Nokia 120 C User Manual
Introduction Guide
Mediamaster 120 C
Contents
Remote control 4
Connecting the Mediamaster 5
Front and Rear panel 5
Connecting the Mediamaster 5
Preparing the remote control 5
Common Connections 6
Connecting to the TV with SCART 6
Connecting to the TV without SCART 6
Connecting a Video recorder with SCART 7
Connecting a Video recorder without SCART 7
Connecting the Mediamaster
& First-time installation 8
About Smart card 8
Connecting a Hi-fi system 8
First-time installation general information 8
This Introduction Guide describes how to connect the Mediamaster and how to perform the first-time
installation. It also describes the main features of the product.
A more detailed User Guide in the English language is available from the Nokia.com support pages
on the Internet.
First-time installation 9
Switching on for the first time and start 9
Watching TV & listening to the radio 10
Navigating with the Navi Bars 10
The Menus in the Settings folder 10
Edit lists folder 11
Sorting channels 13
Programme Guide: EPG 13
Listen to radio channels 13
Nokia Mediamaster software
end-user license 14
Technical specifications 15
Read this before using the Mediamaster
• Do not use any power supply other than the original unit delivered with the
Mediamaster.
• Allow 10 cm of space around the Mediamaster for sufficient ventilation.
• Do not cover the Mediamaster's ventilation openings with items such as newspapers, tablecloths, curtains, etc.
• Do not place the Mediamaster on top of a heat-emitting unit.
• Do not place naked flame sources, such as lit candles, on the Mediamaster.
• Use a soft cloth and a mild solution of washing-up liquid to clean the casing.
• Do not expose the Mediamaster to dripping or splashing liquids.
• Do not place any objects filled with liquids, such as vases, on the Mediamaster.
• To give your Mediamaster extra protection, e.g. during a thunderstorm, we
recommend that you connect it via an external surge protection device.
• Do not connect or modify cables when the Mediamaster is plugged in.
• Do not remove the cover.
• Do not allow the unit to be exposed to hot, cold or humid conditions.
• Service should only be carried out at a Nokia Authorised Service Centre.
• Please note that the only way to isolate the Mediamaster completely from
the mains supply is to unplug the power supply!
GB 3
Remote control
This section describes how to operate the Mediamaster using the buttons on the remote control.
mute Press once to turn the sound off/on (mute/unmute).
ok To confirm a selection.
cursor up Move up in the menus and change to the next channel in
cursor down Move down in the menus and change to the previous
cursor left Move left/change settings in menus.
cursor right Move right/change settings in menus.
opt To display temporary settings (options) while watching TV.
info Three different functions:
back To go back one level at a time within menus.
Press and hold for a few seconds to switch the
Mediamaster into standby mode. In addition,
press this button to switch the Mediamaster on.
To open Navi Bars
viewing mode.
channel in viewing mode.
Decrease the volume level in viewing mode.
Increase the volume level in viewing mode.
Activate Channel Filtering & Sorting in Navi Bars mode.
Pressing once will show current programme name.
Pressing twice will show information about the current
and next programme.
Pressing three times will give the 7-day programme guide
(EPG).
To close the Navi Bars.
Toggle between the present and previous channel.
0 - 9 To change the channel and to select individual menu
0 To toggle between the Mediamaster reception or any
navi To open and close the Navi Bars.
txt Press to enter Teletext (if available).
tv/radio Toggle between TV and radio mode.
GB 4
options.
NOTE: If 0 is entered as the first digit, the TV Release
functionality is activated (see below).
other reception to your TV (depending of TV model.)
Connecting the Mediamaster
Front and Rear panel
antenna cable
for connection of the antenna cable
to the cable TV antenna socket
Reset button
Slot
for a Conax smart card
TV SCART socket * *
for connection to the TV SCART
DC in
for connecting the cable
from the external power
supply
TV/VCR
For connecting to the
RF socket on the TV,
or to a Video
recorder
Digital audio
Digital audio output
(TOS-link optical
connection)
A constant green light indicates that the Mediamaster is
switched ON.
A constant red light indicates standby mode.
The light flashes red when commands from the remote control
are received.
The light flashes green during software updates.
Connecting the Mediamaster
The box for your Mediamaster should contain the following items:
• the Mediamaster
• a remote control with 2 AAA batteries
• a SCART cable (fully connected; 1.0 m)
• an Introduction Guide
• a separate power supply
• an RF cable
Preparing the remote control
Power supply
SCART
cable
• Remove the cover from the battery compartment at the bottom
of the remote control.
• Insert the 2 AAA (1.5 V) batteries as shown in the diagram,
taking care to observe the + and - markings indicated inside.
• Replace the cover.
* * The TV SCART Socket
When you connect other devices to this socket, always use a fully
connected SCART cable like the one supplied. There are SCART
cables available that do not have all the pins connected,
which could reduce picture quality if you were to use them.
GB 5
