ODYS SPACE ONE 10 - QUICK START GUIDE
Function Channel Frequency (MHz)
Output power (dBm)
Output power (mW)
Bluetooth
0
2402 5,1 3,23 802.11b Wi
-Fi 1
2412 16,1 40,73
802.11n (HT40) Wi
-Fi 3
2422 13,2 20,89
802.11b Wi
-Fi 7
2442 16,4 43,65 802.11n (HT40) Wi
-Fi 11
2462 13 19,95
802.11b Wi
-Fi 13
2472 16 39,81
Bluetooth
39
2441 4,4 2,754
Bluet
ooth 78 2480 4,1 2,57
802.11ac (80MHz)Wi
-Fi 42
5210 12,1 16,2
802.11ac (80MHz)Wi
-Fi
157 5785 12,2 16,59
GSM 900 975 880,2 / /
GSM 900 60 902 32,5 1778,2
GSM 900 124 914,8 32,5 1778
DCS 1800 513 1710,4 29,6 912
DCS 1800 700 1747,8 29,8 954,99 DCS 1800
884 1784,6 29,5 891 WCDMA 900
-
low 2937 880,2 22 158,48 WCDMA 900
-
mid 3012 902 22 158,48 WCDMA 900
-
high 3088 914,8 22 158,48 WCDMA 2100
-
low 10562 1920 22 158,48
2 4 7 8
5
9
6
1 8
3
.0
Introduction
Although this product is safe, please observe the information and warnings from the user manual.
The user manual is installed at the devices internal memory and can be accessed over the main
menu. Please refer to the user manual for detailed instructions, conformity and support
information.
To open the user’s manual please tap on the manual icon you can see at the apps list
Please visit our webpage for further information or support.
Turning On/Off
To turn on the device, press and hold the Power button on the unit until you see the boot-up screen then
release. It may take a few minutes to start up the system, please wait before you proceed.
To turn off the device, press and hold the Power button until you see the option “Power Off”, tap on “Power
Off” and then tap on “OK”.
The touchscreen is a capacitive display and designed for precision and responds best when touched with the
smallest point possible. Use the flat pad of your finger to touch the screen.
Tip: This device will sleep with the screen off if it stays inactive for a few seconds. You can briefly press the
Power button to turn on the screen and wake it up.
To light up the screen. Push the lock icon and drag it to the top to unlock.
Power On and Off the Display
- Shortly press the [Power] button to turn off the display.
- Press the [Power] button again shortly turn the display on again.
Getting Started
1. Hybrid slot Compartment for inserting 2x Nano SIM cards or 1x Nano SIM and 1x Miros SD card
2. Headphone jack Sound output for headphones.
3. Microphone
4. Front camera Front-facing camera for taking avatar pictures.
5. Power button Press and hold the [Power] button to turn on or off the device; briefly press the
6. Volume key +/- Press briefly to increase / decrease the volume level.
7. Rear camera Rear-facing camera for taking pictures.
8. Speaker
9. USB-C port Charge and power the tablet with the included power adapter.
Charging Battery
The device has a built-in rechargeable battery. No extra battery installation is required. Just charge the device
when it indicates low battery. To charge the battery, connect the device to any standard wall outlet via the USB
port using the power adaptor. It takes about 5 hours to fully charge the battery.
Note:
a. We advise to use only the delivered power adapter with this tablet.
b. You can operate the device even when it is being charged. But for extended battery life, it is suggested
NOT to use the device when it is charging.
c. It is recommended to charge the battery before you use the device for the first time.
d. For maximum performance, lithium-ion batteries need to be used often. If you don’t use the device often,
be sure to recharge the battery at least once per month.
e. Should the rechargeable battery of the device discharge completely, connect the device (using the
adapter) to the main power source for approximately 5-10 minutes before attempting normal operation.
f. In some cases, devices which have been charged for longer periods of time may not be able to be
switched back on. Should this occur you have to make a Reset. Press and hold for 15 Seconds to reset and
restart the device.
Conformity
We, Axdia International GmbH, hereby declare that this Android Tablet corresponds to the basic
requirements and relevant regulations outlined in guideline 2014/53/EU, 2014/30/EU, 2014/35/EU.
The CE declaration of conformity for this product may be found on the following link:
https://www.odys.de/web/downloads_de.html
Maximum transmission power
for standard Micro SD and Micro SDHC memory cards up to 265GB (FAT32)
Note: The built-in speaker is autom. deactivated when a headphone is connected.
button to turn the screen on or off. Long press (15 sec.) to turn off the device if it
freezes or behaves otherwise abnormally.
Support for USB stick, surf stick, Keyboards and Mouse.
Note: An OTG supporting adapter cable is required (optional).
Please note: Only use connecting cable with a maximum length of 80cm.
Open card compartment - Insert SIM and memory card
Please note: Always switch off the device before inserting
the cards. Otherwise the cards cannot be recognized.
- Hold the unit with the camera facing up.
- Turn the unit over so that the screen is facing down
and place it on a soft surface if necessary. The card
slots are now located on the right side of the device.
- Use the included opening tool and insert the
pointed end into the opening provided on the card
slot.
- Now insert the cards as shown. Make sure that the
cards are aligned correctly. The contacts must point
upwards towards the back of the device. The card and
card reader may be damaged if the cards are not
inserted correctly.
- Close the compartment by gently pushing it back into
the slot. Make sure that the cards you are using are in
the correct orientation and straight so that they do
not jam when inserted.
- To remove or replace the cards, follow the same
procedure.
- To view the files on the card, call up the Explorer by
touching the Explorer icon and selecting the "SD Card"
directory.
Please note:
- We recommend using only Micro SD or SDHC cards up to 265GB capacity.
- When a Micro SD card is inserted in or ejected from the device, it may take few seconds for the
device to update the content.
- Please avoid inserting or ejecting Micro SD card when other operation is running as this may cause
the system hang. Do Not remove the card if the content inside the card is being played.
Transferring Files
- Connect the device to the computer using the supplied USB cable.
- After connecting, the connection is displayed as a notification at the top of the device.
- Open the notification bar. Tap the Notification button for more information.
- Tap again to open the USB settings.
- Activate the data transfer here.
- The internal memory and a memory card, if inserted, are now available via the Explorer of a Windows PC,
for example. Now you can copy files to or from this drive.
- To end this action, disconnect the device from the computer.
Tip: Read the Electronic instructions on the device for an illustrated description.
Note: The pre-installed applications and Android OS occupy a considerable part of capacity –more than 5GB, it
is normal that you see huge difference between available memory space and total capacity.
Caution! The device supports Adobe DRM contents. Adobe Digital Editions (ADE) is required. Please refer to the
user’s manual for closer information’s on how to use DRM protected files.
Home Screen
a. System hints Informs the user if attached memory or updates a re available and also provides
b. System settings System data such as WLAN and battery status as well as the current time are
c. Applications Wipe upwards across the screen to reveal all applications installed on your Tablet
d. Google apps Stay in the know with the Google App
e. Google Duo Simple, high-quality video chat for Android and iOS
f. Google Assistant Just say “Hey Google” or press and hold the home button
g. Google Play Download thousands of apps on Google Play, such as Netflix, Google Stadia, etc.
h. Camera Open the Camera
i. Browser Tap to launch the Browser Chrome to visit your favorite websites
j. SMS Service Read and manage SMS Mes sages
k. Calendar To show the Calendar
l. Phone functions Search through Google Online for everything you want to know
m. Google Search Search for what you want to know about voice control
n. Back soft key Tap to return to the previous screen. If the keyboard is on the screen, tap to close
o. Home soft key Tap to return to the home screen
p. Ongoing application Display of all main applications currently running in the background
Menu soft Key
Google, Android, Google Play and other marks are trademarks of Google LLC.
other system status information.
displayed here. Drag the status bar for further settings at this location down
- You can copy the applications onto the Home screen by pressing and holding
on their icons.
- You can delete the application from the Home Screen by dragging their icons
to the Cross that appears at the top of the screen
the keyboard.
Tap to view the option menu
Note: When you Tap the Menu key from within an application, you will see the
options for that application. But you will not see them on start screen.
Caution! Some apps may show this icon at the top right corner.
Open tray
Insert cards
- Dual Sim use
SIM1 SIM2
- Use with SIM and memory card
SIM1 Micro SD
(Only available in portrait format )
