Page 1

QUICK REFERENCE GUIDE

2014 ROGUE

Page 2

VEHICLE INFORMATION DISPLAY*

HEADLIGHT AND TURN SIGNAL

CONTROL

LOW TIRE PRESSURE WARNING LIGHT

INSTRUMENT BRIGHTNESS

CONTROL SWITCH*

TWIN TRI P ODOMETER RESET BUTTON

*See your Owner’s Manual for information.

111912

1413

BEHIND STEERING

WHEEL

1817

WINDSHIELD WIPER / WASHER SWITCH

STEERING WHEEL SWITCHES

FOR AUDIO CONTROL* / NAVIGATION/ VEHICLE INFORMATION DISPLAY

CRUISE CONTROL/ BLUETOOTH®

SWITCHES

VEHICLE DYNAMIC CONTROL (VDC)

OFF SWITCH*

SPORT MODE SWITCH

POWER LIFTGATE SWITCH

POWER LIFTGATE MAIN SWITCH

SAFETY SHIELD BUTTON

AWD LOCK SWITCH*

HILL DESCENT CONTROL SWITCH

STEERING WHEEL TILT ADJUSTMENT

FUEL-FILLER DOOR RELEASE

HOOD RELEASE*

AUDIO AND NAVIGATION SYSTEM

AUTOMATIC CLIMATE CONTROLS

FRONT PASSENGER AIR BAG

STATUS LIGHT*

USB/AUX JACK/POWE R OUTLET

Page 3

NEW SYSTEM FEATURES

Around View

Monitor with Moving Object Detection (MOD)

(if so equipped) ................................................2

Sport Mode ...................................................3

Blind Spot Warning (BSW) System (if so equipped) .....................3

Lane Departure Warning (LDW) System (if so equipped) .................4

Forward Collision Warning (FCW) System (if so equipped)................4

Hill Start Assist (HSA) System ........................................4

Hill Descent Control (HDC) System (if so equipped) .....................5

All-Wheel Drive (AWD) Indicator Lights.................................5

ESSENTIAL INFORMATION

Tire Pressure Monitoring System (TPMS) with Easy Fill Tire Alert .......6

Loose Fuel Cap ................................................7

Fuel-ﬁller Door .................................................7

Towing Your Vehicle.............................................7

Outside Temperature Display .....................................8

Divide-N-Hide

Floor (if so equipped)..............................8

Clock Set/Adjustment...........................................9

FIRST DRIVE FEATURES

NISSAN Intelligent Key

System (if so equipped) ...................10

Power Liftgate (if so equipped) ....................................11

Front Seat Adjustments.........................................11

Row Seats ................................................12

Row Seats (if so equipped) ..................................12

Outside Mirror Control Switch ...................................12

Starting/Stopping the Engine....................................13

Headlight Control Switch .......................................13

Windshield Wiper and Washer Switch ............................14

Automatic Climate Controls (if so equipped) .......................15

FM/AM/SiriusXM

Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

USB (Universal Serial Bus) Connection Port/Aux Jack and iPod

Satellite Radio with CD Player (if so equipped).....16

Interface 17

Power Panoramic Moonroof (if so equipped) .......................18

Center Console Storage box ....................................18

Tilt and Telescopic Steering Wheel Adjustments ....................18

SYSTEM GUIDE

Vehicle Information Display......................................19

Bluetooth

System Operating Tips.......................................20

Bluetooth Bluetooth

Navigation System (if so equipped) ...............................23

HomeLink

Hands-free Phone System ............................20

System without Navigation (if so equipped)...............20

System with Navigation (if so equipped) .................21

Universal Transceiver (if so equipped).......................24

Please see your Owner’s Manual for important safety information and system operation limitations.

• A cellular telephone should not be used for any purpose while driving so full attention may be given to vehicle operation.

• Always wear your seat belt.

• Supplemental air bags do not replace proper seat belt usage.

• Children 12 and under should always ride in the rear seat properly secured in child restraints or seat belts according to their age and weight.

For more information, refer to the “Safety — Seats, seat belts and

supplemental restraint system (section 1)”, “Center display, heater, air conditioner, audio, phone and voice recognition systems (section

4)” and “Starting and driving (section 5)” of your Owner’s Manual.

• Do not drink and drive.

Additional information about your vehicle is also available in your

Owner’s Manual, Navigation System Owner’s Manual

and at www.nissanusa.com.

To view detailed

instructional videos, go to

www.nissanownersinfo.mobi/

2014/rogue

or snap this barcode with an appropriate barcode reader.

Page 4

NEW SYSTEM FEATURES

AROUND VIEW® MONITOR WITH MOVING OBJECT DETECTION MOD (if so equipped)

With the ignition switch in the ON position, the Around

View® Monitor is activated by pressing the CAMERA button 01, located on the control panel, or by moving the shift lever to the R (REVERSE) position. The monitor displays various views of the position of the vehicle.

When the shift lever is in the P (PARK), N (NEUTRAL) or D (DRIVE) position and the

CAMERA button 01 is pressed, the following views will display in order:

Start from any Control Panel screen

Press

Front view & front-side view

Press Press

Front view & bird’s-eye view

When the shift lever is in the R (REVERSE) position and the CAMERA button 01 is

pressed, the following views will display in order:

Rear view & bird’s-eye view

Press

Rear view & front-side view

The colored guide lines on the display screen indicate vehicle width and approximate distances

to objects with reference to the vehicle body line.

• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft (3 m).

For information regarding how to access additional viewing cycles, please see your

Owner’s Manual.

2 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 5

There are some areas where the system will not

detect objects.

• When in the front or the rear view display, an object below the bumper or on the ground may not be detected

• When in the bird’s-eye view, a tall object near the seam of the camera detecting areas

will not

appear in the monitor.

The distance between objects viewed on the

Around View® Monitor differs from the actual distance.

Objects in the bird’s-eye view will appear further than the

actual distance.

For more information, refer to the “Center display, heater, air conditioner, audio, phone and voice recognition systems

(section 4)” of your Owner’s Manual.

SPORT MODE

In the SPORT mode, the engine and transmission are

controlled to set the engine speed higher than in the D (DRIVE) position. This enhances throttle response for a sporty driving feeling.

The SPORT mode switch

To turn the SPORT mode on, push the SPORT mode switch. The SPORT mode indicator

is located on the left side of the instrument panel.

light in the instrument panel illuminates. To turn the SPORT mode off, push the SPORT mode switch again. The SPORT mode indicator light on the instrument panel will extinguish.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

BLIND SPOT WARNING BSW SYSTEM (if so equipped)

The BSW system helps alert the driver of other vehicles

in adjacent lanes when changing lanes.

The system will operate when the vehicle is driven at

speeds of approximately 20 mph (32 km/h) and above.

When the system detects a vehicle in the detection

zone, the blind spot indicator light

, located near the

outside mirrors, will illuminate. If the turn signal is then activated, the system chimes twice and the blind spot indicator light ﬂashes to alert the driver. The blind spot indicator light continues to ﬂash until the detected vehicle leaves the detection zone.

Push the warning systems switch

off, the indicator light

The indicator light will also be off if all of the warning systems are deactivated using the

on the switch is off.

to temporarily turn the system off. When the system is

settings menu.

For more information, refer to the “Instruments and controls (section 2)” and “Starting and driving (section 5)” of your Owner’s Manual.

3To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 6

NEW SYSTEM FEATURES

LANE DEPARTURE WARNING LDW SYSTEM (if so equipped)

The LDW system helps alert the driver when the

vehicle is traveling too close to either the left or the right side of a traveling lane.

The system will operate when the vehicle is driven

at speeds of approximately 45 mph (70 km/h) and above, and only when the lane markings are clearly visible on the road.

When the vehicle approaches either the left or the right of the traveling

lane, the LDW system will chime and the orange LDW light instrument panel will blink to alert the driver.

The LDW system can be turned on and off through the settings menu in the vehicle

information display. To temporarily turn off the system, push the warning systems switch

When the system is off, the indicator light

For more information, refer to the “Instruments and cont rols (section 2)” and “Starting and driv ing (section 5)” of your Owner’s Manual.

on the switch is off.

on the

FORWARD COLLISION WARNING (FCW)

SYSTEM (if so equipped)

The FCW system helps warn the driver with a help

alert light and chime when the vehicle is getting close to a vehicle ahead in the traveling lane.

The FCW system operates at speeds of approximately 10 mph (15 km/h) and above.

The FCW system can be turned on and off in the vehicle information display through the

Driving Aids menu 01.

For more information, refer to the “Starting and driving (se ction 5)” of your Owner’s Manual.

HILL START ASSIST (HSA) SYSTEM

The HSA system allows time for the driver to release the brake pedal and apply the accelerator when the vehicle is parked on a hill. The brakes are applied automatically for 2 seconds after the driver releases the brake pedal.

The Hill Start Assist will operate automatically under these conditions:

The shift lever is shifted into a forward or a reverse gear.

• The vehicle is stopped completely on a hill by applying the brake.

•

The Hill Start Assist will not operate when the shift lever is in the N (Neutral) or P (Park)

position or on a ﬂat and level road.

For more information, refer to the “Starting and driving (se ction 5)” of your Owner’s Manual.

4 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 7

HILL DESCENT CONTROL (HDC) SYSTEM (if so equipped)

The HDC system is designed to apply the brakes to help control the speed of the vehicle and reduce the workload

of the driver while descending steep hills. To activate the system:

The AWD Lock switch 01 must be on.

The Hill Descent Control system switch 02 must be ON. To deactivate the Hill Descent

Control system, push the switch 02 to the OFF position.

The shift lever must be in a forward or reverse gear.

The Hill Descent Control system operates at speeds of 15 mph (25 km/h) and below.

For more information, refer to the “Starting and driving (se ction 5)” of your Owner’s Manual.

ALL-WHEEL DRIVE (AWD) INDICATOR LIGHTS

With the ignition switch in the ON position, the AWD indicator light illuminates and

stays illuminated. The AWD indicator light staying illuminated is a normal condition and does not indicate a malfunction with the All-Wheel Drive system. Distribution of torque to the front and rear wheels changes automatically, depending on the road conditions encountered.

When AWD Lock is selected, both the AWD indicator light and the AWD Lock light

will illuminate.

For more information, refer to the “Instruments and cont rols (section 2)” and the “Starting and driving (section 5)” of your Owner’s Manual.

