Page 1

BL480REF

OWNER’S GUIDE

www.ninjakitchen.com

Page 2

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING YOUR NUTRI NINJA

WITH AUTO-iQ™.

POLARIZED PLUG

WARNING: To reduce the risk of

electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will ﬁt into a polarized outlet only one way. If the plug does not ﬁt fully into the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician to install the proper outlet. DO NOT modify the plug in

any way.

WARNING: Extension cords are

not recommended for use with this product.

WARNING: TO REDUCE THE RISK OF

FIRE, ELECTRIC SHOCK OR INJURY:

1 WARNING: Remove utensils prior to

processing. Failure to remove may cause the jar to be damaged or to shatter which may cause personal injury.

2 WARNING: Pro Extractor Blades®

Assembly is sharp and removable, handle with care. When handling the Pro Extractor Blades Assembly, always hold them by the base of the blade assembly. Failure to do so will result in a risk of laceration.

3 CAUTION: Do not blend hot liquids,

doing so may cause excessive pressure build-up, resulting in a risk of the user being burned.

4 CAUTION: We do not recommend

grinding in any of our Nutri Ninja® Cups.

5 CAUTION: Remove the Pro Extractor

Blades Assembly from the cup upon completion of blending. Some ingredients have the potential to expand after blending resulting in excessive pressure buildup that can pose a risk of injury.

6 To protect against electrical shock, do not

submerge the appliance or allow the power cord to come into contact with water or any other liquid.

7 DO NOT allow the appliance to be used

by children. Close attention is necessary when used near children. This is not a toy.

8 Never leave an appliance unattended when

inuse.

1-877-646-5288

Page 3

9 Appliance accessories are not intended to

be used in the microwave as it may result in damage to the accessories.

10 Remove the power cord from the electrical

outlet when not in use, before assembling or disassembling parts and before cleaning. To unplug, grasp the plug and pull from the electrical outlet. Never pull from the powercord.

11 DO NOT abuse the power cord. Never carry

the appliance by the power cord or yank it to disconnect from electrical outlet; instead grasp the plug and pull to disconnect.

12 DO NOT operate any appliance with

a damaged cord or plug, or after the appliance malfunctions, has been dropped or damaged in any manner. This appliance has no serviceable parts. Return the appliance to SharkNinja Operating LLC for examination, repair or adjustment.

13 DO NOT let the power cord hang over

the edge of table or counter or touch hot surfaces such as the stove.

14 Always use appliance on a dry, level

surface.

15 Keep hands, hair, clothing, as well as

utensils out of container while processing to reduce the risk of severe injury to persons or damage to the appliance. A scraper may be used but only when the appliance is not

running. 16 Avoid contact with moving parts. 17 DO NOT attempt to sharpen blades. 18 DO NOT use the appliance if blade

assembly is bent or damaged.

19 To reduce risk of injury, never place the

blade assembly on base without pitcher or bowl properly attached.

20 DO NOT operate this appliance on or near

any hot surfaces (such as gas or electric burner or in a heated oven).

21 The use of attachments or accessories

including canning jars, not recommended by the manufacturer may result in ﬁre, electric shock or personal injury.

22 DO NOT remove the cup from the motor

base while the appliance is in operation.

23 To reduce the risk of injury, NEVER operate

the appliance without the lid in place; DO NOT try to defeat the interlock mechanism; make sure that the attachment is properly installed before operating the appliance.

24 DO NOT expose cups to extreme

temperaturechanges. 25 DO NOT overﬁll. 26 DO NOT operate the appliance empty. 27 If the appliance overheats, a thermal

switch will become activated and shut off

the motor. To reset, unplug the appliance

and let it cool down for approximately 30

minutes before using again. 28 THIS PRODUCT IS INTENDED FOR

HOUSEHOLD USE ONLY. Do not use

this appliance for anything other than its

intended use. Do not use outdoors.

SAVE THESE

INSTRUCTIONS

www.ninjakitchen.com

Page 4

THIS BOOK COVERS MODEL NUMBERS:

BL480REF

TECHNICAL SPECIFICATIONS

Voltage: 120V., 60Hz. Power: 1000 Watts

Cup Capacity:

18 ounces (2.25 cups, 530 mL) 24 ounces (3 cups, 710 mL)

NOTE: Select accessories are included. Other are available

for purchase at www.ninjakitchen.com. To see what is included with this model, please refer to the packaging.

