VANDAL-RESISTANT, BARRIER-FREE
VERSACOOLER® II with VERSAFILLER®

PVSBF, PV8SBF

PVSBF and PV8SBF shall deliver 8.0gph of 50º F water at 90º F

ambient and 80º F inlet water. Model PVSBF is a non-refrigerated
drinking fountain and delivers ambient water. Model PV8SBF shall
include PVSBF and the VersaFiller Sports Bottle Filler with independent
manual activation; lower unit shall include a simple vandal-resistant push
botton to activate the manual flow of water for the cooler. VersaFiller
alcove and activation button contain Freshshield® which utilizes a
silver-based antimicrobial compound that reduces the growth of
micro-organisms and mildew to protect the surfaces from discoloration,
odors and degradation. Basin shall be designed to eliminate splashing
and standing water. Bubbler shall have a tamper-proof, flexible guard,
and operate between 20 and 120 PSI. VersaFiller cabinet finish shall be
brushed stainless steel. Cooling system shall use R-134a refrigerant.
These models satisfy CABO/ANSI A117.1 and comply with ADA
requirements, when properly installed. Shall be listed by Underwriters’
Laboratories to U.S. and Canadian standards and comply with
ANSI/NSF 61G. Units also meet guidelines for children’s accessibility
providing the floor to orifice height is 30” and proper clear floor space is
provided for frontal approach.

Options:

□ Stainless Steel one-piece, tamper-resistant, flex bubbler
□ Oasis Green Filtration System

ADA Compliant when installed in alcove or with right wing wall, or with
accessory apron.

Components in this fountain are lead-free as defined by the Safe
Drinking Water Act Amendments of 1986, and the Lead Contamination
Control Act of 1988.

Limited 5-Year Warranty (Continental limits of the United States and

Canada): 5 Years on the sealed refrigeration system and most
component parts. Detailed warranty certificate enclosed with each water
cooler; sample available upon request.

Standard Features

> Built-in 100 micron strainer stops particles before they enter the
waterway
> Waterways are Lead-Free in Materials and Construction
> Heavy-duty Galvanized Steel frame
> Galvanized Steel louver and bottom screen
> High-efficiency cooling tank and coil

Export Warranty: 1 Year on the sealed refrigeration system and most

component parts. Detailed warranty certificate enclosed with each
drinking fountain; sample copy available upon request.

Models covered by this specification comply with all known Plumbing
Codes. Listed by Underwriters’ Laboratories to U.S. and Canadian
standards.

> Vandal-resistant front push-button
> External stream height adjustment
> Vandal-resistant fasteners

Installation:

> Prior to roughing-in, consult local, state and federal
codes for proper mounting height
> Shipped with complete instructions and wall
mounting brackets

other Oasis Ver

50° F Drinking Water

90° F Ambient Air Temp*

Model

PV8SBF 8.0 8.0 No No 1/4 4.4 500 No Yes 74 Lbs.

PVSBF No Yes 44 Lbs.

Rated Capacity

GPH

Base Rate

GPH Pre-Cooler

Hot ’N Cold™

Model**

Compr.

HP

Fountain Only

115 Volts, 60 HZ

Full Load

Amps

Rated
Watts

Glass Filler
Acc. Option

Cabinet

Color Finish

Net Wt.
Approx.

*Industry Standard Rating Condition 80°F inlet water temperature.

VersaCooler® II, Models PVSBF, PV8SBF

Form 3930 | Rev. 02/11
