SERVICE MANUAL

Level 1&2

N5700 RM-230 / RM-302

Service Manual Level 1&2

RM-230

RM-302

Transceiver characteristics:

Band:

EGSM: Quad-band 850/900/1800/1900MHz

WCDMA: 2100MHz (RM-230 only!)

Display:

LCD: 5.588cm QVGA (2.2”) (240x320 pixel); 16M colors

Camera:

Camera: 2.0 Megapixel SMIA95, 4x digital zoom

Operating System:

Series 60

Connections:

Wireless: Bluetooth, IRDA

Connector: Mini USB Connector; AV Connector

Memory:

MicroSD™ (max 4GB)

Page (53)

Transceiver with BP-5M Li-Ion battery pack

Talk time Standby Note

up to 3.4h up to 11days

CONFIDENTIAL

Depends on network

parameters

ISSUE 2

N5700 RM-230 / RM-302

Service Manual Level 1&2

CHANGE HISTORY1.

Status Version No. Date Comments

Draft 0.1 13.Mrz.2007 Initial draft

Approved 1.0 30.Mrz.2007 Approval

Approved 2.0 30.May.2007 RM-302 added

The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential. Please note that NOKIA provides also other guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and comply with the given instructions.

While every endeavor has been made to ensure the accuracy of this document, some errors may exist. If you find any errors or if you have further suggestions, please notify NOKIA using the address below:

CMO Operation & Logistics Training and Vendor Development Multimedia Creation & Support

mailto:Service.Manual@nokia.com

Please keep in mind also that this documentation is continuously being updated and modified, so watch always out for the newest version.

Copyright2.

Copyright © 2007 Nokia. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited. Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners. Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused. The contents of this document are provided “as is”. Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability

and tness for a particular purpose, are made in relation to the accuracy, reliability or contents of this

document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice. The availability of particular products may vary by region. IMPORTANT

This document is intended for use by qualied service personnel only.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

WARNINGS AND CAUTIONS 3.

Warnings and Cautions

Please refer to the phone’s user guide for instructions relating to operation, care and maintenance including important safety information. Note also the following:

Warnings:

CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED WITH ELECTRONIC ENGINE MANAGEMENT SYSTEMS

1. AND ANTI–SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY. THE HANDPORTABLE TELEPHONE MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN POTENTIALLY EXPLOSIVE

2. ATMOSPHERES, EG PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC. OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES, MAY INTERFERE WITH

3. THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY ALSO BE SUBJECT TO INTERFERENCE.

Cautions:

1. Servicing and alignment must be undertaken by qualified personnel only.

2. Ensure all work is carried out at an anti–static workstation and that an anti–static wrist strap is worn.

3. Use only approved components as specified in the parts list.

4. Ensure all components, modules screws and insulators are correctly re–fitted after servicing and alignment.

5. Ensure all cables and wires are repositioned correctly.

ESD protECtioN

Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing the phone. Any product of which the covers are removed must be handled with ESD protection. The SIM card can be replaced without ESD protection if the product is otherwise ready for use. To replace the covers ESD protection must be applied. All electronic parts of the product are susceptible to ESD. Resistors, too, can be damaged by static electricity discharge. All ESD sensitive parts must be packed in metallized protective bags during shipping and handling outside any ESD Protected Area (EPA). Every repair action involving opening the product or handling the product components must be done under ESD protection. ESD protected spare part packages MUST NOT be opened/closed out of an ESD Protected Area. For more information and local requirements about ESD protection and ESD Protected Area, contact your local Nokia After Market Services representative.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

CArE AND MAiNtENANCE5.

This product is of superior design and craftsmanship and should be treated with care. The suggestions below

will help you to full any warranty obligations and to enjoy this product for many years.

• Keep the phone and all its parts and accessories out of the reach of small children.

• Keep the phone dry. Precipitation, humidity and all types of liquids or moisture can contain minerals that will corrode electronic circuits.

• Do not use or store the phone in dusty, dirty areas. Its moving parts can be damaged.

• Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the phone in cold areas. When it warms up (to its normal temperature), moisture can form inside, which may damage electronic circuit boards.

• Do not drop, knock or shake the phone. Rough handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone.