1-877-646-5288

Page 5

Contents

Thank you for purchasing the Nutri Ninja® with AUTO-iQ

™

Getting to Know Your Nutri Ninja® with AUTO-iQ™ ..............................................................5

Before First Use ..............................................................................................................7

Use ................................................................................................................................8

Suggested Uses ...............................................................................................................9

Care & Maintenance ......................................................................................................10

Troubleshooting Guide ....................................................................................................11

Replacement Parts .........................................................................................................11

Sample Recipes .............................................................................................................12

Warranty & Registration ..................................................................................................14

www.ninjakitchen.com

Page 6

Getting To Know Your Nutri Ninja® with AUTO-iQ

™

START

MARCHE

BLEND

STOP

MÉLANGE

ARRÊT

LTRA BLEND

PULSE

MÉLANGE

ULTRA

IMPULSION

Lid

Assembly

c Small 18 oz. Nutri Ninja® Cup

d Regular 24 oz. Nutri Ninja

Cup

a Pro Extractor Blades

b Sip & Seal

e Motor Base

NOTE: The quantity, sizes, and presence of some accessories depends on the speciﬁc model conﬁguration. All conﬁgurations include a motor base, Pro Extractor Blades® Assembly, certain Nutri Ninja® cups, Sip & Seal® Lids, and instructions.

1-877-646-5288

Page 7

Welcome to the Ninja

AUTO-iQ™ Experience! The Nutri Ninja® with AUTO-iQ™ features pre-programmed settings that take the guesswork out of drink and meal making. These programs are timed to deliver consistent, delicious results that ﬁnish on their own so all you have to do is press a button and enjoy!

FEATURES:

• Nutrient & Vitamin Extraction*

• 1000 Watt Motor

• User Interface:

START | STOP

Press once to start continuous running, press again to stop. Timer counts up by seconds, up to 60 seconds.

PULSE

AUTO-iQ

• Personalized, healthy drinks and juices

• Sip & Seal

• Nutri Ninja

• Cord storage

* Extract a drink containing vitamins & nutrients from fruits and vegetables.

Runs only while pressed down. Short presses make short pulses. Timer counts up by seconds as long as pressed down.

™

BLEND

Pulses and blends fresh or softer ingredients to create smooth consistent results. Timer counts down.

™

ULTRA BLEND

Pulses and blends frozen, ﬁbrous or hard ingredients to create smooth consistent results. Timer counts down.

lids for drinks on the go

Cups, BPA free

www.ninjakitchen.com

Page 8

Before First Use

PLEASE KEEP THESE IMPORTANT SAFEGUARDS IN MIND WHEN USING THE APPLIANCE:

WARNING: Remove utensils prior to

processing. Failure to remove may cause the cup to be damaged or to shatter, which may

cause personal injury.

WARNING: Never leave the appliance

unattended while in use.

CAUTION: Do not blend hot liquids, doing

so may cause excessive pressure buildup, resulting in a risk of the user being burned.

CAUTION: Blades are sharp! Use extreme

caution when handling the Pro Extractor Blades® Assembly. Always hold them by the base of the blade assembly.

CAUTION: Never at tempt to remove the cup

while the appliance is still running.

IMPORTANT: Make sure that the motor base

is plugged in for use.

IMPORTANT: Never run the appliance empty.

IMPORTANT: Appliance accessories are not

intended to be used in the microwave as it may result in damage to the accessories.

CAUTION: Do not immerse the motor base into

water or any other liquid.

1 Remove all packaging material and labels from the

appliance. Separate/remove all parts from each other.

2 Wash the lids, cups and Pro Extractor Blades Assembly

in warm, soapy water. Blades Assembly handle to avoid direct hand contact with blades.

WARNING: Handle the Pro Extractor Blade

Assembly with care when washing, as the blades are sharp.

3 Rinse and air dry thoroughly.

4 Cups, lids and Pro Extractor Blades Assembly are all

dishwasher safe. It is recommended that the lids and attachments be placed on the top rack. Ensure that the Pro Extractor Blades Assembly is removed from the cups before placing in the dishwasher.

