Nokia MD-3 User Manual

Nokia Music Speakers MD-3

ENGLISH

The MD-3 stereo speakers offer high-quality audio when you listen to
music or the radio on your compatible Nokia phone or audio device. The
speakers have a 3.5-mm stereo audio plug (located at the base of the
speakers). With the supplied AD-15 or AD-50 adapter, the speakers can
be connected to a compatible Nokia phone that has a Pop-PortTM
connector or to a compatible device that has a 2.5-mm audio connector.

Read this user guide carefully before using the speakers. Also read the
user guide for your phone, which provides important safety and
maintenance information, or the user guide for the compatible audio
device. Keep all accessories and enhancements out of the reach of small
children.

9200267/1

Chargers

ENGLISH

Check the model number of any charger before use with this device.
The device is intended for use when supplied with power from the
AC-4 charger.

Warning! Use only chargers approved by Nokia for use
with this particular device. The use of any other types may
invalidate any approval or warranty, and may be dangerous.

When you disconnect the power cord of any enhancement, grasp and pull
the plug, not the cord.

Set up for use

ENGLISH

The speakers can be powered by three AA batteries or the supplied AC-4
charger. Note that the AC-4 charger does not charge the batteries.
When you use batteries, alkaline batteries are recommended.

To use the speakers on battery power, to install the batteries, open the
battery cover at the back of the speakers by pressing the two catches,
place the batteries as indicated in the battery compartment, and close
the battery cover by pushing it in place. During long periods where the
speakers are not used, remove the batteries to prevent damage from
battery leakage.

To use the speakers with the AC-4 charger, connect the charger to a wall
outlet, and plug the charger cable to the connector at the back of the
speakers.

Use the speakers

ENGLISH

To connect the speakers to the phone or audio device, plug the speaker
cable into the connector on the device. If the phone or audio device has a
Pop-Port connector or a 2.5-mm connector, connect the AD-15 or AD-50
adapter (respectively) to the device. Then connect the speaker cable to the
adapter.

To switch the speakers on or off, press the power key located at the top
of the speakers. When the speakers are switched on, the green indicator
light is on.

To set the volume, use the slider at the top of the speakers. If the sound
level of the speakers becomes too low when using battery power, change
the batteries.

Care and maintenance

ENGLISH

Your device is a product of superior design and craftsmanship and should
be treated with care. The following suggestions will help you protect your
warranty coverage.

• Keep the device dry. Precipitation, humidity, and all types of liquids
or moisture can contain minerals that will corrode electronic
circuits. If your device does get wet, allow it to dry completely.

• Do not use or store the device in dusty, dirty areas. Its moving
parts and electronic components can be damaged.

• Do not store the device in hot areas. High temperatures can shorten
the life of electronic devices, damage batteries, and warp or melt
certain plastics.

• Do not store the device in cold areas. When the device returns to
its normal temperature, moisture can form inside the device and
damage electronic circuit boards.

• Do not drop, knock, or shake the device. Rough handling can break
internal circuit boards and fine mechanics.

• Do not use harsh chemicals, cleaning solvents, or strong detergents
to clean the device.

• Do not paint the device. Paint can clog the moving parts and prevent
proper operation.

If the product is not working properly, take it to the nearest authorized
service facility for service.

ENGLISH

DECLARATION OF CONFORMITY

ENGLISH

Hereby, NOKIA CORPORATION declares that this MD-3 product is in
compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EC. A copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/declaration_of_conformity/.

The crossed-out wheeled bin means that within the European
Union the product must be taken to separate collection at the
product end-of-life. Do not dispose of these products as
unsorted municipal waste. For more information, see
product Eco-Declaration or country specific information
at www.nokia.com.

© 2006 Nokia. All rights reserved.
Nokia, Nokia Connecting People and Pop-Port are registered trademarks

of Nokia Corporation. Other product and company names mentioned
herein may be trademarks or tradenames of their respective owners.

ENGLISH

FCC/Industry Canada notice

This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: 1. This device may not cause harmful
interference; and 2. This device must accept any interference received,
including interference that may cause undesired operation. Changes or
modifications not expressly approved by Nokia could void the user's
authority to operate the equipment.

Altavoces para música MD-3 Nokia

ESPAÑOL

Los altavoces estéreo MD-3 brindan una alta calidad de audio cuando
escucha música o la radio en su teléfono o dispositivo de audio Nokia
compatible. Los altavoces tienen un conector de audio estéreo de 3,5 mm
(ubicado en su base). Con el adaptador AD-15 o AD-50 suministrado, los
altavoces se pueden conectar a un teléfono Nokia compatible que tenga
un conector Pop-PortTM o a un dispositivo compatible que tenga un
conector de audio de 2,5 mm.

Lea atentamente este manual del usuario antes de utilizar los altavoces.
Lea además el manual del usuario de su teléfono, en el cual encontrará
información importante sobre seguridad y mantenimiento, o el manual
del usuario de su dispositivo de audio compatible. Mantenga todos los
accesorios fuera del alcance de los niños.

9200267/1

Cargadores

ESPAÑOL

Verifique el número de modelo de cualquier cargador antes de usarlo con
este dispositivo. El dispositivo debe ser utilizado usando como fuente un
cargador AC-4.

Advertencia: Use sólo cargadores aprobados por Nokia para
este dispositivo particular. El uso de cualquier otro tipo de
cargador o batería podría anular la validez de la garantía
aplicable y podría resultar peligroso.

Cuando desconecte el cable de alimentación de cualquier accesorio,
sujételo y tírelo del enchufe, no del cable.

Configurar los altavoces para su uso

ESPAÑOL

Los altavoces pueden utilizar como fuente de energía tres baterías AA o
el cargador AC-4 suministrado. Tenga en cuenta que el cargador AC-4
no carga las baterías. Cuando use baterías, se recomienda que éstas sean
alcalinas.

Para usar los altavoces con baterías e instalarlas, abra la cubierta de las
baterías que está en la parte posterior de los altavoces al presionar los dos
seguros, coloque las baterías como se indica en el compartimiento de las
baterías y cierre la cubierta al presionarla hasta que encaje en su lugar.
Cuando no utilice los altavoces durante períodos prolongados, retire las
baterías para evitar daños ocasionados por pérdidas en las baterías.

Para usar los altavoces con el cargador AC-4, conecte el cargador a un
tomacorriente de pared y enchufe el cable del cargador al conector
ubicado en la parte posterior de los altavoces.
