Nokia 8270 Service Manual 4 nsd5parts

Programmes After Market Services

NSD-5 Series Transceivers

4. Parts List

Issue 1 05/02 Nokia Corporation

NSD-5

4. Parts List PAMS Technical Documentation

Page 2 Nokia Corporation Issue 1 05/02

NSD-5

PAMS Technical Documentation 4. Parts List

Contents

Page No

Exploded View NSD-5 .................................................................................................. 5

Parts List ........................................................................................................................ 5

NSD-5FX — EDMS Issue 6.0 Code: 0202013 ...........................................................5

Issue 1 05/02 Nokia Corporation Page 3

NSD-5

4. Parts List PAMS Technical Documentation

Page 4 Nokia Corporation Issue 1 05/02

NSD-5

PAMS Technical Documentation 4. Parts List

Exploded View NSD-5

Parts List

NSD-5FX — EDMS Issue 6.0 Code: 0202013

ITEM CODE SIDE X Y DESCRIPTION VALUE TYPE

R100 1430812 Top P 3 chip resistor 0W06 220K J 0402

R101 1430778 Top Q 3 chip resistor 0W06 10K J 0402

R120 1430726 Top P 3 chip resistor 0W06 100R J 0402

R122 1620027 Top O 3 res network 0W06 2x47R J 0404

R123 1620027 Top O 3 res network 0W06 2x47R J 0404

R124 1430796 Top P 3 chip resistor 0W06 47K J 0402

R125 1430770 Top O 3 chip resistor 0W06 4K7 J 0402

R126 1430812 Top P 3 chip resistor 0W06 220K J 0402

R131 1430726 Top O 3 chip resistor 0W06 100R J 0402

R133 1430700 Top O 7 chip resistor 0W06 10R J 0402

R134 1430778 Top O 7 chip resistor 0W06 10K J 0402

R135 1430762 Top N 7 chip resistor 0W06 2K2 J 0402

Issue 1 05/02 Nokia Corporation Page 5

NSD-5

4. Parts List PAMS Technical Documentation

ITEM CODE SIDE X Y DESCRIPTION VALUE TYPE

R136 1430762 Top O 7 chip resistor 0W06 2K2 J 0402

R137 1430762 Top O 8 chip resistor 0W06 2K2 J 0402

R140 1430786 Top O 7 chip resistor 0W06 18K J 0402

R141 1430796 Top O 7 chip resistor 0W06 47K J 0402

R142 1430778 Top Q 3 chip resistor 0W06 10K J 0402

R143 1430778 Top Q 3 chip resistor 0W06 10K J 0402

R144 1430115 Top K 8 chip resistor 0W06 2K2 F 200 ppm 0402

R145 1430115 Top K 8 chip resistor 0W06 2K2 F 200 ppm 0402

R146 1430754 Top O 3 chip resistor 0W06 1K0 J 0402

R162 1430778 Top O 2 chip resistor 0W06 10K J 0402

R175 1430690 Top R 6 chip jumper 0R0 0402

R200 1430764 Bottom N 5 chip resistor 0W06 3K3 J 0402

R201 1430804 Bottom O 4 chip resistor 0W06 100K J 0402

R202 1430788 Bottom O 3 chip resistor 0W06 22K J 0402

R203 1430796 Bottom O 3 chip resistor 0W06 47K J 0402

R205 1430778 Top N 5 chip resistor 0W06 10K J 0402

R241 1430137 Bottom Q 4 chip resistor 0W06 1K0 F 200 ppm 0402

R242 1430871 Bottom Q 4 chip resistor 0W06 82K F 0402

R243 1430215 Bottom Q 4 chip resistor -W06 68K F 200 ppm 0402

R244 1430718 Bottom Q 7 chip resistor 0W06 47R J 0402

R245 1430796 Bottom S 6 chip resistor 0W06 47K J 0402

R250 1430726 Bottom Q 6 chip resistor 0W06 100R J 0402

R251 1430718 Bottom Q 6 chip resistor 0W06 47R J 0402

R260 1430744 Bottom O 6 chip resistor 0W06 470R J 0402

R261 1430744 Bottom Q 6 chip resistor 0W06 470R J 0402

R270 1430744 Bottom O 6 chip resistor 0W06 470R J 0402

R271 1430744 Bottom Q 5 chip resistor 0W06 470R J 0402

R272 1430137 Bottom Q 5 chip resistor 0W06 1K0 F 200 ppm 0402

R273 1430121 Bottom Q 5 chip resistor 0W06 22K F 200 ppm 0402

R274 1430826 Bottom Q 5 chip resistor 0W06 680K J 0402

R275 1430804 Top O 3 chip resistor 0W06 100K J 0402

R280 1430804 Bottom P 8 chip resistor 0W06 100K J 0402

Page 6 Nokia Corporation Issue 1 05/02

NSD-5

PAMS Technical Documentation 4. Parts List

ITEM CODE SIDE X Y DESCRIPTION VALUE TYPE

R282 1430760 Bottom P 8 chip resistor 0W06 1K8 J 0402

R283 1430744 Bottom P 7 chip resistor 0W06 470R J 0402

R284 1430744 Bottom P 7 chip resistor 0W06 470R J 0402

R285 1430744 Bottom P 8 chip resistor 0W06 470R J 0402

R286 1430744 Bottom P 8 chip resistor 0W06 470R J 0402

R287 1430760 Bottom P 8 chip resistor 0W06 1K8 J 0402

R290 1430712 Bottom Q 8 chip resistor 0W06 27R J 0402

R291 1430712 Bottom Q 8 chip resistor 0W06 27R J 0402

R292 1430718 Bottom Q 7 chip resistor 0W06 47R J 0402

R301 1825005 Bottom Q 4 chip varistor VWM14V VC30V 0805

R302 1430700 Bottom R 3 chip resistor 0W06 10R J 0402

R310 1419003 Bottom P 3 chip resistor 0W5 0R22 J 200ppm 1210

R311 1430726 Bottom P 4 chip resistor 0W06 100R J 0402

R315 1430796 Top O 3 chip resistor 0W06 47K J 0402

R316 1430770 Top N 3 chip resistor 0W06 4K7 J 0402

R320 1430853 Top M 6 chip resistor 0W06 2M2 J 0402

R321 1430808 Top M 6 chip resistor 0W06 150K J 0402

R322 1430800 Top M 6 chip resistor 0W06 68K J 0402

R323 1430708 Top M 4 chip resistor 0W06 18R J 0402

R330 1430778 Top N 6 chip resistor 0W06 10K J 0402

R331 1430804 Top M 6 chip resistor 0W06 100K J 0402

R332 1430804 Top M 7 chip resistor 0W06 100K J 0402

R333 1430830 Top N 6 chip resistor 0W06 1M0 J 0402

R334 1430187 Top L 6 chip resistor 0W06 47K F 200 ppm 0402

R335 1430145 Top L 6 chip resistor 0W06 100K F 200ppm 0402

R336 1430796 Top L 6 chip resistor 0W06 47K J 0402

R337 1430830 Top L 6 chip resistor 0W06 1M0 J 0402

R338 1430778 Top L 6 chip resistor 0W06 10K J 0402

R339 1430778 Top L 6 chip resistor 0W06 10K J 0402

R410 1413829 Bottom S 8 chip resistor 0W1 10 R J 0805

R411 1413829 Bottom S 6 chip resistor 0W1 10 R J 0805

R420 1430784 Top M 7 chip resistor 0W06 15K J 0402

Issue 1 05/02 Nokia Corporation Page 7
