Be sure to mount the GTS where its power wires are away from
other electronics, and will not interfere with any moving parts.
Mount GTS to the vehicle’s chassis with the included double-sided
•
tape (use two layers of other double-sided tapes for adequate damping).
• Mount Power Capacitor to chassis with double-sided tape or tiewrap
Cap becomes dented/damaged, ESC failure can occur--replace
immediately.
• Mount the ON/OFF switch in a position where it will be easy to
access. You can use a 4-40 or smaller screw to mount the ON/
OFF switch to a hole in the chassis, or use the included doublesided tape to mount the switch in the vehicle
• Be sure receiver & antenna are mounted as far from ESC, power
wires, battery, and servo as possible--these components all emit
RF noise when throttle is being applied. On graphite or aluminum
chassis vehicles, it may help to place receiver on edge with crystal
& antenna as far above chassis as possible.
Note: Mount antenna as close to receiver as possible--trail any excess wire off top
of antenna mast (cutting or coiling excess antenna wire will reduce radio range).
step step
step
step step
For proper ESC operation, adjust transmitter as follows:
A. Set HIGH ATV or EPA to maximum setting.
[amount of throw at full throttle]
B. Set LOW ATV, EPA, or ATL to maximum setting.
[amount of throw at full brakes]
C. Set EXPONENTIAL to zero setting. [throttle channel linearity]
D.
Set THROTTLE CHANNEL REV. SWITCH to either position.
E. Set THROTTLE CHANNEL TRIM to middle setting.
[adjusts neutral position/increases or decreases coast brakes]
F. Set ELECTRONIC TRIGGER THROW ADJUSTMENT to 70%
throttle and 30% brake throw (or 7:3). [older radios only]
[adjusts trigger throw electronic/digital pistol-grip transmitters]
G. Set MECHANICAL TRIGGER THROW ADJUSTMENT to position
with 2/3 throttle and 1/3 brake throw.
[adjusts trigger throw on mechanical/analog pistol-grip transmitters]
step step
step
step step
With GTS connected to (at least) a receiver & a charged battery pack:
1. TURN ON THE TRANSMITTER’S POWER
2. TURN ON THE SPEED CONTROL’S POWER
PRESS & HOLD GTS’S ONE-TOUCH/SET BUTTON
3.
With transmitter throttle at neutral, press and hold the SET button.
4.
CONTINUE HOLDING SET BUTTON UNTIL RED LED COMES ON
5. RELEASE GTS’S SET BUTTON AS SOON AS LED TURNS RED
6.
PULL TRANSMITTER THROTTLE TO FULL-ON POSITION
Hold it there until the green status LED turns solid green.
Note: Motor will not run during programming even if connected.
7. PUSH TRANSMITTER THROTTLE TO FULL-BRAKES
Hold it there until the green status LED blinks green.
8. RETURN TRANSMITTER THROTTLE TO NEUTRAL
Red status LED will turn solid red, indicating that throttle is at neutral,
and proper programming has been completed--you’re done.
NOTE: If transmitter setting are changed, programming must be repeated.
If you experience any problems, turn off ESC and repeat programming.
You do not need to repeat One-Touch programming after changing motors.
44
4
–MOUNTiNG ESC
44
(if using tie-wraps, be careful not to dent body of Power Cap). If Power
Longer Power Capacitor wires decrease performance.
.
55
5
–transmitter adjustments
55
66
6
–
one-touch programming
66
www.teamnovak.com
trouble-shooting guide
Steering Channel Works But Motor Will Not Run
• Check motor connections. Check motor and brushes.
•
Make sure input signal harness is plugged into throttle channel of
and the ESC. Check throttle channel operation with a servo. Check wiring
color sequence of receiver signal harness.
• Possible thermal shut-down (red status LEDs flashing)––Check motor,
brushes, & drive train. ESC is being over-loaded.
• Possible internal damage––Refer to Service Procedures.
Receiver Glitches/Throttle Stutters During Acceleration
• Receiver or antenna too close to ESC, power wires, battery, or motor.
• Bad connections––Check wiring and connectors.
• Motor brushes worn––Replace brushes.
•
Excessive motor current––Use milder motor or smaller pinion gear.
•
External Power Capacitor damaged/not installed––Replace Power Capacitor.
Motor and Steering Servo Do Not Work
•
Check wires, receiver signal harness wiring & color sequence, radio
crystals, battery & motor connectors, and battery pack.