5To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 8

ESSENTIAL INFORMATION

TIRE PRESSURE MONITORING SYSTEM (TPMS) WITH EASY FILL TIRE ALERT

A Tire Pressure Low - Add Air warning message

will appear in the vehicle information display 01 and the low tire pressure warning light 02 will illuminate when one or more tires are low in pressure and air is needed.

• The tire pressures should be checked when the tires are cold. The tires are considered cold after the vehicle has been parked for 3 hours or more or driven less than 1 mi (1.6 km) at moderate speeds.

When adding air to an under-inﬂated tire, the TPMS with Easy Fill Tire Alert provides visual

and audible signals outside the vehicle to help you inﬂate the tires to the recommended COLD tire pressure.

To use the Easy Fill Tire Alert system:

1. Move the shift lever to the P (PARK) position and apply the parking brake.

2. Place the ignition switch in the ON position. Do not start the engine.

3. Add air to the under-inﬂated tire, and within a few seconds the hazard warning lights will

start ﬂashing.

4. When the designated tire pressure is reached, the horn will beep once and the hazard

warning ﬂashers will stop ﬂashing.

5. Repeat this procedure for any additional under-inﬂated tires.

After tire pressures are adjusted, drive the vehicle at speeds above 16 mph (25 km/h).

The Tire Pressure Low - Add Air warning message and low tire pressure warning light will extinguish.

In addition to the Tire Pressure Low - Add Air warning message you can view the

individual tire’s pressure in the vehicle information display as well as the recommended pressure, denoted by blue lettering, for each tire.

When the low tire pressure warning light ﬂashes for 1 minute and then remains on, the

TPMS is not functioning properly. Have the system checked by a NISSAN dealer.

Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and

the outside temperature. Low outside temperature can lower the temperature of the air inside the tire, which can cause a lower tire inﬂation pressure. This may cause the low tire pressure warning light to illuminate. If the warning light illuminates, check the tire pressure in your tires.

• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

The Tire and Loading Information label contains valuable information. Please refer to

“Technical and consumer information (section 9)”, in your Owner’s Manual for the location of the Tire and Loading Information label.

For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the

“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.

Tire Pressure Low - Add Air

6 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 9

LOOSE FUEL CAP

A Loose fuel cap warning message will appear in

the vehicle information display 01 when the fuel-ﬁller cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click

is heard.

The warning message will disappear when the

vehicle detects the fuel-ﬁller cap is properly tightened and the button, located on the steering wheel, is pressed.

If the cap is not properly tightened, the Malfunction Indicator Light may illuminate.

For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments

(section 3)” of your Owner’s Manual.

FUEL-FILLER DOOR

The fuel-ﬁller door is located on the passenger

side of the vehicle.

To open the fuel-ﬁller door, pull the release lever

, located on the instrument panel to the left of

the steering wheel.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

TOWING YOUR VEHICLE

ALLWHEEL DRIVE AWD VEHICLE if so equipped)

• An all-wheel drive vehicle must be towed with all wheels off the ground.

For proper towing and to avoid accidental damage to your vehicle, NISSAN recommends

that a service operator tow your vehicle after carefully reading the Owner’s Manual precautions.

For more information, refer to the “In case of emergency (section 6)” of your Owner’s Manual.

7To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 10

ESSENTIAL INFORMATION

OUTSIDE TEMPERATURE DISPLAY

When the ignition switch is in the ON position, the

outside air temperature will appear in the vehicle information display 01.

If the outside air temperature is below 25°F (-4°C),

the outside temperature display will blink for 20 seconds then remain on when the ignition is switched on.

If the outside air temperature is between 27°F and

37°F (-3°C and +3°C), the outside temperature display will blink continuously with the ignition switch in the ON position.

To stop the outside temperature display from blinking, stop the vehicle in a safe place and

move the shift lever to the (P) PARK position. Perform the following procedure:

1. Press the

2. Move the

ENTER to select.

3. Move the

4. Move the

5. To exit, press the

LOW OUTSIDE TEMPERATURE WARNING

The Low outside temperature warning message 02 will appear in the vehicle information

display 01 when the outside temperature drops below 37°F (+3°C) with the ignition switch in the ON position.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

button on the steering wheel until the Settings mode is displayed.

button on the steering wheel until it reaches the Alarm mode then press

button until it reaches the Outside temp mode then press ENTER to select. button until it reaches the Off mode then press ENTER to select.

button on the steering wheel again.

DIVIDE-N-HIDE® FLOOR (if so equipped)

Do not place more than 30 lbs (13.6 kg) on the

adjustable ﬂoor when it is in the upper position. Do not place more than 165 lbs (75 kg) on the adjustable ﬂoor when it is in the mid position.

There are multiple positions for the adjustable ﬂoor.

The upper position allows for additional storage below the adjustable ﬂoor 01.

To move the adjustable ﬂoor from the lower position to the upper position:

1. Use the handle to lift the adjustable ﬂoor.

2. Move the adjustable ﬂoor to the upper guide track

and ensure it is secure in place.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

8 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 11

CLOCK SET/ADJUSTMENT

To adjust the time and the appearance of the clock

on the display:

1. Press the

button

2. Touch the “Settings” key.

3. Touch the “System” key.

4. Touch the “Clock” key.

The following settings can be adjusted:

• Time Format: The clock can be set to 12 hours or 24 hours.

