A Sound Investment in Style, Function and Value.

Introducing in-home entertainment, security and communication

systems from NuTone

intercom and intercom systems. You can choose a ‘Master’ station in

a variety of colors and functions to pair up with recess wall-mounted

speakers and remote stations. They are the easiest, most affordable

way to build security, convenience and entertainment into your home.

And with a variety of style and color options, NuTone

to complement the décor of any home.

, the leader in “styled for today” radio

has a system

Stay near those who need you.

Have the peace of mind that you

can easily monitor a child’s room

or stay within earshot of any

family member no matter where

you are in the house.

Table of Contents

4-11 ‘Master’ Stations – IMA-4406, IMA-3303

12-17 Speakers – Music, Door and Intercom

27 Update and Surface Mount Frames

28-29 Apartment Security Entry System –

Know who’s at your door.

No matter where you are in the

home, you’ll be able to answer

your door and safely screen

visitors – making your home more secure.

Music, news, information… any room, any time.

A NuTone® radio intercom system plays your favorite radio stations

throughout the house. The CD system adds crisp, clean music on

demand to any room. You’ll be amazed by the superb sound quality

produced by our systems.

AD-500

18-19 Accessories – Door Chime Modules, Audio Interface Option

20-24 Home and Small Business Intercoms – IM-5000, IMA-516

25 DoorCom and Plug-in Intercoms

26 Rough-in Frames

30-33 Wiring Diagrams

34 Index

IMA-4406 Intercom ‘Master’ Station

Musical Interludes

The IMA-4406 lets you entertain guests with your favorite CD, or listen to one of 12 preprogrammed radio stations as you move throughout the home. The built-in LCD display shows the time, radio station frequency and CD functions at the ‘Master’ station. Battery back-up maintains your memory presets for up to 30 hours. And, for your convenience, you can program the radio to turn on or off at a preset time.

The powerful 20-watt high performance ampliﬁer ﬁlls every part of your home with great sounding audio from any speaker in any room. You can even connect your stereo system to the IMA-4406 allowing audio from your system to be heard throughout your home.

Helping Hand

Tired of yelling for everyone to come to dinner, or to pick up the phone? With the IMA-4406, you can call from any speaker in any room to all other speakers and the person can reply without even pressing a button. Answering the door is just as easy. Think of the added security and convenience of screening visitors without having to open the door. Add an optional gate or door release button to the ‘Master’ station for added convenience. The chime module option plays 10 different musical tunes.

Clearly a Great Choice in Music and Voice.

Room Monitor

How many times have you walked down the hall or up the steps to check on the baby, a small child or a person conﬁned to bed? With the IMA-4406, you can monitor any room from all other speakers as you move from room to room. No heavy receiver to carry or wear on your belt, no batteries to replace, no signal dropouts that occur with wireless baby monitors.

Style Conscious

To enhance the clean style of the ‘Master’ station, all the infrequently used controls and switches are hidden behind easily opened doors. The IMA-4406 ‘Master’ station is offered in three colors – Biscuit, White and Black – to match the décor of your home. The remote stations and controls are offered in many colors, sizes and styles. See pages 6-7 for more details.

IMA-4406 – Indoor and Outdoor Remote Stations

NuTone® remote stations ﬁ ll your home with music... indoors and out

Use up to 9 remote stations and 3 door speakers • Add 6 additional stations

using optional model IAA-440 expansion module • Talk from any station to

all other stations and ‘Master’, answer without pressing any buttons • Answer

door from any station or ‘Master’ • Control radio and CD player from remote

stations; turn on/off, select radio memory channels, CD tracks • Control music

and intercom volume using built-in control

ICA-441WHW

ISA-419

ISA-449WH

IMA-4406 System Components

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

ICA-441WH – Indoor Remote Control

The indoor remote control features all the functions you want from a remote

ISA-445

ICA-441WH

station in a smaller attractive size that takes up little wall space. Use with ceiling or wall mounted speakers, models IS-76, ISA-78 or IS-9615. (One 25 ohm speaker per control.)

ISA-445 – Indoor Remote Station

The 5" indoor remote station is our most popular speaker combining function with clear, crisp sound quality.

ISA-448 – Indoor Remote Station

Enjoy richer bass sound with

ISA-448

the enhanced speaker quality of our 8" indoor remote station.

ICA-441WHW – Outdoor Remote Control

Our outdoor remote control gives you access to all the features of your system while outdoors. Designed to be used with wall or overhang mounted speaker model IS-79. Includes surface mounting frame. (One 25 ohm speaker per control.)

ISA-419 – Outdoor Remote Station

Our 5" outdoor cast metal remote speaker provides quality sound in any weather. Use on patio, deck or at the pool to stay in touch with those inside or to listen to music.

ISA-449WH – Outdoor Remote Station

Enhance the ambiance of the outdoors

with the NuTone

5" outdoor remote speaker. Ideal for use on a patio or deck. Includes surface mounting frame.

‘Master’ Stations

IMA-4406BL IMA-4406L IMA-4406WH

IAA-440 (Expansion Kit – adds an additional 6 stations)

Indoor Remote Stations/Control

ICA-441WH

ISA-445BL ISA-445D ISA-445L ISA-445WH

ISA-448BL ISA-448L ISA-448WH

Outdoor Remote Stations/Control

ICA-441WHW

ISA-419AB ISA-419PB ISA-419WH

ISA-449WH

Black

Biscuit

Bright White

Bright White 7" 4" 1-1/16" 7/8" IR-91

Black

Sable Brown

Biscuit

Bright White

Black

Biscuit

Bright White

Bright White 7" 4" Surface Mount 2-1/2" –

Antique Brass

PolishedB rass

Bright White

Bright White 6-11/16" 8-9/16" Surface Mount 3-1/2" –

17-3/4" 10-1/8" 3-1/2" 1-7/8" IR-105

6-5/16" 8-1/4" 1-7/16" 7/8" IR-50

10" 11-1/4" 2-3/4" 7/8" IR-80

6-1/4" 8-3/16" 1-7/8" 7/16"

Intercom Options:

See p. 19 for chime modules and audio wall plate, p. 12-13 for music speaker options, p. 14-17 for door and intercom speakers and p. 27 for update and surface frames.