• Possible internal damage––Refer to Service Procedures.
Model Runs Slowly/Slow Acceleration
• Check motor and battery connectors––Replace if needed.
• Bad battery or motor––Check operation with another.
•
Incorrect transmitter/ESC adjustment––Refer to Steps 4 & 5.
•
External Power Capacitor damaged/not installed––Replace Power Capacitor.
• Schottky diode damaged––If using external Schottky, check that diode is
installed correctly/Refer to Step 2. Possible internal Schottky damage.
Motor Runs Backwards
• Motor wired backwards––Check wiring and reverse.
• Backwards motor timing––Reverse motor end bell.
•NOT ALL TRANSMITTERS HAVE ALL THESE ADJUSTMENTS•
ESC Is Melted Or Burnt/ESC Runs With Switch Off
• Internal damage––Refer to Service Procedures.
*For more assistance call our Customer Service Department.
service procedures
Before sending your GTS in for service, review Trouble-Shooting guide &
instructions. ESC may appear to have failed when other problems exist.
After reviewing instructions, if you feel your GTS requires service, please
obtain the most current product service options & pricing by the following:
WEBSITE:
SERVICE section of the website. Fill out the needed information on this
form and return it with the Novak product that requires servicing.
PHONE/E-MAIL:
customer service dept. by phone or e-mail as listed on the front page.
WARRANTY SERVICE:
on PRODUCT SERVICE FORM & include a valid cash register receipt with
purchase date and dealer name & phone# on it, or an invoice from previous
service. If warranty provisions have been voided, there will be service charges.
GTS ESCs returned without a serial number will not be serviced under warranty.
ADDITIONAL NOTES:
• Hobby dealers or distributors are not authorized to replace Novak products
thought to be defective.
•
If a hobby dealer returns your GTS for service, submit a completed PRODUCT
SERVICE FORM to the dealer and make sure it is included with the ESC.
• Novak Electronics, Inc. does not make any electronic components
(transistors, resistors, etc.) available for sale.
Print a copy of the PRODUCT SERVICE FORM from the CUSTOMER
product warranty
The GTS speed control is guaranteed to be free from defects in materials or workmanship for a period of 120 days from the original date of purchase (verified by
itemized sales receipt). Warranty does not cover incorrect installation, components
by use, damage to case, damage from using fewer than 4 or more than 6 cells (1.2
volts DC/cell) input voltage, crosstabs, reverse voltage
receiver battery pack, not installing three 0.1µF (50V) capacitors on motor, incorrect
installation of or not using a Power Capacitor on the ESC or from using a damaged
Power Capacitor
age from excessive
bling case, tampering with internal electronics, allowing water, moisture, or any other
foreign material to enter ESC or get onto the PC board, incorrect installation
input plug plastic, allowing exposed wiring or solder tabs to short-circuit, or any
damage caused by a crash, flooding, or act of God.
In no case shall our liability exceed the product's original cost. We reserve the right to
modify warranty provisions without notice.
Because Novak Electronics, Inc. has no control over the connection & use of the speed
control or other related electronics, no liability may be assumed nor will be accepted
any damage resulting from the use of this product. Every Novak speed control is
thoroughly tested & cycled before leaving our facility and is, therefore, considered
operational. By the act of connecting/operating speed control, user accepts all resulting liability.
©2005 Novak Electronics, Inc. • All Rights Reserved • No part of these operating
instructions may be reproduced without the written permission of Novak Electronics
Inc. • GTS Pro Sport ESC, Polar Drive Technology, Radio Priority Circuitry, & OneTouch Set-Up are all trademarks of Novak Electronics, Inc. • All Novak speed controls
are designed & manufactured in the U.S.A.
receiver
system,
If you do not have access to the internet, contact our
For warranty work, you MUST CLAIM WARRANTY
dated,
worn
application, damage from incorrect
, using a non-Novak Power Capacitor, splices to input harness, dam-
force when using the One-Touch/SET button or from disassem-
connection of battery/motor, overheating solder
installation of FET servo or
/wiring of
for
✫✪✼✲✬✄✼✮✽
✑
✾✹
✄
✰✾✲✭✮✄✑✑✄
✰✽
SPECIFICATIONS
Input Voltage.......................................... 4-6 cells (1.2 volts DC/cell)
Motor Limit ......................
