Olympus PT-E05 User Manual

PT-E05

取扱説明書

デジタルカメラ用防水プロテクター

Instruction Manual

Underwater Case for digital camera

 Thank you for buying the Underwater Case PT-E05.  Please read this instruction manual carefully and use the product safely and correctly. Please keep

this instruction manual for reference after reading it.

 Wrong usage may cause damage to the camera inside the Case due to water leakage, and repair

may not be possible.

 Before use, perform an advance check as described in this manual.

Introduction

z Unauthorized copying of this manual in part or in full, except for private use, is prohibited.

Unauthorized reproduction is strictly prohibited.

z OLYMPUS IMAGING CORP. shall not be responsible in any way for lost profits or any claims by third

parties in case of any damage occurring from improper use of this product.

z OLYMPUS IMAGING CORP. shall not be responsible for damage, lost profits, etc. caused by loss of

image data because of defects, disassembly, repair or modification of this product by people other than third parties specified by OLYMPUS IMAGING CORP. or for other reasons.

Please read the following items before use

z This Case is a precision device designed for use at a water depth within 40 m. Please handle it with

sufficient care.

z Please use the Case correctly after sufficient understanding of the contents of this manual in regard

to handling of the Case, checks before use, maintenance, and storage after use.

z The Case must be used in combination with the separately available Waterproof Port. z OLYMPUS IMAGING CORP. shall in no way be responsible for accidents involving immersion of a

digital camera in water. In addition, expenses incurred for damage of internal materials or loss of recorded contents due to water entering the camera will not be compensated.

z OLYMPUS IMAGING CORP. shall not pay any compensation for accidents (injuries or material

damage) at the time of use.

For safe use

This instruction manual uses various pictographs for correct use of the product and to prevent danger to the user and other person, as well as property damage. These pictographs and their meanings are shown below.

WARNING

CAUTION

EN 1

This shows the content regarding assumption of possibility of human death or severe injury in case of handling with disregard of this indication.

This shows the contents regarding assumption of possibility of injury or damage to property in case of handling with disregard of this indication.

WARNING

1 Keep this product out of the reach of babies, infants, and children. There is the possibility of

occurrence of the following types of accidents.

• Injury by dropping onto the body from heights.

• Injury from parts of the body getting caught in parts which open and close.

• Swallowing of small parts. Please consult a physician immediately if any parts have been swallowed.

2 Do not store digital camera with batteries inserted in this product.

Storage with a battery inserted may lead to leakage of the battery liquid and fire hazard.

3 The Case must be used in combination with the Waterproof Port available separately. Remember

that the Case cannot be used without the Waterproof Port.

4 If leakage of water should occur with a camera installed in this product, quickly remove the battery

from the camera. There is the possibility of ignition and explosion from generation of hydrogen gas.

5 This product is made of resin. There is the possibility that injuries may be caused when it becomes

broken due to strong impact with a rock or other hard objects. Please handle it with sufficient care.

6 The silica gel and the silicon grease for this product are inedble.

CAUTION

1 Do not disassemble or modify this product. This may cause water leakage or defect. In case of

disassembly or modification by any party other than those appointed by OLYMPUS IMAGING CORP. the guarantee shall not apply.

2 Do not place this product at locations with abnormally high or low temperatures or at locations with

extreme temperature changes. The product may deteriorate.

3 Opening and closing at locations with much sand, dust, or dirt may impair the waterproof

characteristic and cause water leakage. This should be avoided.

4 This product has been designed and manufactured for use at a water depth within 40 m. Please note

that diving to a depth in excess of 40 m may cause permanent deformation or damage to the Case and the camera inside, or may lead to water leakage.

5 Jumping into the water with the Case in your pocket or in your hand, throwing the Case from a boat

or ship into the water, and other rough handling may cause water leakage. Please handle with sufficient care, when handing it over from hand to hand etc.

6 If the camera on the inside should become wet because of water leakage etc., immediately wipe off

all moisture and confirm the operation.

7 Please remove the O-ring when traveling by air. Otherwise air pressure may make it impossible to

open the Case.