5 Wipe the motor base clean with a damp cloth.

1-877-646-5288

When washing the

, use a dish-washing utensil with a

Pro Extractor

Page 9

Use

WARNING: Handle the Pro Extractor Blades® Assembly with care, as the blades are sharp. WARNING: Remove utensils prior to processing. Failure to remove may cause the Nutri Ninja cup to be

damaged or to shatter, which may cause personal injury. WARNING: Never leave the appliance unattended while in use. CAUTION: Do not blend hot liquids, doing so may cause excessive pressure buildup, resulting in a risk of

the user being burned. CAUTION: Remove the Pro Extractor Blades Assembly from the cup upon completion of blending. Some

ingredients have the potential to expand after blending resulting in excessive pressure buildup that can

pose a risk of injury.

ASSEMBLY USE REMOVAL

Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5

1 Review warning and caution statements above before

proceeding to number 2.

2 Place the motor base on a clean, dry, level surface such

as a counter or table top.

3 Make sure that the motor base is plugged in for use. No

lights will turn on.

4 Add ingredients to the Nutri Ninja

cup.

NOTE: Do not overﬁll! To avoid spilling, do not add

ingredients past the “MAX” ﬁll line.

5 Place the Pro Extractor Blades Assembly onto the cup

and twist it on tightly until you have a good seal. (Fig. 1)

6 Turn the cup upside down and place it onto the motor

base, aligning the tabs on the cup with the motor base.

Turn it clockwise, until you feel it click into place. The

Timer light will illuminate.(Fig. 2)

7 Press one of the buttons to activate. (Fig. 3)

NOTE:

When using the AUTO-iQ™ presets, the unit will operate using pulses, pauses and continuous runs. The pauses allow the contents of the cup to settle. When the timer reaches “0”, it will stop by itself.

8 To remove the cup, ensure that the motor has stopped

running. Then turn the cup counter clockwise (Fig. 4) and pull straight up to remove. (Fig. 5)

Turn the cup upright and remove the Pro Extractor

Blades® Assembly by twisting the Pro Extractor Blades Assembly counter clockwise. Be sure to store the Pro Extractor Blades Assembly attached to an empty cup when not in use.

10 Twist the Sip & Seal® lid onto the cup to enjoy your

drink on the go. Press ﬂip top cap ﬁrmly into the opening to get the best seal. The ﬂip top cap locks open when pressed backward.

11 Make sure that the motor base is unplugged when not

in use.

12 To remove the motor base unit, tip the unit forward

from the rear to easily disengage the suction cups.

www.ninjakitchen.com

Page 10

Suggested Uses

PURPOSE / FUNCTION SUGGESTED CUP TYPE OF FOOD

Chopping / Pulsing

Mixing 24 oz.

18 oz. 24 oz.

Salsa

Leafy Herbs

Batters

Dips

Vinaigrettes

Sauces 24 oz.

Salad Dressings Simple Sauces*

Frozen Blending

Nutrient Juices/Smoothies

18 oz. 24 oz.

Ice

Frozen Fruit

Ice Cream

Fruits

Vegetables

Leafy Greens

CAUTION: DO NOT process dry ingredients without adding liquid to the cup. This product is not intended

for dry blending.

* When blending sauces, make sure they’re cooled to room temperature ﬁrst - Ninja

blending.

FILLING YOUR NUTRI NINJA

For best results, always follow recipe directions when ﬁlling your Nutri Ninja® cups. When you’re not using a recipe, use the following guidelines:

Start with your fresh fruit or veggies. Then add any nuts, seeds or powder followed by any liquids like juice or milk. More liquid can help to integrate powder. Then add your frozen fruit and ice. Remember to securely tighten the blade and don’t overﬁll the cups. (Fig. 6)

containers are not intended for hot

ice

frozen fruit

juices, liquids

nuts, seeds,

powders

fresh fruits/

veggies

Fig. 6

1-877-646-5288

Page 11

Care & Maintenance

HOW TO CLEAN

CAUTION: Make sure that the motor base is

unplugged from the power source before inserting or removing any attachment and before cleaning.

CAUTION: DO NOT immerse the motor base into

water or any other liquid.

1 Separate/remove all par ts from each other.

2 Hand Washing: Wash the lids, Nutri Ninja

Pro Extractor Blades® Assembly in warm, soapy water. When washing the Pro Extractor Blades Assembly, use a dish-washing utensil with a handle to avoid direct hand contact with blades. Handle Pro Extractor Blades Assembly with care to avoid contact with sharp edges. Rinse and air dry thoroughly.

