Page 1

Enterprise Edge Voice Messaging Reference Guide

1-800-4 NORTEL www.nortelnetworks.com

Page 2

Page 3

Chapter 1 How to use this guide 7

Introduction 7 Conventions and symbols used in this guide 8 Prerequisites 8

Chapter 2 Using Enterprise Edge Voice Messaging 9

Introduction 9 Enterprise Edge telephones 9

Enterprise Edge one line display telephones 9

Enterprise Edge two line display telephones 10 Alternate extensions 10 Enterprise Edge ATA 2 11 Entering characters on the Enterprise Edge dialpad 11 Enterprise Edge Voice Messaging voice prompts 12

Interrupting a voice prompt 12 Automated Attendant 13 Types of mailboxes 13

Personal mailbox 13

Information mailbox 14

Special mailboxes 14

Chapter 3 Setting up your mailbox 15

Introduction 15 Initializing your mailbox 15 Opening your mailbox 17

Opening a mailbox after it is initialized 17

Opening your mailbox remotely 17 Mailbox Password 18

Changing your mailbox password 18 Company Directory 19

Recording or changing your name in the Company Directory 19 Assigning a Target Attendant 20

Chapter 4 Feature codes and mailbox options 21

Introduction 21 Feature codes 21

Determining custom feature codes 23

Programming a memory button with a feature code 24 Mailbox options 24

Main Mailbox menu and options 25

Mailbox Administration menu 25

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 4

4 Contents

Chapter 5 Greetings 27

Introduction 27 Types of mailbox greetings 27

Personal mailbox greetings 27

Information mailbox greetings 29 Recording the Primary or the Alternate mailbox greeting 29 Choosing the Primary or the Alternate mailbox greeting 31 Recording a Personalized mailbox greeting 32 Deleting a Personalized mailbox greeting 33 Recording an Information mailbox greeting 34

Chapter 6 Accessing your messages 35

Introduction 35 Receiving calls 35 Enterprise Edge Voice Messaging Never Full mailbox feature 35 Listening to your mailbox messages 36

About erased messages 38 Call Screening 39

Chapter 7 Sending messages 41

Introduction 41 Types of messages 41

Broadcast messages 41

Personal messages 41 About recording and sending a message 42 Using the Company Directory 42 Message delivery options 44

Assigning message delivery options using the Open Mailbox feature

Assigning message delivery options using the Leave Message feature

46 Recording and sending a message using the Open Mailbox feature 46 Recording and sending a message using the Leave Message feature 47 Replying to messages 48

Replying to an internal message sender 48 Replying to an external message sender 49

Sending a message to more than one recipient 49

Sending a message using a Group List 49 Copying a message to other recipients 50 Forwarding a copy of a message to one or more recipients 50

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 5

Chapter 8 Call Forwarding your calls 51

Introduction 51

Call Forwarding your calls to Enterprise Edge Voice Messaging 51 Setting up Call Forward remotely 51 Call Forward with Caller ID (CLID) 52

Chapter 9 Transferring calls 55

Introduction 55 Transferring calls to an Enterprise Edge Voice Messaging mailbox 55

Transferring a mailbox owner’s call to Enterprise Edge Voice

Messaging 56 Transferring calls from your mailbox to the Operator 57 Transferring calls from your mailbox to the Automated Attendant 57 Transferring a call to Custom Call Routing (CCR) 57 Outbound Transfer 58 Adding special characters to the destination number 58

Optimizing Outbound Transfer 60 Programming an Outbound Transfer telephone number when Enterprise

Edge Voice Messaging is behind PBX or Centrex+ 60

Setting up Outbound Transfer to a phone number 61 Setting up Outbound Transfer to an extension 61 Changing the Outbound Transfer parameters 62 Turning Outbound Transfer on and off 63

Contents 5

Chapter 10 Off-premise Message Notification 65

Introduction 65 About Off-premise Message Notification 65 Setting up Off-premise Message Notification to a phone number 66 Setting up Off-premise Message Notification to an extension 68

Setting up Off-premise Message Notification to a pager number 70

Changing Off-premise Message Notification 72

Changing Off-premise Message Notification parameters 72 Changing the destination type from a pager to a telephone or extension

Changing the destination type from phone or extension to a pager 75

Setting up Off-premise Message Notification to more than one destination

76 Deleting an Off-premise Message Notification destination number 78 Inserting an Off-premise Message Notification destination number 79 Turning Off-premise Message Notification on and off 80

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 6

6 Contents

Chapter 11 Recording a call 81

Introduction 81 Using Call Record 81

Chapter 12 Enterprise Edge Voice Messaging Tips 83

Introduction 83 Enterprise Edge Voice Messaging Tips 83

Chapter 13 Troubleshooting 85

Introduction 85

Appendix A: Default values and tone commands 89

Default mailbox numbers for the General Delivery mailbox 89

DTMF tone commands for setting up Of f-premise Message Notific ation

Glossary 91

Index 97

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 7

How to use this guide

Introduction

Use the Enterprise Edge Voice Messaging Reference Guide with the Enterprise Edge Voice Messaging Quick Reference Guide. The Enterprise Edge Voice Messaging Reference Guide gives you detailed information about using the

Enterprise Edge Voice Messaging system. This chapter describes:

• How the Enterprise Edge Voice Messaging Reference Guide is organized

• Conventions and symbols used in this guide

• Prerequisites

How the

Enterprise Edge Voice Messaging Reference Guide

organized

The Enterprise Edge Voice Messaging Reference Guide contains the following chapters:

Chapter Description

1. How to use this guide Describes the contents and conventions of this guide.

2. Using Enterprise Edge Voice Messaging Describes Enterprise Edge telephones, how Alternate sets work, Enterprise Edge ATA 2, entering characters on the Enterprise Edge dialpad, Enterprise Edge Voice Messaging voice prompts, the Automated Attendant, types of mailboxes and exiting Enterprise Edge Voice Messaging.

3. Setting up your mailbox Shows how to initialize and open your mailbox. Explains passwords, the Company Directory and Assigning a Target Attendant.

4. Feature codes and mailbox options Describes feature codes and mailbox options.

5. Greetings Describes Primary, Alternate, Personalized and Information mailbox gr eetings . Shows how to recor d and choose greetings.

6. Accessing your messages Describes Receiving Calls, the Enterprise Edge Voice Messaging Never Full mailbox feature, listening to your mailbox messages, and Call Screening.

7. Sending messages Explains types of messages, using the Company Directory, message delivery options, recording and sending a message, replyi ng to m essages and how to send a message to more than one recipient.

8. Call Forwarding your calls Describes Call Forwarding your calls.

9. Transferring calls Describes transferring calls and Outbound Transfer.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 8

8 How to use this guide

Chapter Description

10. About Off-premise Message Notification Explains what Off-premise Message Notification is and shows how to set up and change Off-premise Message Notification.

11. Recording a call Describes the Call Record feature.

12. Enterprise Edge Voice Messaging Tips Provides suggestions for the optimal use of Enterprise Edge Voice Messaging.

13. Troubleshooting Provides helpful procedures for problems that might occur while operating Enterprise Edge Voice Messaging.

Appendix A: Default values and tone commands

Glossary Defines terms used in this guide. Index Provides an alphabetical list of information contained in

Provides a list of default values and tone commands.

this guide.

Conventions and symbols used in this guide

The following conventions and symbols are used for describing features and their operation:

Convention Example Used for

Word is in a special font (shows top line of display)

Underlined word in capital letters (shows bottom line of a two-line display tel ephone)

Dialpad buttons

Pswd:

PLAY

Command line prompts. Used on Enterprise Edge one line and two line display telephones.

Display button option. Available only on Enterprise Edge two line display tele phones button directly below the option on the display to proceed.

Represents the buttons you press on the dialpad to select a particular option.

Prerequisites

If you are a new user, make sure you are familiar with how to operate Enterprise Edge single-line and two-line display telephones. Refer to Enterprise Edge

telephones on page 9 and read the Enterprise Edge Telephone User Card that came

with your telephone. For more information about Enterprise Edge Voice Messaging, ask your System

Administrator.

You can press the

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 9

Using Enterprise Edge Voice Messaging

Introduction

Enterprise Edge Voice Messaging works with the Enterprise Edge system to provide an automated receptionist service. Enterprise Edge Voice Messaging answers incoming calls, routes them to extensions and mailboxes in the system, and provides message taking capability.

This chapter describes:

• Enterprise Edge telephones

• Alternate extensions

• Enterprise Edge ATA 2

• Entering characters on the Enterprise Edge dialpad

• Enterprise Edge Voice Messaging voice prompts

• Automated Attendant

• Types of mailboxes

Enterprise Edge telephones

Enterprise Edge one line display telephones

You can use Enterprise Edge one line display telephones for most Enterprise Edge Voice Messaging sessions. If you are a using an Enterprise Edge one line display telephone, the display shows the Enterprise Edge Voice Messaging display command line. The Enterprise Edge one line display telephone does not show the display button options.

On an Enterprise Edge one line display telephone, all options are given immediately by the voice prompts. You make selections using the dialpad only. You do not need to wait for the voice prompt to complete the option list. You can interrupt the voice prompt and make your selection immediately.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 10

10 Using Enterprise Edge Voice Messaging

Enterprise Edge two line display telephones

Enterprise Edge two line display telephones show you Enterprise Edge Voice Messaging commands and options. All system administration tasks, such as setting up a Group List, require a two-line display telephone.

Enterprise Edge two line displays can show up to three display button options at a time. In cases where there are more options, wait for the voice prompt to state the other available options. If you know the corresponding dialpad number for the option you want, you can press it any time during the voice prompt.

Press • to return to the previous display prompt. An example of the Enterprise Edge Voice Messaging two-line display is shown in

the following Enterprise Edge two line display illustration.

Enterprise Edge two line display

Display command line Display button options

Display buttons

Alternate extensions

You can have up to two Alternate extensions for your mailbox. If a caller dials the main extension (an extension that has Alternate extensions assigne d), the call rings only at the main extension.

If the call is not answered and a message is left, a message indicator appears at the main extension and at the Alternate extension(s). You can a ccess the message from the Alternate extension(s ) with ƒ access messages from your main extension telephone.

If an Alternate extension is assigned to a telephone that has Caller ID (CLID) and Display Caller enabled, CLID information displays and an audible tone occurs at all telephones when the call goes to Enterprise Edge Voice Messaging. (For information on enabling Display Caller refer to Call Forward with Caller ID (CLID) on page 52.) The message can be intercepted using the Interrupt Feature,

message.

·°‡

Pswd: OTHR RETRY OK

·°⁄

, the same way that you usually

, at all telephones as long as the caller is still leaving a

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 11

Enterprise Edge ATA 2

You can use a single-line Enterprise Edge telephone for most Enterprise Edge Voice Messaging sessions. However, you cannot use a single-line telephone attached to an Enterprise Edge ATA 2 for Enterprise Edge Voice Messaging System Administration tasks.

There is no Message Waiting Notification when you are using an Enterprise Edge ATA 2.

Although a single-line telephone does not have a feature button, you can access Enterprise Edge Voice Messaging features.

To access Enterprise Edge Voice Messaging features, such as the Leave Message feature or the Open mailbox feature, call Enterprise Edge Voice Messaging and follow the voice prompts. You can determine the Enterprise Edge Voice Messaging extension by pressing ƒ

You can also press:

˚•·°⁄

•

Using Enterprise Edge Voice Messaging 11

·°ﬁ

on an Enterprise Edge telephone.

to open your mailbox

˚•·°‚

•

to leave a message, and follow the voice prompts.

Entering characters on the Enterprise Edge dialpad

The buttons on your Enterprise Edge telephone dialpad act as both numbers and letters. Each button represents a number and also represents letters of the alphabet.

You can enter a maximum number of 16 characters on the command line of the Enterprise Edge dialpad. The display shows 16 characters at a time. The prompt remains on the display if you enter fewer than ten characters.

If you are entering information where the prompt and the information is fewer than 16 characters, you can see both the prompt and the information you entered.

An example of a display with fewer than 16 characters, where the command line prompt remains on the display is the

Pswd:1111 OTHR RETRY OK

The prompt disappears for the following command line prompts:

Pswd

command line prompt.

Name:

•

Log:

•

Dest ph:

•

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 12

12 Using Enterprise Edge Voice Messaging

For instance, the following display shows the

Name: RETRY BKSP OK

When you begin to enter the last name, the

Name:

command line prompt disappears.

For example, if you are entering the name Partridge, you press the dialpad button

‡

for P, and the display drops the

P RETRY BKSP OK

Name:

prompt.

The command line prompt is still not shown on the display after you enter the entire name, although the name is only nine characters.

PARTRIDGE RETRY BKSP OK

Enterprise Edge Voice Messaging voice prompts

All Enterprise Edge telephones provide voice prompts.

command line prompt:

The voice prompt tells you the dialpad button to press to use different Enterprise Edge Voice Messaging options. Voice prompts provide the same options as display buttons. Prompts also provide options that do not appear on the display. If you are using an Enterprise Edge two line display telephone, you can use either the display button or the dialpad button to access the option.

On an Enterprise Edge one line display telephone the voice prompt plays immediately. If you do not choose an option after five seconds, the voice prompt replays the options. If you still do not choose an option, Enterprise Edge Voice Messaging ends the session.

On an Enterprise Edge two line display telephone the voice prompt plays after a five-second delay. If you do not choose an option, Enterprise Edge Voice Messaging ends the session.

Interrupting a voice prompt

You can interrupt a voice prompt by selecting any option on the display or dialpad. You can also interrupt a voice prompt by pressing £. You cannot interrupt a voice prompt that is informing you of an error.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 13

Automated Attendant

The Automated Attendant acts as a receptionist for incoming calls. When enabled, the Automated Attendant answers your company’s incoming telephone lines depending on the time of day. If callers know which option they want, they can interrupt the Automated Attendant by entering their selection on the dialpad of any tone-dial telephone.

The Automated Attendant provides callers with voice prompt commands associated with each of the following options:

• entering a mailbox number

• entering the extension

• using the Company Directory

• leaving a message

• reaching the Operator

• selecting an Alternate Language* (not a voice prompt)

Using Enterprise Edge Voice Messaging 13

* If your Enterprise Edge Voice Messaging system is installed with bilingual capabilities, the caller can press · to listen to the Automated Attendant in the Alternate Language.

When a caller selects an option, the Automated Attendant responds to the command either by routing the call to an extension or mailbox within your company, or directing the caller to the Company Directory or the Operator.

The caller listens and then enters the option they want to use.

Types of mailboxes

A mailbox is a storage place for messages. A Enterprise Edge Voice Messaging system can have up to 1,000 mailboxes. There are three types of mailboxes:

• Personal

• Information

• Special Most users have personal mailboxes.

Personal mailbox

A personal mailbox is assigned by the System Administrator and is maintained by the mailbox owner. A personal mailbox can be a user or a guest mailbox.