8 For safe use of the digital camera in this product, please read the “Instruction Manual” for the digital

camera carefully.

9 When sealing this product, take sufficient care that no foreign matter gets caught at the O-ring and

the contact surfaces.

0 The camera’s built-in flash cannot be used when the Case is combined with an external Olympus

flash. Also, the camera’s built-in flash cannot be popped up if the hot shoe cable is connected to the camera’s hot shoe. If the built-in flash is forcibly popped up, the connected flash will not work properly and the hot shoe cable may be disconnected from the camera’s hot shoe. In this case, the camera may also be damaged.

a The camera’s built-in flash cannot be used when the camera is in the Case.

EN 2

Batteries

z Use only with an Olympus lithium-ion rechargeable battery (BLM-1) specially for camera use. z Take care that the battery electrodes do not get wet. This may cause trouble or accidents. z Carefully read the instruction manual for the camera about other cautions regarding batteries.

For Prevention of Water Leakage Accidents

When water leakage occurs while this product is being used, repair of the camera housed in this product may become impossible. Please use while observing the following cautions. 1 When sealing this product, make sure that no hair, fiber, sand particle or other foreign matter stick to

the O-ring, and also to the contact surface. Even a single strand of hair or a single grain of sand may cause water leakage. Please check with special care.

Examples of foreign matter sticking to the O-ring

Hair Fibers Grains of sand

2 The O-ring is a consumable product. Please replace it at least once a year with a new piece. Before

each use, perform the proper maintenance.

3 Deterioration of the O-ring will accelerate according to the usage conditions and the storage

conditions. Immediately replace the O-ring with a new piece if it is damaged, cracked, or has lost its elasticity.

4 During maintenace of O-ring, clean the inside of the O-ring groove and confirm the absence of dirt,

dust, sand, and other foreign matter.

5 Apply the specified silicon grease to the O-ring. 6 The waterproof function is not effective if the O-ring is not installed correctly. When installing the O-

ring, take care that it does not project from the groove and that it is not twisted. Also, when sealing the Case, close the lid after confirming that the O-ring has not come out of the groove.

7 This product is an airtight construction made of plastic (polycarbonate). When it is left for a long time

in a car, on a boat, at the beach, or at other places reaching a high temperature, or when it is subjected to uneven external force for a long time, it may be deformed and the waterproof function may be lost. Pay sufficient attention to temperature control. Also do not place heavy objects onto the product during storage or transport, and avoid unreasonable storage.

8 When the O-ring contact surface is pressed strongly from the outside of the Case, or when the Case

is twisted, the waterproof function may be lost. Take care not to exert excessive force.

9 Please use the Case only after performing the advance test and the final check. 0 If you detect any signs of leakage, such as water drops or fogging, while photographing, get out of

the water immediately and remove any moisture from the camera and the Case. Then perform the leak test described in “Final check”.

EN 3

Handling the Product

z Use or storage of the product at the following locations may cause defective operation, defects,

damage, fire, internal clouding, or water leakage. This should be avoided.

• Places of high temperatures, such as in direct sunlight, in a closed vehicle, etc., and/or where extreme differences in temperatures exist.

• Places with open fire

• Water depths in excess of 40 m

• Places with vibrations

• Places with high temperature and humidity or with severe temperature changes

• Places with volatile substances

z This product is made of polycarbonate resin with excellent impact resistance, but it may be damaged

by rubbing against rocks etc. It also may break when it is hit by hard objects or is dropped.

z This product is not a case to soften impacts to the camera inside the product. When this product with

a digital camera inside is subjected to impact or heavy objects are placed onto it, the digital camera may become damaged. Please handle it with sufficient care.

z When the product is not used for a long time, the waterproof performance may drop because of

deterioration of the O-ring etc. Before use, always perform the advance test and the final check.

z Be careful not to apply excessive force to the port connector, TTL cable connector, zoom dial or tripod

seat.

z Do not push the air vent valve from inside. z Do not use the following chemicals for cleaning, corrosion prevention, prevention of fogging, repair or

other purposes. When these are used for the Case directly or indirectly (with the chemicals in vaporized state), they may cause cracking under high pressure or other problems.