WARNING: Handle the Pro Extractor Blades Assembly with care when washing, as the blades are sharp. Contact with the blades’ edges can result in laceration.

3 Dishwasher: The pitcher, Nutri Ninja cups, lids, and Pro

Extractor Blades Assembly are all dishwasher safe. It is recommended that the lids and Pro Extractor Blades Assembly be placed on the top rack. Ensure the Pro Extractor Blades Assembly is removed from the cup before placing in the dishwasher.

4 Wipe the motor base clean with a damp cloth

If the appliance needs servicing, please call customer

service at 1-877-646-5288.

cups and

HOW TO STORE

1 Store the Nutri Ninja® with AUTO-iQ™ upright. Secure

the power cord underneath the base by wrapping the cord around the cord wrap. Do not place anything on top. Store the cups and the rest of the attachments along side the appliance where they will not be damaged and won’t cause a hazard.

RESETTING THE MOTOR THERMOSTAT

The Nutri Ninja® with AUTO-iQ™ features a unique

safety system which prevents damage to the unit’s motor and drive system should you inadvertently overload your appliance. If the appliance is being overloaded, the motor will stop. To reset the appliance, follow the resetting procedure below:

1 Unplug the appliance from the electrical outlet.

2 Remove and empty the cup and ensure that no food is

jamming the Pro Extractor Blades Assembly.

3 Allow the appliance to cool for approximately 30

minutes.

4 Re-install the cup onto the base and re-plug the

appliance into the electrical outlet.

5 Proceed to use the appliance as before while making

sure not to exceed the recommended maximum capacities.

www.ninjakitchen.com

Page 12

Troubleshooting Guide

PROBLEMS POSSIBLE REASONS & SOLUTIONS

Unit doesn't turn on

• Make sure the unit is plugged in

• Insert and rotate cup clockwise in the base until it "clicks". Display

should turn on.

Unit doesn't turn off

Lid/Pro Extractor Blades Assembly hard to assemble

Food is not evenly chopped

Doesn't mix well, food gets stuck.

Unit moves on counter while blending

Unit is difﬁcult to remove from counter for storage

• Remove cup from base by rotating cup counter clockwise and lifting out.

Display should turn off. Unplug the power cord from the outlet.

• Set the cup on a level surface. Place the lid or Pro Extractor Blades

Assembly on the top of the cup and align the threads so that the lid/ blades sit ﬂat on the cup. Twist clockwise so that the lid/blades evenly align to the cup until you have a tight seal.

• For best results when chopping, make sure all ingredients are as dry

as possible. Cut pieces down to even sizes, and reduce the amount of food in the cup. Use very short pulses by quickly pressing the "PULSE" button.

• Using the AU TO-iQ

results. The pulses and pauses allow the food to settle towards the blade. If food is routinely getting stuck adding some liquid will usually help.

™

programs is the easiest way to achieve great

• When packing the cups, start with fresh items, then powders/nuts. Add

liquids, and ﬁnally frozen items or ice.

• Make sure the surface as well as the feet of the unit are clean and dry.

• Tip unit forward from the back to easily disengage the suction feet.

Replacement Parts

ORDERING REPLACEMENT PARTS

To order additional parts and attachments, please visit our website: www.ninjakitchen.com or feel free to contact customer service: 1-877-646-5288.

1-877-646-5288

Page 13

Sample Recipes

Watermelon Cooler

Ingredients:

¼ pear, seeded, cut into chunks 2 large fresh basil leaves with stems removed 2 cups chilled watermelon, seeded, cut into chunks

Directions:

1. Place all ingredients in the order listed above into the Nutri Ninja® 24 oz. cup.

2. Lock cup onto the base and select AUTO-iQ™ BLEND

Purple Potion

Ingredients:

¾ cup beets, peeled, cut into chunks 1 cup frozen blueberries 1¼ cup carrot juice

Directions:

1. Place the beets with 2 cups of water into a small saucepan over medium heat and cook until tender. Drain, cool completely and set aside.

2. Place all the ingredients in the order listed above into the Nutri Ninja® 24 oz. cup.

3. Lock cup onto the base and select AUTO-iQ™ ULT R A BLE ND

Easy Weeknight Burgers

Ingredients:

8 ounces London Broil, trimmed of fat, cut into 2-inch pieces Kosher salt and fresh ground black pepper to taste 2 hamburger buns, sliced Toppings of choice

Directions:

1. Place the meat in the Ninja 24 ounce cup. Lock cup into base and press START|STOP for 15 seconds.

2. Season ground meat with salt and pepper and form into two patties.

3. Lightly coat a nonstick skillet with cooking spray. Over medium heat, cook the burgers to desired

doneness, about 4-5 minutes per side for medium.

4. Serve each burger on a bun with toppings of choice.

www.ninjakitchen.com

Page 14

Notes

1-877-646-5288

Page 15

NINETY (90) DAY REFURBISHED PRODUCT LIMITED

WARRANTY

SharkNinja Operating LLC warrants this product to be free from material defects and workmanship for a period of ninety

(90) days from the date of purchase when utilized for normal household use, subject to the following conditions, exclusions and exceptions.

The liability of SharkNinja Operating LLC is limited solely, at our option, to either: 1) the cost of the repair or replacement of the unit with a refurbished unit; or 2) an upgrade to a similar model refurbished unit of equal or greater value. Replacement units/parts will be warranted for the remaining portion of the original (90) ninety day warranty period.

This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been tampered with or used for commercial purposes. This Limited Warranty does not cover damage caused by accident, misuse, abuse, negligent handling, incorrect voltage, vandalism, unsuitable environments, damage due to faulty packaging or mishandling in transit, natural disasters or other damages beyond SharkNinja Operating LLC ’s control. This Limited Warranty does not cover damage or defects caused by or resulting from damages from shipping or repairs, service or alteration to the product or any of its parts, which have been performed by a repair person not authorized by SharkNinja Operating LLC . Since this unit has been represented and sold as a refurbished item, this Limited Warranty does not apply to cosmetic damages or defects, including, but not limited to, scratches, scuffs, dents, or dings. Operating the unit in violation of the instructions in the owner’s manual will void the warranty terms.

If your appliance fails to operate properly while in use under normal household conditions within the Limited Warranty period, you may return the complete appliance and accessories with proof of purchase and date, freight prepaid. For Customer Service support and product specialists, call 1-877-646-5288 or visit our website ninjakitchen.com.

If the appliance is found by SharkNinja Operating LLC to be defective, in SharkNinja Operating LLC ’s sole discretion, we will repair or replace it as set out in the second paragraph above free of charge. Proof of purchase date and a check made payable to SharkNinja Operating LLC in the amount of $19.95 to cover the cost of return shipping and handling must be included.*

This Limited Warranty is extended to the original purchaser of this refurbished unit and excludes all other legal, implied and/or conventional warranties. The responsibility of SharkNinja Operating LLC if any, is limited to the speciﬁc obligations expressly assumed by it under the terms of this Limited Warranty. In no event is SharkNinja Operating LLC liable for incidental or consequential damages to anyone of any nature whatsoever. Some states do not permit the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.

This Limited Warranty gives you speciﬁc legal rights, and you may also have other rights which vary from state to state or from province to province.

*IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase date and to attach tag to item before packing with your name, complete address and phone number with a note giving purchase information, model number and what you believe is the problem with the item. We recommend you insure the package (as damage in shipping is not covered by your Limited Warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”.

PRODUCT REGISTRATION

Please visit www.ninjakitchen.com or call 1-877-646-5288 to register your new Ninja® product within ten (10) days of purchase. You will be asked to provide the store name, date of purchase and model number along with your name and address.

The registration will enable us to contact you in the unlikely event of a product safety notiﬁcation. By registering you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying instructions.

www.ninjakitchen.com

Page 16

SharkNinja Operating LLC

US: Newton, MA 02459 CAN: Ville St-Laurent, QC H4S 1A7

1-877-646-5288

www.ninjakitchen.com

Ninja, Nutri Ninja, Pro Extractor Blades and Sip & Seal are registered trademarks of SharkNinja Operating LLC.

AUTO-iQ is a trademark of SharkNinja Operating LLC.

Illustrations may differ from actual product. We are constantly striving to improve our products, therefore the speciﬁcations contained herein are subject to change without notice.

For Shark Ninja U.S. Patent information visit www.sharkninja.com/USPatents

Printed in China

BL480REF_IB_151123_1