Footprint ..............................................
Pro Sport Electronic Speed Control
#55-1940-1
6-2005
Weight (w/o wires) ............................................... 0.74 ounce [21 grams]
On-Resistance @ Transistors**................................................ 0.00040 Ω
Rated Current (forward) ..........................................................540 amps
Braking Current ............................................................ 360 amps
B.E.C. Voltage/Current................................ 5.0 volts DC/1.0 amp
Power Wire ............................................................... 14G Silicone
Signal Harness
PWM Frequency ............................................................... 1.2 kHz
(replaceable) ....................................... 9 inches
SMALL...LIGHTWEIGHT...ECONOMICAL...EASY-TO-USE...RELIABLE.....any other requests?
With the same technology as Novak’s top-of-the-line GTX, the GTS Pro Sport ESC is the
perfect choice for those wanting to step up to the exciting world of racing.
Built with state-of-the-art components just like our World Champion GTX speed control, high-frequency operation for ultra-smooth
throttle response, and thermal overload protection circuitry, the GTS is ready to help you make your mark in today’s racing community.
The GTS also features the ease & convenience of Novak’s original One-Touch programming, user-replaceable
power wires, power capacitor, & input harness--just what you need to get to the top of the podium!
To get the most out of your GTS, PLEASE READ ALL INSTRUCTIONS before using
PRECAuTIONS
WATER & ELECTRONICS DON’T MIX!
Never allow water, moisture, or other foreign materials to get
Damage from water or foreign material will void the warranty!
DISCONNECT BATTERIES WHEN NOT IN USE
when not in use to avoid short circuits and possible fire hazard.
Never use fewer than 4 or more than 6 cells (7.2 volts DC) in
Reverse battery polarity can damage speed control––Disconnect
An external power capacitor is supplied & installed, and MUST be
result in
Always turn on the power of the transmitter first so that you
electrical tape to prevent short circuits, which can damage ESC.
,
Exposure to CA glue or its fumes can cause damage to internal
components of the speed control and result in premature failure.
inside the speed control or on the PC Board.
Always disconnect the battery pack from the speed control
4 TO 6 CELLS ONLY
the vehicle’s main battery pack.
NO REVERSE VOLTAGE!
the battery immediately if a reverse connection occurs.
POWER CAPACITOR REQUIRED
used with your GTS. Failure to use Novak Power Capacitor will
higher ESC operating temperatures & will void warranty!
TRANSMITTER ON FIRST
will have control of the vehicle when you turn it on.
INSULATE WIRES
Always insulate exposed wiring with heat shrink tubing or
NO SOLVENTS
Exposing the speed control’s Lexan® case to any type of
solvents will damage the plastic.
NO CA GLUE
optional accessories
STANDARD REPLACEMENT POWER CAPACITORS [#5677]
An external power capacitor is installed, and MUST BE USED to
maintain cool and smooth operation. Refer to Fig.5 Set-Up Photo
Replacement Power Capacitors available in Novak kit #5677.
LARGE POWER CAPACITORS [FOR EXTREME RACING] [#5675]
Novak Power Capacitor that comes with the World Champion GTX
speed control--for additional ESC cooling & improved performance.
Optional Large Power Capacitors available in Novak kit #5675.
RACING SCHOTTKY MOTOR MODULES [#5636]
The GTS has a built-in Schottky diode and should not require an
external one for most usage--using an external Schottky will optimize
the ESC’s braking and motor performance
Racing Schottky Motor Module is available in Novak kit #5636.
MOTOR CAPACITORS [#5620]
Additional motor capacitors are available in Novak kit #5620.
14G SUPERFLEX SILICONE POWER WIRE [#5500 & 5505]
Replacement GTS battery & motor wire is available in Novak kits #5500
(36”red & 36”black) & #5505 (36”red & 36”blue).
INPUT SIGNAL HARNESS [#5315 & #5320]
The user-replaceable input
and long lengths to fit different applications.
4.5” harness in Novak kit #5315, and 9.0” harness in kit #5315.
Novak Electronics, Inc.