Chemicals which cannot be

Volatile organic solvents, chemical detergents

Anticorrosion agent

Commercial defogging agents

Grease other than specified silicone grease

Adhesive

z Do not perform operations other than specified in this instruction manual, do not remove or modify

parts other than specified, and do not use parts other than specified. Any trouble in taking pictures or with the equipment resulting from the above actions shall not be covered by the guarantee.

z OLYMPUS IMAGING CORP. shall in no way be responsible for accidents involving immersion of a

digital camera in water.

z OLYMPUS IMAGING CORP. shall not pay any compensation for accidents (injuries or material

damage) at the time of use.

used

Do not clean the Case with alcohol, gasoline, thinner or other volatile organic solvents or with chemical detergents etc. Pure water or lukewarm water is sufficient for cleaning.

Do not use anticorrosion agents. Pure water is sufficient when washing the metal parts as stainless steel and brass are used.

Do not use commercial defogging agents. Always use the specified desiccant silica gel.

Use only the specified silicone grease for the silicon O-ring, as otherwise the O-ring surface may deteriorate and water leakage may occur.

Do not use adhesive for repairs or other purposes. When repair is required, please contact a dealer or a service station of OLYMPUS IMAGING CORP.

Explanation

EN 4

Contents

Introduction ............................................................................................................................ 1

Please read the following items before use ........................................................................... 1

For safe use ........................................................................................................................... 1

Batteries ................................................................................................................................. 3

For Prevention of Water Leakage Accidents.......................................................................... 3

Handling the Product.............................................................................................................. 4

1.Preparations.............................................................................................................7

Check the contents of the package........................................................................................ 7

Names of the parts........................................................................................................... 8

Install the Waterproof Port. ....................................................................................................9

Attach the hand strap. ............................................................................................................ 9

Mastering basic Case operations. ........................................................................................ 10

How to hold the Case..................................................................................................... 10

How to Press the Shutter Lever..................................................................................... 10

How to use the mode dial knob...................................................................................... 10

How to use the zoom dial............................................................................................... 11

How to control the power switch lever ........................................................................... 11

Connecting the underwater optical fiber cable ............................................................... 12

Removing the TTL cable connector cap ........................................................................ 12

Cleaning the TTL connector........................................................................................... 13

How to connect the hot shoe cable................................................................................ 13

How to attach and detach the camera table .................................................................. 14

2.Advance check of the Case..................................................................................15

Advance test before use ...................................................................................................... 15

Check the waterproof parts of the Case ........................................................................ 15

Advance test .................................................................................................................. 15

3.Installing the digital camera .................................................................................16

Check the digital camera...................................................................................................... 16

Battery Confirmation...................................................................................................... 16

Check the remaining number of pictures ....................................................................... 16

Remove the strap and lens cap from the camera. ......................................................... 16

Remove the eyecup from the digital camera. ................................................................ 16

Remove the filter from the digital camera ...................................................................... 17

Prepare the digital camera. .................................................................................................. 17

Compatible digital camera? ........................................................................................... 17

Checking camera operation ........................................................................................... 17

Open the Case. .................................................................................................................... 17

Attach the zoom and focus gears provided with the optional underwater port to the

lens. ............................................................................................................................... 18

How to attach the camera table to the digital camera .......................................................... 19

Using the UFL-2 underwater electronic flash with the underwater optical fiber cable.......... 19

Using the electronic flash with the TTL cable....................................................................... 20

Insert the digital camera in the Case.................................................................................... 21

EN 5

Insert the silica gel......................................................................................................... 24

Check the loading status. ..................................................................................................... 24

Seal the Case....................................................................................................................... 25

Check the operation of the loaded camera. ......................................................................... 26

Perform the final checks....................................................................................................... 26

Visual Inspection............................................................................................................ 26

Final Test ............................................................................................................................. 27

4.Underwater Shooting ............................................................................................28

