NordicTrack NTBE05902 Owner's Manual

QUESTIONS?

As a manufacturer, we are com­mitted to providing complete
customer satisfaction. If you
have questions, or find that
there are missing parts, we will
guarantee you complete satis­faction through direct assis­tance from our factory.

TO AVOID UNNECESSARY
DELAYS, PLEASE CALL
DIRECT TO OUR TOLL-FREE
CUSTOMER HOT LINE. The
trained technicians on our cus­tomer hot line will provide
immediate assistance, free of
charge to you.

CUSTOMER HOT LINE:

1-888-825-2588

Mon.–Fri., 6 a.m.–6 p.m. MST

Model No. NTBE05902
Serial No.

Write the serial number in the
space above for reference.

CAUTION

Read all precautions and instruc­tions in this manual before
using this equipment. Save this
manual for future reference.

Serial

Number

Decal

USER’S MANUAL

Patent

Pending

Visit our website at

www.nordictrack.com

new products, prizes,

fitness tips, and much more!

2

Important Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Part Identification Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Adjusting the Weight System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Ordering Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

Note: APart List/Exploded Drawing is attached in the center of this manual. Remove the Part List/Exploded
Drawing before beginning assembly.

Table of Contents

NordicTrack is a registered trademark of ICON Health & Fitness, Inc.

3

1. Read all instructions in this manual before
using the weight rack. Use the weight rack
only as described in this manual.

2. It is the responsibility of the owner to ensure
that all users of the weight rack are ade­quately informed of all precautions.

3. The weight rack is intended for home use
only. Do not use the weight rack in a com­mercial, rental, or institutional setting.

4. Use the weight rack only on a level surface.
Cover the floor beneath the weight rack to
protect the floor or carpet.

5. Inspect and tighten all parts each time you
use the weight rack. Replace any worn parts
immediately.

6. Keep children under 12 and pets away from
the weight rack at all times.

7. Keep hands and feet away from moving
parts.

8. Always wear athletic shoes for foot protec­tion while exercising.

9. Always make sure that there is an equal
amount of weight (not included) on each side
of the barbell.

10. If you feel pain or dizziness while exercising,
stop immediately and begin cooling down.

11. Always set both safety spotters at the same
height.

12. Do not place more than 310 pounds, includ­ing the barbell, on the weight gliders and
safety spotters.

13. Always secure your weights (not included)
with weight clips when they are mounted on
the barbell.

14. The decal shown below has been placed on
the weight rack in the indicated location. If
the decal is missing or illegible, please call
our Customer Service Department toll-free at
1-888-825-2588 to order a free replacement
decal. Apply the decal in the indicated loca­tion.

WARNING:Before beginning this or any exercise program, consult your physician. This

is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

WARNING:To reduce the risk of serious injury, read the following important precau-

tions before using the weight rack.

Important Precautions

!

WARNING

• Misuse of this product may result in serious
injury.

• Read user’s manual and follow all warnings
and operating instructions prior to use.

• Do not allow children on or around machine.

• Replace label if damaged, illegible, or removed.

4

Weight

Storage

Tube

Dumbbell

Storage

Rack

Pull-up Bar

Upright

Weight Guide

Weight Glider

Barbell

Safety Spotter

Right Side

Left Side

Note: The terms “right side” and “left side” are
determined relative to a person sitting on the
optional weight bench; they do not refer to
right and left on the drawings in this manual.

Thank you for selecting the versatile NordicTrack

®

GRT380 weight rack. Whether your goal is a shapely
figure, dramatic muscle size and strength, or a healthi­er cardiovascular system, the NordicTrack®GRT380
will help you achieve the specific results you want. In
addition, the weight rack can be used with the optional
NordicTrack

®

GRT340 weight bench, shown in the
drawing below. To order the NordicTrack®GRT340, call
1-888-825-2588.

For your benefit, read this manual carefully before
using the NordicTrack

®

GRT380 weight rack. If you

have additional questions, please call our Customer
Service Department toll-free at 1-888-825-2588
Monday through Friday, 6 a.m. until 6 p.m. Mountain
Time (excluding holidays). To help us assist you,
please note the product model number and serial
number before calling. The model number is
NTBE05902. The serial number can be found on a
decal attached to the weight rack (see the front cover
of this manual).

Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.

Before You Begin

Optional NordicTrack®GRT340

Model No. NTBE01701

5

Part Identification Chart—Model No. NTBE05902

R0703A

Large Washer (28)

M10 Washer (3)

M8 Washer (35)

M8 x 20mm Screw (33)

M10 Nylon Locknut (7)

M8 x 30mm Bolt (22)

M10 x 25mm Bolt (27)

M10 x 65mm Bolt (26)

M10 x 70mm Bolt (29)

M10 x 90mm Bolt (9)
