MIMXRT1024-EVK
Evaluation kit for the i.MX RT1024 MCU
Arm® Cortex®-M7 core at 500 MHz
4 MB flash, 256 KB RAM
QUICK START GUIDE
GET TO KNOW THE MIMXRT1024-EVK
Power SwitchPower Switch
Power SupplyPower Supply
2
SD SlotSD Slot
ON/OFFON/OFF
User buttonUser button
USB OTGUSB OTG
POR ResetPOR Reset
Audio JackAudio Jack
Figure 1: MIMXRT1024-EVK callouts
Debug USBDebug USB
ArduinoArduino®® and Motor and Motor
Control InterfaceControl Interface
SDRAMSDRAM
i.MX RT1024i.MX RT1024
JTAGJTAG
Arduino and Motor Arduino and Motor
Control InterfaceControl Interface
EthernetEthernet
HOW TO GET STARTED
1. Connect the MIMXRT1024-EVK board to a PC
using the included micro USB cable to USB
connector J23.
2. The MIMXRT1024-EVK board comes
preprogrammed with a demo that will initiate
the LED on the board to flash when plugged
in. When the board is tilted, the green LED
gradually illuminates based on the degree of
tilt on the X-axis.
3. For more information on running the demo,
access to additional out-of-the-box demos and
to download software and tools, please visit:
www.nxp.com/MIMXRT1024-EVK/startnow.
QUICK START GUIDE MIMXRT1024-EVK
3
GET STARTED
Download installation software
and documentation at
com/MIMXRT1024-EVK.
SUPPORT
Visit www.nxp.com/support for a list of phone numbers within your region.
WARRANTY
Visit www.nxp.com/warranty for complete warranty information.
www.nxp.com/MIMXRT1024-EVK