How to use the hand strap ................................................................................................... 28

Hold the Case carefully........................................................................................................ 28

Gently press the shutter lever........................................................................................ 28

5.Handling After Shooting .......................................................................................29

Wipe off any waterdrop. ....................................................................................................... 29

Unload the digital camera. ................................................................................................... 30

Wash the Case with pure water. .......................................................................................... 31

Dry the Case. ....................................................................................................................... 31

6.Maintaining the Waterproof Function..................................................................32

Remove the O-ring...............................................................................................................32

Procedure ...................................................................................................................... 32

Remove any sand, dirt, etc. ................................................................................................. 32

Install the O-ring................................................................................................................... 33

How to Apply Grease to the O-ring ...................................................................................... 33

Replace consumable products............................................................................................. 34

Maintenance of the threaded sections on the TTL cable and TTL cable connector............. 34

Maintenance of the TTL Connector Cap .............................................................................. 34

7.Appendix ................................................................................................................35

Q & A on use........................................................................................................................ 35

Specifications....................................................................................................................... 39

EN 6

1. Preparations

Check the contents of the package.

Check that all accessories are in the box. Contact your dealer if accessories are missing or damaged.

• Silica gel

• Hand strap

• Case body (Check that the O-ring is normal.)

• O-ring remover

• Silicone grease

• Waterproof cap maintenance adapter

• Instruction manual (this manual)

• Authorized distributors list/Authorized service centres list

EN 7

Names of the parts

1 Palm grip

*2 Shutter lever

3 Hand strap ring

*4 F (Exposure correction)

button

*5 Mode dial knob

6 Accessory mount 7 TTL cable connector 8 Optical fiber cable insertion

slot

*9 Zoom dial

0 Front cap

*a Power switch lever

b Front lid c Slide lock d Open/close dial

Note:

Case operation parts marked by * corresponds to the operation parts of the digital camera. When the operation parts of the Case are operated, the corresponding functions of the digital camera will operate. For details of the functions, refer to the instruction manual for the digital camera.

*e INFO (Info display) button *f MENU button *g S (Erase) button *h q (Play) button

i Air vent valve j Pickup finder

*k AEL/AFL button *l Control dial knob

m Fn button n T (AF target) button o IS button

*p u button *q Cross-cursor button S *r Cross-cursor button X *s i button *t Cross-cursor button T

*u Cross-cursor button W

v LCD monitor window w LCD hood x

Rear lid

y LCD hood strap z Hot shoe cable connectors

(w/caps)

A Loading guide rails B O-ring (POL-E05B) C Tripod seat D O-ring (POL-E05A) E LCD inner hood F Camera table lock G Camera table H Eyecup storage space I Hot shoe cover storage

space

EN 8

Install the Waterproof Port.

To enable the Case to be used underwater, the separately available Waterproof Port for the camera lens must be installed on the Case. Align the Waterproof Port with the position where the camera lens will be when the camera is loaded in the Case.

• Refer to the instruction manual provided with the Waterproof Port before attaching the Waterproof Port to the Case.

• Apply the provided Silicon grease to the O-ring section of the Waterproof Port and the Waterproof Port mounting thread on the Case.

• Screw the Waterproof Port into the Case by turning it clockwise all the way.

Waterproof Port mount thread

Silicon grease

CAUTION:

The Case should not be used underwater at depths that exceed 40 meters. Even when the attached underwater lens port or other equipment is able to withstand depths exceeding 40 meters, the Case itself cannot be used at depths of more than 40 meters.

Attach the hand strap.

Attach the hand strap to the Case.

Hand strap ring

Hand strap

CAUTION:

• Be sure to install the hand strap correctly as shown above.

• Two hand strap rings are attached to the side of the Case, at the top and bottom of the palm grip. Before using the Case, be sure to attach the ends of the strap to the two hand strap rings.

• OLYMPUS IMAGING CORP. shall bear no responsibility for damage caused by dropping the Case because of incorrect installation of the hand strap.

EN 9

Mastering basic Case operations.

