BFG25A/X
NPN 5 GHz wideband transistor
Rev. 04 — 27 November 2007 Product data sheet
IMPORTANT NOTICE
Dear customer,
As from October 1st, 2006 Philips Semiconductors has a new trade name
- NXP Semiconductors, which will be used in future data sheets together with new contact
details.
In data sheets where the previous Philips references remain, please use the new links as
shown below.
http://www.philips.semiconductors.com use http://www.nxp.com
http://www.semiconductors.philips.com use http://www.nxp.com (Internet)
sales.addresses@www.semiconductors.philips.com use salesaddresses@nxp.com
(email)
The copyright notice at the bottom of each page (or elsewhere in the document,
depending on the version)
- © Koninklijke Philips Electronics N.V. (year). All rights reserved is replaced with:
- © NXP B.V. (year). All rights reserved. If you have any questions related to the data sheet, please contact our nearest sales
office via e-mail or phone (details via salesaddresses@nxp.com). Thank you for your
cooperation and understanding,
NXP Semiconductors
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
2 of 12
NPN 5 GHz wideband transistor BFG25A/X
FEATURES
• Low current consumption
(100 µA to 1 mA)
• Low noise figure
DESCRIPTION
NPN silicon wideband transistor in a
four-lead dual emitter SOT143B
plastic package (cross emitter).
handbook, 2 columns
34
• Gold metallization ensures
excellent reliability.
APPLICATIONS
• RF low power amplifiers, such as
pocket telephones, paging
systems, with signal frequencies
up to 2 GHz.
PINNING
PIN DESCRIPTION
1 collector
2 emitter
3 base
4 emitter
12
Top view
Marking code: %MU.
MSB014
Fig.1 SOT143B.
QUICK REFERENCE DATA
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
V
CBO
V
CEO
I
C
P
tot
h
FE
f
T
G
UM
F noise figure I
collector-base voltage −−8V
collector-emitter voltage −−5V
collector current (DC) −−6.5 mA
total power dissipation Ts≤ 165 °C −−32 mW
DC current gain IC= 0.5 mA; VCE=1V 5080200
transition frequency IC= 1 mA; VCE=1V;
f = 500 MHz; T
amb
=25°C
maximum unilateral power gain IC= 0.5 mA; VCE=1V;
f = 1 GHz; T
= 0.5 mA; VCE=1V;
C
f = 1 GHz; Γ = Γ
I
= 1 mA; VCE= 1 V; f = 1 GHz;
C
Γ = Γ
opt
; T
amb
amb
=25°C
; T
opt
=25°C
amb
=25°C
3.5 5 − GHz
− 18 − dB
− 1.8 − dB
− 2 − dB
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
3 of 12
NPN 5 GHz wideband transistor BFG25A/X
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
V
CBO
V
CEO
V
EBO
I
C
P
tot
T
stg
T
j
Note
1. T
s
THERMAL CHARACTERISTICS
collector-base voltage open emitter − 8V
collector-emitter voltage open base − 5V
emitter-base voltage open collector − 2V
collector current (DC) − 6.5 mA
total power dissipation Ts≤ 165 °C; note 1 − 32 mW
storage temperature −65 150 °C
junction temperature − 175 °C
is the temperature at the soldering point of the collector pin.
SYMBOL PARAMETER CONDITIONS VALUE UNIT
R
th j-s
thermal resistance from junction to soldering point note 1 320 K/W
Note
1. T
is the temperature at the soldering point of the collector pin.
s
CHARACTERISTICS
=25°C unless otherwise specified.
