Nokia 6310 Service Manual 12 npe 4 schem
11 - SCHEMATICS
Table of Contents
PAMS Technical Documentation Schematics NPE-4
Page No
Schematics (Table of Contents) ............................................................................................................................................... 12-1
ac4a-14 (1) RF - BB ..................................................................................................................................................... 12-2
ac4a-14 (2) RF - RF 0.37 CPH (Connections between RF & BB modules) .................................................... 12-3
ac4a-14 (3) RF / HAGAR ............................................................................................................................................. 12-4
ac4a-14 (4) RF / POWER AMP................................................................................................................................... 12-5
ac4a-14 (5) SYS ac4a (DCT4 Common BB) ........................................................................................................... 12-6
ac4a-14 (6) SYS / AUDIO (Audio Interface) .......................................................................................................... 12-7
ac4a-14 (7) SYS / EMU (Test and Emulator interface) ....................................................................................... 12-8
ac4a-14 (8) SYS / EMU / JTAG (Testpoints for JTAG Emulator) ....................................................................... 12-9
ac4a-14 (9) SYS / EMU / OSTRICH (Testpoints based Ostrich interface) ...................................................... 12-10
ac4a-14 (10) SYS / IR (IR module based implementation) ............................................................................... 12-11
ac4a-14 (11) SYS / KEY (User interface) ............................................................................................................... 12-12
ac4a-14 (12) SYS / LPRF (Power RF interface) ..................................................................................................... 12-13
ac4a-14 (13) SYS / MEMORY AMD64 (Burst Read / Write) ............................................................................. 12-14
ac4a-14 (14) SYS / MEMORY / MEMFILTER (Discrete capacitors for memory without VFlash1)........... 12-15
ac4a-14 (15) SYS / POWER (Dual power management) .................................................................................... 12-16
ac4a-14 (16) DCT4 Power Supply (Light filtering) .............................................................................................. 12-17
ac4a-14 (17) SYS / Production Test Pattern ...................................................................................................... 12-18
ac4a-14 (18) SYS /RF - BB (GSM RF BB interface) ............................................................................................. 12-19
ac4a-14 (19) SYS / SIM (SIM reader) ...................................................................................................................... 12-20
ac4a-14 (20) .SYS / SYS CONN (System connector) ........................................................................................... 12-21
ac4a-14 (21) SYS / UPP (UPP 8M implementation) ............................................................................................ 12-22
ac4a-14 (22) .SYS / UPP / UPP FILTER (Discrete decoupling capacitors for UPP) ....................................... 12-23
Original ãNokia Corporation Page 11-1
PAMS Technical Documentation Schematics NPE-4
ac4a-14(1) RF - BB
Original ãNokia Corporation Page 11-2
PAMS Technical Documentation Schematics NPE-4
ac4a-14(2) RF - RF 0.37 CPH (Connections between RF & BB modules)
NC
POWER_AMP
NC
NC
NC
NC
NC
HAGAR
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
Components: 800 - 899 Components: 600 - 799
NC
NC
NC
NC
NC
NC
Original ãNokia Corporation Page 11-3
PAMS Technical Documentation Schematics NPE-4
ac4a-14(3) RF / HAGAR
VR7
VR2
Original ãNokia Corporation Page 11-4
PAMS Technical Documentation Schematics NPE-4
ac4a-14(4) RF / POWER AMP
Original ãNokia Corporation Page 11-5
PAMS Technical Documentation Schematics NPE-4
ac4a-14(5) SYS ac4a (DCT4 Common BB)
Original ãNokia Corporation Page 11-6
PAMS Technical Documentation Schematics NPE-4
ac4a-14(6) SYS / AUDIO (Audio Interface)
Original ãNokia Corporation Page 11-7