Before loading the digital camera, be sure you are comfortable with the basic Case operations.

How to hold the Case

Press your arms against your sides and hold the Case firmly with both hands at a height where you can comfortably view the image through the Case’s pickup view finder.

Correct Wrong

CAUTION:

• Do not apply excessive force to the waterproof port.

• Be careful not to block the waterproof port’s lens window.

How to Press the Shutter Lever

When pressing the shutter lever, press it gently, so that there will be no movement of the camera.

How to use the mode dial knob

The Case has a mode dial knob that that functions the same way as the mode dial of the digital camera loaded in the Case. After loading the digital camera in the Case, be sure to check that the mode dial knob functions properly before taking any photographs.

CAUTION:

Make sure that the Case’s mode dial knob is properly positioned on camera’s mode dial. Remember that the rotation range of the camera’ s mode dial is limited. Do not turn the Case’s mode dial knob beyond the rotation range of the camera’s mode dial.

EN 10

How to use the zoom dial

The Case’s zoom dial can be used to control the digital camera’s zoom ring or its manual focus ring. Which operation is available depends on the lens being used.

Whether or not the Case’s zoom ring can control the camera’s zoom ring and focus ring depends on which lens is mounted on the digital camera. For details, refer to the instruction manual of the optional waterproof port.

Waterproof

Port

PPO-E01

PPO-E02

PPO-E03 50 mm Macro Not Controllable Controllable

PPO-E03 +PPO-E01

PPO-E04 +PER-E02

PPO-E04 8 mm Fisheye Not Controllable Controllable

PPO-E05 14-42 mm Controllable Not Controllable

*1. The optional PPZR-E04 focusing gear is required. *2. The focus ring on the lens can be turned 360° by using the optional PPZR-E04. *3. The optional PPZR-E05 focusing gear is required.

Applicable

Lens

14-45 mm Controllable Not Controllable

35 mm Macro Not Controllable Controllable

14-54 mm 11-22 mm

50 mm Macro +EC14

7-14 mm Controllable Not Controllable

Zoom Ring Focus Ring Note

Controllable Not Controllable

Not Controllable Not Controllable

How to control the power switch lever

Move the power switch lever of the Case to turn the camera ON and OFF.

Only autofocusing is possible.

The lens’ focus ring can be rotated by 360°.

Only autofocusing is possible.

Manual focusing is possible but the MF ring rotation range is limited to 180°.

Only autofocusing is possible.

The lens’ focus ring can be rotated by 360°.

Only autofocusing is possible.

As of June 2008.

Power switch lever

CAUTION:

When the digital camera has not been operated for a certain period of time, the sleep mode (standby status) will be engaged. The duration before the sleep mode is engaged can be set on the digital camera. To exit the sleep mode (and restore camera functions), press any button (such as the shutter button). For details, refer to your digital camera’s instruction manual.

EN 11

Connecting the underwater optical fiber cable

To connect the separately available UFL-2 underwater flash to the Case using an underwater optical fiber cable (optional), follow the procedures below.

• Put the underwater optical fiber cable plug all the way into the optical fiber cable insertion slot.

Removing the TTL cable connector cap

To perform TTL flash shooting by connecting the separately available underwater flash or other products to the Case using the underwater TTL cable (optional), remove the TTL cable connector cap as described below.

1 Remove the TTL cable connector cap

from the Case.

2 Connect the underwater TTL cable

(optional) to the TTL connector on the Case.

TTL cable connector cap

1 Turn counter

clockwise.

3 Insert into the

connector.

4 Turn the threaded

section of the connector clockwise lightly until it stops.

2 Remove.

Underwater TTL cable

Use this mark to align the position.

 How to attach the TTL cable connector cap to the case

Make sure there is no foreign matter attached to the O-rings inside the cap and on the TTL cable connector. To secure the cap, gently turn it clockwise until it stops.

Check O-rings

2 Gently turn the cap

clockwise until it stops.

1 Attach the cap to

the case.

Cap Connector

EN 12

+ 29 hidden pages