• Do not paint the phone. Paint can clog the moving parts and prevent proper operation.

• Use only the supplied or an approved replacement antenna. Unauthorised antennas, modications or

attachments could damage the phone and may violate regulations governing radio devices. All of the above suggestions apply equally to the product, battery, charger or any accessory.

BAttEry iNforMAtioN

Note: A new battery’s full performance is achieved only after two or three complete charge and discharge cycles! The battery can be charged and discharged hundreds of times but it will eventually wear out. When the operating time (talk-time and standby time) is noticeably shorter than normal, it is time to buy a new battery. Use only batteries approved by the phone manufacturer and recharge the battery only with the chargers approved by the manufacturer. Unplug the charger when not in use. Do not leave the battery connected to a charger for longer than a week, since overcharging may shorten its lifetime. If left unused a fully charged battery will discharge itself over time Temperature extremes can affect the ability of your battery to charge. For good operation times with Ni-Cd/NiMh batteries, discharge the battery from time to time by leaving the product switched on until it turns itself off (or by using the battery discharge facility of any approved accessory available for the product). Do not attempt to discharge the battery by any other means Use the battery only for its intended purpose. Never use any charger or battery which is damaged.

Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object (coin, clip or

pen) causes direct connection of the + and - terminals of the battery (metal strips on the battery) for example when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery

or the connecting object.

Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions, will reduce the capacity and lifetime of the battery. Always try to keep the battery between 15°C and 25°C (59°F and 77°F). A phone with a hot or cold battery may temporarily not work, even when the battery is fully charged. Batteries’ performance is particularly limited in temperatures well below freezing.

Do not dispose batteries in a re! Dispose of batteries according to local regulations (e.g. recycling).

Do not dispose as household waste.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

TABLE OF CONTENTS

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

21.

22.

23.

24.

25.

26.

27.

28.

29.

30.

31.

32.

33.

34.

35.

36.

CHANGE HISTORY 2 COPYRIGHT WARNINGS AND CAUTIONS ESD PROTECTION CARE AND MAINTENANCE BATTERY INFORMATION EXPLODED VIEW SPARE PARTS OVERVIEW GENERAL RECYCLING RECOMMENDATION LEVEL 2 SOLDER COMPONENTS SERVICE DEVICES 1 SW-UPDATE 1 UPPER BLOCK DISASSEMBLY 1 UPPER BLOCK ASSEMBLY HINTS 1 LOWER BLOCK DISASSEMBLY 2 LOWER BLOCK ASSEMBLY HINTS 3 LEGEND FOR QUICK TROUBLE SHOOTER 3 QUICK TROUBLE SHOOTER - POWER ON 3 QUICK TROUBLE SHOOTER - CHARGING 3 QUICK TROUBLE SHOOTER - NO SERVICE 3 QUICK TROUBLE SHOOTER - EARPIECE 3 QUICK TROUBLE SHOOTER - IHF SPEAKER (UPPER) 3 QUICK TROUBLE SHOOTER - IHF SPEAKER (LOWER) 4 QUICK TROUBLE SHOOTER - DISPLAY 4 QUICK TROUBLE SHOOTER - MICROPHONE 4 QUICK TROUBLE SHOOTER - KEYMAT NUMERIC 4 QUICK TROUBLE SHOOTER - KEYMAT MENU 4 QUICK TROUBLE SHOOTER - KEYMAT MUSIC 4 QUICK TROUBLE SHOOTER - BACKLIGHT LEDS (NUMERIC) 4 QUICK TROUBLE SHOOTER - VOLUME KEYS 4 QUICK TROUBLE SHOOTER - MENU KEY 4 QUICK TROUBLE SHOOTER - CLEAR KEY 4 QUICK TROUBLE SHOOTER - FLASH LIGHT 5 QUICK TROUBLE SHOOTER - ROTATOR SENSOR 5 QUICK TROUBLE SHOOTER - AV CONNECTOR 5 QUICK TROUBLE SHOOTER - CAMERA 5

Page

2 3 3 4 4 6 7 8 9 0 1 2 9 5 0 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3

Page (53) ISSUE 2

CONFIDENTIAL

EXPLODED VIEW7.

See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL.