NuTone® products should not be installed on outside walls unless they are speciﬁ cally designed for outside use.

NuTone

Intercom Wire is an integral part of all NuTone® Radio Intercom Systems; such wire has been designed to enable full system performance and to minimize outside interference, dimmer noise, radio frequency interference and other reception problems. If wire other than NuTone applicable to any defect or problem relating to the use of non-NuTone

Installation Wire: NuTone cable: 100 ft. (IW-2-100), 500 ft. (IW-2-500), twisted-pair 18/2: (S-143-500). For installations where UL listed wire is speciﬁ ed, add ‘UL’ sufﬁ x to model number when ordering.

IMA-4406 ‘Master’ s tation powered by (2) 18 volt, 72 VA transformers NuTone

*ISA-419AB, ISA-419PB and ISA-419WH use model IR-50 rough-in for non-masonry installation or model IR-55 rough-in when mounting to stucco or brick.

speciﬁ ed wire is used in the installation of a NuTone® Radio Intercom, the Warranty shall not be

3-twisted-pair/6-wire cable: 200 ft. (IW-6-200), 1000 ft. (IW-6-1000), NuTone® twisted-pair 22/2

speciﬁ ed wire.

model 801T supplied with the IR-105 rough-in.

Rough-In

Model No.

IR-50*

IR-55*

IMA-3303 Intercom ‘Master’ Station

Broadcast Your Favorite Station

The IMA-3303 becomes part of your home, ﬁlling it with great

sounding music, or the crack of the bat as you listen to your favorite

team’s broadcast. The built-in AM/FM radio has 12 memory channels

which you can select from any remote speaker in the home. Battery

backup maintains memory presets for up to 30 hours. Preset the timer

to turn the radio on or off as you choose.

Helping Hand

It always seems to happen. You’re on the opposite side of the house

when someone comes to the door. Now you can safely screen visitors

from wherever you are in the home. Add an optional gate or door

release button to the ‘Master’ station for added convenience. Add an

optional chime to the ‘Master’ unit to ensure you hear the door chime

from every speaker in your house.

Convenient and Simple to Operate.

Room Monitor

The IMA-3303 offers peace-of-mind by allowing you to listen in on a

baby or a person conﬁned to bed. The rooms being monitored can be

heard at all speakers, giving you the freedom to move around while

still keeping in touch.

Style Conscious

The IMA-3303 ‘Master’ station is offered

in white and biscuit. The rounded corners

and edges provide a soft, clean style.

All the infrequently used controls are

tucked neatly behind the drop down doors.

Remote station and controls are available

in a variety of colors, sizes and styles,

including both indoor and outdoor options.

See pages 10-11 for more details.

IMA-3303 – Indoor and Outdoor Remote Stations

NuTone® remote stations ﬁ ll your home with music... indoors and out!

Use up to 13 remote stations and 3 door speakers • Talk from any station to

all other stations and ‘Master’ • Answer door from any station or ‘Master’ •

Control radio from remote stations; turn on/off, select radio memory channels

• Control music and intercom volume using built-in control

ICA-331WHW

ISA-319

ISA-339WH

ICA-331WH

ISA-335

ISA-338

ICA-331WH – Indoor Remote Control

The indoor remote control features all the functions you want from a remote station in a smaller attractive size that takes up little wall space. Use with ceiling or wall mounted speakers, models IS-76, ISA-78 or IS-9615. (One 25 ohm speaker per control.)

ISA-335 – Indoor Remote Station

The 5" indoor remote station is our most popular speaker combining function with clear, crisp sound quality.

ISA-338 – Indoor Remote Station

Enjoy richer bass sound with the enhanced speaker quality of our 8" indoor remote station.

ICA-331WHW – Outdoor Remote Control

Our outdoor remote control puts all the basic functions of your system within your reach while outdoors. Designed to be used with wall or overhang mounted speaker model IS-79. Includes surface mounting frame. (One 25 ohm speaker per control.)

ISA-319 – Outdoor Remote Station

Our 5" outdoor cast metal remote speaker provides quality sound in any weather. Use on patio, deck or at the pool to stay in touch with those inside or to listen to music.

ISA-339WH – Outdoor Remote Station

Enhance the ambiance of the outdoors

with the NuTone

5" outdoor remote speaker. Ideal for use on a patio or deck. Includes surface mounting frame.

IMA-3303 System Components

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

‘Master’ Stations

IMA-3303L IMA-3303WH

IMA-3303WHK Package: (1) IMA-3303WH, (3) ISA-335WH, (1) IS-67WH, (1) IA-28

IR-104K Package: (1) IR-104, (3) IR-50, (1) IR-6, IWA-3-200UL, IW-2-100UL –

Indoor Remote Stations/Control

ICA-331WH

ISA-335BL ISA-335D ISA-335L ISA-335WH

ISA-338BL ISA-338L ISA-338WH

Outdoor Remote Stations/Control

ICA-331WHW

ISA-319AB ISA-319PB ISA-319WH

ISA-339WH

Biscuit

Bright White

Bright White 7" 4" 1-1/16" 7/8" IR-91

Black

Sable Brown

Biscuit

Bright White

Black

Biscuit

Bright White

Bright White 7" 4" Surface Mount 2-1/2" –

Antique Brass Polished Brass

Bright White

Bright White 6-11/16" 8-5/8" Surface Mount 3-1/2" –

15-7/16" 8-3/16" 3-3/8" 1-3/16" IR-104

6-5/16" 8-1/4" 1-9/16" 7/8" IR-50

10" 11-1/4" 2-3/4" 7/8" IR-80

6-1/4" 8-3/16" 1-7/8" 7/16"

Intercom Options:

See p. 19 for chime modules and audio wall plate, p. 12-13 for music speaker options, p. 14-17 for door and intercom speakers and p. 27 for update and surface frames.

NuTone® products should not be installed on outside walls unless they are speciﬁ cally designed for outside use.