User mailbox

A user mailbox can be assigned to each mailbox owner who has an operating Enterprise Edge extension.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 14

14 Using Enterprise Edge Voice Messaging

Guest mailbox

Guest mailboxes provide temporary employees and guests with access to internal messaging and call routing features. Guest mailboxes do not have an operating extension. They are assigned a number that looks and works like an extension. This allows the guest mailbox owner to access Enterprise Edge Voice Messaging the same way a mailbox owner accesses their mailbox from another extension or telephone. If you need a guest mailbox, request one from the System Administrator.

Information mailbox

An Information mailbox is designed to provide an informative message to a caller. These mailboxes do not have an operating Enterprise Edge extension, and the caller cannot leave a message in them. A voice prompt provides a caller with access to Information mailboxes. An Information mailbox is reached through the Automated Attendant, Custom Call Routing (CCR) or the Operator. For more information, refer to Information mailbox greetings on page 29.

Information mailboxes are created by the System Administrator, and are maintained by either the System Administrator or a mailbox owner.

Special mailboxes

Special mailboxes are set up automatically when the Enterprise Edge Voice Messaging system is initialized.

The Special mailboxes include:

• General Delivery mailbox

• System Administrator mailbox

General Delivery mailbox

The General Delivery mailbox is used:

• to collect messages from callers who use a rotary dial telephone

• for individuals in your company who do not have personal mailboxes

• for mailbox owners whose mailboxes are full. For more information, refer to the

Enterprise Edge Voice Messaging Never Full mailbox feature on page 35.

The receptionist or System Administrator sends messages left in the General Delivery mailbox to the appropriate mailbox owner. For more information about the General Delivery mailbox, refer to Default mailbox numbers for the General

Delivery mailbox on page 89.

System Administrator mailbox

This mailbox is used by your System Administrator as a personal mailbox. You can leave messages for your company’s System Administrator in this mailbox.

Ask your System Administrator for the mailbox number.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 15

Setting up your mailbox

Introduction

This chapter shows you how to set up your mailbox and describes the following topics:

• Initializing your mailbox

• Opening your mailbox

• Mailbox Password

• Company Directory

• Assigning a Target Attendant

Initializing your mailbox

Initializing your mailbox prepares your mailbox to receive messages. Your mailbox cannot receive and store messages until it is initialized.

Initializing your mailbox involves:

• choosing a password from four to eight digits long that does not start with zero

• changing the Enterprise Edge Voice Messaging default password to your new password

• recording your name in the Company Directory (refer to Recording or changing

your name in the Company Directory on page 19)

To initialize your mailbox, follow the steps in Initializing and opening your mailbox

for the first time on page 16.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 16

16 Setting up your mailbox

Initializing and opening your mailbox for the first time

To initialize and open your mailbox for the first time:

Pswd: OTHR RETRY OK

Must change pswd

Pswd: RETRY OK

Again: RETRY OK

1. Press ƒ

£.

‚‚‚‚

2. Press

·°⁄

(the default password) and press

Note: If you are at another Enterprise Edge set, press

OTHR

or • to access the

From the

Log:

prompt, enter your mailbox

Log:

display prompt.

number and password as a continuous number. Your mailbox number is normally the same as your extension. Your default password is

‚‚‚‚

3. This display appears briefly to indicate that you must change your password.

4. Choose a password from four to eight digits long that does not start with zero. Enter your new mailbox password and press OK or £.

5. Enter your new mailbox password again and press OK or £.

Record name: RETRY OK

6. At the tone, record your name in the Company Directory. Press OK to end your name. Press

to erase and re-record your name.

RETRY

Note: Include your mailbox number in your

Company Directory recording. For example “Paul Wayne, mailbox 5813”.

Accept name? RETRY PLAY OK

7. Press OK or £ to accept the recording. Press

⁄

to listen to the recording. Press

RETRY

PLAY

or ¤ to

erase and re-record your name.

0 new 0 saved PLAY REC ADMIN

8. Press

to end the session.

After your mailbox is initialized, record your Personal mailbox greetings. If you do not record any Personal greetings, your Company Directory name recording plays to callers who reach your mailbox.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 17

Opening your mailbox

You can open your mailbox from:

• your own extension

• another Enterprise Edge Voice Messaging extension

• an outside telephone (as shown in Opening your mailbox remotely)

Opening a mailbox after it is initialized

This section describes how to open:

• your mailbox from your own telephone

• your mailbox from another Enterprise Edge extension

• a Guest mailbox After a mailbox is initialized, follow these steps to open it:

Setting up your mailbox 17

·°⁄

Pswd: OTHR RETRY OK

1. Press ƒ

2. Enter your mailbox password and press OK or

Note: If you are at another Enterprise Edge

extension, or if you are using a Guest mailbox,

OTHR

press

or • to access the

prompt. From the

Log:

prompt, enter your

Log:

display

mailbox number and password as a continuous number. Your mailbox number is normally the same as your extension.

Opening your mailbox remotely

If you are calling your Enterprise Edge Voice Messaging mailbox from an outside telephone, press

••

during your greeting to open your mailbox. At the voice prompt, enter your mailbox number, password and press £. Follow the voice prompts.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 18

18 Setting up your mailbox

Mailbox Password

Your password is from four to eight digits long and cannot start with zero. When you initialize Enterprise Edge Voice Messaging, the default mailbox password is four zeros (0000). You are prompted to change this password.

It is recommended that you change your password every 30 days. By changing your password regularly, you decrease the chance that someone will discover your password and gain access to your system.

Keep a written copy of your password in a safe place, and avoid giving it to your co-workers. Your mailbox password is used to keep your voice messages private and confidential. For security reasons, it is a good idea to choose an uncommon password (not a predictable password like 1234 or 1111). If someone else knows your password, they can access your mailbox and listen to or delete your messages. They can also access your Enterprise Edge Voice Messaging system and use it fraudulently or disrupt service.

Changing your mailbox password

You can change your mailbox password at any time. Remember to choose a password from four to eight digits long that does not start with zero.

To change your password:

1. Press ƒ

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Pswd: RETRY OK

Again: RETRY OK

Mailbox admin GREET PSWD QUIT

2. Enter your mailbox password and press OK or

3. Press

4. Press

5. Enter your new mailbox password and press OK or £.

6. Enter your new mailbox password again and press OK

7. Press

or £.

·°⁄

ADMIN

PSWD

or ›.

to end the session.

to open your mailbox.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 19

Company Directory

The Company Directory is a list of mailbox owners on the Enterprise Edge Voice Messaging system. Before your mailbox can be used to receive messages, you must record your name in the Company Directory. It is a good idea to include your mailbox number in your Company Directory recording. For example “Paul Wayne, mailbox 5813”.

This establishes your “voice” name in a directory that is used by other Enterprise Edge Voice Messaging users and outside callers who use the Company Directory.

If you do not want your name in the Company Directory, ask your System Administrator. The Company Directory feature can be disabled by the System Administrator. If you are unsure whether or not you have this feature, ask your System Administrator.

Recording or changing your name in the Company Directory

Names included in the Company Directory can be changed at any time. To change your name in the Company Directory:

Setting up your mailbox 19

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Record name: RETRY OK

Accept name? RETRY PLAY OK

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ⁄.

Note: This is a voice prompt option. It does not

appear as a display button option on a two-line display telephone.

5. At the tone, record your name. Press OK or

to end

your recording. The recording of your name is automatically placed in the Company Directory.

6. Press OK or £ to accept your recording. Press or ⁄ to listen to the recording. Press

RETRY

PLAY

or ¤ to erase and re-record your name in the Company Directory.

Mailbox admin GREET PSWD QUIT

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

7. Press

to end the session.

Page 20

20 Setting up your mailbox

Assigning a Target Attendant

The person that you assign to answer your telephone is your Target Attendant. After you assign your Target Attendant, a caller who reaches your mailbox can

press ‚ to speak with the Target Attendant. If the Target Attendant does not answer, the call goes to your mailbox. If your personal mailbox is not available, the call goes to the General Delivery mailbox.

Remember to tell callers in your greetings that if they need assistance they can press

‚

to speak to Target Attendant. For example, “Please press ‚to speak to my

assistant.” The Target Attendant can be any valid extension. The default Target

Attendant is the person assigned as the Enterprise Edge Voice Messaging Operator. To assign your personal Target Attendant:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Atdt ext: oper CHNG QUIT

Ext: RETRY OPER

Atdt ext: <xxx> CHNG QUIT

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or

3. Press

ADMIN

4. Press ﬁ.

5. Press

CHNG

or ⁄ to change the Target Attendant. The

Atdt ext:oper

prompt indicates that the current Target Attendant is the Enterprise Edge Voice Messaging Operator.

6. Enter the extension number of your new Target Attendant. Press

OPER

or ‚ to change the Target Attendant back to the Enterprise Edge Voice Messaging Operator.

7. The

Atdt ext:xxx

prompt appears, where

represents the extension you entered. Press

xxx

QUIT

accept the number of the Target Attendant. Press or ⁄ to change the Target Attendant.

CHNG

Press

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

to end the session.

Page 21

Feature codes and mailbox options

Introduction

This chapter describes the Enterprise Edge Voice Messaging feature codes and mailbox options, and includes the following topics:

• Feature codes

• Determining custom feature codes

• Programming a memory button with a feature code

• Mailbox options

Feature codes

The table Description of feature codes on page 23 explains the purpose of each Enterprise Edge Voice Messaging feature code.

Feature codes are assigned during installation. The feature codes in this guide are the default feature codes. If your company is using custom feature codes, you need to find out what the custom feature codes are. To determine the Enterprise Edge Voice Messaging custom feature codes, refer to Determining custom feature codes on page 23.

Once you know the feature codes that your company is using (default feature codes or custom feature codes), you can program the feature codes onto memory buttons. For information, refer to Programming a memory button with a feature code on page 24.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 22

22 Feature codes and mailbox options

Feature Code Name Default feature code Description

Leave Message

Open Mailbox

Operator Status

Call Forward to Enterprise Edge Voice Messaging

Enterprise Edge Voice Messaging extension

Transfer Interrupt

Call Record

·°‚

·°⁄

·°¤

·°›

·°ﬁ

·°ﬂ

·°‡

·°·

Leaves a message in a mailbox. No password is required.

Opens your Personal mailbox to listen to your messages and access Enterprise Edge Voice Messaging options. Your personal password is required.

Not a user feature. Used by the System Administrator, receptionist, or Operator to set the Operator Status.

Forwards incoming calls to Enterprise Edge Voice Messaging.

Determines the Enterprise Edge Voice Messagingextension. You nee d to know what the Enterprise Edge Voice Messagingextension is when you forward your extension to Enterprise Edge Voice Messaging.

Transfers calls to a mailbox. Interrupts Enterprise Edge Voice Messaging

when a caller is listening to your personal mailbox greeting or leaving a message. This allows you to speak with a caller who has reached your mailbox. (Refer to the Note that follows this table.)

Records a telephone call from your Enterprise Edge telephone. The resulting message is left in your mailbox.

Note: When a caller leaving a message in a mailbox is interrupted, the part of the

message that is recorded before the interruption remains in the mailbox. Delete this message. If Off-premise Message Notification is turned on, the interrupted message causes Enterprise Edge Voice Messaging to call the Off-premise Message Notification number immediately. For information on Off-premise Message Notification, refer to About Off-premise Message

Notification on page 65.

If Outbound Transfer is turned on, you cannot interrupt the call unless you interrupt it before the caller transfers to your Outbound Transfer destination number by pressing ‡. For information on Outbound Transfer, refer to

Outbound Transfer on page 58.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 23

Feature codes and mailbox options 23

Determining custom feature codes

If your company is using custom feature codes, find out what the custom feature codes are. To determine the Enterprise Edge Voice Messaging custom feature codes, use an Enterprise Edge two line display telephone.

To determine the Enterprise Edge Voice Messaging feature codes:

Leave msg: F9xx NEXT

Open mbox: F9xx NEXT

Interrupt: F9xx QUIT

1. Press ƒ

·•⁄

2. The name and numerical code of the first feature, the Leave Message feature, is shown on the display. The

represents a number between 00 and 99. Record the custom feature code for the Leave Message feature in the appropriate column in the table Description of

feature codes on page 23. Press

3. The display shows the name and numerical code of the Open Mailbox feature. Record the feature code for the Open Mailbox feature in the appropriate column in the table Description of feature codes on page 23. Press

4. Continue pressing

to show all of the Enterprise Edge Voice Messaging feature codes and record them in the appropriate column in the table Description of

feature codes on page 23.

5. This display is shown when you reach the last Enterprise Edge Voice Messaging feature code, the Interrupt feature code. Press

QUIT

to end the

session.

After you have determined the custom feature codes, make sure that you record the custom feature codes in the appropriate column.

Table 1 Description of feature codes

Feature Code name Default feature code Custom feature code

Leave Message Open Mailbox Operator Status Call Forward to Enterprise Edge Voice

Messaging Transfer Interrupt Record Call

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

·°‚

·°⁄

·°¤

·°›

·°ﬂ

·°‡

·°·

___ ___

Page 24

24 Feature codes and mailbox options

Programming a memory button with a feature code

Each Enterprise Edge Voice Messaging feature code can be programmed to a single memory button.

To program a memory button:

Program Features

Press a button QUIT

Feature code: QUIT

F_ QUIT CLEAR

Programmed

1. Do not lift your handset. Press ƒ

2. The transient display displays

Program Features

•‹

3. Press a programmable button.

4. Press ƒ.

5. Enter the feature code number you want to program. For example, enter

·°‚

to program the Leave Message feature code. For a list of frequently used feature codes, refer to the table Description of feature

codes on page 23.

The display shows that the button has been programmed.

Repeat steps 1 to 5 for each Enterprise Edge Voice Messaging feature code you want to program.

Use one of the paper labels that came with your Enterprise Edge telephone to identify the programmed button. To use the feature, press the labeled button.

Mailbox options

To access the main mailbox menu, refer to the table Main Mailbox menu and

options on page 25. The main mailbox menu options are described in the table Main Mailbox Options on page 25.

To access the mailbox administration menu, refer to Mailbox Administration menu on page 25. The mailbox administration options are described in the table Mailbox

Administration Options on page 26.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 25

Main Mailbox menu and options

To access the main mailbox menu:

Feature codes and mailbox options 25

1. Press ƒ

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Table 2 Main Mailbox Options

Display Button

PLAY

REC

ADMIN

Button Task Description Found on Page

¤ ‹ ﬂ °

‚ £

Listening to your mailbox messages (new messages). 36 Replying to messages. 48 Listening to your mailbox messages (saved messages). 36 To change mailbox options. Refer to the Mailbox

Administration menu. To talk to an operator if an operator is available. --

About the Automated Attendant. 13

2. Enter your mailbox password and press OK or £.

3. The main mailbox menu options appear. Choose one

·°⁄

to open your mailbox.

of the options shown in the table below.

Mailbox Administration menu

To access the Mailbox Administration menu:

1. Press ƒ

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

4. Choose one of the options shown in the table Mailbox

Administration Options on page 26.

·°⁄

or °.

to open your mailbox.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 26

26 Feature codes and mailbox options

Table 3 Mailbox Administration Options

Display Button

GREET

PSWD

QUIT

Button Task Description Found on Page

⁄

› ﬁ

ﬂ °

•

Recording or changing your name in the Company Directory.

Choosing the Primary or the Alternate mailbox greeting.

Changing your mailbox password. 18 Assigning a Target Attendant. The Target Attendant

answers the call if a caller presses 0 during the call. The Target Attendant overrides the Designated Operator.

About Off-premise Message Notification. 65 Outbound Transfer. 58 Quitting the Mailbox Administration menu and

returning to the Main menu.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 27

Greetings

Introduction

This chapter describes the mailbox greetings and how to record them. This chapter includes:

• Types of mailbox greetings

• Recording the Primary or the Alternate mailbox greeting

• Choosing the Primary or the Alternate mailbox greeting

• Recording a Personalized mailbox greeting

• Deleting a Personalized mailbox greeting

• Recording an Information mailbox greeting

Types of mailbox greetings

The two types of greetings are:

• Personal mailbox greetings (which include Primary, Alternate, and Personalized greetings)

• Information mailbox greetings

Personal mailbox greetings

Personal mailbox greetings play to callers who reach your mailbox. Greetings inform callers that they have reached the correct mailbox and give callers any necessary information or instructions. You can change the greetings at any time.

After you initialize your mailbox, you can record your greetings. If you do not record any Personal greetings, your Company Directory name recording plays to callers who reach your mailbox. Refer to Recording or changing your name in the

Company Directory on page 19.

There are three types of Personal mailbox greetings: Primary, Alternate and Personalized.

Recording technique for personal mailbox greetings

When you record your Personal greetings, remember to speak clearly and at a pace that is easy to understand. After you record a greeting, you can replay it before you accept it. You can record or change a greeting from any Enterprise Edge telephone or, if you are away from the office, from any touch tone phone. When you record a greeting, do not use the Handsfree feature. You have better results if you speak directly into the handset.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 28

28 Greetings

Primary mailbox greeting

Record your Primary mailbox greeting for everyday use. In this greeting include your name and a brief message explaining to callers that you are unable to answer their calls. For example:

“Hi. This is Paul Wayne. I’m not able to t ake your call ri ght n ow. Pl ease leave me a message at the tone and I will return your call as soon as possible.”

If you are a new mailbox owner, record your Primary mailbox greeting immediately.

Alternate mailbox greeting

The Alternate mailbox greeting is normally used for special circumstances. For example:

“Hi. This is Paul Wayne. I am out of the office until Thursday, the 17th of December. Although I am out of the office, I do check my mailbox daily. Please leave me a message at the tone and I will return your call as soon as possible. Thank you.”

After it is recorded, you must choose which greeting you want Enterprise Edge Voice Messaging to play. You can change the selection at any time, and as often as needed.

Personalized mailbox greeting

Personalized mailbox greetings are available only if your company subscribes to the Caller ID (CLID) service from your local telephone company. For more information about CLID, ask your System Administrator.

A Personalized mailbox greeting plays to callers based on the caller’s phone number. Enterprise Edge Voice Messaging recognizes the assigned incoming phone number and plays the Personalized mailbox greeting. For example:

“Hi Susan. I may have missed your call, but I don’t want to miss meeting you for lunch. See you at noon.”

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 29

Greetings 29

Information mailbox greetings

Information mailboxes greetings provide messages and announcements to callers. A caller is automatically disconnected after listening to an Information mailbox greeting. Information mailboxes can be used to:

• announce sales

• provide product lists

• announce special events

For example:

“Paddy’s Dance Studio proudly presents an extravaganza of dance. The entertainment begins at 8:00 p.m. on the fourth of July. Toddlers tap is in the White Room. Folk dance is in the Green Room. Classical ballet is in the Pink Room. Contemporary jazz is in the Blue Room. The Studio and Recital Rooms are located at 222 Main Street.”

Make Information mailboxes easy for a caller to find. Do this by using your company Operator or the Automated Attendant Company greetings to route the caller. For details about Information mailboxes, ask your System Administrator.

Information mailboxes are different from Custom Call Routing (CCR) Information Mailboxes. Callers must use the CCR Tree to access a CCR Information mailbox. For more information about CCR Information Mailboxes, ask your System Administrator.

Recording the Primary or the Alternate mailbox greeting

This procedure shows you how to record your Primary or Alternate mailbox greetings. To start using Enterprise Edge Voice Messaging, only a Primary mailbox greeting is necessary. If you do not record any Personal mailbox greetings, your Company Directory name recording plays to callers who reach your mailbox.

If you record both Primary and Alternate mailbox greetings, you must choose which greeting plays. If you do not choose a greeting, the Primary mailbox greeting automatically plays. For information on how to choose a greeting, refer to Choosing

the Primary or the Alternate mailbox greeting on page 31.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 30

30 Greetings

To record your Primary or Alternate mailbox greeting:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Greeting options REC CHOOSE CFWD

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

Note: If you record a mailbox greeting from a

telephone that has not been assigned to your Personal mailbox, press shows the

Log:

prompt. When this prompt

OTHR

. The display

appears, enter your mailbox number and password. If you are using a single-line display telephone, press • at the

Pswd:

prompt to show the

prompt.

3. Press

4. Press

5. Press

ADMIN

GREET

REC

or ⁄.

or °.

or ¤.

Log:

Greeting: PRIME ALT PERS

Record new? YES NO QUIT

Record greeting: RETRY OK

Accept greeting? RETRY PLAY OK

Mailbox admin GREET PSWD QUIT

6. Press

PRIME

or ⁄ to record the Primary mailbox

greeting. Press

ALT

or ¤ to record the Alternate

mailbox greeting.

Note: If you are changing your greeting, your current

recorded Primary mailbox greeting begins to play.

7. Press

YES

or ⁄ and record your greeting at the tone.

8. Press OK or £ to end your recording.

9. Press OK or £ to accept the greeting. Press

⁄

to listen to the greeting. Press

RETRY

PLAY

or ¤ to

erase and re-record the greeting.

10. Press

to end this session.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 31

Choosing the Primary or the Alternate mailbox greeting

Primary mailbox greeting

You record a Primary mailbox greeting after initializing your mailbox. If you record a Primary and an Alternate mailbox greeting, you need to choose which greeting plays. If you do not choose a greeting, the Primary mailbox greeting plays automatically.

Alternate mailbox greeting

If you choose the Alternate mailbox greeting, you are asked whether the mailbox accepts messages. If you choose Y (yes) your mailbox receives messages in the normal way.

If you choose N (no) the following occurs:

• messages cannot be left in the mailbox

• the Alternate mailbox greeting takes precedence over all other greetings

• if a caller presses a button to cut the message short, they hear a voice prompt that says this is a special greeting

Greetings 31

• if a caller presses a button to send a fax, the fax goes to the general delivery mailbox (not your personal mailbox)

If you choose the Alternate mailbox greeting, remember to change back to the Primary mailbox greeting at the appropriate time.

To choose a Primary or Alternate mailbox greeting:

·°⁄

to open your mailbox.

or °.

or ¤.

or ¤ to choose a greeting.

or ⁄ to choose the Primary mailbox

ALT

or ¤ to choose the Alternate

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Greeting options REC CHOOSE CFWD

Use greeting: PRIME ALT QUIT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

4. Press

5. Press

6. Press

ADMIN

GREET

CHOOSE

PRIME

greeting. Press mailbox greeting.

Note: If you choose the Alternate mailbox greeting,

go to step 7. If you choose the Primary mailbox greeting, go to step 8.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 32

32 Greetings

Accept msgs:Y CHNG OK

7. If you choose the Alternate mailbox greeting, you are asked whether the mailbox accepts messages. Press

CHNG

to toggle from yes to no. If you choose Y (yes)

then the mailbox can receive messages. If you choose

(no) messages cannot be left in the mailbox. Press

Mailbox admin GREET PSWD QUIT

8. Press

to end the session.

Note: If you have chosen a greeting that is not yet recorded, you are transferred back to the greeting options menu to record the greeting.

Recording a Personalized mailbox greeting

If your company subscribes to a CLID service, you have the option of recording a Personalized mailbox greeting. For more information about CLID, ask your System Administrator. The Personalized mailbox greeting plays only for a person calling from the phone number that you designate. For the Personalized mailbox greeting to play, the phone number you enter must match the caller’s phone number exactly.

You can record up to three Personalized mailbox greetings, but each greeting can be assigned to only one phone number.

Note: Personalized mailbox greetings do not play if you have recorded and chosen

the Alternate mailbox greeting. The Alternate mailbox greeting takes precedence over all other greetings.

To record a Personalized mailbox greeting:

·°⁄

to open your mailbox.

or °.

or ‹ to record a Personalized mailbox

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Greeting options REC

CHOOSE CFWD

Greeting: PRIME ALT PERS

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

4. Press

5. Press

6. Press

ADMIN

GREET

REC

or ⁄.

PERS

greeting.

Greeting: RETRY OK

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

7. Enter a Personalized greeting number of 1, 2, or 3.

Page 33

Greetings 33

Ph: <none> CHNG OK

Ph: RETRY OK

8. Press

9. Enter the phone number (maximum 10 digits) to which

CHNG

or ⁄.

you are assigning the Personalized mailbox greeting. Press OK or £ to accept the phone number.

Record greeting: RETRY OK

Accept greeting? RETRY PLAY OK

10. At the tone, record the greeting. Press OK or £ to end the recording.

11. Press OK or £ to accept the recording. Press

⁄

to listen to the recording. Press

erase and re-record the greeting.

12. To record another Personalized mailbox greeting, repeat steps 5 to 11. Press

Deleting a Personalized mailbox greeting

If you program Enterprise Edge Voice Messaging with a Personalized mailbox greeting that you no longer need, you can delete the Personalized mailbox greeting.

RETRY

to end the session.

PLAY

or ¤ to

To delete a Personalized mailbox greeting:

1. Press ƒ

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Greeting options REC CHOOSE CFWD

Greeting: PRIME ALT PERS

Greeting: RETRY OK

2. Enter your mailbox password and press OK or £.

3. Press

4. Press

5. Press

6. Press

ADMIN

GREET

REC

PERS

or °.

or ¤.

or ⁄.

or ‹ to choose a Personalized mailbox

greeting.

7. Enter the Personalized greeting number (1, 2, or 3) that you want to delete.

·°⁄

to open your mailbox.

Press

DEL

or ¤ to delete the greeting.

to end the session.

Ph: XXXXXXX CHNG DEL OK

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

8. Press

Page 34

34 Greetings

Recording an Information mailbox greeting

Before you record your Information mailbox greeting, you must determine what the greeting includes. As you prepare your greeting, be sure to include important times and dates. Write the greeting down and practice reading it aloud. When you are confident the greeting includes everything you want it to, record the greeting. If you are using a Enterprise Edge Voice Messaging system with bilingual capability, you must record the Information mailbox greeting in both languages.

An Information mailbox greeting can be either a Primary or an Alternate mailbox greeting. Perform the steps in Recording the Primary or the Alternate mailbox

greeting on page 29 to record an Information mailbox greeting.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 35

Accessing your messages

Introduction

This chapter describes accessing your messages and explains the following related topics:

• Receiving calls

• Enterprise Edge Voice Messaging Never Full mailbox feature

• Listening to your mailbox messages

• Call Screening

Receiving calls

Enterprise Edge Voice Messaging can be used by any outside caller and by other mailbox owners in your company. When you are away from the office, you can use Enterprise Edge Voice Messaging with any touch tone phone. When you are at the office, you can use Enterprise Edge Voice Messaging from any Enterprise Edge telephone connected to your company’s Enterprise Edge Voice Messaging system.

Even outside callers using a rotary dial telephone are able to use Enterprise Edge Voice Messaging. When a caller uses Enterprise Edge Voice Messaging from a rotary dial telephone, the system transfers the call to your company receptionist or the Operator. If a receptionist or the Operator is not available to answer the call, the call transfers to the General Delivery mailbox.

Enterprise Edge Voice Messaging Never Full mailbox feature

The Never Full mailbox feature lets external callers leave a message in your mailbox, even if the mailbox is technically “full”. The message is stored in your mailbox, but cannot be accessed until you delete at least one existing message to allow space for the new message. If you attempt to listen to any new messages before deleting an existing message, you hear this voice announcement:

“Your mailbox is full. You must erase some messages before you can listen to new messages.”

You are not able to leave a message in another mailbox, create a new message, Copy, Send, or Reply to a message, until you delete at least one existing message.

The Never Full mailbox feature is not available to internal callers. Internal callers cannot leave messages in mailboxes that are technically “full”.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 36

36 Accessing your messages

Listening to your mailbox messages

To listen to your messages:

Pswd: OTHR RETRY OK

2 new 0 saved

PLAY

REC ADMIN

A number of options are available to you during and after listening to a message. The table Listening to your mailbox messages shows the options and when they are available.

Listening to your mailbox messages

Option Button Available

while listening to a message

Backup

Copy

End of Message

Envelope

Erase

Forward

⁄

< <<

ﬁ

COPY

‹‹

> >>

‡

ERASE

‹

> >>

X Rewinds the message nine seconds and resumes

X X Sends a copy of the message to one or more

X Skips to the end of the message.

X X Plays the information in the message envelope.

X X Deletes the message currently being played or, if

X Advances the message nine seconds and

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

PLAY

to listen to your messages. For options,

refer to the table Listening to your mailbox messages.

4. Press

Available after listening to a message

to end the session.

Description

playing it from that point.

mailboxes. When you record the introduction to the forwarded message, the introduction must be more than three seconds long.

Envelope information includes the date and time the message was sent and, if the message was internal, the directory name of the sender. This option is not shown on the display.

no messages are playing, deletes the message just played. Deleted messages remain in your mailbox until the session is ended. (Refer to Notes 1. and

2.)

continues playing from that point. A message can be forwarded as many times as required.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 37

Listening to your mailbox messages

Accessing your messages 37

Option Button Available

while listening to a message

ﬂ

X X Plays the next message in your mailbox. If used

££

Pause/ Continue

Quit

Replay

STOP/PLAY

›

•

⁄⁄

< <<

⁄

X Stops a message temporarily. When you stop the

X X Stops playing the current message and begins

X Goes back to the beginning of the message and

Available after listening to a message

X Stops playing the message and p lays the Mailbox

X Replays the last message. This option is not

Description

while a message is playing, it stops playing the current message and plays the next message in your mailbox. This option is not shown on the display.

message, you have the option to play the previou s message, continue playing the current message, or skip to the next message.

playing the previous message. This option is not shown on the display.

main menu options.

plays the message again.

shown on the display.

Save Message

Volume Control

‡‡

SAVE

•

X X Replies to a message. (Refer to Note 3.)

The reply can be either:

- a message to an internal sender’s mailbox

- a telephone call to an internal or external party (Refer to Note 4.)

X Saves the message being played. (If you do not

delete a message, it is automatically saved). This option is not shown on the display unless you erase a message. If you erase a message, and play the message again, you are given the option to

SAVE

press display telephone. (Refer to Note 2.)

X Adjusts the volume of the message that is

playing. The volume increases each time you press •. After four consecutive presses, the volume returns to the lowest level. This option is not shown on the display.

on an Enterprise Edge two line

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 38

38 Accessing your messages

Notes:

1. Because your mailbox has limited message storage space, delete any messages you no longer need. After a certain time period, your saved messages may be erased automatically. Ask your System Administrator about this.

2. You can retrieve a deleted message only if you have not quit the session in which you deleted it. Locate the deleted message. Then play (press and save (press retrieving deleted messages refer to About erased messages.

3. Applies only if the Reply feature is enabled.

4. You can reply to an outside caller by dialing them back if your company subscribes to Caller ID (CLID) service. For further information about replying to an outside caller refer to Replying to an external message sender on page

49.

About erased messages

‡‡

SAVE

) the message. For further information about

⁄⁄

)

After listening to your messages and exiting Enterprise Edge Voice Messaging, all messages that you do not erase are automatically saved. Since message storage space is limited, we recommend that you erase messages that are no longer needed.

You can retrieve an erased message if you are still in the Enterprise Edge Voice Messaging session. An erased message remains in your mailbox until you end the current Enterprise Edge Voice Messaging session.

After you erase a new or saved message, the number of new or saved messages

0 new

shown on the display is decreased by one. Even though the display may show

0 saved

, you can still play and retrieve your erased messages. Press

PLAY

listen to your erased message. Refer to the table Listening to your mailbox messages on page 36.

After you play your erased message, you are given the option to save it. If you end the current session without saving the erased message, it is permanently deleted from Enterprise Edge Voice Messaging.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 39

Call Screening

Call Screening lets you determine who is calling before you accept the call. It applies only to external calls transferred from the Automated Attendant or from Custom Call Routing (CCR). See your System Administrator for information on CCR.

Call Screening is useful in the following circumstances:

• if CLID is not available

• if CLID is not a reliable indication of the caller identity

• if your Enterprise Edge telephone does not have display capabilities

The System Administrator enables the Call Screening feature for your Enterprise Edge Voice Messaging system.

If Call Screening is unavailable, the call transfers immediately for the following types of calls:

• internal calls

• external calls placed directly to your phone number

Accessing your messages 39

• external calls for which you have established a Personalized greeting

How to use Call Screening

To use the Call Screening feature:

1. You receive an external call that is transferred from the Automated Attendant or from Custom Call Routing (CCR).

2. Enterprise Edge Voice Messaging announces the caller’s name to you. If the caller chooses not to record their name, the voice prompt says, “Unknown caller.”

3. You have the option of accepting the call or having the caller leave a message in your Enterprise Edge Voice Messaging mailbox:

• press

ANS

or ⁄ to accept the call

QUIT

or • to transfer the call to your Enterprise Edge Voice Messaging

mailbox (and the caller is informed that you are not available).

If Call Screening is enabled, Enterprise Edge Voice Messaging asks the caller to record their name after the tone. (If the caller presses • when they are asked to record their name, the call goes back to the Automated Attendant. ) The caller hears a hold tone while they wait. If you do not answer, the caller is informed that you are not available, and the call transfers to your mailbox.

Since some callers may not like recording their name and waiting for service, use this feature with discretion.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 40

40 Accessing your messages

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 41

Sending messages

Introduction

This chapter describes sending messages and explains the following topics:

• Types of messages

• About recording and sending a message

• Using the Company Directory

• Message delivery options

• Recording and sending a message using the Open Mailbox feature

• Recording and sending a message using the Leave Message feature

• Replying to messages

• Sending a message to more than one recipient

Types of messages

There are two types of messages, Broadcast messages and Personal messages.

Broadcast messages

There might be times when you open your Personal mailbox and a message plays immediately. This is a Broadcast message left by your System Administrator. This type of message can be sent only by your System Administrator. Make sure you listen to the e ntire message. After it play s, the message is automatically erased from your mailbox.

Personal messages

Sending personal messages to a mailbox

To send a message, refer to About recording and sending a message on page 42. To send a message when you do not know the person’s mailbox number, use the Company Directory. Refer to Using the Company Directory on page 42.

Personal messages addressed to a Group List

You can send a message to a group of people by addressing a message to a Group List. For more information, refer to Sending a message using a Group List on page

49.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 42

42 Sending messages

About recording and sending a message

Messages can be recorded and sent using:

• the Open Mailbox feature (ƒ

• the Leave Message feature (ƒ

When you use the Open Mailbox feature, you open your personal mailbox and enter your password. Then you record your message and enter the extension of the message recipient.

The Leave Message feature prompts you to enter the extension of the message recipient immediately. Then you record your message. No password is required because you do not open a mailbox.

Both features allow you to:

• use the Company Directory (refer to Using the Company Directory)

• assign message delivery options (refer to Message delivery options on page 44)

• send a message to more than one recipi ent (refer to Sending a message to more

than one recipient on page 49).

Using the Company Directory

You can find any initialized mailbox by searching the Company Directory. Use the Company Directory if you do not know the mailbox number of someone you want to send a message to. You can access the Company Directory if:

·°⁄

·°‚

)

• the display shows

DIR

•the voice prompt announces, “Press £ to use the Directory.”

• you are prompted to choose a mailbox

The Company Directory option is available from both the Open Mailbox feature and the Leave Message feature.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 43

Sending messages 43

To access the Company Directory using the Leave Message feature:

Mbox:

QUIT

DIR

Last name: OK

Wayne, Paul RETRY NEXT OK

1. Press

DIR

or £ to use the Company Directory.

2. Use the dialpad buttons associated with the first three or four letters of the mailbox owner’s name to locate and select the person’s mailbox. (Enter the last name, first name or both names depending on how your system is set up. This display shows an example of a prompt for a mailbox owner’s last name.) You do not need to enter a comma. Press OK or £.

For example, to enter the letters “Wayn”

·¤·ﬂ

press

. If the mailbox owner has fewer than four letters in their last name, press the buttons on the dialpad to spell out the entire last name, and press

or £. For more information, refer to Entering

characters on the Enterprise Edge dialpad on page 11.

3. In this example, the name of the mailbox owner, Paul Wayne appears on the display and is announced. To accept the mailbox owner, press OK or £.

Wayne, Paul

If you do not want the person who is shown, press

or ⁄ to see the next matching name.

4. The greeting of the mailbox owner plays. If the mailbox owner you selected does not have a Personal greeting recorded and selected, you hear their Company Directory recording.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 44

44 Sending messages

Message deliver y options

Enterprise Edge Voice Messaging provides you with five possible message delivery options:

• Normal

• Certified

•Urgent

•Private

• Timed Delivery

Option Display Button Button Description

⁄

‹

›

Sends a message with Normal delivery option.

Sends you notification that your message has been received and played.

Plays messages marked Urgent before other messages left in the mailbox. Urgent messages are preceded by the v oice prompt, “This message is urgent”.

Accesses the Private and Timed delivery options. If the Timed delivery option is not available.

Private messages cannot be forwarded to another mailbox.

Allows you to assign the time that the message is received.

Send

Certified

Urgent

Other

Private

Timed

SEND

CERT

URGENT

OTHR

PRIV

TIME

PRIV

appears instead of

OTHR

Normal, Certified, and Private messages play in the order they are received. Urgent messages play before other messages left in the mailbox, except for Broadcast messages. (Refer to Broadcast messages on page 41.) The Certified and Timed delivery options are available only if you call from a telephone that has a mailbox associated with it. Messages sent with the Timed delivery option are played at the time that you specify.

If you use the Timed delivery option, you first enter the time, including a.m. or p.m. You are then prompted to accept or change the date, which defaults to today or tomorrow, and you can accept the date that corresponds to the next occurrence of the specified time. Dates are shown by month and day, and the year is inferred. If the month and day are earlier than the current date, the next year is assumed. When the specified time and date occurs, the message is sent. You cannot cancel the message prior to delivery.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 45

Sending messages 45

Assigning message delivery options using the Open Mailbox feature

To assign message delivery options using the Open Mailbox feature:

Delivery options CERT URGENT OTHR

Delivery options PRIV TIME

Time hhmm: RETRY

1. Press

CERT

or ⁄ to assign the Certified delivery

option. Press

URGENT

delivery option. Press Timed delivery options. If

OTHR

, the Timed delivery option is not available.

Note: The

OTHR

or ¤ to assign the Urgent

OTHR

to assign the Private or

PRIV

appears instead of

display button is not available or required for single-line display telephones. You can access the Private and Timed Delivery options by pressing the dialpad buttons on either a two-line or a single-line display telephone.

2. Press

PRIV

or ‹ to send a message with a Private

delivery option. If you press

PRIV

or ‹, go to step 7. If you want to send a message with the Timed delivery option press

TIME

or ›. If you press

TIME

or ›,

continue with step 3.

3. Enter the time that you want to send a message using the Timed delivery option

hh:mm RETRY AM PM

hh:mm am/pm RETRY OK

Tu mm dd CHNG NXTDAY OK

Wayne, Paul OPTS CC SEND

Note: This is a four digit field. Any single-digit hour

or minute must be preceded by a zero. For example, enter 0800 for eight o’clock.

4. Press

5. Press

RETRY

6. Press

or ⁄ or

or £ to accept the time you entered or press

or • to change the time.

CHNG

or ⁄ to change the date shown to a

different date. Press

or ¤.

NXTDAY

to change the date to the

next day (the day after the date that is shown). Press

or £ to accept the date shown, which defaults to today or tomorrow, and select the one that corresponds to the next occurrence of the specified time.

7. Press

SEND

or £ to send this message now. Press •

to cancel all delivery options.

Press

to end this session.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 46

46 Sending messages

Assigning message delivery options using the Leave Message feature

To assign message delivery options using the Leave Message feature:

·°‚

DIR

or £

Mbox: DIR QUIT

1. Press ƒ

2. Enter the mailbox number or Group List number of the person or Group you want to leave a message for. If you do not know the mailbox number, press to use the Company Directory.

Record message: RETRY PAUSE OK

3. At the sound of the tone, record your message. Press

PAUSE

you pause, press

or ¤ to pause during your recording. When

CONT

or ¤ to continue recording

your message. Press OK or £ to end your recording.

RETRY

Message options: RETRY PLAY SEND

Press

4. Press

PLAY

sending it. Press

to erase and re-record your message.

or ⁄ to listen to your message before

RETRY

or ¤ to erase and re-record

your message. Press ‹ to access delivery options.

SEND

Press

or £ to send your message now.

Recording and sending a message using the Open Mailbox feature

To record and send a message using the Open Mailbox feature:

·°⁄

to open your mailbox.

PAUSE

CONT

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC

Record message: RETRY PAUSE OK

ADMIN

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

REC

or ‹ and record your message at the tone.

4. Record your message. Press recording your message to stop temporarily. When you wish to resume recording, press continue recording your message. Press OK or £ to end your recording. Press

RETRY

to erase and re-record

your message.

Accept rec? RETRY PLAY OK

5. Press OK or £ to accept your message. Press

⁄

to listen to your message. Press

erase and re-record your message.

or ¤ while

or ¤ to

PLAY

RETRY

or ¤ to

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 47

Sending messages 47

Mbox: DIR QUIT

6. Enter the mailbox number or Group List number of the person or Group you want to leave a message for. If you do not know the mailbox number, press

DIR

or £

to use the Company Directory.

Wayne, Paul OPTS CC SEND

7. Press

SEND

or £ to send the message now with the

Normal delivery option. Press

OPTS

‹

for delivery options. Press CC or › to send this message to more than one mailbox owner, with one set of delivery options applied to all recipients.

Note: The display shows the name of the mailbox

owner or Group (in this example, mailbox owner Paul Wayne).

0 new 8 saved PLAY REC ADMIN

Press

to end this session.

Recording and sending a message using the Leave Message feature

To record and send a message using the Leave Message feature:

Mbox: DIR QUIT

Record message: RETRY PAUSE OK

Message options: RETRY PLAY SEND

1. Press ƒ

·°‚

2. Enter the mailbox number or Group List number of the person or Group you want to leave a message for. If you do not know the mailbox number, press

DIR

or £

to use the Company Directory.

3. At the sound of the tone, record your message. Press

or £ to end your message.

4. Press

SEND

or £ or replace the receiver to send the

message using the Normal Delivery Option. Press

PLAY

or ⁄ to listen to your message. Press

to erase and re-record your message. Press ‹ to

RETRY

change the Delivery Options.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 48

48 Sending messages

Replying to messages

You can reply to internal message senders and to external message senders. To reply to a message from an external message sender, your company must subscribe to Caller ID (CLID).

Replying to an internal message sender

You can reply to a message from an internal message sender by:

1. Using the

CALL

option. If you select

CALL

, you are immediately transferred to the internal message sender’s extension. You must have an initialized Enterprise Edge Voice Messaging mailbox and an operating directory to use

CALL

the

2. Using the

option.

MSG

option. If you select the

MSG

option, begin recording your reply

at the tone.

To reply to an internal message sender:

or ¤.

·°⁄

to open your mailbox.

or ¤ to call the message sender

Pswd: OTHR RETRY OK

1 new 0 saved PLAY REC ADMIN

End of message REPLY ERASE NEXT

Reply to msg MSG CALL QUIT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

PLAY

4. After you have listened to your message, press or ·.

5. Press

CALL

MSG

press

or ⁄ to record and send a reply. (Refer to Recording and sending a message using the

Open Mailbox feature on page 46.)

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 49

Sending messages 49

Replying to an external message sender

You can reply to a message from an external message sender if your company subscribes to CLID. Before using the Reply option you must play the message.

To reply to an external message sender:

·°⁄

or ¤.

Pswd: OTHR RETRY OK

1 new 0 saved PLAY REC ADMIN

End of message

ERASE NE XT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

4. Press

PLAY

5. Enterprise Edge Voice Messaging dials the external number directly.

After you call the message sender, your session ends.

Sending a message to more than one recipient

Sending a message using a Group List

A Group List is a collection of mailbox owners. When you send a message to a Group List, each mailbox owner in the Group List receives the same message. If you are a member of the group you are addressing, you do not receive a copy of the message.

to open your mailbox.

If you would like a Group List for your specific needs, ask your System Administrator to create a Group List for you. Include the following information for the System Administrator:

• the mailbox owners’ names

• a list of the mailbox numbers

• the Group List name Your System Administrator can publish a list of the mailboxes in each Group List.

You can enter the Group List number instead of a mailbox number at the

Mbox:

prompt. You can also enter the name of the Group List in the Company Directory

DIR

at the

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

prompt.

Page 50

50 Sending messages

Copying a message to other recipients

You can copy a message to other recipients using the Open Mailbox feature:

• using

ALL

- message recipients have the same delivery options

• using CC - this allows message recipients to have different delivery options Note: You cannot copy a message to other recipients using the Leave Mailbox

feature. You cannot copy Private messages.

Forwarding a copy of a message to one or more recipients

From the Main Mailbox menu you can forward a copy of a message during or after playing the message. When you forward a copy of a message to a mailbox, you are prompted to record an introduction to the message. Your introduction has to be at least three seconds long.

When you record an introduction and enter the mailbox number, your introduction and a copy of the message are automatically sent to the mailbox you selected. You then have options to send an additional copy of the introduction and the message to another mailbox, or to quit and return to the Listen to Messages menu. You can forward copies to as many mailboxes as you want. (Messages marked Private cannot be forwarded to another mailbox.)

For more information on playing your messages, refer to Listening to your mailbox

messages on page 36.

Copying a message is not the same as forwarding a message using the Copy option. Copied messages do not have recorded introductions. Refer to Copying a message

to other recipients on page 50.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 51

Call Forwarding your calls

Introduction

This chapter shows the following ways that you can forward your calls:

• Call Forwarding your calls to Enterprise Edge Voice Messaging

• Setting up Call Forward remotely

• Call Forward with Caller ID (CLID)

Call Forwarding your calls to Enterprise Edge Voice Messaging

To forward incoming calls to your mailbox, press ƒ To cancel Call Forward, do one of the following:

• press

• press ƒ

• press

Setting up Call Forward remotely

When you are away from the office, you can forward your calls to your Enterprise Edge Voice Messaging mailbox by using the dialpad of any touch tone phone.

To access your Personal mailbox from another location and set up Remote Call Forward:

1. Call the Automated Attendant or your Enterprise Edge telephone from any

2. Enter your mailbox number and password and press £.

3. Press °.

∞

£›

CANCEL

touch tone phone and press

••

while the greeting plays.

·°›.

4. Press ¤.

5. Press ‹ to turn call forwarding from the Call Forward menu on and off.

6. Press ⁄ to turn Call Forward on and off.

Note: If Call Forward is turned on, the voice prompt says: “Calls will be

answered immediately.” All calls to your telephone are now answered

by Enterprise Edge Voice Messaging. If Call Forward is turned off, the voice prompt says: “Calls will ring at

your set.”

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 52

52 Call Forwarding your calls

7. Press ⁄ to turn Call Display on and off.

Note: If Call Display is turned on, the voice prompt says: “Caller

information will be displayed at your set.” If Call Display is turned off, the voice prompt says: “Caller information will not be displayed.”

8. Replace the handset to end this session.

Call Forward with Caller ID (CLID)

The Call Forward with CLID feature is available only if your company subscribes to CLID service. If you are not sure whether your company subscribes to CLID service, ask your System Administrator. CLID does not appear if the caller has a private or unknown phone number.

You can set up Call Forward with CLID to screen calls forwarded to your Enterprise Edge Voice Messaging mailbox. If the feature is enabled, you hear an Alert tone and the CLID information appears on the telephone display.

To talk to the caller who has been forwarded to your mailbox, press

·°‡

to interrupt the call.

To turn Call Forward with CLID on and off:

·°⁄

to open your mailbox.

or °.

or ¤.

or ‹.

⁄

to turn Call Forward on and off.

or ⁄ to turn Call Display on and off.

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Greeting options REC CHOOSE CFWD

Forward calls:Y CHNG NEXT

Display caller:Y CHNG NEXT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

4. Press

5. Press

6. Press

7. Press

ADMIN

GREET

CFWD

CHNG

Mailbox admin GR E ET PSWD QU I T

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

8. Press

to end the session.

Page 53

Call Forwarding your calls 53

Call Forward on Busy overrides CLID

If your Enterprise Edge telephone is assigned Call Forward on Busy, CLID information does not appear on the display. Call Forward on Busy is a feature that forwards all of your calls to another designated telephone or extension if your telephone is busy. Call Forward on Busy is assigned by the Enterprise Edge System Administrator.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 54

54 Call Forwarding your calls

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 55

Transferring calls

Introduction

This chapter describes transferring calls and explains:

• Transferring calls to an Enterprise Edge Voice Messaging mailbox

• Transferring calls from your mailbox to the Operator

• Transferring calls from your mailbox to the Automated Attendant

• Transferring a call to Custom Call Routing (CCR)

• Outbound Transfer

• Adding special characters to the destination number

• Setting up Outbound Transfer to a phone number

• Setting up Outbound Transfer to an extension

• Changing the Outbound Transfer parameters

• Turning Outbound Transfer on and off

Transferring calls to an Enterprise Edge Voice Messaging mailbox

Any time a caller wants to leave a message in a mailbox, you can easily transfer their call from your Enterprise Edge telephone to any mailbox initialized with Enterprise Edge Voice Messaging.

Transferring calls to an Enterprise Edge Voice Messaging mailbox has the following advantages:

• If you transfer a call to a mailbox instead of another telephone, the call does not come back to you. If you transfer a call to another telephone and the call is not answered, the call does comes back to you.

• The call is immediately transferred to the mailbox (which saves time).

telephone.

·°ﬂ

is not available on the Enterprise Edge Companion Wireless

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 56

56 Transferring calls

To transfer a call to a mailbox from your Enterprise Edge telephone:

1. Press ƒ

·°ﬂ

. Do not press ˙ because the call is put on

hold automatically.

2. Enter the mailbox number or use the Company Directory by pressing

Note: Press OK or £ to accept a name when using the Company Directory.

Do not use the Internal Autodial feature.

3. Wait until the display shows

Call transferred

before attempting any other Enterprise Edge Voice Messaging functions. The call is automatically transferred and the Enterprise Edge Voice Messaging session ends.

Transferring a mailbox owner’s call to Enterprise Edge Voice Messaging

You can transfer a mailbox owner’s call to their Enterprise Edge Voice Messaging mailbox so that they can change their greetings or retrieve their messages.

Note: ƒ

·°ﬂ

is not available on the Enterprise Edge Companion

Wireless telephone.

To transfer a mailbox owner’s call to their Enterprise Edge Voice Messaging mailbox from your Enterprise Edge telephone:

DIR

1. Press ƒ

·°ﬂ

. Do not press ˙.

2. Enter the mailbox owner’s mailbox number.

3. Wait until the display shows

Call transferred

before attempting any other Enterprise Edge Voice Messaging functions. The call is automatically transfers and the Enterprise Edge Voice Messaging session ends.

Note: Do not use ƒ

‡‚

to transfer a mailbox owner’s call. This feature transfers the call to their telephone and the call comes back to you.

After a mailbox owner’s call transfers to their mailbox, the mailbox owner must:

1. Press

••

while their Personal greeting plays.

2. Enter their mailbox number and password and press £.

3. Follow the voice prompts.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 57

Transferring calls 57

Transferring calls from your mailbox to the Operator

To transfer calls from your mailbox to the Operator, press ‚ while at the Main Mailbox menu. For more information, refer to Main Mailbox menu and options on page 25.

Transferring calls from your mailbox to the Automated Attendant

To transfer to the Automated Attendant from your mailbox, press £ at the Main Mailbox menu. For more information, refer to Automated Attendant on page 13 and

Main Mailbox menu and options on page 25.

Transferring a call to Custom Call Routing (CCR)

About Custom Call Routing (CCR)

Custom Call Routing (CCR) is a single-digit application that provides callers with a more sophisticated menu and a wider range of options. Using CCR, a caller can:

• listen to the Home menu and make a selection

• listen to a pre-recorded CCR Information message

• leave a message in a mailbox

• transfer to another extension or an external number For more information about CCR, ask your System Administrator.

A call can be transferred to the beginning of a CCR Tree. To transfer a call to a CCR Tree:

1. Press ƒ

·°ﬂ

. Do not press ˙.

2. Choose a CCR Tree by entering a digit from 1 to 4 and pressing £.

3. Wait until the display shows

Call transferred

before attempting any other Enterprise Edge Voice Messaging functions. The call automatically transfers and the Enterprise Edge Voice Messaging session ends.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 58

58 Transferring calls

Outbound Transfer

You can set up Outbound Transfer to transfer a caller who has reached your mailbox to a number that you assign. A caller can use Outbound Transfer from any touch tone telephone, and you can direct your Outbound Transfer calls to any telephone.

You can personally inform callers of this feature, or you can inform callers of this feature in your personal greeting. If you choose to inform callers of this feature in your mailbox greeting, you must tell them to press ‡ to be transferred. For example:

“Hi. This is Brenda Whately. I’m away from the office today. Please leave me a message after the tone and I will return your call as soon as possible. If you need to reach me before tomorrow, press ‡ and you will be transferred to my cellular phone. Thanks.”

Note: The restrictions that apply to your telephone line also apply to Outbound

Transfer numbers. For example, if you are unable to dial long distance phone numbers from your telephone, you cannot have a long distance Outbound Transfer destination. If your mailbox is restricted to extension destinations for Outbound

Transfer, see your System Administrator. For Outbound Transfer to function properly, you must have a greeting recorded. When you set up Outbound Transfer, you can add special characters to the

destination number. Read Adding special characters to the destination number and refer to the following tables and examples.

Adding special characters to the destination number

Follow the voice prompts or press phone number (or a destination pager number if you are setting up a destination pager number in Off-premise Message Notification. The destination pager number cannot be longer than 29 characters.) The destination phone number cannot be longer than 30 characters.

Note: If you are adding special characters, do not press the dialpad buttons

to enter a #, or • to enter a *. Press the button directly below the

option on a two-line display telephone, or listen to the voice prompts.

ADD

to add special characters to a destination

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 59

Transferring calls 59

To add special characters on an Enterprise Edge one line display telephone, refer to the table Adding special characters using an Enterprise Edge one line display

telephone. To add special characters on a two-line display telephone, refer to the

table Adding special characters using an Enterprise Edge two line display

telephone.

Table 4 Adding special characters using an Enterprise Edge one line display telephone

Press Description

to retry or add digits to the destination phone number.

‹

›

ﬁ

ﬂ

•

Adding special characters using an Enterprise Edge two line display telephone

Press Description

•

‹

DIGS

PAUS

to enter a timed pause that appears as P on the display. Pauses are four seco nds long.

to recognize dial tone (behind PBX). The Recognize Dial Tone special character appears as D on the display.

to enter a #.

to enter a *.

to cancel and retry.

to retry or add digits to the destination phone number.

to enter a timed pause that appears as P on the display. Pauses are four seconds long.

OTHR

TONE

to recognize dial tone (behind PBX). The Recognize Dial Tone

to enter a #.

to enter a *.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

to go to the next display to enter the following special characters:

special character appears as D on the display.

Page 60

60 Transferring calls

Optimizing Outbound Transfer

When Enterprise Edge Voice Messaging transfers a call to an external telephone number using Outbound Transfer, two lines are used. An incoming line is used to connect the caller to your mailbox and an outgoing line is used to transfer the caller to your Outbound Transfer telephone number. Both lines remain in use while the caller connects to the Outbound Transfer telephone number.

To optimize the use of Enterprise Edge Voice Messaging lines, the Outbound Transfer call to an external telephone number can transfer to the incoming line to make the outgoing call. This type of transfer is called a Link transfer.

Note: A Link transfer can be performed only if the Enterprise Edge Voice

Messaging line is equipped with Link transfer capability. If a Link transfer

is programmed for an Outbound Transfer and your Enterprise Edge Voice

Messaging lines do not support this feature, the caller disconnects. Ask your

System Administrator before programming the Link transfer. To perform a Link transfer with Outbound Transfer you must add a £ before the

Outbound Transfer telephone number. For example, the telephone number would look like:

£ﬁﬁﬁ⁄¤‹›

where:

instructs Enterprise Edge Voice Messaging to use the incoming line to perform

the transfer

ﬁ⁄¤‹›

is the telephone number dialed

Programming an Outbound Transfer telephone number when Enterprise Edge Voice Messaging is behind PBX or Centrex+

When Enterprise Edge Voice Messaging is installed behind a PBX or Centrex+ and you want to access an outside line and recognize dial tone, enter:

·£›¤ﬁﬁﬁ⁄¤‹›

where:

accesses an outside line

specifies the next digits are special characters

›

recognizes dial tone

specifies the next digits are numbers to be dialed

ﬁﬁﬁ⁄¤‹›

is the phone number dialed

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 61

Setting up Outbound Transfer to a phone number

To set up Outbound Transfer to a phone number for the first time:

Transferring calls 61

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Outbound xfr ADMIN SELECT

Ph: RETRY OK

<x> ADD OK

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

4. Press ° to open the Outbound Transfer (

5. Press

ADMIN

or °.

xfr

) menu.

or ⁄ to set up Outbound Transfer.

6. Enter the destination phone number and press OK or

7. Press OK or £ to accept the destination number (represented by the <x>). Press

ADD

or ¤ to add special characters. For information, refer to Adding

special characters to the destination number on page

58. After you add special characters, press OK or £ to accept the destination number.

Transfer: off CHNG QUIT

Transfer: on CHNG QUIT

8. Press

9. Press

CHNG

or ⁄ to turn Outbound Transfer on.

QUIT

or •. Press

Setting up Outbound Transfer to an extension

To set up Outbound Transfer to an extension for the first time:

·°⁄

or °.

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

4. Press ° to open the Outbound Transfer (

to end this session.

to open your mailbox.

xfr

) menu.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 62

62 Transferring calls

Outbound xfr ADMIN SELECT

Ext: RETRY OK

Accept:<x> RETRY OK

Transfer: off

QUIT

CHNG

Transfer: on CHNG QUIT

5. Press

6. Enter the destination extension and press OK or £.

7. Press OK or £ to accept the number.

8. Press

9. Press

ADMIN

Note: The

CHNG

QUIT

or ⁄ to set up Outbound Transfer.

<x>

represents the extension.

or ⁄ to turn Outbound Transfer on.

or •. Press

Changing the Outbound Transfer parameters

To change the Outbound Transfer parameters:

<x> CHNG NEXT

10. Press

CHNG

or ⁄.

to end this session.

Note: The

Transfer destination number.

<x>

represents the current Outbound

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 63

Transferring calls 63

Turning Outbound Transfer on and off

You can turn Outbound Transfer on or off at any time after you set it up. Turning Outbound Transfer off does not affect any of its assigned parameters.

To turn Outbound Transfer on or off:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Outbound xfr ADMIN SELECT

Transfer: on CHNG QUIT

Transfer: off CHNG QUIT

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

4. Press ° to open the Outbound Transfer (

5. Press

6. Press

7. Press

ADMIN

SELECT

CHNG

again to turn Outbound Transfer on.

QUIT

or °.

or ¤.

or ⁄ to turn Outbound Transfer off. Press

to end this session.

xfr

) Menu.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 64

64 Transferring calls

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 65

Off-premise Message Notification

Introduction

This chapter describes how to set up and change Off-premise Message Notification and includes the following topics:

• About Off-premise Message Notification

• Setting up Off-premise Message Notification to a phone number

• Setting up Off-premise Message Notification to an extension

• Setting up Off-premise Message Notification to a pager number

• Changing Off-premise Message Notification parameters

• Setting up Off-premise Message Notification to more than one destination

• Deleting an Off-premise Message Notification destination number

• Inserting an Off-premise Message Notification destination number

• Turning Off-premise Message Notification on and off

About Off-premise Message Notification

You can program Enterprise Edge Voice Messaging to call you and let you know there is a message for you at a phone number, an extension, or a pager. The Offpremise Message Notification feature is enabled by your System Administrator.

If you program Enterprise Edge Voice Messaging to call you at a telephone, you are prompted to enter your password before you can listen to your messages.

You can receive notification of a message at a maximum of five different destination numbers assigned by you. When the number of retry attempts is reached for each assigned destination number, the next number in the series is called. For example, Enterprise Edge Voice Messaging can contact your car phone number first to let you know you have a message. If there is no answer, the call rings at your home number. If there is still no answer, the call rings at your pager number and so on. The number of retry attempts is assigned by your System Administrator.

If the destination type is stop times apply to all five notification numbers.

Off-premise Message Notification begins when the start time is reached. Set the start time for the time you will be at the destination phone number, so you are there to receive your calls.

phone

, you must assign start and stop times. The start and

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 66

66 Off-premise Message Notification

Off-premise Message Notification parameters

You can set up the parameters for Off-premise Message Notification from any touch tone phone. The parameters include:

• destination type (telephone, extension or pager)

• destination number (telephone, extension or pager)

• time range for receiving calls at phone numbers or extensions (Pagers are notified any time there is a qualifying message.)

• types of message you want to receive (all new messages, or just messages marked urgent)

Note: The restrictions that apply to your telephone line also apply to Off-premise

Message Notification numbers. For example, if you are unable to dial long distance phone numbers from your telephone, you cannot have a long distance Off-premise Message Notification destination number.

Setting up Off-premise Message Notification to a phone number

When you set up Off-premise Message Notification, you can add special characters to the destination phone number. Refer to:

• Adding special characters to the destination number on page 58

• Optimizing Outbound Transfer on page 60

To set up Off-premise Message Notification to one phone number for the first time:

·°⁄

to open your mailbox.

or °.

or ⁄ to set up Off-premise Message

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN

SELECT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

Notification.

Destination: PHONE EXT PAGER

Ph: RETRY OK

6. Press

7. Enter the destination phone number and press OK or

PHONE

or ⁄ to choose a phone number

destination.

. The destination phone number is a maximum of

30 digits.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 67

Off-premise Message Notification 67

<x> ADD OK

Start hhmm: RETRY OK

<start time> RETRY AM PM

<start time> RETRY OK

Stop hhmm: RETRY OK

8. Press OK or £ to accept the destination phone number. The <x> represents the phone number. Press

ADD

or ¤ to add special characters. For information, refer to Adding special characters to the destination

number on page 58. After you add special characters,

press OK or £ to accept the destination number.

9. Enter the start time for Off-premise Message Notification. This is a four-digit field. Any single-digit hour and minute must be preceded by a zero.

10. Press AM or ⁄ or PM or ¤.

11. Press OK or £ to accept the start time.

12. Enter the time when Off-premise Message Notification is to stop. This is a four digit field. Any single-digit hour and minute must be preceded by a zero.

<stop time> RETRY AM PM

<stop time> RETRY OK

Start:< CHNG NEXT

Stop:<stop time> CHNG NEXT

Msg type: new CHNG OK

start time

13. Press AM or ⁄ or PM or ¤.

14. Press OK or £ to accept the stop time.

15. Press

or £ to accept the start time that you

entered. Press

CHNG

or ⁄ to change the start time.

Note: Steps 16 and 17 allow you to review the start

and stop times.

16. Press

or £ to accept the stop time that you

entered. Press

CHNG

or ⁄ to change the stop time.

17. You can choose to be notified of all new messages or urgent messages only. Press OK or £ to accept the default message type new. This means you are notified whenever you receive a new message. Press

⁄

to change the message type to urgent. Changing

CHNG

the message type to urgent means you are notified only when you receive an urgent message.

Msg notify ADMIN SELECT

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

18. Press

to end the session.

Page 68

68 Off-premise Message Notification

Setting up Off-premise Message Notification to an extension

To set up Off-premise Message Notification to one extension for the first time:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN

SELECT

Destination: PHONE EXT PAGER

Ext: RETRY OK

Accept:<x> RETRY OK

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to set up Off-premise Message

Notification.

6. Press

EXT

or ¤ to choose an extension destination.

7. Enter the destination extension and press OK or £.

8. Press OK or £ to accept the destination extension. The <x> represents the extension.

Start hhmm: RETRY OK

<start time> RETRY AM PM

<start time> RETRY OK

Stop hhmm: RETRY OK

<stop time> RETRY AM PM

<stop time> RETRY OK

9. Enter the start time for Off-premise Message Notification. This is a four-digit field. Any single-digit hour and minute must be preceded by a zero.

10. Press AM or ⁄ or PM or ¤.

11. Press OK or £ to accept the start time.

12. Enter the time when Off-premise Message Notification is to stop. This is a four digit field. Any single-digit hour and minute must be preceded by a zero.

13. Press AM or ⁄ or PM or ¤.

14. Press OK or £ to accept the stop time.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 69

Off-premise Message Notification 69

Start:< CHNG NEXT

Stop:<stop time> CHNG NEXT

Msg type: new CHNG OK

Msg notify ADMIN SELECT

start time

15. Press

or £ to accept the start time that you

entered. Press

CHNG

or ⁄ to change the start time.

Note: Steps 16 and 17 allow you to review the start

and stop times.

16. Press

or £ to accept the stop time that you

entered. Press

CHNG

or ⁄ to change the stop time.

⁄

to change the message type to urgent. Changing

CHNG

the message type to urgent means you are notified only when you receive an urgent message.

18. Press

to end the session.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 70

70 Off-premise Message Notification

Setting up Off-premise Message Notification to a pager number

When you set up Off-premise Message Notification, you can add special characters to the destination pager number. Read:

• Adding special characters to the destination number on page 58

• Example of a destination pager number on page 70

Example of a destination pager number

If you are assigning a pager destination number from behind a PBX or Centrex+, remember to insert a · (depending on your system) before the £ to access an outside line.

There is a combined limit of 29 characters for the pager phone number and the pager message.

For example, to reach your pager, enter:

£›¤ﬁﬁﬁ⁄¤‹›£‹

where:

specifies the next digits are special characters

›

recognizes dial tone

specifies the next digits are numbers to be dialed

ﬁﬁﬁ⁄¤‹› ‹

inserts a timed pause

is the pager phone number dialed

Depending on the company supplying your paging service, the programming sequence may vary. For more information about setting the destination phone number parameters for your pager, contact your pager company.

To set up Off-premise Message Notification to one pager number for the first time:

·°⁄

or °.

to open your mailbox.

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

1. Press ƒ

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

4. Press ﬂ to open the Off-premise Message Notification menu.

Msg notify ADMIN

SELECT

Destination: PHONE EXT PAGER

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

5. Press

6. Press

ADMIN

Notification.

PAGER

destination.

or ⁄ to set up Off-premise Message

or ‹ to choose a pager number

Page 71

Pager: RETRY OK

<x> ADD OK

Off-premise Message Notification 71

7. Enter the destination pager number and press

8. Press The <x> represents the pager number. Press

or £ to accept the destination pager number.

ADD

to add special characters. If the paging service requires additional answer or setup time, add pause characters to the beginning of the pager message. For information, refer to Adding special characters to the

destination number on page 58. After you add special

characters, press OK or £ to accept the destination number.

Show:<xxxx> CHNG NEXT

Msg type: new CHNG OK

Msg notify ADMIN SELECT

9. Press

or £ to accept the default pager message (represented by the xxxx). The default pager message sent by Enterprise Edge Voice Messaging is the Enterprise Edge Voice Messaging extension. This is the sequence of digits sent after the pager service is dialed (to notify you of who is paging you). Press

CHNG

or ⁄ to change the pager message.

Note: There is a combined limit of 29 characters for

the pager phone number and the pager message.

10. You can choose to be notified of all new messages or urgent messages only. Press OK or £ to accept the default message type new. This means you are notified whenever you receive a new message. Press

⁄

to change the message type to urgent. Changing

CHNG

the message type to urgent means you are notified only when you receive an urgent message.

11. Press ƒ to end the session.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 72

72 Off-premise Message Notification

Changing Off-premise Message Notification

To change the parameters of Off-premise Message Notification refer to:

• Changing Off-premise Message Notification parameters

• Changing the destination type from a pager to a telephone or extension on page 74

• Changing the destination type from phone or extension to a pager on page 75

Changing Off-premise Message Notification parameters

To change the Off-premise Message Notification parameters from your Enterprise Edge telephone (assuming that you have entered a time range):

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN SELECT

Notify:<x> CHNG

Destination: PHONE EXT PAGER

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to set up Off-premise Message

Notification.

6. Press

CHNG

Note: The

or ⁄ to change the destination.

<x>

represents the type of destination

(phone, extension or pager).

7. Press

PHONE

or ⁄ to choose a phone number destination. Press destination. Press

EXT

PAGER

to choose an extension

or ‹ to choose a pager

number destination.

<x>: RETRY OK

8. Enter the destination number and press destination phone number cannot be longer than 30

or £. The

digits.

Note: The

<x>

represents the type of destination

(phone, extension or pager).

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 73

Off-premise Message Notification 73

9. Press OK or £ to accept the destination number (represented by the

<x>

). Press

ADD

or ¤ to add special characters if the destination number is a phone or pager. For information, refer to Adding special

characters to the destination number on page 58. After

you add special characters, press OK or £ to accept the destination number.

Note: If you chose a phone or extension destination,

go to step 11.

Notify:<x> CHNG NEXT

Start:< CHNG NEXT

Stop:<stop time> CHNG NEXT

Msg type: new CHNG OK

start time

10. Press

CHNG

or ⁄ to change the destination and repeat

steps 7 to 9. Press

Note: The

<x>

represents the type of destination

or £ to continue.

(phone, extension or pager).

11. Press

CHNG

or ⁄ to change the start time. Press

or £ to accept the start time.

12. Press

CHNG

or ⁄ to change the stop time. Press

or £ to accept the stop time.

Note: Steps 13 and 14 allow you to review the start

and stop times.

13. Press

CHNG

or ⁄ to change the message type to urgent. Press OK or £ to accept the new default message. You can choose to be notified of all new messages or urgent messages only. This means you are notified whenever you receive a new message. Changing the message type to urgent means you are notified only when you receive an urgent message.

Msg notify ADMIN SELECT

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

14. Press

to end the session.

Page 74

74 Off-premise Message Notification

Changing the destination type from a pager to a telephone or extension

To change the Off-premise Message Notification destination from a pager to a phone or extension (assuming that you have never entered a time range):

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN

SELECT

Notify: pager CHNG NEXT

Destination: PHONE EXT PAGER

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to change Off-premise Message Notification. The displays show a review of the first destination type and destination number, followed by the display in step 6.

6. Press

CHNG

or ⁄ to change the destination type and

the destination number.

7. Choose the type of destination number. Press

⁄

to choose a phone number destination. Press

PHONE

or ¤ to choose an extension destination.

EXT

Notify:<x> CHNG NEXT

8. Press OK or £ to accept the destination number. Press

ADD

or ¤ to add special characters if the destination number is a phone. For information, refer to Adding

special characters to the destination number on page

58.

9. Press

Note: The

or £ to continue.

<x>

represents the type of destination

(telephone or extension).

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 75

Off-premise Message Notification 75

Changing the destination type from phone or extension to a pager

To change the Off-premise Message Notification destination from a phone or extension to a pager:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN

SELECT

Notify:<x> CHNG NEXT

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to change Off-premise Message Notification. The displays show a review of the first destination type and destination number, followed by the display in step 6.

6. Press

CHNG

or ⁄ to change the destination type and

the destination number.

Note: The

<x>

represents the type of destination

(phone or extension).

Destination: PHONE EXT PAGER

Notify:pager CHNG NEXT

7. Press destination.

8. Press

PAGER

or ‹ to choose a pager number

or £ to continue.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 76

76 Off-premise Message Notification

Setting up Off-premise Message Notification to more than one destination

You can receive notification of a message at a maximum of five different destination numbers assigned by you. The following steps show you how to enter a phone number destination and then add a pager destination for the first time. To set up Off-premise Message Notification to more than one destination number:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN SELECT

Destination: PHONE EXT PAGER

Ph: RETRY OK

<x> ADD OK

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to set up Off-premise Message

Notification.

6. Press

PHONE

or ⁄ to choose a destination phone

number.

7. Enter the destination phone number and press

. The destination phone number cannot be longer

than 30 digits.

8. Press

or £ to accept the destination phone

number. The <x> represents the phone number. Press

ADD

or ¤ to add special characters. For information, refer to Adding special characters to the destination

number on page 58. After you add special characters,

press OK or £ to accept the destination number.

Start hhmm: RETRY OK

9. Enter the start time for Off-premise Message Notification. This is a four-digit field. Any single-digit hour and minute must be preceded by a zero.

<start time> RETRY AM PM

<start time> RETRY OK

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

10. Press AM or ⁄ or PM or ¤.

11. Press OK or £ to accept the start time.

Page 77

Off-premise Message Notification 77

Stop hhmm: RETRY OK

<stop time> RETRY AM PM

<stop time> RETRY OK

Notify 2:pager CHNG OTHR NEXT

Notify 3:none SETUP NEXT

Start:< CHNG NEXT

start time

12. Enter the time when Off-premise Message Notification is to stop. This is a four digit field. Any single-digit hour and minute must be preceded by a zero.

13. Press AM or ⁄ or PM or ¤.

14. Press OK or £ to accept the stop time.

15. Press

16. Press

or £.

or £ to continue. Press

SETUP

to add

another destination.

17. Press

or £ to accept the start time that you

entered. Press

CHNG

or ⁄ to change the start time.

Note: Steps 18 and 19 allow you to review the start

and stop times.

Stop:<stop time> CHNG NEXT

Msg type: new CHNG OK

Msg notify ADMIN SELECT

18. Press

or £ to accept the stop time that you

entered. Press

CHNG

or ⁄ to change the stop time.

19. You can choose to be notified of all new messages or urgent messages only. Press OK or £ to accept the default message type new. This means you are notified whenever you receive a new message. Press

⁄

to change the message type to urgent. If you

CHNG

change the message type to urgent you are notified only when you receive an urgent message.

20. Press

to end the session.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 78

78 Off-premise Message Notification

Deleting an Off-premise Message Notification destination number

If you have set up more than one destination number in Off-premise Message Notification, you are given the option to delete the destination(s). To delete an Offpremise Message Notification destination:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN SELECT

Notify 1:<x> CHNG OTHR NEXT

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to set up Off-premise Message

Notification.

6. Press

OTHR

or press

if you want to delete the first destination,

or £ to scroll through the destinations until you find the destination that you want to delete. When you find the destination that you want to delete,

OTHR

press

Note: The

<x>

represents the type of destination

(phone, extension or pager).

Notify 1:<x> DEL

INS QUIT

Notify 1:<x> CHNG OTHR NEXT

7. Press

DEL

to delete the first destination number.

8. The first destination number is deleted. The destination changes to become the

Notify 1

destination number.

Note: To delete more destination numbers, press

OTHR

and repeat steps 6 and 7. When you are done deleting destination numbers, press to end this session.

Notify 2

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 79

Off-premise Message Notification 79

Inserting an Off-premise Message Notification destination number

You have the option to insert destination number(s) if you have more than one destination number. To insert an Off-premise Message Notification destination:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN SELECT

Notify 1:<x> CHNG OTHR NEXT

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

ADMIN

or ⁄ to set up Off-premise Message

Notification.

6. Press

OTHR

to insert a new destination number in the

first Off-premise Message Notification position

Notify 1

(

), or press

to scroll through the destinations until you find the destination position that you want to replace, and then press

Note: The

<x>

represents the type of destination

OTHR

(phone, extension or pager).

Notify 1:<x> DEL INS QUIT

Notify 1:none SETUP

7. Press

INS

to insert a destination number.

Note: The

<x>

represents the type of destination

(phone, extension or pager).

8. Press

SETUP

to set up a new destination number, and follow the steps in Setting up Off-premise Message

Notification to a phone number on page 66 or Setting up Off-premise Message Notification to an extension

on page 68 or Setting up Off-premise Message

Notification to a pager number on page 70.

Note: When you are done inserting destination

numbers, press

to end this session.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 80

80 Off-premise Message Notification

Turning Off-premise Message Notification on and off

You can turn Off-premise Message Notification on or off at any time. When you turn Off-premise Message Notification off, you do not affect any of the assigned parameters (refer to About Off-premise Message Notification on page 65.) When you turn Off-premise Message Notification is on, you are notified whenever you receive a message during the time you specified.

To turn Off-premise Message Notification on and off:

Pswd: OTHR RETRY OK

0 new 0 saved PLAY REC ADMIN

Mailbox admin GREET PSWD QUIT

Msg notify ADMIN SELECT

Notify on CHNG TIME OK

Notify off CHNG TIME OK

1. Press ƒ

·°⁄

to open your mailbox.

2. Enter your mailbox password and press OK or £.

3. Press

ADMIN

or °.

4. Press ﬂ to open the Off-premise Message Notification menu.

5. Press

6. Press

SELECT

CHNG

or ¤.

or ⁄ to turn Off-premise Message

Notification off if it is on (as shown).

7. Press OK or •.

Note: Press

TIME

to review the start and stop time

parameters.

Mailbox admin GREET PSWD QUIT

8. Press

to end the session.

A person who receives an Off-Premise Message Notification call can cancel Offpremise Message Notification to their destination number. This is useful if a destination is incorrectly programmed and a wrong party receives the calls. The recipient of an Off-premise Message Notification call hears the following voice prompt: “Message for (name of mailbox owner). To log in press ⁄. If you have received this call by mistake, please press ¤.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 81

Recording a call

Introduction

resulting message in your mailbox. Before you activate the Call Record feature, ask the parties on the call for permission to record the call.

The maximum length of the Call Record message is determined by the Class of Service setting for your incoming message length. If the mailbox message length is surpassed, the voice prompt “Recording stopped. The recording limit has been reached” plays and the recording ends. After Call Record stops, you can re-activate

separate messages if this occurs. Ask your System Administrator for the message length that is assigned to your mailbox.

Note: Call Record is not enabled by default. The System Administrator must

·°·

enable this feature by assigning you a Class of Service that supports Call Record. In some areas Call Record is not available as it contravenes local laws. Ask your System Administrator about the availability of Call Record in your area.

Using Call Record

After a call is recorded, Enterprise Edge Voice Messaging places the recorded call, as a message, in the mailbox associated with the extension that activated the Call Record feature. The call includes alternate extensions associated with the mailbox. The Call Record message can be forward to other mailboxes. For more information on forwarding messages, refer to Forwarding a copy of a message to one or more

recipients on page 50.

allows you to record an active telephone call and place the

to start another record call session. The call is recorded in two

To record a call:

1. While on an active call, press ƒ Other parties on the call may hear hold tones while the system conferences in Enterprise Edge Voice Messaging. Before the call begins recording, the prompt “This call is being recorded” plays to all the parties on the call and then a recording tone plays.

Recording PAUSE QUIT

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

2. Press

QUIT

to stop the call recording. The Call Record

message is left in your mailbox.

PAUSE

Press

RESUME

stop the call recording. If the message is stopped, all the parties on the call hear “Recording stopped”.

to suspend the call recording. Press

to continue call recording or press

·°·

QUIT

Page 82

82 Recording a call

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 83

Enterprise Edge Voice Messaging Tips

Introduction

This chapter describes some easy to follow guidelines to optimize using Enterprise Edge Voice Messaging.

Enterprise Edge Voice Messaging Tips

To take advantage of Enterprise Edge Voice Messaging and its many features: Listen to your messages frequently. Answer your messages promptly to

encourage callers to use Enterprise Edge Voice Messaging and reassure them that it is as reliable as speaking with you personally.

You do not have to be at your desk to play your messages. When you are away from your desk, you can play your messages from any touch tone phone.

Clean up your mailbox. There is limited storage in your mailbox and within Enterprise Edge Voice Messaging. Do not save messages unless you need to listen to them again. When you are finished with a message, erase the message to free storage space for yourself and other mailbox owners.

Keep a record of your password in a secure place. Treat your Enterprise Edge Voice Messaging password as a secret code. Write down your password and keep it in a safe place. Do not keep your password near your telephone. If you let someone else have temporary access to your mailbox, change your password afterwards. If you forget your password, the System Administrator can reset it to the default password 0000. You can then enter a new password.

When sending messages, make them brief and to the point. More than 75% of the time spent on a normal business telephone call consists of making small talk, pleasantries and other socializing. Sending a message rather than making a call can save you time. Try to avoid sounding hurried or rude while restricting your messages to the essentials.

Change your Primary greeting frequently. It is a good idea to change your Primary greeting on a regular basis. Change your greeting to indicate that you listen to your messages and maintain your mailbox on a regular basis. Change your Primary greeting to provide a personal touch that frequent callers appreciate.

Make your Alternate greeting specific. Choosing an Alternate greeting usually means you are away from the office. If you are out of the office, indicate in your Alternate greeting when you expect to return. If you check your mailbox even though you are out of the office, make that clear. If callers can reach you at another phone number, ensure that your message includes the phone number and the time period of the temporary arrangement. If you are going to be out of the office, remember to forward your telephone to Enterprise Edge Voice Messaging.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 84

84 Enterprise Edge Voice Messaging Tips

Extended Ab senc e Greet ing . Begin this greeting by announcing your vacation or travel plans. This gets the a ttention of the c aller. For exam ple, “Vacation alert! Hi,

this is Marshall. I will be on vacation start ing on the 5th, and I will be ret urning to work on the 12th. If you care to do so, please leave a message and I will return your call when I return from vacation. For immediate assistance, please press zero.”

Record your greetings and messages clearly. For a better quality recording, speak directly into the handset. Do not use the Handsfree feature. Remember to speak clearly with a pleasant voice at a pace that is easy to understand. Do not speak too softly or loudly or make the greeting or message too lengthy. After you record a greeting or message play it back. Make sure that your greeting or message sounds the way you want it to before you accept it.

Do not forget to use th e C op y and Re pl y fe atur es . You can use Enterprise Edge Voice Messaging to send copies of messages to other mailboxes and reply to messages with a message of your own. When you send copies of messages to other people, ensure that your introduction explains why you are forwarding a copy of the message. Is the copy for information only? Is the message meant for the person to whom you are forwarding it? Who is responsible for the action on the message?

Use Group Lists for multiple copies of messages. If you find that you regularly send the same message to several different people, ask the System Administrator to create a Group List for you. With a Group List, you can send the same message to all the mailboxes in the Group List.

Encourage Enterprise Edge Voice Messaging use. Old habits are sometimes hard to break, and some people have difficulty accepting or even trying new technologies. Use your Personal mailbox and other Enterprise Edge Voice Messaging features, and encourage your co-workers and frequent callers to use them too.

Report problems promptly. If you encounter problems using Enterprise Edge Voice Messaging, report the trouble to the System Administrator as soon as possible.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 85

Troubleshooting

Introduction

This chapter describes some problems that can occur while you are using Enterprise Edge Voice Messaging. This chapter includes a list of typical problems and what to do when they occur.

The problems you encounter while using Enterprise Edge Voice Messaging are usually operating problems. Sometimes a difficulty occurs that indicates a system problem with the Enterprise Edge server. If events occur that are not covered in this chapter, report them to your System Administrator immediately.

The Automated Attendant transfers some callers to the General Delivery Mailbox.

Enterprise Edge Voice Messaging requires a tone signal and a minimum voice level. If a response is not received, the caller is automatically transferred by the Automated Attendant to the Enterprise Edge Voice Messaging operator. If the operator is not available, the call transfers to the General Delivery mailbox.

Possibly the extension called does not have a mailbox assigned to it. Ask your System Administrator to verify that the mailbox is assigned to the extension

Feature 981 produces a LOG prompt on my Enterprise Edge display.

Whenever the

• Possibly the extension you are using does not have an operating mailbox. If the extension does not have a mailbox, Enterprise Edge Voice Messaging requests both a mailbox number and a password.

• A Guest mailbox that normally does not have an assigned extension. Ask your System Administrator to verify that your extension is properly assigned to your mailbox.

My telephone cannot be forwarded to Enterprise Edge Voice Messaging.

If you are attempting to forward your extension to Enterprise Edge Voice Messaging and the display shows wrong extension number. Use feature code 985 to verify you are calling the correct Enterprise Edge Voice Messaging extension number.

My mailbox is not accepting messages.

A mailbox accepts messages only after the mailbox is initialized. A mailbox cannot receive messages until it is initialized by the mailbox owner. Initialize your mailbox. Refer to the Enterprise Edge Quick Reference Guide or to Chapter 3 of this guide.

Log:

prompt appears on the display, it can be caused by:

Not in service

you might be forwarding to the

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 86

86 Troubleshooting

My name is not played in the Company Directory.

Check to ensure that your mailbox is initialized. If it i s not initial ized, your name is not played in the Company Directory and your mailbox cannot receive any messages. If you have recorded your Company Directory name, ask your System Administrator to ensure that the Company Directory Override is set to

I have forgotten my mailbox password.

A forgotten password cannot be recovered. Your old password must be reset to the default password of four zeros (0000). After the System Administrator has reset your password, you must open your mailbox and change the default password.

YES

I attempt to access my mailbox and I hear the recording:

prevent unauthorized access. Please contact your administrator for assistance.”

“This mailbox has been locked to

Your mailbox is assigned a maximum number of incorrect password attempts. Enterprise Edge Voice Messaging records the number of incorrect attempts from the last time your mailbox was successfully accessed. After the number is passed you are “locked-out”. Your mailbox cannot be opened again until the System Administrator resets the password.

Enterprise Edge Voice Messaging Timeout

The Enterprise Edge Voice Messaging Timeout feature allows five seconds for you to choose an option. If Enterprise Edge Voice Messaging does not detect a selection, the Automated Attendant replays the option list. If an option is still not selected, Enterprise Edge Voice Messaging ends the session.

Enterprise Edge Voice Messaging has minimum voice level detection. If Enterprise Edge Voice Messaging does not detect an audio signal, it requests the caller to speak louder and provides the option to re-record. If no voice level is detected after the prompt, Enterprise Edge Voice Messaging ends the session.

Messages are cut off

If people need to leave long messages in your mailbox (up to 10 minutes), you can ask the System Administrator to give you more message recording storage space.

I attempt to listen to my messages and I hear the recording: “

erase some messages before you can listen to new messages.”

Your mailbox is full. You must

Your mailbox is equipped with the Never Full Mailbox feature, which allows a caller to leave a message in your mailbox, even if the mailbox is “full”. The message is stored, but cannot be accessed until you delete at least one saved message. If you find that you need more message time in your mailbox, ask your System Administrator to give you more storage space.

Wrong prompt language

If the wrong language appears on the display of your Enterprise Edge telephone, ask the System Administrator to change this.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 87

Troubleshooting 87

Outbound Transfer does not work.

Ensure that you have recorded the correct instructions for callers in your personal greeting. In your greeting, tell callers to press ‡ to reach you. Refer to Outbound

Transfer on page 58.

Ensure that the destination number you enter is not restricted. For example, if you cannot call long distance numbers from your telephone, then you cannot set up Outbound Transfer to a long distance number.

Check to see if Outbound Transfer is turned on. Refer to Turning Outbound

Transfer on and off on page 63.

Off-premise Message Notification does not work

If Off-premise Message Notification does not work, ask the System Administrator to check the Off-premise Message Notification parameters. Also, ask the System Administrator to check if you are allowed to have Off-premise Message Notification. Ensure that the destination phone number and time parameters are correct.

Ensure that the destination number(s) that you enter are not restricted. For example, if you cannot call long distance numbers from your telephone, then you cannot set up Off-premise Message Notification to a long distance number.

Check to see if Off-premise Message Notification is turned on. Refer to Turning

Off-premise Message Notification on and off on page 80.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 88

88 Troubleshooting

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 89

Appendix A: Default values and tone commands

Default mailbox numbers for the General Delivery mailbox

Mailbox number length

210 3 100 4 1000 5 10000 6 100000 7 1000000

If the Group List leading digit is one then the default General Delivery mailbox numbers begin with two.

DTMF tone commands for setting up Off-premise Message Notification

Default General Delivery Mailbox number

Option function Dialpad button

Review number Enter more digits Insert a timed pause (4 sec) Recognize dial tone (1.5 sec) Insert a # button tone Insert a * button tone Accept number Cancel and re-enter

⁄ ¤ ‹ › ﬁ ﬂ £

•

If Enterprise Edge Voice Messaging is installed with PBX or Centrex+ and you want to access an outside line, you must enter the command to recognize a dial tone. For example, enter · to access an outside line, press £ and then › to recognize dial tone and then press ¤ to enter more digits. Enter the destination number, press

and any required pauses. Each pause entered is four seconds long. For definitions of Pause, Recognize dial tone and Enter more digits, refer to the Glossary.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 90

90 Appendix A: Default values and tone commands

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 91

Glossary

Administration

The tasks involved in maintaining the Enterprise Edge Voice Messaging mailboxes, greetings and set up configuration.

Alternate greeting

A greeting recorded for a Personal mailbox and played on occasions such as absence, illness, or vacation.

Attendant sign On/Off

The task performed by a company receptionist or Operator that indicates to Enterprise Edge Voice Messaging when an Operator is available to answer calls.

Automated Attendant

The Enterprise Edge Voice Messaging answering service that answers incoming calls with a Company greeting, plays a list of Enterprise Edge Voice Messaging options to a caller and performs call routing functions in response to a caller’s dialpad selections.

Broadcast Message

A message that can be sent only by the System Administrator. This type of m essage plays in all initialized Personal mailboxes and plays immediately after the mailbox is opened. It is automatically erased after the mailbox owner listens t o the message.

Business Status

A Enterprise Edge Voice Messaging setting that tells Enterprise Edge Voice Messaging whether a company is closed or open for business.

Class of Service

A predetermined number designation that specifies the Enterprise Edge Voice Messaging Options for a mailbox.

Company Directory

An internal voice list that contains the names of users with initialized mailboxes designated to appear in the Company Directory.

Conventions

The way certain information is described. For example, using underlined text to represent second-line display prompt information.

Default

The parameters preset in the Enterprise Edge Voice Messaging system.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 92

92 Glossary

Designated Operator

An individual in a company who is assigned to answer the Enterprise Edge Voice Messaging Operator Request option.

Display

A one-line or two-line screen on an Enterprise Edge telephone that shows Enterprise Edge Voice Messaging commands and options.

Display buttons

The three buttons that appear on an Enterprise Edge two line display display. When pressed, these buttons select the specified Enterprise Edge Voice Messaging option.

Display options

The choices available to a user that appear on an Enterprise Edge two line display display. Options appearing on the display can be selected using the display or dialpad buttons

Enterprise Edge ATA 2

An Enterprise Edge product that allows you to connect an analog device, such as a single-line telephone or a facsimile machine, to an Enterprise Edge Voice Messaging system.

Envelope information

A date and time stamp that appears on all messages left in a mailbox. If the message is left by another mailbox owner, envelope information includes the message sender’s name.

Extension

A two-digit to seven-digit number used to reach a designated telephone. Also an Enterprise Edge internal telephone.

Feature code

A unique three-digit code used to access Enterprise Edge Voice Messaging features and options.

General Delivery mailbox

One of the two Special mailboxes used to collect messages for individuals in a company who have not been assigned a Personal mailbox.

Greetings

There are three types of Enterprise Edge Voice Messaging greetings: Company greetings, Personal mailbox greetings and Information greetings. Company greetings play by the Automated Attendant to incoming callers. Personal mailbox greetings play to callers who want to leave a message in the selected mailbox. Information mailbox greetings play to describe goods or services available to callers.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 93

Glossary 93

Group Lists

A collection of mailbox numbers assigned to a special group name and number by the System Administrator. If a message is sent to a Group List, all mailboxes contained in the list receive the same message.

Guest mailbox

A mailbox assigned to a user who does not have an extension.

Information mailbox

A mailbox that provides a caller with a message describing goods or services available from your company.

Initialize mailbox

Preparing a mailbox to receive messages, which includes changing a mailbox default password and recording a Company Directory name.

Leave Message

The feature code used to leave messages in Enterprise Edge Voice Messaging mailboxes.

Mailbox

A storage place for voice messages on the Enterprise Edge Voice Messaging system.

Mailbox number length

The number of digits allowed in a mailbox number. The mailbox number length ranges from two to seven digits.

Mailbox overrides

Mailbox overrides are optional parameters in addition to the Class of Service values. The mailbox overrides are: Include in Company Directory, Alternate Extensions, Fax line (virtual), Call Screening, Message Waiting Notification and Outdial route.

Message Delivery options

Message sending options stamped onto a message. There are five Message Delivery Options: Normal, Certified, Urgent, Private and Timed. A Message Delivery Option can be assigned to a message after it has been recorded.

Message Waiting Notification

A display prompt that informs a mailbox owner when a message has been left in a mailbox. This feature is a mailbox override.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 94

94 Glossary

Never Full mailboxes

Your Enterprise Edge Voice Messaging mailbox is equipped with the Never Full mailbox feature, which allows an external caller to leave a message in your mailbox, even if the mailbox is “full”. The message will be stored, but cannot be accessed until you delete at least one saved message.

Off-premise Message Notification

The Enterprise Edge Voice Messaging feature that calls destination numbers that you set up, to let you know you have a new or urgent message. This feature is a part of the Class of Service.

Operator Status

The Enterprise Edge Voice Messaging indicator that determines if a company’s receptionist or Designated Operator is available.

Option

A Enterprise Edge Voice Messaging choice that is given to a user through voice or display prompts.

Password

A four- to eight-digit number that is entered on the dialpad. A password is used to open mailboxes or perform configuration tasks.

Pause

Pause is used when setting up pager notification. Each pause entered is automatically four seconds. For voice pagers, pauses are entered after the pager number to delay the start of the Enterprise Edge Voice Messaging voice prompt that activates the pager. For alphanumeric pagers, pauses are entered after the pager number and before the digits that appear on the pager display.

Personal mailboxes

Mailboxes assigned to users as a place to store messages.

Primary greeting

The main greeting played in a Personal mailbox.

Programmable memory buttons

Buttons on the Enterprise Edge one line and two line display telephones that can store feature codes and numbers.

Recognize dial tone

After accepting the Outbound Transfer or Off-premise Message Notification destination phone number, entering › adds a D to the digit string. The Enterprise Edge system uses this to recognize dial tone when an access code is required.

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 95

Glossary 95

Resetting passwords

A System Administrator task that changes a mailbox password from its current setting back to the Enterprise Edge Voice Messaging default setting 0000 (four zeros).

Special mailboxes

The two mailboxes used by the System Administrator and designated Enterprise Edge Voice Messaging Operator. The two Special mailboxes are System Administrator and General Delivery.

System Administrator

The person responsible for configuring, updating, and maintaining the Enterprise Edge Voice Messaging system.

System Administrator mailbox

One of the two Special mailboxes. This mailbox is used by the System Administrator for sending Broadcast Messages. This is also the System Administrator’s Personal mailbox.

Touch tone phone

A push-button telephone that emits DTMF tones.

Voice prompts

The prerecorded voice instructions that play when you access the different Enterprise Edge Voice Messaging features and options.

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 96

96 Glossary

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 97

Index

Activating

Call Forward with Caller ID Outbound Transfer

Adding special characters

pause characters

to a destination number Alert tone Alternate greeting

Alternate Language Assigning

Assigning a Target Attendant

Automated Attendant

Automatic dis connection from Information

choosing whether mailbox accepts

messages

using

Message Delivery options

Personalized greeting

overrides routing to Operator

transferring to

message

28, 83

39, 57, 85

Broadcast messages 44

Call Forward on Busy

overrides Caller ID Call Forward with Caller ID

activating

canceling Call Record Call Screening

purpose

when unavailable Caller ID

interaction with Call Forward on Busy Calls

interrupting

transferring

Canceling

Call Forward with Caller ID

Outbound Transfer CCR Information message

28, 32, 38, 39, 52, 53

to CCR

to Enterprise Edge Voice Messaging to General Delivery mailbox to Operator to receptionist

22, 52

Certified Message Delivery option Changing

Off-premise Message Notification

parameters

Outbound Transfer

destination number

parameters your mailbox password your name in the Company Directory

Character limit

for Off-premise Message Notification

destination pager number and message

for Off-premise Message Notification

destination number

for Outbound Transfer

destination pager number

destination telephone number

Choosing the Primary or Alternate greeting Company Directory

changing your name in recording your name in removing a name from

Company Directory name Copying a message

to other recipients

using ALL

using CC

Custom Call Routing (CCR)

transferring calls to

Custom feature codes

13, 19, 42, 86

27, 29

Default feature codes 21 Default pager message Default password Default values and tone commands Default values for Special Mailboxes Deleted messages, retrieving Deleting

Personalized greeting

Deleting messages Destination number

character limit for pagers special characters in when Enterprise Edge Voice Messaging is

behind PBX or Centrex

used to access an outside line

Destination pager number

character limit

15, 18

36 71

58, 70

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 98

98 Index

Destination telephone number

character limit

Directory number sent as default pager message

Displaying feature codes

Entering a destination number 58 Entering characters

on command line

Enterprise Edge ATA 2

has no feature button no Message Waiting Notification capability

Enterprise Edge one-line display telephones

using using the dialpad to make selections

Enterprise Edge two-line display telephones,

using

Enterprise Edge Voice Messaging

default password display how callers reach transferring calls to using

using with rotary dial telephone Erasing messages Etiquette, telephone

with touch tone telephone

81, 83

Feature 980 Feature 981 Feature 985 Feature 986 Feature 987 Feature 988

Feature codes

default

displaying

programming

table of Forwarded messages

recording an introduction for Full mailbox

42 42 11 55, 56, 57 52 44

General Delivery mailbox 35

purpose

used when Personal mailbox not available

Greetings

Alternate

example purpose using

28, 83

28, 29, 34

Information Personal Personalized

Primary

recording

types of

Group List

name sending messages to

Group message

using a Group List

Guest mailboxes

no operating extension for

Guide, organization

assigning available with Caller ID deleting recording

example purpose

Alternate Primary

29, 34

16, 27

28, 83

Hold tone 39 Home menu

Information greeting

example purpose

Information message

automatic disconnection from

CCR Initializing your mailbox Internal messages, replying to Interrupting calls Interrupting voice prompts

29, 34

22, 52

9, 10, 12

Language, Alternate 13 Leave Message feature Listening to your messages. see Playing your

mailbox messages

11, 42, 46, 47

Mailbox

full

initializing

setting up

83, 85

Mailbox greetings, see Greetings Mailboxes

General Delivery

purpose Guest Information

21, 27, 35, 41, 51, 55, 65, 81,

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Page 99

Index 99

Personal Special User

Making selections using the dialpad

with Enterprise Edge one-line display

Memory buttons Menu, Home (CCR) Message Delivery options

assigning Certified Normal Private Timed Delivery Urgent

Message Waiting Notification

not available with Enterprise Edge ATA 2

Messages

addressed to a Group List Broadcast copying

cut off deleted, retrieving deleting erasing Group left in General Delivery mailbox listening to, see Messages, playing playing

playing the next playing the previous Private, cannot copy quitting recording replaying replying to saving sending sending to multiple recipients

telephones

36, 50

using ALL using CC

pausing rewinding skipping forward skipping to end the Envelope volume control

42 37

37, 48

37 50

Name

recording in Company Directory

removing from Company Directory Never Full mailbox feature Normal Message Delivery option

Off-premise Message Notification

activated by interrupted message changing parameters destination number

character limit

destination pager number and message

character limit feature restrictions not working setting up

to a pager number

to a telephone number

to an extension number stopping unwanted

Off-premise Message Notification parameters

destination telephone number destination type time range types of message

Open Mailbox feature Opening your mailbox

remotely

Operator

transferring to

Optimizing Outbound Transfer Organization, guide Outbound Transfer

activating canceling destination pager number

character limit destination telephone number

character limit setting up

to a telephone number

to an extension number

63 63

72 71 70

11, 42, 45, 46

58 58

61–62

Password 86

“locked-out” changing

default Pause characters, adding Pausing a message Personal greetings

example

recording technique Personal Mailbox

Guest

User Personal messages addressed to a Group List

16, 27

P0908524 Issue 01 Enterprise Edge Voice Messaging Reference Guide

Page 100

100 Index

Personalized greeting

assigning deleting

recording Play order of messages Playing the message Envelope Playing your mailbox messages Prerequisites, for using guide Primary greeting Primary or Alternate greeting

choosing Private Message Delivery option

no forwarding with Private messages

cannot copy

not forwarded Programming a memory button

to a feature code Prompt language, wrong

28, 83

Recording

Alternate greeting

Personalized greeting

Primary greeting

your name in the Company Directory Recording a call Recording messages Recording technique

Personal greetings Replaying messages Reply feature Replying

to an external message sender

to an internal message sender

to messages Retrieving deleted messages Rewinding messages Routing messages from General Delivery

mailbox

using the DIAL option using the CALL option

using the MSG option

48 48 48

37, 48

Saving messages 37 Sending messages

to a Group List to multiple recipients

Setting up

Off-premise Message Notification

to a pager number to a telephone number to an extension number

Outbound Transfer

to a telephone number to an extension number

your mailbox

81, 83, 85

Skipping forward in messages Skipping forward to end of messages Special characters

in destination number

Special mailboxes

General Delivery System Administrator

Stopping unwanted Off-premise Message

Notification

21, 27, 35, 41, 51, 55, 65,

61–62

Target Attendant, assigning 20 Timed Message Delivery option Timeout Transfer Transferring

Transferring calls

Troubleshooting Types Types of greeting

to Operator to the Automated Attendant

to CCR to Enterprise Edge Voice Messaging to General Delivery mailbox to Operator to receptionist

Urgent Message Delivery option 44 Urgent messages

Play order of messages

User mailboxes

Voice prompts 11, 44, 51

interrupting on an Enterprise Edge one-line display

telephone

Volume control

9, 10, 12

Enterprise Edge Voice Messaging Reference Guide P0908524 Issue 01

Nortel Networks P0908524 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

How to use this guide

Introduction

Conventions and symbols used in this guide

Prerequisites

Using Enterprise Edge Voice Messaging

Introduction

Enterprise Edge telephones

Enterprise Edge one line display telephones

Enterprise Edge two line display telephones

Alternate extensions

Enterprise Edge ATA 2

Entering characters on the Enterprise Edge dialpad

Enterprise Edge Voice Messaging voice prompts

Interrupting a voice prompt

Automated Attendant

Types of mailboxes

Personal mailbox

Information mailbox

Special mailboxes

Setting up your mailbox

Introduction

Initializing your mailbox

Opening your mailbox

Opening a mailbox after it is initialized

Opening your mailbox remotely

Mailbox Password

Changing your mailbox password

Company Directory

Recording or changing your name in the Company Directory

Assigning a Target Attendant

Feature codes and mailbox options

Introduction

Feature codes

Determining custom feature codes

Programming a memory button with a feature code

Mailbox options

Main Mailbox menu and options

Mailbox Administration menu

Greetings

Introduction

Types of mailbox greetings

Personal mailbox greetings

Information mailbox greetings

Recording the Primary or the Alternate mailbox greeting

Choosing the Primary or the Alternate mailbox greeting

Recording a Personalized mailbox greeting

Deleting a Personalized mailbox greeting

Recording an Information mailbox greeting

Accessing your messages

Introduction

Receiving calls

Enterprise Edge Voice Messaging Never Full mailbox feature

Listening to your mailbox messages

About erased messages

Call Screening

Sending messages

Introduction

Types of messages

Broadcast messages

Personal messages

About recording and sending a message

Using the Company Directory

Message deliver y options

Assigning message delivery options using the Open Mailbox feature

Assigning message delivery options using the Leave Message feature

Recording and sending a message using the Open Mailbox feature

Recording and sending a message using the Leave Message feature

Replying to messages

Replying to an internal message sender

Replying to an external message sender

Sending a message to more than one recipient

Sending a message using a Group List

Copying a message to other recipients

Forwarding a copy of a message to one or more recipients

Call Forwarding your calls
