Nintendo Zone Box
System and a local WiFi network, enabling the System to retrieve and/or receive WiFi content)
(NOA P/N and Description: Automates the connection between a consumer’s Nintendo DS
[NZB-001]
User’s Manual
Please read this manual before using this product. Store this manual in a safe place.
(2)
Please contact Support for the following.
• When Nintendo Zone Box is not working properly
• When parts are lost or the device is damaged
• When discontinuing use
Assembled in Japan All rights reserved.
Nintendo of America Inc.
12521 128 Lane NE Suite B, Kirkland, WA. 98034
(3)
1. Kit Contents
Nintendo Zone Box (NZB-001) x1
consumer’s Nintendo DS System and a local WiFi network, enabling the System to retrieve and/or receive WiFi
content)
(NOA P/N and Description: Automates the connection between a
(1) Status Window
Open the window to check status of current communication.
(2) Power LED (Blue)
The light turns on when power is on.
(3) Wireless Communication LED (Yellow)
Light is steady when power is on; light blinks during wireless communications.
AC Adapter
(NOA P/N and Description)
[WAP-002(JPN)]
x1
Wall mounting resin plate
(NOA P/N and Description)
x1
When mounting this device to a wall, this part is attached to the device with screws.
(-> “5. Installation)
Note: Use the included “Pan head screws (M4x6).”
(NOA P/N and Description)
Wall mounting bracket
(NOA P/N and Description)
x1
When mounting this device to a wall, this part is attached to the wall with screws. (-> “5.
Installation)
Note: Use the included “Wall mounting screws.”
Cord stickers
(NOA P/N and Description)
x2
These are used to secure the AC adapter cord to the wall.
(-> “6. Connecting the AC Adapter and Setting up Download Services that use the Internet”)
Pan head screws (M4x6)
(NOA P/N and Description)
x2
These are used when mounting the Wall mounting resin plate to the main device.
(-> “5. Installation)
Wall mounting screws
(NOA P/N and Description)
x3
These are used when mounting the Wall mounting bracket.
(-> “5. Installation)
DC Plug lock
(NOA P/N and Description)
x1
This fitting is to prevent the DC plug of the AC adapter from being unplugged from the device.
(-> “5. Installation)
(4)
2. WARNING – FIRE OR ELECTRICAL SHOCK
Failure to install or use this product as directed may result in fire or electrical shock.
Please observe the following precautions for safe use:
■ Observe Safety Precautions
Please read this User’s Manual before use.
■ Periodic Inspections
Periodically inspect the AC adapter cord and AC plug for damage and check for dust between
the outlet and AC plug.
■ If there is a problem
Note: Exercise caution, as it is dangerous to make excessive contact.
1. Unplug the AC adapter AC plug from the outlet to turn power OFF.
2. Immediately contact Nintendo Zone Support. Note: Do not have repairs
performed by the supplier.
(5)
■ Ceases to function properly
If normal functions cease, immediately contact Nintendo Zone Support.
■ Warning Icons
The following warning icons should be understood before reading this manual.
DANGER: Strong possibility of death or serious injury
WARNING: Possibility of an accident resulting in serious injury or death
CAUTION: Possibility of injury or damage to personal property
Request for use: Possibility of damaging this device or damaging personal property
(6)
3. Cautions during Use
WARNING
• Do not install this device in the following locations. If it fails, it may result in injury, fire, or
damage.
• Places exposed to weather, such as the outdoors
• Unstable locations; walls not sufficiently strong to mount this device
• Places exposed to direct sunlight; near sources of heat, such as heaters and
stoves
• Places were electromagnetic waves or power line noise is generated, such as
near microwave ovens or motors
• Places exposed to humidity, dust, oily smoke, or tobacco smoke
• Places where children can reach
• Places subject to condensation due to sudden changes in temperature, such as
near air conditioner vents
• Places subject to strong static electricity; places near open flames
• Do not use any AC Adapter other than the proprietary AC adapter [WAP-002 (JPN)].
Using another adapter may result in fire, electric shock, or malfunction.
• Do not alter, disassemble, or try to repair this product as it may result in fire, electric
shock, or malfunction.
• Always use the included parts for wall mounting when mounting this device on a wall
and firmly affix the device on the wall in the proper direction.
• If you detect odd sounds, smoke, or odd smells, immediately unplug the AC plug from
the outlet. After confirming there is no smoke, contact Nintendo Zone Support.
Continuing use may cause fire or malfunctions.
• Exercise caution, as it is dangerous to make excessive contact.
• Do not attempt repairs by yourself.
• Do not touch the connector or terminals with your fingers or metal objects and do not
insert foreign objects.