• Date Format: The date can be changed to one of 5 different formats.

• Clock Mode: From here the clock mode options are:

· Manual: Allows for the option “Set Clock Manually”. Touch this to begin setting the clock

manually using the “+” or “–“ to adjust the hours, minutes, day and month up or down.

· Time Zone: Touch the “Time Zone” key

to choose from the applicable time zone list, and/or touch “Daylight savings time” to switch between on and off.

· Auto: Automatically sets the clock to the vehicles

current location.

Press the BACK button 03 to return to the previous screen.

For more information please refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

9To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 12

FIRST DRIVE FEATURES

NISSAN INTELLIGENT KEY® SYSTEM (if so equipped)

The NISSAN Intelligent Key® System allows you to lock or unlock the vehicle, open your liftgate and start the engine. It is important to make sure the Intelligent Key is with you (that is, in your pocket or purse).

The operating range of the Intelligent Key is within

31.5 in (80 cm) from each request switch.

To lock the vehicle, push either door handle request

switch 01, push the liftgate opener switch 02 or press the button 03 on the key fob.

To unlock the vehicle, perform one of the

following procedures:

• Push either door handle request switch or the liftgate opener switch 02 once; the corresponding door will unlock. Push the request switch again within 5 seconds; all other doors will unlock, or

• Press the the driver’s side door. Press the other doors will unlock.

LIFTGATE RELEASE

To open the rear liftgate, press the

To close the rear liftgate, press the

The Intelligent Key can also be used to activate the panic alarm by pressing and holding the

button 06 for more than 1 second. Once activated, the panic alarm and headlights will

stay on for a period of time.

INTELLIGENT KEY BATTERY DISCHARGE

If the battery of the Intelligent Key is discharged, or environmental conditions interfere with

the Intelligent Key operation, start the engine according to the following procedure:

1. Move the shift lever to the P (PARK) position.

2. Firmly apply the foot brake.

3. Touch the ignition switch with the Intelligent Key and a chime will sound.

4. Within 10 seconds after the chime sounds, push the ignition switch while depressing the

brake pedal and the engine will start.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

button 04 on the key fob to unlock

once

button again; all

button 05 for longer than 1 second.

button 05 again for longer than 1 second.

10 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 13

POWER LIFTGATE (if so equipped)

When the liftgate is closed and locked, the liftgate will

open automatically by:

• Pushing the power liftgate switch 01 on the instrument panel.

• Pushing the liftgate opener switch 02. The liftgate must be unlocked, or you must have the Intelligent Key with you (in your pocket or purse).

• Pressing the

button 03 on the NISSAN

Intelligent Key® for more than 1 second.

The power liftgate operation can be turned on or

off by the power liftgate on/off switch 04 on the instrument panel.

• When the power liftgate on/off switch 04 is

pushed to the OFF position, power operation is not available using the power liftgate switch 05 on the liftgate or the liftgate opener switch 02.

LIFTGATE POSITION SETTING (if so equipped) The liftgate can be set to open to a speciﬁc height by performing the following:

1. Open the liftgate using the request switch or the Intelligent Key.

2. Pull the liftgate down to the desired position and hold the liftgate (the liftgate will have some

resistance when being manually adjusted).

3. While holding the liftgate in position, press and hold the power liftgate switch 05 located

on the liftgate for approximately 5 seconds or until 3 beeps are heard.

The liftgate will open to the selected position setting. To change the position of the liftgate,

repeat steps 1-3 for setting the position of the liftgate.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

0401

FRONT SEAT ADJUSTMENTS

To slide the seat forward or backward, push the control switch 01 forward or backward.

To recline the seatback, push the switch 02 forward or backward.

SEAT LIFTER

To raise or lower the front portion or height of the

seat, push the front or back end of the switch 01

up or down.

POWER LUMBAR SUPPORT (if so equipped for driver’s seat)

To adjust the seat lumbar support, push the front or back end of the switch 03.

For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (section 1)” of your Owner’s Manual.

11To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 14

FIRST DRIVE FEATURES

2ND ROW SEATS

To access the 3RD row seats, lift the seatback release

lever 01 to fold and slide the 2ND row seat forward.

Pull the release strap 02 to fold down the 2ND row

armrest and access the cup holders.

Pull the bar 03 and hold it while sliding the seat

forward or backward to the desired position. Release the bar to lock the seat in place.

For more information, refer to the “Safety — Seats, seat belts and

supplemental restraint system (section 1)” of your Owner’s Manual.

3RD ROW SEATS (if so equipped)

To fold the seatback forward, pull the release strap 01

and push the seatback forward.

To return the seatback to the upright position, pull

the release strap 01 and the seatback up at the same time.

The 3

row seats can fold forward for additional storage.

Pull the handle 02 and lift the ﬂoor.

Pull the straps 03 on both sides simultaneously, to

unlatch the 3RD row seat.

Lift the 3RD row seat to access the storage area

beneath the 3RD row seat 04.

For more information, refer to the “Safety — Seats, seat belts and

supplemental restraint system (section 1)” of your Owner’s Manual.