NuTone

IMA-3303 ‘Master’ s tation powered by (2) 16 volt, 30 VA transformers NuTone

*ISA-319AB, ISA-319PB and ISA-319WH use model IR-50 rough-in for non-masonry installation or model IR-55 rough-in when mounting to stucco or brick.

speciﬁ ed wire is used in the installation of a NuTone® Radio Intercom, the Warranty shall not be

Flat Parallel 3 wire cable: 200 ft. (IWA-3-200), 1000 ft (IWA-3-1000), NuTone® twisted-pair 22/2

speciﬁ ed wire.

model 301T supplied with the IR-104 rough-in.

Rough-In

Model No.

IR-50*

IR-55*

Music Distribution Speakers

25 ohm (for use with NuTone® Intercom Systems)

Turn Up the Volume of Your Life.

The two-way (woofer and tweeter) speakers provide enhanced music ﬁ delity

in an attractive style. Can be used to listen to music and hear intercom calls

from the intercom system. Controlling audio level is easy and convenient

when used in conjunction with model IC-901WH volume control.

(Music distribution and intercom speakers must not be installed in the same room or audio feedback will occur during intercom operation. Music distribution speakers can be used for monitoring and to make/reply to intercom calls when used with an intercom remote control; however, monitor and intercom audio levels from the music distribution speakers will be reduced when compared with intercom speakers.)

Music Speaker and Control Options for: IM-5000, IMA-4406, IMA-3303 and IMA-516

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

IC-901WH

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

IC-901WH

IS-9523BL IS-9523WH

IS-9825WH

IS-9625WH

IS-9626WH

Bright White 2-7/8" 4-3/4" 1/2" + Box 1"

Black

Bright White

Bright White 7-5/32" 10-5/8" 2" 3/8" –

Bright White 8-5/64" Dia. – 3-3/8" 3/4" –

Bright White 8-25/32" Dia. – 3-9/64" 3/4" –

5-5/16" Dia. 5-5/16" Dia.

7-7/8" 7-7/8"

–

5" 5"

Rough-In

Model No.

Single Gang

Box

–

IS-9523

IS-9825WH

IC-901WH – Indoor Volume Control

Small, attractive indoor volume control gives you inﬁ nite level adjustment of your music, incoming intercom calls, monitor and chime audio in areas of your home where intercom calls do not need to be made. Use with ceiling or wall mounted speaker models IS-76, ISA-78 series, IS-9615, IS-100 and IS-900 series. (Use with NuTone

intercoms only, one 25 ohm speaker per control. 2 watt maximum rating.)

IS-9523 – Outdoor Speaker

Outdoor weather-resistant surface-mounted two-way speaker. Mounts easily to a wall or overhang.

• Available in white or black ﬁ nishes

• Power rating: 70 Watts RMS

• 25 ohms impedance

• 3-1/2" polypropylene woofer with rubber surround,

1/2" aluminum dome tweeter

• Frequency response: 100-21,000 Hz ± 3dB

• Sensitivity (1m @ 1W): 86dB

IS-9825WH – Indoor Speaker

Indoor two-way in-wall speaker provides ﬁ rst-rate music performance in an attractive package.

• White paintable frame and grill

• Power rating: 70 Watts RMS

• 25 ohms impedance

• 5-1/4" polypropylene woofer with foam surround, 1" aluminum dome tweeter

• Frequency response: 80-20,000 Hz ± 3dB

• Sensitivity (1m @ 1W): 89dB

IS-9625WH/IS-9626WH – Indoor Speaker

Indoor two-way built-in speaker provides ﬁ rst class music performance in an attractive round proﬁ le for ceiling mounting.

• White paintable frame and grill

• Power rating: 60 Watts RMS for the IS-9625WH

70 Watts RMS for the IS-9626WH

• 25 ohms impedance

• IS-9625WH features a 5-1/4" polypropylene woofer with rubber surround,

1/2" polyester dome tweeter

• IS-9626WH features a 6-1/2" polypropylene woofer with rubber surround,

1" treated cloth dome tweeter

• Frequency response: IS-9625WH: 80-20,000 Hz ± 3dB IS-9626WH: 70-20,000 Hz ± 3dB

• Sensitivity (1m @ 1W): IS-9625WH: 89dB, IS-9626WH: 91dB

IS-9625WH/IS-9626WH

Door Speakers

Add security and convenience at every entry of your home.

Installing speakers at your entry doors provides the security and convenience

of answering the door from the ‘Master’ or any remote station/remote

control in your home. Many of our door speakers have a built-in door chime

pushbutton, so a separate button is not required. Each door speaker includes

a 3-1/2" weather resistance speaker for intercom communications. These door

speakers are designed to work with NuTone

IMA-3303 and IMA-516.

models IM-5000, IMA-4406,

IS-67

IS-69

IA-70

ISB-64

ISA-63

IA-70

In some installations, recess mounting of the door speakers is not possible. The IA-70 surface-mounting frame allows any NuTone® recess door speaker to be surface mounted. Mount to any ﬂ at surface on the wall or doorframe.

ISA-63

Surface-mount, molded plastic door speaker without chime pushbutton. Mounts beside door on any ﬂ at surface. Includes metal back for mounting.

ISB-64

Surface-mount, molded plastic door speaker with unlighted chime pushbutton. Mounts beside door on any ﬂ at surface. Includes metal back for mounting.

IS-67

Recess-mount, molded plastic door speaker with lighted chime pushbutton makes it easy to ﬁ nd in the dark. Mounts beside door.

IS-69

Recess-mount, cast metal door speaker with lighted chime pushbutton makes it easy to ﬁ nd in the dark. Mounts beside door.

IS-70

Recess-mount, cast metal door speaker without chime pushbutton. Mounts beside door.

IS-70

Intercom Door Speaker Options for: IM-5000, IMA-4406, IMA-3303 and IMA-516

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

IA-70

ISA-63

ISB-64

IS-67D

IS-67WH

IS-69AB IS-69PB IS-69WH

IS-70AB IS-70PB IS-70WH

Black 4-7/8" 6-1/2" – 1-11/16" –

Dark Brown/

Brass

Dark Brown/

Brass

Woodgrain/

Brass White

Antique Brass Polished Brass

White

Antique Brass Polished Brass

White

3-3/4" 4-5/8" Surface Mount 2" –

4-7/8" 6-1/2" 2" 9/16" IR-6

4-7/8" 6-1/2" 1-3/4" 9/16" IR-6

Rough-In

Model No.

Intercom Speakers

NuTone® intercom speakers function as both an intercom and music speaker.

Use a separate intercom speaker and intercom remote control to gain the advantage

of a smaller intercom control at eye level. Place the speaker high on the wall or

on the ceiling. All speakers are designed to work with any NuTone

control (see NuTone

models starting with IC/ICA). Can be used with NuTone®

‘Master’ station models IM-5000, IMA-4406 and IMA-3303. Speakers rated

at 25 ohms impedance.

IS-76

remote

IS-76 – Indoor Speaker

Indoor 8" recessed round speaker is designed for ceiling mounting. Operates with remote control models IC-502WH, ICA-441WH, ICA-331WH and model IC-901WH volume control.

ISA-78 – Indoor Speaker

Indoor 8" recessed rectangular speaker designed to be wall mounted. Operates with remote control models IC-502WH, ICA-441WH, ICA-331WH and model IC-901WH volume control.

IS-9615 – Indoor Speaker

Indoor 5-1/4" recessed round speaker is designed for ceiling mounting. Operates with remote control models IC-502WH, ICA-441WH, ICA-331WH and model IC-901WH volume control.

IS-100 – Indoor Speaker

Entry-level indoor 6" recessed round speaker is designed for ceiling mounting. Operates with remote control models IC-502WH, ICA-441WH, ICA-331WH and model IC-901WH volume control. Flush mount design requires no rough-in.

IS-100

IS-79 – Outdoor Speaker

Outdoor, weather resistant 8" recess-mount speaker designed to be wall or overhang mounted. Operates with remote control models IC-502LW, ICA-441WHW, ICA-331WHW.

IS-79

Intercom Speaker Options for: IM-5000, IMA-4406, IMA-3303

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

ISA-78

IS-9615

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

Indoor Speakers

IS-76

ISA-78L ISA-78WH

IS-9615WH

IS-100

Outdoor Speaker

IS-79

White 12-3/4" Dia. – 2-3/4" 1/4" IR-70

Biscuit

Bright White

Bright White 8" Dia. – 3-25/64" 1/4" –

White 6-1/2" Dia. – 1-11/16" 13/16"

Aluminum 12-5/8" 12-5/8" 2-5/8" 1/4" IR-9

10-1/8" 11-3/8" 2-3/4" 3/8" IR-80

Rough-In

Model No.

4-7/8" Dia.

Cutout

Intercom Accessories

Never miss a call when you add a NuTone® Chime Module option.

Have you ever missed a guest because you were out of hearing range of your

door chime? When you add a chime module to your intercom, all the remote

stations and controls become your chime! This easy to add option is available

on models IM-5000, IMA-4406 and IMA-3303. NuTone

8-note model and deluxe 10-tune musical model.

offers a basic

IA-28

IA-28 Chime Module

The IA-28 allows you to play chimes throughout the intercom system. Supports 3 door pushbutton locations and works with lighted or unlighted door pushbuttons. Plays 8 notes for front door, 2 notes for side door and 1 note for rear door. Features adjustable chime volume control. Mounts in and connects to IMA-3303, IMA-4406 and IM-5000 ‘Master’ stations. Not for use with IMA-516.

IA-29 Chime Module

Play chimes throughout the intercom system with the IA-29. Your choice of 10 melodies for the front door, 2 notes for side door and 1 note for rear door. Supports 3 door pushbutton locations and works with lighted or unlighted door pushbuttons. Melodies include: Westminster Chimes (8 notes and 4 notes), Anniversary Waltz, Beethoven’s Fifth, Dixie, Greensleeves, Happy Birthday, Jingle Bells, Joy to the World, Mazel Tov, Oh Tannenbaum, Star-Spangled Banner. Features adjustable chime volume control. Mounts in and connects to IMA-3303, IMA-4406 and IM-5000 ‘Master’ stations. Not for use with IMA-516.

IA-30WH

IA-29

IA-30WH Audio Wall Plate

Interface home audio equipment into the NuTone® intercom system. Allows you to send audio from a CD, MP3, DVD or cassette tape and distribute it through a NuTone® intercom system. White metal audio plate includes two RCA™ female connectors for connecting to your equipment. Mounts on wall behind home audio equipment. Installs and connects to the intercom using IR-30K rough-in kit.

IR-30K Rough-in Kit

Rough-in housing kit is used to mount and connect IA-30WH wall plate. Includes plastic single gang wall box and two 50' shielded audio cables with RCA™ plugs.

Chime Module Options for: IM-5000, IMA-4406, IMA-3303

Module mounts inside ‘Master’ station.

Finish Kit Model No. Width Height Location

IA-28

IA-29

2-3/8" 4-3/16" Mounts inside ‘Master’ Station

IA-30K

Intercom Accessories

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

IA-30WH

Bright White 2-13/16" 4-9/16" 9/16" 9/16" IR-30K

Rough-In

Model No.

IM-5000 Selective Call Intercom

Keeping In Touch

The IM-5000 intercom system allows you to ‘keep in touch’ with your family anywhere in your home. Use the ‘All Call’ intercom function to talk to all speakers at the same time from any speaker in your home. When you don’t want to disturb the whole house, use the numeric keypad and ‘Selective Call’ intercom function to call a single speaker from any speaker in your home. The monitor function allows you to ‘listen-in’ and ‘keep in touch’ with your family as you move around the house. Especially useful for families with a baby, small children or a person conﬁned to a bed. Don’t want to be disturbed? Just press the ‘private’ button on your remote station and all incoming intercom calls will be blocked. The system supports 20 remote stations and offers

many advanced intercom features.

