Nokia Customer Care
6235/6235i/6236i (RM-60)
Mobile Terminals
General Information
Issue 1 04/2005 Company Confidential ©2005 Nokia Corporation
6235/6235i/6236i (RM-60)
General Information
Contents Page
Introduction ..................................................................................................................................................... 3
Mobile Terminal Variants ............................................................................................................................. 4
Sales Package................................................................................................................................................... 4
Supported Accessories................................................................................................................................... 4
Page 2 ©2005 Nokia Corporation Company Confidential Issue 1 04/2005
6235/6235i/6236i (RM-60)
Nokia Customer Care General Information
Introduction
The Nokia 6235/6235i/6236i mobile terminal offers a CDMA trimode (800/1900MHz plus
AMPS) engine and includes the following features:
• 128 x 128 display wiht 65,536 colors
• Internal hands-free speaker
• Integrated VGA camera and video
•FM radio
• Integrated browser
• QCELP and MP3 ringtones
• BREW 2.0
• Java 2.0
• Calendar, reminder, and to-do list
•5-way scroll
• 10MB of dynamic memory
Parameter Value and Unit
Dimensions:
Volume
Length
Width
Thickness
Weight
69 cc
105.5 mm
42.3 mm
18.0 mm
98 grams
Issue 1 04/2005 ©2005 Nokia Corporation Company Confidential Page 3
6235/6235i/6236i (RM-60)
General Information
Parameter Value and Unit
BL-6C (1070mAh)
Talk time
Standby time Up to 48 hours (analog)
Mobile Terminal Variants
Variant Description
6235 CDMA 800/1900MHz plus AMPS, without GPS
6235i CDMA 800/1900MHz plus AMPS, with GPS
6236i CDMA 800/1900MHz, with GPS (no AMPS)
Sales Package
Name Type
Mobile Terminal RM-60
Battery BL-6C (1070 mAh Li-Ion) BL-6C
Up to 2.00 hours (analog)
Up to 3.5 hours (digital)
Up to 288 hours (digital)
Travel Charger ACP-12
Supported Accessories
Type Name
AC-1 Retractable Charger
ACP-12 Travel Charger
ACP-7 Standard Travel Charger
AD-5B Wireless Audio Adapter (headset profile only - no car kit)
BHF-3 Headrest Handsfree
BL-6C 1070 Lion Battery
CK-7W Advanced Car Kit (no Bluetooth)
DCV-14 Deskstand
DKU-2 Data Cable
HDB-4 Boom Headset
HDS-3 FM Stereo Headset
HDW-3 Wireless Headset
HF-2 Activity Handsfree
Page 4 ©2005 Nokia Corporation Company Confidential Issue 1 04/2005
6235/6235i/6236i (RM-60)
Nokia Customer Care General Information
Type Name
HF-3 Easey-to-Use Handsfree
HS-11W Basic Wireless Headset
HS-3 Fashion Stereo Headset
HS-4W Wireless Boom Headset
HS-5 Headset
LCH-12 Mobile Charger
LPS-4 Loopset
LS-2 Fitness Monitor
LS-3 Medallion Square
LS-4 Medallion Moon
LS-5 Medallion Snake
LS-6 Medallion Pocket
MBC-155 Mobile Holder
PD-1 Image Album
Issue 1 04/2005 ©2005 Nokia Corporation Company Confidential Page 5
6235/6235i/6236i (RM-60)
General Information Nokia Customer Care
This page intentionally left blank.
Page 6 ©2005 Nokia Corporation Company Confidential Issue 1 04/2005