03 03

01 01

OUTSIDE MIRROR CONTROL SWITCH

Move the small switch 01 to select the right or left

side mirror.

Adjust each mirror to the desired position using the

large switch 02.

To prevent accidentally moving the mirror, move the

small switch 01 to the middle (neutral) position.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

12 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 15

STARTING/STOPPING THE ENGINE

It is important to make sure the NISSAN Intelligent

Key® is with you (that is, in your pocket or purse). Depress the brake pedal. Push the ignition switch in.

TURNING THE ENGINE OFF

Move the shift lever to the P (PARK) position, apply

the parking brake and press the ignition switch.

AUTO ACCESSORY

With the vehicle in the P (PARK) position, the Intelligent key with you and the ignition

placed from ON to OFF, the radio can still be used for a period of time, or until the driver’s

door is opened.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

HEADLIGHT CONTROL SWITCH

HEADLIGHT CONTROL

Turn the headlight control switch to the

position

to turn on the front parking, side marker, tail, license plate and instrument panel lights. Turn the switch to the

position 02 to

turn on the headlights.

AUTOLIGHT SYSTEM (if so equipped)

The autolight system will automatically turn the headlights on when it is dark and off when

it is light. The system will keep the headlights on for a period of time after you turn the ignition off and all doors are closed.

To activate the autolight system, turn the headlight control switch to the AUTO position

then turn the ignition switch to ON. To deactivate the autolight system, turn the

headlight control switch to the OFF,

position

HIGH BEAM SELECT

Push the headlight control switch forward 04 to select the high beam function. The blue

indicator light

illuminates in the instrument panel. Pull the headlight switch back to the original position to select the low beam. The blue indicator light will extinguish.

Pull and release the headlight control switch 05

to ﬂash the headlight high beams on and off.

FOG LIGHT SWITCH (if so equipped)

The headlights must be on and the low beams

selected for the fog lights to operate.

Turn the switch (inside collar) to the

to turn the fog lights on.

Turn the switch (inside collar) to the OFF position

position

to turn the fog lights off.

position 02.

13To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 16

FIRST DRIVE FEATURES

LANE CHANGE SIGNAL

To signal a lane change, move the lever up or down to the point where the indicator light

begins to ﬂash, but the lever does not latch.

The turn signal will ﬂash 3 times automatically.

For more information, refer to the “Instruments and cont rols (section 2)” of your Owner’s Manual.

WINDSHIELD WIPER AND WASHER SWITCH

Move the lever to the following positions to operate

the windshield wipers:

Mist — One sweep operation of the

front wipers.

Intermittent

intermittently and the speed can be adjusted by twisting the time control ring

— Front wipers operate

increase or decrease wiper speed.

Low — Front wipers operate at a

continuous low-speed.

High — Front wipers operate at a

continuous high-speed.

Front Washer — Pull the lever toward you

to activate the front washer. The front wipers will operate several times.

06 09

REAR WINDSHIELD WIPER AND WASHER

Intermittent — Rear wiper operates

intermittently.

Low — Rear wiper operates at a

continuous low-speed.

Rear Washer

to activate the rear washer. The rear wiper will

— Push the lever forward

operate several times.

WIPER BLADE REPLACEMENT PROCEDURE The windshield wipers must be in the service position in order to replace the wiper blades.

To move the wiper blades to the service position, follow this procedure:

When the ignition switch is in the ON position or within 60 seconds of placing the

ignition switch to the OFF position, push the windshield wiper and washer lever up to the Mist

position two times in less than 0.5 seconds. The windshield wipers will

move to the service position automatically, and the wiper blades can now be replaced.

To move the wiper blades back to the original position:

Pull the windshield wiper and washer lever up for more than 1 second or push the lever

down to operate at any wiper speed.

For more information, refer to the “Instruments and cont rols (section 2)” and the “Maintenance and do-it-yourself

(sect ion 8)” of your Owner’s Manual.

MIST

OFF

INT

14 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 17

AUTOMATIC CLIMATE CONTROLS (if so equipped)

DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front window defroster mode

press the A/C button Turn the temperature control dial left or right to set the desired temperature. To set the defroster on high, press the fan speed

. This feature removes humidity from the air.

driver’s side temperature control dial

DEFROSTING REAR WINDOW

Push the rear window defroster

defroster off. This function automatically turns off after approximately 15 minutes.

ON•OFF BUTTON/DRIVER’S SIDE TEMPERATURE CONTROL DIAL

Push the ON/OFF button to turn the climate controls on or off. Turn the temperature

control dial to the left for cooler air or right for warmer air.

MODE BUTTON

Press the MODE button to cycle through the following air ﬂow outlets:

Air ﬂows from the center and side vents. Air ﬂows from the center, side and foot vents. Air ﬂows mainly from the foot vents. Air ﬂows from the defroster and foot vents.

FAN SPEED CONTROL BUTTONS

Press the fan speed control button for low fan speeds or

A/C ON•OFF BUTTON

Press the A/C button to turn the air conditioner system on or off. This system helps cool

and dehumidify the air inside the cabin and defog the windows.

DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL

Press the DUAL button to turn the passenger’s side temperature controls on or off. This

will allow the passenger’s side temperature to be adjusted independently from the driver’s

side by turning the passenger’s side temperature control dial. Turn the passenger’s side temperature control dial left for cooler air or right for warmer air.

