Page 1

Title page

Meridian 1, Succession 1000, Succession 1000M Succession 3.0 Software

i2002 Internet Telephone User Guide

Page 2

Page 3

Revision history

October 2003

Standard 2.00. This document is up-issued to support Succession 3.0 Software.

November 2002

Standard 1.00. This document is issued to support Meridian 1 Release 25.40 and Succession Communication Server for Enterprise 1000, Release 2.0.

Revision history

Page 4

Contents

i2002 Internet Telephone 7

Features................................................................................................ 7

Your i2002 Internet Telephone’s controls 8

i2002 Internet Telephone display 11

Install your i2002 Internet Telephone 12

Your i2002 Telephone Option menu 14

Adjust volume...................................................................................... 15

Adjust Screen contrast.......................................................................... 17

Select a language ................................................................................ 18

Select Date/Time format....................................................................... 18

Display diagnostics.............................................................................. 19

Local Dialpad Tone.............................................................................. 19

Choose Ring type................................................................................. 20

Enable OnHook Default Path ................................................................ 20

Change Feature Key Label.................................................................... 21

Set Information .................................................................................... 22

Call features 23

Make a call 24

Make a call while on-hook ................................................................... 24

Make a call while off-hook ................................................................... 24

Use Handsfree calling .......................................................................... 25

Use the Corporate Directory ................................................................. 26

Use Predial.......................................................................................... 28

Use Auto Dial...................................................................................... 29

Activate Ring Again............................................................................. 30

Redial last number called ..................................................................... 31

Use Speed Call.................................................................................... 31

4 Draft 0.01

Page 5

Contents

Make a System Speed Call................................................................... 32

Use Hot Line........................................................................................ 32

Make an Intercom call.......................................................................... 33

Answer a call 34

While on an active call 35

Place a call on hold ............................................................................. 35

Transfer a call ..................................................................................... 35

Use Timed Reminder Recall .................................................................. 36

Use Attendant Recall............................................................................ 37

Use Call Park ...................................................................................... 37

Record a Calling Party Number ............................................................ 39

Display incoming calls ......................................................................... 39

Trace a Malicious call .......................................................................... 40

Incoming calls 41

Activate Automatic Answerback............................................................ 41

Activate Call Pickup............................................................................. 41

Use Call Waiting................................................................................. 42

While you are away from your desk 44

Use Call Forward ................................................................................ 44

Use Internal Call Forward..................................................................... 45

Use Remote Call Forward..................................................................... 45

Secure your telephone ......................................................................... 47

Talk with more than one person 49

Use the Call Join feature....................................................................... 49

Set up a Conference call ...................................................................... 49

Use the Conferee selectable display and disconnect feature .................... 50

Use Group Call ................................................................................... 51

Work without interruption 53

Activate Make Set Busy ........................................................................ 53

Page 6

Contents

Additional call features 54

Auto Dial Transfer feature .................................................................... 54

Use the Buzz signal.............................................................................. 54

Use Call Page Connect to make an announcement ................................. 55

Use Centrex/Exchange Switchhook Flash .............................................. 55

Charge a call or Charge a Forced call................................................... 56

Use Enhanced Override feature ............................................................ 58

Use Forced Camp-on feature ................................................................ 58

Override a busy signal......................................................................... 59

Use Privacy Release ............................................................................. 60

Use Radio Page................................................................................... 60

Use Voice Call..................................................................................... 62

Additional features 63

Virtual Office....................................................................................... 63

Succession Branch Office ..................................................................... 68

Hospitality features 70

Set Automatic Wake-Up....................................................................... 70

Activate Message Registration............................................................... 71

Use Maid Identification ........................................................................ 72

Display Room Status ............................................................................ 73

Flexible Feature Codes (FFCs) 75

Terms you should know 76

Index 80

6 Draft 0.01

Page 7

i2002 Internet Telephone

This document describes i2002 features and how to use the i2002 Internet Telephone. The i2002 Internet Telephone brings voice and data to the desktop by connecting directly to a LAN through an Ethernet connection.

Note 1: Not all features are available on all telephones. Consult your network administrator to verify which features are available for your use.

Note 2: In this guide, Programmable Line (DN)/Feature Keys (self-labeled) keys display beside the label. Soft Feature keys display directly below the label.

Features

The i2002 Internet Telephone supports the following features:

• Four Programmable Line (DN)/Feature Keys (self-labeled)

• Four Soft Keys (self-labeled) providing access to ten features

• Large multi-field LCD display

• Wideband-compatible speakerphone

• Headset jack with On/Off key

• Volume control bar for adjusting ringer, speaker, handset, and headset

• Six specialized fixed keys:

— Quit

— Directory

— Inbox (Message)

— Shift (reserved for future feature development)

— Services

— Expand to PC (reserved for future development)

• Call processing fixed keys:

— Hold

— Goodbye

— Handsfree

— Mute

• Automatic IP address

• Hearing-aid compatibility

Page 8

Your i2002 Internet Telephone’s controls

Speaker

Handsfree Key LED

Programmable Line (DN)/ Feature Keys (self-labeled)

Message Waiting Light/ Incoming Call Indicator

LED

Mute

LED Volume Control Bar

Soft Keys (self-labeled)

Navigation Keys Inbox (Message)

Shift Directory

Services Quit Expand to PC

Goodbye

Hold

Headset

Your i2002 Internet Telephone’s controls

Use the Volume Co n t r ol to adjust the volume of the Handset, Headset, Speaker, Ringer, and Handsfree features. Press the right side of the rocker bar to increase volume, the left side to decrease volume.

552-ITG0010

Use the Goodbye key to terminate an active call.

Press the Headset key to answer a call using the headset or to switch a call from the handset or Handsfree to the headset.

2498

A steady LCD light beside a Line (DN) key indicates the feature or line is active. A flashing LCD indicates the line is on hold or the feature is being programmed.

Page 9

Your i2002 Internet Telephone’s controls

Press the Hold key to put an active call on hold. Press the Line (DN) key beside the flashing to return to the caller on hold.

Press the Speaker key to activate handsfree. The speaker LED lights to indicate when handsfree is active.

The Expand to PC key is a fixed key that is reserved for future development.

Press the Inbox (Message) key to access your voice mailbox.

Note: On the 3900 telephone series, the

Messages key corresponds to the Inbox (Message) key.

The Shift key is a fixed key that is reserved for future feature development.

Press the Directory key to access directory services.

Press the Mute key to listen to the receiving party without transmitting. Press the Mute key again to return to a two-way conversation. The Mute key applies to Handsfree, Handset, and Headset microphones. The Mute LED flashes when the Mute option is in use.

Use the Navigation keys to scroll through menus and lists in the display area.

Press the Quit key to end an active application. Pressing the Quit key does not affect the status of the calls currently on your telephone.

Page 10

Your i2002 Internet Telephone’s controls

Press the Services key to access the following items:

• Telephone Option:

• Virtual Office Login and Virtual Office

• Test Local Mode and Resume Local

- Volume Adjustment

- Contrast Adjustment

- Language

- Date/Time Format

- Display diagnostics

- Local Dialpad Tone

- Ring type

- OnHook Default Path

- Change Feature key Label

- Set Information

Logout (if Virtual Office is configured)

Mode (if Branch Office is configured)

2498

More..

CallWait

FWD

The Primary Directory Number (DN) keys are the Line/Feature keys located at the sides of the upper display area. When you pick up the handset, the line associated with this key can support a call.

Note: Although you can have additional DN keys assigned to your telephone, there is only one Primary DN.

Press the More.. key to access the next layer of Soft Feature (self-labeled) keys.

Programmable Line (DN)/Feature Keys (self-labeled) are configured for various

features on the telephones.

Soft Keys (self-labeled) are located below

the display area. The LCD label above the key changes, based on the active feature.

Note: A triangle appears before a key label indicates that the key is active.

Page 11

i2002 Internet Telephone display

This section summarizes the display features of the i2002 Internet Telephone. The Idle display is shown in the figure below.

The i2002 telephone has two display areas:

• The upper display area provides line and feature key status and

contains single line information for items such as party and set information.

• The lower display area provides feature key labels.

