Nokia C2-00 User Manual

Nokia C2-00 User Guide

Issue 1.0

2Contents

Contents

Safety 4

Your device in brief 5

Your dual SIM device 5
Keys and parts 5

Get started 6

Insert a SIM card and battery 6
Insert a second SIM card 7
Insert a memory card 9
Charge the battery 9
Switch the device on or off 10
GSM antenna 11
Connect a headset 11
Attach a strap 12

Basic use 12

Support 12
Access codes 12
Set which SIM card to use 13
Lock the keys 14
Copy contacts or pictures from your old
device 14
Use your device without a SIM card 15

Calls 15

Make a call 15
View your missed calls 15
Call the last dialled number 16
Divert calls to your voice mailbox or
another phone number 16

Contacts 16

Save a name and phone number 16
Use speed dial 17
Send your contact information 17

Write text 18

Switch between text input modes 18

Write using traditional text input 18
Use predictive text input 19

Messaging 19

Send a message 19
Save an attachment 20
Retrieve a multimedia message 20
Listen to voice messages 21
Send an audio message 21

Connectivity 21

Bluetooth 21
USB data cable 23

Clock 24

Change the time and date 24
Alarm clock 24

Pictures and videos 25

Take a picture 25
Record a video 25
Send a picture or video 25
Organise files 26

Music and audio 26

Media player 26
FM radio 27

Web 29

About the web browser 29
Browse the web 29
Clear browsing history 30

Device management 30

Update device software using your
device 30
Update device software using your PC 31
Restore original settings 32
Back up your pictures and other
content to a memory card 32

Nokia original accessories 32

Practical rules about accessories 32
Battery 33

Protect the environment 33

Save energy 33
Recycle 33

Product and safety information 34

Contents 3

4Safety

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect
performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

BATTERIES, CHARGERS AND OTHER ACCESSORIES

Use only batteries, chargers, and other accessories approved by Nokia for use
with this device. Do not connect incompatible products.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your
ear when the loudspeaker is in use.

Your device in brief 5

Your device in brief

Your dual SIM device

You can insert two SIM cards.

Some benefits of a dual SIM device

• You can make savings when you use services from different service providers.

• Use one phone number for personal calls and another for work, but carry only one

device.

• Avoid network coverage variation between service providers.

Both SIM cards are available at the same time when the device is not being used, but
while one SIM card is active, for example, making a call, sending or receiving a message,
or transferring data, the other is unavailable.

If there is no SIM card in the internal SIM card holder, demo mode is activated in your
device.

Some features and operator services are only available when using the SIM card in the
internal SIM card holder.

A GPRS connection cannot be open in the background. If an application is using a GPRS
connection, and you return to the home screen or switch to another application, menu,
or other view, the connection is automatically closed.

Keys and parts

1 Headset connector/Nokia AV connector (3.5 mm)
2 Earpiece
3 Display
4 Selection keys
5 Navi™ key (scroll key)

6Get started

6 Call key
7 End/Power key
8 Keypad

9 Charger connector
10 Micro-USB connector
11 SIM card slot (SIM 2)
12 Loudspeaker
13 Camera lens
14 Microphone

Get started

Insert a SIM card and battery

This device is intended for use with a BL-5C battery. Always use original Nokia batteries.

If you only have one SIM card, insert the card into the internal SIM card holder.

1 Place your finger in the recess at the bottom of the device, and carefully lift and

remove the back cover (1).

2 If the battery is inserted, lift it out (2).

3 Open the SIM card holder (3), and insert or remove the SIM card (4 or 5). Make sure

the contact area of the card is facing down.

Get started 7

4 Line up the contacts of the battery and the battery compartment, and insert the

battery (6). To replace the back cover, direct the top locking catches toward their
slots (7), and press down until the cover locks into place (8).

Insert a second SIM card

Have a second SIM card, but want to keep using your main SIM card? You can insert or
remove a second SIM card without switching the device off.

1 Open the cover of the external SIM card slot (1, 2), marked with

.

8Get started

2 Insert the SIM card (3). Make sure the contact area of the card is facing down. Push

the card in, until it locks into place. Close the cover (4).

Remove the second SIM card

Get started 9

Insert a memory card

Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on the
card.

Your device supports memory cards with a capacity of up to 32 GB.

1 Remove the back cover.
2 Make sure the contact area of the card is facing down. Push the card in, until it locks

into place.

3 Replace the back cover.

Remove the memory card

Important: Do not remove the memory card when an application is using it.

Doing so may damage the memory card and the device, and corrupt data stored on the
card.

You can remove or replace the memory card without switching the device off.

1 Remove the back cover.
2 Push the card in, until it is released, and pull the card out.
3 Replace the back cover.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it
before you can switch on your device for the first time. If the device indicates a low
charge, do the following:

10 Get started

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging.

If the battery is completely discharged, it may take several minutes before the charging
indicator appears on the display or before any calls can be made.

If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.

Switch the device on or off

Press and hold the power key

.

You may be prompted to get the configuration settings from your service provider
(network service). For more information, contact your service provider.

Get started 11

GSM antenna

The figure shows the GSM antenna area marked in grey.

Avoid touching the antenna area unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the communication quality and may cause a
higher power level during operation and may reduce the battery life.

Connect a headset

Do not connect products that create an output signal as this may cause damage to the
device. Do not connect any voltage source to the Nokia AV connector. If you connect an
external device or headset, other than those approved by Nokia for use with this device,
to the Nokia AV connector, pay special attention to volume levels.

12 Basic use

Attach a strap

Straps may be available separately.

Basic use

Support

When you want to learn more about how to use your product or you are unsure how
your device should function, go to www.nokia.com/support, or using a mobile device,
nokia.mobi/support.

If this does not resolve your issue, do one of the following:

• Reboot your device. Switch off the device, and remove the battery. After about a
minute, replace the battery, and switch on the device.

• Restore the original factory settings

• Update your device software

If your issue remains unsolved, contact Nokia for repair options. Go to www.nokia­asia.com/repair. Before sending your device for repair, always back up your device data.

Access codes

Select Menu > Settings > Security > Access codes.

PIN or PIN2 code These protect your SIM card against unauthorised use or are

required to access some features.
