QUICK REFERENCE GUIDE

2018 MAXIMA

10 119 12

Headlight and Turn Signal Switch

Low Tire Pressure Warning Light

Vehicle Information Display

Trip Odometer*

Instrument Brightness Control*

Wiper and Washer Switch

*See your Owner’s Manual for information.

Underneath

instrument panel

Steering Wheel Switches For

Audio*/Vehicle Information Display/Navigation

Cruise Control/Bluetooth® and

Voice Recognition Switches

Trunk Lid Release Switch

Vehicle Dynamic Control (VDC)

OFF Switch

Heated Steering Wheel Switch*

Rear Power Sunshade Switch Tilt/Telescopic

Steering Column*

Hood Release*

Control Panel Display* Front Passenger Air Bag

Status Light*

Heater and Air Conditioner

Controls (automatic)

Display Commander

NEW SYSTEM FEATURES

How to Use Your Maxima’s Touch-screen Display .....................................2

Intelligent Around View Monitor (I-AVM) (if so equipped) ..............................3

Blind Spot Warning (BSW) (if so equipped) .............................................4

Intelligent Forward Collision Warning (I-FCW) .........................................5

Automatic Emergency Braking (AEB) ..................................................5

Vehicle Dynamic Control (VDC) ........................................................6

NissanConnect® Services Powered by SiriusXM®......................................6

SiriusXM Travel Link and SiriusXM Trac ..............................................8

Display Commander ...................................................................8

ESSENTIAL INFORMATION

Tire Pressure Monitoring System (TPMS) with Easy-Fill Tire Alert .....................9

Loose Fuel Cap........................................................................10

Fuel-ller Door ........................................................................10

Heated Steering Wheel (if so equipped)...............................................10

Clock Set/Adjustment .................................................................11

FIRST DRIVE FEATURES

Nissan Intelligent Key® System .......................................................12

Automatic Drive Positioner (if so equipped) ..........................................14

Seat Adjustments .....................................................................15

Trunk Lid Release .....................................................................16

Outside Mirror Control Switch ........................................................16

Starting/Stopping the Engine ........................................................17

Headlight Control Switch .............................................................17

Wiper and Washer Switch .............................................................18

Moonroof/Rear Sunshade Switch (if so equipped) ...................................19

Heater and Air Conditioner (automatic) ..............................................20

FM/AM/SiriusXM® Satellite Radio with CD Player.....................................21

USB (Universal Serial Bus) Connection Port/AUX Jack and iPod® Interface .........23

Front Armrest/Center Console Storage Box..........................................23

Cruise Control (if so equipped)........................................................24

Intelligent Cruise Control (ICC) (if so equipped).......................................25

SYSTEM GUIDE

Vehicle Information Display...........................................................26

Apple CarPlay™ .......................................................................27

Hands-free Text Messaging Assistant ................................................28

Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Bluetooth® Hands-free Phone System .............................................. 30

System Operating Tips............................................................ 30

Bluetooth® Streaming Audio..........................................................33

Navigation System ....................................................................34

HomeLink® Universal Transceiver.....................................................36

Additional information about your vehicle is also available in your Owner’s Manual, NissanConnect® Owner’s Manual, and at www.NissanUSA.com.

Please see your Owner’s Manual for important safety information and system operation limitations.

• A cellular telephone should not be used for any purpose while driving so full attention may be given to vehicle operation.

• Always wear your seat belt.

• Supplemental air bags do not replace proper seat belt usage.

• Children 12 and under should always ride in the rear seat properly secured in child restraints or seat belts according to their age and weight.

For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (section 1)”, the “Monitor, climate, audio, phone and voice recognition systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.

• Do not drink and drive.

NEW SYSTEM FEATURES

3 3

HOW TO USE YOUR MAXIMA’S TOUCH-SCREEN DISPLAY

Launch Bar - Various functions can be

accessed by touching the items on the Launch Bar 1, which is displayed on most of the main screens. Touching these keys will bring up the corresponding screens.

Widget - These items can be interchanged,

moved, or deleted from the MENU pages.

Touch either arrow to navigate to the next or

previous page of the “MENU” screen.

These dots indicate the page you are

currently on, in white, out of the number of pages there are available, in gray.

Shortcut - Shortcuts, once touched, will bring

up the system they correspond to for quick, one-touch convenience for commonly used features.

Shortcuts and Widgets can be set up

through the “Edit Menu” screen, which can be accessed by touching the “ Settings” key

followed by the “Edit Home Menu” key 7. This will display the “Edit Menu” screen, which allows Shortcuts and Widgets to be moved and rearranged 8, deleted 9 or created 10.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to your NissanConnect® Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

INTELLIGENT AROUND VIEW MONITOR (I-AVM) (if so equipped)

With the ignition switch in the ON position,

the Intelligent Around View Monitor (I-AVM) is activated by pressing the CAMERA button

, located on the control panel, or by moving the shift lever to the R (REVERSE) position. The monitor displays various views of the position of the vehicle.

When the shift lever is in the P (PARK),

N (NEUTRAL) or D (DRIVE) position and the CAMERA button 1 is pressed, the following views will display in order:

Start from any

Control Panel screen

Press

Front view & front-side view

Press Press

When the shift lever is in the R (REVERSE) position and the CAMERA button 1

Front view & bird’s-eye view

is pressed, the following views will display in order:

Rear view & bird’s-eye view

Press

Rear view & front-side view

The colored guide lines on the display screen indicate vehicle width and

approximate distances to objects with reference to the vehicle body line.

• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft (3 m) (if so equipped).

For information regarding how to access additional viewing cycles, please see

your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

NEW SYSTEM FEATURES

There are some areas where the system will not

detect objects.

• When in the front or the rear view display, an object below the bumper or on the ground may not be detected

• When in the bird’s-eye view, a tall object near the seams of the camera detecting areas appear in the monitor.

• The distance between objects viewed on the I-AVM diers from the actual distance.

Objects in the bird’s-eye view will appear

farther than the actual distance.

Always check your surroundings and turn to look behind

you before moving the vehicle.

MOVING OBJECT DETECTION (MOD) (if so equipped)

The MOD system helps inform the driver of moving objects around the vehicle.

The system will operate when the shift lever is in the D (DRIVE), N (NEUTRAL),

will not

R (REVERSE) or P (PARK) position and the vehicle is driven at speeds of

approximately 5 mph (8 km/h) or less.

If the MOD system detects moving objects, a yellow frame will be displayed on

the camera image.

When the following is displayed:

• Blue

• Gray

• No

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems

(section 4)” of your Owner’s Manual.

MOD icon

MOD icon; the system is not active.

MOD icon; the system is o. The indicator

will also be o if all of the warning systems are deactivated using the Settings menu.

The MOD system will not operate if the trunk

is open.

; the system is active.

BLIND SPOT WARNING (BSW) (if so equipped)

The BSW helps to alert the driver when

another vehicle moves into the vehicle’s detection zone.

