Nokia HS HS 4W User Manual

User Guide for the Wireless Boom Headset (HS-4W)

HS-4W_EN_1st_tab.fm Page 1 Monday, August 15, 2005 11:47 AM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product HS-4W is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/.

HS-4W_EN_1st_tab.fm Page 2 Monday, August 15, 2005 11:47 AM

Contents

English English

Contents

Introduction.............................. 4

Bluetooth wireless technology.......... 4

Bluetooth passcode............................... 5

Call functions........................................ 15

Answering and ending a call ........ 16

Automatic answer............................ 16

Rejecting a call ................................. 16

HS-4W_EN_1st_tab.fm Page 3 Monday, August 15, 2005 11:47 AM

Introduction

The Wireless Boom Headset HS-4W can be connected to a compatible phone that supports Bluetooth technology. This allows you freedom to make and receive calls while on the move or in the office.

HS-4W_EN_1st_tab.fm Page 4 Monday, August 15, 2005 11:47 AM

Introduction

English

metres of each other. Connections can be subject to interference from obstructions, such as walls, or other electronic devices.

The Wireless Boom Headset HS-4W is compliant with and adopts the Bluetooth Specification 1.1. However, interoperability between the Wireless Boom Headset HS-4W and other Bluetooth-enabled products is not guaranteed because it depends on compatibility. For more information on the compatibility between

HS-4W_EN_1st_tab.fm Page 5 Monday, August 15, 2005 11:47 AM

Getting started

1. Getting started

Note: The use of wireless devices may be restricted in some situations.

Observe any restrictions and obey all signs and instructions concerning use of wireless devices.

HS-4W_EN_1st_tab.fm Page 6 Monday, August 15, 2005 11:47 AM

Getting started

English

The headset contains the following parts, as shown in Figure 1.

1 - Power key: Switches the headset on and off, or mutes the ongoing call.

2 - Speaker: Relays the caller’s voice.

3 - Indicator light: Displays the current status of the headset. The indicator

light can be yellow, green or red. If the light is yellow, a Bluetooth connection is active. The green and red lights indicate the status of a call and charging.

HS-4W_EN_1st_tab.fm Page 7 Monday, August 15, 2005 11:47 AM

Getting started

■ Chargers and batteries

HS-4W_EN_1st_tab.fm Page 8 Monday, August 15, 2005 11:47 AM

Getting started

English

Warning! Use only batteries and chargers approved by Nokia for use with this particular enhancement. The use of any other types will invalidate any approval or warranty applying to the enhancement, and may be dangerous.

For availability of approved batteries and chargers, please check with your local dealer.

HS-4W_EN_1st_tab.fm Page 9 Monday, August 15, 2005 11:47 AM

Getting started

When the battery charge falls low

Fully charged batteries last up to 6 hours of talk-time and up to 160 hours of standby time. However, talk and standby times may vary when used with different handsets, other Bluetooth enabled-products, battery condition, usage settings, usage style and environments. (In standby mode the headset is switched on but no call is in progress.)

HS-4W_EN_1st_tab.fm Page 10 Monday, August 15, 2005 11:47 AM

Getting started

English

Once you have entered the passcode, the phone becomes the default phone for the headset, if the headset has not been previously paired with another phone. See also Using the headset with several paired phones on page 17.

The headset beeps once and an active Bluetooth connection is displayed by a blinking yellow indicator light. The headset should now appear in the phone menu where you can view the Bluetooth devices that are currently paired

HS-4W_EN_1st_tab.fm Page 11 Monday, August 15, 2005 11:47 AM

Getting started

Reconnecting the paired headset to the compatible phone

To reconnect the headset to the default phone or the last phone used, switch on the headset. Otherwise, make the connection in the phone’s Bluetooth menu as instructed in the user guide of the phone.

Note that switching on the headset creates the connection automatically only if you have set the phone to accept Bluetooth connection requests without your

HS-4W_EN_1st_tab.fm Page 12 Monday, August 15, 2005 11:47 AM

Getting started

English

• The pairing information list of the headset may be full. The headset can store the information of up to 8 phones at a time. If the list becomes full, reset the headset to the original settings. See Resetting the headset on page 18.

• If the headset does not automatically reconnect to the default or last used phone, press and hold the answer/end key.

HS-4W_EN_1st_tab.fm Page 13 Monday, August 15, 2005 11:47 AM

Using the headset

2. Using the headset

Note: The use of wireless devices may be restricted in some situations.

Observe any restrictions and obey all signs and instructions concerning use of wireless devices.

HS-4W_EN_1st_tab.fm Page 14 Monday, August 15, 2005 11:47 AM

Using the headset

English

Placing the headset over the ear

HS-4W_EN_1st_tab.fm Page 15 Monday, August 15, 2005 11:47 AM

Using the headset

Answering and ending a call

When you receive a call, you hear a ringing tone through the headset.

Press the answer/end key to answer the call or to end the currently active call.

You can also answer or end the call using the phone.

HS-4W_EN_1st_tab.fm Page 16 Monday, August 15, 2005 11:47 AM

Using the headset

English

Voice dialling

When no call is in progress, press and hold the answer/end key until you hear a tone that indicates that you can say the desired name ("voice tag"). Say the voice tag. The phone plays the voice tag and dials the related phone number.

You can also activate voice dialling with the phone. For details on voice dialling, see the phone’s user guide.

HS-4W_EN_1st_tab.fm Page 17 Monday, August 15, 2005 11:47 AM

Using the headset

The phone that was first paired with the headset is called the "default phone". The phone that was last used with the headset is called the "last used phone".

If the headset is switched on within 10 metres of several paired phones, the headset will try to connect to the "default phone" within a few seconds.

If the headset cannot connect to the "default phone" (for example, it is switched off or its user rejects the connection), the headset tries to connect to the "last used

HS-4W_EN_1st_tab.fm Page 18 Monday, August 15, 2005 11:47 AM

Battery information

English

3. Battery information

Your headset is powered by a rechargeable battery. Take good care of the battery and follow the guidelines below.

HS-4W_EN_1st_tab.fm Page 19 Monday, August 15, 2005 11:47 AM

Battery information

Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object (coin, clip or pen) causes direct connection of the + and - terminals of the battery (metal strips on the battery), for example, when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery or the connecting object.

Leaving the battery in hot or cold places, such as in a closed car in summer or

HS-4W_EN_1st_tab.fm Page 20 Monday, August 15, 2005 11:47 AM

Care and maintenance

English

Care and maintenance

Your headset is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfil any warranty obligations and to enjoy this product for many years.

HS-4W_EN_1st_tab.fm Page 21 Monday, August 15, 2005 11:47 AM

Care and maintenance

• Do not paint the headset. Paint can clog the moving parts and prevent proper operation. If the headset is not working properly, take it to your nearest qualified service facility. The

personnel there will assist you and, if necessary, arrange for service.

HS-4W_EN_1st_tab.fm Page 22 Monday, August 15, 2005 11:47 AM