T
j
SYMBOL P ARAMETER CONDITIONS MIN. TYP. MAX. UNIT
I
CBO
h
FE
C
re
f
T
G
UM
F noise figure I
Note
1. G
collector leakage current IE= 0; VCB=5V −−50 µA
DC current gain IC= 0.5 mA; VCE=1V 5080200
feedback capacitance IC=ic= 0; VCB= 1 V; f = 1 MHz − 0.21 0.3 pF
transition frequency IC= 1 mA; VCE=1V;
T
=25°C; f = 500 MHz
amb
maximum unilateral power gain
(note 1)
is the maximum unilateral power gain, assuming S12 is zero and
UM
IC= 0.5 mA; VCE=1V;
f = 1 GHz; T
= 0.5 mA; VCE= 1 V; f = 1 GHz;
C
Γ = Γ
I
Γ = Γ
; T
opt
= 1 mA; VCE= 1 V; f = 1 GHz;
C
; T
opt
amb
amb
amb
=25°C
=25°C
=25°C
G
UM
3.5 5 − GHz
− 18 − dB
− 1.8 − dB
− 2 − dB
10 log
--------------------------------------------------------------
1
S
–
11
2
S
21
2
1
–
dB=
2
S
22
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
4 of 12
NPN 5 GHz wideband transistor BFG25A/X
40
handbook, halfpage
P
tot
(mW)
30
20
10
0
0 50 100 200
150
Fig.2 Power derating curve.
MRC038 - 1
Ts (oC)
100
handbook, halfpage
h
FE
80
60
40
20
0
10
VCE=1V.
3
2
10
1
110
I (mA)
C
Fig.3 DC current gain as a function of collector
current; typical values.
MCD138
10
0.3
handbook, halfpage
C
re
(pF)
0.2
0.1
0
0
IC=ic= 0; f= 1 MHz.
246
Fig.4 Feedback capacitance as a function of
collector-base voltage; typical values.
MCD139
V (V)
CB
handbook, halfpage
6
f
T
(GHz)
4
2
0
0
VCE= 1 V; f = 500 MHz; T
12 4
amb
=25°C.
Fig.5 Transition frequency as a function of
collector current; typical values.
3
MCD140
I (mA)
C
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
5 of 12
NPN 5 GHz wideband transistor BFG25A/X
30
handbook, halfpage
G
gain
(dB)
20
10
0
VCE= 1 V; f = 500 MHz.
GUM = maximum unilateral power gain;
MSG = maximum stable gain.
0.5 1.5 2.0
0 1.0 2.5
UM
MSG
Fig.6 Gain as a function of collector current;
typical values.
MCD141
I (mA)
C
20
handbook, halfpage
gain
(dB)
15
10
5
0
0 1.0 2.5
0.5 1.5 2.0
VCE= 1 V; f = 1 GHz.
GUM = maximum unilateral power gain;
MSG = maximum stable gain.
G
UM
MSG
Fig.7 Gain as a function of collector current;
typical values.
MCD142
I (mA)
C
50
handbook, halfpage
gain
(dB)
40
30
20
10
0
10 10
IC= 0.5 mA; VCE=1V.
GUM = maximum unilateral power gain;
MSG = maximum stable gain.
G
UM
MSG
2
Fig.8 Gain as a function of frequency;
typical values.
MCD143
3
10
f (MHz)
4
10
50
handbook, halfpage
gain
(dB)
40
30
20
10
0
10 10
IC= 1 mA; VCE=1V.
GUM = maximum unilateral power gain;
MSG = maximum stable gain.
G
UM
MSG
2
10
3
f (MHz)
MCD144
4
10
Fig.9 Gain as a function of frequency;
typical values.
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
6 of 12
NPN 5 GHz wideband transistor BFG25A/X
handbook, halfpage
4
F
(dB)
3
2
1
0
−1
10
VCE=1V.
f = 2 GHz
1 GHz
500 MHz
110
IC (mA)
Fig.10 Minimum noise figure as a function of
collector current; typical values.
MCD145
handbook, halfpage
4
F
(dB)
3
2
1
0
10
VCE=1V.
IC = 2 mA
1 mA
0.5 mA
2
3
10
f (MHz)
Fig.11 Minimum noise figure as a function of
frequency; typical values.
MCD146
4
10
handbook, full pagewidth
0.5
0.2
+
j
0
– j
0.2
IC= 1 mA; VCE= 1 V; f = 500 MHz; ZO=50Ω; Maximum stable gain = 15.6 dB; F
unstable region
0.5
MSG
15.6 dB
14 dB
12 dB
Fig.12 Common emitter noise figure circles; typical values.
1
2
6 dB
4 dB
2.5 dB
101520.50.2
*
2
1
= 1.9 dB; Γ
min
= 0.85, 5°; Rn/50 = 2.4.
opt
5
5
MCD147
stability
circle
10
∞
F = 1.9 dB
10
OPT
min
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
7 of 12
NPN 5 GHz wideband transistor BFG25A/X
handbook, full pagewidth
0.5
0.2
+
j
0
– j
0.2
IC= 1 mA; VCE= 1 V; f = 1000 MHz; ZO=50Ω; Maximum stable gain = 12.4 dB; F
unstable region
0.5
0.5 10.2 1052
MSG
12.4 dB
11 dB
9 dB
Fig.13 Common emitter noise figure circles; typical values.
1
2
stability
6 dB
4 dB
3 dB
*
circle
5
10
OPT
F = 2 dB
min
∞
10
5
2
1
= 2 dB; Γ
min
MCD148
= 0.78, 14°; Rn/50 = 2.6.
opt
handbook, full pagewidth
0.5
unstable region
0.2
+ j
0
0
– j
0.2
0.5
IC= 1 mA; VCE= 1 V; f = 2000 MHz; ZO=50Ω; Maximum stable gain = 8.9 dB; F
0.5 10.2 1052
MSG
9 dB
7.5 dB
6 dB
Fig.14 Common emitter noise figure circles; typical values.
1
6 dB
10.2 10520.5
1
4 dB
3 dB
= 2.4 dB; Γ
min
stability
circle
2
F = 2.4 dB
*
2
MCD149
= 0.72, 38°; Rn/50 = 1.9.
opt
OPT
min
5
10
∞
10
5
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
8 of 12
NPN 5 GHz wideband transistor BFG25A/X
handbook, full pagewidth
IC= 1 mA; VCE= 1 V; Zo=50Ω.
1
0.5
0.2
+ j
0
– j
0.2
0.5
0.5 10.2 1052
3 GHz
1
2
40 MHz
2
5
10
∞
10
5
MCD150
Fig.15 Common emitter input reflection coefficient (S11); typical values.
handbook, full pagewidth
IC= 1 mA; VCE=1V.
o
90
o
45
o
0
54321
_
o
45
MCD151
180
o
135
3 GHz
o
40 MHz
_
o
135
_
o
90
Fig.16 Common emitter forward transmission coefficient (S21); typical values.
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
9 of 12
NPN 5 GHz wideband transistor BFG25A/X
o
90
handbook, full pagewidth
IC= 1 mA; VCE=1V.
handbook, full pagewidth
180
o
135
3 GHz
o
_
o
135
0.10.20.30.40.5
40 MHz
_90o
_
45
45
MCD153
o
o
0
o
Fig.17 Common emitter reverse transmission coefficient (S12); typical values.
1
0.5
2
IC= 1 mA; VCE= 1 V; Zo=50Ω.
Fig.18 Common emitter output reflection coefficient (S22); typical values.
0.2
+ j
0
– j
0.2
0.5
0.5 10.2 1052
3 GHz
2
1
40 MHz
MCD152
5
10
∞
10
5
NXP Semiconductors Product specification
Rev. 04 - 27 November 2007
10 of 12
NPN 5 GHz wideband transistor BFG25A/X
PACKAGE OUTLINE
Plastic surface mounted package; 4 leads SOT143B
D
y
e
b
p
B
w M
E
v M
A
B
H
E
A
X
34
Q
A
A
1
21
b
1
e
1
detail X
L
c
p
DIMENSIONS (mm are the original dimensions)
UNIT
mm
OUTLINE
VERSION
SOT143B
1.1
0.9
0 1 2 mm
scale
A
1
A
max
0.1
b
c
D
3.0
1.4
2.8
1.2
REFERENCES
E
b
0.48
0.38
1
p
0.88
0.15
0.78
0.09
IEC JEDEC EIAJ
1.9
e
1.7
H
L
E
1
2.5
2.1
0.45
0.15
p
0.55
0.45
EUROPEAN
PROJECTION
e
ywvQ
0.1 0.10.2
ISSUE DATE
97-02-28
NXP Semiconductors
Rev. 04 - 27 November 2007
11 of 12
Legal information
Data sheet status
BFG25A/X
NPN 5 GHz wideband transistor
Document status
Objective [short] data sheet Development This document contains data from the objective specification for product development.
Preliminary [short] data sheet Qualification This document contains data from the preliminary specification.