An indicator light located near the outside

mirrors 1 will illuminate if the radar sensors detect a vehicle in the detection zone.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

1st vehicle 2nd vehicle

The indicator light 2 will illuminate after the ignition

switch is ON and the BSW is enabled. This indicates that the BSW is operational.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

INTELLIGENT FORWARD COLLISION WARNING (I-FCW)

The I-FCW system can help alert the driver

of sudden braking by the second vehicle traveling ahead of your vehicle in the same lane.

The I-FCW system operates at speeds above

approximately 3 mph (5 km/h).

If there is a potential risk of a forward collision, the I-FCW system

will warn the driver with the vehicle ahead detection indicator light

and an audible warning tone will be heard.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more informati on, refer to the “Sta rting and d riving (section 5)” of your Owne r’s Manua l.

1st vehicle 2nd vehicle

AUTOMATIC EMERGENCY BRAKING (AEB)

The AEB can assist the driver when there is a risk of a forward collision with a

vehicle ahead in the traveling lane.

The AEB operates at speeds greater than 3 mph (5 km/h).

If there is a risk of a forward collision, an audible tone will sound

and the vehicle ahead detection indicator light 1 will illuminate. If the driver applies the brakes after the warning and the AEB detects that there is still the possibility of a forward collision, the system will automatically increase the braking force. If the driver does not take action, the AEB will issue a second visual warning

, an audible warning and also apply partial braking.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

NEW SYSTEM FEATURES

VEHICLE DYNAMIC CONTROL (VDC)

VDC should remain on when driving, except when freeing the

vehicle from mud or snow.

When the VDC OFF switch 1 is pushed, an indicator light

will illuminate. If the system is turned o, it will turn back on when the switch is pushed a second time. Also, if the system is turned o and the vehicle is restarted, the system will automatically turn on again.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” and the “Starting and driving

(section 5)” of your Owner’s Manual.

NISSANCONNECT® SERVICES POWERED BY SiriusXM®

NissanConnect® Owner’s Manual is a collection of security and convenience services that add innovation to your daily drive.

To enroll in NissanConnect Services, create an account or log into your

Nissan Owner Portal with your Vehicle Identication Number or VIN. Under the NissanConnect Services tab, select the red button next to Manage Subscription. Follow the prompts to enroll in NissanConnect Services. Next, download the NissanConnect Services companion app and log into it using your Nissan Owner Portal ID and password.

For full details on NissanConnect Services or to enroll your vehicle, please visit www.NissanUSA.com/connect or call 855-426-6628.

Here is a quick overview of some of the features that may be available for your vehicle. A full description of these and other NissanConnect Services can be found in your Navigation System Owner’s Manual.

Automatic Collision Notication, a service that

generates an automatic connection between the vehicle and the Emergency Response Center when the vehicle has been involved in an accident that was severe enough to deploy the air bags.

Emergency Call, which connects you to a

NissanConnect Services Specialist who will assist in the dispatch of emergency services to the vehicle location. To use this feature, press the should only be used in emergency situations.

Roadside Assistance, which dispatches roadside assistance to the vehicle’s

location in non-emergency situations. Roadside Assistance can be accessed by touching the headset icon 2 on the map screen, via the NissanConnect Services companion app or by calling the Roadside Assistance provider directly.

Stolen Vehicle Locator, a service that works in coordination with law

enforcement agencies to assist in the recovery of a stolen vehicle.

To view detailed instructional videos regarding these and other features,

SOS button

please go to www.nissanownersinfo.mobi.

on the overhead console. The SOS button 1

Remote Door Lock/Unlock, for use when you

forget to lock your vehicle or if you need to open it and do not have the keys. To use this feature, log into the NissanConnect Services companion app or website or contact a

NissanConnect Services Response Specialist.

Remote Engine Start - Start your engine

remotely using the NissanConnect Services companion app or website.

Assisted Search, a feature that allows you to verbally request point-of-interest

or destination data from a live operator by touching the headset icon 2 on the map screen.

Journey Planner, with which you can send a route with a destination and up to

ve way points directly to the vehicle.

Boundary Alert, a feature that allows you to monitor the movement of your

vehicle in and out of specied regions you have set on the Monitoring section of the NissanConnect Services web portal or companion app.

Speed Alert, which sends you alerts when your vehicle speed exceeds a

threshold you have set on the web portal or companion app.

Alarm Notication - This system will notify you when the factory-installed

vehicle alarm has been activated.

Maintenance Alert – Receive notications

via a selected method of a vehicle system malfunction that triggers instrument panel warning lights.

Connected Search – Select “Connected

Search” from the Destination menu on the vehicle’s Navigation System to conduct a Point Of Interest (POI) search within a certain distance of the vehicle’s location.

Valet Alert – Use Valet Alert to set up a

0.2‐mile radius around your vehicle. Activate alerts via the NissanConnect Services companion app or website.

Curfew Alert – Specify curfew limits via the

NissanConnect Services companion app or website and be notied via a selected method if curfew is violated.

To access these features in your vehicle:

• Touch the “

• Touch the ”NissanConnect Services” key

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information. For more information, refer to the “Information (section 5)” of your NissanConnect® Owner’s Manual.

Info” key 3 on the control panel.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

NEW SYSTEM FEATURES

SiriusXM TRAVEL LINK AND SiriusXM TRAFFIC

Your vehicle’s Navigation System is equipped

with SiriusXM Travel Link and SiriusXM Trac capabilities.

Touch the ” Info” key to access SiriusXM

Travel Link and SiriusXM Trac.

SiriusXM Travel Link provides access to

real-time weather information and forecasts, nearby fuel prices, movie listings, sports scores and stock quotes.

SiriusXM Trac provides information that

may help to avoid delays due to trac incidents. Trac jams, roadwork, road closures around the current location, etc., are represented graphically on the map by icons depicting the nature of the event. Incidents on the route are automatically displayed as they are approached.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Information (section 5)” of your NissanConnect® Owner’s Manual.

DISPLAY COMMANDER

1 MENU - Press to display the “HOME

MENU” screen.

BACK - Press to go back to the

previous screen.

MAP/VOICE - Press to display the vehicle’s

current location on the map. Press and hold to hear the current voice guidance for a programed route.

OK - Press to enter the selected item. If this button is pressed while a map is

displayed, the map menu is shown on the display.

Center dial/Slide switch - Turn the dial to scroll the highlighted item or to

adjust a setting (treble, brightness, etc.). While the map screen is displayed, adjust the map scale by turning the dial. Depending on the screen, sliding the slide switch can select areas on the screen or scroll the pages. While the map screen is displayed, scroll the map screen by sliding the switch.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Getting started (section 2)” of your NissanConnect® Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

ESSENTIAL INFORMATION

TIRE PRESSURE MONITORING SYSTEM (TPMS) WITH EASY-FILL TIRE ALERT

A Tire Pressure Low-Add Air warning

message will appear in the vehicle information display 1 and the low tire pressure warning light 2 will illuminate when one or more tires are low in pressure and air is needed.

• The tire pressures should be checked when the tires are cold. The tires are considered cold after the vehicle has been parked for 3 hours or more or driven less than 1 mi (1.6 km) at moderate speeds.

After tire pressures are adjusted, drive the vehicle at speeds above 16 mph

(25 km/h). The Tire Pressure Low-Add Air warning message and low tire pressure warning light 2 will extinguish.

In addition to the Tire Pressure Low-Add Air warning message, you can view

the individual tire’s pressure in the vehicle information display as well as the recommended pressure, denoted by blue lettering, for each tire.

When adding air to an under-inated tire, the TPMS with Easy-Fill Tire Alert

provides visual and audible signals to help you inate the tire to the recommended COLD tire pressure.

To use the Easy-Fill Tire Alert:

1. Move the shif t lever to the P (PARK) position and apply the parking brake.

2. Place the ignition switch in the ON position. Do not start the engine.

3. Add air to the under-inated tire, and within a few seconds, the hazard

warning lights will start ashing.

4. When the designated tire pressure is reached, the horn will beep once and the

hazard warning ashers will stop ashing.

5. Repeat this procedure for any additional under-inated tires.

When the low tire pressure warning light 2 ashes for 1 minute and then

remains on, the TPMS is not functioning properly. Have the system checked. It is recommended that you visit a Nissan dealer for this service.

Tire pressure rises and falls depending on the heat caused by the vehicle’s

operation and the outside temperature. Low outside temperature can lower the temperature of the air inside the tire, which can cause a lower tire ination pressure. This may cause the low tire pressure warning light 2 to illuminate. If the warning light illuminates, check the tire pressure in your tires.

• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

The Tire and Loading Information label contains valuable information. Refer to

the “Technical and consumer information (section 10)” of your Owner’s Manual for the location of the Tire and Loading Information label.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the “Do-it-yourself (section 8)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

ESSENTIAL INFORMATION

LOOSE FUEL CAP

A LOOSE FUEL CAP warning message

will appear in the vehicle information display 1 when the fuel-ller cap is not tightened correctly.

To tighten, turn the cap clockwise until a

single click is heard.

If the cap is not properly tightened, the

Malfunction Indicator Light may illuminate.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks

and adjustments (section 3)” of your Owner’s Manual.

FUEL-FILLER DOOR

To open the fuel-ller door, push the right side of the fuel-ller

door to release.

The fuel-ller door is located on the driver’s side of the vehicle.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Pre-driving checks and adjustments (section

3)” of your Owner’s Manual.

HEATED STEERING WHEEL (if so equipped)

Once activated, your heated steering wheel

will automatically turn on and o to maintain a temperature above 68°F (20°C).

When the surface temperature of the steering

wheel is above 68°F (20°C) and the switch

is turned on, the system will not heat the

steering wheel. This does not indicate a malfunction.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

CLOCK SET/ADJUSTMENT

To adjust the time and the appearance of the

clock on the display:

1. Press the

control panel.

2. Touch the “

Launch Bar.

3. Touch the “

The following settings can be adjusted:

On-screen Clock: The clock in the upper right corner of the display can be

• turned ON or OFF.

Clock Format (24h): The clock can be set to 12 hours or 24 hours.

•

Oset (hour): The time can be adjusted by increasing or decreasing per hour.

•

Oset (min): The time can be adjusted by increasing or decreasing

• per minute.

Daylight Savings Time: The application of Daylight Savings Time can be

• turned ON or OFF.

Time Zone: Adjust the time zone. Choose a time zone from the available list.

•

Touch the “ ” key or press the BACK button on the Display Commander to

return to the previous screen.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Getting started (section 2)” of your NissanConnect® Owner’s Manual.

MENU button on the

Settings” key on the

Clock” key.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

NISSAN INTELLIGENT KEY® SYSTEM

The Nissan Intelligent Key® system allows you to lock or unlock your vehicle, open your trunk lid and start the engine. It is important to make sure the Intelligent Key (I-Key) is with you (that is, in your pocket or purse).

KEY-LINKED SYSTEM (if so equipped)

The vehicle information display has added

features, allowing the Key-Linked System to remember some of the vehicle information display settings.

The Key-Linked System states which I-Key is

being recognized 1, and enabling/disabling of the system’s function can be easily accessed through notications on the vehicle information display.

The Key-Linked System can be turned on or

o through the vehicle information display in the “Key-Linked Settings” screen 2.

You can set a maximum of two I-Keys to the

Key-Linked System.

When the system is enabled, the recognized I-Key is displayed at engine start-up

(Engine ON) as well as within the “Key-Linked Settings” screen 2.

When the system is active, the vehicle information display setting items are

memorized for each key that has been enabled in the Key-Linked System.

If two keys are in the vehicle, the Key-Linked System will recognize the key that

was used most recently; this usually means the last key to unlock/lock the door from the I-Key.

If there is a desire to change to another key that is in the vehicle, turn o the

engine and initiate communication from the desired key.

1. Turn the engine to OFF.

2. Press the

3. Start the engine.

4. The desired key number recognized should appear on the vehicle

information display.

The vehicle information display displays a pop-up notication at Engine ON for

the recognition of the system with a shortcut function to the setup menu.

From the shortcut setup menu, you can select to enable or disable the

Key-Linked System or select “Later” to keep the factory state.

When enabled, the Key-Linked System will remember the state of the items

memorized automatically from the last ignition cycle.

button from the desired I-Key.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

REMOTE ENGINE START WITH INTELLIGENT CLIMATE CONTROL*

The Remote Engine Start operating range is approximately 200 ft (60 m) from

the vehicle. The eective operating range may be shorter if there are walls, strong radio wave sources near the operating location or other obstructions between the key and the vehicle.

For the Remote Engine Start to function, the vehicle must be in the P (PARK)

position with the ignition o and all doors must be closed and locked. Please see your Owner’s Manual for additional information.

To start your vehicle remotely:

1. Press the

2. Within 5 seconds, press and hold the Remote Engine Start

button 3 for at least 2 seconds.

The engine will start, and the parking lights will turn on.

The automatic climate control system will begin heating

button 4 to lock all of the doors.

or cooling the vehicle depending on the outside (ambient) temperature, cabin (in-car) temperature and the last user mode. During this period, the climate control display and buttons will be inoperable until the ignition switch is turned ON.

The engine will run for 10 minutes and then turn o.

Repeat steps 1 through 2 to extend the time for an additional 10-minute period.

Remote Engine Start can only be activated for a maximum of 20 minutes.

• After two remote starts, the ignition switch must be cycled before the Remote Engine Start can be used again.

• To cancel Remote Engine Start, press the remote start

To start driving, depress the brake pedal and press the ignition switch

button 3.

START/STOP button.

LOCKING AND UNLOCKING THE VEHICLE

The operating range of the I-Key is within

31.5 in (80 cm) from each request switch.

To lock the vehicle, either push the door

handle request switch 7 once or press the

button 4 on the key fob.

To unlock the vehicle, perform one of the following procedures:

• Push either door handle request switch

once to unlock the corresponding door. Push the door handle request switch 7 again within 1 minute to unlock all doors, or

• Press the

button 5 on the key fob to unlock the driver’s side door. Press

the button 5 again within 1 minute to unlock all doors.

The I-Key can also be used to activate the panic alarm by pressing and holding

the button 6 for 1 second. Once activated, the panic alarm and headlights will stay on for a period of time.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

AUTO UNLOCK

In the Vehicle Settings menu in the vehicle information display, there are three options to choose from for the auto unlock function:

• OFF - Auto Unlock is disabled.

• IGNITION OFF - All doors unlock when the ignition is turned o.

• SHIFT TO PARK - All doors unlock when the shift lever is moved to the P (PARK) position.

NISSAN INTELLIGENT KEY® BATTERY DISCHARGE

If the battery of the I-Key is discharged or

environmental conditions interfere with the I-Key operation, Key Battery Low 8 will display on the gauge and the engine will need to be started according to the following procedure:

1. Move the shif t lever to the P (PARK) position.

2. Firmly apply the foot brake.

3. Touch the ignition switch with the I-Key. A chime will sound.

4. Within 10 seconds after the chime sounds, press the ignition switch

START/STOP button while depressing the brake pedal and the engine will start.

* State laws may apply; review local laws before using.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)”, the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and the “Do-it-yourself (section 8)” of your Owner’s Manual.

Key

Battery Low

AUTOMATIC DRIVE POSITIONER (if so equipped)

Two positions for the driver’s seat, steering

column (if so equipped) and outside mirrors can be stored in the automatic drive positioner memory.

Follow this procedure to set the

memory positions:

• Place the ignition switch in the ON or ACC position. (The vehicle should be stopped while setting the memory.)

• Adjust the driver’s seat, steering column (if so equipped) and outside mirrors to the desired positions using the adjusting switches for each feature.

• Push the SET switch (1 or 2).

• The indicator light for the memory switch you select will illuminate for approximately 5 seconds, and a chime will sound when the memory is stored.

• The driver’s seat, steering column (if so equipped) and outside mirror positions are now set to your preferences.

To view detailed instructional videos regarding these and other features,

, and within 5 seconds, push the memory switch

please go to www.nissanownersinfo.mobi.

These memorized positions can also be linked to your Nissan Intelligent Key®.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

SEAT ADJUSTMENTS

SEAT FABRIC

If so equipped, your vehicle’s seats may be made from a material known as

Alcantara®. In the case of most localized stains, using lukewarm water and soap will restore Alcantara® to its factory condition. For more details on proper cleaning, please refer to your Owner’s Manual.

POWER SEATS

To slide the seat forward or backward, push

the switch 1 forward or backward.

To recline the seatback, push the

switch 2 forward or backward.

POWER SEAT LIFTER (if so equipped for passenger seat)

To adjust the angle of the front seat cushion

or height of the seat, push the front or rear end of the switch 1 up or down.

POWER LUMBAR SUPPORT (if so equipped for driver’s seat)

To adjust the seat lumbar support, push the front or back

end of the switch 3.

THIGH SUPPORT (if so equipped for driver’s seat)

Pull up and hold the lever 4 to extend

the front portion of the seat to the desired position.

FOLDING DOWN THE REAR SEAT

To fold the rear seatback, press down on

the button on the rear parcel shelf 5. The passenger’s side rear seatback will release.

The pull straps 6 located in the trunk will

release the rear seatbacks to allow them to fold forward.

To raise the seatback, lift up each seatback

and push it to the upright position until it is latched.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (section 1)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

TRUNK LID RELEASE

Use one of the following methods to open the trunk lid:

Press the button 1 on the Nissan Intelligent Key®

for 1 second.

Push the trunk opener request switch 2 while carrying the

Intelligent Key with you (that is, in your pocket or purse).

From inside the vehicle, push the trunk opener switch 3,

located on the instrument panel to the left of the steering wheel.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

OUTSIDE MIRROR CONTROL SWITCH

To select the right or left side mirror, slide the

mirror control switch 1 right or left.

To adjust the mirror angle, move the control

switch up, down, right or left.

To prevent accidentally moving the mirror,

slide the mirror control switch center (neutral) position.

REVERSE TILT-DOWN FEATURE (if so equipped)

The reverse tilt-down feature will turn both outside mirror surfaces downward to provide better rear visibility close to the vehicle.

1. Apply the brake.

2. Place the ignition switch in the ON position.

3. Move the shift lever to the R (REVERSE) position.

4. Both outside mirror surfaces will turn downward. (The mirror control switch

must be out of the center [neutral] position.)

The outside mirror surfaces will return to their original positions when one of the following conditions occurs:

The shift lever is moved to any position other than R (REVERSE).

The outside mirror control switch

The ignition switch is placed in the OFF position.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

to the

is set to the center (neutral) position.

STARTING/STOPPING THE ENGINE

It is important to make sure the Nissan

Intelligent Key® is with you (that is, in your pocket or purse).

Depress the brake pedal.

Press the ignition switch START/STOP

button to start the engine.

TURNING THE ENGINE OFF

Move the shift lever to the P (PARK) position.

Press the ignition switch START/STOP button to turn the engine o.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

HEADLIGHT CONTROL SWITCH

HEADLIGHT CONTROL

Rotate the headlight control switch to the

position 1 to turn on the front parking, side marker, tail, license plate and instrument panel lights. Rotate the switch to the position 2 to turn on the headlights.

AUTOLIGHT SYSTEM

The autolight system will automatically turn the headlights on when it is dark

and o when it is light. The system will keep the headlights on for a period of time after you turn the ignition o and all doors are closed.

To activate the autolight system, turn the headlight control switch to the AUTO

position

then push the ignition switch to ON. To deactivate the autolight

system, turn the headlight control switch to the or position 2.

HIGH BEAM SELECT

With the headlights ON (either in the AUTO

or position), push the headlight control switch forward 4 to select the high beam function. The blue indicator light will illuminate in the instrument panel. Pull the headlight switch back to the original position to select the low beam. The blue indicator light will extinguish.

Pull and release the headlight control switch 5 to ash the headlight high

beams on and o.

OFF position, position

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

FOG LIGHT SWITCH

The headlights must be on and the low

beams selected for the fog lights to operate.

Turn the switch (inside collar) to the

position 6 to turn the fog lights on.

Turn the switch (inside collar) to the OFF

position to turn the fog lights o.

LANE CHANGE SIGNAL

Move the lever up or down until the turn signal begins to ash but the lever does

not latch to signal a lane change. Hold the lever until the lane change is completed.

Move the lever up or down until the turn signal begins to ash but the lever

does not latch and release the lever. The turn signal will automatically ash three times.

Choose the appropriate method to signal a lane change based on the road and trac conditions.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

WIPER AND WASHER SWITCH

Move the lever to one of the following

positions to operate the windshield wipers:

Mist (MIST) - One sweep operation of the

front wipers.

Auto (AUTO) - Operates the rain-sensing

wipers (if so equipped) intermittently. The intermittent speed can be adjusted by rotating the time control ring 3 to increase or decrease wiper sensitivity. Also, the intermittent operation speed varies in accordance with vehicle speed.

Low (LO) - Front wipers operate at a

continuous low-speed.

High (HI) - Front wipers operate at a

continuous high-speed.

Pull the lever toward you to activate the front washer.

The wipers will operate several times.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

MIST

OFF

AUTO

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

MOONROOF/REAR SUNSHADE SWITCH (if so equipped)

OPENING/CLOSING THE MOONROOF AND SUNSHADE

To fully open the moonroof and sunshade,

push the switch fully past the detent toward

OPEN position

the

To fully close the moonroof and sunshade,

push the switch fully past the detent toward

CLOSE position

the

To open just the sunshade (moonroof will

remain closed), push the switch 3 to the detent toward the

OPEN position

Push the switch 3 toward the open position 1 again to open the moonroof.

To close just the moonroof (sunshade will remain open), push the switch 3 to

the detent toward the

CLOSE position

again to close the moonroof.

CLOSE position

. Push the switch 3 toward the

OPENING THE SUNSHADE/TILTING THE MOONROOF

Push the switch 3 once to open the

sunshade and tilt the moonroof.

Push the switch 3 again to close the

moonroof. Push the switch 3 to the detent toward the

CLOSE position

the sunshade.

to close

REAR POWER SUNSHADE

The rear sunshade switch 4 is located

in the instrument panel to the left of the steering wheel.

To raise the sunshade, push the upper side of

the switch.

To lower the sunshade, push the lower side of

the switch.

The switch does not need to be held down.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

3 5

HEATER AND AIR CONDITIONER (automatic)

AUTO BUTTON/DRIVER’S SIDE TEMPERATURE CONTROL DIAL

The automatic mode may be used year-round. Press the AUTO button to

turn the system on, and the system will automatically control the inside temperature (automatic cooling and/or dehumidied heating), air ow distribution and fan speed.

Turn the driver’s side temperature control dial left for cooler air or right for

warmer air.

DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL

Press the DUAL button to turn the passenger’s side temperature controls

on or o. This will allow the passenger’s side temperature to be adjusted independently from the driver’s side by turning the passenger’s side temperature control dial.

Turn the passenger’s side temperature control dial left for cooler air or right

for warmer air.

ON•OFF BUTTON

Press the ON•OFF button to turn the system on or o.

FAN SPEED CONTROL BUTTONS

Press either the or the button to decrease or increase fan speed.

MODE BUTTON

Press the MODE button to cycle through the following air ow outlets:

Press the A/C button to turn the air conditioner system on or o. This system

Press the fresh air intake button 7 to draw outside air into the

Air ows from the center and side vents.

Air ows from the center, side and foot vents.

Air ows mainly from the foot vents.

Air ows from the front defroster and foot vents.

A/C BUTTON

helps cool and dehumidify the air inside the cabin and defog the windows.

FRESH AIR INTAKE BUTTON

passenger compartment.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

AIR RECIRCULATION BUTTON

Press the air recirculation control button 8 to recirculate interior

air inside the vehicle. The indicator light on the button will illuminate. This system is used to avoid certain outside odors and to adjust the inside vehicle temperature more eectively.

The air recirculation mode cannot be activated when the climate control

system is in the front defroster mode or the front defroster and foot vent mode .

DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the front defroster button to turn the system on. This feature

removes humidity from the air. Turn the temperature control dial 1 to set the desired temperature. To defrost the front and side windows quickly, set the temperature controls

and fan speed controls to their maximum settings.

DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS (if so equipped)

Push the rear window and outside mirror (if so equipped) defroster switch

to turn the system on or o. This function automatically turns o after approximately 15 minutes.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” and the “Monitor, climate,

audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.

6 7 8 9

FM/AM/SiriusXM® SATELLITE RADIO WITH CD PLAYER

Touch the ” Audio” key on the Launch Bar to display the current audio source. Touch the ” Audio” key a second time to access the source selection screen.

(ON•OFF) BUTTON/VOLUME CONTROL KNOB

Press the (on•o) button to turn the audio system on or o.

Turn the VOLUME control knob right or left to increase or decrease the volume.

AUDIO KEY

Touch the ” Audio” key on the Launch Bar to bring up the current source’s

control screen.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

/ (SEEK and CAT/TRACK) BUTTONS

Press the button or the button to seek up or down to the next

receivable station. For satellite radio to switch to the rst channel of the previous or next

category, press the button or the button. To change tracks on a CD, press the button or the button. To rewind or fast forward a track on a CD, press and hold the button

or the button.

ENTER SOUND BUTTON/TUNE•SCROLL KNOB

Press the ENTER SOUND button to cycle through the audio settings

individually and use the TUNE•SCROLL knob to adjust the current setting. Touch the ” Settings” key on the Launch Bar and then touch the “Sound”

key to view all audio settings. To manually tune the radio, turn the TUNE•SCROLL knob left or right.

AUDIO (SOURCE) BUTTON

Pressing this button will give access to the AM, FM, SXM, CD, USB1/iPod,

USB2/iPod, Bluetooth Audio or AUX audio source. Twelve memory stations can be set for the FM band, six for the AM band and

18 for satellite radio. These appear at the bottom of the screen when one of

these sources is selected. To store a station in a preset, you must rst select a radio band by touching

the ”AM” key 6, “FM” key 7 or “SXM” key 8 then tune to the desired AM,

FM or satellite radio station. Next, press and hold the desired station preset

key until you hear a beep. The channel indicator will then display, and the

sound will resume. Programing is now complete. To retrieve a previously set station, select the radio band where the preset

was stored then press the corresponding station select key.

AM KEY / 7 FM KEY

Touch the “AM Menu” or “FM Menu” key to view the station list or turn HD

mode on or o. Tag favorite songs to save to an iPod®.

• Apple® website: If you are listening to a radio station that supports iTunes

Tagging, you can tag a song you hear so you can preview and purchase it later on the iTunes Store. Songs that can be tagged are marked with a tag icon next to the song title or on the “Now Playing” screen.

SXM KEY

Touch the “SXM Menu” key to bring up the categories, favorites and

replay options.

CD KEY

Touch the “CD Menu” key to view the track list.

AUX KEY

A cable with 1/8 in (3.5 mm) stereo mini plugs is required for audio playback.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Audio system (section 3)” of your NissanConnect® Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

USB (Universal Serial Bus) CONNECTION PORT/AUX JACK AND iPOD® INTERFACE

The USB ports are located in the media

pocket 1 below the climate control system.

USB1/iPod® and USB2/iPod®

• When a device is connected via USB, the

system will automatically start playing music from it.

• This system supports Android™ and Apple®

devices and USB memory devices. Only Android brand, Android certied cables, Apple brand or Apple certied cables will work. NISSAN cannot guarantee compatibility with aftermarket cables that are not certied by Android or Apple.

• Android Auto™ and Apple CarPlay™ can only be used with USB1, which is the

port closest to the driver.

• It may not be compatible with some versions of Android.

Touch the “USB/iPod® Menu” key to view the folder list and track listing, playlist,

albums, album art, artist and songs.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Audio system (section 3)” of your NissanConnect® Owner’s Manual.

FRONT ARMREST/CENTER CONSOLE STORAGE BOX

To open the console box, press up on the

lever 1 and raise the lid.

To close, push the lid down until the

lock latches.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls

(section 2)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

FIRST DRIVE FEATURES

CRUISE CONTROL (if so equipped)

The cruise control system enables you to set a constant cruising speed once the

vehicle has reached 25 mph (40 km/h).

The system will automatically maintain the set speed until you tap the brake

pedal, accelerate, cancel or turn the system o.

To activate the cruise control, push the

ON/OFF switch 1 on the steering wheel. The cruise indicator light in the instrument panel will illuminate.

To set a cruising speed, accelerate the vehicle

to the desired speed, push the SET- switch

on the steering wheel and release. Take your foot o the accelerator pedal. Your vehicle will maintain the set speed.

To reset at a faster cruising speed, push and hold the RES+ switch 3 on the

steering wheel. When the vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the SET- switch 2 on the

steering wheel. Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, tap the brake pedal or push the CANCEL switch 4

on the steering wheel.

To turn o cruise control, push the ON/OFF switch 1 on the steering wheel.

The cruise indicator light in the instrument panel will extinguish.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

INTELLIGENT CRUISE CONTROL (ICC) (if so equipped)

VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE

To set Vehicle-To-Vehicle mode, push the CRUISE switch 1 on the steering

wheel. The CRUISE indicator light 2 will illuminate.

Accelerate to the desired speed.

Push down on the SET- switch 3 on the

steering wheel and release it. Intelligent Cruise Control will be set to the desired speed.

Push the distance switch 4 on the

steering wheel repeatedly to change the set distance between long, middle and short.

When a vehicle is not detected ahead of you

in the lane, the set distance and set vehicle speed indicator lights will illuminate 5 in set mode.

When a vehicle is detected ahead of you in the lane, the

vehicle ahead detection, set distance and set vehicle speed indicator lights will illuminate 6 in set mode.

To reset at a faster cruising speed, push and hold the RES+

switch 7 on the steering wheel. When the vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the SET-

switch 3 on the steering wheel. Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, push the CANCEL switch 8 on the steering wheel

or tap the brake pedal. The set vehicle speed indicator 5 will extinguish.

To turn o Intelligent Cruise Control, push the CRUISE switch 1 on the

steering wheel. The CRUISE indicator light 2 in the instrument panel will extinguish.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SYSTEM GUIDE

VEHICLE INFORMATION DISPLAY

When the arrow buttons 1 on the steering wheel are pressed, the following

modes will appear on the vehicle information display 2:

Home – Displays the current speed, the compass and the additional media

that is available.

Audio – Displays the current

playing media.

Navigation – Displays the vehicle’s

current heading.

Drive Computer – Displays Average

Fuel Economy, Average Speed, Trip Computer and Time of the Trip. Each can be reset individually.

Fuel Economy – Displays Average Fuel

Economy. Press and hold the OK button

on the steering wheel to reset.

Driving Aids (if so equipped)– Displays the Driving Aids that are equipped

on your vehicle. Use the OK button system on or o.

Tire Pressure (psi) – Displays the individual tire’s pressure while driving.

S SPORT – Displays the oil pressure, gear oil temperature, digital speedometer

and horsepower percentage.

Warning Review – Displays the current warnings.

Settings – Displays the available settings that can be changed.

— Press the

the various setting modes.

— Press the OK button

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.

selected menu.

To view detailed instructional videos regarding these and other features,

arrow buttons

on the steering wheel to choose the

please go to www.nissanownersinfo.mobi.

on the steering wheel to turn each

on the steering wheel to cycle through

APPLE CARPLAY™

The in-vehicle system can be used as a controller for some of the iPhone®

functions through Apple CarPlay™.

If your iPhone® is compatible, the Apple CarPlay can be used.

• Select the “

MENU“ key

• Select “Apple CarPlay”

To connect your CarPlay capable iPhone® to the system, you must connect the

iPhone® cable to USB1.

• Depending on the setting, the “Startup Information” screen will appear.

• Touch “Yes” to use Apple CarPlay.

• The Apple CarPlay top menu screen will appear, and the iPhone® functions displayed on the screen can be operated by the in-vehicle system.

• To return to the “Apple CarPlay” top menu screen after operation, touch the

” key 4 on the lower left corner of the “Apple CarPlay” screen.

“

• To exit the “Apple CarPlay” screen and display the other screens, press the

MENU button or one of the other buttons on the control panel and touch

the preferred menus.

• To return to the “Apple CarPlay” screen, touch the “ Bar and then touch the “Apple CarPlay” key

When connected to Apple CarPlay, Siri® operation can also be accessed.

on the screen.

from the menu.

Info” key

on the Launch

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SYSTEM GUIDE

There are three ways to start a Siri session.

1. Press and hold the

steering wheel.

2. Touch and hold the “

lower left corner of the Apple CarPlay screen.

3. Say “Hey Siri” (requires appropriate

permissions enabled via phone).

Press the button on the steering wheel or touch the “ ” key 4 at the lower

left corner of the Apple CarPlay screen to end Siri operation.

Keep the interior of the vehicle as quiet as possible. Close the windows to

eliminate the surrounding noises (trac noises, vibration sounds, etc.), which may prevent the system from recognizing the voice commands correctly.

Some Siri functions may not be available during driving.

For functions that can be used with Siri, please refer to the Apple website.

Nissan Phone menu and Nissan Voice Recognition cellular phone commands will

not be available when Apple CarPlay is active.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the ”Getting started (section 2)” and the ”Information (section 5)” of your NissanConnect® Owner’s Manual.

button on the

” key 4 at the

HANDS-FREE TEXT MESSAGING ASSISTANT*

This text messaging feature allows for

sending and receiving text messages through the vehicle’s interface.

Using predened or custom messages, send

a text to an entry stored in your Bluetooth® Hands-free Phone System.

Once enabled, the text message, sender and

delivery time are shown on the control panel display when the vehicle speed is less than 5 mph (8 km/h).

Text messages have the option of being read aloud.

Once the vehicle is in motion, text messages can only be replied to using the

Voice Recognition button on the steering wheel.

Text messages can be created manually when the vehicle is not in motion.

Custom text messages must be created in advance.

Many cellular phones may require special permission to enable text messaging.

Check the cellular phone’s screen during Bluetooth® pairing. For some cellular phones, you may need to enable “Notications” in the cellular phone’s Bluetooth® menu for text messages to appear on the touch-screen display. For more detailed information and instructions, refer to your cellular phone’s Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

Text message integration requires that the cellular phone support Message

Access Prole (MAP) for both receiving and sending text messages. Some cellular phones may not support all text messaging features. Please see www.NissanUSA.com/bluetooth for compatibility information as well as your device’s Owner’s Manual.

* Laws in some jurisdictions may restrict the use of “Text‐to‐Speech”. Some of the applications and

features, such as social networking and texting, may also be restricted. Check local regulations for any requirements before using these features.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Hands-Free Phone (section 4)” of your NissanConnect® Owner’s Manual.

ANDROID AUTO™

The in-vehicle system can be used as a

controller for some of the Android™ functions through Android Auto™.

INITIAL SETUP

Download the Android Auto app from the

Google Play™ store to your compatible Android phone.

Launch the app from your Android phone

and follow the directions for setting up the application.

Complete the initial set-up as prompted on

your Android phone. Several permissions will need to be given to the app for Android Auto to fully function on your in-vehicle system.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SYSTEM GUIDE

USING ANDROID AUTO

To connect your Android Auto capable phone to the system, you must connect

a certied USB cable to the USB1 port located below the center console.

• Depending on the setting, the “Startup Information” screen will appear on the center display.

• Touch “Yes” to use Android Auto.

• The Android Auto top menu screen will appear, and the Android functions displayed on the screen can be operated by the in-vehicle system.

When connected to Android Auto, voice

operation can be accessed. There are three ways to start voice operation:

1. Press and hold the button on the

steering wheel until a beep is heard.

2. Touch the “ ” key 1 on the upper right

corner of the “Android Auto” screen.

3. Say “OK Google” (requires appropriate permissions enabled via phone).

To return to the “Android Auto” top menu screen after operation, touch the ” ”

key 2 on the bottom of the “Android Auto” screen.

To exit the “Android Auto” screen and display the other screens, press the

MENU button or touch the

To return to the “Android Auto” screen, touch the “ Info” key

Bar and then touch the Android Auto key 5.

Nissan Phone menu and Nissan Voice Recognition cellular phone commands will

not be available when Android Auto is active.

If you have diculties with connection or performance, try a dierent certied

USB cable.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the ”Getting started (section 2)” and the ”Information (section 5)” of your NissanConnect® Owner’s Manual.

” ”

key 3.

2 3

on the Launch

BLUETOOTH® HANDS-FREE PHONE SYSTEM*

A cellular telephone should not be used

while driving so full attention may be given to vehicle operation.

For Information regarding connecting your

cellular phone, refer to the connecting procedure within this guide.

SYSTEM OPERATING TIPS

Press the button on the steering wheel to

interrupt the voice prompts at any time and speak a command after the tone.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

Bluetooth® controls

To use the system faster, you may speak the

second level commands with the main menu command on the main menu. For example, press the button on the steering wheel, and after the tone, say “Call Redial”.

The “Help” command can be used to hear a

list of available commands at any time.

Reduce background noise as much as possible

Microphone

by closing windows and pointing heater and air conditioner vents away from the ceiling.

Speak naturally without long pauses and without

raising your voice.

If you experience diculty with the Voice Recognition System recognizing a

contact name, please try saying both the rst and last name of the contact as this improves recognition accuracy.

To cancel a Voice Recognition session, say “Cancel” or “Quit” or press and hold

the button on the steering wheel for 5 seconds.

For more detailed information and instructions, refer to your cellular phone’s

Owner’s Manual and visit

www.NissanUSA.com/bluetooth.

CONNECTING PROCEDURE

The vehicle must be stationary when

connecting the cellular phone.

1. Press the

and touch the “

button on the steering wheel

Connect Phone” key.

2. Initiate connecting from the cellular phone.

• The connecting procedure varies

according to each cellular phone model. For detailed connecting instructions and a list of compatible cellular phones, please visit

www.NissanUSA.com/bluetooth.

• When prompted, conrm the PIN on

the display with the PIN shown on the handset. If your device does not support Secure Simple Pairing and requests you to input a PIN, enter “1234” from the handset.

• Some cellular phones may incorrectly

state that the connection was unsuccessful. Please verify that the touch-screen displays that the connection is successful, or touch “

Settings” > “Bluetooth” > “Select BT Device” > “Phone” and conrm that your

cellular phone is listed.

3. When connecting is complete, the screen

will return to the Phone menu display.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SYSTEM GUIDE

PHONEBOOK SETUP

Press the MENU button on the control panel.

Touch the “ Settings” key on the Launch Bar, touch the “Phone” key and then

touch the “

Depending on your cellular phone, the system

may automatically download your cellular phone’s entire phonebook to the vehicle’s Bluetooth® system.

The Quick Dial phonebook can also be set for

up to ve entries that can be used with your cellular phone.

1. Press the

touch the “

2. Touch the “

methods to input a phone number. Select one of the following options:

• “ Copy from Call History” to save a number from the Outgoing, Incoming or

• “Copy from the Phonebook” to save a number that has been downloaded

• “Enter Number by Keypad” to input the

MAKING A CALL

To make a call, follow this procedure:

1. Press the

The Phone menu will appear on the control panel display.

2. Touch one of the following:

• “

Quick Dial”, “Phonebook” or “Call History”

key. Select the desired entry from the list and then the desired number, or

• To enter a number manually, touch the

Dial Number” key, then enter the number

“ and touch “

RECEIVING/ENDING A CALL

To accept the call:

• Press the wheel, or

• Touch the “ touch-screen display.

Phonebook” key.

button on the Launch Bar and

Quick Dial” key.

Add New” key at the top of the display. There are dierent

Missed Calls lists.

from your handset to the vehicle.

number and name manually.

button on the steering wheel.

OK”.

button on the steering

Answer” key on the

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

To reject the call:

• Press the

arrow buttons on the steering wheel to highlight “Decline” through the vehicle information display and press

OK button on the steering wheel, or

the

• Touch the “

Decline” key on the

touch-screen display.

To hang up:

• Press the

button on the steering wheel, or

• Touch the “Hang up” key on the touch-screen display.

* Some jurisdictions prohibit the use of cellular telephones while driving.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the“Hands-Free Phone (section 4)” of your NissanConnect® Owner’s Manual or please visit www.NissanUSA.com/bluetooth.

BLUETOOTH® STREAMING AUDIO

If you have a compatible Bluetooth® device with streaming audio (A2DP prole),

you can set up the wireless connection between your Bluetooth® device and your vehicle’s audio system. This connection allows you to listen to audio from the Bluetooth® device using your vehicle’s speakers.

A cellular phone should not be used while driving so full attention may be given

to vehicle operation.

1. Touch the “

2. A prompt to connect your device will display.

• If the device is already paired:

a. Touch the “

from an already paired device.

b. Select the desired device and touch the

Connect” key

“

c. The last played audio will start playing

once the device is connected.

• If the device needs to be connected:

a. Touch the “

b. Touch the “

c. Touch the “

Touch “BT Menu” to view track listing, artist, songs or albums.

Touch “BT Settings” to change which device is playing audio.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Hands-Free Phone (section 4)” of your NissanConnect® Owner’s Manual or please visit www.NissanUSA.com/bluetooth.

Audio” key and select the “Bluetooth Audio” key.

Select Devices” key to play

Settings” key.

Bluetooth” key.

Connect Device” key.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SYSTEM GUIDE

1 8 4 9

NAVIGATION SYSTEM

Your Navigation System can calculate a route from your current location to

a preferred destination. The real-time map display and turn-by-turn voice guidance will lead you along the route.

The Navigation System will continually update your vehicle’s position. If you

have deviated from the original route, it will recalculate the route from your current location.

To help promote safe driving, some functions cannot be operated or have

limited operation when the vehicle speed is above 5 mph (8 km/h). The on-screen text and keys for these restricted functions will be grayed-out or muted and cannot be selected while driving. These functions will become available again when the vehicle is not in motion. Voice commands may be available for some of the restricted functions. For more information, refer to the “Voice recognition (section 7)” of your Navigation System Owner’s Manual.

MENU - Touch to access all available shortcut and widget items in the

“Menu” screen.

Touch-screen

Map Menu - Touch to access dierent options related to either a selected

location by touch or one that you have navigated to. Some options include “Save Location”, “Nearby POIs”, “Map Icons” or “New Destination”.

Navi (Navigation) - Touch to access the Navigation function.

Info (Information) - Touch to display the vehicle, trac (if so equipped) and

weather (if so equipped) information.

ZOOM OUT, 7 ZOOM IN - Touch to adjust the map scale. When parked,

you can pinch in or out to zoom on the screen.

Map - Touch to display the map.

Settings - Touch to display the system settings.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SETTING A DESTINATION

You can set a destination with your Navigation System using the touch-screen display or Voice Recognition.

Touch-screen Display

• Touch the “

• When a destination is set, touch the “

Navi” key on the Launch Bar.

New Destination” key and then select one

of the displayed options for choosing your destination.

Voice Recognition

• Press the

button on the steering wheel, and after the tone, say “Navigation”. From here, the system will give you the options available for setting a destination.

SETTING A DESTINATION USING POINTS OF INTEREST (POI)

Touch-screen Display

• Touch the “ touch the “

Navi” key on the Launch Bar, and if a destination is already set,

New Destination” key.

• Touch the “Points of Interest” key and then select one of the displayed options for choosing your destination.

Voice Recognition

• Press the

button on the steering wheel, and after the tone, say “Navigation” then say “Points of Interest”. From here, the system will give you the options available for setting a POI.

NAVIGATION SWIPE TO METER

Turn-by-turn route guidance can also be viewed in the vehicle information

display by using Navigation Swipe to Meter. This can be done by programing a route, touching the turn-by-turn route icon on the center display, and swiping toward the general direction of the vehicle information display.

The turn-by-turn route icon will move across the center display and

transfer the route information to the vehicle information display when the vehicle is not moving.

The icon will not move across the screen if the vehicle speed is over 4 mph (7

km/h), but the information will still transfer to the vehicle information display.

The turn-by-turn route guidance cannot be transferred to the vehicle information

display if the navigation screen is already shown or if a warning is present.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to your NissanConnect® Owner’s Manual.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

SYSTEM GUIDE

HOMELINK

HOMELINK® UNIVERSAL TRANSCEIVER

The HomeLink® Universal Transceiver can learn and consolidate the functions

of up to three dierent hand-held transmitters, operating items such as garage doors, property gates, outdoor and indoor lights or alarm systems.

To program the HomeLink® Universal Transceiver:

• Position the handheld transceiver 1-3 in (2-3 cm) away from the HomeLink surface, keeping the HomeLink indicator light in view.

• Press and hold the desired HomeLink button and the handheld transmitter button simultaneously until the HomeLink indicator light ashes slowly and then rapidly.

• Both buttons may be released when the indicator light ashes rapidly.

To verify the programing is complete, press and hold the HomeLink button and

observe the indicator light:

• A solid, continuous light indicates the programing is complete and the HomeLink button will activate your device.

• A blinking light that turns to a solid, continuous light after 2 seconds indicates additional steps are required to complete the programing.

An additional person may make the remaining steps easier. To complete the

programing process:

• At the receiver of the device that you are programing to the HomeLink button, press and release the “learn” or “smart” button (the name may vary by manufacturer, but it is usually located near where the hanging antenna wire is attached to the unit). You have approximately 30 seconds to initiate the following step.

• Press and hold the programed button for 2 seconds and release.

You may have to repeat the previous two steps up to three times to complete

the programing process. HomeLink should now activate your device.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information.

For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink website at www.homelink.com or call 1-800-355-3515.

To view detailed instructional videos regarding these and other features,

please go to www.nissanownersinfo.mobi.

MEMO

Helpful Resources

Below is a list of helpful resources that can be used to learn more about the vehicle’s systems and feature operations.

Vehicle Owner’s Manual

NissanConnect® Owner’s Manual (if so equipped)

Printed Quick Reference Guide (this document)

www.NissanUSA.com/bluetooth

www.NissanUSA.com/connect

www.youtube.com/user/NissanUSA

Nissan Consumer Aairs 1-800-647-7261

Electronic Quick Reference Guide

(Use Quick Response (QR) code or URL below.)

Nissan Quick Guide (available in the

App Store® or Google Play™ store for download to your smartphone)

To view detailed instructional videos,

go to www.nissanownersinfo.mobi/2018/maxima

or snap this barcode with an appropriate barcode reader.

This Quick Reference Guide is intended to provide an overview of some of the unique features of your new vehicle. Please see your Owner’s Manual for important safety information and system operation limitations. Features and equipment in your vehicle may vary depending on model, trim level, options selected, order, date of production, region or availability. Therefore, you may nd information about features or equipment that are not included or installed on your vehicle.

All information, specications and illustrations in this Quick Reference Guide are those in eect at the time of printing. NISSAN reserves the right to change specications, performance, design or component suppliers without notice and without obligation. From time to time, NISSAN may update or revise this Quick Reference Guide to provide owners with the most accurate information currently available. Please carefully read and retain with this Quick Reference Guide all revision updates sent to you by NISSAN to ensure you have access to accurate and up-to-date information regarding your vehicle. Current versions of vehicle Quick Reference Guides, Owner’s Manuals and any updates can also be found in the Owner section of the NISSAN website at https://owners.nissanusa.com/nowners/navigation/manualsGuide. If you have questions concerning any information in your Owner’s Manual, contact NISSAN Consumer Aairs. See the NISSAN CUSTOMER CARE PROGRAM page in the Owner’s Manual for contact information.

Nissan MAXIMA 2018 Quick Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS
