Numark EM260 User Guide
Professional Disc Jockey Products
EM260
EM260
EM260EM260
PROFESSIONAL DJ EFFECTS MIXER
PROFESSIONAL DJ EFFECTS MIXER
PROFESSIONAL DJ EFFECTS MIXERPROFESSIONAL DJ EFFECTS MIXER
With
With KAOSS* Pad Multi-effects Processor
With With
Pad Multi-effects Processor
Pad Multi-effects Processor Pad Multi-effects Processor
Owner’s Manual
*KAOSS technology under license from KORG
©2001 Industries http://www.numark.com
EM 260
Safety Information
SAFETY INSTRUCTIONS
a) Read Instructions - All the safety and operating
instructions should be read before this product is
connected and used.
b) Retain Instructions - The safety and operating instructions
should be kept for future reference.
c) Heed Warnings - All warnings on this product and in
these operating instructions should be followed.
d) Follow Instructions - All operating and other instructions
should be followed.
e) Water and Moisture -
This product should be
kept away from direct
contact with liquids.
f) Heat - Avoid placing this
product to close to any high heat sources such as
radiators.
g) Ventilation - The appliance should be situated so that it’s
location or position does not interfere with it’s proper
ventilation. For example, the appliance should not be
situated on a bed, sofa, rug,
or similar surface that may
block the ventilation
opening; or, placed in a builtinstallation, such as bookcase
or cabinet that may impede
the flow of air through the ventilation openings.
h) Power Sources - This product should be connected to a
power supply only of the type described in these
operating instructions, or as marked on the unit.
i) Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked upon or
pinched by items placed on or against them. When
removing the cord from a power outlet be sure to remove
it by holding the
plug attachment
and not by pulling
on the cord.
j) Object and Liquid Entry - Take care that objects do not
fall into and that liquids are not spilled into the inside of
the mixer.
k) Cleaning – The appliance should be cleaned only as
recommended by the manufacturer.
Non-use Periods – The power cord of the appliance
l)
should be unplugged from the outlet when left unused for
long periods of time.
m) Damage Requiring Service - Never attempt to make any
adjustments or repairs other
than those described in this
manual.
personnel should service
this product. If you have
any questions about service
please contact Numark at the number(s) shown on the
back cover of this manual.
n) Grounding or Polarization - Precautions should be taken
so that the grounding or polarization means built into the
CD player is not defeated.
o) Internal/External Voltage Selectors - Internal or external
voltage selector switches, if any, should only be reset and
re-equipped with a proper plug for alternative voltage by
a qualified service technician. Do not attempt to alter this
yourself.
WARNING: To reduce the risk of fire or electrical shock, do
not expose this appliance to rain or moisture. Electrical
equipment should NEVER be kept or stored in damp
environments.
Only qualified
- The Leader in DJ Technology
©2001 Industries - 2 - http://www.numark.com
EM260
EM260
EM260
EM260EM260
With
With KAOSS PAD Multi-effects Processor
With With
CONGRATULATIONS!
You have purchased the EM260 Stereo Effects Mixer by . The first series of DJ mixers with a
completely interactive, real-time effects processor. This one of a kind DJ product boasts all of the qualities that
you have come to expect from a mixer plus, it features a built in KAOSS PAD*. This piece of
equipment literally puts effects processing at the DJ’s fingertips. The EM260 is easily suited for mobile or
installation use. Special features found on this product are rotary cut control, fader start, and multiple
headphone outputs. The fader start feature is designed to work with ’s Fader Start CD players as well
as its other popular CD players. The KAOSS Pad* effects processing unit lets the DJ control his choice of up
to sixty effects programs in real-time. The effects unit allows for sampling functions, parameter controls, and
MIDI compatibility.
Thank you for purchasing NUMARK products!
PAD Multi-effects Processor
PAD Multi-effects Processor PAD Multi-effects Processor
PROFESSIONAL DJ EFFECTS MIXER
Mixer Features:
• Four line, two phono, one mic inputs
• Front panel Neutrik
• 3-band EQ (CUT), Pan, and gain control on all
channels
• Replaceable cross-fader with slope control
• Fader start
• Split/blend headphone cueing
TM
mic input
Table of Contents
Safety Measures 2
Introduction 3
Registration 3
Description of the Features 4
Quick Setup Diagram 7
KAOSS PAD* Features:
• Real-time effects processing
• X-Y touch sensitive pad
• Separate parameter controls
• Sixty “effects programs”
• Hold switch to lock in settings
• Sampler (5 seconds at 48 kHz)
• MIDI compatibility
• 100% digital processing
*KAOSS technology under license from KORG
KAOSS Effects 8
MIDI Implementation 9
Specifications 10
Bock Diagram 11
Warranty 12
Product Registration
Please record the serial number of your unit as shown on the back of the chassis as well as the name of the
dealer from whom you purchased the unit. Retain this information and your original purchase receipt for
your records. Please return the enclosed warranty card to register your unit with us.
MODEL: __________________________ PURCHASED FROM:_________________________
SERIAL NUMBER:__________________ DATE OF PURCHASE:________________________
- The Leader in DJ Technology
©2000 Industries - 3 - http://www.numark.com
EM260
MIXER FEATURES
24
26
25
21
4
3
8
2
7
1
22
23
20
10
28
29
27
13
11
12
detented for setting tone "flat". For best results, use a dynamic
cardioid microphone.
8. Mic Off/On/Talkover Switch – controls DJ Mic. Talkover
turns down the input level of your music –12dB for easy
understanding of announcements.
HEADPHONE CUEING
Channel PFL Cue Assign - are used to route Pre Fader Level
9.
(PFL) channel audio to the Monitor Section. The channel
faders do not control the Cue volume.
PFL Meter Select – Changes the meter to show PFL levels and
10.
allow for precise matching of channel input levels.
Headphone Mix - controls the mix of PFL and PGM signals to
11.
your headphones. When the slider is moved to the left, all you
will hear is the cue source. When the slider is all the way to the
right, you will hear what is playing through the master output.
By blending, beats can be matched exactly and segues can be
smooth when a song is cued.
12. Headphone Level – adjusts cue volume.
13. Split/Blend Cue – controls how PFL and Program audio are
sent to your headphones. In split mode, the PFL audio can be
heard in your left ear and PGM audio can be heard in your right
ear. In blend mode, both PFL and PGM can be heard in both
ears.
14. Headphone output – for your 1/8” and 1/4” headphones.
5
9
19
15
6
1. Input faders - control individual source levels in the mix.
Note: Never use spray cleaners on the slide controls. Residues
cause excessive dirt build-up and this will void your warranty.
In normal use slide controls can last for many years. If they
malfunction (usually because of a dirty or dusty environment)
consult a professional technician.
2. Input Toggle Switches - select which source will be live to that
channel based on what you have connected to the rear panel
input section.
3. 3-Band Stereo Equalizer (EQ) - compensates for differences in
source material sound quality. You can create interesting effects
by removing frequencies if you turn the knob to –30dB.
4. PFL Gain – allows you to adjust the input level of the music to
match other channels. The idea is to set all input levels to
approx. 0dB so channels match. Do not try to match to the
master output meter.
5. Mic Gain Controls – controls the DJ Mic volume.
6. ¼” Mic connector - allows connection of a 1/4” jack
microphone.
7. Treble and Bass Controls – for fine-tuning the tone of your
voice on both mics through the sound system. The controls are
16 17 18
INPUTS
14
CROSSFADER
Replaceable Crossfader - achieves clean segues between the
15.
two input channels selected by the Crossfader Assign.
Note: The crossfader is a user replaceable item and subject to
wear. Excessive force can wear out the fader quickly. This is
not a warranted item. In case of failure. Simply unscrew the two
large screws that hold it in place, lift it out and disconnect its
cable. Re-attach the new crossfader and screw the mounting
plate back onto the unit - you’re back in business!
16. Crossfader Slope (front panel)– determines how quickly the
audio from the opposing side of the crossfader activates. A tight
curve (right position) turns on the opposing audio signal with
very little crossfader movement. A loose curve (left position)
makes very long and smooth segues in transition.
Hamster switch with Off position (front panel))– reverses the
17.
direction of the crossfader. In the center position the crossfader
is deactivated.
18. Fader Start (front panel) – activates the crossfader to send play
and cue commands to your auto-start Numark CD player or
other popular brand. For fader start, attach your mixer to a
remote start CD player using industry standard 1/8”(3.5mm)
cables. When you move the crossfader toward the active
channel, the attached CD player will start. When it is moved
away, that side will cue (similar to pressing the cue button).
OUTPUTS
19. Master Fader – controls the overall output level.
20. Stereo Auto Peak Hold Level Indicator- quickly and
accurately tracks level of audio output. Proper attention to the
meter peaks results in the punchiest possible sound without
audible distortion.
- The Leader in DJ Technology
©2000 Industries - 4 - http://www.numark.com