AIR RECIRCULATION BUTTON

The air recirculation button is used to avoid outside odors. Press the air recirculation button The air recirculation mode cannot be activated when the climate control system is in the

front defroster mode

or the front defroster and foot vent mode .

button. If it is difﬁcult to defog the windows,

all the way to the right.

switch

. Push the switch again to manually turn the

button

all the way up and turn the

for high fan speeds.

once to turn on and press again to turn off.

15To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 18

FIRST DRIVE FEATURES

AUTO BUTTON

Press the AUTO button to turn the system on and the system will automatically control the

inside temperature (automatic cooling and/or dehumidiﬁed heating), air ﬂow distribution

and fan speed.

FRESH AIR INTAKE BUTTON

Press the fresh air intake

The fresh air intake indicator light on the button will illuminate.

For more information, refer to the “Instruments and controls (section 2)” and the “Center display, heater, air conditioner, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

button to draw outside air into the passenger compartment.

01 02

FM/AM/SiriusXM®* SATELLITE RADIO WITH CD PLAYER (if so equipped)

VOLUME CONTROL KNOB/POWER BUTTON

Turn the VOLUME control knob to the right or left to increase or decrease the volume. Press the POWER button to turn the system on or off.

TUNE/SCROLL KNOB/ENTER/AUDIO BUTTON

To manually tune the radio, turn the TUNE/SCROLL knob left or right. Press the ENTER/AUDIO button to go to the audio settings screen.

SEEK BUTTONS

To tune and stop at the next or previous broadcast station, press the seek buttons or . For satellite radio, to switch to the ﬁrst channel of the previous or next category,

press the seek buttons or .

To change tracks on a CD, press the seek buttons or . To fast forward or rewind a track on a CD, press and hold the seek buttons or .

STATION SELECT KEYS

Twelve stations can be set for the FM band, 6 for the AM band and 18 for

satellite radio.

To store a station in a preset, you must ﬁrst select a radio band by pressing the

FM•AM button05 or SXM button 06 then tune to the desired FM, AM or satellite

radio station.

*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional satellite radio subscription service.

16 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 19

Then press and hold the desired station select button (1-6) until a beep is heard and the

sound is brieﬂy muted. The channel indicator will appear on the display and the sound will resume. Programing is now complete.

To retrieve a previously set station, select the radio band where the preset was stored

then press the corresponding station select button (1-6).

For more information, refer to the “Center display, heater, air conditioner, audio, phone and voice recognition systems

(section 4)” of your Owner’s Manual.

CRUISE CONTROL

The cruise control system enables you to set a constant

cruising speed once the vehicle has reached 25 mph (40 km/h). The system will automatically maintain the set speed until you tap the brake pedal, accelerate, cancel or turn the system off.

To activate the cruise control, push the ON•OFF

switch 01. The CRUISE indicator light in the instrument panel will illuminate.

To set cruising speed, accelerate the vehicle to the

desired speed, push the COAST/SET switch 02 and release. The SET indicator light in the instrument panel will illuminate and the set speed will display next to the indicator light. Take your foot off the accelerator pedal. Your vehicle will maintain the set speed.

To reset at a faster cruising speed, push and hold the ACCEL/RES switch 03.

When the vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch 02.

Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, tap the brake pedal or push the CANCEL switch 04.

To turn off cruise control, push the ON•OFF switch 01. Both the CRUISE indicator light

and SET indicator light in the instrument panel will extinguish.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

USB Universal Serial Bus) CONNECTION PORT/AUX JACK and iPOD® INTERFACE

The USB port/Aux jack 01 is located beneath the

climate controls.

When a compatible USB memory device, iPod® or

auxiliary device is plugged into the USB port/Aux jack, compatible audio ﬁles stored on the device can be played through the vehicle’s audio system.

For more information, refer to the “Center display, heater, air conditioner, audio, phone and voice recognition systems

(section 4)” of your Owner’s Manual.

17To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 20

FIRST DRIVE FEATURES

POWER PANORAMIC MOONROOF (if so equipped)

To fully open or close the moonroof, push the switch

to the open position 01 or the close position 02 and release it. The roof will automatically open or close. To stop the roof, push the switch once more while it is opening or closing.

To tilt the moonroof open, press the tilt button 03.

To close the moon roof, push the switch to the close position 02.

AUTO-REVERSE When the auto-reverse function is activated, the moonroof will automatically open or tilt up

when the control unit detects something caught in the moonroof when the moonroof is closing or tilting down.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

CENTER CONSOLE STORAGE BOX

To access the top storage tray, pull up on the driver’s

side lever 01.

To access the bottom storage bin, pull up on the

passenger’s side lever 02.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

TILT AND TELESCOPIC STEERING WHEEL ADJUSTMENTS

Release the lock lever by pulling it down.

Adjust the steering wheel forward or backward by

moving it to the desired position.

Adjust the steering wheel up or down to the

desired position.

