Unleashing productivity
with unsurpassed
cleaning agility
Efficient | Effective, single-pass cleaning
Rugged | Heavy-duty, durable construction
Versatile | Adaptable for the way you work
Tough on dirt.
Easy on operators.
Experience the combination of effortless control and
efficient, sustainable scrubbing in one powerful, compact
package: the Advance SC6500™ rider scrubber. The tight
turning radius, simple operation and up to 48 inch cleaning
Efficient scrubbing.
path of the SC6500 makes cleaning the dirtiest floors a
breeze for virtually anyone.
With the tightest aisle turn in its class and large, 70 gallon solution
and recovery tanks to maximize scrubbing time, the SC6500 helps you
get the job done faster. And, with a high power scrub deck, a single
pass is all you need to get an amazingly clean floor.
Rugged construction.
Don’t let the smooth, precise acceleration of its maintenance-free
AC brushless propulsion drive fool you. With an industrial bumper,
frame-mounted deflectors and a tubular, steel construction all
specifically engineered for the most severe industrial applications,
the SC6500 is as tough as they come and built to last.
Available with
TrackClean
Centralized Fleet Management
Versatile operation.
The SC6500 represents cleaning the way it should be—that is, exactly
how you want it. With the optional EcoFlex™ system that allows you
to use only the amount of chemical needed, an offset scrub deck
that effectively cleans hard-to-reach edges and an ergonomic design
compatible with your operators, the SC6500 easily adapts to the
conditions you throw at it.
The Advance EcoFlex™ System
1
provides customizable settings to
save water, chemical and brushes
Heavy-duty adjustable Linatex® side
2
squeegees provide appropriate down
pressure to leave floors completely dry
7
1
10
9
8
3
4
Yellow color-coded touch points simplify
3
routine maintenance
Maintenance-free AC brushless
4
propulsion drive delivers quiet, reliable,
powerful and efficient performance
Frame-mounted rollers protect scrub
5
deck from impact damage
Dual side brooms (cylindrical models)
6
deliver true edge cleaning and prevent
debris from fouling squeegees
High capacity 70 gallon tanks boost
7
scrub time productivity
Optional dual vac system enhances
8
water pickup on rough floors, even
at high speeds
High-traction, non-marking, industrial
9
wheels improve stability and control
2
Dual-disc brakes provide complete
10
5
6
stopping power even on wet floors
Clear-View™ design and adjustable tilt steering
column enable an ergonomic ride for most
operators.
Large One-Touch™ controls make operation
easy and accessible.
Powerful offset scrub deck provides edge and
high productivity cleaning in a single pass.
Removable, high capacity detergent
cartridge for sustained flexible cleaning is
available with optional EcoFlex™ System.
Under the hood.
SC6500™ Specifications
Models SC6500™ 40C SC6500™ 45C SC6500™ 48C SC6500™ 40D SC6500™ 45D SC6500™ 48D
Scrub Deck Type Cylindrical Disc
Scrub Path 40 in (102 cm) 45 in (114 cm) 48 in (122 cm) 40 in (102 cm) 45 in (114 cm) 48 in (122 cm)
Scrubbing Coverage Rate Per Hour (Max.) 96,800 108,900 116,200 96,800 108,900 116,200
Scrub Brush Size 40 in x 8.5 in
Scrub Brush Speed 630 rpm 240 rpm 225 rpm 225 rpm
Brush Motor Power 2 x 1.5 hp (1.13 kW) 1 x 3.0 hp (2.24 kW) 3 x 1.5 hp (1.13 kW) 3 x 1.5 hp (1.13 kW)
Sweeping Path 57 in (145 cm) –
Debris Hopper Capacity 0.40 ft3 (11 L) 0.44 ft3 (12.5 L) 0.50 ft3 (14 L) –
Solution/Recovery Tank Capacity 70 gal (265 L)
Vacuum Motor 0.8 hp (0.6 kW) - dual vac optional
Waterlift Single Vac - 64 in (163 cm) / Dual Vac - 67 in (170 cm)
Battery Options / Maximum Run Time* 36 V, 420 Ah C20 – Up to 3.0 hrs. – 40 Cyl / 3.5 hrs. – 40 Disc
Propulsion System Variable speed AC brushless drive
Propel Speed Forward 6.0 mph (9.5 km/h)
Propel Speed Reverse 3.0 mph (5 km/h)
Propel Motor (Peak) 3.0 hp (2.25 kW)
Gradeability Transport @ Gross Weight
Scrubbing
Length 74 in (187 cm)
Width 48 in (121 cm) 54 in (136 cm) 56 in (141 cm) 43 in (108 cm) 52 in (131 cm) 53 in (133 cm)
Height 50 in (149 cm)
Minimum Aisle Turn 84 in (214 cm)
Weight GVW
Empty
Sound Level IEC 60335-2-72, ISO 11201* 70 dB A
Specifications subject to change without notice.
*Run-time will vary based on machine configuration and operating conditions.
(102 cm x 22 cm)
3,325 lb (1,508 kg)
2,897 lb (1,314 kg)
45 in x 8.5 in
(114 cm x 22 cm)
36 V, 450 Ah C6 (monoblock) – Up to 3.75 hrs. – 40 Cyl / 4.75 hrs. – 40 Disc
3,365 lb (1,508 kg)
2,937 lb (1,332 kg)
Scrubbing and Recovery Systems
48 in x 8.5 in
(122 cm x 22 cm)
Battery and Propulsion System
Dimensions / Weight / Sound
3,410 lb (1,547 kg)
2,982 lb (1,353 kg)
2 x 20 in (51 cm) 3 x 16 in (41 cm) 3 x 17 in (43 cm)
16% (9°)
10.5% (6°)
3,220 lb (1,460 kg)
2,792 lb (1,266 kg)
3,270 lb (1,483 kg)
2,842 lb (1,289 kg)
3,320 lb (1,506 kg)
2,892 lb (1,312 kg)
SC6500
Optional Accessories:
• Tubular steel heavy duty bumper
• Heavy duty front bumper
• Deluxe Grammer seat and seat belt kit
• Refillable detergent cartridge
• CoolTool scrub and vac wand kit
• Recovery tank drain hose extension
• Floor mat kit
• 2nd vac motor kit
™
• Warning beacon kit
• Front headlight kit
• Back-up alarm kit
• Seat belt kit for standard seat
• Overhead guard
• Operator foot guard kit
• Solution auto-fill kit
• Battery roll out kit for 450 Ah C6 battery
(batteries not included)
TrackClean
Centralized Fleet Management
Increase productivity with TrackClean asset management technology installed on
your fleet of machines to monitor, verify and improve operational effectiveness.
Learn more: http://www.advance-us.com/TrackClea
Visit http://www.advance-us.com/SC6500 or contact your
Advance sales representative to learn more.
