Professional Disc Jockey Products

TT-100

DIRECT DRIVE TURNTABLE

OWNER’S MANUAL

PRO TT-2 Turntable

Safety Information

8. Power Sources - This product should be connected to a

power supply only of the type described in these operating instructions, or as marked on the unit.

9. Power Cord Protection - Power supply cords should be

routed so that they are not likely to be walked upon or pinched by items placed on or against them. When removing the cord from a power outlet be sure to remove it by holding the plug attachment and not by pulling on the cord.

10. Object and Liquid Entry - Take care that objects do not

fall into and that liquids are not spilled into the inside of the mixer.

11. Cleaning – The appliance should be cleaned only as

recommended by the manufacturer.

12. Non-use Periods – The power cord of the appliance

should be unplugged from the outlet when left unused for long periods of time.

13. Damage Requiring Service - Only qualified personnel

should service this product. If you have any questions about service please contact Numark at the number(s) shown on the back cover of this manual.

SAFETY INSTRUCTIONS

1. Read Instructions - All the safety and operating

instructions should be read before this product is connected and used.

2. Retain Instructions - The safety and operating instructions

should be kept for future reference.

3. Heed Warnings - All warnings on this product and in

these operating instructions should be followed.

4. Follow Instructions - All operating and other instructions

should be followed.

5. Water and Moisture -

This product should be kept away from direct contact with liquids.

6. Heat - Avoid placing this

product to close to any high heat sources such as radiators.

7. Ventilation - The appliance should be situated so that it’s

location or position does not interfere with it’s proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation opening; or, placed in a builtinstallation, such as bookcase or cabinet that may impede the flow of air through the ventilation openings.

14. Grounding or Polarization - Precautions should be taken

so that the grounding or polarization means built into the CD player is not defeated.

15. Internal/External Voltage Selectors - Internal or external

voltage selector switches, if any, should only be reset and re-equipped with a proper plug for alternative voltage by a qualified service technician. Do not attempt to alter this yourself.

WARNING: To reduce the risk of fire or electrical shock, do not expose this appliance to rain or moisture. Electrical equipment should NEVER be kept or stored in damp environments.

- The Leader in DJ Technology

PRO TT-2 Turntable

IMPORTANT INFORMATION...

Please read this entire manual before connecting the unit to your system.

For optimum performance:

1. Always make sure that AC power is OFF while making

any connections.

2. Do not force the platter to stop moving while the motor is engaged. Quality slipmats should be used to hold records in position. Forcing the motor to stop can damage the motor assembly.

3. Never use spray cleaners or oils on the slide control. Residues cause excessive dirt build-up and this will void your warranty. In normal use slide controls can last for many years. If they malfunction (usually because of a dirty or dusty environment)

4. Never attempt to make any adjustments or repairs other than those described in this manual. Take the TT-100 to your dealer or to an authorized

5. Do not place the unit in a location where it will be exposed to direct sun light or near a heating appliance.

6. Do not place the unit in a location where there is high humidity or a lot of dust.

7. Cartridge may pick up slight sound pressure or vibrations of the speakers coming along the floor or through the air resulting in howling. Find a location, which is very stable and free of vibration.

8. The legs have functions for adjusting the height of the unit itself. Adjust the legs to stabilize the main body horizontally.

A NOTE ON CABLES:

Quality cable makes a big difference in audio fidelity and punch. See your or an electronics or audio specialist store if you are not sure which cables to get.

Service Center.

dealer

GENERAL SYSTEM PRECAUTIONS

• Use appropriate cables throughout your system: Quality

shielded audio cables and terminated shielded video cables, low-capacitance preferred. Speaker cables must be 14-gauge minimum; 12- or 10-gauge is better.

• Be sure plugs and jacks are tightly mated. Loose

connections can cause hum, noise or intermittent that could easily damage your speakers.

• Reliability will be enhanced through the use of banana

connectors on the speaker wires. Observe correct speaker wire polarity. If in doubt, consult your or a qualified technician.

• Take care to connect only one cable at a time. Pay

attention to the color-coded, labeled Input and Output jacks.

• ALWAYS remember: “TURN AMPS ON LAST AND

OFF FIRST”. Begin with master faders or volume

controls on minimum and the amplifier gain/input control(s) down. Wait 8 to 10 seconds before turning up the volume. This prevents transients, which may cause severe speaker damage.

• Use restraint when operating controls. Try to move them

slowly. Rapid adjustments could damage speakers due to amplifier clipping.

• Avoid amplifier “clipping” at all costs: this occurs when

the red LEDs (usually on the front panel of most professional power amplifiers) start flashing. “Clipping” is when the power amplifier is distorting and working beyond it’s limits. Amplifier distortion is THE major cause of speaker failure.

• To prevent fire or shock hazard, do not expose the unit to

rain or moisture. Never place cans of beer, soda, glasses

of water or anything wet on top of the turntable!

dealer

- The Leader in DJ Technology

PRO TT-2 Turntable

TT-100

PROFESSIONAL DIRECT-DRIVE TURNTABLE

CONGRATULATIONS!

You are now the owner a TT-100 Direct Drive Turntable. This unit has been designed to deliver solid performance at a reasonable price. With its full selection of adjustment features the TT-100

offers essential control to the user. Enjoy this turntable and remember:

BE CREATIVE!

Thank you for buying Numark DJ products!

FEATURES:

• ± 10 or20% pitch adjustment

• Direct Drive Motor

• Start/Stop Button

• Electronic Braking

• 33/45/78 RPM speeds

• Forward and Reverse Platter Direction

• Pop-up Stylus Target Light

• Adjustable Feet for Leveling

• Easily removable smoked plastic lid

• Quartz Lock of 0% speed position

• 45RPM adapter and holder

• Extra Stylus Holder

• S Shaped Tone arm assembly with:

• Counterweight

• Height Adjustment

• Skating Adjustment

• Height Lock

• Lever lift with height adjustment

• Tone arm holder with locking mechanism

• Output for:

• Audio{Left Right & Ground}

• Platter Speed – to be used with external

process devices

• External START/STOP control

- The Leader in DJ Technology