Product [short] data sheet Production This document contains the product specification.
[1] Please consult the most recently issued document before initiating or completing a design.
[2] The term ‘short data sheet’ is explained in section “Definitions”.
[3] The product status of device(s) described in this document mayhave changed since this document was published and may differ in case of multipledevices.Thelatestproductstatus
information is available on the Internet at URL
[1][2]
Product status
Definitions
Draft — The document is a draft version only. The content is still under
internal review and subject to formal approval, which may result in
modifications or additions. NXP Semiconductors does not give any
representations or warranties as to the accuracy or completeness of
information included herein and shallhaveno liability for the consequences of
use of such information.
Short data sheet — A short data sheet is an extract from a full data sheet
with the same product typenumber(s) and title. A short data sheet is intended
for quick reference only and should not be relied upon to contain detailed and
full information. For detailed and full information see the relevant full data
sheet, which is available on request via the local NXP Semiconductors sales
office. In case of any inconsistency or conflict with the short data sheet, the
full data sheet shall prevail.
Disclaimers
General — Information in this document is believed to be accurate and
reliable. However, NXP Semiconductors does not give anyrepresentations or
warranties, expressed or implied, as to the accuracyor completeness of such
information and shall have no liability for the consequences of use of such
information.
Right to make changes — NXP Semiconductors reserves the right to make
changes to information published in this document, including without
limitation specifications and product descriptions, at any time and without
notice. This document supersedes and replaces all information supplied prior
to the publication hereof.
Suitability for use — NXP Semiconductors products are not designed,
authorized or warranted to be suitable for use in medical, military, aircraft,
space or life support equipment, nor in applications where failure or
[3]
http://www.nxp.com.
Definition
malfunction of an NXP Semiconductors product can reasonably be expected
to result in personal injury, death or severe property or environmental
damage. NXP Semiconductors accepts no liability for inclusion and/or use of
NXP Semiconductors products in such equipment or applications and
therefore such inclusion and/or use is at the customer’s own risk.
Applications — Applications that are described herein for any of these
products are for illustrative purposes only. NXP Semiconductors makes no
representation or warranty that such applications will be suitable for the
specified use without further testing or modification.
Limiting values — Stress above one or more limiting values (as defined in
the Absolute Maximum Ratings System of IEC 60134) may cause permanent
damage to the device.Limitingvalues are stress ratingsonly and operation of
the device at these or any other conditions above those given in the
Characteristics sections of this document is not implied. Exposure to limiting
values for extended periods may affect device reliability.
Terms and conditions of sale — NXP Semiconductors products are sold
subject to the general terms and conditions of commercial sale, as published
http://www.nxp.com/profile/terms, including those pertaining to warranty,
at
intellectual property rights infringement and limitation of liability, unless
explicitly otherwise agreed to in writing by NXP Semiconductors. In case of
any inconsistency or conflict between information in this document and such
terms and conditions, the latter will prevail.
No offer to sell or license — Nothing in this document may be interpreted
or construed as an offer to sell products that is open for acceptance or the
grant, conveyance or implication of any license under any copyrights, patents
or other industrial or intellectual property rights.
Trademarks
Notice: All referenced brands, product names, service names and trademarks
are the property of their respective owners.
Contact information
For additional information, please visit: http://www.nxp.com
For sales office addresses, send an email to: salesaddresses@nxp.com
NXP Semiconductors
BFG25A/X
NPN 5 GHz wideband transistor
Revision history
Revision history
Document ID Release date Data sheet status Change notice Supersedes
BFG25AX_N_4 20071127 Product data sheet - BFG25AX_3
Modifications:
BFG25AX_3
(9397 750 02767)
BFG25AX_2 19950901 Product specification - BFG25AX_1
BFG25AX_1 19921101 Product specification - -
• Fig. 1 on page 2; Figure note changed
19971029 Product specification - BFG25AX_2
Please be aware that important notices concerning this document and the product(s)
described herein, have been included in section ‘Legal information’.
© NXP B.V. 2007. All rights reserved.
For more information, please visit: http://www.nxp.com
For sales office addresses, please send an email to: salesaddresses@nxp.com
Date of release: 27 November 2007
Document identifier: BFG25AX_N_4
Loading...