Lock the steering wheel in place by pushing the lock lever up ﬁrmly.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

18 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 21

SYSTEM GUIDE

VEHICLE INFORMATION DISPLAY

The vehicle information display 01 displays such items as:

Vehicle settings Trip computer information Drive system warnings and settings (if so equipped) Audio information Navigation turn-by-turn Cruise control system information NISSAN Intelligent Key® operation information Indicators and warnings Tire pressure information

USING THE VEHICLE INFORMATION DISPLAY

The vehicle information display can be changed using the

button 02 and the ENTER

located on the steering wheel.

Press 02 to change the display mode. Move the switch 03 up or down to navigate

through the vehicle information display menu. Press ENTER 04 to change or select an item. Press 05 to go back to the previous menu.

STARTUP DISPLAY

When the ignition is in the ON position, the vehicle information display will support four of the following modes:

Active system status (if so equipped) Fuel economy Trip computer Warnings (if there are any) Tire pressure information

RESETTING THE TRIP COMPUTER

1. Press the

2. Press the

speed, distance to empty and journey time.

3. Pushing the TRIP RESET switch 06 for more than 1 second resets the currently

displayed trip odometer to zero.

SETTINGS The setting mode allows you to change the information displayed in the vehicle

information display:

Driver Assistance Alarm Clock Unit Meter Settings Language Vehicle Settings Factory Reset Maintenance

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

button 02 until you reach the trip computer mode. button 02 for more than 1.5 seconds to reset fuel consumption, average

buttons 03

19To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 22

SYSTEM GUIDE

BLUETOOTH® HANDS-FREE PHONE SYSTEM

A cellular telephone should not be used while driving

so full attention may be given to vehicle operation.*

SYSTEM OPERATING TIPS

Press the

at any time and speak a command after the tone.

To use the system faster, you may speak the second

level commands with the main menu command on the main menu. For example, press the button and after the tone say, “Call Redial”.

The “Help” command can be used to hear a list of

available commands at any time.

Reduce background noise as much as possible by

closing windows and pointing HVAC vents away from the ceiling.

Speak naturally without long pauses and without

raising your voice.

When speaking Phonebook names, please be aware some phones require the last name to be

spoken before the ﬁrst name. For example, “Michael Smith” may be spoken as “Smith Michael”. To cancel a voice recognition session, say “Exit” or press and hold the button. To decrease or increase the volume of the voice prompts, push the volume control switches

system while the system is responding. Voice commands can be used to operate various Bluetooth® System features using the

NISSAN Voice Recognition system. See your Owner’s Manual for detailed information. For more detailed information and instructions, refer to your cellular phone Owner’s Manual and

visit www.nissanusa.com/bluetooth.

button to interrupt the voice prompts

on the steering wheel or turn the VOL/ON•OFF control knob on the audio

BLUETOOTH® SYSTEM WITHOUT NAVIGATION (if so equipped)

PAIRING PROCEDURE

1. Press the

3. Say: “Add Phone”. The system acknowledges the command and asks you to initiate connecting

from the phone handset.

4. Initiate pairing from the phone.

• The connecting procedure varies according to each cellular phone model.

For detailed connecting instructions and a list of compatible phones, please visit www.nissanusa.com/bluetooth.

• When prompted, compare the PIN on the display with the PIN code shown on the handset.

If your device does not support Secure Simple Pairing and requests you to input a PIN, enter “1234” from the handset.

5. Say a name for the phone when the system asks you to provide one. You can give the phone a

name of your choice.

*Some jurisdictions prohibit the use of cellular telephones while driving.

20 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

button on the steering wheel. The system announces the available commands.

Page 23

PHONEBOOK REGISTRATION

When the cellular phone is connected to the in-vehicle module, the data stored in the cellular

phone, such as phonebook, outgoing call logs, incoming call logs and missed call logs is

automatically transferred and registered to the system.

The availability of this function depends on each cellular phone. The copying procedure

also varies according to each cellular phone. See your cellular phone’s Owner’s Manual for

more information.

Up to 1,000 entries per registered cellular phone can be stored in the phonebook.

MAKING A CALL

1. Push the

button on the steering wheel. A tone will sound.

2. Say: “Call”. The system acknowledges the command and announces the next set of

available commands.

3. Say: the registered person’s name. The system acknowledges the command and announces

the next set of available commands.

4. Say: “Yes”. The system acknowledges the command and makes the call.

RECEIVING/ENDING A CALL

To accept the call, press the

To reject the call, press the button.

To hang-up, press the button.

button on the steering wheel.

BLUETOOTH® SYSTEM WITH NAVIGATION (if so equipped)

Send predeﬁned or custom text messages* through your vehicle’s Bluetooth® system.

Receive texts through your vehicle’s Bluetooth® system that can be read to you.

Bluetooth® Streaming Audio allows you to use a compatible Bluetooth® phone to play

audio ﬁles from your device through your vehicle’s audio system. Once your compatible cellular phone is connected to the vehicle’s audio system, the audio ﬁles will play through the vehicle’s speakers.

SMARTPHONE INTEGRATION*

For information on how to pair your phone and use

popular smartphone apps in your NISSAN, please visit: www.nissanusa.com/connect/support.

CONNECTING PROCEDURE

1. Press the

2. Select the “Settings” key

3. Select the “Phone & Bluetooth” key

*Laws in some jurisdictions may restrict the use of “Text-to-Speech.” Some of the applications and features, such as social networking and texting, may also be restricted. Check local regulations for any requirements before using these features.

button on the control panel.