(949) 833-8873 • FAX (949) 833-1631
Customer Service e-mail: cs@teamnovak.com
Monday-Thursday: 8:00am-5:00pm (PST)
Friday: 8:00am-4:00pm
P1P4
www.teamnovak.com
Brush-type R/C motors down to 12 turns
1.31”x1.10” [33.3x27.9mm]
[22.8 cm]
**Transistor rating @ 25°C
(recommendeed for racing)
signal harness is available in both short
(closed every other Friday)
.
stepstep
step
stepstep
The GTS has the industry-standard receiver input connector on a
user-replaceable input harness & works with all major radio brand’s
new receivers. However, some very old receivers must have the
wiring sequence in the plastic 3-pin connector housing changed.
changing wiring sequencechanging wiring sequence
changing wiring sequence
changing wiring sequencechanging wiring sequence
11
1
–
connect input harness
11
This is important, because receiver & servo electronics
may be damaged if the sequence is incorrect.
receiver endreceiver end
@@
@
receiver end
@@
receiver endreceiver end
JR • Hitec • Futaba • New KO • Airtronics Z
JR, Hitec, Futaba, new KO, & Airtronics Z receivers do not need input
harness re-wiring.
KO cases have tabs on the input harness openings as in Figure 1.
•
Plug one end of the input harness into the
receiver with the BLACK wire toward the outside edge of receiver case.
• Plug the other end of the input harness into 3-pin header inside
the ESC’s case with the BLACK wire toward the left edge of the
ESC’s case & the WHITE wire toward the middle of the ESC’s case.
input harness
opening
black wire
toward edge
of case
New KO (with tabs) Old KO (no tabs)
tabs
white
red
FIGURE 1
black
Airtronics Z receivers have blue plastic cases & new
– + S
THROTTLE CHANNEL (#2)
no tabs
white
black
FIGURE 2
red
white wire
middle of
of
toward
ESC
Old-style KO • Old-style Sanwa/Airtronics
If your receiver is an older KO or Sanwa/Airtronics, you must change
the sequence of the ESC’s input harness wires.
Old Sanwa/Airtronics cases are black in color & Old KO cases do not
have the tab openings, as in Figure 2 above.
• Using a small standard/flat blade screwdriver, remove the red and
black wires from the plastic 3-pin connector housing at the receiver
end of the input harness as in Figure 3 below.
• Interchange the red and black wires in the plastic 3-pin connector
housing at the receiver end of the input harness.
• Insert modified 3-pin end of the harness into the receiver with the
RED wire toward the outside edge of receiver case.
FIGURE 3 With a small standard screwdriver, gently lift plastic prong
until wire and metal socket easily slide out of plastic housing.
stepstep
step
stepstep
22
2
–MOtor prep
22
1. MOTOR CAPACITORS
Electric motors generate RF noise that causes interference.
included 0.1µF (50V) non-polarized, ceramic capacitors
used on all motors to reduce motor noise & prevent ESC damage.
Note: Some motors come with capacitors built-in. If your motor
only has two capacitors, you need to install a capacitor between
the positive & negative motor tabs––If you experience radio inter
ference when using only built-in capacitors, install external ones.
Solder 0.1µF (50V) capacitors between:
• POSITIVE (+) motor tab & NEGATIVE (–) motor tab.
• POSITIVE (+) motor tab & GROUND tab*.
• NEGATIVE (–) motor tab & GROUND tab*.
*If motor has no ground tab (below), solder the capacitors to motor can.
Negative (–) motor tab
0.1µF Capacitors
Schottky diode
Positive (+) motor tab
FIGURE 4
Extra 0.1µF capacitors are available in Novak kit #5620.
Ground / motor can
2. INSTALLING OPTIONAL SCHOTTKY DIODE
The GTS has a built-in Schottky diode and should not require an
external one under standard conditions. The external Schottky
will optimize the ESC’s braking and motor performance in racing
applications with heavy or repeated braking (lap after lap), or
when using low-turn modified motors.
If using a Schottky diode with axial leads like shown in the photo
•
above
(older Novak style--35V/8A minimum)
CLOSEST to the silver stripe on the body of the Schottky diode
to the POSITIVE (+) motor tab. Solder the lead OPPOSITE the
silver stripe on the body to the NEGATIVE (–) motor tab.
If using the Novak Racing Schottky Motor Module
•
perfoming Schottky diode available)
module to the POSITIVE (+) motor tab. Solder the black wire
from the Schottky module to the NEGATIVE (–) motor tab.
If Schottky diode is installed backwards it will be destroyed. Replace
only with Schottky diodes with a minimum rating of 35 volts/8 amps.
Racing Schottky Motor Modules are available in Novak kit #5636.
, solder the red wire from the
, solder the lead
FIGURE 5: SET-UP PHOTO
(in-line ’single wire method’ of red wire shown)
Trail excess wire off
top of antenna mast
Three
0.1µF (50V)
ceramic
capacitors
Red power wire
(battery &
motor positive)
The
must be
-
(this is the best
Keep receiver & antenna as
far from motor, servo, battery,
stepstep
step
stepstep
To get the best possible performance from your GTS, it is essential
that you make very good connections between the battery, speed
control, & motor. A common cause of perfomance problems & ESC
failures is poor solder joints
skills, we suggest seeking assistance at your local hobby shop or track.
• Keep the ESC and its power wires away from other electronics
in the vehicle, especially the receiver & antenna.
• Do not bundle receiver/signal wires with other wires--messy
installations account for nearly all radio interference (glitching)
problems. A clean looking install almost always works better.
• Route ESC wires to clear any moving parts in the vehicle.
• Airflow through the ESC’s heat sink is a huge performance plus.
Like a real car, cooling is everything--if you can mount the ESC
where it will see some air flow, it will run cooler; and that means
that the ESC will be even more efficient (and make you faster!).
Once you’ve decided where to put the GTS in the vehicle, it’s time for
some wiring. The GTS uses a high-performance 3-wire system where
the battery & motor share the same red wire. You can direct solder
your system for the least amount of resistance
soldering/desoldering battery pack each run)
motor connectors as discussed at the end of this section.
1.
PREP & SOLDER SPEED CONTROL’S RED WIRE
Depending on your vehicle’s configuration, there are two main ways that
you can make the red wire connections--making a “Y”
red wire to go to the motor & battery, or a single wire set-up where the red
wire goes to the battery and then continues on to the motor
using the single wire method
a.a.
a.
Position the GTS where it will be mounted, strip a 1/4-3/8” section
a.a.
of insulation from the mid-section of its red wire where
solder it to positive
the middle)
b.b.
b.
Solder the exposed section of wire to positive
b.b.
or the positive (+) end of the battery pack
c.c.
c.
Cut the GTS’s red wire
c.c.
so it will reach the final component
and strip 1/8-1/4” of insulation off the end. Twist & tin the wire.
d.d.
d.
Solder the tinned end of the GTS’s red wire to the final
d.d.
component--battery positive (+) or positive (+) tab of the motor.
& power wires as possible.
33
3
–
wiring speed control, motor, & battery
33
--If you have any doubts about your soldering
select a mounting location
(this method will require
, or you can use battery &
(or “T”) out of the
(or vice versa).
(+)
. Tin the exposed section of wire with solder.
of the motor or battery
(after the first connection)
(battery positive or motor positive)
FIGURE 6: ‘Y’ METHOD OF WIRING
(component that is in
(+)
tab of the motor
[see Figure 5: Set-Up Photo].
to the proper length
:
:
you will
continued –>
using the “y” method
a.a.
a.
Strip a 1/4-3/8” section of insulation from the mid-section of the
a.a.
GTS’s red wire where you want to split and go to the motor &
battery. Tin the exposed section of wire with solder.
b.b.
b.
Strip a 1/4” of insulation off the one end of the extra piece of red
b.b.
wire that came with the GTS. Twist & tin the wire.
c.c.
c.
Slide the supplied piece of heat shrink tubing over the red wire
c.c.
coming from the GTS, and slide it all the way to the ESC.
d.d.
d.
Solder the tinned end of the extra piece of red wire to the
d.d.
section along the GTS’s red wire & shrink the tubing over the solder
joint with a heat gun
e.e.
e.
Cut one end of the GTS’s red wire
e.e.
length so it will reach the positive
1/8-1/4” of insulation off the end. Twist & tin the wire.
f.f.
f. Solder this end of the GTS’s red wire to the positive (+) motor tab.
f.f.
g.g.
g.
Cut the other end of the GTS’s red wire to the proper length so it
g.g.
will reach battery pack positive (+) and strip 1/8-1/4” of insulation
off the end. Twist & tin the wire.
h.h.
h.
Solder this end of the GTS’s red wire to battery positive (+).
h.h.
(a lighter or match also works well).
(after the ”Y”)
(+) tab of the motor
:
(Figure 6)
to the proper
and strip
tinned
2. PREP & SOLDER GTS’S BLUE & BLACK WIRES
a.a.
a.
Cut the end of the GTS’s blue wire to the proper length so it will
a.a.
reach the negative
insulation off the end. Twist & tin the wire.
b.b.
b.
Solder the end of the GTS’s blue wire to motor negative (
b.b.
c.c.
c.
Cut the end of the GTS’s black wire to the proper length so it will
c.c.
reach battery pack negative
off the end. Twist & tin the wire.
d.d.
d.
Solder the end of the GTS’s black wire to battery negative (
d.d.
charged 4 to 7 cell pack.
TIP: Twisting BLUE & RED wires once or twice around each other as they
go to the motor helps reduce RF noise emitted from power wires.
using battery & motor connectorsusing battery & motor connectors
using battery & motor connectors
using battery & motor connectorsusing battery & motor connectors
Battery & motor connectors can be used for making your connections.
If you are going to use connectors for your battery and/or motor, we
suggest the Dean’s Ultra Connectors--do not use crimp on types.
When using battery and motor connectors, please note the following:
• If you have any doubts about your soldering skills, seek assistance
from your local hobby shop or track, or see our website for tips.
• Use connectors that cannot be plugged in backwards--reverse
voltage will damage the GTS and void the warranty.
• Use a female connector on battery packs to avoid shorting.
• If using connectors for both battery & motor leads, use a male
connector on the GTS’s battery lead and a female on the GTS’s
motor lead to prevent cross connection
For additional information on connector usage, visit our website.
(–) tab of the motor and strip 1/8-1/4” of
–
).
(–)
and strip 1/8-1/4” of insulation
–
) of a
(also voids warranty).
using a receiver battery packusing a receiver battery pack
using a receiver battery pack
using a receiver battery packusing a receiver battery pack
If using an external receiver battery pack with the GTS:
1. Plug an external 5 cell (1.2VDC/cell) receiver battery pack into
the battery slot of the receiver.
2. Leave the GTS’s ON/OFF switch in the OFF position, and use
receiver battery pack’s ON/OFF switch to turn the system power
on and off––Do not use the GTS’s switch.
4 to 7 cell
(+)
Racing Schottky Motor Module
P2 P3
(–)
optional
(tape to chassis)
Blue power wire
(motor negative)
(+)
insulate exposed
wiring & leads
Power Capacitor
(tape or tie-wrap to chassis)
status LEDs
One-Touch/“SET”
programming button
battery pack
ON/OFF switch
(screw or tape to chassis)
(–)
Black power wire
(battery negative)
User-replaceable
input harness
why you want the power capictorwhy you want the power capictor
why you want the power capictor
why you want the power capictorwhy you want the power capictor
The GTS comes with factory-installed power Capacitor that drops ESC operating temperatures by
10-15°F (remember, cooler means your GTS will be more efficient & faster) and dissipates noise &
voltage spikes from the ESC’s high switching speed that gives the GTS its smooth throttle response.
You MUST use Novak Power Capacitors--other capacitors with similar ratings don’t provide the
same protection. We’ve done extensive research to find capacitors with the very best quality factors.
ON/OFF switch
screwed to chassis
‘Y’ in red wire
heat shrink all
exposed wiring
Optional large Power
Cap taped to chassis
replacing power wiresreplacing power wires
replacing power wires
replacing power wiresreplacing power wires
When replacing the battery or motor power wires at the GTS’s solder
tabs, it’s important to not overheat PCB (printed ciruit board) with the
soldering iron by applying prolonged or excessive heating.
• Remove wires from the tab by first removing GTS from vehicle to
access solder joints on the bottom of the tabs. Use a soldering iron
to apply heat to the wire’s solder joint while gently pulling on the
wire to remove it from the hole in the PC Board.
• Replace the wires by stripping 1/8-1/4” of insulation from the end
of the new wire. Tightly twist the wire strands and lightly tin with
solder. Insert the wire end into the proper hole in the PC Board
there is still solder in the hole you can melt it with the iron while pushing the
wire through the hole). Apply heat to the section of wire that is sticking
through the tab’s hole, and add solder to the tip of the soldering
iron and to the wire. Add just enough solder to form a clean &
continuous joint from the plated area of the solder tab up onto the
wire. Use side cutters to trim excess wire above tab
@@
solder tabssolder tabs
@
solder tabs
@@
solder tabssolder tabs
(about 1/16”).
(if
Loading...