Programmable Line DN/

Feature Keys (self-labeled)

Date/time display

Call party info

Feature Status info

Options info

Directories info

Soft Keys

(self-labeled)

Auto Dial Auto Dial Auto Dial 2637

Jan 31 5:54pm

Nortel Networks

Navigation Keys

553-ITG0011

Page 12

Install your i2002 Internet Telephone

Connect the i2002 telephone components

CAUTION Damage to Equipment

Do not plug the i2002 Internet telephone into an ISDN connection. This results in severe damage to the i2002 telephone. Consult your system administrator to ensure that you plug your set into a 10/100BaseT Ethernet jack.

1. Connect one end of the handset cord to the handset jack (identified with a handset icon) on the back of the telephone and the other end to the jack on the handset.

2. Choose one of the following connections:

a. For a telephone not sharing a LAN access with a PC,

connect one end of the CAT-5 line cable to the LAN ethernet port located on the back of the telephone (identified with a LAN icon). The other end of the CAT-5 line cable plugs into the IP network.

b. For a telephone sharing a LAN access with a PC,

connect one end of the CAT-5 line cable to the LAN ethernet port located on the back of the telephone (identified with a LAN icon) and the other end to the IP network. Insert a second CAT-5 line cable into the PC ethernet port located on the back of the telephone (identified with a PC icon) and the other end into the computer's Ethernet port.

3. Contact your installation technician for the proper power option. This telephone can be powered by an AC adapter or over a LAN.

4. Thread the cord around the strain relief, retaining hook, and channel provided for a secure power connection.

5. Secure the telephone footstand to the telephone base. Use the angle grip on the top back of the telephone to change position.

Page 13

i2002 Ethernet port connections

Network Ethernet

PC Ethernet

Install your i2002 Internet Telephone

Page 14

Your i2002 Telephone Option menu

The i2002 Internet Telephone Services menu lists the following menus:

• The Telephone Option menu enables you or your Network

Administrator to configure telephone preferences.

• The Virtual Office Login and Test L o c a l Mode (for Branch Office)

menus are listed when an i2002 Internet Telephone class of service is set for Virtual Office and Branch Office.

The Telephone Option menu offers the following options:

Volume adjustment...

Contrast adjustment

Language...

Date/Time format...

OnHook Default path

Note: The ellipses (...) appears after an option item to indicate a sublist.

To use the Telephone Option menu:

1. Press the Services key.

2. Using the Navigation keys to move up

Telephone Option

Select

3. Press the Select key.

Display diagnostics

Local Dialpad Tone

Ring type...

Change Feature key label

Set Information

and down through the Services Menu, highlight Telephone O p t i o n.

Language...

4. Use the Navigation keys to scroll through the list of customizable options.

5. Highlight a feature to adjust (for example, Language).

Page 15

Your i2002 Telephone Option menu

Select

Quit

6. Press the Select key. The display

provides information required to adjust your selection.

7. Choose one of the following:

a. Press the Select key to save changes

and return to the Telepho ne O p t ion menu.

b. Press the Quit key to keep existing

settings.

Adjust volume

After selecting Volume adjustment... from the Telephone Option menu, choose Ringer, Handset, or Handsfree for volume adjustment.

To adjust Ringer volume:

Ringer

Lower

Higher

1. Select Ringer from the Vo lu me menu.

2. Press Lower to decrease volume,

Higher to increase volume.

3. Choose one of the following:

a. Press the Select key to save the

volume level and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Page 16

Your i2002 Telephone Option menu

To adjust Handset listen volume:

Handset listen

Lower

Higher

To adjust the Handsfree listen volume:

Handsfree listen

Lower

Higher

1. Select Handset listen from the

Volume menu.

2. Press Lower to decrease volume,

Higher to increase volume.

3. Choose one of the following:

a. Press the Select key to save the

volume level and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

1. Select Handsfree listen from the

Volume menu.

2. Press Lower to decrease volume,

Higher to increase volume.

3. Choose one of the following:

a. Press the Select key to save the

volume level and return to the

Telephone Option menu.

To adjust the Headset listen volume:

Headset listen

Lower

Higher

b. Press the Quit key to keep existing

settings.

1. Select Headset listen from the Volume menu.

2. Press Lower to decrease volume,

Higher to increase volume.

3. Choose one of the following:

a. Press the Select key to save the

volume level and return to the

Telephone Option menu.

Page 17

To adjust the Buzzer volume:

Your i2002 Telephone Option menu

b. Press the Quit key to keep existing

settings.

Buzzer

Lower

Higher

1. Select Buzzer from the Vo lu me menu.

2. Press Lower to decrease volume,

Higher to increase volume.

3. Choose one of the following:

a. Press the Select key to save the

volume level and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Adjust Screen contrast

The Screen contrast option adjusts the telephone’s display contrast. After selecting

Contrast Adjustment from the Telephone Option menu:

Lower

Higher

1. From the Contrast screen, press Lower

to decrease display contrast level,

Higher to increase display contrast

level.

2. Choose one of the following:

a. Press the Select key to save the

contrast level and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Page 18

Your i2002 Telephone Option menu

Select a language

The display is available in multiple languages. After selecting Language... from the

Telephone Option menu:

1. Using the Navigation keys, highlight the desired language (for example, German [Deutsche]).

Deutsche

Select

2. Choose one of the following:

a. Press the Select key to save the

language and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Select Date/Time format

There are several Date/Time formats. Formats are based on the 12-hour and the 24-hour clock. After selecting Date/Time format... from the Telephone Option menu:

1. Using the Navigation keys, highlight the desired format. Sample formats appear on the upper right side of the display area.

2. Choose one of the following:

Select

a. Press the Select key to save the

format and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Page 19

Your i2002 Telephone Option menu

Display diagnostics

The Display diagnostics option tests the telephone’s display screen and indicator lights. After selecting Display Diagnostics from the Telephone Option menu:

1. Using the Navigation keys, scroll

through the list to view display capabilities.

2. Press the Quit key to return to the

Telephone Option menu.

Local Dialpad Tone

The Local Dialpad Tone option enables a pressed telephone dial key to produce Dual Tone Multi-Frequency (DTMF) sounds, a single tone, or no sound. After selecting Local Dialpad Tone from the Telephone Option menu:

1. Using the Navigation keys, highlight

one of the following dial pad ring tones:

a. None to disable all tones.

b. Short Click to enable a single tone

for all keys.

Select

c. DTMF to turn on a separate DTMF

tone for each key.

2. Choose one of the following:

a. Press the Select key to save the tone

selection and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Page 20

Your i2002 Telephone Option menu

handsf

Choose Ring type

The Ring type option sets the telephone’s ring tone. After selecting Ring Type... from the Telephone Option menu:

1. Using the Navigation keys, highlight one of the ring types.

Ring type 3

Play

Select

2. Press the Play key to sample the ring tone.

3. Choose one of the following:

a. Press the Select key to save the ring

type and return to the Te le ph one

Option menu.

b. Press the Quit key to keep existing

settings.

Enable OnHook Default Path

When the set is on-hook, the OnHook Default Path option enables a Headset or a Handsfree connection. After selecting the OnHook Default Path from the

Telephone Option menu:

ree enable

headset enable

1. From the OnHook Default Path screen, choose one of the following:

a. Press the handsfree enable option.

b. Press the headset enable option.

2. Choose one of the following:

Select

a. Press the Select key to save the

default path and return to the

Telephone Option menu.

b. Press the Quit key to keep existing

settings.

Page 21

Your i2002 Telephone Option menu

Change Feature Key Label

The Change Feature Key Label option renames the label displayed next to each feature key or restores the default labels to the keys. After selecting Change Feature

Key Label from the Telephone Option menu, choose one of the following:

To Change the labels:

Select a Feature key

uit

Edit the Feature key label <The new label displays here>

Select Delete Clear More.. Select Case Clear More.. Select Symbol/Text Clear More..

To restore the default labels: Choose one of the following:

estore all key labels

1. From the Change Feature Key Label

screen, press Select key.

2. Press the Feature key that is being

changed.

3. Enter the new information for the

feature key label. To enter special characters, press the up navigation key.

Note:

If you enter a prime DN key, an

error message displays.

4. Press the Select key to save the changes

and return to the Telephone Option menu.

1. To restore all default labels:

a. From the Change Feature Key

Label screen, press the Restore all key labels key.

b. Press Ye s to change all feature keys

to default values.

Note: When Yes is selected and values are changed to the default values, you can not undo the change. Feature key labels are erased in the memory. The label settings must be re-entered.

2. To restore one selected label:

estore one key label

a. Press Restore one key label.

b. Press Select.

c. Press a feature label key.

Page 22

Your i2002 Telephone Option menu

d. Select Ye s to change the selected

feature label key to the default value.

Set Information

The Set Information option displays the following set-specific information:

• IP address

• Hardware ID of the Internet Telephone

• Current firmware version

• TN programmed on set

• Node ID and IP address

• The Voice Gateway Media Card on which the Internet Telephone is

registered

After selecting Set Information from the Telephone Option menu:

1. Using the Navigation keys, scroll through the list to view the Set information.

2. Press the Quit key to return to

Telephone Option.

Page 23

Call features

System administration is required for Call features. Contact your system

administrator to configure these features and codes on your telephone.

The Call features and Flexible Feature Codes (FFC) described in the following sections must be assigned to your telephone and supported by system software.

To access a feature, press a Feature key or enter a Flexible Feature Code.

Note: Whenever “Lift the handset” appears in this guide, you can also press the

Headset or Handsfree button.

Page 24

Make a call

This section describes features associated with making a call. There are several ways to make a call from an i2002 telephone.

To make a call:

1. Do one of the following:

2498

Make a call while on-hook

2498

a. Press the Line (DN) key.

b. Lift the Handset.

c. Press the Handsfree key.

d. If a Headset is connected, press the

Headset key.

2. Dial the number.

1. Leave the Handset in the cradle.

2. Press a Line (DN) key.

3. Dial the number when dial tone sounds.

Make a call while off-hook

4. When the called party answers, lift the

Handset.

1. Lift the Handset.

2. Dial the number.

Page 25

Make a call

Use Handsfree calling

Use Handsfree calling to operate a built-in microphone and speaker instead of the handset. While on an active call, you can switch between Handset and Handsfree mode.

To answer a call in Handsfree mode:

Press the Handsfree key.

To discontinue a Handsfree call:

Press the Goodbye key.

To mute a Handsfree call:

1. Press the Mute key. The LED indicator

flashes.

To switch from Handsfree to Handset mode:

To switch from Handset mode to Handsfree mode:

2. Press the Mute key again to return to a

two-way handsfree conversation.

1. Lift the Handset.

2. Replace the Handset to end the call.

1. Press the Handsfree key.

2. Replace the Handset.

3. Press the Goodbye key to end the call.

Page 26

Make a call

To use a Headset:

To switch from Handsfree to Headset:

Use the Corporate Directory

1. Connect the Headset to the headset jack or the handset jack depending on the headset type and telephone.

2. Press the Headset key.

Note: Amplified and unamplified headsets are compatible with the i2002 Internet Telephone.

3. Adjust your Headset volume by using

Volume adjustment... in the Telephone Option menu.

1. Connect the Headset and put the headset on.

2. Press the Headset key.

Use the Directory feature to view, select, and dial Corporate Directory numbers.

1. Press the Directory key to access the Directory.

Corporate Directory

Select

2. Using the Navigation key, highlight Corporate Directory.

3. Press the Select key.

Page 27

To search for a specific number:

Make a call

1. When prompted, use the keypad to enter

the desired name in the format, “Last, First”.

2. To edit the entry, select from the

following:

a. To toggle letters, use the 1-9

number keys.

b. For upper case letters, use the

second level of feature keys and press the Case key.

c. For special characters, use the up

and down Navigation keys (a

Choose key appears for selecting

the characters).

d. To remove the letter to the left of

the cursor, press the Delete key.

Dial

3. Press the Search key to find the desired

name.

Note: A successful search displays the first match on the screen.

4. Choose one of the following:

a. Press the Dial key to dial the result-

ing number.

b. If there is no match to the search

query, start a new search or change the information in the initial search.

c. Press the Quit key to exit without

dialing.

Page 28

Make a call

To scroll to a specific number:

1. Using the Navigation keys, scroll through the names in the Corporate Directory.

Dial

2. Press the Dial key to dial the resulting number.

Use Predial

Use the Predial feature to enter, preview, and edit numbers before dialing.

To use Predial:

1. Without selecting a Line key, dial the number.

2498

To edit a Predial number:

2. Press a Line key to dial the number.

3. Lift the Handset when the called party answers or, if in Handsfree mode, begin to talk.

1. Without selecting a Line key, dial the number.

2. Using the Navigation keys to highlight the numbers, re-enter new numbers.

2498

3. Press a Line key to dial the number.

Page 29

Make a call

Use Auto Dial

Use the Auto Dial feature to display, store, and automatically dial telephone numbers.

To use Auto D i a l:

1. Lift the Handset.

AutoDial

To display Auto Dial number:

Display

AutoDial

To store an Auto Dial number:

AutoDial

2. Selecting an associated Auto Dial key

from the upper display area, press to dial the number.

1. Press the Display key.

2. Selecting from the upper display area,

press the configured Auto Dial key.

1. Without lifting the handset, press the

appropriate Auto Dial key.

Note: The display screen displays the word “Autodial” next to the appropriate key.

2. Dial the telephone number (including

access code) to be stored on the selected

Auto Dial key.

3. Press the Auto Dial key a second time

to store the number on the selected key.

Note: Once a number has been stored, the word “Autodial” disappears, and the stored number displays.

4. Assign a label to the key.

Note: After assigning the label, the number disappears and only the label appears on the screen next to the key.

Page 30

Make a call

Activate Ring Again

Use the Ring Again feature if a busy tone sounds or when there is no answer after placing a call. Ring Again activates an audible tone notification that you receive when the person you tried calling is available or has used their telephone. Ring Again also automatically redials the number.

To use Ring Again:

1. Dial a number and receive a busy tone or no answer.

RngAgn

To call a Ring Again party when you receive notification:

RngAgn

To Quit Ring Again before notification:

RngAgn

2. Choose one of the following:

a. Press the Ring Again key.

b. Enter the Ring Again Activate

FFC.

1. After receiving the notification tone, lift the Handset.

2. Press the Ring Again key to automatically dial the number.

Choose one of the following:

a. Before hearing the notification

tone, press the Ring Again key a second time.

b. Enter the Ring Again Deactivate

FFC.

Page 31

Make a call

Redial last number called

Use the Last Number Redial feature to automatically redial the last dialed number.

To use Last Number Redial:

Choose one of the following

1. To redial using the Handset:

2498

a. Lift the Handset.

b. Press the Line (DN) key.

2. Without lifting the Handset, press the

Line (DN) key twice (the last number

dialed is automatically redialed).

Use Speed Call

By entering a one, two, or three digit code (0–999), use the Speed Call feature to store, edit, and automatically dial frequently called telephone numbers.

To store a Speed Call number:

SpcCtl

1. Press the Speed Call Controller key.

The triangular icon flashes, indicating programming mode.

2. At the prompt:

a. Enter a one-, two-, or three-digit

code (0-999), and telephone number (internal, external, or long-distance number).

SpcCtl

b. If required, dial the access code.

3. Press the Speed Call Controller key

again to save the code and number. The flashing icon turns off.

Page 32

Make a call

To make a Speed Call:

1. Lift the Handset.

SpcCtl

2. Press the Speed Call Controller key.

3. Dial the Speed Call code to automatically dial the number.

Make a System Speed Call

Use the System Speed Call feature to dial Speed Call codes that override all restrictions on a call.

To make a System Speed Call:

1. Lift the Handset.

SScUsr SScCtl

2. Press the System Speed Call key or the

System Speed Call Controller

(SScCtl) key.

3. Dial the Speed Call code to automatically dial the number.

Use Hot Line

Use the Hot Line feature to automatically dial a specific number. Other features, such as Call Redirection, can be added to Hot Line. Call Redirection redirects a Hot Line call to be answered only by a person.

To use Hot Line:

HotLne

Press the Hot Line to automatically dial the number.

Page 33

Make a call

Make an Intercom call

Use the Intercom feature to call a member of your intercom group by pressing the code assigned to each member.

To make an I n t ercom call:

1. Lift the Handset.

Intrcm

To answer an Intercom call while on a line other than your Intercom group line:

Intrcm

2. Press the Intercom key.

3. Dial the one- or two-digit code for the

desired intercom group member.

1. Press one of the following keys:

a. The Hold key to put the current call

on hold.

b. The Goodbye key to end the call.

2. Press the Intercom key and begin to

speak.

Page 34

Answer a call

Each incoming call causes the telephone to ring and the LCD indicator to flash.

To answer a call:

1. Choose one of the following:

a. Lift the Handset.

b. Press the Handfree button located

on the left side of the handset.

Note: The Handsfree feature may not be available on your telephone.

2498

c. Press the Line (DN) key beside the

LCD indicator as it flashes.

d. Press the Headset key if a headset

is connected to your telephone.

Page 35

While on an active call

This section describes features available during an active call.

Place a call on hold

Use the Hold feature when talking on one line and another call arrives on a second line. Retain the original call by putting it on hold and then answer the second call.

To place a call on hold:

Press the Hold key. The LCD indicator flashes beside the line on hold.

Note: If Automatic Hold is enabled, the active call is automatically put on hold when you answer the second call.

To retrieve a call on hold:

2498

Press the Line (DN) key beside the flashing LCD indicator.

Transfer a call

Use the Transfer feature to redirect a call to the appropriate person.

To use the Transfer feature to direct a call to a third party:

TRANSF

1. Press the Transfer key. The other party

is on hold and a dial tone sounds. The LCD indicator light flashes steadily.

2. Dial the DN number to which the call is

transferred.

3. When that number rings or a person

answers, press the Transfer key.

Page 36

While on an active call

To go back to the original call, if the transfer is incomplete:

2498

If the person called is not available, press the

Line (DN) key (next to the LCD indicator)

to reconnect to the original call.

Use Timed Reminder Recall

Use the Timed Reminder Recall feature to receive a reminder tone when a transferred call is not answered.

To use Timed Reminder Recall:

TRANSF

or b. Replace the Handset before the

1. Press the Tran sfer key. The call is put on hold.

2. Dial the number to which the call is being transferred.

3. Choose one of the following:

a. Press the Transfer key again.

extension answers. This starts the recall timer.

If the transferred call is not answered, your telephone rings:

TRANSF

Note: If the transfer is complete, the recall timer stops.

1. Lift the Handset to reconnect to the original caller.

2. Choose one of the following:

a. Press the Tr ansfe r key and repeat

the transfer (to a different DN).

b. If the transfer is picked up while

you are on the line, press the

Goodbye key to complete the

transfer.

Page 37

While on an active call

Use Attendant Recall

Use the Attendant Recall feature to contact an attendant during a call and to connect the call to the attendant.

To contact the attendant while on a call:

AttRcl

1. Press the Attendant Recall key and stay

on the line until the attendant answers.

2. Press the Goodbye key. The caller

remains connected to the attendant.

Use Call Park

Use the Call Park feature to hold temporarily (parked) and retrieve a call from any telephone. Using Call Park does not tie up a line and, when configured network-wide, can be used across networks. A System Park Extension can be set to automatically park most calls.

To park a call on the System Park DN or your own DN:

Park Park

To park a call on a DN other than the System Park DN or your own DN:

Park

During an active call, press the Park key twice.

By default, the call is parked on your DN unless a System Park is enabled to automatically park calls on the system.

1. Press the Park key.

Park

2. Dial the DN where you want to park the

call.

3. Press the Park key.

Page 38

While on an active call

To park a call using the SPRE code or FFC:

TRANSF

To retrieve a parked call:

Conf

Park

Conf

1. Press the Tran sfer key or the

Conference key.

2. Dial the Call Park FFC.

3. To use an alternate DN from the System

Park DN or your own DN, dial the DN

where you want to park the call.

4. Press the Tran sfer key or the

Conference key.

1. Lift the Handset.

2. Press the Park key.

3. Dial the Call Park FFC.

4. Dial the DN where you parked the call.

Note: If a parked call is not retrieved within a specified period of time, it rings back to your telephone or to the attendant.

Page 39

While on an active call

Record a Calling Party Number

Use the Calling Party Number feature to record a caller’s number or charge a call to an account number for accounting purposes during an established call.

To record a caller’s number for accounting purposes:

CParty

1. Press the Call Party key, the caller is

placed on hold.

The Entered number

displays.

2. Dial a charge account number or the

caller’s number.

Note: For information on using the

Charge key, see “Charge a call or

Charge a Forced call” on page 56.

CParty

3. Press the Call Party key to return to the

call.

Display incoming calls

Use the Display feature to display a second incoming caller’s number and name (if available) during an active call, without interfering with the call in progress.

To view the information on an incoming call while on a call in progress:

Disply

1. Press the Display key.

2498

2. Press the flashing Line (DN) key. The

call waiting information displays.

Note: When used with other feature keys, the Display key displays information associated with those feature keys.

Page 40

While on an active call

Trace a Malicious call

Use the Malicious Call Trace feature to trace nuisance calls within your system.

To use Call Trace while on a call:

CallTrace

To use Call Trace without a Call Trace key:

TRANSF

Conf

Press the Call Trace key.

1. Press the Transfer key or the

Conference key.

2. Dial the SPRE code followed by 83 or dial the Call Trace FFC to automatically reconnect.

Page 41

Incoming calls

This section describes features that are used with incoming calls.

Activate Automatic Answerback

When the Automatic Answerback feature is active, your set automatically answers in handsfree mode after one ring; however, calls are not forwarded to the voice message service.

To activate Automatic Answerback:

AtoAns

To deactivate Automatic Answerback:

AtoAns

Press the Automatic Answerback key.

Press the Automatic Answerback key again.

Activate Call Pickup

Use the Call Pickup feature to pick up calls from any telephone in the same pickup group or another pickup group.

To answer a call in your own Call Pickup group:

1. Lift the Handset.

Pickup

To answer an incoming call in another Call Pickup group:

2. Press the Pickup key, or enter the

Pickup Ringing Number FFC.

1. Lift the Handset.

GrpPkp

2. Press the Group Pickup key or enter

the Pickup Group FFC.

Page 42

Incoming calls

To answer a call at a specific extension in any pickup group:

3. Dial the pickup group number of the ringing telephone.

1. Lift the Handset.

DNPickup

2. Press the DN Pickup key, or enter the

Pickup Directory Number FFC.

3. Dial the DN of the telephone that is ringing (in your call pickup group).

If the pickup DN or group number is invalid (an overflow burst tone sounds and the screen displays Goodbye and try again), press the Goodbye key.

Use Call Waiting

Use the Call Waiting feature to alert you to an incoming call by producing a tone. It also puts the current call on hold while you answer the new call.

To answer an incoming call while on another call:

1. When the incoming call tone sounds, press the Hold key to put a current call on hold.

Note: If Automatic Hold is enabled, it is not necessary to press the Hold key.

CallWait

2. Press the Call Waiting key.

To return to the first telephone call:

1. Choose one of the following:

a. Press the Hold key to put the

second call on hold.

b. Press the Goodbye key to end the

second call.

Page 43

Incoming calls

2498

If you do not have a Call Waiting key:

2498

2. Press the Line (DN) key associated with

the first call.

1. Press the Goodbye key to end the

current call and answer the incoming call.

2. Press the Line (DN) key beside the

flashing status icon to answer the incoming call.

Page 44

While you are away from your desk

This section describes features that are used when you are away from your desk.

Use Call Forward

Use the Call Forward feature to direct incoming calls to ring at another Line (DN). If the telephone is in the process of ringing, that call cannot be forwarded.

To forward your calls or change the forward number:

CFWD

To Quit Call Forward:

CFWD

To reinstate Call Forward to the same number:

CFWD

1. Press the Forward key or lift the

Handset and enter the Call Forward All Calls Activate FFC.

2. Dial the DN where you want to forward your calls.

3. Press the Forward key.

Press the Forward key or lift the

Handset and enter the Call Forward All Calls Deactivate FFC.

Press the Forward key twice.

Page 45

While you are away from your desk

Use Internal Call Forward

Use the Internal Call Forward to accept only calls originating at internal DNs to ring at another DN. Calls originating outside your telephone system still ring at your telephone. Current incoming calls cannot be forwarded.

To forward internal calls:

IntForward

1. Press the Internal Call Forward key or

lift the Handset and enter the Internal

Call Forward Activate FFC.

2. Dial the DN to which your internal calls

will be forwarded.

IntForward

To Quit Internal Call Forward:

IntForward

3. Press the Internal Call Forward key.

Press the Internal Call Forward key or lift the Handset and enter the Internal

Call Forward Deactivate FFC.

To reinstate Call Forward to the same number:

IntForward

Press the Internal Call Forward key twice.

IntForward

Use Remote Call Forward

Use the Remote Call Forward feature to forward calls (from any telephone other than your own) to any telephone.

To activate Remote Call Forward:

1. Lift the Handset.

2. If calling from a telephone outside the

system, dial your direct system access number and wait for dial tone.

3. Dial the Remote Call Forward

Activate FFC to activate the feature.

Page 46

While you are away from your desk

4. Dial your Station Control Password. A dial tone sounds.

5. Choose one of the following:

a. Dial your DN.

b. To forward calls to the previous call

forward telephone number, press the # key. (Do not perform steps 6 and 7).

6. Dial the number to which calls are being forwarded. If calls are forwarded to an invalid number, a fast busy signal sounds.

To Quit Remote Call Forward:

7. Press the # key.

1. Lift the Handset.

2. If calling from a telephone outside the system, dial the direct system access number and wait for the dial tone.

3. Dial the Remote Call Forward

Deactivate FFC.

4. Dial your Station Control Password.

5. After hearing the dial tone, dial your DN.

6. Press the # key.

Page 47

While you are away from your desk

Secure your telephone

Use the Electronic Lock feature to prevent others from making calls from your telephone. The lock consists of a password that you can change.

To lock your telephone:

1. Lift the Handset.

2. Dial the Electronic Lock Activate

FFC.

3. Dial your Station Control Password.

4. Choose one of the following:

a. If dialing locally, press the

Goodbye key.

b. If dialing FFC remotely, dial your

DN.

To unlock your telephone:

1. Lift the Handset.

2. Dial the Electronic Lock Deactivate

FFC.

3. Dial your Station Control Password.

4. Choose one of the following:

a. If dialing locally, press the

Goodbye key.

b. If dialing FFC remotely, dial your

DN.

Page 48

While you are away from your desk

To change your password (must be done from your telephone):

1. Lift the Handset.

2. Dial the Station Control Password

Change FFC.

3. Dial the current password for your telephone.

4. Dial the new password.

5. Dial the new password again.

6. Press the Goodbye key.

Page 49

Talk with more than one person

This section describes features that enable conversations between more than two people.

Use the Call Join feature

Use the Call Join feature to connect a call to a current active call. This creates a conference between the two callers and yourself.

To connect a call on hold (on a different line) to your current call:

Conf

2498

Conf

1. Press the Conference key.

2. Press the Line key that has the number

of the caller you want to connect to your current call.

3. Press the Conference key again to join

the person on hold to your conversation.

Set up a Conference call

Use a Conference call for three (or six, depending on your telephone’s configuration) people, including yourself.

To set up a conference call:

Conf

1. While on a call, press the Conference

key to place the party on hold. You receive dial tone.

2. Dial the number of the person you want

to add to the conference call. You can talk privately to the person you are adding at this time.

Conf

3. Press the Conference key a second time

to conference all parties together.

4. If necessary, repeat the procedure until

four people are in the conference.

Page 50

Talk with more than one person

If the person you attempt to add to the conference is unavailable:

1. Press the Goodbye key.

2498

2. Press the Line (DN) key with the flashing icon to return to your original

call

Use the Conferee selectable display and disconnect feature

Use the Conferee Selectable Display feature to list active conferees and disconnect a conferee from the conference call.

To view active conferees:

ConfDsp

To disconnect a conferee:

1. While on a conference call, press the

Conferee Selectable Display key to

turn on the LCD indicator. Each key press changes the screen to show a different active conferee.

Note: This action has no effect on the display of other telephones involved in the conference.

2. Press the Goodbye key. If configured, the Conference Count Display returns an updated total count of conferees. The LCD indicator turns off.

ConfDsp

2498

1. While on a conference call, press the

Conferee Selectable Display key until

the conferee you want to disconnect appears on the screen.

2. Press the DN key on which the conference call is established.

3. Choose one of the following:

a. For a single conferee, press the

Goodbye key. If configured, the Conference Count Display returns

an updated total count of conferees.

Page 51

Talk with more than one person

The LCD indicator turns off.

b. For multiple conferees, repeat steps

1 and 2 until all conferees are disconnected. Then press the

Goodbye key.

Use Group Call

Use the Group Call feature to automatically call members of a predefined group, one at a time, until they all answer.

To call group members:

1. Lift the Handset.

GrpCl

To answer a Group Call:

2. Press the Group Call key or enter the

Group Call FFC.

The feature automatically calls all group members. The icon flashes until all members answer.

The telephone numbers of the group members appear display as they answer. When the last person answers, the

Group Call indicator lights steadily.

When a person in your group is on a conference call or another group call, they are not connected to your group call.

After everyone in the group has answered, only the person who made the group call can put the call on hold.

1. Lift the Handset.

Note: About Notification Tones:

a. If you are on a call and receive three

10-second tones, this is the notification of a group call on your current extension.

Page 52

Talk with more than one person

To end a Group Call:

b. If you are on a call on another line

on your telephone when a group call is made, you receive a long tone through the handset or speaker.

c. If you are already on a conference

call or another group call, you do not receive notification of a group call.

Press the Goodbye key.

Note: When the person who made the group call disconnects, the call terminates for all members of the group. However, the members of the Group Call can disconnect from the call and not affect other members on the call.

Page 53

Work without interruption

This section describes features that provide uninterrupted work time.

Activate Make Set Busy

Use the Make Set Busy feature to make your telephone appear busy to all callers.

To activate Make Set Busy:

MakeSetBsy

To deactivate Make Set Busy:

MakeSetBsy

Press the Make Set Busy key, or lift the

Handset and enter the Make Set Busy Activate FFC.

Press the Make Set Busy key a second time to deactivate the feature, or lift the

Handset and enter the Make Set Busy Deactivate FFC.

Page 54

Additional call features

Auto Dial Transfer feature

Use the Auto Dial Transfer feature to transmit digits through your Auto Dial key to the central office after a Trunk Switchhook Flash. You must be on a Central Office/Exchange (CO) trunk call from or to a CO that offers Centrex or exchange line-type features.

To use Auto Dial Transfer when picking up an incoming trunk call:

CentrexSHF

AutoDial

1. Press the Centrex Switchhook Flash key and wait for interrupted dial tone.

2. Press the Auto Dial key to call the number desired.

3. Press the Goodbye key to end the call.

Use the Buzz signal

Use the Buzz feature to notify another person of a call, a visitor, or a request. Two telephones that are linked together enable one person to signal the other. The person signaled hears a buzz.

To buzz the telephone linked to your telephone:

Buzz

1. Press the Buzz key.

The telephone linked to your telephone buzzes as long as you press the key.

2. When you are finished signaling, press the Buzz key.

Page 55

Additional call features

Use Call Page Connect to make an announcement

Use the Call Page Connect feature to make an announcement over a paging system.

Note: A Page key on an attendant console overrides and disconnects the telephones. The telephones must re-access the page trunk.

To connect to Call Page:

1. Lift the Handset.

2. Dial the Page Trunk Access Code to

complete the connection to the page system.

3. Make your announcement.

To disconnect Call Page:

4. Press the Goodbye key.

Use Centrex/Exchange Switchhook Flash

Use the Centrex/Exchange Switchhook Flash feature during an established call to use a Centrex service, such as Call Transfer or Three-Way Calling.

To use Centrex/Exchange Line Switchhook Flash:

CentrexSHF

1. While in a call, press the

Centrex Switchhook Flash key.

A special dial tone sounds.

2. Dial the codes for your custom Centrex

feature.

3. Press the Goodbye key to end the call.

Page 56

Additional call features

Charge a call or Charge a Forced call

Use the Call Charge feature to charge a call to a specific account. The Forced Charge feature charges long-distance calls from a telephone restricted to local calls.

To charge a local or long-distance call to an account before you dial:

1. Lift the Handset.

Charge

To charge a call in progress:

TRANSF

Conf

Charge

2498

2. Press the Charge key or dial the

Call Detail Recording FFC.

3. Dial the charge account number.

4. When the dial tone sounds, dial the number.

1. Press the Transfer key or the

Conference key.

2. Press the Charge key or dial the

Call Detail Recording FFC.

3. Dial the charge account number.

4. Press the Line (DN) key to return to the call.

Page 57

To charge a call to an account when you transfer a call:

Additional call features

TRANSF

Charge

TRANSF

To charge a call to an account when you add someone to a conference call:

Conf

1. Press the Transfer key. The call is on

hold.

2. Press the Charge key or dial the

Call Detail Recording FFC.

3. Dial the charge account number.

4. After the dial tone, dial the number to

where the call is to be transferred.

5. Press the Tran sfer key when you hear

the telephone ring.

Note: You can talk privately to the person at the transfer number before you press the Transfer key.

1. Press the Conference key. The call is

placed on hold.

Charge

Conf

2. Press the Account key or dial the

Call Detail Recording FFC.

3. Dial the charge account number.

4. Dial the number of the person you want

to add to the conference.

5. Press the Conference key.

Page 58

Additional call features

Use Enhanced Override feature

Use the Enhanced Override feature to override an active call after you have attempted a Forced Camp-on. Use Enhanced Override to make a simple call or a consultation call, such as placing a call on hold and calling another party.

To use Enhanced Override:

You receive a busy signal after dialing a telephone number.

EnhOvr

1. Press the Override key or enter the

Override FFC to initiate a Forced

Camp-on.

If either person on the call disconnects at this time, you receive an overflow (fast busy/engaged) signal.

EnhOvr

2. Press the Override key again or enter the Override FFC again.

The other two persons on the call receive an override tone and a conference call is established between the three of you. If anyone disconnects, the other two persons remain connected.

To end the connection:

Press the Goodbye key.

Use Forced Camp-on feature

Use the Forced Camp-on feature to automatically ring another telephone (internal or external) immediately after that telephone disconnects from its current call. Forced Camp-on in conjunction with Priority Override is referred to as Enhanced Override.

To use Forced Camp-on:

EnhOvr

You are receiving a busy signal after dialing a telephone number.

1. Press the Override key, or enter the

Override FFC, to initiate a Forced

Camp-on.

Page 59

To answer a call camped-on to your extension:

Override a busy signal

Additional call features

Note: The person you called receives a tone, and you receive a ring/ringback signal or a busy/engaged signal, depending on the options chosen. You are now camped-on to the number you dialed.

2. When the person you called finishes

their call, your telephone automatically dials the number. Your and their telephones ring.

When the telephone rings, lift the

Handset.

Note: You can program your telephone for either Camp-on or Call Waiting, but not both.

Use the Override feature to override a busy signal and interrupt another call.

To override a busy/engaged signal:

1. Dial a telephone number and receive a

busy signal.

EnhOvr

2. Press the Override key, or enter the

Override FFC.

The people in the targeted call receive a tone for approximately one second. After Override joins you to their call, a short tone repeats every sixteen seconds.

To end the connection:

Press the Goodbye key.

Page 60

Additional call features

Use Privacy Release

Use the Privacy Release feature to enable one or more people who share your DN to join a call.

To use Privacy Goodbye in an established state:

PrivRls

Press the Privacy Release key during a call. A person joins the call by pressing the shared number (DN) key on their telephone (Multiple Appearance DN feature).

Use Radio Page

Use an on-site Radio Page system feature to page a person and stay on the line until they answer. The paged person answers the call after entering a special Page Meet-me code from any telephone.

To use Automatic Preselection (Meet -me page):

1. Lift the Handset.

2. Dial the Radio Paging Access FFC. The paging tone sounds (two beeps followed by a dial tone).

3. Dial the number of the party you want to page. After dialing, the ringback tone sounds.

Note: The paged person can use any telephone to enter a Radio Paging

Answer FFC, plus their own DN

number.

4. If your call goes unanswered for a preset time period and a 15-second high pitched tone sounds followed by silence, press the Goodbye key or replace the

Handset.

Page 61

Additional call features

To use Automatic Post selection: The called party is either busy on the

telephone or away from the desk.

To page the called party, there is no need to redial the number of the called party.

RadPag

1. Press the Radio Page key. A special dial

tone sounds.

2. Dial the Radio Paging Access FFC.

The ringback tone sounds.

Note: The paged person can use any telephone to enter a Radio Paging

Answer FFC, plus their own DN

number.

3. If your call goes unanswered for a preset

time period and a 15-second highpitched tone sounds followed by silence, press the Goodbye key or replace the

Handset.

To answer a Radio Page: If you carry a Radio Pager, a page indicates

that someone dialed your Directory Number (DN).

If the Radio Page system is set up to function in Meet-me mode, you can answer the page call from any telephone.

1. Lift the Handset.

2. Dial the Radio Page Answer FFC. The

paging tone sounds.

3. Dial your own DN to connect to the

paging caller. If the caller has hung up, a steady high pitched (Number Unavailable) tone sounds.

Page 62

Additional call features

Use Voice Call

Use the Voice Call feature to page another person or make an announcement through someone else’s telephone speaker.

To make a voice call:

1. Lift the Handset.

VceCal

To respond to a voice call:

2. Press the Voice Call key and make the announcement.

3. Press the Goodbye key.

Your telephone rings once and the caller's voice transmits through your speaker. Lift the Handset.

Page 63

Additional features

Virtual Office

When you are away from your office telephone, use the Virtual Office feature to transfer calls and all of it’s features to a remote telephone.

When designated as the office telephone, the i2002 can be activated for Virtual Office by an i2004, i2050, or an i2002 Internet Telephone. A Virtual Office login from an i2002 Internet Telephone to an i2004 or i2050 might be blocked in certain situations. Consult your local network administrator.

Virtual Office Login

To activate Virtual Office on your Office telephone from your Remote telephone:

1. Press the Services key to access the

Options menu.

Virtual Office Login

Select

2. Using the Navigation keys, highlight

Virtual Office Login.

3. Press the Select key. The display

provides a prompt for the User ID.

4. Enter your User ID.

5. Press the Select key. The display

provides a prompt for the password.

6. Enter the home Station Control

Password (SCPW).

7. If the User ID is not found locally the

message “Locating Remote Server” displays.

Note: After three failed login attempts, you must wait one hour before attempting to login again.

Page 64

Additional features

Virtual Office on your Remote Telephone

A successful login transfers all the features, time, date, and tones to your remote telephone from your office telephone.

Logged on to i2002

Figure 1: Logged on using an i2002 Figure 2: Logged on using an i2004

Figure 3: Logged on using an i2050

On the i2004 and i2050 displays, the two top left feature keys always remain empty (as your i2002 supports only four keys).

A User information line appears on all displays listing the number of your office telephone.

Page 65

Virtual Office on your Office Telephone

Additional features

When activated for Virtual Office by a remote telephone, your office telephone is logged out and no longer operational.

A Logged Out message displays on your telephone alerting you that it is being used for Virtual Office.

To regain operation of a telephone being used for Virtual Office:

Home

Virtual

Virtual Office Logout

To log out from a remote telephone:

Virtual Office Logout

Select

To regain operation of your telephone from Virtual Office, choose one of the following:

1. To completely disconnect your office

telephone from the remote telephone:

a. Press the Home key.

b. Enter your User ID and password

(this logs the office telephone back on to your office network).

2. To use your office telephone as the

remote telephone for Virtual Office, press the Virtual key to login to another telephone.

1. Press the Services key to access the

Options menu.

2. Using the Navigation keys, highlight

Virtual Office Logout.

3. Press the Select key.

Page 66

Additional features

Troubleshoot Virtual Office

When using Virtual Office you may encounter error messages displayed on your screen. The following table lists error messages and actions to correct the causes.

Table 1: Troubleshoot Virtual Office (Part 1 of 3)

Displayed Message Probable Cause Actions

Busy, try again Remote Internet

Telephone is active (not idle).

ACD is logged in. Log out ACD before

Make-Set-Busy is inactive on ACD Internet Telephone.

Invalid ID (1) Incorrect User ID

entered.

User ID is not in Gatekeeper database.

Invalid ID (2) Incorrect User ID

entered.

Invalid ID (3) Incorrect User ID

entered.

User ID in Gatekeeper database points to originating Succession Call Server.

Wait for remote Internet Telephone to become idle and try again.

Virtual Office from another Internet Telephone.

Set Make-Set-Busy active on ACD Internet Telephone.

Enter correct User ID.

Notify local network administrator.

Enter correct User ID.

Notify local network administrator.

Locked from Login Three failed attempts to

enter the correct Station Control Password.

Wait one hour for the lock to clear automatically, or notify local network administrator to clear lock.

Page 67

Table 1: Troubleshoot Virtual Office (Part 2 of 3)

Displayed Message Probable Cause Actions

Additional features

Permission Denied (1) Remote telephone has no

Station Control Password.

Permission Denied (3) Incorrect User ID

entered.

Remote telephone has no Station Control Password.

Permission Denied (4) Incorrect User ID

entered.

Attempt to login to a remote i2004 or i2050 Internet Telephone from an i2002 Internet Telephone (some restrictions apply).

Permission Denied (5) Incorrect User ID

entered.

Remote telephone does not have VOUA Class of Service.

Notify local network administrator.

Enter correct User ID.

Notify local network administrator.

Enter correct User ID.

Go to an i2004 or i2050 Internet Telephone and try again, or consult your local network administrator.

Enter correct User ID.

Notify local network administrator.

Permission Denied (6) Incorrect User ID

Enter correct User ID.

entered.

Incorrect Station Control Password entered.

Select Retry, and try again with the correct Station Control Password.

Server Unreachable (1) Network problem. Notify network

administrator if problem persists.

Page 68

Additional features

Table 1: Troubleshoot Virtual Office (Part 3 of 3)

Displayed Message Probable Cause Actions

Server Unreachable (2) Network problem. Notify network

administrator if problem persists.

Succession Branch Office

The Branch Office telephone can operate in the Normal or the Local mode.

Normal Mode

The telephone registers with the Main Office and receives telephone services from the Main Office. At any time during Normal Mode, you can check local mode functionality (make and receive calls) by enabling Local Mode and returning to Normal Mode. After testing, you can return to Normal Mode by using the Resume Normal Mode command or by waiting for ten minutes.

Local Mode

If the WAN connection goes down the telephone loses communication with the Main Office TPS. It then registers with the Branch Office and receives telephone services from the Branch Office. When in Local Mode, the telephone displays “LOCAL MODE”.

Test Local Mode

Use Test Local Mode to check local mode functionality (make and receive telephone calls). This is useful when provisioning has changed for an Internet Telephone on a Branch Office Controller.

1. Press the Services key to access the

Test Local Mode

Services menu.

2. Using the Navigation keys, highlight

Test Local Mode.

Select

3. Press the Select key (the telephone resets and registers to the Branch Office).

Page 69

Additional features

Resume Normal Mode

Use the Resume Normal Mode command to return to Normal Mode after testing survival functionality.

Note: If the Resume Normal Mode command is not performed after testing, the telephone automatically returns to Normal Mode in ten minutes.

1. Press the Services key to access the

Services menu.

Resume Normal Mode

2. Using the Navigation key, highlight

Resume Normal Mode.

Select

3. Press the Select key (the telephone

registers back to the Main Office).

Troubleshoot Branch Office

When using Branch Office you may encounter error messages displayed on your screen. The following table lists error messages and actions to correct the causes.

Table 2: Troubleshoot Branch Office

Display Message Probable Cause Actions

Local Mode Test Local mode. Press Services key, and

then select Resume Normal Mode.

Network problem. Contact Local network

administrator if problem persists.

Local Mode

Invalid ID (1)

Gatekeeper unable to find end point from Branch User ID.

Notify local network administrator.

Local Mode

Invalid ID (2)

Branch User ID not found in any equipped TN.

Notify local network administrator.

Page 70

Hospitality features

The hospitality features in this section are intended for hotel operations.

Set Automatic Wake-Up

Use the Automatic Wake-Up feature to receive a timed reminder call. From your telephone, you can program the Meridian 1, Succession 1000, or Succession 1000M to automatically place a call to yourself at a predetermined time. When you answer the call, recorded music plays for up to 30 seconds, followed by a prerecorded announcement or the attendant.

To enter the time for an Automatic Wake-Up call:

1. Lift the Handset.

2. Dial the Automatic Wake-Up Request

FFC.

3. Dial the Automatic Wake-Up time in a 24-hour time format (hhmm). A tone sounds to confirm your entered time.

To Quit an Automatic Wake-Up call:

Note: In a 24-hour time format, 7:30 a.m. is entered as 0730; 9:45 p.m. is

2145.

4. Press the Goodbye key.

1. Lift the Handset.

2. Dial the Automatic Wake-Up Quit

FFC.

3. Press the Goodbye key.

Page 71

Hospitality features

To verify the time for the Automatic Wake-Up call:

1. Lift the Handset.

2. Dial the Automatic Wake-Up Verify

FFC.

3. Dial the Automatic Wake-Up time in a

24-hour time format (hhmm). If your query matches the preset time, a confirmation tone sounds.

Note: In a 24-hour time format, 7:30 a.m. is entered as 0730; 9:45 p.m. is

2145.

4. Press the Goodbye key.

Activate Message Registration

Use the Message Registration feature to read, change, or reset meters that log your hotel telephone calls.

To read meters:

MRK

To change a meter:

MRK

1. Press the Message Registration key.

2. Dial the room Directory Number (DN).

3. Press the Message Registration key.

1. Press the Message Registration key.

2. Dial the room DN number.

3. Dial the correct meter count.

Page 72

Hospitality features

MRK

To reset a meter to zero:

MRK

4. Press the * key.

5. Press the Message Registration key.

1. Press the Message Registration key.

2. Dial the room Directory Number (DN).

3. Press the * key.

4. Press the Message Registration key.

Use Maid Identification

Use the Maid Identification feature to track the cleaning status of rooms. The maid enters the information from the telephone in each room.

To enter cleaning status:

RMK

1. Press the Room Status key.

2. Dial the Directory Number (DN) for the room for which the cleaning status is being changed.

3. Dial one of the following cleaning status codes:

1 = Cleaning requested

= Cleaning in progress

3 = Room cleaned

4 = Room passed inspection

5 = Room failed inspection

6 = Cleaning skipped

7 = Not for sale

The interrupted dial tone sounds.

Page 73

Hospitality features

RMK

4. Press the * key.

5. Dial the Maid ID. If you dial the wrong

Maid ID, press the * key and redial the

ID.

6. Press the Room Status key.

Display Room Status

Use the Room Status feature to print the status of a room using the Display Module.

To read the status of a room:

RMK

1. Press the Room Status key.

2. Dial the Directory Number (DN) for the

room. The DN displays followed by a two-digit code.

a. The first digit indicates the

occupancy status:

0 = Room vacant

1 = Room occupied

RMK

b. The second digit indicates the

cleaning status of the room:

1 = Cleaning requested

2 = Cleaning in progress

3 = Room cleaned

4 = Room passed inspection

5 = Room failed inspection

6 = Cleaning skipped

7 = Not for sale

3. Press the Room Status key.

Page 74

Hospitality features

To change the status of a room:

RMK

1. Press the Room Status key.

2. Dial the Directory Number (DN) for the room. The DN displays followed by a two-digit code.

a. The second digit indicates the

occupancy status:

0 = Room vacant

1 = Room occupied

b. The second digit indicates the

cleaning status of the room:

1 = Cleaning requested

2 = Cleaning in progress

3 = Room cleaned

4 = Room passed inspection

5 = Room failed inspection

6 = Cleaning skipped

7 = Not for sale

RMK

3. Dial the status code for the room. A three-digit code appears. The first digit indicates the occupancy status, the second is the old cleaning status, and the third is the new status.

4. Press the Room Status key.

Page 75

Flexible Feature Codes (FFCs)

Use this table to keep track of the FFCs assigned by your system administrator.

Call Detail Recording Charge Account

Call Forward All Calls Activate

Call Forward All Calls Deactivate

Call Forward All Calls Verify Override

Internal Call Forward Activate

Internal Call Forward Deactivate

Remote Call Forward Activate

Remote Call Forward Deactivate

Park Call Ring Again Deactivate

Park Call Access Speed Call Controller

Pickup Ringing Number Speed Call User

Make Set Busy Activate

Make Set Busy Deactivate

Malicious Call Trace

Radio Paging

Radio Paging Access

Radio Paging Answer

Ring Again Activate

Pickup Group System Speed Call User

Pickup Directory Number Station Control Password Change

Electronic Lock Activate Automatic Wake-Up Activate

Electronic Lock Deactivate Automatic Wake-Up Deactivate

Group Call Automatic Wake-Up Verify

Page 76

Terms you should know

Attendant

A telephone operator in your organization.

Auto Dial

A telephone number programmed on the AutoDial key for one touch dialing.

Call party information

The display showing Call Party Name Display (CPND) information including the telephone number and name of the incoming call. The system must have CPND enabled.

Date/time display

The current date and time when the telephone is in an idle state.

Directory key

Enables access to the Corporate Directory.

Terms you should know

Directory Number (DN)

Expand to PC

Fastbusy

Feature display

A number consisting of one to seven digits for a telephone. Also known as an extension number.

A Fixed key on the i2002 telephone that is reserved for future feature development. An audible non-working tone is generated along with a display message Service not available if this key is pressed.

A signal given when all outgoing lines are busy.

An area that shows status information about the feature in use. It also displays the name and status of the active session.

Page 77

Terms you should know

FFCs

See Flexible Feature Codes.

Fixed key

The hard labeled keys on your telephone.

Flexible Feature Codes (FFCs)

Specialized codes entered using the dial pad that enable features, for example Automatic Wake-Up call.

Handsfree

A method of conversing with the party on the other end of the line without lifting your handset.

Inbox (Message)

A Fixed key on the i2002 telephone that connects to your voice messaging system when the key is pressed.

Indicator

An LCD or an LED that indicates the status of a feature by the flash, wink, steady on, or off.

Information display

Information line

Interrupted dial tone

Meridian 1

Any display of call activity, lists, prompts, and status of calls. On the i2002 telephone this information area is a one-line by twenty-four characters. If the text message exceeds this area, a scroll arrow icon indicates that you must use the scroll keys to view the remaining text.

A one-line by twenty-four character area which displays date and time or application information.

A broken or pulsed dial tone, heard when you access some of the features on your telephone.

An office communications system.

Page 78

Terms you should know

More...

Off-hook

Paging tone

Primary Directory Number

An option allowing access to the multiple layers of the Soft keys. These keys are the four keys located directly below the display area.

Any line that is selected to either make a call or receive an incoming call. The term off-hook is applied, regardless of whether the end-user actually lifts up the handset, or presses a line key, or is automatically answered at the set, or a line is automatically selected for an outgoing call.

A special tone heard when using the Radio Paging feature. You hear two beeps followed by dial tone.

The main extension number on your telephone. It is referred to by the Primary Directory Number (PDN) key.

Private Line

Programmable Line (DN) /Feature Keys (self-labeled)

Quit key

Ringback/ring tone

A feature that can be assigned to your telephone. With this line, you can reach an outside number without dialing a code to access an outside line. Internal extensions cannot be dialed from a private line.

The four keys located at the sides of the upper area of the display.

A Fixed key on the i2002 telephone that is used to exit applications.

A sound indicating that a call you have made is ringing at its destination.

Page 79

Secondary Directory Number

A second incoming/outgoing line for your telephone.

Shared Directory Number

A DN (extension) that is shared by two or more persons.

Soft Keys (self-labeled)

A set of keys programmed by your system administrator. These four keys located directly below the display area have four programmable layers. The layers are accessed through the More... key. These keys are also used to configure parameters in the Telephone Option menu.

Special dial tone

The three consecutive tones followed by dial tone that you hear when accessing telephone features.

Status Messages

A message displayed to inform the user of important information. A right arrow appears if more than one Status Message is present. Examples of Status Messages include: Message Waiting, All Lines Forwarded to: 6453, Do Not Disturb On, Ring Again active, Ringer is OFF, and Line x Unavailable.

Terms you should know

System or Switch

Switchhook

User Interface

A Meridian 1, Succession 1000, or Succession 1000M; your office communication system.

A button that the handset presses down, disconnecting your call when you replace the handset. The handset (when lifted) releases the switchhook and you either answer an incoming call or you receive a dial tone to make a call.

In this User Guide, User Interface refers to the screen displays that interact with the end-user as a result of an action or event.

Page 80

Index

Application Key 10 Attendant 76 Attendant Recall 37 Auto Dial 29, 76 Auto Dial Transfer 54 Automatic Answerback 41 Automatic Wake-Up 70

Buzz signal 54

Call Charge 39 Call Forward 44 Call Forward - Internal 45 Call Join 49 Call Page 55 Call Page Connect 55 Call Park 37 Call party information 76 Call Pickup 41 Call Waiting 42 Camp-on, Forced 32 Centrex/Exchange Switchhook Flash 55 Change Feature Key Label 10, 21 Charge a call or Charge a Forced call 56 Conference call 49 Contrast adjustment 10, 17

Date/time display 76 Date/time format 10, 18 Direct system access 46 Directory 9, 26

Directory Key 26, 76 Directory Number 76 Display 17, 18 Display Diagnostics 10, 19 Display incoming calls 39 Display Key 39 DN 76

Electronic Lock 47 Enhanced Override Feature 58

Fastbusy 76 Feature display 76 Fixed key 77 Flexible Feature Code (FFC) 41, 42, 44, 45,

46, 51, 53, 58, 77

Forced Camp-on 32, 58

Goodbye Key 8, 25 Group Call 51

Handsfree 25, 77 Handsfree Button 25 Headset Key 8, 26 Hold 35 Hold Key 9 Hospitality features 70 Hot Line 32

i2002 Telephone display 11 Inbox (Message) 9, 77 Indicator status 77

Page 81

Index

Information display 77 Information line 77 Intercom call 33 Internal Call Forward 45 Interrupted dial tone 77

Join a call 49

Language 10, 18 Last Number Redial 31 Line (DN) Key 8 Local Dialpad Tone 10, 19

Maid Identification 72 Make Set Busy 53 Malicious call Trace 40 Meet - me page 60 Meridian 1 77, 79 Message Registration 71 More Key 10, 78 Mute 9, 25

Navigation Keys 9, 14

Off-hook 24 On-hook 24 OnHook Default Path 10 On-hook dialing 28 Override 58, 59

Page Meet- me code 60 Paging tone 78 Password change 48

Predial Recall 28 Primary Directory Number 10, 78 Privacy Release 60 Private Line 78 Programmable Line (DN) /Feature Keys

(self-labeled) 78

Quit Key 9, 78

Radio Page 60 Record a Caller’s Number 39 Redial last number called 31 Remote Call Forward 45 Ring Again 30 Ring type 10, 20 Ringback/ring tone 59, 78 Room Status 73

Secondary Directory Number 79 Secure your telephone 47 Selectable Conferee display and

Disconnect 50 Services 14 Services key 10 Set Information 10, 22 Shared Directory Numbers 79 Shift 9 Soft Keys (self-labeled) 10, 79 Speaker Key 9 Special dial tone 79 Speed Call 31 Speed Call, System 32 Station Control Password 46, 48 Status Messages 79 Succession 1000 79

Page 82

Index

Succession 1000M 79 Succession Branch Office 68 Switchhook 79 System or Switch 79 System Speed Call 32

Telephone Option 10 Timed Reminder Recall 36 Transfer a call 35

User Interface 79

Virtual Office 10, 63 Voice Call 62 Volume adjustment 10, 15 Volume Control 8

Page 83

Page 84

Meridian 1, Succession 1000, Succession 1000M

i2002 Internet Telephone User Guide

Networks reserves the right to make changes in design or components as progress in engineering and manufacturing warrant. This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules, and the radio interference regulations of the Industry Canada. These limits are designed to provide reasonable production against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which cast the user will be required to correct the interference at their own expense.

SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

Publication Number: P1002467 Document Release: Standard 2.00 Date: October 2003 Produced in Canada

Internet address

http://www.nortelnetworks.com