21To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 24

SYSTEM GUIDE

4. Select the “Connect New Device” key 03.

5. Initiate the connecting process from the handset.

The system will display the message:

“Is PIN XXXXXX displayed on your Bluetooth device?”

If the PIN is displayed on your Bluetooth

device,

select “Yes” to complete the connecting process.

VEHICLE PHONEBOOK

To access the vehicle phonebook:

1. Press the

2. Select the “Phonebook” key

3. Choose the desired entry from the displayed list.

button on the instrument panel.

MAKING A CALL

1. Press the

button on the instrument panel. The “Phone” screen 05 will appear on the display.

2. Select one of the following options to make a call:

“Phonebook”: Select the name from an entry stored in the vehicle phonebook.

“Call Lists”: Select the name from the incoming, outgoing or missed call history.

“Redial”: Dial the last outgoing call from the vehicle.

— Input the phone number manually using the keypad displayed on the screen.

RECEIVING/ENDING A CALL

To accept the incoming call, either:

• Press the

• Select the

To reject the incoming call, either:

button on the steering wheel, or

icon on the screen.

• Press the button on the steering wheel, or

• Select the icon on the screen.

To end a call, either:

• Press the button on the steering wheel, or

• Select the icon on the screen.

For more information, refer to the “Center display, heater, air conditioner, audio, phone and voice recognition systems

(section 4)” of your Owner’s Manual.

22 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 25

03 09

NAVIGATION SYSTEM (if so equipped)

Your Navigation System can calculate a route from the current location to a preferred destination.

The real-time map display and turn-by-turn voice guidance will lead you along the route.

The Navigation System will continually update your vehicle’s position. If you have deviated

from the original route, it will recalculate the route from your current location.

NissanConnectSM Mobile Apps integrates popular smartphone apps and services into your

vehicle. NissanConnectSM Mobile Apps requires a subscription. Please visit

www.nissanusa.com/connect for more information.

NAV button – Press to access the functions of the Navigation System.

MAP button – Press to display the current location map screen.

VOLUME knob – Turn right to increase the volume or left to decrease the volume.

key – Select to zoom the map in.

key – Select to zoom the map out.

button – Press to access Trafﬁc messages, MyApps, SiriusXM® Travel Link, Voice

For more information, refer to your Navigation System Owner’s Manual.

Commands, and Settings.

button – Press to change the display brightness between day and night modes. While the mode is being displayed, the brightness can be adjusted using the SCROLL knob. Press and hold to turn the display off. Press again to turn the display on.

BACK button – Press to return to the previous screen.

SCROLL knob – Turn to scroll through the items in a list. Press to select a menu item.

Touch screen display.

SD-card location - An SD-card with map data must be inserted here for map functions to operate.

23To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 26

SYSTEM GUIDE

HOMELINK

HOMELINK® UNIVERSAL TRANSCEIVER (if so equipped)

The HomeLink® Universal Transceiver can learn and consolidate the functions of up to 3

different hand-held transmitters, operating items such as garage doors, property gates, outdoor and indoor lights or alarm systems.

To program the HomeLink® Universal Transceiver:

• Position the handheld transceiver 1-3 in (26-76 mm) away from the HomeLink surface, keeping the HomeLink indicator light in view.

• Press and hold the desired HomeLink button and the handheld transmitter button simultaneously until the HomeLink indicator light ﬂashes slowly and then rapidly.

• Both buttons may be released when the indicator light ﬂashes rapidly.

To verify the programing is complete, press and hold the HomeLink button and observe the

indicator light:

• A solid, continuous light indicates the programing is complete and the HomeLink button will activate your device.

• A blinking light that turns to a solid, continuous light after 2 seconds indicates additional steps are required to complete the programing.

An additional person may make the remaining steps easier. To complete the

programing process:

• At the receiver of the device that you are programing to the HomeLink button, press and release the learn or smart button (the name may vary by manufacturer, but it is usually located near where the hanging antenna wire is attached to the unit). You have approximately 30 seconds to initiate the following step.

• Press and hold the programed HomeLink button for 2 seconds and release.

You may have to repeat the previous 2 steps up to 3 times to complete the programing

process. HomeLink should now activate your device.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink website at www.homelink.com or call 1-800-355-3515.

24 To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Page 27

MEMO

Page 28

This Quick Reference Guide is intended to provide an overview of some of the unique features of your new vehicle. See your Owner’s Manual, which contains important safety warnings and information about the operation and maintenance of your vehicle, for complete details. NISSAN North America, Inc. reserves the right to make changes, at any time, without prior notice, in prices, colors, materials, equipment, speciﬁcations, and models and to discontinue models or equipment. Due to continuous product development and other pre- and post-production factors, actual vehicle, materials and speciﬁcations may vary. Some vehicles are shown with optional equipment. See the actual vehicle for complete accuracy. Speciﬁcations, options and accessories may differ in Hawaii, U.S. territories and other countries. For additional information on availability, options or accessories, see your NISSAN dealer or contact NISSAN North America, Inc.

go to www.nissanownersinfo.mobi/2014/rogue

or snap this barcode with an appropriate barcode reader.

To view detailed instructional videos,

Nissan Rogue 2014 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS
