Olympus D200-L, D-300L User Manual
➧Preparations
➧Taking pictures
➧Displaying pictures on the
LCD monitor
➧Transferring images to a
personal computer
➧Others
Digital Camera Instructions
DD
DD----
33
33
00
00
00
00
LL
LL
DD
DD----
22
22
00
00
00
00
LL
LL
䡲 Before using your camera, read this manual
carefully to ensure correct use.
䡲 We recommend that you take test shots to
get accustomed to your camera before
taking important photographs.
Digital camera
CD-ROM
Serial number
2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
WARNING:
TO REDUCE THE RISK OF FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
IMPORTANT SAFETY
INSTRUCTIONS
1. Read Instructions — All the safety and operating
instructions should be read before the product is operated.
2. Retain Instructions — The safety and operating
instructions should be retained for future reference.
3. Heed Warnings — All warnings on the product and in the
operating instructions should be adhered to.
4. Follow Instructions — All operating and use instructions
should be followed.
5. Cleaning — Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
Exception: A product that is meant for uninterrupted service
and that for some specific reason, such as the possibility of
the loss of an authorization code for a CATV converter, is not
intended to be unplugged by the user for cleaning or any other
purpose, may exclude the reference to unplugging the product
in the cleaning description otherwise required in this section.
3
6. Attachments — Do not use attachments not
recommended by the product manufacturer as they may
cause hazards.
7. Water and Moisture — Do not use this product near water
— for example, near a bath tub, wash bowl, kitchen sink,
or laundry tub; in a wet basement; or near a swimming
pool; and the like.
8. Accessories — Do not place this product on an unstable
stand, tripod, bracket, table, or cart. The product may fall,
causing serious injury to a child or adult, and serious
damage to the product. Use only with a tripod, stand,
bracket. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
9. A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
10.Ventilation — Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation of
the product and to protect from overheating, and these
openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not
be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11. Power Sources — This product should be operated only
from the type of power source indicated on the label. If you
are not sure of the type of power supply to your home,
consult your product dealer or local power company. For
products intended to operate from battery power, or other
sources, refer to the operating instructions.
12. Grounding or Polarization — This product may be
equipped with a polarized alternating-current line plug (a
plug having one blade wider than the other). This plug will
fit into the power outlet only one way. This is a safety
feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to
fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
PORTABLE CART WARNING
(Symbol provided by RETAC)
4
Alternate Warnings — This product is equipped with a threewire grounding-type plug, a plug having a third (grounding)
pin. This plug will only fit into a grounding-type power outlet.
This is a safety feature. If you are unable to insert the plug into
the outlet, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the grounding-type
plug.
13.Power-Cord Protection — Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the
product.
14. Protective Attachment Plug — The product is equipped
with an attachment plug having overload protection. This is
a safety feature. See Instruction Manual for replacement or
resetting of protective device. If replacement of the plug is
required, be sure the service technician has used a
replacement plug specified by the manufacturer that has
the same overload protection as the original plug.
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC – NATIONAL ELECTRICAL CODE
ELECTRIC SERVICE
EQUIPMENT
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
GROUND CLAMP
5
15.Outdoor Antenna Grounding — If an outside antenna or
cable system is connected to the product, be sure the
antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for
the grounding electrode. See figure “Example of antenna
grounding as per National Electrical Code, ANSI/NFPA 70”
16.Lightning — For added protection for this product during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
17.Power Lines — An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
18.Overloading — Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
19. Object and Liquid Entry — Never push objects of any
kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any
kind on the product.
20. Servicing — Do not attempt to service this product
yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
6
21. Damage Requiring Service — Unplug this product from
the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the
product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation.
e) If the product has been dropped or damaged in any
way.
f) When the product exhibits a distinct change in
performance — this indicates a need for service.
22. Replacement Parts — When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer or have
the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
23. Safety Check — Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks to determine that the product is in
proper operating condition.
24.Heat — The product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
Note to CATV system installer
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
Radio and Television Interference
● Change or modifications not expressly approved by the
manufacturer may void the user’s authority to operate this
equipment.
This equipment has been tested and found to comply with the
limits for Class B digital device, pursuant to Part 15 of the FCC
Rules.These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
7
interference to radio communications. However, there is no
guarantee that interference will not occur in particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
Only RS232C serial cable in the set should be connected to
the camera and a PC.
FCC statement
This device complies with Part 15 of FCC rules. Operation
is subject to following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
WARNINGS
• The lithium battery must only be replaced with a lithium
battery model number CR2025 [3V]. Use of another
lithium battery may present the risk of fire or explosion.
• Keep the batteries away from children.
• If a battery is swallowed, see a doctor immediately.
• Dispose of used lithium batteries promptly, in a safe
manner that complies with all applicable laws.
• The lithium battery may present the risk of fire or chemical
burn if mishandled.
• Do not recharge, disassemble, heat above 100°C (212
°F) or dispose of in the fire.
• Before use, wipe the battery clean with a dry soft cloth to
assure good contact.
• Never use metallic tweezers to hold the battery, and
never short circuit the (+) and (–) sides of the battery.
8
Windows is a trademark of Microsoft Corporation.
Macintosh is a registered trademark of Apple Computer
Inc.
All other brand names and product names are
registered.
Legal and other notices
● All contents of this publication are subject to change
without notice.
● Although the contents of this publication have been
carefully checked to avoid errors, some may still
occur. If you are in doubt about any points or find
mistakes or omissions, please contact us.
● No part of this publication may be reproduced or
reprinted except for personal use without the prior
permission of Olympus.
● Olympus makes no representations or warranties
regarding any damages, or benefit expected by using
this unit lawfully, or any request from a third person,
which are caused by the inappropriate use of this unit.
● Olympus makes no representations or warranties
regarding any damages or any benefit expected by
using this unit lawfully which are caused by erasing
the picture data.
● The quality of the picture taken with this camera is
different from the quality of a picture taken with a
conventional compact camera.
9
FOR SAFE USE
Thank you for purchasing the Olympus digital
camera. Before you start to use your new camera,
please read these instructions carefully to obtain
optimum performance and a longer service life from
the unit. Be sure to retain this manual for future
reference.
1.NEVER TRY TO USE THE FLASH WHEN TAKING
PICTURES OF PEOPLE (ESPECIALLY INFANTS) AT
CLOSE RANGE. THE CAMERA’S FLASH MAY DAMAGE
THE SUBJECT’S EYES AT CLOSE RANGE. DO NOT
TAKE PICTURES OF CHILDREN FROM A DISTANCE OF
LESS THAN ONE METER (ABOUT THREE FEET).
2. DO NOT AIM YOUR CAMERA DIRECTLY AT THE SUN
OR OTHER EXTREMELY BRIGHT SUBJECTS. DOING
SO MAY DAMAGE YOUR EYES.
3. DO NOT USE THIS CAMERA IN THE VICINITY OF
FLAMMABLE OR EXPLOSIVE GAS.
4. DO NOT LEAVE THIS CAMERA WITHIN THE REACH OF
INFANTS OR CHILDREN.
• THE CHILD MIGHT PUT THE STRAP AROUND HIS OR
HER NECK. THIS COULD CAUSE STRANGULATION
OR CHOKING.
• THE CHILD MIGHT SWALLOW BATTERIES OR
SMALL ATTACHMENTS. IF THIS HAPPENS,
CONTACT A PHYSICIAN IMMEDIATELY.
WARNINGS
Warning: Ignoring this Warning mark and
operating this product incorrectly may
lead to serious injury or death.
Caution: Ignoring this Caution mark and
operating this product incorrectly
may lead to injury.
0
• THE CHILD MIGHT ACTIVATE THE FLASH FROM TOO
CLOSE AND CAUSE DAMAGE TO HIS OR HER EYES.
• THE CHILD MIGHT DAMAGE THE CAMERA.
5. BATTERY FLUID MAY LEAK, GENERATING HEAT AND
POSSIBLY CAUSING A FIRE OR EXPLOSION.
• DO NOT USE UNSPECIFIED BATTERIES.
• DO NOT THROW BATTERIES INTO A FIRE, OR
EXPOSE TO HEAT.
• DO NOT DISASSEMBLE THE UNIT WITH BATTERIES
INSIDE.
• DO NOT USE NEW BATTERIES AND OLD BATTERIES
TOGETHER. DO NOT MIX DIFFERENT TYPES OF
BATTERIES OR DIFFERENT MANUFACTURERS’
BATTERIES.
• DO NOT CHARGE ALKALINE AND LITHIUM
BATTERIES. IT IS NOT POSSIBLE TO CHARGE
THESE TYPES OF BATTERIES.
• KEEP UNLOADED BATTERIES OUT OF THE REACH
OF INFANTS AND CHILDREN. IF AN INFANT OR
CHILD SWALLOWS THE BATTERIES, CONTACT A
PHYSICIAN IMMEDIATELY.