N5700 RM-230 / RM-302

Service Manual Level 1&2

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

SPARE PARTS OVERVIEW8.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

GENERAL RECYCLING RECOMMENDATION9.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

LEVEL 2 SOLDER COMPONENTS10.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

SERVICE DEVICES11.

FLS-5 incl. ACF-8, Driver and User

Guide

Dongle and flash device incorporated into one package, developed specifi-

cally for POS use.

DKE-2

Service Cable to connect the PC with

the mini USB connector.

ACF-8

Universal Power Supply is used to

power FLS-4S.

SS-45

Camera removal tool. One side is for disassembly, the other side for as-

sembly.

Travel Charger AC-4

Small and lightweight charger for

fast charging of your phone battery.

RJ-135

Soldering Jig

Internal Battery BP-5M

Inserted under the back cover, this Li-Ion battery provides power in a

lightweight package.

Page (53) ISSUE 2

Lead-free Solder Wire

Mandatory for lead-free products

(Level 2 only).

CONFIDENTIAL

0772040 NMP Standard Toolkit (V2)

For more informations refer to the Service Bulletin (SB-011) on NOKIA On-

line. Supplier or manufacturer contacts for tool re-order can be found in “Recom- mended service equipment” docu-

ment on NOKIA Online.

N5700 RM-230 / RM-302

Service Manual Level 1&2

SW-UPDATE12.

Flash Concept – (Point of Sales)

To use FLS-5 Flash Dongle you have to follow the user guide inside the sales package. Please check always for the latest version of flash software, which is available on

NOKIA Online.

Page (53) ISSUE 2

CONFIDENTIAL

N5700 RM-230 / RM-302

Service Manual Level 1&2

UPPER BLOCK DISASSEMBLY13.

1. Needed tools: A Torx driver, the bit holder, a Torx Plus size 5 bit, a torque driver, angled tweezers, the SS-93, a dental pick, metal tweezers, and the DC-plug.

3. Unlock and remove the BATTERY COVER. Remove the battery if inserted.

2. Cover all windows with a protective lm.

4. Use the SS-93 to unlock the TOP COVER. Always start on the shown side. Avoid damaging the ANTENNA.

5. Remove the TOP COVER.

Page (53) ISSUE 2

CONFIDENTIAL

6. Remove the LOGO PLATE ASSY.

N5700 RM-230 / RM-302

Service Manual Level 1&2

7. Pay attention to the light guide.

9. Remove the SIDE ASSY RIGHT.

8. Use the SS-93 to unlock the SIDE ASSY RIGHT by pushing the SIDE ASSY upwards at the same time.

10. Unlock the SIDE ASSY LEFT by pushing it as shown.

11. Remove the SIDE ASSY LEFT.

Page (53) ISSUE 2

CONFIDENTIAL

12. Lift the KEYMAT MENU a bit and remove it.

N5700 RM-230 / RM-302

Service Manual Level 1&2

13. Remove the JOYSTICK COVER.

15. ... release hooks also on both sides of the ANTENNA ASSY.

14. Gently unlock the ANTENNA ASSY hooks...

16. Remove the ANTENNA ASSY.

17. Now, open the unit.

Page (53) ISSUE 2

CONFIDENTIAL

18. Undo the screws in the order shown...

N5700 RM-230 / RM-302

Service Manual Level 1&2

19. ...and remove them.

21. Gently open the covers as shown. Do not separate the parts from each other yet.

20. remove the SIDE CONNECTOR TAPE and discard it.

22. Carefully open the HD FLEX connector.

23. Very gently, lift a bit the COAX CABLE connector with the dental pick...

Page (53) ISSUE 2

CONFIDENTIAL

24. ...and open it with angled tweezers. Now, the FRAME UPPER

ASSY with the SYSTEM MODULE can be separated from the C-COVER ASSY.

N5700 RM-230 / RM-302

Service Manual Level 1&2

25. Hold the parts as shown.

27. ...and then open LCD connector, avoiding touching the

surrounding components. Separate the parts from each other.

26. First open the FLEX UPPER connector...

28. The Frame LCD assy is secured with four clips to the FRAME UPPER ASSY.

29. Release the clips...

Page (53) ISSUE 2

CONFIDENTIAL

30. ...and remove the parts from the FRAME UPPER ASSY as

shown.