Easy to Operate

Answering the door is just as easy as using the intercom. When the door chime rings, simply press the button at any speaker to talk and release the button to hear the reply. Up to 3 door speakers can be used. You can even add the basic 8-note chime module or a 10-tune musical chime module option that plugs right into the system to hear the door chime

at every station.

The Right Connection at Home or in the Small Business Environment.

Make the Connection

Although the IM-5000 does not come with a built-in tuner, you can still play music, sports and news over our system using equipment you may already own. A built-in auxiliary audio input can be connected to any audio source like your CD player, AM/FM tuner or tape player and played through the remote stations. Auxiliary audio volume is controlled by an up/down pushbutton electronic volume control located on every

remote station.

Style Conscious

Since the IM-5000 ‘Master’ does not contain any controls or speaker, it can easily mount away from view in a utility room, closet or basement. Remote stations and controls used throughout your home are available in several sizes and styles for both indoor and outdoor use. See pages 22-23 for more details.

IM-5000 shown.

IM-5000 – Remote Stations

Stay connected inside and out, with our full line of intercom remote stations.

The IM-5000 intercom system offers all the features you are looking for in an

intercom. Talk with one room only by utilizing the ‘Selective Call’ intercom feature,

or use the ‘All Call’ intercom to call all stations at the same time. Audible signal

announces someone is calling. The convenient ‘Hands-free’ feature allows you to

answer from any station without pressing a button. Simply press the talk button

to speak, and release to hear reply. Communicate with up to three doors from any

intercom station. A ‘Listen-in’ feature monitors activities in other rooms and the

privacy mode prevents unwanted intercom calls. Each station includes separate

electronic touch volume controls for intercom and program volume. Built-in

microphone provides enhanced intercom clarity.

IC-502LW

IC-502WH

IS-518WH

IS-515

IC-502WH – Indoor Remote Control

This indoor remote control offers the same functions as our remote stations in a smaller attractive size that takes up little wall space. Use with ceiling or wall mounted speaker models: IS-76, ISA-78, IS-9615WH, IS-9523, IS-9825WH, IS-9625WH and IS-9626WH. (One 25 ohm speaker per control.)

IS-515 – Indoor Remote Station

The IS-515 indoor remote station provides all the system functions of the IM-5000 system. Includes built-in 5" speaker.

IS-518WH – Indoor Remote Station

In larger rooms enjoy the rich, full sound of our 8" indoor remote station. Offers all the IM-5000 system functions with enhanced bass sound.

IC-502LW – Outdoor Remote Control

Hear all that’s going on inside with the outdoor remote control. Its compact design takes up minimal space. Use with wall and overhang mounted speakers: IS-79 and IS-9523. Use IR-91 rough-in. (One 25 ohm speaker per control.)

IS-519 – Outdoor Remote Station

Don’t miss a thing when you’re outside. The 5" outdoor remote speaker is perfect for use on patio or deck. Use model IR-50 for non-masonry installation. Use IR-55 rough-in when mounting to stucco or brick.

IS-519

IM-5000 System Components

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

‘Master’ Station

IM-5000

401T Transformer - 24VAC, 40VA

Indoor Remote Stations/Control

IC-502WH

IS-515L IS-515WH

IS-518WH

Outdoor Remote Station/Control

IC-502LW

IS-519

Bright White 8" 12-1/2" Surface Mount 3-1/2" –

2-3/4" 2-1/4" 2-1/2" – –

Bright White 7" 4" 1" 1" IR-91

Biscuit

Bright White

Bright White 10-1/8" 11-1/2" 2-1/8" 13/16" IR-80

Biscuit 7" 4" 1" 1" IR-91

Biscuit 6-1/4" 8-1/4" 1-1/8" 1"

6-1/4" 8-1/4" 1-1/8" 1" IR-50

Intercom Options:

See p. 19 for chime modules and audio wall plate, p. 12-13 for music speaker options, p. 14-17 for door and intercom speakers and p. 27 for update and surface frames.

NuTone® products should not be installed on outside walls unless they are speciﬁ cally designed for outside use.

NuTone

*IS-519 uses model IR-50 rough-in for non-masonry installation or model IR-55 rough-in w hen mounting to stucco or brick.

speciﬁ ed wire is used in the installation of a NuTone® Radio Intercom, the Warranty shall not be

3-twisted-pair/6-wire cable: 200 ft. (IW-6-200), 1000 ft. (IW-6-1000), NuTone® twisted-pair 22/2

speciﬁ ed wire.

Rough-In

Model No.

IR-50* or

IR-55*

IMA-516– Intercom System

IK-15WH/IK-25WH DoorCom & IMA-110WH

Versatile, “whole house” intercom for home or business... economical too!

Everything you need to set up a basic intercom system. The IMA-516 uses up to 10

remote stations for intercom, plus 2 door speakers for door answering. As an added

beneﬁ t, the unit can distribute music when connected to an external music source.

IMA-516

IMA-516 Ampliﬁ er

This is the perfect choice for residential or small ofﬁ ce use. It allows you to talk from any station to all other stations or answer the door from any station while response is hands-free.

• ‘Talk Lock’ feature allows you to monitor activities

in other rooms

• Auxiliary audio input to connect and play from an

external audio source

• Ampliﬁ er mounts in a utility room or closet, surface-mount

• No rough-in required

• Connects to optional, external electronic chime models

LA-52WH or LA-174WH (Does not use IA-28 or IA-29 chime module)

ISB-53WH ISB-53LW

ISB-53 Indoor Remote Speakers

This indoor speaker features a rotary volume control that can be turned off for privacy.

• ‘Push to Talk’ intercom switch

• ‘On-Off’ door speaker switch

• ‘Talk Lock’ feature allows any

station to be monitored.

ISB-53LW Outdoor Remote Speaker

This weather-resistant outdoor speaker features a rotary volume control that can be turned off for privacy.

• ‘Talk/Listen’ intercom switch

• ‘On-Off’ door speaker switch

• ‘Talk Lock’ button which allows

for monitoring

• Surface-mount frame included

IK-15WH DoorCom

2-station door answering intercom with optional door release.

Get added security and convenience for your condo, townhouse, apartment or small ofﬁ ce with this economical, easy-to-install intercom.

• Press talk button to talk and release to hear reply

• Two-note chime sounds when caller presses pushbutton

• Bright white inside speaker has volume control and automatic time out

privacy feature

• Brown outdoor speaker has chime button and operates hands-free; includes nameplate

• Optional features: second door speaker (IS-68), door release button (PB18WHCL)

and door release (DR-1 and DR-2)

• Inside speaker: 5-1/4" w x 7-3/4" h, projects 1-3/4"; surface mount

• Door speaker: 4" w x 5-3/8" h, projects 1-7/8"; surface mount

• Includes 16VAC transformer

Installation Wire: NuTone® twisted-pair 22/2 cable 100 ft. (IW-2-100), 500 ft. (IW-2-500).

For installations where UL listed wire is speciﬁ ed, add ‘UL’ sufﬁ x to model number.

IK-25WH DoorCom

3-station door answering intercom provides two inside speakers and a door speaker.

The system combines two inside speakers with one door speaker to expand your convenience.

• Answer the door from either of the two inside speakers plus talk privately

between them

• Two note electronic chime sounds at both inside speakers

• Push ‘Door Talk’ button on inside speaker to talk to door speaker. Door speaker

responds hands free.

• ‘Inside Talk’ button lets you communicate with other indoor stations, bypassing

the outdoor speaker for privacy

• Optional features: second door speaker (IS-68), door release button (IM-25SW)

and door release (DR-1 and DR-2)

• Inside speaker: 5-1/4" w x 7-3/4" h, projects 1-3/4"; surface mount

• Door speaker: 4" w x 5-3/8" h, projects 1-7/8"; surface mount

• Includes 16VAC transformer

Installation Wire: NuTone® 3-twisted-pair wire/6-wire cable: 200 ft. (IW-6-200), 1000 ft.

(IW-6-1000), NuTone® twisted-pair 22/2 cable 100 ft. (IW-2-100), 500 ft. (IW-2-500).

For installations where UL listed wire is speciﬁ ed, add ‘UL’ sufﬁ x to model number.

IK-15WH

IK-25WH

IS-68 optional second door speaker. Order

separately if second door speaker desired.

Use with either IK-15WH or IK-25WH.

IMA-516 System Components

Order Rough-in PLUS ﬁ nish kit to make a complete unit.

Finish Kit Model No. Finish Width Height In-Wall Depth Projects

IMA-516

ISB-53LW

ISB-53L ISB-53WH

*IA-15 *IA-15WH

301T Transformer - 16VAC, 30VA 2-5/8"

Eggshell White

and Aluminum

Eggshell White 4-7/8" 6-3/4" Surface Mount 3" –

Eggshell White

Bright White

Eggshell White

Bright White

4-5/8" 7-5/8" – 2-3/8" –

4-7/8" 6-3/4" 1-1/2" 1/2" IR-3

5-1/8" 7" – 1-5/8" –

2-3/16" 2-3/4" – –

Rough-In

Model No.

*Surface mounting frame for ISB-53L/WH

NuTone

products should not be installed on outside walls unless they are speciﬁ cally

designed for outside use.

NuTone

Intercom Wire is an integral part of all NuTone® Radio Intercom Systems; such wire has been designed to enable full system performance and to minimize outside interference, dimmer noise, radio frequency interference and other reception problems. If wire other than NuTone Intercom, the Warranty shall not be applicable to any defect or problem relating to the use of non-NuTone

Installation Wire: NuTone (IW-6-1000), NuTone twisted-pair 18/2: (S-143-500). For installations where UL listed wire is speciﬁ ed, add ‘UL’ sufﬁ x to model number when ordering.

IMA-516 ‘Master’ s tation powered by a 16 volt, 30 VA transformer NuTone

speciﬁ ed wire is used in the installation of a NuTone® Radio

speciﬁ ed wire.

3-twisted-pair/6-wire cable: 200 ft. (IW-6-200), 1000 ft.

twisted-pair 22/2 cable: 100 ft. (IW-2-100), 500 ft. (IW-2-500),

model 301T.

IMA-110WH

Plug into an AC outlet at any location!

This 4-channel line carrier FM intercom can use up to 8 stations. The voice-activated ‘Auto’ key provides total hands-free operation, or choose the monitor function.

• Advanced circuit to receive the clearest reception with no drifting

• Built-in circuitry reduces interference from appliances or dimmers

• Rotary volume control with ‘Off’ setting allows you to adjust each station

• Provides a 500 foot range

• Compatible with NuTone

model IM-110; available in two-pack IMA-110WH-2

• RF frequencies are 200 KHz, 230 KHz, 260 KHz and 290 KHz

• Compact size: 7" w x 5-3/4" d x 1-7/8" h

IMA-110WH

15/16"

61/8"

31/4"

Recess Mounting Rough-in Frames

IR-3*

• Metal housing for ISB-53 speaker

• Cutout: 3-7/8" w x 5-7/8" h

IR-70*

• Metal housing for IS-76 round speaker

• Cutout: 10-3/4" dia.

Update and Surface Frames

An easy way to convert your older system to a new radio-intercom.

To make replacing your system easier, NuTone

frames that ﬁ t over and cover the larger opening left by the older system.

Updating frames allow you to install the latest systems without needing

to patch walls. Rough-ins purchased separately.

offers several “updating”

IA-119WH

IR-6*

• Metal housing for IS-67, IS-69 and

IS-70 series door speakers

• Cutout: 3-11/16" w x 5" h

IR-9*

• Metal housing for IS-79 speaker

• Cutout: 10-1/16" w x 11-1/16" h

IR-50*

• Metal housing for ISA-319, ISA-335,

ISA-419, ISA-445, IS-515 and IS-519 series speakers

• Cutout: 5-3/8" w x 7-3/16" h

IR-55*

• Metal housing for ISA-319, ISA-419

and IS-519 series speakers

• Cutout: 5-3/8" w x 7-3/16" h

IR-80*

• Metal housing for ISA-78, ISA-338,

ISA-448, IS-518WH series speakers

• Cutout: 8-5/8" w x 10-1/4" h

IR-91*

• Metal housing for ICA-331WH, ICA-441WH,

IC-502WH and IC-502LW remote controls

• Cutout: 6-1/8" w x 3-1/4" h

IR-104*

• Metal housing for IMA-3303 Voice Music Intercom

• Cutout: 14-1/2" w x 7" h

• Includes AM/FM antenna and two 301T transformers

IR-105*

• Metal housing for IMA-4406 Voice Music Intercom

• Cutout: 14-1/2" w x 9" h

• Includes AM/FM antenna and two 801T transformers

Update Frames

IA-119WH

Mounts over and covers opening of older ‘Master’ station. Use with IMA-3303 ‘Master’ station. Features plastic construction.

IA-51

Allows you to adapt the opening from your older horizontal speakers to work with current ISA-335 and ISA-445 5" speakers. Surface mounts over old speaker opening. Features plastic construction.

IA-55

Adapts older horizontal speaker areas to work with current ISA-335 and ISA-445 5" speakers. Recess mounts into old speaker opening (requires increasing the opening above and below the old speaker opening). Features plastic construction.

IA-83

Adapt the openings from your older speakers to work with current ISA-338 and ISA-448 8" speakers. Frame recess mounts into old speaker opening. Features wood construction.

Surface Frame

IA-60

Converts 5" inside speakers to surface mount. Speaker frame is designed for use with the IMA-3303, IMA-4406 voice/music intercoms and the IM-5000 selective call intercom.

IA-51

IA-55

IA-83

Rough-Ins for: IM-5000, IMA-4406, IMA-3303 and IMA-516 Systems

Rough-Ins IR-3 IR-6 IR-9 IR-50 IR-55 IR-70 IR-80 IR-91 IR-104 IR-105

IM-5000 System

IMA-4406 System

IMA-3303 System

IMA-516 System

*New and retroﬁ t construction **New construction only

• • • • •

• • • • • • •

• • • • • • • •

Update and Surface Frames

Model No. Used With To Update Finish Width Height In-Wall Depth Projects

IA-119WH

IA-51

IA-55L IA-55WH

IA-83L IA-83WH

IA-60L IA-60WH

*Updating frames for these models are not available.

Note: No ‘Mas ter’ or speaker update frame is needed to update the IM-3003 to the IMA-3303 system.

IMA-3303

IMA-3303, IMA-4406

Surface-mounting frame for ISA-335, ISA-445 and IS-515 series speakers

Older 3 wire ‘Master’ stations except 2015/16* and 2011/12*

5" horizontal speakers from older systems to ISA-335 or ISA-445

Larger speakers from older systems to more compact ISA-338 or ISA-448

Bright White 17" 9-3/4" 3/16" 3/16" IR-104

Bright White 9-3/8" 8-5/8" – 2-1/4" –

Biscuit

Bright White

Biscuit

Bright White

Biscuit

Bright White

9-1/2" 9" – 3/16" IR-50

12-1/4" 13-1/2" – 3/4" IR-80

6-3/8" 8-1/4" –

4" (with speaker)

IA-60

Rough-In

Model No.

–

AD-500 Apartment Security Entry System

Answering the door is as simple as picking up a telephone.

Backlit, two-line directory features a programmable welcome message, and easy-to-use, built-in, scroll-through directory

• Two relay output channels can be programmed to control

entry-way door locks or barrier gates

• System boasts a 250 resident capacity, while allowing

access using up to 500 distinct entry codes

Bright, easy-to-read, 12-key telephone style keypad

DR-1 Door Release NuTone’s® electric ‘Wood Door Frame’ door release is available in your choice of ﬁ nishes: Brass Anodized (DR-1BA) or Silver Anodized (DR-1SA). Fits into door frames as shallow as 1-9/16" or faceplate 1-1/4" w x 5-7/8" h.

AD-500 shown installed in the IRAD-500 trim ring

Operation is Easy.

The unit’s memory is programmed with each resident’s

name and directory code. Visitors use the keypad to scroll

through for the desired resident. Upon entry of the directory

code, the system dials the resident’s phone number to

establish contact. The resident may grant or deny access

by pressing a number on their touchtone™ telephone

keypad. For tenant access, they simply enter their access

code on the AD-500 keypad.

Built-in microphone and speaker

Rugged 16-gauge brushed stainless steel front panel

Convenient Programming Options.

Two relay output channels are programmed to control

electric door strikes or magnetic locks. Programming of the

system is made convenient using any of these methods:

• Local programming through the keypad

• Remote programming using a touchtone™ phone

• Remote programming by a computer with a dial-up

modem and an internet web browser

Programming navigation is simple and intuitive.

The AD-500 Telephone Entry/Access Control System is

designed for surface mounting, or order the IRAD-500

Trim Ring Rough-In (sold separately) to recess mount

the AD-500 system.

DR-2-SA Door Release

This electric ‘Metal Door Frame’ door release comes in a Silver Anodized ﬁ nish. The faceplate measures 1-1/4" w x 4-7/8" h. Fits into hollow door frames as deep as 1-5/8".

Note: In new construction with metal doors, order door equipped with proper electrical release to match door lockset from door supplier.

The DR-1 and DR-2-SA door releases are powered by a separate 301-T transformer.

Model No. Finish Width Height Depth Projects

AD-500

(without IRAD-500) (with IRAD-500)

IRAD-500

301T Transformer - 16VAC, 30VA 2-5/8"

DR-1**

DR-2-SA

Installation Wire: NuTone® twisted-pair 18/2 cable: 500 ft. (S-143-500). For installations where UL listed wire is speciﬁ ed, add ‘UL’ sufﬁ x to model number when ordering.

