, 98 or NT.
Power Requirements (RS232C Port) – 4.75V @ 5mA

(RTC and DTR lines combined)

4 Installation

To install the Configurator:
a) Disconnect the PC from any network (if connected).

b) Insert the installation disk (disk 1) into a disk drive.
c)

Windows 3.xx Users only:

Select Run... from the File menu in the Program Manager

d)

Windows 95, 98 and NT Users only:

Select Run... from the Start menu

e) In the Command Line box, type a:\SETUP – if the disk is in drive B, type

b:\SETUP.
f) Choose OK.
g) Follow the instructions on screen.

Licensing, Trademarks and Copywrights

MS Windows is a trademark of the Microsoft Corporation

A – Panel-mounted Indicators and Controllers

5 Starting the PC Configurator

The PC Configurator is started in the same way as other Windows applications:
a) Run MS Windows.
b)

Windows 3.xx Users only:

In the Program Manager, open the Configurator Program Group window and

double-click the Configurator Icon.
c)

Windows 95, 98 and NT Users only:

Select Omega Configurator Vx.x from the Programs option in the Start

menu.
d) The Configurator starts up in one of two ways:

i) If the configurator is being used 'Offline' (i.e. instrument not connected),

the instrument type must be selected (i.e CN3440, DP3410 etc). Click on
the required instrument box to proceed to the startup menu.

ii) If the Configurator is being used 'Online' (i.e. instrument connected and

in Configuration Mode), the instrument type is detected automatically
and the startup menu appears.

e) The startup menu gives three options:

i) Create a new configuration

ii) Open an existing configuration.

iii) Upload a configuration from an instrument.

Click on the required option box to proceed. Online help is available from this

point onwards.

6 Connecting an instrument to a PC – Fig. 6.1.

Connect the instrument to the PC's RS 232 Port using the cable supplied with the
configurator.

B – Wall-/pipe-mounted Indicators and Controllers

Information.

• The COM Port being used by the Configurator must be set up in the
Options Menu.

• Communication between the instrument and the PC is only possible when
the instrument is powered-up and in the Configuration Mode.

C – Chart Recorders

Fig. 6.1 Connecting the Instrument to a PC