• DO NOT LOAD THE BATTERIES IN THE OPPOSITE
DIRECTION TO THAT SHOWN IN THIS
INSTRUCTIONS.
6.DO NOT STORE THE CAMERA IN HUMID OR DUSTY
PLACES. THIS MAY CAUSE FIRE OR ELECTRIC SHOCK
7.DO NOT COVER THE FLASH WITH YOUR HAND
DURING OPERATION. DO NOT TOUCH THE FLASH
AFTER FIRING IT CONTINUOUSLY. YOU MAY GET
BURNED.
8.IF YOU DROP THE CAMERA IN WATER OR GET WATER
INSIDE IT, UNLOAD THE BATTERIES IMMEDIATELY
AND CONTACT YOUR NEAREST OLYMPUS SERVICE
CENTER. LEAVING BATTERIES IN A WET CAMERA
MAY CAUSE FIRE OR ELECTRIC SHOCK.
!
1.IF YOU NOTICE AN UNUSUAL SMELL, NOISE, OR
SMOKE EMITTING FROM THIS CAMERA, UNLOAD THE
BATTERIES CAREFULLY TO AVOID BEING BURNED.
CONTACT YOUR NEAREST OLYMPUS SERVICE
CENTER IMMEDIATELY.
2. NEVER ATTEMPT TO DISASSEMBLE THIS CAMERA. IT
CONTAINS HIGH-VOLTAGE CIRCUITRY THAT MAY
CAUSE ELECTRIC SHOCK AND INJURY.
3.UNLOAD THE BATTERIES WHEN NOT USING THE
CAMERA FOR LONG PERIODS. BATTERY HEAT
GENERATION OR FLUID LEAK MAY CAUSE A FIRE OR
INJURY.
4.DO NOT USE THE CAMERA IF THE BATTERY FLUID
HAS LEAKED. LEAKED BATTERY FLUID MAY CAUSE A
FIRE OR ELECTRIC SHOCK. CONTACT YOUR
NEAREST OLYMPUS DEALER OR OLYMPUS SERVICE
CENTER.
5. DO NOT OPERATE THE CAMERA WITH WET HANDS.
AS YOU MAY GET AN ELECTRIC SHOCK.
6.DO NOT STORE THE CAMERA IN ANY PLACE
EXPOSED TO EXCESSIVE HEAT. THIS MAY WEAKEN
THE PARTS OR CAUSE A FIRE.
CAUTIONS
@
䡲 This camera is built with precision electric parts. To avoid
malfunctioons or mechanical problems, do not use or store the
camera in the following places:
• Places exposed to direct sunlight (a beach in summer, for
example).
• Places exposed to excessive heat, humidity, or extreme
variations of temperature and humidity.
•Places exposed to sand or dust.
•Near a fire.
•Near any volatile materials.
•Near a heater, cooler, or humidifier.
•Places exposed to excessive moisture.
•Places exposed to vibrations.
•Inside a car.
•Near magnetic field.
䡲 Do not shake or shock the camera.
䡲 Do not leave the camera with its lens pointing towards direct
sunlight. This will damage the lens.
䡲 Do not leave the camera unused for a long period of time. This
may cause battery leakage. In addition this can lead to problems
including the growth of mold in the camera. Before using the
camera, press the shutter release button to check operation.
䡲 Do not turn the camera when it is mounted on a tripod.
䡲 Do not touch any of the camera’s internal parts.
䡲 Do not use the flash for extended periods as this can cause the
flash to become excessively hot. Do not touch the flash when it
is hot.
HANDLING
䡲 This camera uses four AA alkaline batteries. AA NiCd batteries
or AA nickel hydrocloride batteries or AA lithium batteries can
also be used, but the battery check function will not function
correctly.
䡲 Do not use 3 V manganese batteries. Besides shortening
battery life, manganese batteries may overheat and damage
the camera.
䡲 Use the batteries correctly. Incorrect use of batteries can cause
fluid leak, heat generation, or other damage. When replacing
batteries, be sure to load them correctly.
䡲 The batteries may be temporarily disabled when exposed to
cold temperatures. Try to keep the camera and batteries warm
when using the camera in a cold environment. Batteries that
are weak in cold temperatures will be restored under normal
temperatures.
䡲 Sweat, oil, and so on, can prevent a battery’s terminals from
making electrical contact. To avoid this, wipe both terminals
before loading battery.
䡲 Keep spare batteries on hand when going on a long trip. New
batteries may be difficult or impossible to obtain abroad.
䡲 When you use NiCd batteries and nickel hydrocloride batteries,
make sure they have all been fully charged in the same battery
charger.
䡲 Use NiCd batteries and nickel hydrocloride batteries only after
having carefully read the instructions accompanying them.
BATTERY HANDLING
CARE AND STORAGE
#
CHECK THE CONTENTS
Instructions
Warranty card
User’s card
Windows / Macintosh package includes:
• 232C PC serial cable
• Conversion connector for Windows
• Conversion connector for Macintosh
• CD-ROM software for Macintosh & Windows
• 3.5" floppy disk software
(for Windows 95 / Windows 3.1)
• 3.5" floppy disk software for Macintosh
Option
• AC adaptor
Camera Strap
AA alkaline
batteries
(4 pieces)
Lithium battery
(CR2025 x 1 piece)
$
MAIN FEATURES
䡲 Portable, battery-powered, lightweight, compact design.
䡲 In addition to an optical viewfinder, an LCD monitor is provided for more flexibility when
composing shots and viewing image.
䡲 The highest performance wide-angle lens in its class, offers you the same ease of use as a
conventional compact camera.
䡲 810,000-pixel CCD delivers the highest quality pictures in its class. (D-300L only)
➧“Make sure” indicates items to be double checked.
➧“Note” indicates other information you should be aware of.
➧Actual product may differ slightly from that shown in illustrations.
%
CONTENTS
PREPARATIONS
Names and functions of parts ................................................16
Using the strap.......................................................................18
Loading the batteries..............................................................19
Loading the lithium battery.....................................................19
Turning on and checking the batteries...................................20
Checking the number of remaining pictures...........................21
Points to remember................................................................22
TAKING PICTURES
Taking pictures.......................................................................24
Using the focus lock (D-300L only)........................................27
Autofocus (D-300L only) ........................................................28
Selecting the resolution..........................................................29
Using the flash modes............................................................30
Auto-Flash...........................................................................31
Red-Eye Reducing Flash ...............................................31
Off (flash override)..........................................................32
Fill-In Flash (forced activation).......................................32
Macro mode ...........................................................................33
Working range........................................................................33
Self-timer................................................................................34
Setting the beep sound..........................................................34
DISPLAYING PICTURES ON THE LCD
MONITOR
Turning on the LCD monitor...................................................35
Displaying pictures.................................................................36
Protection...............................................................................36
Erasing pictures .....................................................................37
Slide-Show mode...................................................................39
Multi-Display mode.................................................................39
Adjusting the date and time....................................................40
TRANSFERRING IMAGES TO A PERSONAL
COMPUTER
Personal computer environment............................................41
Installing provided software....................................................42
Connecting to a personal computer.......................................44
Using the household power supply (Optional) .......................45
System chart ..........................................................................46
OTHERS
Questions and answers..........................................................47
Troubleshooting .....................................................................48
Notes on display backlights....................................................52
Specifications.........................................................................53
^
PREPARATIONS
NAMES AND FUNCTIONS OF PARTS
5
0 !
#@
9
&
^
*
4
$ %
)
q
(
8
7
63
1
2
&
1 Shutter release / Erase OK button.............................P. 23
2 Flash mode button......................................................P. 30
3 Erase mode button......................................................P. 37
4 Flash.............................................................................P. 30
5 Control panel...............................................................P. 17
6 Self-timer / Slide-Show button..............................P. 34/39
7 Macro mode / Protect mode button......................P. 33/36
8 Resolution selection / Multi-Display button.........P. 29/39
9 Self-timer signal ..........................................................P. 34
0 Lens
! Lens cover ...................................................................P. 20
@ Computer terminal ......................................................P. 44
# DC input terminal ........................................................P. 45
$ Viewfinder....................................................................P. 17
% Green lamp...................................................................P. 17
^ LCD monitor.................................................................P. 17
& LCD monitor ON/OFF/PLAY button......................P. 26/35
* Previous (–) / Next (+) button ................................P. 36/39
( Lithium battery compartment cover..........................P. 19
) Tripod thread...............................................................P. 34
q Battery compartment cover........................................P. 19
Control Panel / LCD monitor
•Control Panel Icons
Resolution
Erase Battery check
Macro
Self-timer
Flash mode
Frame
number
•LCD Monitor Icons
Resolution
Protect mark
Battery check
Number of
remaining
pictures
Viewfinder Display
Close-up correction marks (p. 33)
Autofocus mark* /
Backlighting correction
mark (p. 27/31)
Write
Green lamp
* Autofocus available only with D-300L.
15
’96 03 21
10:35
Main Unit
Date / Time
Loading...