**Add sufﬁ x to specify ﬁ nish – “BA” (Brass) or “SA” (Silver).

Stainless Steel

Stainless Steel 12-3/4" 14-3/4" 2-7/8" –

Brass or Silver

Anodized

Silver Anodized 1-1/4" 4-7/8" 1-5/8" –

10-3/4" 12-3/4"

1-1/4" 5-7/8" 1-9/16" –

12-3/4" 14-3/4"

2-3/16" Surface Mount 2-3/4"

–

3-1/2"

1/2"

IM-5000

Master Station

IMA-4406

Master

Station

Wiring Diagrams

IMA-4406 Basic 3 Remote Station System

Quantity Model Description

1 IMA-4406 ‘Master’ Station

1 IR-105 ‘Master’ Rough-In

3 ISA-445 Remote Stations

3 IR-50 Remote Station Rough-Ins

1 IS-69 Door Speaker

1 IR-6 Door Speaker Rough-In

1 IW-6-200UL Intercom Wire

1 IW-2-100UL Door Speaker Cable

Components must be ordered separately.

IM-5000 Basic 3 Remote Station System

Quantity Model Description

1 IM-5000 ‘Master’ Station

1 401T Transformer – 24v AC, 40VA

3 IS-515 Remote Stations

3 IR-50 Remote Station Rough-Ins

1 IS-69 Door Speaker

1 IR-6 Door Speaker Rough-In

1 IW-6-200UL Intercom Wire

1 IW-2-100UL Door Speaker Cable

Components must be ordered separately.

AD-500

Master

Station

TRANSFORMER

120v PRIMARY

IW-2 (22 GA)

100' MAX

DOOR SPEAKER

IW-2 (22 GA)

300' MAX

BROWN

MASTER SPEAKER

GREEN RED

TRANSFORMER

120VAC

MASTER STATION

IW-6 CABLE

INSIDE REMOTE

STATION

IW-2 (22 GA)

100' MAX

DOOR

SPEAKER

IW-6 CABLE

100' MAX

(50' MAX IF DOOR

RELEASE IS USED)

IW-2 (22 GA)

300' MAX

BROWN

GREEN

BROWN

ORANGE

GRAY

BLACK

WHITE

ORANGE ORANGE

ORN/WHT ORN/WHT

BLACK BLACK

BLK/WHT BLK/WHT

RED

(NOT USED)

RED/WHT RED/WHT

IMA-3303

Master

Station

Wiring Diagrams

AD-500 Apartment Security Entry System Diagram

Quantity Model Description

1 AD-500 ‘Master’ Station

1 DR1/DR2 Door Release

1 301T Transformer

1 S143-500UL Wire

Components must be ordered separately.

IK-15WH DoorCom Wiring Diagram

IMA-3303 Basic 3 Remote Station System

Quantity Model Description

1 IMA-3303 ‘Master’ Station

1 IR-104 ‘Master’ Rough-In

3 ISA-335 Remote Stations

3 IR-50 Remote Station Rough-Ins

1 IS-67 Door Speaker

1 IR-6 Door Speaker Rough-In

1 IW-3-200UL Intercom Wire

1 IW-2-100UL Door Speaker Cable

Can be ordered as a kit or as individual models.

IK-25WH DoorCom Wiring Diagram

Index

Radio Intercoms and Intercoms

Model Page

IA-15 24

IA-28 19

IA-29 19

IA-30WH 19

IA-51 27

IA-55 27

IA-60 27

IA-70 14

IA-83 27

IA-119WH 27

IAA-440 7

ICA-331WH 10

ICA-331WHW 11

ICA-441WH 6

ICA-441WHW 7

IC-502LW 23

Model Page

IMA-4406 4 – 7

IM-5000 20 – 23

IMA-516 24

IR-3 26

IR-6 26

IR-9 26

IR-30K 19

IR-50 26

IR-55 26

IR-70 26

IR-80 26

IR-91 26

IR-104 26

IR-104K 11

IR-105 26

IS-67 15

Model Page

ISA-339WH 11

ISA-419 7

ISA-445 6

ISA-448 6

ISA-449WH 7

IS-515 22

IS-518WH 22

IS-519 23

IS-9523 12 – 13

IS-9615WH 16

IS-9625WH 12 – 13

IS-9626WH 12 – 13

IS-9825WH 12 – 13

ISA-63 14

ISA-78 16

ISB-53 24

IC-502WH 22

IC-901WH 12 – 13

IK-15WH 25

IK-25WH 25

IMA-110WH 25

IM-110WH-2 25

IM-25SW 25

IMA-3303 8 – 11

IMA-3303WHK 11

IS-68 25

IS-69 15

IS-70 15

IS-76 16

IS-79 17

IS-100 17

ISA-319 11

ISA-335 10

ISA-338 10

Apartment Security Entry System

Model Page

AD-500 28 – 29

DR-1 29

Model Page

DR-2-SA 29

IRAD-500 28 – 29

ISB-53LW 24

ISB-64 14

IW-2 7, 11, 23 – 24

IW-6 7, 23 – 25

IWA-3 11

PB18WHCL 25

S-143 7, 11, 23 – 24, 29

301T 24

401T 2 3

Model Page

S-143 29

301T 29

326715 15248

NuTone… life. style. home.

Speakers Ironing Centers Chimes Heaters Fresh Air Systems

Trash Compac tors Ceiling Fans Medicine Cabinets

Decorative BacksplashesVentilation Fans Central VacuumsRange Hoods

NuTone® is America’s leading brand of residential built-in convenience products including door chimes, central vacuum systems,

intercom systems, home theater speakers, medicine cabinets, ironing centers and ventilation fans.

Broan

is America’s leading brand of residential ventilation products including range hoods, ventilation fans, heater/fan/light combination units, Indoor Air Quality (IAQ) Fresh Air Systems, built-in heaters, whole-house fans, attic ventilators, paddle fans and trash compactors.

Broan and NuTone are proud to be ENERGY STAR

partners.

Broan-NuTone LLC, 926 W. State Street, Hartford, WI 53027 • 888-336-3948

www.NuTone.com

In Canada call 888-882-7626

NuTone 801T, IR-55, ISA-78, IR-50, 301T User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
